Memorex MMP8565C - 1 GB Digital Player User manual

1
TABLE OF CONTENTS
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . 2
FCC Declaration . . . . . . . . . . . . . . . . . . . . . . 3
EIA Guidelines. . . . . . . . . . . . . . . . . . . . . . . . 4
Location of Controls . . . . . . . . . . . . . . . . . . . 6
Charging the Battery . . . . . . . . . . . . . . . . . . . 7
Downloading and Transferring Files . . . . . . . 8
Installing MP3 Player Utilities 5.10 . . . . . . . 12
Using MP3 Player Utilities 5.10
(Video Converter) . . . . . . . . . . . . . . . . . . . . 14
General Operation...................16
• Turning the Power On/Off. . . . . . . . . . . . 16
• MENU/Lock Button. . . . . . . . . . . . . . . . . 16
• Headphones Jack. . . . . . . . . . . . . . . . . . 17
• Volume Buttons . . . . . . . . . . . . . . . . . . . 17
Operation–Music Playback Mode . . . . . . 18
• To Listen to MP3s/WMAs . . . . . . . . . . . . 18
• To Delete Songs from the Play Queue. . 20
• High-Speed Music Search . . . . . . . . . . . 21
• Forward/Reverse Skip . . . . . . . . . . . . . . 21
• Music Contextual Menu–Equalizer. . . . . 22
• Music Contextual Menu–Play Mode. . . . 23
• Music Contextual Menu–Color Theme . . 24
Operation–Video Playback Mode.......25
• To Watch Videos. . . . . . . . . . . . . . . . . . . 25
• High-Speed Video Search . . . . . . . . . . . 26
• Forward/Reverse Skip . . . . . . . . . . . . . . 26
Operation–Photo Playback Mode ......27
• To View Photos. . . . . . . . . . . . . . . . . . . . 27
• Thumbnail View . . . . . . . . . . . . . . . . . . . 28
• Slide Show View. . . . . . . . . . . . . . . . . . . 28
Settings Menu ......................29
Troubleshooting Guide...............40
Formatting the Player ................42
Resetting the Unit ...................43
Updating the Firmware ...............43
Specifications ......................44
XXA TOC and page
refers will be redone
when comment process
is complete. XXB

COPYRIGHT:
• Distributing copies of MP3, WMA with DRM or WAV tracks without permission is a
violation of international copyright laws.
SAFETY:
• Vibration experienced during walking or exercising will not affect the player. However,
dropping the player or dropping a heavy object on the player may result in damage or
sound distortion.
• Avoid spilling any liquid onto or into the player.
• Do not leave the player in a location near heat sources; in a location subject to direct
sunlight, excessive dust, sand, moisture, rain or mechanical shock; on an unlevel
surface; or in a car with the windows closed during periods of excessive heat.
ROAD SAFETY:
• Do not use headphones while driving, cycling or operating any motorized vehicle. It
may create a traffic hazard and it is illegal in some areas. It can be potentially
dangerous to play your headset at a high volume while walking, especially at pedestrian
crossings. You should exercise extreme caution or discontinue use in potentially
hazardous situations.
FCC WARNING:
• This equipment may generate or use radio frequency energy. Changes or
modifications to this equipment may cause harmful interference unless the
modifications are expressly approved in the instruction manual. The user could lose
the authority to operate this equipment if an unauthorized change or modification
is made.
PRECAUTIONS
2
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003
du Canada.

3
FCC DECLARATION
This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions: 1) This device may not cause interference, and 2) This
device must accept any interference received, including interference that may cause
undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Shield cable must be used with this unit to ensure
compliance with class B FCC limits.

Dear Customer:
Selecting fine audio equipment such as the unit you’ve just purchased is only the start
of your musical enjoyment. Now it’s time to consider how you can maximize the fun
and excitement your equipment offers. This manufacturer and the Electronic Industries
Association’s Consumer Electronics Group want you to get the most out of your
equipment by playing it at a safe level. One that lets the sound come through loud and
clear without annoying blaring or distortion and, most importantly, without affecting
your sensitive hearing.
Sound can be deceiving. Over time your hearing “comfort level” adapts to higher
volumes of sound. So what sounds “normal” can actually be loud and harmful to your
hearing. Guard against this by setting your equipment at a safe level BEFORE your
hearing adapts.
To establish a safe level:
• Start your volume control at a low setting.
• Slowly increase the sound until you can hear it comfortably and clearly, and without
distortion.
Once you have established a comfortable sound level:
• Set the dial and leave it there.
Taking a minute to do this now will help to prevent hearing damage or loss in the future.
After all, we want you listening for a lifetime.
We Want You Listening For A Lifetime
Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment.
Since hearing damage from loud noise is often undetectable until it is too late, this
manufacturer and the Electronic Industries Association’s Consumer Electronics Group
recommend you avoid prolonged exposure to excessive noise. This list of sound levels
is included for your protection.
4

Decibel
Level Example
30 Quiet library, soft whispers
40 Living room, refrigerator, bedroom away from traffic
50 Light traffic, normal conversation, quiet office
60 Air conditioner at 20 feet, sewing machine
70 Vacuum cleaner, hair dryer, noisy restaurant
80 Average city traffic, garbage disposals, alarm clock at two feet
THE FOLLOWING NOISES CAN BE DANGEROUS UNDER CONSTANT EXPOSURE:
90 Subway, motorcycle, truck traffic, lawn mower
100 Garbage truck, chain saw, pneumatic drill
120 Rock band concert in front of speakers, thunderclap
140 Gunshot blast, jet engine
180 Rocket launching pad
Information courtesy of the Deafness Research Foundation.
5
A
S
S
O
C
I
A
T
I
O
N
EST. 1924
E
L
E
C
T
R
O
N
I
C
I
N
D
U
S
T
R
I
E
S
EIA
We
LISTENING
For A Lifetime
Want You

LOCATION OF CONTROLS
6
1
2
3
4
5
6
8
7
9
10
11
12
13
1. Headphone Jack
(HEADPHONES PART NO.
261-32000-E010*)
2. Display
3. Navigation πButton
4. Navigation √/Skip/Search o
Button
5. Navigation †Button
6. USB Jack
(USB CABLE PART NO.
337-01000-E050*)
7. Reset Button
(Inside the Recess Hole)
8. Volume + Button
9. Volume - Button
10. MENU/Lock Button
11. Power On/Off Button
12. Enter/Play/Pause ®p Button
13. Navigation ®/Skip/Search n
Button
SOFTWARE DISC PART NO. PA-E558*
*Consumer Replaceable Part
(See page XX to order.)

7
CHARGING THE BATTERY
This unit has a built-in Lithium Polymer rechargeable battery. When the bars
in the battery indicator (in the display) become low (see Figure 1) and
especially when the bars turn red, recharge the battery as follows.
1. Connect the USB cable to the USB
jack on the bottom of this unit and to
the USB port on your computer (as
shown); “✓OK to Remove” will
appear on the screen. When
charging, the battery indicator will
cycle from the current battery level to
full. Once the battery is fully charged,
the indicator will stop cycling.
NOTES:
• When you disconnect this unit from your computer, this unit will turn on and update the
playlist automatically.It will take several seconds to several minutes to update the
player's library depending on the number of files that you have transferred to the player.
• It takes approx. 6 hours to charge the battery from empty to full. When fully charged,
the unit can playback for approx. 12 hours in Music Playback mode. (Actual playback
times may vary.)
• For data transfer, please use the USB cable (included) to connect the unit to
your computer.
Computer
USB Cable
USB Jack
Figure 1

8
SUPPORTED OPERATING SYSTEMS AND FORMATS
SUPPORTED OPERATING SYSTEMS
This unit is compatible with Windows XP (SP2) with Windows Media Player 10,
or above.
Please refer to the following pages to learn how to: transfer video, music and photo
files, convert music on an audio CD into MP3 or WMA format using Windows Media
Player 10, transfer MP3/WMA files and WMA files with DRM 9 or 10 using Windows
Media Player 10.
NOTE: Visit www.Microsoft.com to download the corresponding Windows Media
Player for your computer.
MEDIA FILES SUPPORTED FORMATS
AUDIO FORMATS: MP3, MPEG 1/2/2.5 Layer 3 with a bit rate up to 320 kbps
(max.), WMA files with DRM 9 or 10 with a bit rate up to 320 kbps.
VIDEO FORMATS: AVI support (decoder: xvid, size: 128 x 128 resolution, Frame
Per Second: 30fps max, Bit Rate: 768 kbps max, Frequency Range: 8-48kHz,
Audio Format: 128kbps, 48kHz, Stereo CBR); WMV support (decoder complexity:
simple profile, size 128 x 128 resolution, Frame Per Second: 30fps max, Bit Rate:
384 kbps max, Frequency Range: 8-48kHz, Audio Format: 128kbps, 48kHz,
Stereo CBR).
PHOTO FORMATS: Baseline JPEGs.
IMPORTANT! Make sure the video resolution is 128 x 128; otherwise, the video file
will not be able to be played.

9
Software Installation CD General Information
The MyDJ Plug-In is for Windows Media Player and is compatible with Microsoft Windows XP
(Home or Professional Edition with Service Pack 2 or higher). The MusicIP Mixer is compatible
with Microsoft Windows ME, 2000 and XP.
For Microsoft Windows XP:
Use the CD to install the MyDJ Plug-In and Windows Media Player 10 OR the MusicIP Mixer
for Windows.
System requirements for MyDJ Plug-in:
• Intel Pentium (700MHz or better recommended)
• 128MB RAM (recommended minimum)
•An active Internet connection
Windows will automatically detect the audio player without installing the CD software when the
USB cable is connected.
IMPORTANT NOTE:
• For PC users, please only install Windows Media Player 10 OR MusicIP Mixer. Installing both
may cause the unit to not be detected by your computer.
INSTALLING THE SOFTWARE

10
INSTALLING THE MyDJ PLUG-IN
Procedure to Install the MyDJ Plug-In:
(for Windows Media Player 10; see
requirements on the previous page):
1. Insert the installation CD-Rom into the CD
Drive, then the installation screen will appear.
If the installation screen doesn't automatically
appear,double-click My Computer then
double-click on the CD drive, then the
installation screen will appear. Click
“Download & Install MyDJ Plug-in for Windows
Media Player”.
2. At the first pop-up screen, click “Save” to save
“wmp_plugin.msi” onto your computer. Save in
aconvenient location, such as on your
Desktop.
3. Double-click on the “wmp_plugin” icon on
your Desktop (if saved there) and the Setup
Wizard will appear. Click “Next”.

11
INSTALLING THE MyDJ PLUG-IN
4. The “Select Installation Folder” screen will
appear. It is recommended to keep the folder
as is. Then click “Next”.
5. At the “Confirm Installation” screen, click
“Next” to start the installation.
6. When successfully completed, the “Installation
Complete” screen will appear. Click “Close” to
exit the Setup Wizard. Please see page XX for
how to use the MyDJ Plug-In.

12
WINDOWS MEDIA PLAYER 10 INSTALLATION
Once you have installed Windows Media Player 10, you can transfer MP3 files, WMA
files, WMA files with DRM 9 or 10 to your player using the “Sync” function.
1. Insert the installation CD-Rom into the CD
Drive, then the installation screen will appear.
If the installation screen doesn't automatically
appear,double-click My Computer then
double-click on the CD drive, then the
installation screen will appear. Click
“Download Windows Media Player”.
2. You will be directed to the Windows Media
Download Center. Select Download (Windows
Media Player), Version (Player 10 [for
Windows XP] is recommended) and
Language. Then, click “Download Now”.
At the pop-up window, click “Run” to run
“MP10Setup.exe”. Click “Run” again.
Installation will begin.
NOTE: Please install WMP up to WMP10,
otherwise the unit may not be detected by
your computer.
3. Read the License Agreement, then click I
ACCEPT.

13
4. Installation will continue.
5. At the Welcome screen, click NEXT.
6. Select the desired privacy options.
WINDOWS MEDIA PLAYER 10 INSTALLATION

14
7. Click on Privacy Statement to view the
Statement, if desired. When finished, click
“Next”.
8. Read the instructions and tick the check
boxes as desired. Then click on More Options
and tick the check boxes as desired.
9. Click “Finish” to finish the installation of
Windows Media Player 10.
WINDOWS MEDIA PLAYER 10 INSTALLATION

15
INSTALLING THE MUSICIP MIXER
Procedure to Install the MusicIP Mixer:
1. Insert the installation CD-Rom into the CD
Drive, then the installation screen will appear.
If the installation screen doesn't automatically
appear, double-click My Computer then
double-click on the CD drive, then the
installation screen will appear.Click
“Download & Install MusicIP Mixer”.
2. For Windows, at the first pop-up screen, click
“Save” to save “mixerwin32.exe” onto your
computer. Save in a convenient location, such
as on your Desktop.
3. Double-click on the “MusicIP Mixer” icon on
your Desktop (if saved there) and the Setup
Wizard will appear. Click “Next”.

16
INSTALLING THE MUSICIP MIXER
4. The “License Agreement” screen will appear.
Select “I accept the agreement” and then click
“Next”.
5. The “Select Destination Location” screen will
appear. It is recommended to keep the folder
as is. Then click “Next”.
6. The “Select Start Menu Folder” screen will
appear. It is recommended to keep the folder
as is. Then click “Next”.

17
INSTALLING THE MUSICIP MIXER
7. The “Select Additional Tasks” screen will
appear. Select (check) “Create a desktop icon”
and/or “Create a Quick Launch icon”, as
desired, and then click “Next”.
8. The “Ready to Install” screen will appear. To
continue, click “Install”.
9. The “Completing the MusiclP Mixer Setup
Wizard” screen will appear.If the “Install Bonjour
Service (to enable TiVo support)” is listed as an
option, you do NOT need to select it.
It is highly recommended that you select “View
help file”, so that after installation, you will
immediately be directed to further instructions
regarding the MusicIP Mixer. Click “Finish” to
exit the Setup Wizard.
Please see page XX for how to use the
MusicIP Mixer.
You can also refer to the document located in:
"C:\Program Files\MusicIP\MusicIP
Mixer\help\index.htm" (if you did not change the
folder in Step 5).
You can also visit:
http://www.musicip.com/mixer/help.jsp
for the MusicIP Mixer Help page.

18
INSTALLING MP3 PLAYER UTILITIES 5.10
Procedure to Install MP3 Player Utilities 5.10:
1. Insert the installation CD-Rom into the CD
Drive, then the installation screen will appear.
If the installation screen doesn't automatically
appear, double-click My Computer then
double-click on the CD drive, then double-click
on “Setup.exe”.
2. The “Welcome” screen will appear. Click
“Next”.
3. The “Installation Folder” screen will appear. It
is recommended to keep the folder as is. At
this screen, you can also choose to install
MP3 Player Utilities 5.10 for yourself, or for
anyone who uses that computer. Then click
“Next”.

19
INSTALLING MP3 PLAYER UTILITIES 5.10
4. The “MP3 Player Utilities 5.10 Information”
screen will appear. Read the information and
click “Next”.
5. The “Confirm Installation” screen will appear.
Click “Next”.
6. After the program is done installing, the
“Installation Complete” screen will appear.
Click “Close” to end installation. See page XX
for how to use MP3 Player Utilities 5.10.

20
DOWNLOADING AND TRANSFERRING FILES
For Windows XP, you can also utilize Windows Media
Player 10 software to convert music on an audio CD into
MP3 or WMA format as follows:
1. Open the Windows Media Player 10 Browser, then
click on the “Rip” icon on the top tool bar. Insert a
music CD into the CD-Rom drive of your computer.
2. Click on the “Tools” menu option at the top menu
bar, then click on “Options”; the Option setting
menu will appear. Click on Rip Music and set the
Rip Music to the desired location on your computer.
Then, set the desired format for the newly ripped
music (MP3 format or Windows Media Audio format). Adjust
the audio quality as desired. When finished, click “OK” to
confirm the settings.
3. Click on the “Rip Music” icon to start ripping the music to
your computer.
4. When the music tracks are ripped, you can transfer them to
your player using Windows Media Player 10 as described
on the next page.
