Metrohm 762 IC Interface User manual

762 IC Interface
762 IC Interface MetrohmMetrohm
SYSTEM 1
SYSTEM 2 RUN
STOP
RUN/
STOP
RUN/
STOP
8.762.1003
Instructions for Use
METROHM Ltd.
CH-9101 Herisau
Switzerland
Phone ++41 71 353 85 85
Fax ++41 71 353 89 01

CH-9101 Herisau/Switzerland
Tel. ++41 71 353 85 85
Fax ++41 71 353 89 01
Internet www.metrohm.ch
E-Mail [email protected]
762 IC Interface
762 IC Interface MetrohmMetrohm
SYSTEM 1
SYSTEM 2 RUN
STOP
RUN/
STOP
RUN/
STOP
8.762.1003 Instructions for Use
16.02.2000 / dö

Table of contents
762 IC Interface I
Table of contents
1 Introduction............................................................................................1
1.1 Instrument description.............................................................................1
1.2 Parts and controls.....................................................................................2
1.2.1 2.762.0010 IC Interface .................................................................2
1.2.2 2.762.0020 IC Interface .................................................................4
1.3 Information on the Instructions for Use................................................6
1.3.1 Organization ..................................................................................6
1.3.2 Notation and pictograms............................................................... 7
1.4 Safety notes ...............................................................................................8
2 Installation ..............................................................................................9
2.1 Setting up the instrument........................................................................9
2.1.1 Packaging......................................................................................9
2.1.2 Check ............................................................................................9
2.1.3 Location......................................................................................... 9
2.1.4 Arrangement of the instruments.................................................... 9
2.2 Mains connection....................................................................................10
2.2.1 Mains voltage and fuses .............................................................10
2.2.2 Mains cable .................................................................................10
2.2.3 Switching the instrument on/off...................................................10
2.3 Connection to the PC .............................................................................11
2.3.1 Connecting cable ........................................................................11
2.3.2 Software installation..................................................................... 11
2.4 Connection of external instruments....................................................12
2.4.1 General information.....................................................................12
2.4.2 732 IC Detector, 733 IC Separation Center, 709 IC Pump .........13
2.4.3 752 Pump Unit.............................................................................14
2.4.4 753 Suppressor Module..............................................................15
2.4.5 754 Dialysis Unit..........................................................................16
2.4.6 750 Autosampler .........................................................................17
2.4.7 766 IC Sample Processor ...........................................................18
2.4.8 791 VA Detector...........................................................................19
2.4.9 761 Compact IC ..........................................................................20
3 Operation................................................................................................21
3.1 Manual operation.....................................................................................21
3.2 Operation via «IC Net»............................................................................22
3.2.1 Settings in the "762 IC Interface" window.................................... 22
3.2.2 Event output lines........................................................................ 25
4 Appendix..................................................................................................29
4.1 Technical data..........................................................................................29
4.2 Scope of delivery.....................................................................................32
4.3 Optional accessories..............................................................................33
4.4 Warranty and conformity.......................................................................34
4.4.1 Warranty ......................................................................................34
4.4.2 EU Declaration of conformity ......................................................35
4.4.3 Certificate of conformity and system validation ..........................36
4.5 Index..........................................................................................................37

Table of contents
762 IC InterfaceII
List of figures
Fig. 1:Connection possibilities at 762 IC Interface................................................... 1
Fig. 2:Front of 2.762.0010 IC Interface ..................................................................... 2
Fig. 3:Rear of 2.762.0010 IC Interface...................................................................... 3
Fig. 4:Front of 2.762.0020 IC Interface ..................................................................... 4
Fig. 5:Rear of 2.762.0020 IC Interface...................................................................... 5
Fig. 6:Connection of 762 IC Interface to PC .................................................... 11
Fig. 7:Connection of 732, 733 and 709............................................................. 13
Fig. 8:Connection of 732, 733, 709 and 752.................................................... 14
Fig. 9:Connection of 2×732, 733, 2×709 and 753........................................... 15
Fig. 10:Connection of 732, 733, 709, 753 and 754........................................... 16
Fig. 11:Connection of 732, 733, 709 and 750.................................................... 17
Fig. 12:Connection of 732, 733, 709 and 766.................................................... 18
Fig. 13:Connection of 732, 733, 709 and 791.................................................... 19
Fig. 14:Connection of 732, 733, 709 and 761.................................................... 20

1.1 Instrument description
762 IC Interface 1
1 Introduction
1.1 Instrument description
The 762 IC Interface provides the connection between the PC and
external IC or HPLC peripheral instruments. Up to 16 instruments in-
cluding 4 detectors can be connected to the 762 IC Interface and con-
trolled either uniformly or independently by means of the «IC Net»PC
software. The IC 762 Interface can also record and convert the analog
signals from a maximum of 4 channels (two at once) which are proc-
essed at very high resolution.
Fig. 1 shows an overview of all the Metrohm instruments which can be
connected to the 762 IC Interface and are described in these
‘Instructions for Use’. It is also possible to connect Bischoff instru-
ments; please refer to the «IC Net»on-line program help as well as the
relevant Bischoff instruction manuals.
766 IC Sample Processor
732 IC Detector
733 IC Separation Center
709 IC Pump
752 Pump Unit
762 IC Interface
750 Autosampler 754 Dialysis Unit
753 Suppressor Module
761 Compact IC
Fig. 1: Connection possibilities at 762 IC Interface

1 Introduction
762 IC Interface2
1.2 Parts and controls
1.2.1 2.762.0010 IC Interface
3344
762 IC Interface MetrohmMetrohm
SYSTEM 1 RUN/
STOP
1122
Fig. 2: Front of 2.762.0010 IC Interface
11 Mains switch
For switching the instrument
on/off
33 Run/Stop key for System 1
RUN: Manual start of a determi-
nation (external start)
STOP: Manual stop of a determi-
nation or data acquisition
(if defined in «IC Net»)
22 Mains pilot lamp
Lights up when instrument is
switched on
44 Status display for System 1
LED dark: No system loaded
LED lit up: Instrument ready
(waiting for external
start)
LED flashes: Determination run-
ning

1.2 Parts and controls
762 IC Interface 3
101012121313
1414
99
Run
Com
Start
System 1
Events
Made by Metrohm Herisau Switzerland
f = 50-60 Hz
100 - 240 V
Type 1.762.0020 Nr.
P = 7 W
Dev. 1/5 Dev. 2/6 Dev. 3/7 Dev. 4/8
Channels1/2
PC
1234567
S
77 88 1111
Fig. 3: Rear of 2.762.0010 IC Interface
77 Earthing socket 1111 Analog signal connection
88 Mains connection plug
Mains connection see section 2.2 1212 Remote input/output lines connection (RUN)
99 Serial number 1313 Remote input/output lines
connection (COM)
1010 PC connection
RS232 interface
1414 RS232 interfaces

1 Introduction
762 IC Interface4
1.2.2 2.762.0020 IC Interface
3344
762 IC Interface MetrohmMetrohm
5566
SYSTEM 1
SYSTEM 2 RUN
STOP
RUN/
STOP
RUN/
STOP
1122
Fig. 4: Front of 2.762.0020 IC Interface
11 Mains switch
For switching the instrument
on/off
44 Status display for System 1
LED dark: No system loaded
LED lit up: Instrument ready
(waiting for external
start)
LED flashes: Determination run-
ning
22 Mains pilot lamp
Lights up when instrument is
switched on
55 Run/Stop key for System 2
RUN: Manual start of a determi-
nation (external start)
STOP: Manual stop of a determi-
nation or data acquisition
(if defined in «IC Net»)
33 Run/Stop key for System 1
RUN: Manual start of a determi-
nation (external start)
STOP: Manual stop of a determi-
nation or data acquisition
(if defined in «IC Net»)
66 Status display for System 2
LED dark: No system loaded
LED lit up: Instrument ready
(waiting for external
start)
LED flashes: Determination run-
ning

1.2 Parts and controls
762 IC Interface 5
101012121313
1414
99
Com
RunRun
Com
StartStart 1234567
Events
System 2
Channels 3/4
Dev. 4/8Dev. 3/7Dev. 2/6Dev. 1/5
System 1
Events
Made by Metrohm Herisau Switzerland
f = 50-60 Hz
100 - 240 V
Type 1.762.0020 Nr.
P = 7 W
Dev. 1/5 Dev. 2/6 Dev. 3/7 Dev. 4/8
Channels 1/2
PC
1234567
S
77 88 1111 1818
1616 1717
1515
Fig. 5: Rear of 2.762.0020 IC Interface
77 Earthing socket 1313 Remote input/output lines
connection (COM)
88 Mains connection plug
Mains connection see section 2.2 1414 RS232 interfaces
99 Serial number 1515 Analog signal connection
1010 PC connection
RS232 interface
1616 Remote input/output lines
connection (RUN)
1111 Analog signal connection 1717 Remote input/output lines
connection (COM)
1212 Remote input/output lines
connection (RUN) 1818 RS232 interfaces

1 Introduction
762 IC Interface6
1.3 Information on the Instructions for Use
Please read through these Instructions for Use carefully before you put
the 762 IC Interface into operation. The Instructions for Use contain
information and warnings to which the user must pay attention in order
to assure safe operation of the instrument.
1.3.1 Organization
These 8.762.1003 Instructions for Use for the 762 IC Interface pro-
vide a comprehensive overview of the installation, startup procedure,
operation and technical specifications of this instrument. The Instruc-
tions for Use are organized as follows:
Section 1 Introduction
General description of instrument, parts and controls
and safety notes
Section 2 Installation
Mains connection, connection to PC,
connection of external instruments
Section 3 Operation
Manual operation and operation via «IC Net»
Section 4 Operation
Technical data, standard equipment, options, warranty,
declarations of conformity, index
To find the required information on the instruments you will find it an
advantage to use either the Table of contents or the Index at the
back.

1.3 Information on the Instructions for Use
762 IC Interface 7
1.3.2 Notation and pictograms
The following notations and pictograms (symbols) are used in these In-
structions for Use:
Range Menu item, parameter or entry
value
in «IC Net» program
SYSTEM STATE Program window
in «IC Net» program
<OK> Button
in «IC Net» program
[ RUN/STOP ] Switch or key
1515 Part or control of 762
Hazard
This symbol draws attention to a
possible danger to life or of injury if
the associated directions are not
followed correctly.
Warning
This symbol draws attention to
possible damage to instruments or
instrument parts if the associated
directions are not followed cor-
rectly.
Caution
This symbol marks important infor-
mation. First read the associated
directions before you continue.
Comment
This symbol marks additional in-
formation and tips.

1 Introduction
762 IC Interface8
1.4 Safety notes
While electrical safety in the handling of the 762 IC Interface is assured
in the context of the specifications IEC 1010-1 (protection class 1, de-
gree of protection IP40), the following points should be noted:
• Mains connection
The mains connection must be effected in accordance with the
instructions in section 2.2.
• Opening the instrument
Inside the instrument there are no parts which must be set or adjusted
by the user.
If the 762 IC Interface is connected to the power supply, the instru-
ment must not be opened nor must parts be removed from it, other-
wise there is a danger of coming into contact with components which
are live. Hence, always disconnect the instrument from all voltage
sources before you open it and ensure that the mains cable is
disconnected from mains connection 88 !
• Protection against static charges
Electronic components are sensitive to static charging and can be
destroyed by discharges. Before you touch any of the components
inside the 762 IC Interface, you should earth yourself and any tools
you are using by touching an earthed object (e.g. housing of the
instrument or a radiator) to eliminate any static charges which exist.

2.1 Setting up the instrument
762 IC Interface 9
2 Installation
2.1 Setting up the instrument
2.1.1 Packaging
The 762 IC Interface is supplied together with the separately packed
accessories in special packagings containing shock-absorbing foam
linings designed to provide excellent protection. The instrument itself is
packed in an evacuated polyethylene bag to prevent the ingress of
dust. Please store all these special packagings as only they assure
transport of the instrument free from damage.
2.1.2 Check
After receipt, immediately check whether the shipment is complete and
has arrived without damage (compare with delivery note and list of
accessories in section 4.2). In the case of transport damage, see
instructions in section 4.4.1 "Warranty".
2.1.3 Location
Position the instrument in the laboratory at a location convenient for op-
eration, free from vibrations and protected against a corrosive atmos-
phere and contamination by chemicals.
2.1.4 Arrangement of the instruments
The 762 IC Interface can be piled up together with other IC instruments
(e.g. 732, 733, 709).

2 Installation
762 IC Interface10
2.2 Mains connection
2.2.1 Mains voltage and fuses
The 762 Interface has a power supply which automatically adjusts itself
to the existing mains voltage (100…240 V) and frequency (50…60 Hz).
It is equipped with an electronic overload protection device and also
has two fuses; however, these should only be exchanged by Metrohm
service technicians.
2.2.2 Mains cable
The instrument is supplied with one of three mains cables
• 6.2122.020 with plug SEV 12 (Switzerland, …)
• 6.2122.040 with plug CEE(7), VII (Germany, …)
• 6.2133.070 with plug NEMA 5-15 (USA, …)
which are three-cored and fitted with a plug with an earthing pin. If a
different plug has to be fitted, the yellow/green lead (IEC standard)
must be connected to the earthing socket 77 (protection class 1).
Any break in the earthing inside or outside the instrument can make it
a hazard!
Plug the mains cable into mains connection plug 88 at the 762 IC Inter-
face (see Fig. 3 and Fig. 5).
2.2.3 Switching the instrument on/off
The 762 IC Interface is switched on and off using mains switch 11 (see
Fig. 2 and Fig. 4). When the instrument is switched on the mains pilot
lamp 22 lights up.

2.3 Connection to the PC
762 IC Interface 11
2.3 Connection to the PC
2.3.1 Connecting cable
Always switch off 762 IC Interface and PC before you connect the two
instruments with the 6.2134.100 Cable.
Connect the PC connection 1010 at the 762 IC Interface to one of the se-
rial COM ports at the PC using the 6.2134.100 Cable (9 pin/9 pin). If
only a 25-pin COM interface is available on the PC then the 6.2125.110
Adapter cable or a commercially available adapter must be used.
762
6.2134.100
Fig. 6: Connection of 762 IC Interface to PC
2.3.2 Software installation
The PC program «IC Net 2.0» is required for the operation of the 762
IC Interface; this is contained on the 6.6034.003 CD included in the ac-
cessories. This program runs under Windows 95, Windows 98 and
Windows NT operating systems and is installed according to section
1.4.2 of the «IC Net»Instructions for Use.

2 Installation
762 IC Interface12
2.4 Connection of external instruments
2.4.1 General information
Before an external instrument is connected to the 762 IC Interface, the
762 IC Interface must always be switched off using mains switch 11 !
Each system of the two versions of the 762 IC Interface has four RS232
interfaces 1414 or 1818 for connection of a maximum of 8 external instru-
ments, an 1111 or 1515 interface for analog signals from a maximum of 2
detectors and 8 remote output lines 1212/1313 or 1616/1717 for controlling ex-
ternal instruments by making contacts or impulses (see Fig. 2 and
Fig. 4). Information about the technical data of these interfaces is given
in section 4.1.
For installation and startup of external instruments proceed as follows:
1Switch off all instruments
• Switch off 762 IC Interface and all external instruments using
the mains switch.
2Connect instruments
• Connect the instruments to the 762 IC Interface according to
the connection diagrams shown in sections 2.4.2 to 2.4.9 by
using the cables named in the diagrams. Other instrument
combinations can be set up by using these examples as a
guide.
3Switch on all instruments
• Switch on 762 IC Interface and all external instruments using
the mains switch.
4Instrument settings
Operation with the 762 IC Interface requires that the following
settings must be made:
• 732 IC Detector:
>CONFIG/RS settings
handshake: SWchar
>CONFIG/RS settings
RS control: on
• 709 IC Pump:
Switch on external control of the 709 IC Pump using the
[EXT. ] key.
• 752 Pump Unit, 753 Suppressor Module,
754 Dialysis Unit:
Switch on external control via remote interface using the
[Remote ] switch.

2.4 Connection of external instruments
762 IC Interface 13
• 750 Autosampler:
Always switch on the 762 IC Interface first and then the 750
Autosampler.
• 766 IC Sample Processor:
>RS232 settings
handshake: SWchar
>RS232 settings
RS control: on
5Create new system in «IC Net»
• Start the «IC Net»program.
• Create a new system file with the selected instruments
(details see IC Net Instructions for Use).
2.4.2 732 IC Detector, 733 IC Separation Center, 709 IC Pump
Example
Analysis of anions or cations on a modular system with electronic sup-
pression.
Instruments
• 2.762.0010 IC Interface for 1 system
• 2.732.0010 IC Detector with standard detector block
• 2.733.0010 IC Separation Center with 1 injector
• 2.709.0010 IC Pump
Interconnection
732
733
709762
PC
6.2134.100
6.2128.130
6.2115.070
6.2134.090
6.2125.090
(732)
Fig. 7: Connection of 732, 733 and 709

2 Installation
762 IC Interface14
2.4.3 752 Pump Unit
Example
Analysis of anions or cations on a modular system with chemical sup-
pression.
Instruments
• 2.762.0010 IC Interface for 1 system
• 2.732.0110 IC Detector with metal-free detector block
• 2.733.0130 IC Separation Center with 1 injector
and suppressor module, metal-free
• 2.709.0110 IC Pump, metal-free
• 2.752.0010 Pump Unit
Interconnection
732
733
709762
PC
6.2134.100
6.2128.130
6.2115.070
6.2134.090
6.2125.090
(732)
752
6.2128.180
Fig. 8: Connection of 732, 733, 709 and 752

2.4 Connection of external instruments
762 IC Interface 15
2.4.4 753 Suppressor Module
Example
Simultaneous analysis of cations and anions on a modular system with
two independent detectors.
Instruments
• 2.762.0020 IC Interface for 2 systems
• 2.732.0110 IC Detector with metal-free detector block for
System 1 (cations)
• 2.732.0110 IC Detector 732 with metal-free detector block for
System 2 (anions)
• 2.733.0120 IC Separation Center with 2 injectors, metal-free
• 2.709.0110 IC Pump, metal-free, for System 1 (cations)
• 2.709.0110 IC Pump, metal-free, for System 2 (anions)
• 2.753.0010 Suppressor Module, for System 2 (anions)
Interconnection
732-1
733
709-1762
PC 6.2134.100
6.2115.070
6.2134.090
6.2125.090
(732)
6.2128.180
753
709-2
732-2
6.2125.090
(732)
6.2115.070
6.2134.090
6.2128.180
6.2128.130
6.2128.130
Fig. 9: Connection of 2××732, 733, 2××709 and 753

2 Installation
762 IC Interface16
2.4.5 754 Dialysis Unit
Example
Analysis of anions on a modular system with chemical suppression af-
ter preceding sample dialysis.
Instruments
• 2.762.0010 IC Interface for 1 system
• 2.732.0110 IC Detector 732 with metal-free detector block
• 2.733.0120 IC Separation Center with 2 injectors, metal-free
• 2.709.0110 IC Pump, metal-free
• 2.753.0010 Suppressor Module
• 2.754.0010 Dialysis Unit
Interconnection
732
733
709762
PC
6.2134.100
6.2128.130
6.2115.070
6.2134.090
6.2125.090
(732)
6.2128.180
754
753
6.2128.180
6.2128.180
Fig. 10: Connection of 732, 733, 709, 752 and 754
