Members Mark TPGAZ2029 Owner's manual

THIS ASSEMBLY MANUAL CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Customer Assistance (spare/replacement parts):1-800-847-7508
or Email: [email protected]
Item Number: 980298079
Model Number:TPGAZ2029
DISCLAIMER: Supplier is fully responsible for the entire content of the assembly
manual, including all Sam’s Club suggested edits or revisions.
Assembly Instructions & User’s Manual
for
Member’s Mark [10'x12'ALAMEDA HARDTOP GAZEBO]
1
TM

2
Table of Contents
Quality Statement ..........................................................................................3
Important Safety Information..........................................................................3
Before Assembly............................................................................................3
Care & Use.....................................................................................................3
Product Information........................................................................................3
Components...................................................................................................4
Hardware........................................................................................................6
Tools...............................................................................................................6
Step 1 – Step 3...............................................................................................7
Warning..................................................................................................18
Danger....................................................................................................18
Care & Use and Storage Instructions.............................................................18
Warranty Information......................................................................................19

3
Product Information
Product Dimensions:127.56” x 151.57” x 111.02” (324cm x 385cm x 282cm)
Product Weight Capacity: Supports up to 220lbs(100kg)
Remove all parts and hardware from the box. Place all items on a carpeted or
scratch-free work surface, as this will avoid damaging parts during assembly.
The shipping box provides an ideal work surface.
To avoid accidentally discarding small parts or hardware, do not dispose of any
packaging or contents of the shipping carton until assembly is complete.
Use the parts and hardware lists below to identify and separate each of the
pieces included.
The use of power tools for assembly is not recommended. Power tools can
damage the hardware and/or split the wood.
Note: Do not fully tighten all bolts until all parts are in place. Failure to follow
these instructions may cause the bolts to misalign during assembly.
Before Assembly
Care & Use
Quality Statement
Important Safety Information
Please read all instructions carefully before assembling this gazebo.
For your safety, assembly by two or more adults is strongly recommended.
Hardware may loosen overtime. Periodically check that all connections are tight.
NOTICE: To prevent injury and property damage from unexpected tipping of
furniture, we highly recommend installation of the anti-tip kit included with this
product.
For cleaning, use a mild detergent solution, rinse with water, and allow to air dry.
Do not use acetone, abrasive, or other special detergents as they would be harmful
to the product’s finish.
Due to the nature of metal, surface oxidation (rusting) will occur if this protective
coating is scratched.
This is a natural process. To minimize this condition, it is recommended that care
be taken when assembling and handling the product in order to prevent the paint
from being scratched.

AUpper Central
Connector
Lower Central
Connector
1
B1
C
Long Top Bar
Short Top Bar
4
D6
E1 Left Lintel
Left Lintel
Right Lintel
Right Lintel
2
E2
Connector
2
2
2
E4
E3
F4
G1 Left Support
Bar
Right Support
Bar
4
G2 4
Components
H Connector 6
ICorner
Connector 4
J Post 4
K
Base
Roof Support
-Left Top
Roof Support
-Right Top
Roof Support
-Left Middle
Roof Support
-Right Middle
Roof Support
-Upper Middle
and MiddleTop
Roof Support
-Lower Middle
Roof Support
-Left Bottom
Top
Connector 4
L4
N1 4
N2
O1
O2
O3
O4
P1
4
4
4
4
4
2
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
4
Roof Support
-Right Bottom
P2
Top Panel
Cover
4
Q 4
Mosquito Net
Lintel Cover
R4
S4
T Hook 1
21.85" / 555mm
21.85" / 555mm
41.73" / 1060mm
41.73" / 1060mm
22.24" / 565mm
22.24" / 565mm
59.53" / 1512mm
59.53" / 1512mm

Edge Cover
-Short Right
Edge Cover
-Long Left
Edge Cover
-Long Right
U3
U4
U2 2
2
2
(1) Roof Panel
Roof Panel
Roof Panel
Roof Panel
Roof Panel
Roof Panel
Roof Panel
4
(2) 4
Components
(3)
(4)
(5)
(6)
(7)
2
4
4
2
2
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
5
Edge Cover
-Short Left
U1
2

AA M6*15 238
BB Bolt/Plastic Washer
Bolt/Flat Washer
Bolt/Flat Washer/Nut
M6*25
Bolt/Plastic Washer
M6*35
20
CC
M6*55
Bolt M6*15
DD
8
8
16
FF
Spacer 18
GG
Hanger 44
HH
Stake 12
II
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
Hardware
6
Tools
Part No:EE
Wrench (Included) Allen Wrench (Included) Hammer(Not Included)
Qty: 2Part No:JJ Qty: 1
Safety goggles
(Not Included)
Stepladder
(Not Included)
Electric drill
(Not Included)
Gloves
(Not Included)
Hardhat
(Not Included)

J
J
AA
AA AA
Fig 1
L
1- a. Connect Base (L) and Post (J) with Bolt/Flat Washer M6*15(AA).
Step 1
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
(AA)
Bolt/Flat Washer (M6X15) Bolt (M6X15)
Qty: 128
(FF)
Qty: 16
Hanger
(HH)
Qty: 44
(EE)
Wrench
Qty: 1
(KK)
Allen Wrench
Qty: 1
7

E1
E3
E3
E1
E4
H
H
H
H
H
F
F
E1 E2
E4
E2 E2
AA
AA
AA
AA
E4E4
Fig 2
E2
E3
AA
H
1-b. Insert the Hanger (HH) into the track of Right Lintel (E2). Insert the Connector (F) into Left Lintel
(E1)/Right Lintel (E2), at the same time connect it to Left Lintel (E1)/Right Lintel (E2) by the Connector
(H) with Bolt/Flat Washer M6*15(AA). Insert the Hanger (HH) into the track of Right Lintel (E4 ).
Insert the Connector (F) into Left Lintel (E3)/RightLintel (E4).
Connect the Connector (H) to Lintel (E3/E4) by with Bolt/Flat Washer M6*15(AA). See Fig.2.
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
8
HH
×12PCS
HH
×10PCS

Attach the lintel (E3/E4) to Post (J) with Bolt/Flat Washer M6*15(AA)/Bolt M6*15(FF) .See Fig.3-4
Attach the lintel (E1/E2) to Post (J) with Bolt/Flat Washer M6*15(AA)/Bolt M6*15(FF) .See Fig.6-7
E1
E1
J
J
J
J
E4
E4
E4
FF
AA
Fig 6 Fig 7
E3
E3
E1
E1
G1
G1
G1
G1
G2
G2
G2
G2
J
J
J
J
E4
E3 E2
E2
E4
1-d.
A ttach the Righ t Support Bar (G1/G2) to Lintel(E3/E4) and Post(J) with Bolt/Flat Washer M6*15(AA).
See Fig.5
1-c.
G2
J
E4
AA
J
JE3/E4
E3/E4
FF
AA
Fig 3 Fig 4
Fig 5
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
9

E1
G1 G2
J
E4
AA
Fig 8 Fig 9
E3
E1
E1
J
J
J
J
E4
E2
E2
E4
E3
Attach the Left Support Bar(G1) to Left Lintel(E1) and Post(J) with Bolt/Flat Washer M6*15(AA),
attach the Right Support Bar (G2) to Right Lintel(E2) and Post (J) with Bolt/Flat Washer M6*15(AA),
Attach the Top Connector(K) to Post (J) with Bolt/Flat Washer M6*15(AA).See Fig.8-9
1-e
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
10
E1
K
J
E4
Equal diagonal distance
AA
Fig 10 Fig 11
E1/E3
I
R
E1
E2/E4
E4
1-f. Attach the Corner Connector (I) to the Right Lintel (E4) and Left Lintel (E1) with Bolt/Flat Washer
M6*15(AA).
Bolt/Flat Washer M6*15(AA),
Attach the Corner Connector (R) to the Left Lintel (E1) and Lintel (E2) with Bolt/Flat Washer M6*15(AA),
Attach the CornerConnector (R) to the Lintel (E3) and Right Lintel (E4) with
See Fig.10-11
AA AA

Step 2
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
(AA)
Qty: 86
(BB)
Qty: 2
11
H
H
H
H
E1
C
CC
E1
E4
E4
E2
E2
E3
E3
(EE)
Wrench
Qty: 2
Bolt/Flat Washer/Nut
(M6X55)
(DD)
Qty: 8
Bolt/Flat Washer
(M6X15)
Bolt/Plastic Washer
(M6x25)

B
C
CAA
C
C
C
C
B
C
C
C
C
C
C
Fig.12
2-a.
Attach Long Top Bar (C) to Lower Central Connector (B) with Bolt/Flat Washer M6*15(AA),
See Fig.12
Attach the long Top Bar (C) to Top Connector (K) with Bolt/Flat Washer /Nut M6*55 (DD),
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
12
DD
K
C
J
E1
E2
E1
E3
E1
E4
E2
E4
E2 D
D
D
D
D
E3
AA
C
D
B
C
C
C
AA
H

2-b. Attach Short Top Bar (D) to Lower Central Connector (B) with Bolt/Flat Washer M6*15(AA),
attach Short Top Bar (D) to Connector (H) with Bolt/Flat Washer M6*15(AA), using the
same method to attach others. See Fig.13
Fig.13
D
D
D
AA D
C
B
D
B
C
C
D
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
13
Fig.14
BB
T
D
C
C
BB
C
C
B
A
A
D
D
D
D
2-c . Attach Upper Central Connector (A) to Lower Central Connector (B) with Bolt/Plastic
Washer M6*25(BB), at the same time Screw the hook(T) to the Upper Central
Connector (A) and twist to tighten.See Fig.14.

Fig.15
O1
O1
D
N1
C
N2
O2
O2
D
AA
N2
O3
N2
O2
O3
AA
AA
C
C
N2
N1
C
N1
D
D
C
O1
D
AA CAA
AA
N2
O3
N1
D
AA
C
AA
AA
D
AA
N2
N1
N1
C
AA
2-d Attach the Roof Supports-Left Top (N1) /Roof Supports-Right Top (N2) / Roof Supports-Left
Middle (O1) / Roof Supports-Right Middle (O2) tothe Long Top Bar (C) with Bolt/Flat Washer
M6*15(AA).
Attach the Roof Supports-Left Top (N1) /Roof Supports-Right Top (N2) / Roof Supports-Left
Middle (O1) / Roof Supports-Right Middle (O2) /Roof Supports-Upper Middle and MiddleTop
(O3) to the Short Top Bar (D) with Bolt/Flat Washer M6*15(AA).See Fig.15-16.
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
14
Fig.17 Fig.18
Fig.16
DD
D
D
C
C
C
C
P1
O4
O3
P1
P1
P1
P2
P2
P2
P2
AA
P1
P2/O4
D
AA
AA
P2
P1
C
AA
2-e. Attach Roof Supports-Left Bottom (P1) toLong top Bar (C)/Short Top Bar (D) with Bolt/Flat Washer
M6*15(AA).Attach Roof Supports-Right Bottom (P2) toLong top Bar (C)/Short Top Bar (D) with Bolt/Flat
Washer M6*15(AA).Attach Roof Supports-Lower Middle (O4)toShort Top Bar (D) with Bolt/Flat M6*15
(AA).See Fig.17-18.

Step 3
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
(BB)
Bolt /Plastic Washer (M6X25) Bolt /Plastic Washer (M6X35)
Qty: 18
(GG)
Spacer
Qty: 18
(CC)
Qty: 8
(EE)
Wrench
Qty: 1
15
(AA)
Bolt /Flat Washer(M6X15)
Qty: 24
1
1
2
2
3
4
5
4
6 7
10' side
12' side
5

IMPORTANT:
● Make sure each screw installed on this step is attached to a spacer (GG).
● Wait at the end of the installation of the roof panels before tightening all screws.
If you do not wait and tighten from the beginning, you will not be able to correctly
install all the roof panels.
BB
7
6
5
4
J
U1
U2 U3
U4 J
J2
1
4
5
3
2
1
GG
Plastic Washer
O1//O2/O3
3-a. Install the roof panel starting from left to right.
Attach all the roof panels show as Figure toRoof Support (O1/O2/O3) with Bolt/Plastic Washer
M6*25(BB) and Spacer (GG).Repeat on each side.See Fig.19.Tighten all bolts.
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
16
3-b. Connect Edge Cover (U1/U2/U3/U4) to Lintel (E1/E2/E3/E4) with Bolt/Flat Washer M6*15(AA).
See Fig.20
Fig.20
Fig.19
U4
U1
E4 E1
AA

3-c. Place Top Panel Cover (Q) on the top of Top Bar (C) and then insert Top Panel Cover (Q) into the
gap between Upper Central Connector (A) and Long Top Bar (C). Then attach Top Panel Cover (Q)
to Long Top Bar (C) with Bolt/Plastic Washer M6*35 (CC).See Fig.21-22.
Fig.21 Fig.22
Plastic Washer
Q
CC
CC
Q
Q
A
CC
C
A
CC
C
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
17
Fig.24
3-d.Hang Mosquito Net (S) on the Hanger (HH). See Fig.23.
3-e. Adjust position of gazebo and anchor posts to the ground
by inserting Stakes (II) into each hole in each Base Plate.
See Fig.24
Yourgazebo isnow completely assembled.
S
Fig.23
S
HH
E1/E2/E3/E4
II
II
II

Need Assistance? Visit us at: samsclub.com/membersmarkhelp
18
KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS TENT FABRIC.
This tent meets the flammability requirements of CPAI-84. The fabric may burn if left in
continuous contact with any flame source. The application of any foreign substance to
the tent fabric may render the flame-resistant properties ineffective.
Danger
• DO NOT use or enter the gazebo under harsh weather (e.g. thunderstorms,
high winds, hail, heavy snow etc.). In these conditions, it might tip over and could
cause serious injury to bystanders. Any damage or injury caused by these conditions
is not covered by the warranty.
• DO NOT install the gazebo adjacent to trees or a sloped roof. Snow and ice may
slide onto the gazebo and cause it to collapse.
• DO NOT use or enter the gazebo if there exist any of the following or of similar
conditions:
1. visible movement of support members, roofing panels or sagging roofline.
2. cracks, fractures or malformation of support member or roof panels.
3. damaged or missing fasteners.
• DO NOT hang any weights on the roof frame.
• DO NOT use ladder leaning against the gazebo or climbing onto the roof.
• Keep away from heat or flame source.
• If the gazebo will not be used for a long period of time (e.g. during winter time),
disassemble and store it in a clean, dry location.
Care&Use Instructions
• Our steel components for gazebo and garden accessories are treated with
rust inhibiting paint that protects it from rusting. However, due to the nature of steel,
surface oxidation (rusting) will occur if these protective coatings are scratched.
This is not a defect and thus not covered by the warranty.
To minimize this condition, we recommend care when assembling & handling the
product to prevent scratching the paint. Should any scratching or damage occur, we
recommend immediate touch-up with rust inhibiting paint.
Surface rust can also be easily removed with a very light application of regular
cooking oil. If surface oxidation (rusting) occurs and if no preventive measure is taken,
the oxidation may start dripping onto deck or patio and caused damaging stains,
which may be difficult to remove.
This damage can be prevented if the above-mentioned measures are taken to keep the
gazebo’s frame from oxidizing.
• Do not use bleach, acid, or other abrasive cleaners on the roof or frame parts.
• Keep instruction manual for future reference.
• Keep the original packaging to store the gazebo.
WARNING

AA 15
BB Bolt Plastic Washer
M6*25
Bolt Plastic Washer
M6*35
5
CC
Bolt M6*15
DD
2
2
2
FF
Spacer
3
GG
Hanger
5
HH
Spare Parts
Distributed by Sam’s West Inc.
2101 SE Simple Savings Dr.
Bentonville, Arkansas 72716-0745
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
19
This product component has a 1 year guarantee against defects in material
and/or workmanship. If you have any questions regarding the warranty or spare
/ replacement parts, please call our toll-free number
1-800-847-7508 or email
us at
[email protected]
NOTE: Please consider recycling all applicable packaging material.
Warranty Information
Bolt/Flat Washer
M6X15
Bolt/Flat Washer/Nut
M6*55

Need Assistance? Visit us at: samsclub.com/membersmarkhelp
Need Assistance? Visit us at: samsclub.com/membersmarkhelp
20
MADE IN CHINA
