Mercia Garden Products 01OVLPA10DDGP-V1 Instruction manual

OVERLAP APEX SHED 5X10, 10X10, 15X10, 20X10
2mm Drill bit
x2 Winter = High Moisture = Expansion
Summer = Low Moisture = Contraction
All building’s should be
erected by two adults
For ease of assembly, you
MUST pilot drill all screw
holes and ensure all screw
heads are countersunk.
For assistance please contact customer care on: 01636 821215
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk
CAUTION
Every eort has been made during the
manufacturing process to eliminate the
prospect of splinters on rough surfaces of the
timber. You are strongly advised to wear gloves
when working with or handling rough sawn
timber.
Please retain product label and instructions for future reference
General Instructions
BEFORE YOU START PLEASE READ INSTRUCTIONS CAREFULLY
- Check the pack and make sure you have all the parts listed.
- When you are ready to start, make sure you have the right tools at hand (not supplied) including a Phillips
screwdriver, Stanley knife, Wood saw, Step ladder, Hammer and a Drill with 2mm bit.
- Ensure there is plenty of space and a clean dry area for assembly.
LOCATION FOR YOUR GARDEN BUILDING
A minimum of 60cm should be left around the perimeter of your garden building to allow access for
maintenance, annual treatment and to allow air ow around the building.
Where possible you should avoid placing your garden building underneath large trees to prevent the tree
causing damage to the building.
TIMBER
As with all natural materials, timber can be aected during various weather conditions. For the duration of
heavy or extended periods of rain, swelling of the wood panels may occur. Warping of the wood may also
occur during excessive dry spells due to an interior moisture loss. Unfortunately, these processes cannot be
avoided but can be helped. It is suggested that the outdoor building is sprayed with water during extended
periods of warm sunshine and sheltered as much as possible during rain or snow.
Once your garden building has been installed it will need to be treated as soon as possible and annually to
prevent the timber from deteriorating and to waterproof it. This is required to maintain the anti-rot guarantee.
Dip Treated buildings - Require a preservative treatment to protect against rot and decay and a waterproof
treatment to prevent water ingress
Pressure Treated buildings - Require a waterproof treatment to prevent water ingress
Log Cabins - Are supplied untreated and require a preservative and waterproong treatment.
BUILDING A BASE
When thinking about where the building and base is going to be constructed:
Ensure that there will be access to all sides for maintenance work and annual
treatment.
Ensure the base is level and is built on rm ground, to prevent distortion. Refer to diagrams for the base
dimensions, The base should be slightly smaller than the external measurement of the building, i.e. The
cladding should overlap the base, creating a run o for water. It is also recommended that the oor be at least
25mm above the surrounding ground level to avoid ooding.
TYPES OF BASE
- Concrete 75mm laid on top of 75mm hard-core.
- Slabs laid on 50mm of sharp sand.
Whilst all products manufactured are made to the highest standards of Safety and in the case of childrens
products independently tested to EN71 level, we cannot accept responsibility for your safety whilst erecting
or using this product.
**Protim Aquatan T5 (621)**
Your building has been dip treated with Aquatan.
Aquatan is a water-based concentrate which is diluted with water, the building as been treated by the correct
application of Aquatan solution and then allowed to dry.
Aquatan is a decorative nish to colour the wood, which is applied industrially to timber fence panels and
garden buildings.
Aquatan undiluted contains: boric acid, sodium hydroxide 32% solution, aqueos mixture of sodium dioctyl
sulphosuccinat and alcohols: 2, 4, 6-trichlorophenol.
01OVLPA10DDGP-V1
REGISTER FOR YOUR
ANTI-ROT
GUARANTEE TODAY
PLEASE SCAN HERE:
Overall Dimensions:
Width = 3097mm
Depth = 6018mm
Height = 2255mm
Base Dimensions:
Width = 2974mm
Depth = 5948mm

10x10ft - NO WINDOWS
15x10ft - NO WINDOWS
20x10ft - NO WINDOWS
5x10ft - NO WINDOWS
10x10ft - 1 FIXED WINDOW
15x10ft - 1 FIXED WINDOW
20x10ft - 1 FIXED WINDOW
5x10ft - 1 FIXED WINDOW
10x10ft - 2 FIXED WINDOWS
15x10ft - 2 FIXED WINDOWS
20x10ft - 2 FIXED WINDOWS
15x10ft - 3 FIXED WINDOWS
20x10ft - 4 FIXED WINDOWS 20x10ft - 3 FIXED WINDOWS
01OVLPA10DDGP-V1 - OVERLAP APEX SHED 5X10, 10X10, 15X10, 20X10
Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN
The building you have purchased can be built in various ways. Within this document it is demonstrated on how to construct your building whether it is a 5x10, 10x10, 15x10 or 20x10.
P 2
5X10 Apex
Overall Dimensions:
Width = 3097mm
Depth = 1548mm
Height = 2255mm
Base Dimensions:
Width = 2974mm
Depth = 1487mm
10X10 Apex
Overall Dimensions:
Width = 3097mm
Depth = 3038mm
Height = 2255mm
Base Dimensions:
Width = 2974mm
Depth = 2974mm
15X10 Apex
Overall Dimensions:
Width = 3097mm
Depth = 4528mm
Height = 2255mm
Base Dimensions:
Width = 2974mm
Depth = 4461mm
20X10 Apex
Overall Dimensions:
Width = 3097mm
Depth = 6018mm
Height = 2255mm
Base Dimensions:
Width = 2974mm
Depth = 5948mm

H=220cm W=140cm L=130cm
P 3
OVERLAP APEX SHED 10X10
Please retain product label and instructions for future reference
2
1345
Front Gable Right
QTY 1
AI-01OVLPFGR796X1929-V2
Front Gable Left
QTY 1
AI-01OVLPFGL796X1929-V2
Front Gable Top
QTY 1
AI-01OVLPFGT1332X452-V2
Back Gable
Right QTY 1
AI-01OVLPHPGR1462X2226-V2
Back Gable
Left QTY 1
AI-01OVLPHPGL1462X2226-V2
Door QTY 2
AI-01MBDR1780X661-V1
10
Door Strip - 12x56x1000mm QTY 2
S1256-1000
Ridge Bar - 27x70x1434mm QTY 1
F2770-1434
Door Gable Bottom Rail - 28x28x1332mm QTY 1
F2828-1332mm
Door Block - 28x28x140mm QTY 2
F2828-140
15
16
17
Fascia - 12x56x2000mm QTY 4
S1256-2000
Plain Gable Strip - 12x45x2200mm QTY 1
S1245-2200
Cover Trim - 12x45x1585mm QTY 4
S1245-1585
Door Beading Strip - 12x27x2000mm QTY 2
S1227-2000
18
19
20
21
Finial QTY 2
DIAMOND SHED FINIAL
Door Gable Strip - 7x125x1876mm QTY 1
OP7125-1876mm
Eaves Frame - 28x28x1502mm QTY 2
F2828-1502
Window Strip - 12x27x2000mm QTY 2
S1227-2000
22 22
29
24 24 25
25
Plastic Window Cill QTY 1
PI-08-0013
26 26
T Hinge QTY 6
PI-02-1045
28
28
29
Turn Button QTY 3
PI-07-0034
Styrene QTY 2
PI-05-0114
33
34
L-Bracket QTY 2
PI-07-0012
U Channel QTY 1
PI-07-0013
30
30
31
31
32
U Channel QTY 1
PI-07-0013
Building Content - Pack A
01OVLPA10DDGP-V1
Building Content - Pack B Fixed Window
01OVLPA0510FWPB-V1
Building Content - Pack C No WIndow
01OVLPA0510NWPC-V1
6
7
Plain Side QTY 1
AI-01OVLPPS1490X1567-V2
Window Side QTY 1
AI-01OVLPWS1490X1567-V2
Floor QTY 2
AI-01OVLPF1487X1487-V1
Roof Sheet QTY 2
PI-03-0232
8
Floor QTY 2
AI-01OVLPF1487X1487-V1
Plain Side QTY 2
AI-01OVLPPS1490X1567-V2
9
9
9
Roof Sheet QTY 2
PI-03-0232
11
Truss QTY 1
AI-01TRS2924X690-V2
Truss Block - 27x44x140mm QTY 2
F2744-G-160 (1X66° cut, 140mm nished length)
Floor Blocks - 28x28x400mm QTY 8
F2828-400
13
Truss Block - 27x44x140mm QTY 2
F2744-G-160 (1X66° cut, 140mm nished length)
14
Floor Blocks - 28x28x400mm QTY 8
F2828-400mm
Nail Bag
30mm Screw x 18
50mm Screw x 14
70mm Screw x 6
40mm Screw x 54
100mm Screw x 2
There may be extra screws present in the nail bag
Felt Tacks x 100
Nail Bag
30mm Screw x 33
50mm Screw x 14
70mm Screw x 6
40mm Screw x 54
100mm Screw x 2
There may be extra screws present in the nail bag
Felt Tacks x 100
Nail Bag
30mm Screw x 75
50mm Screw x 39
40mm Screw x 41
There may be extra screws present in the nail bag
Ridge Bar - 27x70x1490mm QTY 1
F2770-1490
Eaves Frame - 28x28x1502mm QTY 2
F2828-1502
23
Ridge Bar - 27x70x1490mm QTY 1
F2770-1490
12
Cover Trim - 12x45x1585mm QTY 2
S1245-1585mm
Cover Trim - 12x45x1585mm QTY 2
S1245-1585
Truss QTY 1
AI-01TRS2924X690-V2
Felt
27
27
Plain Gable Strip - 12x45x1000mm QTY 1
S1245-1000

Please retain product label and instructions for future reference
For assistance please contact customer care on: 01636 821215
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk
Door Gable Assembly
Step 1
2 x 50mm screws
Parts Needed - No. 1 QTY 1
No. 3 QTY 1
Lay the Front Gable Right (No 1) and Front
Gable top (No 3) on a level oor place them
next to each other, ensure they are level at
the top then x together using 2x50mm
screws. Stagger the screws so they do not
collide.
1
3
50mm
screw Pre drill
hole
IMPORTANT: Pre-drill before xing screws.
IMPORTANT: Pre-drill before xing screws.
Step 2
2 x 50mm screws
Parts Needed - No. 2 QTY 1
Lay the Front Gable Left (No. 2) next to the
Front Top Gable, ensure they are level at the
top then x together using 2x50mm screws.
Stagger the screws so they do not collide.
50mm
screw Pre drill
hole
2
Line the Door Gable Strip up (No. 12) to the
assembled gable at the corners as shown in
the illustration and x in place using 40mm
screws
6 x 40mm screws
40mm
screw Pre drill
hole
12
12
Step 3
Parts Needed - No. 12 QTY 1
P4
Remove transportation blocks
from the bottom of each panel
before beginning assembly.
Each Panel should have two
blocks.
Pre Assembly
Please retain product label and instructions for future reference

IMPORTANT: Pre-drill before xing screws.
IMPORTANT: Pre-drill before xing screws.
IMPORTANT: Pre-drill before xing screws.
Plain Gable Assembly
Step 4
10 x 50mm screws
Parts Needed - No. 4 QTY 1
No. 5 QTY 1
Lay the Back Left Gable and Back Right
Gable on a level oor place them next to
each other, ensure they are level at the top
and bottom then x together using
10x50mm screws. Stagger the screws so
they do not collide.
50mm
screw Pre drill
hole
45
Step 5
8 x 40mm screws
Parts Needed - No. 24 QTY 2
Place oor (No. 24) on rm and level base,
ensure base has suitable drainage free from
areas where water can collect. (See front
page on base requirements).
If you are building a 5x10 shed, please
proceed to Step 7:
Attach the oors using 8 x 40mm screws
40mm
screw Pre drill
hole
24
24
40mm
screw Pre drill
hole
Parts Needed 10x10 - No. 24 QTY 2
No. 29 QTY 8
Parts Needed 15x10 - No. 24 QTY 4
No. 29 QTY 16
Parts Needed 20x10 - No. 24 QTY 6
No. 29 QTY 24
Fix another two oor panels (No. 24)
using the oor blocks (No. 29) provid-
ed.
Place the oor blocks in between the
framing as shown in the diagram.
Screw the oor blocks to oor using
2x40mm screws per block screwing
through the oor into the oor blocks.
Fix the two oor panels together
using the same method shown in step
4 using 8x40mm screws.
Repeat this step once more if you are
assembling the 15x10 and another
two times if you are assembling the
20x10.
10x10 - 24x40mm screws
15x10 - 48x40mm screws
20x10 - 72x40mm screws
Step 6
15x10
5x10
20x10
10x10
29
Please retain product label and instructions for future reference
24
24
P 5

IMPORTANT: Pre-drill before xing screws.
IMPORTANT: Pre-drill before xing screws.
IMPORTANT: Pre-drill before xing screws.
50mm
screw Pre drill
hole
Step 7
Parts Needed - No. 23 QTY 1
Place the assembled Back Gable Panel (please
refer to Step 3 if you have not yet assembled this)
and the Plain Panel (No. 23) next to each other
and onto the oor as shown in the illustration,
Ensure to position the panels so there is equal
spacing between the oor and cladding on
each side.
Fix the two Panels together by screwing into the
corner using 50mm screws.
3x50mm Screws
5
23
4
Step 8
Parts Needed - No. 23 QTY 1 (No Window ONLY)
No. 22 QTY 1 (Fixed Window ONLY)
On the opposite side of the shed, repeat the method
used in Step 7 to x either a Window Panel (No. 22)
or another Plain Panel (No. 23) on to your Shed.
Ensure to position the panels so there is equal
spacing between the oor and cladding on each
side.
If you are building a 5x10 shed, please proceed
to Step 10:
3x50mm Screws
50mm
screw Pre drill
hole
22
P 6
Step 9
Parts Needed 10x10 - No. 23 QTY 1 (No Window QTY2)
No. 22 QTY 1 (Fixed Window ONLY)
Parts Needed 15x10 - No. 23 QTY 2 (No Window QTY4)
No. 22 QTY 2 (Fixed Window ONLY)
Parts Needed 20x10 - No. 23 QTY 3 (No Window QTY6)
No. 22 QTY 3 (Fixed Window ONLY)
Using the same method continue to x either
Window Panels (No. 22) or other Plain Panels
(No. 23) on to your shed. Fix at the corners using
50mm screws as shown in the diagram.
Ensure to position the panel so there is equal spacing
between the oor and cladding on each side.
Do not secure the building to the oor until the
roof is tted.
10x10 - 6x50mm Screws
15x10 - 12x50mm Screws
20x10 - 18x50mm Screws
5x10 15x10
20x10
50mm
screw Pre drill
hole
Please retain product label and instructions for future reference
22
22
23
23
23
22
23
23
22
22
22
23
10x10
Please retain product label and instructions for future reference

IMPORTANT: Pre-drill before xing screws.
IMPORTANT: Pre-drill before xing screws.
IMPORTANT: Pre-drill before xing screws.
Step 10
Fix the Door Gable (refer to steps 1
and 2 if you have not already
assembled this) at the corners with
50mm screws as shown in diagram.
6x50mm Screws
50mm
screw Pre drill
hole
1
3
2
Step 11
Parts Needed - No. 7 QTY 1
Fit the Door Gable Bottom rail (No.
7) between the Front Gable Left and
Right. Fix to the oor using 3x50mm
screws making sure the screws go
through to the oor framing.
3x50mm Screws
50mm
screw Pre drill
hole
7
Parts Needed - No. 17 QTY 6
No. 16 QTY 2
Fix the T Hinges (No. 17) on to
the doors (No. 16) and door
gable as shown. Ensure that the
screws go through the cladding
and into the framing behind.
If you are building a 5x10
shed, please proceed to Step
14.
42x30mm screws
Step 12
Internal View
16
16
30mm
screw Pre drill
hole
Please retain product label and instructions for future reference
17
P 7
Please retain product label and instructions for future reference

IMPORTANT: Pre-drill before xing screws. IMPORTANT: Pre-drill before xing screws.
Step 13
Parts Needed -
10x10 - No. 26 QTY 1
No. 30 QTY 2
15x10 - No. 26 QTY 2
No. 30 QTY 4
20x10 - No. 26 QTY 3
No. 30 QTY 6
Place a Truss central to where two
panels join. Align the top of the truss
with the top of the sides as shown in
the diagram.
HINT - Use a piece from the xing kit as
a guide.
Pencil mark the truss position and
remove truss.
Place the truss blocks up to the pencil
mark and x using 2x70mm screws per
block.
Place the truss back into position on
top of the support block and secure
using 100mm screw each side from the
top down through the truss and into
the block.
5x10 - No Truss
10x10 - 4x70mm Screws
2x100mm Screws
15x10 - 8x70mm Screws
4x100mm Screws
20x10 - 12x70mm Screws
6x100mm Screws
For 15x10 and 20x10 build a truss
where each panel joins, for 5x10 you
will have no trusses, 10x10 you will have
one truss, 15x10 you will have two trusses
and for the 20x10 you will have three
trusses.
26
30 30
70mm
screw
70mm
screw Pre drill
hole
100mm
screw Pre drill
hole
26
20x10
26
26
26
26
26
15x10
5x10
10x10
Step 14
20x10
5x10 - 8x30mm Screws
10x10 - 2x70mm Screws
18x30mm Screws
15x10 - 4x70mm Screws
28x30mm Screws
20x10 - 6x70mm Screws
38x30mm Screws
Parts Needed -
5x10 - No. 6 QTY1, No. 20 QTY 2
10x10 - No. 6 QTY 1, No. 20 QTY 2,
No. 28 QTY 1, No. 31 QTY 1
15x10 - No. 6 QTY 1, No. 20 QTY 2,
No. 28 QTY 2, No. 31 QTY 2
20x10 - No. 6 QTY 1, No. 20 QTY 2,
No. 28 QTY 3, No. 31 QTY 3
For 5x10, you do not need a U-channel.
You only need to t the one ridge bar
(No. 6) using the ‘L’ Brackets.
Position the Ridge Bars (No. 6 & 28)
within the ‘U’ channel (No. 31). Secure
from either side with 3x30mm screws
and 4x30mm screws from underneath.
For 15x10 you need to add another ridge
bar and U-channel. For 20x10 you need
to add a further two ridge bars and
U-channels.
Secure an ‘L’ bracket (No. 20) to either
end of the ridge bar using 2x30mm
screws per bracket.
Place the assembled ridge bar in
between the front and back Gables
above the already tted truss. Ensure
the top corners of the support bar are
ush with each top point of the Gable.
Secure the ‘L’ brackets (No. 20) on to
both the Gables framing using 2x30mm
screws.
Using 2x70mm screws, secure the ridge
bar to the truss. Screw in from above
either side of the truss as shown in the
diagram.
6
30mm
screw
28
31
31
20
20
20
20
28
6
6
28
28
28
28
28
6
10x10
15x10
5x10
6
Please retain product label and instructions for future reference
P 8

P9
IMPORTANT: Pre-drill before xing screws. IMPORTANT: Pre-drill before xing screws.
20x10
Step 15
Parts Needed - No. 27 QTY 2
No. 25 QTY 2
Fix the eaves frame (No. 27) to the
roof sheet (No, 25) sheet using
4x30mm screws for each sheet.
If you are constructing a 5x10, go
to step 17.
Place two roof sheets on top of the
plain gable and truss making sure
the roof sheet sits ush to the
outside edge of the plain gable
and x using 40mm screws. Before
xing the roof sheet to the truss
frame make sure the edge of the
roof sheet sits in the middle of the
truss then x using 40mm screws.
8x30mm Screws
24x40mm Screws
40mm
screw Pre drill
hole
30mm
screw Pre drill
hole
25
25
15x10
5x10
25
25
25
25
10x10
25
273
Step 16
Parts Needed -
10x10 - No. 27 QTY 2
No. 25 QTY2
15x10 - No. 27 QTY 4
No. 25 QTY 4
20x10 - No. 27 QTY 6
No. 25 QTY 6
Fix the remaining eaves frames to
the remaining roof sheets using
4x30mm screws per sheet.
Place the roof sheet ontop of the
truss and ensure that it butts up
to the one already xed. Fix in
place with 40mm screws ensuring
they go through to the framing.
For 15x10 & 20x10 buildings
continue this process untill the
roof is complete.
10x10 - 8x30mm Screws
24x40mm Screws
15x10 - 16x30mm Screws
48x40mm Screws
20x10 - 24x30mm Screws
72x40mm Screws
20x10
25
25
25 25
25
27
30mm
screw Pre drill
hole
40mm
screw Pre drill
hole
15x10
5x10
10x10
25
25
25
25
25
25
25
25 25
25
Please retain product label and instructions for future reference

P10
IMPORTANT: Pre-drill before xing screws.
5x10
Step 17
Once the roof is xed, attach
the building to the oor with
50 mm screws.
5x10 - 22 x 50mm Screws
10x10 - 26 x 50mm Screws
15x10 - 34 x 50mm Screws
20x10 - 42 x 50mm Screws
15x10
20x10
50mm
screw Pre drill
hole
10x10
Step 18
HANDLE
WITH CARE
12
3
4
5x10 - 100 x felt tacks
10x10 - 170 x felt tacks
15x10 - 240 x felt tacks
20x10 - 310 x felt tacks
Cut four strips of felt (No. 21)
and place onto the roof. See
below for sizes.
Place the felt at onto the roof
in the order that is stated on
the diagram below.
Once the sheets are laid out x
them onto the roof with tacks
100mm apart.
12
34
Felt Strip Sizes
5x10 - 1610mm
10x10 - 3110mm
15x10 - 4610mm
20x10 - 6110mm
21
1
3
42
Felt
tacks Pre drill
hole
Please retain product label and instructions for future reference

IMPORTANT: Pre-drill before xing screws.
IMPORTANT: Pre-drill before xing screws.
9
9
Step 19
Parts Needed -
5x10 - No. 9 QTY 4
10x10 - No. 9 QTY 6
15x10 - No. 9 QTY 8
20x10 - No. 9 QTY 10
Using a pencil and a stright edge,
measure the Strip (No.9) to 1575mm.
Cut along the marked line to make a
cover trim measuring 1575mm in
length.
Fit the Cover Trims (No. 9) to the front,
back and sides where the panels join
using 3x40mm screws.
20x10
40mm
screw Pre drill
hole
9
9
5x10 - 12x40mm Screws
10x10 - 18x40mm Screws
15x10 - 24x40mm Screws
20x10 - 30x40mm Screws
5x10
15x10
10x10
9
9
*trim to t
P 11
Step 20
Parts Needed - No. 15 QTY 1
Locate the cover trim (No.15) on the
back of the shed so it covers where the
plain gable panels join together.
Ensure the Trim sits centrally over the
join, as shown in the illustration.
Secure in place using 3x40mm screws.
3 x 40mm Screws
40mm
screw Pre drill
hole
15
Please retain product label and instructions for future reference

P 12
IMPORTANT: Pre-drill before xing screws. IMPORTANT: Pre-drill before xing screws.
Step 21
Parts Needed - No. 14 QTY 1
Using a pencil and a straight edge,
measure the Strip (No.14) to create
two 250mm length strips.
Cut along the marked lines to make
two cover trims measuring 250 mm in length.
Locate the cover trims onto the front gable,
so they cover where the panels join together.
Ensure the Trims sit centrally over the join, as
shown in the illustration.
Secure in place using 3x40mm screws
per cover trim.
4 x 40mm Screws
14
14
40mm
screw Pre drill
hole *trim to t
Step 22
16x40mm Screws
Parts Needed - No. 11 QTY 4
No. 18 QTY 2
Using a pencil and a straight
edge, measure the Strip
(No.11) to 1667mm.
Cut along the marked lines to
make a fascia measuring
1667mm in length.
Attach faiscas to the roof
leaving a slight overhang at
the top.
Fit the fascias to the roof over
the felt and secure in place
with 40mm screws as shown.
After the fascias are tted,
attach the two Finials (No.18)
to the front and the back
using two screws per Finial.
Pre drill to avoid splitting.
11
11
11
11
18
18
15x10
5x10
20x10
40mm
screw Pre drill
hole
11
18
18
18
18
11
11
11
11
11
11
11
11
11
11
11
18
18
10x10
*trim to t
Please retain product label and instructions for future reference

P 13
IMPORTANT: Pre-drill before xing screws.
30mm
screw Pre drill
hole
Parts Needed - No. 8 QTY 2 & No. 19 QTY 1
Step 24
Fix the door strips (No. 8)
to the master door using
3x30mm screws per strip.
Trim each strip down to
approx 830mm each.
If the strips are attached
to the secondary door the
doors will not open
properly.
6x30mm Screws
Use 1x30mm screw to
secure the turn button
(No. 19) to the master
door.
1x30mm Screws
b
a
8
8
19
b
*trim to t
a
IMPORTANT: Pre-drill before xing screws.
Step 23
c
30mm
screw Pre drill
hole
Use 4x30mm Screws to x
each beading strip (No.
10) onto the door gable.
Ensure that the screw is
parallel with the door
frame when xing the
strip to the door gable as
shown in the close up
view. Trim strips down to
t.
Attach the turn button
(No.19) to the top and
bottom door blocks with
1x30mm screw for each
First line up the door
blocks (No.13) on top of
the framing of the doors.
Then x with 2x30mm
screws by screwing 2x30mm Screws
8x30mm Screws
bca
8x30mm Screws 16
b
10
c
13
19
a
13
Parts Needed - No. 10 QTY 2, No. 13 QTY 2 & No. 19 QTY 2
Please retain product label and instructions for future reference

P 14
30mm
screw Pre drill
hole
32
32
Step 25 (Fixed Window only)
Parts Needed - No. 29 QTY 1
Using a pencil and a straight edge, measure
the Strip (No. 32) to create two 546mm
length strips per window panel.
Cut along the marked lines to make 2
window strips, each measuring 546mm in
length.
*Please note you have excess strip left over,
keep this to one side as you will require this
in future steps.
Fix 2 window strips to the framing that
sits either side of the window, using
3x30mm screws per trim, as shown in the
illustration.
Repeat this for both Window Panels.
6 x 30mm Screws
IMPORTANT : Pre-drill before xing screws.
*trim to t
34
SILICONE
SEALANT
Place the plastic window cill (No.34)
onto the Window Panel and use a silicone
sealant to secure in place, as shown in the
illustration.
*please note silicone sealant is not supplied
with your building*
Fit the styrene sheets (No.33) on top
of the window cill (No.34).
When positioning the styrene sheets
ensure there is an equal distance
between them and either side of the
windows.
Repeat for both Window Panels.
a
b
33
a
b
33
Step 26 (Fixed Window only)
Parts Needed Per Window Side - No. 32 QTY 2
No. 34 QTY 4
Styrene
Window Cill
Cladding
Side View
Please retain product label and instructions for future reference

P15
It is ESSENTIAL that you apply wood
treatment immediately after the building
has been assembled.
AFTER TREATMENT:
score around protective
cover on glazing and
carefuly peel
covering back
Please retain product label and instructions for future reference
32
32
32
Pre drill
hole
33
32
32
32
33
33
33
Step 27 (Fixed Window only)
Parts Needed Per Window Side - No. 32 QTY 1
Using a pencil and a straight edge, measure
the Strips (No.32) to create three 546mm
length strips.
Cut along the marked lines to make 3
window strips in total, each measuring
546mm in length.
Locate the Window strips
(No. 32) onto the Window Panel, one either
side of the styrene slot in the panel and one in
the centre of the two pieces of styrene, as
shown in the illustration.
Fix in place using 3x30mm screws per Trim,
ensuring the screws enter the framing of
the window panel and not the styrene.
9 x 30mm screws.
30mm
screw
IMPORTANT : Pre-drill before xing screws.
*trim to t





















































2





1












3
4














REGISTER FOR YOUR
ANTI-ROT
GUARANTEE TODAY
PLEASE SCAN HERE:



















¡




1




2























¡



