TVS Scooty Pep Plus User manual

I
I
CONTACT(S) FOR SUPPORT
Incase you need any Clarification please contact above Dealer
Or
TVS Motor Company’s Area Offices (flip over for addresses)
Or
Toll Free Number : 1800-258-7111
Email : [e-mail]
Disclaimer : TVS Motor Company or any of its officials / Authorized Main dealer / Authorized Dealer do not ask customers for bank
/ card / wallet details / authentication. In case you face any such claim, please report to the relevant local authorities immediately.

II
CONTACT AT OUR AREA OFFICES
TAMILNADU-1, 3 & 4
1. TVS Motor Company Limited
V Floor, Gee Gee Universal,
No. 2, MC Nichols Road,
Chetpet, Chennai - 600 031.
Phone : [phone]
Email : [e-mail]
[e-mail]
TAMILNADU-2
2. TVS Motor Company Limited
No. 10, 2nd floor,
Shree Shanmugapriya Towers,
Kannuswamy Street,
Behind Hotel Annapoorna,
R S Puram, Coimbatore - 641 002.
Phone : [phone]
Email : [e-mail]
KERALA
3. TVS Motor Company Limited
Ambady Towers, Second Floor,
Door No. 27/631, A6,
Edappally-Pookkattupady Road,
Edappally PO., Cochin - 682 024.
Phone : [phone]
Email : [e-mail]
KARNATAKA-1, 2 & GOA
4. TVS Motor Company Limited
No. 600, Anand Surya, 2nd Floor,
15th Cross, 6th Phase, JP Nagar,
Opp. BMTC Bus Stop,
Bangalore - 560 078.
Phone : [phone]
Email : [e-mail]
[e-mail]
ANDHRAPRADESH -1 & 2
5. TVS Motor Company Limited
Rukumani Towers, First Floor,
No. 3-11-30, Plot No. 11,
Paigha Colony, Behind Anand Theater,
Secunderabad - 500 003.
Phone : [phone]
Email : [e-mail]
[e-mail]
MAHARASHTRA-1 & 2
6. TVS Motor Company Limited
No. 401, 4th Floor, The Chambers,
Plot No. 4/12/3, Near Ganapati Chowk,
Viman Nagar, Pune - 411 014.
Phone : [phone]
Email : [e-mail]
MAHARASHTRA-3 & CHATTISGARH
7. TVS Motor Company Limited
No. 502B, 6th Floor, B Wing,
Shriram Shyam Towers,
Near LIC Square, Sardar,
Nagpur - 440 001.
Phone : [phone]
Email : [e-mail]
[e-mail]
GUJARATH
8. TVS Motor Company Limited
109, Ayna Complex,
Opp. Suvarna Villa Bungalows,
100 ft Thaltej Hebbatpur Road,
Off : S.G. Highway, Thaltej,
Ahmedabad - 380 054.
Phone : [phone]
Email : [e-mail]

III
III
MADHYA PRADESH-1 & 2
9. TVS Motor Company Limited
No. 211-212, 2nd Floor,
Chinar Incube Business Centre,
Chinar Fortune City,
Near Brindhavan Dhaba,
Hosangabad Road,
Bhopal - 462 026.
Phone : [phone]
Email : [e-mail]
[e-mail]
RAJASTHAN-1 & 2
10. TVS Motor Company Limited
Plot No. 17-18,
2nd Floor of National Motors Building,
Jhotwara Industrial Area,
Jaipur - 302 012.
Phone : [phone]
Email : [e-mail]
[e-mail]
DELHI & HARYANA
11. TVS Motor Company Limited
D-3 & D-4, 2nd Floor,
Sector - 10, Noida,
Uttar Pradesh - 201 301.
Phone : [phone]
Email : [e-mail]
[e-mail]
PUNJAB & CHANDIGARH
12. TVS Motor Company Limited
4th Floor, Royal Business Park,
Chandigarh Ambala Highway,
Zirkapur - 140 603.
Phone : [phone]/465777
Email : [e-mail]
UTTAR PRADESH WEST
13. TVS Motor Company Limited
D-3 & D-4, 2nd Floor,
Sector - 10, Noida,
Uttar Pradesh - 201 301.
Phone : [phone]
Email : [e-mail]
UTTAR PRADESH CENTRAL & EAST
14. TVS Motor Company Limited
1st Floor, Cyber Tower, TC-34/V-2,
Vibhuti Khand, Gomti Nagar,
Lucknow - 226 010.
Phone : [phone]
Email : [e-mail]
[e-mail]
WEST BENGAL
15. TVS Motor Company Limited
Ground Floor & First Floor,
133 A. S. P. Mukherjee Road,
Opp. Tollygunge Police Station,
Kolkatta - 700 026.
Phone : [phone]
Email : [e-mail]
BIHAR
16. TVS Motor Company Limited
N-Plaza, Jamal Road,
P.S. Kotwali,
Patna - 800 001.
Phone : [phone]
Email : [e-mail]

IV
ORISSA & JHARKHAND
17. TVS Motor Company Limited
No. 303, 3rd Floor,
Creative Plaza, Rasulgarh,
Bhubaneshwar - 751 010.
Phone : [phone]
Email : [e-mail]
NORTH EAST STATES
18. TVS Motor Company Limited
147, Udayan, Ganesh Guri,
Opp. Punjab National Bank,
R G B. Road, Guwahati - 781 005.
Phone : [phone]
Email : [e-mail]

V
V
UNIQUE FEATURES OFTVS Scooty Pep+
ECO thrust CVTi’ Engine
Your Scooter is powered by Next Gen
90cc Ecothrust CVTi engine with
ignition map, higher spark energy,
all Aluminum, higher efficiency
charging system & improved fuel
economy. It uses digital IDI ignition
with inbuilt variable timing modes to
ensure that you get the best from
your engine.
Your scooter so has best in class
Power to Weight ratio with best in
class pickup. It makes your scooter
smooth and zip through traffic with
ease.
ECONOMETER®
Your speedometer has an
ECONOMETER® which indicates
whether you are riding in Economy
Mode. This unique feature of your
scooter enables to manage your
scooter fuel efficiency.
LONG-IDLING INDICATOR
The long-idling indicator (economy
mode blinking) reminds you to
switch off the ignition while waiting
at signals or when your scooter is
idle, thus helping you to save fuel
EaZy® CENTERSTAND
Your TVS Scooty Pep+ is fitted with
a “Effortless Centre Stand” a unique
feature to reduce the effort to place
the vehicle on stand.
LIGHT WEIGHT
Optimum weight 93kgs
COMFORTABLE HEIGHT
Best in class ground reachability –
768mm

VI
TELESCOPIC SUSPENSION
Makes bumpy rides more
comfortable
SYNCHRONISED BRAKING
TECHNOLOGY (SBT)#
Synchronised Braking Technology
reduces the stopping distance,
While keeping the stability intact.
PARKING BRAKE (REAR BRAKE
LOCK)#
The parking brake is another unique
safety feature which protects your
scooter from falling when it is
parked on a slope.
GLOVE BOX
Your TVS Scooty Pep+ is fitted with
unique feature of “Glove Box” to
carry the small things weighing upto
3 kg.
Briefcase hook
Your TVS Scooty Pep+ is fitted
with yet another unique feature of
“Briefcase hook” to carry the small
things weighing upto 3 kg.
BAG HANGER
For more convenience, another
luggage hook is locate just under
the seat of your scooter
UTILITY BOX
Your TVS Scooty Pep+ is fitted with
a “Utility box” has a large 10 litre
under-seat storage space to carry
your bags, books and belongings.
HELMET HOOK
Your TVS Scooty Pep+ is fitted with
a “Helmet hook” under the seat
assembly to conveniently place the
helmet

VII
VII
MFR HEADLAMP
Your TVS Scooty Pep+ is provided
with a “Multi focal reflector” - the
bright headlamp with a ‘Halogen
bulb’ for a better visibility in the dark.
LED DAY TIME RUNNING LAMP
(DRL)
DRL increases the conspicuity of the
vehicle during daylight conditions
“Drive with safety and style”. Refer
page no. 12 for details.
GLOW RING
Your TVS Scooty Pep+ is fitted with
a unique feature of “Glow Ring”
around the ignition lock for better
visibility of lock location even in dark.
SMART PHONE CHARGER*
(optional )
Your TVS Scooty Pep+ has a Smart
phone changer enable to charge
your mobile phone when you are
traveling. Refer page no. 19 for
operating procedure.

VIII
Dear Scooty Pep+ Owner,
Congratulations and welcome to the iconic world of Scooty Pep+. You are a proud owner of a scooter which has over
42 lakh happy customers all across the country.
You have made a perfect and smart choice by choosing the stylish Scooty Pep+. So go ahead and enjoy the comfortable
and happy ride on India's No.1 Mileage Scooter.
Its new ECOTHRUST CVTi engine makes it more durable and ensures you have a long-lasting loving association with
your Scooty. Also, telescopic suspension, EaZy* Centre stand will make all your rides wonderfully smooth.
This manual explains in detail, the many features, benefits and operations of your Scooty Pep+. Do read through your
manual carefully, it will help you get the best out of your vehicle, and keep it going strong for years to come.To ensure
reliable performance, we urge you to get your Scooty Pep+ serviced only at TVS Motor Company Authorized Main
Dealers / Authorized Dealers at regular intervals as specified by your service provider.
We wish you peppy, comfortable, safe and awesome trips for many years to come!
Happy riding!
TVS MOTOR COMPANY LIMITED
FOREWORD

IX
IX
This manual should be considered as a permanent part of the scooter and should remain with the scooter when
resold or transferred to a new owner.
All information, illustrations, photographs and specifications contained in this owner’s manual are based on the latest
product information available at the time of this publication. TVS Motor Company Limited may, however, incorporate
modifications or improvements on its vehicles at any time without notice, and therefore, in such events it is possible
that the relevant part of the owner’s manual does not apply to your vehicle.
Prior permission of TVS Motor Company Limited is required for quoting, copying or reproducing any part of this
owner’s manual.
Revision 1, Jan 2021
NOTICE
Accessories shown in the picture may not be part of the standard equipment.
Your scooter is provided with a day time running lamp (DRL).The DRL glows automatically once the ignition is
turned ON and continues to glow till the head lamp is switched ‘ON’.
Note

X
Operating this vehicle safely is an important responsibility of the rider. To help you make decisions on safety, we
have provided necessary operating procedure and other information in this manual. This information alerts you on
potential hazards that could hurt you or others. Since it is not possible to warn you about all the hazards associated
with operating or maintaining the vehicle, you must use your own judgment.
You will find important safety information in following form in this manual.These words carry the following connotations:
Disregarding this message might result in injury to the rider or deadly accidents.
Warning
This message indicates special procedures or precautions to be followed to avoid damage to the vehicle.
Caution
This message provides further clarification for clear understanding of any particular information.
Note
SAFETY INFORMATION

XI
XI
CONTENTS
RUNNING-IN INFORMATION 01
SAFE RIDING TIPS 02
KNOW YOUR TVS Scooty Pep+ 06
RIDING YOUR TVS Scooty Pep+ 20
MAINTENANCE 24
EXPRESS SERVICE 43
EXPERT ON WHEELS 44
PICKUP AND DROP 45
WARRANTY AND SERVICES 46
TECHNICAL SPECIFICATIONS 52
GENERAL INFORMATION 57

1
1
The first 1000 km is a crucial part of your scooter. Proper running-in operation during this period helps in ensuring a
maximum life and smooth performance of your scooter.
The reliability and performance of your scooter depends on the special care and restrain exercised during the running-
in period. It is especially important that you avoid operating the engine in high speed (RPM), which could expose the
engine parts to excessive stress. Recommended speed during the running-in is:
Maximum 50 km/h speed upto 1000 km (vary the engine speed for better mating of parts).
The first free service at 500 ~ 750 km is most important. During running-in period all the engine components and
other parts will have set in. All adjustments to be restored, all fasteners to be tightened. Engine cum transmission
oil to be replaced. Timely performance of the first free service will ensure optimum service life and performance
from the engine.
RUNNING-IN INFORMATION
Replacing the engine cum transmission oil during first service is most important for better life of engine. Always use TVS
TRU4 SKUUTA (SAE 10W30 API-SL, JASO MB) oil for better performance and life.
Caution

2
SAFE RIDING TIPS
SAFE RIDING RECOMMENDATIONS
Any two wheeler riding requires some precautions to be taken to ensure the safety of the rider, pillion rider and other
road users. These precautions are:
Familiarise yourself with newTVS Scooty Pep+
Riding skill and your mechanical knowledge form the foundation of safe riding practices. We suggest you to practice
riding TVS Scooty Pep+ in a low-traffic condition until you are thoroughly familiar with your vehicle and its controls.
Remember practice makes you perfect.
Riding apparel
Loose, fancy clothing can be uncomfortable and unsafe when riding a two-wheeler. Choose good quality two wheeler
riding apparel.
Know your limits
Ride within the boundaries of your own skill at all times. Knowing these limits and staying within them will help you
avoid accidents.
Two wheeler safety starts with wearing a good quality helmet. One of the most serious injuries that can happen is a
head injury. Always wear an ISI approved helmet that should fit your head comfortably and securely. You should also have
good quality goggles to protect your eyes and help your vision.
To prevent or minimize accident, never consume alcohol or drugs before or during the operation of your vehicle. Even minimal
consumption of these will affect the rider’s ability to control the vehicle.
Warning

3
3
Posture
Proper vehicle riding starts with proper posture.
1. Keep your elbows relaxed and flexible.
2. Sit and adjust yourself on seat so that arms and
shoulders are relaxed.
3. Look widely instead of gazing at one point.
One-hand riding is dangerous. Keep both hands firmly
on the handle bar and both feet securely on the floor
board. Under no circumstances should both the hands
be removed from the handle bar, as it is very dangerous.
Avoid use of mobile phones while riding as it could
lead to fatal accident.
Slow down to a safe speed before negotiating a corner.
If this is the first time that you are riding a vehicle of this
type, we suggest that you practice on a safe, open area
to become thoroughly familiar with the operation of the
vehicle.
Warning
Cornering
When cornering, centrifugal force works in a direction
perpendicular to the direction in which the vehicle
is moving. Centrifugal force increases in proportion
with speed and the radius of the corner.
During cornering, reduce speed so as to lessen the
effects of centrifugal force. By all means, avoid abrupt
application of brake or sudden steering.
Braking
For safe riding, it is very important to master the
braking techniques.
1. Close / release the throttle.
2. Hold the vehicle upright as you apply the brake.
3. Progressive application of brake is safer.
4. Apply both the brakes. ‘SBT’ provides
additional braking even when ‘Only Rear
brake’ is applied, But applying ‘Both the
brakes’ helps you use the full potential of the
brakes.
5. Riding down hills, while cornering and wet roads
close throttle and come to a slower speed to
avoid the loss of control over the vehicle due to
skidding.

4
Causes for poor braking
1. If the brake shoes or drum are worn out or if there
is water or oil on them, sufficient friction does not
develop and brakes do not work well.
2. Even when the brake works normally, if the road
surface is wet or the tyre surface is worn-out,
tyres do not take a firm hold on the surface,
increasing the stopping distance.
3. Approximately 60% braking effect is from front
brake. Non-usage of front brake causes poor
braking.
As the vehicle speed increases, the stopping distance
also increases progressively. Be sure that, you have
sufficient distance between you and the vehicle or
obstruction ahead of you.
Avoid directing the water jet directly towards brake
drums during water wash.
Using only the front or rear brake is dangerous and can
cause skidding and loss of control. Apply both the
brakes together and with great care on a wet road or
other slippery surfaces. Any abrupt braking on slippery
or irregular roads can cause loss of rider control.
Warning
ACCESSORY INSTALLATION AND SAFETY TIPS
Use extreme caution while selecting and installing
the accessories for your scooter.
The addition of unsuitable accessories can lead to
unsafe operating conditions. Your friendly Dealer
will assist you in selecting quality accessories and
installing them correctly.
While selecting the accessories, make sure that the
accessories should not obstruct lighting, steering,
suspension level and ground clearance.
Additional electrical equipments and controls
should not exceed the specified electrical system
load of the vehicle (capacity of battery and
magneto).

5
5
EMISSION CONTROL
All the TVS vehicles are tested in the factory for
optimum fuel efficiency and CO levels. If the vehicle
needs any adjustments, please consult nearest
TVS Motor Company Authorised Main Dealer or
Authorised Dealer.
While adequate care is exercised at the factory to
ensure that the emissions are within the limits, it is
essential for the owner to always maintain the scooter
in good condition by getting it periodically checked
and serviced by TVS Motor Company Authorised
Main Dealer / Authorised Dealer so that the emission
and fuel consumption levels are maintained as per
norms.
Crankcase emission control system
The engine of newTVS Scooty Pep+ is equipped with
a closed crankcase system to prevent discharging
crankcase emissions into the atmosphere. Blow-by
gas is returned to the combustion chamber through
the air cleaner and the fuel system.
Your vehicle is tested and certified for emission
which meets BS VI emission norms and is valid for
initial 12 months from the date of purchase. Get
your vehicle certified by the Government authorised
emission testing station every year (after initial 12
months of usage).
Note

6
VEHICLE IDENTIFICATION NUMBER
Serial numbers of both frame and engine are required for vehicle identification. They are also required to assist your
Dealer for ordering parts or referring to special information.
KNOW YOUR TVS Scooty Pep+
The frame serial number is stamped on the frame, at
the rear end below the seat assembly. Open the seat
assembly to read the frame number.
The engine serial number is stamped on the left
side of the engine, at the bottom, near center stand
mounting. See bottom to read serial number.
Frame number
Engine number
Control key number
Please fill the above boxes now for future reference
AK1NK2000049

7
7
LOCATION OF PARTS - HANDLE BAR
1. Horn switch
2. Turn signal lamp switch
3. Rear brake lever
4. Parking brake (rear brake lock)
5. Rear view mirror L
6. High / low beam switch
7. Speedometer assembly
8. Rear view mirror R
9. Front brake lever
10. Throttle grip
11. Lights ON/OFF switch
12. Electric starter switch
13. Ignition cum steering lock
14. Briefcase hook
7
78
8
7
9
7
10
7
7
7
1
7
2
7
3
7
57 6
7
4
11
7
12
13
7
14

8
CONTROL KEY
TVS Scooty Pep+ comes with a pair of identical
control keys. These keys are to operate ignition cum
steering lock, seat lock and fuel tank cap.
IGNITION CUM STEERING LOCK
TVS Scooty Pep+ is provided with a self illuminating
ring (glow ring) around the ignition cum steering lock
for better visibility of lock location in darkness. The
three positions of the switch are described below.
1. ‘OFF’ position
All the electrical circuits are turned ‘OFF‘ in this
position. Engine will not start. Key can be taken out.
2. ‘ON’ position
In this position, all the electrical circuits are turned
‘ON’ and the engine can be started now. Key cannot
be removed in this position.
3. ‘LOCK’ position
TVS Scooty Pep+ steering can be locked in both ‘left’
and ‘right’ directions.
Turn the handlebar to the ‘left’ or ‘right’. Press the
key IN and rotate it to the ‘LOCK’ position from ‘OFF’
position. All electrical circuits are deactivated and the
steering is locked. Control key can be removed from
the lock.
Insert the key into the lock and press the key IN
and turn it to ‘OFF’ or ‘ON’ position to unlock the
steering.
Note
When you switch on ignition key, the pump priming
noise may be heard, which is normal. Avoid frequent
SWITCH-OFF & ON of ignition key, to avoid unnecessary
run of fuel pump.
The speedometer back illumination, tail lamp and license
plate lamp glow automatically once the ignition key is
turned ‘ON’ without activating any other switches.

9
9
SPEEDOMETER ASSEMBLY
1. Speedometer
Indicates vehicle speed in kilometers per hour.
Always ride the vehicle in ‘economy mode’ for better fuel
efficiency.
If the battery voltage is very low, economy mode lamp
will blink once you switch ‘ON’ the ignition key till you
start the vehicle. Electric starter will not work in this
condition. Use kick starter only. Contact TVS Motor
Company Authorised Main Dealer or Authorised Dealer.
Note
Leaving the ignition cum steering lock in ‘ON’ position
will drain the battery when the vehicle is not in use.
“Switch Off” and take the key out when the vehicle is
not in use. For safety always lock the steering.
Caution
2. Odometer
Registers and displays the total distance covered by
the vehicle in kilometers. The last digit denotes one
tenth of a kilometer.
3. Economy indicators
Eco indicator (green lamp) indicates that the vehicle
is running in economy mode which gives better fuel
economy.
4.Turn signal indicator lamp ( )
Flashes when the ‘right’ or ‘left’ side turn signal
indication is activated.
5. Fuel gauge
Fuel gauge indicates the approximate quantity of fuel
available in the fuel tank. Once the fuel indication is
in red band (marked in the dial) re-fill the fuel as soon
as possible.
7
1
7
7 7
7
3
4 5
6
Never attempt to move the vehicle when the steering is
locked, you may lose balance.
Warning
7
2
7
7
