Merkava Cobra5K User manual

Cobra5K
User Manual

2.
4.
5.
7_
8.
1.
3.
6.
Carefully remove contents of box out of the packaging.
You willfind:
. 1 x CobrasK
. 1x110VChar8er
. lxToolKit
. 2xKeys
Lift riser/stem to the upright position and lock it into place by tightening the 4 allen (hex)
screws located at the bottom ofthe riser. When facing the CobrasK these will be visible to
you. There are two screws on each side ofthe riser,
lnsert the left and right part of the handle bar into their respective slots at the top of the
riser, position brake levers to desired height and tighten the two hex screws per side.
Place your CobrasK on a raised surface for easy inspection while securing one ofthe wheels
so it stays in place then proceed to visually check the CobrasK components and ensure that
all screws and bolts are tightened and that tires are correctly inflated. The CobraSK uses
tubeless tires- This check is usually already done once at the factory and once before
shipping but as a precautionary measure we recommend you do this as well before riding.
Charge your CobraSK in a clean environment at ambient temperature until li8ht on the
chargerturns from red to green
On the top left hand side ofthe riseryou willfind a "Sport" button. Depressing itwill unlock
the moto/s full power output. We recommend only using this feature after several hours of
practice on the regular mode.
on thetop righthand side ofthe riseryou willfind a switch which willactivate your Front
and Rear LED lights. lf riding duringthe daywe suggest leavingthese offto conserve power.
The cob.a5K utilizes powerful 203mm hydraulic disc brakes. Please use them mildly until
your accustomed to their braking power. The pressure applied to the front/rear brake iever
should be 70/30 respectively in orderto maintain proper balance.
9. To turn your CobrasK on simply insert key and turn once clockwise.
once you've familiarized yourself with the Cobra5K you will be ready to ride. Please ride
carefullyl

Before shipping, each and every transporter is checked for overall qual;ty control and condition of
battery pack. Eattery is tested and fully char8ed before shipping.
The lithium ion technology is intended to last for several years while being charged and discharged many
times. However, the battery's life span will depend on your care of the battery.
Baftery life will depend on your maintenance and care of the battery. Cobra5K uses advanced Lithium-
lon batteries made with SAMSUNG cells and they should be charged at least once a month (when not in
use)to ensure the longevityofyour battery. Make sure to only use oursupplied 48Vchargeron your
48V battery.
Allow your battery to rest for 10 minutes after charging before riding and for 10 min after riding before
charging. Unpll]g your battery charger after the light turns green indicatingyour battery is fully charged.
Always unplugthe charger frorn the walloutlet befote plug$ing or unpluEging the other end into your
CobraSK.
Typicalcharging time afterthe battery has reached the 10% critical low level (40V) is between 1.5 to 5
hours depending on whether you have the regular 5Ah or the 15Ah Fast charger offered as an optionai
add on.
Cautiori Do not expose your battery to extremely low or high temperatures to avoid potential damage
to your battery.>>
IMPORTANT NOTE: ro AVorD DAMAGTNG youR BATTERY pAcr( wE srRoNGLy RECoMMENo
USER SHUTS DOWN AND RECHARGE THE COERAsK ONCE SATTERY LEVEI. REACHES 1O%. YOU wlI.I.
ENTERTHIS CRITICAL LEVELSHORTI.Y AFTER YOUR DISPLAY REACHES4OV IN THE VOLTAGT METER.

Merkava stands behind its products. All our tmnsporters benelit from a 2 year limited
watranty.
The COMPANY wanarts that the frame will be free from defects in the materials and
workmanship for a period of2 years.
The COMPANY wa ants that tire motor and battery pack will be fiee fiom defects in the
materials and workmanship for a period of I year*.
The COMPANY wafiants that the electrical components including the controller and
charger will be free from defects in the mateials and workmaoship for a period of6 months.
Before shipping, we conduct spot checks on our transporters to validate overall quality and
condition ofelectrical components including motor and baftery pack. These checked units have
their batlery tesled ard fully charged before slripping.
The lithium ion technology we use is intended to last for several years while being charged and
discharged many times. However, the battery's life span will depend on your care ofthe battery.
Ifthe PRODUCT proves defective AND a claim is filled during the warranty period. the
COMPANY at its option. will:
Repair the PRODUCT by means oftelephone support, email support, or by providing the
necessary parts at no charge.
Warranty claims must be filed with Merkava by email: inlbldmcrkara-ca
*Warranty on battery will be limited to 6 months if it is determined that our guidelines for proper
battery care have not been followed.
The following are not covered by the warranty:
. Wear and tear on frame, grip tape, levers, tubes, tires. brake discs, brake pads, cables,
seats, plastic fairings and any other component which wears out naturally during usage
. Minor scratches and stress marks that may occur duing shipping and handling.
. Water damage caused by exposing sensitive elect cal parts to water such as washing
transporter with hose or pressue washer.
. Accidents, misuse, abuse, human errors or lack ofmaintenance.
. Acts-of-god such as fre, flood, earthquake, freezing, etc

Warranty information €ontinued:
The following will void the wrrranty:
. The modification ofyour hansporter or use outside those specified on this site.
r The serial number ofthe product has been altered or removed.
. The product has been dismantled and repaired/reassembled with aftemarket parts.
o Overloading your transporter.
. Storing youl transporter outdoors.
IMPORTANT NOTE: To AvoID DAMAGING YoUR BATTERY PAc( wE slnoNcTY RECoMMEND
USER SHUTS DOWN ANO RECHARGE THE COBRAs( ONCE BATTERY I-EVEI. REACHES 1O%. YOU WILI.
ENTERTHIS CRITICAT LEVEL SHORTLY AFTER YOUR DISPLAY REACHES4OV IN THE VOLTAGE METER.

. Always wear a Helmet
. Always Start in the slow speed mode
. Grip both hand grips
. Stand with one foot on the deck and one foot on the ground
. Check brake level for positive braking action
. lnse* key and turn once clockwise
. Push the ground with one foot while turning the throttle slightly to accelerate
Steering your Cobra5K is achieved by slightly turning the handlebar and shifting your body
weight from side to side. Try out these different riding styles to find what suits you best.
1- Ride Style with one foot forward and one foot back, shift your weight from heel
to toe. Regular riders will have their left foot forward and goofy foot riders will have their right
foot forward
2- Ride Style with feet side by side, drop your hip and push handlebars to the side you are
steering towards
3- Ride Style with one foot forward in the center of the deck and one foot on the tail - this
style centers your weightfor quicker direction changes. This is an advanced riding style for
experienced riders
Pull hand brake lever toward the hand grips when you need to slow down or stop. when
braking at higher speeds, lean back so that your weight is over the back wheel to decrease your
stopping distance and maintain board control.
Always wear an ASTIM and CPSC certified helmet when riding. Make sure that chin strap is
attached before your rade and follow the helmet manufactures,nstructions for proper user and
fit.
Make sure to always wear shoes that have good traction on the board and will stay on your
feet.
Squeeze the hand brake lever to ensure there is positive braking action before starting your
ride.
Make sure you are standing on your board with your hands on the hand grips before engaging
the throttle and keep hands on hand grips when riding.
