1
DCP
Digital Communication Platform
Installation Guide
Ref No MC-xCM10 850 ML Version 4
Part numbers:
2G (RS232): MC-2CM10-100-F-20-000
3G (RS232): MC-3CM10-100-F-20-000
In the Box
+ 2G or 3G DCP
+ Antenna
+ P-5 H-2V connector (x1)
+ P-3.5 H-4V connector (x1)
+ P-10 H-2V connector (x1)
+ Grey clamp (x2)
+ Manual
2G (RS422/ 485): MC-2CM10-100-F-40-000
3G (RS422/ 485): MC-3CM10-100-F-40-000
Not Included
+ Screwdriver
+ SIM card
PRODUCT DESCRIPTION
The Digital Communications Platform (DCP) provides an information gateway between
all compatible connected Avire devices in the lift shaft and our online monitoring
platform the Avire Hub. The product is installed as a stand-alone device and doesn’t
require connection to the controller panel.

2
ELEVATOR SAFETY
Please follow all Health and Safety rules & take all necessary precautions before and
during installation.
SETTING UP THE DCP
Avire SIM cards come activated and ready to be installed. If a non-Avire SIM card is
used, please make sure that the SIM card is activated and unlocked.
3. Connect the antenna on the DCP to J2 and
ensure it is completely tightened.
NOTE: Only use antennas authorised by Avire.
4. Connect the battery to J3.
5. Wait for the LED lights to turn on.
Check the SIM LED to make sure it is
green or amber (check step 10). If it’s
ashing red check it’s been inserted
correctly and then unlock the SIM
card using instructions on page 4.
6. Check the signal strength by using the built-in
network signal strength scanner. To use the signal
scanner function:
+Turn SW1 dipswitch 1 to ON (check dipswitch 4 is
also ON)
Please refer to pages 12 and 13 for the full picture
and connector information
1. Open the DCP with a PZ1 screwdriver.
2. Insert SIM into J4, pushing the SIM until it click.
SIM0
J2
J3
J4
SW1

3
+LEDs on the front of the DCP unit will show the network signal level
+
+
+
+
+
+
+
+
+
+
You can check the status of the power supply, battery, connection, coverage or
Phone Line (SLIC) at any time by referring to the LED Indicators (page 14).
7. Connect the power supply 230VAC to J6 using the 3pin connector supplied with
the unit.
Note: The signal scanner will
indicate the best location for the
device to receive signal, Network
coverage will vary based on local
conditions.
+Once nished turn SW1 dipswitch 1 back to OFF.
Neutral
Live
SW1
J6

4
8. Clamp the power cable using the grey clamp provided inside the box.
9. Place the lid back on the top of the DCP and fasten the lid with the screw.
10. Turn on the power to the DCP. The RUN LED on the DCP should change colour
from ashing amber to ashing green when the mains power connection is made.
If you see any other colour, please consult the LED Indication list on page 14.
RUN LED ashes green Power supply is OK
BAT LED is always on Battery is OK
SIM LED is green or amber Device is connected to the network
Coverage LED is green or amber Good coverage
SLIC LED is green Device is in standby
J6
11. To x the device in position, drill two holes in the wall and insert the plugs and
screws provided with the device. Hang the DCP on these two points using the tear-
shaped holes at the back box of the DCP (mid points of holes are 105mm apart).
12. If a non-Avire SIM card is used, APN settings must be set prior to conguring it on
the Avire Hub; please refer to “Setting Parameters on non-Avire SIM cards” (page
5). If the SIM LED is ashing red, please see “SIM Card unlocking” (see page 4).

5
SIM CARD UNLOCKING
Important Note: An Avire SIM card doesn’t have a SIM PIN code; if the SIM LED is
ashing red, please make sure that the SIM card has been inserted correctly. The SIM
PIN code for other network providers may vary and it can usually be
found on the outer plastic case of the SIM card.
OPTION 1
Disable the blocking PIN code using a conventional mobile phone. Plug the SIM into a
dierent mobile device and delete SIM PIN code in the device settings.
OPTION 2
You can program the PIN code of the SIM card into the DCP using an analogue phone
plugged into to the J1A or J9 connection (please see page 12 for more details).
Enter DCP conguration mode: wait for DCP voice command
Enter SIM card PIN parameter:
xxxx is the SIM PIN code given by the service provider for SIM.
Example if SIM PIN code is required: *1# xxxx#
At this point, the SIM card LED (middle LED) will stop ashing red. If it does not, make
sure the SIM is correctly inserted and you have entered the correct PIN.
OPTION 3
You can remotely enter SIM PIN code into DCP by texting:
P1234, P090 xxxx
This option can only be used if DCP is already connected
Important Note: Check ADDITIONAL INFORMATION FOR PROGRAMMING THE DCP
on page 11 for more information.

6
SETTING PARAMETERS ON NON AVIRE SIMS
OPTION 1
Super settings allow quick and easy conguration of APN settings, depending on the
country and network provider. Congure settings for the DCP based on the tables
below.
Example:
Digit 1 0 1 2 3 4 5 6
Country Default Spain Portugal Italy UK Germany France
Digit 1 Digit 2 Digit 3
Country SIM Network Type of connection
The Digital Communications Platform comes pre-congured with factory settings of 000 (this
conguration doesn’t specify any use case or country).
Digit 2 Spain Portugal Italy UK Germany France
0default default default default default default
1AvireSim AvireSim AvireSim AvireSim AvireSim AvireSim
2Telefonica MEO Wind O2 Telekom DE Orange
3Orange NOS TIM EE ABD SFR
4Vodafone Vodafone Vodafone Vodafone Vodafone DE Bouygues Telecom
5Iliad 3 O2 DE Free Mobile
6tre(3) Virgin BASE
71P Swisscom
8Telit Telit Telit BT A1 Telit
9GiGa tmobileAT
Digit 3 0 1 2 3
Type Transparent Gateway Avire Hub P100 P100 + Avire Hub
Digit 1 Digit 2 Digit 3
Country SIM Network Type of Connection
Example
4 = (UK) 3 = (EE) 1 = (Avire HUB)
Once all digits are selected, the text
needs to be sent to the SIM card
telephone number along with the
PIN code and command. Response
should show:

7
OPTION 2
If super settings are not used, then APN settings need to be set up manually:
Command Description
P060 (P zero six zero) APN address
P061 (P zero six one) APN username
P062 (P zero six two) APN password
P063 (P zero six three) Type of connection
These parameters must be congured by sending an SMS to the SIM card number.
Examples for various regional providers are shown below:
Carrier APN name - P060 APN username - P061 APN password - P062
Vodafone UK wap.vodafone.co.uk wap wap
O2 Germany surfo2 (blank) (blank)
Orange France Orange.fr orange orange
Other APN settings are available on the web and can be easily found online. If an APN
is incorrect for the provider or is not set up correctly, the DCP will not check into the
Avire HUB.
Important Note: The default PIN code for DCP is always 1234.
Example of an SMS for single SIM card device (for example if the SIM card is from
Vodafone):
Pin1234, P060 wap.vodafone.co.uk, P061 wap, P062 wap, P063 1
If either APN username and/or APN password are (blank) (O2 Germany example) and
the DCP is congured to be used with the Avire Hub, then the text message will be:
Pin1234, P060 surfo2, P063 1
P063 0 1 2 3
Type Transparent Gateway Avire Hub P100 P100 + Avire Hub
If everything is congured correctly, you will receive a text within a few minutes:

8
Obtaining the CCID number
AVIRE SIM CARDS
Avire SIM cards come unlocked to be used with our products
immediately after plugging them in and setting correct Super settings.
You will need to know the CCID number to add this information to the
Avire Hub.
The CCID Number is shown on the back of the SIM card and also on the outer plastic
case of the SIM card (highlighted in red on the picture below).
Important Note: CCID number consists of 19 digits.
NON-AVIRE SIM CARDS
It is also possible to retrieve the CCID number by sending a SMS command to a SIM
card telephone number; the command needs to be separated by a comma as shown
below:
Pin1234, P005?
You will receive a text with the CCID number back within a few minutes; in this example,
the number shown after “P005=” is the CCID number of this SIM card.
Important note: Example CCID number is highlighted in red on picture above.
You will need to retrieve the CCID number when the DCP installation is set up on the
Avire Hub online platform. Please make sure that if this installation is set up by the
oce, they know the details for installation.

9
AVIRE HUB
Please contact your local sales oce for access to the Avire Hub.
The link to the Avire Hub is http://avirehub.avire-global.com
To view installation tutorial videos please go to the “Help” section of the Avire Hub.
Click on “Installations” in the menu on the side
and then on “Buildings”. Inside of “Buildings” tab
click on “Create Building”
Enter information relevant to your installation in General data

10
On the other side of the page please enter the number of elevator group you have in
this installation and how many elevators you have in the group. As an example, if this
is a simplex installation the number of elevator groups will be “1” and the number of
elevators will also be “1”. If it’s a duplex installation it will be “1” and “2” respectively.
You can also edit the group names to easily identify installations. Once all information
is entered click “Next”.
In the new page, you should be able to see Groups and Elevators. Click on “Add
Gateway” under “Gateway” tab and select “DCP”. A pop up window will appear where
you can enter the SIM information (Note: Avire SIMs are (+31), but this doesn’t aect
costs). Enter all required information and then click “Apply”.
Note: The Background Call Period is the frequency of test checks and 72hrs is the
maximum period as per guidance from standards.

11
Click “Save” in the left corner under the General data column.
To make sure that everything has been set up correctly click on the green DCP button.
The buttons “Access” and “Events” should now be accessible.
Click on the “Access” button.
Please click on the “Read Parameters” button. On the right hand side of the page you
will see a window with time, date and the word “Connecting” shown in green. Once
the DCP is connected to the Avire Hub parameters will appear. This means your DCP is
ready to be connected to emergency phones and other products within our Ecosystem.

12
ADDITIONAL INFORMATION FOR PROGRAMMING THE DCP
SMS COMMANDS
+All DCP parameters can be remotely congured via SMS sent to the SIM card’s number.
+Each SMS message should begin with ‘Pin1234’ which is the access code to read or make any changes to the
conguration of the DCP.
+You can modify or check several parameters in each SMS by separating them with commas ","
To send parameter information:
Text Description
Pin1234, Pzzz xxx (send) • Pin1234 is default PIN code for DCP
• Pzzz is the programming command
• xxx is the parameter
To read parameter information:
Text Description
PinXXXX, Pzzz? (send) • Pin1234 is default PIN code for DCP
• Pzzz is the programming command
• “?” is to request a parameter read
Note: Use a question mark ‘?’ when you are reading parameters.
Examples:
1. To program telephone number 1 in the DCP when connected to a DAU
E.g: Pin1234, P031 0123456789 (send, text message will come back with P031=0123456789)
2. To retrieve telephone number 1 in the DCP when connected to a DAU
E.g: Pin1234, P031? (send, text message will come back with P031= or with the programmed number)
CMD Description Default value
P005 CCID- Unique Identier of the Sim Card (19 digits)
P020
DCP Background Call Mode
P020=00 -> Transparent Protocol
P020=06 -> CAN Protocol
P020=21 -> P100 Protocol
21 (Autodialler’s need to make
Background calls in P100
Protocol)
P064 Background Call Periodicity (in Minutes) 4320 (3 days)
P030 Maintenance Alarm Number (Blank)
P031 Alarm Number 1 (Blank – Insert your alarm
number here)
P032 Alarm Number 2 (Blank)
P033 Alarm Number 3 (Blank)
P034 Alarm Number 4 (Blank)
P035 Background Number (not used with DAU)
3308084431 (must match
Background Number in
Autodialler, without prexes)
P008 Enable Guidance Message * 0 (disabled)
P085 Language 4 (English)
P091 Super settings set up 0000
P003 DCP information (software version, type of DCP) As per package
Important Note: The default PIN code for DCP is always 1234.

13
Connector Description
Description
J2 External antenna
J3 Battery
J6 Power Supply
J8 CANBus
J9/ J1A Phone line
J10 Serial connector
J11 Programmable I/O
To access dipswitches and connectors,
open the DCP case by unfastening the
front screw (using a PZ1 screwdriver) and
removing the lid.
J2 - External antenna - Connect the external antenna delivered with the kit to the
J2 connector. Only antennas approved by Avire should be used in the installation,
otherwise the device might not function properly and may be damaged.
J3 - Battery
Pin Function Signal
1+12 Positive
2GND Negative
J6 - Power Supply
Pin Function Signal
1LLive
2N Neutral
J8 - CANBus
Pin Function Signal
1VCC Unregulated
output
2CANH Bus CAN H
3CANL Bus CAN L
4GND Ground
J9/ J1A - Phone line (SLIC)
Pin Function Signal
1L1 Tip
2L2 Ring
Supply voltage: 100-240 VAC, 50/60 Hz
VCC is an unregulated output 10-21 VDC + battery
support 10-14 VDC

14
J10 CONNECTOR - RS-232 or 422/485 Serial Connector
The J10 connector is a standard serial communication port that allows the connection
of computers, controls or any other device that needs remote communication through
a reliable wireless data channel. The connectivity provided by the port is in real time
and acts as a point to point transmitter.
Pin Signal Pin Signal
2TX Out 7RTS Out
3RX In 8CTS In
5Ground Ground RS-232
Pin Signal Pin Signal
2T+ T+ RS422 7T- T- RS422
3R- R- RS422 8R+ R+ RS422
5Ground Ground RS-422
J11 - Digital Input/ Output
Pin Function Signal
1AK1 Input Outo-
Coupler
2AK2 Input Outo-
Coupler
3VCC Output 10-21
VDC
4OP1 Open collector
Mosfet N
5GND Ground

15
LED INDICATORS
The DCP has ve indicator LEDs that constantly report the device status. The indicators
will be either red, amber or green.
Each indicator will be fully on, fully o or ashing. On start-up, you should see the
following within 60 seconds:
RUN LED ashes in green. Power supply is OK
BAT LED is always on Battery is OK
SIM LED is green or amber Device is connected to the network
Coverage LED is green or amber Good coverage
SLIC LED is green Device is in standby
RUN LED
OFF
ON FLASHING
Green Amber Red Green Amber Red
CRITICAL SYSTEM ERROR
Proper
Operation (AC)
Proper
Operation
(BAT)
Restarting
System
BATTERY
OFF
ON FLASHING
Green Amber Red Orange Red
OK Charging Low DAU battery failure Error
SIM OFF ON Flashing
Green Amber Red Green Amber Red
AT
modem
Available
GSM and
GPRS
GSM
available
GPRS not
available
Out of
Service /
Initialising
Ongoing Data
Transmission
Ongoing
voice call
Sim error or
missing pin
Amber/Red Missing PUK
SLIC
OFF
ON Flashing
Green Amber Red Green
RS-232 local
conguration
Local line
ready
Initialising
local line
Local line
out of
service
Local line in use
COVERAGE
OFF
ON
Green Amber Red
AT
modem OK Medium Low
The below tables provides an overview for what each LED colour means:
Important Note: DCP shows battery status of DCP or battery failure of any attached DAU
units as per EN81-28:2018.

16
System Architectures
DCP Triphony Unit Universal Power
Display
Digital Audio Unit Induction Loop CAN Bus Splitter
PIT Phone
Lift car system architecture with DCP, DAU,
TOC Triphony Unit, Inductive Loop

17
Two lift cars with DCP, UPS, CANBus Splitter,
TOC Triphony Unit, DAU, PIT Phone.
Four lift cars with DCP, UPS, CANBus
Splitters, DAU, Triphony Units TOC,
PIT Phones
Note: There is a maximum
of two CANBus Splitters
per DCP
Two lift car system architecture with DCP,
DAU, TOC and BOC Triphony Units
Note: UPS battery back
up only uses H and L
wires from DCP

18
Installation with a Digital Audio Unit
When connecting a Digital Audio Unit (DAU) connect the unit or the CAN Bus Splitter to
J8 using a 4-core cable (2 wires for power and 2 for communication)
+If only connecting 1 device to the DCP (e.g. DAU) set SW1 dipswitch 4 to ON
+It is recommended to use shielded twisted pair cables
+If connecting 2 devices to the DCP (e.g. 1 DAU and 1 PIT unit) set SW1 dipswitch 4 to OFF
+There are no standard wiring colours for CANBus wiring
Please refer to the DAU Installation guide for full setup of the DAU.
J8 CAN BUS
1 +Vin
2 CAN H
3 CAN L
4 -Vin
1
4
-Vin
L
H
+Vin

19
Installation with a Memcom+
When connecting a Memcom+ use the analogue phone line connection from J1A or J9.
Please refer to the Memcom+ installation guide for full set up of the Memcom+.
J 9 G S M
phone line
OUT
N
L
Connections on DCP
J 9 G S M
phone
line IN
Connection on Memcom +

DCP IG_ V04 (GB): JE 11/12/2019
ENVIRONMENT CONDITIONS
This device is designed to be used indoors (0oC to 45oC with relative humidity between
20% to 80% not condensing). Sudden changes of temperature and humidity should be
avoided.
CLEANING AND MAINTENANCE
Use a soft dry cloth. Do not use solvent or abrasive products.
SAFETY
Please read these safety instructions before starting the device.
+Do not expose this device to liquids or excessive humidity. The DCP is an indoor device and
is not waterproof.
+Do not expose the device to re.
+Do not try to modify the device.
+Do not use the device in potentially hazardous areas or where there is risk of explosion.
The DCP emits low levels of radio frequency when in operation.
BATTERY
The DCP includes a NiCd 12 V/600 mAh battery that allows it to keep functioning in the
event of a mains power failure.
This battery should be replaced every 4 years. Only install batteries authorized by Avire,
and only allow qualied personnel to replace the battery.
This battery should be properly recycled and not disposed of with unsorted household
waste. Please take all neccessary precautions when changing the battery.
DISPOSAL
The device complies with regulations 2002/95/CE and 2003/108/CE regarding
the use and disposal of hazardous substances in electric appliances.
Do not dispose of this device with unsorted household waste. Disposing
of the device in an unauthorised way could result in a ne in line with local
regulations.
ENVIRONMENTAL REGULATIONS
RoHS - Avire certies that its production process complies with the 2011/65/EU
European Directive of 03 January 2013 regarding the restriction of use of hazardous
substances in electric and electronic appliances.
INSTALLATION
The equipment is intended for installation in restricted areas by qualied personnel.
GENERAL NOTE
Any wiring or plug used together with the equipment must be certied in line with
relevant product standards. The wiring insulation must comply with the applicable IEC
60332 or IEC 60695/11/21 standards.
Avire Trading Ltd
Unit 1, The Switchback
Gardner Road
Maidenhead
Berkshire
SL6 7RJ, UK
T: 01628 540100
F: 01628 621 947
E: [e-mail]
W: www.avire-global.com
Memco is a brand of Avire
