Members Mark GL-1268-ARP User manual

Dream day lounger with 4pcs toss pillow
Model Number: GL-1268-ARP
THIS ASSEMBLY MANUAL CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Assembly Manual

Important Safety Information
Please read all instructions carefully before assembling this furniture.
For your safety, assembly by two or more adults is strongly recommended.
Use only vendor-supplied hardware to assemble this item. Using unauthorized
hardware could jeopardize the structural integrity of the item.
Hardware may loosen overtime. Periodically check that all connections are tight.
Remove all parts and hardware from the box. Place all items on a carpeted or
scratch-free work surface, as this will avoid damaging parts during assembly.
The shipping box provides an ideal work surface.
To avoid accidentally discarding small parts or hardware, do not dispose of any
packaging or contents of the shipping carton until assembly is complete.
Use the parts and hardware lists below to identify and separate each of the
pieces included.
The use of power tools for assembly is not recommended. Power tools can
damage the hardware.
Note: Do not fully tighten all bolts until all parts are in place. Failure to follow
these instructions may cause the bolts to misalign during assembly.
Before Assembly
Dust often and use a vacuum cleaner crevice tool to clean seams. To maintain
the woven appearance, gently clean soiled areas with a soft cloth dampened
with a mild, water based detergent. Remove all lather and wipe with a clean
damp cloth. Dry with another soft cloth by blotting the damp surface (do not
rub).
Care and Cleaning

Components
A....Left panel....1
B....Right panel....1
Hardware
(J)
Allen/Hex Head Bolt
M6x25mm
Qty: 25
(K)
M6 Washer
Qty: 38
(L)
Allen/Hex Head Bolt
M6x40mm
Qty: 10
E
C....Front cross beam....1
FH
D....Back cross beam....1
E.......Ceiling...1
F....Back panel....1
G....Seat panel....1
H....Back connector panel....1
I......Middle leg....3
ABC D
G I
(M)
Allen/Hex Head Bolt
M6x120mm
Qty: 3
(N)
Canopy
Qty: 1
(O)
Allen Wrench
Qty: 2
(P)
Seat cushion
Qty: 1
(Q)
Back cushion
Qty: 1
(R)
Side cushion
Qty: 2
(S)
Toss pillow
Qty: 4
Need Assistance? Visit us at: samsclub.com/membersmarkhelp

Carefully place the Left panel (A) and Right panel (B) on a non-abrasive surface.
Assemble the front cross beam (C) and back cross beam (D) to the left panel(A) and
back panel(B) with bolts (J) and washer (K) by using Allen wrench (O).
Do not tighten the bolts until assembling is completed.
Step 1
(J)
Allen/Hex Head
Bolt M6x25
Qty: 16
(K)
M6 Washer
Qty: 16
(O)
Allen Wrench
Qty: 1
Need Assistance? Visit us at: samsclub.com/membersmarkhelp

Attach the ceiling (E) to the front cross beam (C) and back cross beam (D) using bolts
(J) and washers (K) with Allen Wrench (O).
Do not tighten the bolts until assembling is completed.
Step 2
Step 3
Attach the back panel(F) to the left panel (A) and right panel (B) using bolts (J) and
washers (K) with Allen Wrench (O).
Do not tighten the bolts until assembling is completed.
Need Assistance? Visit us at: samsclub.com/membersmarkhelp

Step 4
Attach the seat panel (G) to the left panel (A) and right panel (B) using bolts (L) and
washers (K) with Allen Wrench (O).
Do not tighten the bolts until assembling is completed.
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
(L)
Allen/Hex Head
Bolt M6x40
Qty: 10
(K)
M6 Washer
Qty: 10
(O)
Allen Wrench
Qty: 1
(J)
Allen/Hex Head
Bolt M6x25
Qty: 3
(K)
M6 Washer
Qty: 6
Step 5
(O)
Allen Wrench
Qty: 1
(M)
Allen/Hex Head
Bolt M6x120
Qty: 3

Step 6
Attach the back connector panel (H) to the seatt panel (G) and back panel (E) using
bolts (J & M) and washers (K) with Allen Wrench (O).
Tighten all bolts (J,M and K) with Allen wrench (O) .
Attach the middle legs (I) to under the seat panel (G) using bolts (J) and washers (K)
with Allen Wrench (O).
Tighten all bolts with Allen wrench (O) .
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
(J)
Allen/Hex Head Bolt
M6x25mm
Qty: 6
(K)
M6 Washer
Qty: 6
(O)
Allen Wrench
Qty: 1

Crefully turn the table over.
Place the seat cushions (P), back cushion (Q), side cushion (R) and toss pillow (S) on
the day lounger.
The day lounger is ready for your enjoyment.
Step 7
Step 8
S
S
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
Crefully turn the daybed over.
Attach the Canopy (N)on the daybed.
