Memmert SF Series User manual

www.memmert.com
MADE IN GERMANY.
SNxx SFxx
OPERATING
INSTRUCTIONS
STERILISER S

Manufacturer and customer service
Memmert GmbH + Co. KG
Willi-Memmert-Straße 90–96
D-91186 Büchenbach
Deutschland
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Internet: www.memmert.com
Customer service:
Service hotline: [phone]
Service fax: [phone]
E-mail: [email protected]
When contacting customer service, always quote the product serial number on the nameplate
(see page 12).
Shipping address for repairs:
Memmert GmbH + Co. KG
Kundenservice
Willi-Memmert-Str. 90-96
DE-91186 Büchenbach
Germany
Please contact our customer service before sending appliances for repair or before returning
equipment, otherwise, we have to refuse acceptance of the shipment.
© 2019 MEMMERT GmbH + Co. KG
D33347 | Date 12/2019
We reserve the right to make changes

D33347 | Date 12/2019 3
About this manual
About this manual
Purpose and target group
This manual describes the assembly, function, transport and operation of sterilisers SNxx and
SFxx. It is intended for use by trained personnel of the owner who have the task of operating
and/or maintaining the respective appliance.
If you are asked to work on the appliance, read this manual carefully before starting. Familiar-
ise yourself with the safety regulations. Only perform work that is described in this manual. If
there is something you do not understand, or certain information is missing, ask your superior
or contact the manufacturer. Do not do anything without authorisation.
Versions
The appliances are available in different configurations and sizes. If specific equipment fea-
tures or functions are available only for certain configurations, this is indicated at the relevant
points in this manual.
The functions described in this manual refer to the latest firmware version.
Due to individual configurations and sizes, illustrations in this manual may be slightly different
from the actual appearance. Function and operation are identical.
Other documents that have to be observed:
►For operation of the appliance with MEMMERT AtmoCONTROL, observe the separate
software manual
►For service and repair (see page 46), please refer to the separate service manual
Storage and forwarding
This instruction manual belongs with the appliance and should always be stored where
persons working on the appliance have access to it. It is the responsibility of the owner to
ensure that persons who are working or will work on the appliance are informed as to the
whereabouts of this instruction manual. We recommend that it is always stored in a protected
location close to the appliance. Make sure that the instruction manual is not damaged by heat
or humidity. If the appliance is sold on or transported and then set up again at a different
location, the operating instructions must go with it.
You will find the current version of our operating manual as pdf file if you go to
www.memmert.com/de/service/downloads/bedienungsanleitung/.

4 D33347 | Date 12/2019
Contents
1. For your Safety 6
1.1 Terms and signs used........................................................................................................... 6
1.1.1 Terms used ........................................................................................................................ 6
1.1.2 Signs used ......................................................................................................................... 6
1.2 Product safety and dangers ................................................................................................ 7
1.3 Requirements of the operating personnel.......................................................................... 7
1.4 Responsibility of the owner................................................................................................. 8
1.5 Intended use........................................................................................................................ 8
1.6 Changes and alterations...................................................................................................... 8
1.7 Behaviour in case of malfunctions and irregularities.......................................................... 9
1.8 Switching off the appliance in an emergency .................................................................... 9
2. Construction and description 10
2.1 Construction ...................................................................................................................... 10
2.2 Function............................................................................................................................. 11
2.3 Material.............................................................................................................................. 11
2.4 Electrical equipment.......................................................................................................... 11
2.5 Connections and interfaces............................................................................................... 12
2.5.1 Electrical connection ....................................................................................................... 12
2.5.2 Communication interface ............................................................................................... 12
2.6 Designation (nameplate)................................................................................................... 12
2.7 Technical data .................................................................................................................... 13
2.8 Applied directive................................................................................................................ 14
2.9 Declaration of conformity ................................................................................................. 14
2.10 Ambient conditions........................................................................................................... 14
2.11 Scope of delivery ............................................................................................................... 15
2.12 Optional accessories.......................................................................................................... 15
3. Delivery, transport and setting up 16
3.1 For your Safety................................................................................................................... 16
3.2 Delivery .............................................................................................................................. 17
3.3 Transport............................................................................................................................ 17
3.4 Unpacking ......................................................................................................................... 17
3.4.1 Checking for completeness and transport damage ....................................................... 17
3.4.2 Removing the transport protection................................................................................ 17
3.4.3 Disposing of packaging material .................................................................................... 17
3.5 Storage after delivery ........................................................................................................ 17
3.6 Setting up .......................................................................................................................... 18
3.6.1 Prerequisites .................................................................................................................... 18
3.6.2 Installation options ......................................................................................................... 19
3.6.3 Tilt protection.................................................................................................................. 20
3.6.4 Adjusting the doors (only for model sizes 450 and 750)............................................... 21
4. Putting into operation 22
4.1 Connecting the appliance .................................................................................................22
4.2 Switching on...................................................................................................................... 23
5. Operation and control 24
5.1 Operating personnel.......................................................................................................... 24
5.2 Opening the door.............................................................................................................. 24
Contents

D33347 | Date 12/2019 5
Contents
5.3 Loading the appliance....................................................................................................... 25
5.4 Operating the appliance.................................................................................................... 25
5.4.1 ControlCOCKPIT .............................................................................................................. 25
5.4.2 Basic operation................................................................................................................ 27
5.4.3 Operating modes ............................................................................................................ 27
5.4.4 Manual mode.................................................................................................................. 28
5.4.5 Operation with digital backwards counter with target time setting,
adjustable from 1 minute to 99 days (Timer)................................................................. 28
5.5 Temperature monitoring .................................................................................................. 29
5.5.1 Electronic temperature monitoring ............................................................................... 30
5.5.2 Mechanical temperature monitoring: Temperature limiter (TB)..................................... 31
5.5.3 Function .......................................................................................................................... 31
5.6 Ending operation............................................................................................................... 31
6. Malfunctions, warning and error messages 32
6.1 Warning messages of the temperature monitoring function ..........................................32
6.2 Malfunctions, operating problems and appliance errors ................................................ 33
6.3 Power failure...................................................................................................................... 34
7. Menu mode 35
7.1 Overview............................................................................................................................ 35
7.2 Basic operation in menu mode using the example of language selection....................... 36
7.3 Setup.................................................................................................................................. 37
7.3.1 IP address and subnet mask ...........................................................................................37
7.3.2 Unit.................................................................................................................................. 38
7.3.3 Temperature monitoring (Alarm Temp and Max Alarm) ................................................ 38
7.3.4 Timer Mode..................................................................................................................... 40
7.3.5 Type of the slide-in unit (Grid or Shelf) ........................................................................... 40
7.3.6 Remote control .............................................................................................................. 40
7.3.7 Gateway .......................................................................................................................... 41
7.4 Date and Time ................................................................................................................... 41
7.5 Calibration ......................................................................................................................... 42
8. Notes on sterilisation 45
8.1 Contraindications / unwanted side effects........................................................................ 45
8.2 Note in accordance with Medical Devices Directive ......................................................... 45
8.3 Guidelines for sterilisation.................................................................................................45
9. Maintenance and service 46
9.1 Cleaning............................................................................................................................. 46
9.1.1 Working chamber and metal surfaces............................................................................ 46
9.1.2 Plastic parts ..................................................................................................................... 46
9.1.3 Glass surfaces.................................................................................................................. 46
9.2 Regular maintenance.........................................................................................................46
9.3 Repairs and service ............................................................................................................ 46
10. Storage and disposal 47
10.1 Storage .............................................................................................................................. 47
10.2 Disposal ............................................................................................................................. 47
Index 48
Appendix 50

6 D33347 | Date 12/2019
For your Safety
1. For your Safety
1.1 Terms and signs used
In this manual and on the appliance itself, certain common terms and signs are used to warn
you of possible dangers or to give you hints that are important in avoiding injury or damage.
Observe and follow these hints and regulations to avoid accidents and damage. These terms
and signs are explained below.
1.1.1 Terms used
"Warning" is used whenever you or somebody else could be injured if you do not
observe the accompanying safety regulation.
"Caution" is used for information that is important for avoiding damage.
1.1.2 Signs used
Warning signs (warning of a danger)
Danger of
electrocution
Danger
of explo-
sion
Dangerous
gases / va-
pours
Danger of
burns
Danger of
toppling
over
Hazard area!
Observe the opera-
ting instructions
Prohibition signs (forbidding an action)
Do not lift Do not
tilt
Do not enter
Regulation signs (stipulating an action)
Disconnect
the mains
plug
Wear
gloves
Wear safety
boots
Observe
information
in separate
manual
Other icons
Important or useful additional information

D33347 | Date 12/2019 7
For your Safety
1.2 Product safety and dangers
The appliances described in this manual are technically sophisticated, manufactured using
high-quality materials and subject to many hours of testing in the factory. They contain the
latest technology and comply with recognised technical safety regulations. However, there are
still risks involved, even when the appliances are used as intended. These are described below.
Warning!
After removing covers, live parts may be exposed. You may receive
an electric shock if you touch these parts. Disconnect the mains plug
before removing any covers. Only electrical technicians may work on
the electrical equipment of the appliances.
Warning!
When loading the appliance with an unsuitable load, poisonous or
explosive vapours or gases may be produced. This could cause the
appliance to explode, and persons could be severely injured or poi-
soned. The appliance may only be loaded with materials/test objects
which do not form any toxic or explosive vapours when heated up
(see also Intended use on page 8).
Warning!
If the door is open while the appliance is in operation, the appliance
may overheat and pose a fire hazard. Do not leave the door open
during operation.
Warning!
Depending on operation, the surfaces in the working chamber
and the chamber load may still be very hot after the appliance is
switched off. Touching these surfaces can cause burns. Wear heat-
resistant protective gloves or wait until the appliance cools down.
Warning!
In case of appliances of a certain size, you can get accidentally
locked in, which is life-threatening. Do not climb into the appliance!
1.3 Requirements of the operating personnel
The appliance may only be operated and maintained by persons who are of legal age and
have been instructed accordingly. Personnel who are to be trained, instructed or who are un-
dergoing general training may only work with the appliance under the continuous supervision
of an experienced person.
Repairs may only be performed by qualified electricians. The regulations in the separate service
manual must be observed.

8 D33347 | Date 12/2019
For your Safety
1.4 Responsibility of the owner
The owner of the appliance
►is responsible for the flawless condition of the appliance and for its proper operation in
accordance with its intended use (see page 8);
►is responsible for ensuring that persons who are to operate or service the appliance are
qualified to do this, have been instructed accordingly and are familiar with the operating
instructions at hand;
►must know about the applicable guidelines, requirements and operational safety regula-
tions, and train staff accordingly;
►is responsible for ensuring that unauthorised persons have no access to the appliance;
►is responsible for ensuring that the maintenance plan is adhered to and that maintenance
work is carried out properly (see page 46);
►has to ensure that the appliance and its surroundings are kept clean and tidy, for example
through corresponding instructions and inspections;
►is responsible for ensuring that personal protective clothing is worn by operating person-
nel, e.g. work clothes, safety shoes and protective gloves.
1.5 Intended use
This appliance is exclusively intended for heating up non-explosive substances and objects.
Any other use is improper, and may result in hazards and damage.
The appliance is not explosion-proof (does not comply with the German workplace health &
safety regulation VBG 24). The appliance may only be loaded with materials and substances
which cannot form any toxic or explosive vapours at the set temperature and which cannot
explode, burst or ignite.
The appliance may not be used for drying, vaporising and branding paints or similar materi-
als the solvents of which could form an explosive mixture when combined with air. If there
is any doubt as to the composition of materials, they must not be loaded into the appliance.
Potentially explosive gas-air mixtures must not form, neither in the working chamber nor in
the direct vicinity of the appliance.
Intended use
In accordance with the Medical Devices Directive 93/42/EEC, the following intended purpose
applies: The appliance is intended to sterilise medical material using dry heat at atmospheric
pressure.
1.6 Changes and alterations
No unauthorised changes or alterations may be made to the appliance. No parts may be
added or inserted which have not been approved by the manufacturer.
Unauthorised modifications or changes result in the CE declaration of conformity losing its
validity and the appliance must no longer be operated.
The manufacturer is not liable for any damage, danger or injuries that result from unauthor-
ised changes or alterations, or from non-observance of the regulations in this manual.
1.7 Behaviour in case of malfunctions and irregularities

D33347 | Date 12/2019 9
For your Safety
The appliance may only be used in a flawless condition. If you as the operator notice irregu-
larities, malfunctions or damage, immediately take the appliance out of service and inform
your superior.
You can find information on correcting malfunctions from page 32.
1.8 Switching off the appliance in an emergency
Push the On/Off switch on the control panel
(Fig. 1) and disconnect power plug. This
disconnects the appliance from the power
supply at all poles.
Warning!
Depending on the operation performed , the surfaces in the working
chamber and the chamber load may still be very hot after the appli-
ance is switched off. Touching these surfaces can cause burns. Wear
heat-resistant protective gloves or wait until the appliance cools
down.
ON
O
O
ON
N
N
N
O
O
N
O
Fig. 1
Switch off the appliance by pressing the On/
Off switch

10 D33347 | Date 12/2019
Construction and description
2. Construction and description
2.1 Construction
1
2
3
4
7
8
5
6
Fig. 2 Construction
1 ControlCOCKPIT with capacitive function
keys (see page 26)
2 On/Off switch (see page 23)
3 Working chamber fan (for
UF/IF/SF appliances only)
4 Steel grid
5 Working chamber
6 Nameplate (covered, see page 12)
7 Door handle (see page 24)
8 Turn control with confirmation key
