Metos ARDOX S2 User manual

Installation and Operation Manual
FLAT-TOP RANGE
ARDOX S2, S4, S6,Tabletop, Drop-In
Accessories
CHEF 200, CHEF 220, CHEF 240,
height adjustment, cupboard
Valid from 01.08.2011 Rev.: 5.0 (17.4.2019)
Original instructions
4210016, 4210023, 4210143, 4210048, 4210168, 4210104, 4210111, 4210129, 4210136, 3752018, 3752015, 3752019, 3752017,
3753577, 3753286, 3753289

2|
Rev. 5.0 (from 01.08.2011)
Metos ARDOX S
CAUTION: Read the instructions before using the machine.
Manufacturer:
Metos AS
Saha tee 18, Loo
74201 Harju maakond
www.metos.ee

|3
Rev. 5.0 (from 01.08.2011)
Metos ARDOX S
CONTENTS
1. General .......................................................................................................................................................4
1.1. Symbols used in the manual .......................................................................................................................4
1.2. Symbols used on the appliance...................................................................................................................4
1.3. Checking the relationship of the appliance and the manual .......................................................................4
2. Safety .........................................................................................................................................................5
2.1. Safe use of the appliance ............................................................................................................................5
2.2. Using the height adjustment stand .............................................................................................................5
2.3. Disposal of the appliance ............................................................................................................................5
3. Functional description ..............................................................................................................................6
3.1. Application of the appliance ........................................................................................................................6
3.1.1. Prohibited use .............................................................................................................................................6
3.2. Operating principle and construction...........................................................................................................6
4. Operation instructions ..............................................................................................................................8
4.1. Before use...................................................................................................................................................8
4.2. Before using the height adjustable stand....................................................................................................8
4.3. Operation.....................................................................................................................................................8
4.3.1. Selecting cookware .....................................................................................................................................8
4.3.2. Direct cooking .............................................................................................................................................8
4.4. Using the range...........................................................................................................................................8
4.5. Height adjustable stand...............................................................................................................................9
4.5.1. Adjusting the height ....................................................................................................................................9
4.6. After use......................................................................................................................................................9
4.6.1. Cleaning.......................................................................................................................................................9
4.6.2. Service ...................................................................................................................................................... 10
5. Installation ............................................................................................................................................... 11
5.1. General...................................................................................................................................................... 11
5.2. Transporting and unpacking the range....................................................................................................... 11
5.3. Positioning the range................................................................................................................................. 11
5.3.1. Positioning the Ardox S range and the Tabletop range .............................................................................. 11
5.3.2. Positioning the Ardox S Drop-In range.......................................................................................................12
5.4. Electrical installation..................................................................................................................................12
5.4.1. Ranges ......................................................................................................................................................12
5.4.2. Height adjustable stand.............................................................................................................................13
5.5. Test-run......................................................................................................................................................14
6. Troubleshooting.......................................................................................................................................15
7. Technical specifications ..........................................................................................................................16

4|
Rev. 5.0 (from 01.08.2011)
Metos ARDOX S
1. General
Carefully read the instructions in this manual as they contain important information regarding proper,
efficient and safe installation, use and maintenance of the appliance.
Keep this manual in a safe place for eventual use by other operators of the appliance.
The installation of this appliance must be carried out in accordance with the manufacturer’s instructions
and following local regulations. The connection of the appliance to the electric and water supply must be
carried out by qualified persons only.
Persons using this appliance should be specifically trained in its operation.
Switch off the appliance in case of failure or malfunction. The periodical function checks requested in the
manual must be carried out according to the instructions. Have the appliance serviced by a technically
qualified person authorized by the manufacturer and using original spare parts.
Not complying with the above may put the safety of the appliance in danger.
1.1. Symbols used in the manual
This symbol informs about a situation where a safety risk might be at hand. Given instructions are man-
datory in order to prevent injury.
This symbol informs about the right way to perform in order to prevent bad results, appliance damage
or hazardous situations.
This symbol informs about recommendations and hints that help to get the best performance out of the
appliance.
1.2. Symbols used on the appliance
This symbol on a part informs about electrical terminals behind the part. The removal of the part must be
carried out by qualified persons only.
1.3. Checking the relationship of the appliance and the manual
The rating plate of the appliance indicates the serial number of the appliance. If the manuals are missing,
it is possible to order new ones from the manufacturer or the local representative. When ordering new
manuals it is essential to quote the serial number shown on the rating plate.
STOP

|5
Rev. 5.0 (from 01.08.2011)
Metos ARDOX S
2. Safety
2.1. Safe use of the appliance
Because the range is a heated appliance that has hot surfaces during normal use, the following warnings
and instructions must be followed in order to avoid burns:
• During long-time operation even the frame surrounding the flat top gets hot.
• The capability of the flat top to store and even out the heat also keeps it hot for a long time after
switching it off.
• For safe handling of cookware on the cooking top, always use heat protective gloves.
• Do not leave the range on for long periods totally without supervision.
2.2. Using the height adjustment stand
To ensure safe use of the device, the following safety instructions should be followed:
• When moving the appliance or servicing it, it must be disconnected from the mains.
• When washing, be careful so that the electrical equipment of the appliance does not come in contact
with water. Do not use a water jet for washing the appliance.
• Exposing the appliance to rain is prohibited.
2.3. Disposal of the appliance
Once the unit has reached the end of its useful life, it must be disposed of in compliance with local
rules and regulations. The best way of dealing with or recycling any substances which potentially have
an adverse impact on the environment is to dispose of them through a proper problem waste company.
The crossed-out wheeled bin means that within the European Union the product
must be taken to separate collection at the product end-of life.
This applies to your device but also to any enhancements marked with this sym-
bol. Do not dispose of these products as unsorted municipal waste.

6|
Rev. 5.0 (from 01.08.2011)
Metos ARDOX S
3. Functional description
3.1. Application of the appliance
The Ardox S solid flat top cooking units are intended for cooking of food directly on the hot surface of the
solid flat top and also for preparing different kind of food staff using cookware.
3.1.1. Prohibited use
Use of appliance for any other purposes than stated above is prohibited.
The manufacturer shall not be held liable for any situations which may arise from failure to comply with
the warnings and instructions given in this manual.
3.2. Operating principle and construction
In addition to a single range, there are combinations of a range and Chef-series oven or proving cabinet
This manual covers the Ardox range, while Chef-series products have their own manuals.
The tabletop appliance is intended for installation on suitable kitchen flat working surface. The overall
dimensions of the working surface should allow to place unit so that it supported on the all four legs.
The drop-in model is intended for drop-in installation only.
The Drop-In model comes supplied with a separate control panel to be installed. See ”Installation” for
more information.
The appliance is equipped with two, four or six cooking zones.
Each cooking zone is equipped with a step less power regulator. To switch on cooking zone turn knob in
clockwise direction. A green pilot light for every cooking zone indicates that the power is on.
Control panel, Ardox S 2, 4 and 6
Front cooking zone
1. Power regulator
2. Symbol of cooking zone
3. Pilot light, power on
Rear cooking zone
4. Pilot light, power on
5. Symbol of cooking zone
6. Power regulator
STOP
123456

|7
Rev. 5.0 (from 01.08.2011)
Metos ARDOX S
Control panel, Ardox S Tabletop
Appliance is equipped with removable grease box. (1).
Left cooking zone
2. Pilot light, power on
3. Power regulator
Right cooking zone
4. Power regulator
5. Pilot light, power on
23 4 51
Control panel Ardox S, Drop-In
Because the appliance is intended for drop-in installation in customer table top the controls ( power
regulators and pilot lamps) are delivered separately for installation in suitable location during installation.
Refer to chapter “Installation” for details.
Height adjustable stand
The stand is ergonomically designed to provide the correct working position by means of a height adjust-
ment. The right working height is between 70-90 cm, depending on the worker’s length.
The stand is made of stainless steel.
The height adjustment is done by means of electric motors.
The operating switch is located on the stand and can be detached from the holder.

8|
Rev. 5.0 (from 01.08.2011)
Metos ARDOX S
4. Operation instructions
4.1. Before use
There is a slight smell of metal and thermal insulation when the range is heated for the first time. This is
completely normal and disappears by heating the range. Before using the range for the first time, heat it
at maximum temperature until the smell disappears.
4.2. Before using the height adjustable stand
Before starting to use, check that there is no transport damage that could jeopardize safe use.
4.3. Operation
4.3.1. Selecting cookware
You can use the same cookware on the flat-top range as on the conventional range.
To get the best benefit from the range as well as from the cookware observe the following:
• Always lift pans, do not drag.
• Use good quality flat-based cookware.
• Wait for pans to cool before putting them in cold water.
• Always ensure that pans have clean, dry bases before use.
• Ensure that pan handles are positioned safely and away from heat sources.
• Always use pan lids except when frying.’
Remember that good quality pans retain heat well, so generally only low or medium heat is necessary.
4.3.2. Direct cooking
You can use unit as a griddle for cooking food directly on the hot surface of the solid flat top and for
keeping warm of food.
4.4. Using the range
Ranges intended for use aboard ships are equipped with a kettle support. Using a range without the
kettle support is prohibited (not Drop-In models).
During installation a mains switch may have been fitted near the range, often on a wall nearby. Check that
the mains switch is in the ON position.
The range is controlled with power regulators and pilot lights (see Figure “Operating panel”). Each
cooking zone has its own stepless control switch for regulating the power. The green cooking light
indicates when the cooking zone is switched on.
Start cooking on maximum power (turn the knob 3/4 rounds clockwise). When boiling starts decrease
the power as needed.
Do not leave the cooking zone on without any load because it then overheats, which considerably
decreases its operating life. By turning the cooking zone off when not needed energy is also saved and a
cooler working environment is achieved (although the chrome cooktop will deliver much less heat to the
environment than traditional ranges).
If there are longer interruptions in the electricity distribution, all power regulators of the range should be set to
the 0 position. This should be done in order to prevent unexpected start-up of the range when the electricity
comes back on again.

|9
Rev. 5.0 (from 01.08.2011)
Metos ARDOX S
Applies to the Tabletop model: Make sure that the overflow grease box is in place during cooking.
Otherwise, grease, oil or liquids may leak inside the device. Check the overflow vessel from time to time
and empty if necessary.
4.5. Height adjustable stand
4.5.1. Adjusting the height
Adjust the height by pressing the switch on the control panel. The control panel is located on the right
side of the table and is removable from its holder.
The maximum operating time per hour is 6 minutes and the maximum load is 200 kg.
When going down, make sure that there is no obstacle in between.
4.6. After use
4.6.1. Cleaning
Always disconnect the appliance from the mains before cleaning.
Use of a hose or pressure washer to clean the range is forbidden
Before cleaning the range, please remember that it remains hot for a long time after use
Do not rub the range with a scrubber or abrasive cleaner.
The ranges and the height adjustable stands are electrical appliances, which means that there are
restrictions regarding cleaning them with water. Clean the outside of the range with a damp cloth only
to avoid water getting into the air inlets.
Cleaning of stainless steel surfaces
• When cleaning the stainless steel surfaces of the appliance, use a slightly alkaline detergent (pH 8-10)
diluted in water according to instructions.
• Cleaning is very easy if possible spillovers are removed immediately with a damp cloth.
• Sugar and mixes containing much sugar must be removed immediately, because later removing will
be laborious.
Cleaning of chromium-plated surface of the solid flat top
• Never use abrasive materials or detergents.
• Never use chemical agents (e.g. oven cleaner).
• The plate should be kept clean at all times. Any food residue left on the surface must always be
removed immediately after use. To remove food residue, heat up the plate at approx. 140°C and put
on the surface ice flakes or cubes. Residue easy peel off with the help of suitable scrapper.
• Once the plate has cooled down (to 80°…100°C), wipe over the surface with cloth soaked in water
or vinegar.
• Once the plate has cooled completely, clean the surface with a non-scratch cleaning cream/fluid to
bring back its original shine.
• Rinse and wipe over the plate with a damp cloth. Dry.
Applies to the Tabletop model: Make sure that the overflow grease box is in place during cooking.
Otherwise, grease, oil or liquids may leak inside the device. Empty the overflow vessel after cleaning.
UP DOWN
STOP
STOP
STOP
STOP

10 |
Rev. 5.0 (from 01.08.2011)
Metos ARDOX S
Sugar and mixes containing much sugar must be removed immediately, because later removing will be
laborious.
A clean cooking top ensures efficient heat transfer to the cookware. Cooking is then fast and the
operating life of the heating elements is extended.
4.6.2. Service
This appliance does not contain parts which can be serviced by the user. Maintenance must be carried
out by an authorized agent.
In the event of fault or malfunction, switch the appliance off at the mains. Contact an agent authorized
by the manufacturer and use original spare parts.
STOP

|11
Rev. 5.0 (from 01.08.2011)
Metos ARDOX S
5. Installation
5.1. General
The installation of the appliance must be carried out in accordance with the manufacturer’s instructions
and in compliance with local rules and regulations. These instructions must be used together with the
installation drawing.
This appliance may be connected to the mains electricity by qualified persons only
The ground terminal is located at the back of the appliance at the bottom and is marked with the
corresponding symbol .
5.2. Transporting and unpacking the range
The range is best transported in its own package, which protects it from outside damage. If it is necessary
to unpack the range, possible lifting must be done from the bottom frame using suitable spacers of
wood. To prevent damage, the top of the range must not be used as a worktop on the construction site
or during installation.
5.3. Positioning the range
5.3.1. Positioning the Ardox S range and the Tabletop range
Because the temperature of the cooking zone accidentally forgotten on without a pan may reach even
350°C, it is mandatory to follow local fire safety regulations when installing the range. t.
When installing the range, care should be given to ensure that there is a free passage of cooling air
around the range and that there are no other sources of heat near the cooling vents.
It is recommended that the range is placed under a hood because of the steam arising during cooking.
The range is positioned in the installation place and adjusted in a horizontal position using the adjustable legs.
On ranges fitted with an oven, the horizontal position should be checked from the runners of the oven in
order to achieve good browning results.
When the range is in the right place and in a horizontal position, fix it firmly to the floor. Models for use
on land are fixed by the plates on the back legs and ranges intended for use on ships by the plates on
each leg.
The Tabletop model is designed to be placed on a flat, horizontal work surface. The level should be large
enough for the device to rest on all four feet. The final adjustment is done by adjusting the adjustment
feet. After adjustment, check that the unit is standing firmly and that the feed cable is not pinched under
the feet.
STOP
STOP

12 |
Rev. 5.0 (from 01.08.2011)
Metos ARDOX S
5.3.2. Positioning the Ardox S Drop-In range
The appliance is delivered partly disassembled. Depending of the model of the appliance the package
contains the following parts:
Ardox S2 Drop-in Solid Top Cooking Unit:
• Hob assembly 3753288 1 pc.
• Frame 3753263 1 pc.
• Connection link 3753452 2 pc.
• Screws ISO 1481-ST4,8x16 C (or other suitable type) 20 pcs.
• Grease box 3753432 1 pc.
• Installation and Operation Manual 1 pc.
Ardox S4 Drop-In Solid Top Cooking Unit:
• Hob assembly 3753284 1 pc.
• Frame 3753257 1 pc.
• Connection link 3753452 2 pc.
• Screws ISO 1481-ST4,8x16 C (or other suitable type) 24 pcs.
• Grease box 3753432 1 pc.
• Installation and Operation Manual 1 pc.
The appliance is intended for drop-in installation in the customer stainless steel table top. .
Installation in tabletops made from wood or other flammable surface is not allowed.
Max. recommended thickness of table top ( external stainless steel surface+ plywood underneath)
30mm. Dimensions of drop-in hole in table top must be as follows:
• Ardox S2 Drop-in Solid Top Cooking Unit 453mmx753mm
• Ardox S4 Drop-in Solid Top Cooking Unit 753mmx753mm
Please refer to the installation drawings and other drawings in chapter “Technical specification” and
follow the installation steps described below:
• Cut drop-in hole in table top according to model of appliance to be installed. .
• Drop the frame into drop-in hole and fix it to the tabletop by taping screws supplied with the appliance.
• Drop carefully the onto the frame hob. Frame must be completely covered by the stainless steel
frame of the hob. Orientation of the hob is correct when the drain hole is in front left corner.
The hob is heavy, handle it carefully. The S2 hob weighs about 40 kg and the S4 hob weighs about 70 kg.
5.4. Electrical installation
5.4.1. Ranges
Before making the connection to the mains, ensure that the voltage and frequency are as indicated on
the appliance rating plate.
Should maintenance require the appliance to be tested before all the protective coverings are in place,
please be particularly careful of the moving parts inside the casing as well as of live parts..
To facilitate future maintenance and to increase safety, install a separate disconnection switch for the
range in the immediate vicinity of the appliance. The switch should disconnect the appliance completely
from the mains supply.
All information needed to connect the range is to be found on the name plate, the connection diagram
and the installation drawing.
STOP
STOP

|13
Rev. 5.0 (from 01.08.2011)
Metos ARDOX S
Ardox S2 Solid Top Cooking Unit
The supply cable inlet is in the back right-hand corner of the range and the connection point inside the range.
The top deck needs to be opened to connect the range to the mains. Raise the deck up.
Be cautious when opening the deck because of its weight and always lock the deck into the open
position with the fixing rod.
In case of combination of a range and an oven, the connection point for the supply cable is located on
the rear wall of the oven (right low corner). In order to make the connection, the right side panel of the
oven must be removed.
Ardox S Tabletop
The Tabletop is equipped with a cable with with a plug. The length of the cable with plugs is 2000 mm.
Ardox S Drop-In
Appliance is delivered with completely made internal wiring. To switch appliance on just connect supply
cable to the connection terminals.
Mounting bracket with connection terminals is placed temporary inside electrical compartment of the hob.
Mounting bracket with connection terminals must be fixed outside electrical compartment in proper
place before supply cable is connected.
Spisens The controls of the appliance are fixed to the electrical compartment of the hob. For customer
installation controls are moved in other proper place.
The electrical installation is as follows:
• To perform the electrical connection of the appliance, the deck of the hob must be opened. Lift up the
lid carefylly as it is heavy. Lock the lid to the open position with the support bar.
• Drill mounting holes for thermostats and for pilot lights in new place. The size of mounting holes is
shown on the installation drawings. Make sure that length of wiring and capillary tube of the
thermostat is enough for installation in new place.
• Take off plastic knob from thermostat axle. Unscrew two screws and release thermostat head with
capillary tube and wiring.
• Pull out the signal lamps with wiring.
• Install thermostat heads and signal lamps in new place.
• Attach bottom back to electrical compartment.
• Return hob in working position.
Positioning of grease box
Recommended position of the grease box is shown on installation drawings.
However grease box can be installed in other place(remote from drain pipe of the hob).For this installation
use suitable type of hose. Connect one end of hose to the drain pipe of the hob and other end of hose
must be located and fixed so that grease comes right in grease container.
5.4.2. Height adjustable stand
There must be no obstructions in the lifting area at the installation site (radiator tubing, window sash,
electric boxes, etc.).
Adjust the table directly using the adjustable screws on the feet. Check that the table stands firmly on
all feet.
Connect the power cord to an approved outlet. Do not use a separate extension cord.

14 |
Rev. 5.0 (from 01.08.2011)
Metos ARDOX S
5.5. Test-run
Please read the safety and operation instructions as well as the functional description of the appliance
before testing the range.
Test the range once it has been connected to the mains electricity.
Check that every cooking zone heats up and the corresponding pilot light turns on when the zone is
switched on with the power regulator.
Close the top deck.

|15
Rev. 5.0 (from 01.08.2011)
Metos ARDOX S
6. Troubleshooting
If the appliance fails to work, check to ensure thata
• it has been used according to the instructions
• all removable parts are in place
• the main power switch (usually on a wall or in the immediate vicinity of the appliance) is in the ON
position
• the fuses (overload protection) have not blown in the fuse box. Ask a qualified person to check
overload protection.
Should the range still not work, contact an authorised agent. Before contact, make sure you have at
hand the appliance type and serial number to be found on the name plate on the right front corner of
the appliance.
This appliance does not contain parts which can be serviced by the user. Maintenance must be carried
out by an authorised agent.
STOP

16 |
Rev. 5.0 (from 01.08.2011)
Metos ARDOX S
7. Technical specifications
• Installation drawings
• Technical specifications

6
0
1
2
3
4
5
6
0
1
2
3
4
5
6
0
1
2
3
4
5
6
0
1
2
3
4
5

6
0
1
2
3
4
5
6
0
1
2
3
4
5
6
0
1
2
3
4
5
6
0
1
2
3
4
5
6
0
1
2
3
4
5
6
0
1
2
3
4
5

6
0
1
2
3
4
5
6
0
1
2
3
4
5
6
0
1
2
3
4
5
6
0
1
2
3
4
5

6
0
1
2
3
4
5
6
0
1
2
3
4
5
6
0
1
2
3
4
5
6
0
1
2
3
4
5
6
0
1
2
3
4
5
6
0
1
2
3
4
5
