Metra Electronics AXXESS AXDSPX-HD2 User manual

AXDSPX-HD2
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2023 METRA ELECTRONICS CORPORATION REV. 2/9/23 INSTAXDSPX-HD2
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink • Tape • Wire cutter
• Zip ties
TABLE OF CONTENTS
Connections ............................................................2
Installation ......................................................... 3-4
Harley Davidson DSP Package with Water
Resistant Enclosure 2014-Up
• Water resistant plug-n-play harness for the AXDSP-X
• AXDSP-X included
• Water resistant enclosure with zip tie mounts included
• Amplifier, if equipped, does not need to be retained
• All wiring will be done at the radio location
• Micro-B USB updatable
• AXDSP-X circuit board
• AXDSPX-HD2 harness (with gaskets)
• AXDSPX-HD2 enclosure
• Case
• Cap (with O-ring)
Google Play Store Apple App Store
iOS 12.1 or higher
ATTENTION: With the key out of the
ignition, disconnect the negative battery
terminal before installing this product. Ensure
that all installation connections, especially the
air bag indicator lights, are plugged in before
reconnecting the battery or cycling the ignition
to test this product.
NOTE: Refer also to the instructions included
with the aftermarket radio.

2
CONNECTIONS
SUB
An SPDT relay, Metra part number
E-123, must be used if the amp turn-on
current of all amps exceed 1-amp.
Loose Wires
Do Not Use
Additionable Outputs
For Optional Amps
CH 6 CH 10CH 7 CH 8 CH 9
AXDSPX-HD2
Harness
Factory Harness
Cap (with O-ring)
Case
White / Front Left +
White/Black / Front Left -
Gray / Front Right +
Gray/Black Front Right -
Green / Rear Left +
Green/Black / Rear Left -
Purple / Rear Right +
Purple/Black / Rear Right -
AXDSP-X
Circuit Board
AXDSPX-HD2
Harness
Blue/White - Amp Turn-On
Red/White - Do Not Use
16-Pin 20-Pin
Gasket
Zip-tie Mounts
Factory Radio
Locking clip shown
in unlocked position

3
REV. 2/9/23 INSTAXDSPX-HD2
Attention! Harley Davidson radios come pre-programmed with a preset EQ that cannot be
changed without flashing the radio. Only an authorized Harley Davidson Dealer can flash the
radio and flatten the factory EQ curve. Ask the Dealer to flash the radio to a flat EQ curve. Without
performing this task, the AX-DSP will be distorted and not sound very good.
1. Remove the fairing to access the back of the factory radio. Refer to MetraOnline,
part number 99-9700 for fairing disassembly instructions.
2. Install the AXDSPX-HD2 harness and make all necessary connections, but leave the amp
turn-on wire disconnected.
3. With the arrow stamped onto the cap facing upwards, push the 16-pin connector from
the AXDSPX-HD2 harness into the left side of the cap. The locking clip on the connector
should face upward. Make sure the gasket is seating properly in the cap. (Figure A)
4. With the arrow stamped onto the cap still facing upwards, push the 20-pin connector from
the AXDSPX-HD2 harness into the right side of the cap. The locking clip on the connector
should face upward. Make sure the gasket is seating properly in the cap. (Figure A)
5. Plug the 16-pin and 20-pin connectors from the AXDSPX-HD2 harness into the
AXDSP-X circuit board. (Figure A)
6. Slide the assembly into the case, then click it shut. Zip-tie the enclosure to a secure
location in the fairing to secure it. Make sure the Axxess logo is facing up to further
ensure that no outside elements can enter the enclosure.
I N S TAL L AT IO N
Cap (with O-ring)
Case
AXDSP-X
Circuit Board
AXDSPX-HD2
Harness
16-Pin 20-Pin
Gasket
Zip-tie Mounts
(Figure A)
Continued on the next page

4
7. Download and install the AXDSP-X app from the Google Play Store or Apple App Store.
8. Open the app and follow the instructions on the Bluetooth Connection tab to pair the
mobile device to the AXDSP-X. (Figure B)
9. Scroll to the Configuration tab then select the vehicle type. Press the Lock Down button
to save the configuration. (Figure C)
10. Connect the amp turn-on wire from the AXDSPX-HD2 harness.
11. Click the Identify button to confirm that the AXDSPX-HD2 is connected properly. If so, a
chime will be heard from the front left speaker. Test all functions of the installation for
proper operation.
12. Adjust the DSP settings in the app as desired. Refer to the instructions under the Setup
Instructions tab, or online at AxxessInterfaces for an explanation of each tab in the app.
I N STA LL ATIO N (CONT’D)
(Figure B)
(Figure C)

5
REV. 2/9/23 INSTAXDSPX-HD2

6

7
REV. 2/9/23 INSTAXDSPX-HD2

KNOWLEDGE IS POWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.edu or call
386-672-5771 for more information and take steps
toward a better tomorrow.
®
Metra recommends MECP
certified technicians
AxxessInterfaces.com © COPYRIGHT 2023 METRA ELECTRONICS CORPORATION REV. 2/9/23 INSTAXDSPX-HD2
