Metos 92/04 VTC User manual

ELECTRIC RANGES CERAMIC GLASS
900 Series
TYPE: 92/04 VTC, 94/04 VTC, 94/04 VTCE, 92/04 TVTC, 94/04 TVTC
User Manual
S/N: Valid from:23. 10. 2007 Rev.: 1.1

24.10.2007 Rev. 1.1
Dear Customer,
Congratulations on deciding to choose a Metos appliance for your kitchen activities. You
made an excellent choice. We will do our best to make you a satisfied Metos customer
like thousands of customers we have around the world.
Please read this manual carefully. You will learn correct, safe and efficient working meth-
ods in order to get the best possible benefit from the appliance. The instructions and hints
in this manual will give you a quick and easy start, and you will soon note how nice it is
to use the Metos equipment.
All rights are reserved for technical changes.
You will find the main technical data on therating plate fixed to the equipment. When you
need service or technical help, please let us know the serial number shown on the rating
plate. This will make it easier to provide you with correct service.
For your convenience, space is provided below for youto record your local Metos service
contact information.
METOS TEAM
Metos service phone number:...............................................................................................
Contact person:....................................................................................................................

24.10.2007 Rev. 1.1

24.10.2007 Rev.
1. General information ..................................................................................... 1
1.1 Symbols used in the manual .......................................................................................... 1
1.2 Symbols used on the appliance ...................................................................................... 2
1.3 Checking correspondence between the appliance and the manual ................................ 2
2. Safety .............................................................................................................. 3
2.1 Using the appliance safely ............................................................................................. 3
2.2 Safety instructions in the event of a fault ...................................................................... 3
2.3 Disposing of the appliance ............................................................................................ 3
3. Functional description .................................................................................. 5
3.1 Appliance application .................................................................................................... 5
3.1.1 Prohibited use/Improper use .................................................................................. 5
3.2 Construction .................................................................................................................. 5
3.3 Cooking tops .................................................................................................................. 6
3.3.1 ............................................................................................................................... 6
3.4 Electric oven .................................................................................................................. 6
3.5 Cooking top operating principle ................................................................................... 7
3.5.1 Ceramic glass ......................................................................................................... 7
3.5.2 Operating switches and indicator lights ................................................................. 7
4. Operating instructions ................................................................................. 9
4.1 Before use ...................................................................................................................... 9
4.1.1 Preparazione al funzionamento .............................................................................. 9
4.2 Using the appliance ..................................................................................................... 10
4.2.1 Switching on the cooking top .............................................................................. 10
4.2.2 Cooking ................................................................................................................ 11
4.2.3 Switching off ........................................................................................................ 11
4.2.4 Lighting the electrical oven ................................................................................ 12
4.3 After having used the appliance .................................................................................. 13
4.3.1 Cleaning ............................................................................................................... 13
4.3.2 Idle period ............................................................................................................ 14
4.3.3 Periodic maintenance ........................................................................................... 14
4.3.4 Cleaning air filter ................................................................................................. 15

24.10.2007 Rev.
5. Installation ................................................................................................... 17
5.1 General information ..................................................................................................... 17
5.1.1 Regulatory installation conditions ....................................................................... 17
5.2 Exhausting fumes ........................................................................................................ 17
5.3 Possible environmental interference ............................................................................ 17
5.4 Storage ......................................................................................................................... 18
5.5 Unpacking the appliance ............................................................................................. 18
5.6 Disposal of packaging materials ................................................................................ 18
5.7 Positioning ................................................................................................................... 18
5.8 Electrical connections ................................................................................................ 19
5.8.1 General information ............................................................................................. 19
5.8.2 Connection requirements ..................................................................................... 19
5.8.3 Connecting the cable for Y-type electrical connection to the appliance terminal
block (ceramic glass top and sides). ............................................................................. 20
5.8.4 Connecting the cable for Y-type electrical connection to the appliance terminal
block [model with electric oven]. ................................................................................. 21
5.8.5 Equipotential terminal .......................................................................................... 23
5.9 Training of personnel .................................................................................................. 24
5.10 Rating plate ................................................................................................................ 24
6. Troubleshooting .......................................................................................... 25
8. Technical specifications .............................................................................. 39

24.10.2007 Rev. 1.1
General information
1
1. General information
Read the instructions in this manual carefully, as they contain important information on
how to install, use and service the appliance safely, properly, and effectively.
Keep this manual in a safe place so that it can be used as reference by other operators of
the appliance.
This appliance should be installed following the instructions provided by the manufactur-
er and in compliance with all applicable local regulations. Electricity and water connec-
tions to the appliance must be performed by qualified technicians.
The operators who will use the appliance have to be specifically trained beforehand.
In the event of failure or malfunction, switch off the appliance. The periodic functional
checks requested in this manual have to be carried out according to the instructions. Have
the appliance serviced by a technically qualified person duly authorized by the manufac-
turer that uses genuine spare parts.
Failure to comply with the above may jeopardise the appliance’s safety.
1.1 Symbols used in the manual
This symbol informsus about a potentially hazardous situation. The instructions provided
are mandatory in order to prevent injury.
This symbol informs us about the right way to act in order to prevent bad results, damage
to the appliance, or hazardous situations.
This symbol informs about tips and hints that help the user to get the best performance
from the appliance.
This symbol informs about a function that should be taken into account for self-control
purposes.

24.10.2007 Rev. 1.1
General information
2
1.2 Symbols used on the appliance
This symbol on a part warns the user that there are electrical terminals behind it. There-
fore, the concerned part should only be removed by qualified personnel.
1.3 Checking correspondence between the appliance and the manual
The serialnumber for the appliance is given ontherating plate. If the manuals are missing,
it is possible to order new ones from the manufacturer or your local representative. When
ordering new manuals, it is essential to quote the serial number shown on the rating plate.

24.10.2007 Rev. 1.1
Safety
3
2. Safety
2.1 Using the appliance safely
Being an appliance designed for professional use only, it should be operated exclusively
by qualified personnel.
Never leave the appliance unattended while in use!
Do not move the appliance while hot!
Personnel who wear pacemakers or metal prostheses must take care when using the appli-
ance. When the appliance is operating, keep the part with the prosthesis or pacemaker
away from the work surface.
For safe use, make sure to consult the specialist medical service for wearers of prostheses
or pacemakers.
2.2 Safety instructions in the event of a fault
In the event of failure or malfunction, disconnect the appliance from the power supply.
Call the technical support service.
If an emergency occurs, use the main switch to disconnect power to the appliance.
2.3 Disposing of the appliance
This appliance was built using recyclable raw materials and contains neither hazardous
nor toxic substances. To dispose of the appliance, strictly follow all local regulations in
force in the place where it is installed. Packaging materials have be separated according
to their types and delivered to thepertinent collection sites. Please abide by environmental
protection regulations.
A crossed-out wheeled bin symbol means that the appliance, at the end
of its useful life, has to be disposed of separately from other waste. At
such time, therefore,bring this specific appliance to a collection point
specialising inrecycling electric and/or electronicequipment;or,bring
it to the local representative when purchasing a similar type of appli-
ance. Proper separate waste collection promotes recycling and contrib-
utes to preventing possible negative effects on both the environment
and on human health. Users ridding themselves of the appliance in an
unlawful manner are punishable by law.

24.10.2007 Rev. 1.1
Safety
4

24.10.2007 Rev. 1.1
Functional description
5
3. Functional description
3.1 Appliance application
The electric induction cooker is designed for cooking products in suitable pots or pans
placed on the ceramic glass top.
The electric cooker was designed to cook products in suitable pots or pans placed on the
ceramic glass top.
3.1.1 Prohibited use/Improper use
The appliance is not designed for cooking directly on the glass surface, like a fry-top.
The Manufacturer declines any liability for faults due to incorrect installation or unsuita-
ble use of the appliance. In these cases, the warranty is invalid.
3.2 Construction
Stainless-steel support structure placed on 4 height-adjustable feet. Outer covering and
top entirely in stainless steel.
Unbreakable ceramic glass top, fixed "watertight" on the top.
Light indicating possible residual heat still present on the ceramic glass top.

24.10.2007 Rev. 1.1
Functional description
6
3.3 Cooking tops
3.3.1
Fig. 1a1. Cooking zone, 180 mm diameter (1.3 kW)
2. Cooking zone, 270 mm diameter (2.1 kW)
• Each cooking zone is marked by silkscreened concentric circles, indicating the
various heating levels;
• power adjustment from minimum to maximum;
3.4 Electric oven
• Static oven in stainless steel, with adjustable temperature control from 50° to
300°C (122°-572°F);
• two sets of heating elements (one on upper and one on lower side) adjustable sep-
arately through a selector and a sole thermostat;
• safety thermostat against any overtemperature;
• knobs fitted with watertight gasket;
• rack support structure featuring a non-tip device and two loading positions;
• removable high-radiance ribbed cast iron floor.

24.10.2007 Rev. 1.1
Functional description
7
3.5 Cooking top operating principle
3.5.1 Ceramic glass
The heating elements installed under the ceramic glass top heat the surface to the required
temperature, and a max. of 550 °C can be reached in just a few minutes.
The pot absorbs the heat by means of contact and radiance.
When cooking food, energy saving depends on the quality of the pots and, in particular,
their bottoms.
The pot diameter must match that of the cooking zone. Use pots suitable for electric hot-
plates.
3.5.2 Operating switches and indicator lights
Fig. 2 1. Cooking zone temperature adjustment knob
2. Line lamp
3. Safety trip indicator lamp
4. Oven on light (model with oven)
5. Oven line lamp (model with oven)
6. Oven heating direction knob (model with oven)
7. Oven thermostat knob (model with oven)

24.10.2007 Rev. 1.1
Functional description
8

24.10.2007 Rev. 1.1
Operating instructions
9
4. Operating instructions
4.1 Before use
If the glass breaks, the appliance cannot be used due to the risk of electric shocks.
4.1.1 Preparazione al funzionamento
Remove all packaging materials and adhesive films very carefully. Remove the protective
film from the panels, ensuring no traces of glue are left on the steel surface; if necessary,
use a non-flammable solvent to remove the glue.
Before cooking for the first time, it is advisable to carefully clean the appliance, and in
particular the ceramic glass top, using hot water and a sponge.
To clean the stainless steel parts, ensure the detergent is non-abrasive and suitable for use
with stainless steel.
After cleaning the appliance, rinse it well with clean water and wipe it dry with a clean
cloth.
Never use a water jet to clean the appliance!

24.10.2007 Rev. 1.1
Operating instructions
10
4.2 Using the appliance
4.2.1 Switching on the cooking top
Vetroceramica
Turning the knob (pos. 1 in Fig. 2) to thedesired position switches on the power indicator
light (pos. 2 in Fig. 2) . This means that the appliance is on and the selected cooking zone
is beginning to heat up. This type of heating takes place when the heating elements are
enabled and heat spreads through radiation.The heating elements temperature can be ad-
justed through a power regulator.
Fig. 3 1. OFF position
2. Minimum temperature
3. Maximum temperature
4. Switching on the second heating element
By turning the knob further, for a few seconds, until it reaches (pos. 4 in Fig. 3), the se-
lected zone reaches maximum heat thanks to the second heating element switching on.
To bring the appliance back to its normal operating status -with only one heating element
switchedon-,turn theknob to the 0 position;if additionalheat is needed, select the desired
temperature.

24.10.2007 Rev. 1.1
Operating instructions
11
4.2.2 Cooking
• Select the cooking temperature by means of the energy regulator.
• When cooking food, energy saving depends on the quality of the pots and, in par-
ticular, their bottoms.
• The pot diameter must match that of the cooking zone. Use pots suitable for elec-
tric hot-plates.
• During cooking always use the lid.
• Use the maximum temperature to reach the cooking temperature, then lower it
enough to continue cooking.
Never leave the appliance unattended when switched on!
In daily use, only use perfectly dry pots. Do not place wet containers or objects with con-
densate, e.g. lids, on the ceramic glass top.
4.2.3 Switching off
Switch the cooker off by turning the knob to position 0; the green light also goes off.
The cooking hob may still be red hot! In any case, the appliance has another warning light
indicating any residual heat present on each cooking zone.

24.10.2007 Rev. 1.1
Operating instructions
12
4.2.4 Lighting the electrical oven
Choose the heating direction on the knob indicated as (pos. 3 in Fig. 6). Set the cooking
chamber temperature by turning the oven operating thermostat knob in clockwise direc-
tion (from pos. 4b to pos. 4c in Fig. 6), lthe heating elements start to operate and the line
pilot lamp (pos. 2 in Fig. 6) lights up together with the oven indicator lamp (pos. 1 in Fig.
6). When the selected temperature has been reached, the indicator lamp turns off. The
oven temperature can be set between 50° and 300°C and to intermediate values.
A bad smell during the first ignition is considered within the norm and it is due to theover-
heating of the oil residues used for the metal processing and to insulating materials. Dur-
ing the first ignition, without putting food into the chamber, set the oven to a temperature
of 300°C until the smell disappear.
Fig. 6 1. Electrical oven indicator lamp
2. Line pilot lamp
3. Heating direction knob
4. Electrical oven thermostat knob
3a. OFF heating position
3d. Heating direction of the top heating element
3c. Heating direction of the bottom heating element
3b. Heating direction of both heating elements (top and bottom)
4a. OFF position
4b. 50°C position (minimum temperature)
4c. 300°C position (maximum temperature)

24.10.2007 Rev. 1.1
Operating instructions
13
4.3 After having used the appliance
4.3.1 Cleaning
Before cleaning, switch the appliance off and disconnect its power supply.
General information
The main causes for stainless steel wear or corrosion are:
• using abrasive or acid detergents especially chlorine-based products, such as hy-
drochloric acid or sodium hypochlorite (bleach). Therefore, before buying a clean-
ing product, make sure it does not corrode stainless steel (also see paragraph
"Routine cleaning" below);
• ferrous deposits (such as rust dissolved in the water through thepipe system, espe-
cially after a long time without being used), therefore have to be avoided; do not
use wire wool to remove stubborn food deposits. Use, instead, pads or spatulas
made of stainless steel or softer, non-ferrous materials;
• Do not use abrasive steel wool pads to clean the ceramic-glass top; it could get
scratched.
• stagnation of substances having acid components such as vinegar, lemon juice,
sauces, salt, etc. Avoid prolonged contact of the stainless steel parts of the appli-
ance with those substances. The evaporation of saline solutions over the appliance
surfaces is particularly harmful to them.
Routine cleaning
Cleaning the appliance thoroughly on a daily basisis the key to keeping it in perfect work-
ing condition and to prolong its life. Clean the appliance with a damp cloth using water
and soap or detergents, provided that they are not acid or abrasive as discussed above.
Such detergents should not even be used to wash the floor near the appliance, as their
fumes may deposit on the steel surfaces and damage them. If the appliance is very dirty,
use a Scotch-BriteTM type synthetic sponge. Rinse it well with clean water and wipe it
dry with a clean cloth. Do not rub the appliance with steel wool pads as they could leave
rust stains. For the same reason, avoid touching the appliance with ferrous objects.
Never use direct water jets to clean the appliance because this could result in water enter-
ing into it and damaging it.
Do not use abrasive steel wool pads to clean the ceramic-glass top; it could get scratched.
Stains and abrasions on the steel surface
Scratches and dark stains may be smoothed or removed using stainless steel wool pads or
synthetic abrasive sponges, which should always be rubbed in the same direction as the
satin finish.

24.10.2007 Rev. 1.1
Operating instructions
14
Rust
If you need to remove rust stains, contact manufacturers of industrial detergents to find a
suitable product. Industrial descaling products can also be used to that end. After remov-
ing stains and rinsing off the appliance with clean water, an alkaline detergent may be re-
quired to neutralize any acid compounds left on the surface.
Cleaning the ceramic glass top
To ensure best use of the appliance, make sure to follow this advice :
• firstly, remove any residual grime and food from the top with a special scraper
(NON-ABRASIVE);
• pour a few drops of suitable detergent on the top when cold and rub with a paper
towel or soft cloth;
• rinse the top and dry with a clean cloth or paper towel;
It is advisable to regularly clean the top whenever it is used.
If aluminium foil, plastic wrap, sugar or foods containing sugar melt on the hob surface
they must be immediately removed from the hot cooking zone with a non-abrasive scrap-
er. This will prevent damage to the surface.
Before cooking foods with high sugar content (e.g. jam) apply a suitable protective prod-
uct on thecooking surface to prevent damaging it in case of spilling from the cooking con-
tainer.
4.3.2 Idle period
If the appliance will be idle for some time, clean it and wipe it dry first, and then apply a
film of a suitable product (such as vaseline oil spray or similar) to protect it. Switch the
power off fitted upstream from the appliance.
In order to prevent corrosion spots from forming, ensure that any salt residues are care-
fully removed from the sides, internally and externally.
4.3.3 Periodic maintenance
Only qualified personnel are allowed to carry out service and maintenance operations.
The following maintenance operations have be carried out at least once a year:
• checking that all control and safety devices operate correctly;
We recommend signing a service agreement providing for at least one check-up a year.
