These Short Instructions contain important information about the Com-
bustion IC system. In addition to an introduction and safety instructions,
you can find a description of the Combustion IC system and information
on installing the 920 Absorber Module and its interfaces to the Combus-
tion-IC-System. You can download the detailed manual for the 920
Absorber Module as a PDF file from the Internet
(https://www.metrohm.com).

2.1 The Combustion IC system ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
2￭￭￭￭￭￭￭￭ Combustion-IC-System
2 Introduction
2.1 The Combustion IC system
2.1.1 Overview
Combustion is a sample preparation technique that uses burning to digest
a sample. Solid, liquid and gaseous samples that are flammable can be
digested using combustion. Combustion IC is particularly suited for deter-
mining the following elements:
Figure 1 Detectable elements
An additional instrument is required for the determination of gaseous
samples: the LPG/GSS Module (AJ) (2.136.0720) or the GLS Sampler CIC
(TEI) (2.0136.0630).

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ 2 Introduction
Combustion-IC-System ￭￭￭￭￭￭￭￭ 3
2.1.2 System description
Figure 2 Overview – CIC system
The sample is combusted in the Combustion Module (AJ) / Combustion
Oven (TEI).
The gases generated during combustion are dissolved into an absorber
solution in the 920 Absorber Module and are optimized for analysis using
suitable sample preparation techniques.
In the end, the absorption solution is preconcentrated in an ion chromato-
graph and analyzed.
The entire process is controlled and monitored using MagIC Net software.
The analysis data is saved in the software's database.
2.1.3 Sequence of a determination
A determination in the Combustion IC system runs according to the fol-
lowing diagram:

2.1 The Combustion IC system ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
4￭￭￭￭￭￭￭￭ Combustion-IC-System
Start determination
(CIC system)
Rinse absorber tube and
provide absorber solution
(920 Absorber Module)
Sample input
(Combustion Module)
Rinse c apillary f. combustion
gases w. absorber solution
(920 Absorber Module)
Absorption of
combustion gases
(920 Absorber Module)
optional: Water infeed
(920 Absorber Module)
Combustion
Fill loop with
absorption solution
(920 Absorber Module)
Matrix elimination
(930 Compact IC Flex)
Re-rinse absorber tube
(920 Absorber Module)
IC determination
(930 Compact IC Flex)
Combustion Module (AJ)/
Combustion Oven (TEI)
Combustion Module (AJ)/Combustion Oven (TEI)
Figure 3 Sequence of the determination
NOTICE
Do not mix these up!
￭Absorber solution: e.g. H2O2 solution for oxidizing sulfur oxides.
￭Absorption solution: Combustion gases dissolved in the absorber
solution.
The determination is controlled entirely by MagIC Net. You can find a
detailed description of the sequence in the online help for MagIC Net
under the title "Combustion sequence".

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ 2 Introduction
Combustion-IC-System ￭￭￭￭￭￭￭￭ 5
2.2 Intended use
The present system is suitable for processing chemicals and flammable
samples. Usage of the Combustion IC system therefore requires the user
to have basic knowledge and experience in handling toxic and caustic
substances. Knowledge regarding the application of fire prevention meas-
ures prescribed for laboratories is also mandatory.
2.3 Safety instructions
2.3.1 General notes on safety
WARNING
Operate this instrument only according to the information contained in
this documentation.
This instrument left the factory in a flawless state in terms of technical
safety. To maintain this state and ensure non-hazardous operation of the
instrument, the following instructions must be observed carefully.
2.3.2 Electrical safety
The electrical safety when working with the instrument is ensured as part
of the international standard IEC 61010.
WARNING
Only personnel qualified by Metrohm are authorized to carry out service
work on electronic components.
WARNING
Never open the housing of the instrument. The instrument could be
damaged by this. There is also a risk of serious injury if live components
are touched.
There are no parts inside the housing which can be serviced or replaced
by the user.

2.3 Safety instructions ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
6￭￭￭￭￭￭￭￭ Combustion-IC-System
Supply voltage
WARNING
An incorrect supply voltage can damage the instrument.
Only operate this instrument with a supply voltage specified for it (see
rear panel of the instrument).
Protection against electrostatic charges
WARNING
Electronic components are sensitive to electrostatic charges and can be
destroyed by discharges.
Do not fail to pull the power cord out of the power socket before you
set up or disconnect electrical plug connections at the rear of the
instrument.
2.3.3 Tubing and capillary connections
CAUTION
Leaks in tubing and capillary connections are a safety risk. Tighten all
connections well by hand. Avoid applying excessive force to tubing con-
nections. Damaged tubing ends lead to leakage. Appropriate tools can
be used to loosen connections.
Check the connections regularly for leakage. If the instrument is used
mainly in unattended operation, then weekly inspections are manda-
tory.

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ 2 Introduction
Combustion-IC-System ￭￭￭￭￭￭￭￭ 7
2.3.4 Flammable solvents and chemicals
WARNING
All relevant safety measures are to be observed when working with
flammable solvents and chemicals.
￭Set up the instrument in a well-ventilated location (e.g. fume cup-
board).
￭Keep all sources of flame far from the workplace.
￭Clean up spilled liquids and solids immediately.
￭Follow the safety instructions of the chemical manufacturer.
2.3.5 Recycling and disposal
This product is covered by European Directive 2012/19/EU, WEEE – Waste
Electrical and Electronic Equipment.
The correct disposal of your old instrument will help to prevent negative
effects on the environment and public health.
More details about the disposal of your old instrument can be obtained
from your local authorities, from waste disposal companies or from your
local dealer.

3.1 Overview ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
8￭￭￭￭￭￭￭￭ Combustion-IC-System
3 Installation
3.1 Overview
Components of the Combustion-IC-System
Depending on the application, the Combustion-IC-System consists of the
following instruments:
Type of sample Instruments Manufacturer
solid/liquid samples only ￭Combustion Module with Auto Boat Drive (ABD)
(2.136.0700)
￭optional: sampler (MMS 5000)
Analytik Jena
￭920 Absorber Module (2.920.0010)
￭930 Compact IC Flex Oven SeS/PP/Deg (2.930.2560)
Metrohm
gaseous samples only ￭Combustion Module with LPG/GSS Module (2.136.0730) Analytik Jena
￭920 Absorber Module (2.920.0010)
￭930 Compact IC Flex Oven SeS/PP/Deg (2.930.2560)
Metrohm
solid, liquid and gaseous
samples
￭Combustion Module with Auto Boat Drive (ABD)
(2.136.0700)
￭LPG/GSS Module (2.136.0720)
Analytik Jena
￭920 Absorber Module (2.920.0010)
￭930 Compact IC Flex Oven SeS/PP/Deg (2.930.2560)
Metrohm
The following chapters provide brief instructions for installing the 920
Absorber Module and connecting it to the remaining system components.
Refer to the respective manuals for more detailed information. You can
find the operating instructions for the instruments from Analytik Jena on
the accompanying CD. The manuals for Metrohm instruments are
included with delivery and you can download them from the Internet
(www.metrohm.com).
Installation of the 920 Absorber Module
The 920 Absorber Module is provided with a wide array of accessories.
These accessory parts have to be installed before the instrument can be
put into operation.

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ 3 Installation
Combustion-IC-System ￭￭￭￭￭￭￭￭ 9
Capillaries and tub-
ings
Figure 4 Capillaries and tubings in use – Overview
1PTFE capillary, 0.75 mm ID / 3 m
(6.1803.160)
Connection between the 6-port valve and
the waste container.
2PEEK capillary, 0.5 mm ID / 15 cm
(6.1831.040)
Connection between the 6-port valve and
the 10-port valve.
3PTFE capillary, 0.75 mm ID / 3 m
(6.1803.160)
Approx. 80 cm. Connection between the
10-port valve and the bottle with the stan-
dard solution.
4PTFE capillary, 0.75 mm ID / 3 m
(6.1803.160)
Approx. 80 cm. Connection between the
10-port valve and the bottle with the check
standard.
5PTFE capillary, 0.75 mm ID / 3 m
(6.1803.160)
Approx. 60 cm. Connection between the
10-port valve and the absorber tube.
6PTFE capillary, 0.75 mm ID / 3 m
(6.1803.160)
Approx. 5 cm. For aspirating air segments.
7PTFE capillary, 0.75 mm ID / 3 m
(6.1803.160)
Connection between the 10-port valve and
the waste container.
8Combustion Module (AJ): PTFE capil-
lary 1/8 OD / 1/16 ID / 1.5 m | Combus-
tion Oven (TEI): PTFE capillary 1/8 OD /
1/16 ID / 5 m
Connection between the absorber tube and
the Combustion Module (AJ) / Combustion
Oven (TEI).

3.1 Overview ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
10 ￭￭￭￭￭￭￭￭ Combustion-IC-System
9Combustion Module (AJ): PTFE capil-
lary 0.5 mm ID / 3 m (6.1803.030) |
Combustion Oven (TEI): PTFE capillary
0.8 mm ID / 2.5 m (capillary absorber
solution)
Connection between the Metrosep A Trap 1
- 100/4.0 trap column (6.1014.000) and the
Combustion Module (AJ) / Combustion Oven
(TEI).
10 PTFE capillary, 0.5 mm ID / 3 m
(6.1803.030)
Approx. 20 cm. Connection between the
Dosino with the absorber solution and the
Metrosep A Trap 1 - 100/4.0 trap column
(6.1014.000).
11 FEP tubing M6 for 920 150 cm
(6.1805.030) with FEP aspiration tub-
ing (6.1819.100)
Aspiration tubing for the absorber solution.
Connection between the Dosino with the
absorber solution and the bottle with the
absorber solution.
12 FEP tubing M6 for 920, 13 cm
(6.1805.010)
Connection between the Dosino with the
absorber solution and the T connector.
13 FEP tubing M6 for 920, 13 cm
(6.1805.010)
Connection between the Dosino with ultra-
pure water and the T connector.
14 Combustion Module (AJ): PTFE capil-
lary 0.5 mm ID / 3 m (6.1803.030) |
Combustion Oven (TEI): PTFE capillary
0.8 mm ID / 2.5 m (6.07311.310)
Connection between the Dosino with ultra-
pure water and the Combustion Module
(AJ) / Combustion Oven (TEI).
15 FEP tubing M6 for 920 150 cm
(6.1805.030) with FEP aspiration tub-
ing (6.1819.100)
Aspiration tubing for ultrapure water. Con-
nection between the Dosino with the water
bottle.
16 PTFE capillary, 0.5 mm ID / 3 m
(6.1803.030)
Approx. 30 cm. Connection between the
Dosino with ultrapure water and the Metro-
sep I Trap 1 - 100/4.0 trap column
(6.1014.200).
17 PTFE capillary, 0.5 mm ID / 3 m
(6.1803.030)
Approx. 40 cm. Connection between the
Metrosep I Trap 1 - 100/4.0 trap column
(6.1014.200) and the 6-port valve.
18 PTFE capillary, 0.5 mm ID / 3 m
(6.1803.030)
Connection between the 6-port valve and
the 930 Compact IC Flex.
Colored sleeves Different liquids move throughout the 920 Absorber Module. In order to
provide you an overview of the different flow paths, we recommend using
the provided colored sleeves as follows to code the capillaries that route
the distinct liquids:
Table 1 Recommended color codes for the flow paths
Liquid Colored sleeve
Ultrapure water blue

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ 3 Installation
Combustion-IC-System ￭￭￭￭￭￭￭￭ 11
Liquid Colored sleeve
Absorber solution yellow
Standard solution black
Check standard red
Waste white
NOTICE
The colored sleeves are heat-shrink tubing; this means they shrink when
they are exposed to heat.
Slip the colored sleeve over the capillary and secure it to the desired
spot by heating it, for example by using a hairdryer.
3.2 Dosino for ultrapure water
3.2.1 Connecting the ports – Overview
Figure 5 Connect the Dosino for ultrapure water

3.3 Dosino for the absorber solution ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
12 ￭￭￭￭￭￭￭￭ Combustion-IC-System
Next steps Connect
capillary/
tubing at
port …
… to
1 Metrosep I Trap 1 - 100/4.0 (6.1014.200) trap column inlet
2 Water bottle
3 T connector (6.1808.060)
4 Combustion oven inlet (see chapter 3.6.1, page 16)
You can find detailed instructions in the manual for the 920 Absorber
Module.
3.3 Dosino for the absorber solution
3.3.1 Connecting the ports – Overview
Figure 6 Connect the Dosino for the absorber solution

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ 3 Installation
Combustion-IC-System ￭￭￭￭￭￭￭￭ 13
Next steps Connect
capillary/
tubing at
port …
… to
1 T connector (6.1808.060)
2 Bottle with the absorber solution
3 Connect the Metrosep A Trap 1 – 100/4.0 inlet
You can find detailed instructions in the manual for the 920 Absorber
Module.
3.4 10-port-valve
3.4.1 Connecting the ports
The transfer tubing and capillaries for all of the liquids being used are con-
nected to the 10-port valve.
Connecting the 10-port valve
Connect the ports of the 10-port valve according to the following figure:
NOTICE
We recommend connecting the central port first.
Figure 7 Connecting the 10-port valve

3.5 6-port valve ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
14 ￭￭￭￭￭￭￭￭ Combustion-IC-System
Next step Connect
capillary/
tubing at
port …
… to
1 6-port valve (see chapter 3.5, page 14)
2 Bottle with standard solution
3 Bottle with check standard
8 Absorber tube
10 Waste container
You can find detailed instructions in the manual for the 920 Absorber
Module.
3.5 6-port valve
3.5.1 Connecting the ports
Connecting the 6-port valve
Connect the ports of the 6-port valve according to the following figure:
6.1803.030
6.1803.160
6.1803.030
6.2744.010
6.2744.010
6.2744.010
6.2744.010
6.1831.040
6.1825.290
1
2
3
4 5
6
Figure 8 Connecting the 6-port valve
Next steps Connect
capillary/
tubing at
port …
… to
2 Waste container
