1 Overview
1.1 Instrument description
Metrohm Instant Raman Analyzers (MIRA) are handheld, high-power
Raman spectrometers designed for rapid, nondestructive identification of
unknown chemical samples, both liquid and solid. Barely larger than a
smartphone, MIRA spectrometers are the only handheld Raman spectrom-
eters currently on the market with Orbital Raster Scan (ORS) technology.
1.2 Model versions
MIRA XTR DS instruments are available in the following versions:
Table 1 Model versions
2.926.0110 MIRA XTR DS Basic
MIRA XTR DS Basic is a starter pack-
age that contains the basic compo-
nents required for operating MIRA
XTR DS.
Check Metrohm Website for included
parts.
Laser class 3B
2.926.0120 MIRA XTR DS Advanced
MIRA XTR DS Advanced includes a
wide range of attachments suitable
for standard applications in the field
of first responders, military and secur-
ity officials.
Check Metrohm Website for included
parts.
Laser class 3B
NOTICE
To purchase additional Accessories (see chapter 1.7, page 5).

MIRA software ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
2￭￭￭￭￭￭￭￭
1.3 MIRA software
MIRA Cal DS software
In order to configure a MIRA DS or MIRA XTR DS instrument, the follow-
ing software is needed:
Table 2 Model versions
6.06071.020 MIRA Cal DS USB Stick
To download the latest version of MIRA Cal DS software and firmware,
click on the following link:
https://www.metrohm.com/en/support-and-service/software-center/mira-
cal/
MIRA Cal M mobile app
MIRA Cal M allows the user to analyze, manage, or share samples
acquired on MIRA DS or MIRA XTR DS instruments. MIRA Cal M mobile
app can be installed on an Android™ device optionally (see "Installing
MIRA Cal M for Android", page 18).
1.4 Third party software
HazMasterG3® software
HazMasterG3 is a CBRNE/IED and HME investigative tool for use in tradi-
tional incident response situations. It delivers insights and guidance for
167,000+ chemical agents (toxic industrial chemicals (TICs), toxic industrial
materials (TIMs), chemical warfare agents (CWAs), precursors, trade
names, etc.).
HazMasterG3 is compatible with MIRA DS and MIRA XTR DS sample data
and can be installed on an Android or Windows® device optionally.
Table 3 Model versions
6.6071.640 HazMasterG3 Software
The HazMasterG3 software is optional. To purchase the HazMasterG3
software, click on the following link:
https://www.metrohm.com/en-us/products-overview/66071640

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ Overview
