Operating manual
Electric wheelchair
Model 1.620

2
Contents
Meaning of the applied markers 7
Introduction 7
List of models 7
Indications / contraindications 8
Function exit assist 8
Acceptance 9
Intended purpose 9
Use 9
Adjustment 10
Combination with manufacturer foreign products 10
Reinstallment 10
Life span 10
Base position 11
Overview 12
Model 1.620 12
Handling the electric wheelchair 13
Securing the electric wheelchair 13
Functional checks 13
Driving 13
Brakes 13
Service brake 13
Braking the electric wheelchair 13
Emergency braking 13
Parking brake 13
Locking the brakes 14
Releasing the brakes 14
Drive-/push mode 15
Selecting the push mode 15
Selecting the motor mode 15

3
Selecting the operation 16
Pre-operation checks 18
Battery charging procedure 18
Positioning the operating module 19
Function description 19
Adjusting the distance to the padded arm support 19
Removing the operating module 19
Inserting the operating module 19
Swivelling the operating module 20
Arm supports 21
Lowerable arm support 21
Swivelling up the arm supports 22
Swivelling down the arm supports 22
Back support 23
Back support upholstery 23
Head support 24
Adjustment of the head support 24
Removing and height adjusting the head support 24
Adjusting the head support during handicapped transport inside a motor vehicle 24
Leg support 25
Footboard 25
Knee cushions 26
Removing/attaching the knee cushions 26
Side cushions 27
Adjusting the side cushions 27
Removing the side cushions 27
Inserting the side cushions 27

4
Seat 28
Special safety information 28
Seat pad 28
Seat inclination 28
Electrically adjusting the seat angle 28
Seat height adjustment 29
Standing function 30
Lying function 31
Exit assist 32
Chest strap 33
Fastening the chest strap 33
Opening the chest strap 33
Shoulder strap 34
Fastening the shoulder strap 34
Adjustment of belt length 34
USB connector socket 35
Rear-view mirror 36
Removing the rear-view mirror 36
Attaching the rear-view mirror 36
Adjusting the rear-view mirror 36
Lighting 37
Loading and transportation 38
Loading 38
Ramps and lifting platforms 38
Transport of people inside a motor vehicle 38
Transport security 39
Tyres 40

5
Maintenance 40
Maintenance 40
Maintenance schedule 41
Fuses 43
Replacing the fuses 43
Lighting 44
Headlights 44
Fault correction 45
Basic safety information 46
Accompanying person 46
Transfer out of the electric wheelchair 46
Reaching for objects 47
Driving on falling, rising or transverse gradients 47
Crossing obstacles 47
Electrical system 48
Transport in public methods of transportation 48
Driving on public highways 48
Cleaning 49
Finish 50
Disinfection 50
Repairs 50
Repairs 50
Customer Service 50
Spare parts 50
Information for extended pauses of use 51
Disposal 51

6
Technical data 52
Tyre pressure of pneumatic tyres 52
Maximum range 52
Hill climbing ability 52
Hill climbing ability 53
Applied norms 53
Values acc. to ISO 7176-15 for model 1.620 iCHAIR SKY 54
Meaning of the labels on the electric wheelchair 57
Meaning of the symbols on the type plate 58
Meaning of the symbols on the washing instruction 59
Inspection certificate 60
Warranty / Guarantee 61
Warrantee / Guarantee section 62
Inspection certificate for transfer 62
Notes 63

7
MEANING OF THE AP-
PLIED MARKERS
Safety instructions with a coloured back-
ground are mandatory and need to be
observed under any circumstance!
☞This symbol indicates tips and recom-
mendations.
[ ] Reference to a picture number.
( ) Reference to a function element within
a picture.
INTRODUCTION
Read and observe this manual before first
operation.
Children and juveniles should read this
documentation together with their par-
ents respectively a supervisor or accom-
panying person before first use.
This operating manual is to help you get
accustomed to the handling of the electric
wheelchair as well as to prevent accidents.
☞For this observe the following docu-
ments:
– the operating manual < Operating
module >,
– the safety and general handling in-
structions < Electric vehicles >.
☞Please note that the illustrated equip-
ment variants can deviate from your
model.
We have therefore also listed chapters with
options that might not be applicable for
your individual electric wheelchair. A list of
the available options and accessories can
be viewed in the order form of your electric
wheelchair.
Users with visual impairments can find the
PDF-files together with further information
on our website:
< www.meyra.com >.
☞Contact your specialist dealer when re-
quired.
Alternatively users with visual impairments
can have the documentation read out by a
helper.
Inform yourself regularly about product
safety and possible recalls of our products
in the < Information center > on our website:
< www.meyra.com >.
We have developed an electric wheelchair
that complies with the technical and gov-
ernmental regulations of medical devices.
For information about a severe accident
that can still not be ruled out completely,
please use our E-mail address < info@mey-
ra.de > and inform the responsible govern-
mental agency of your country.
LIST OF MODELS
This operating manual applies to the follow-
ing models:
Model 1.620

8
INDICATIONS /
CONTRAINDICATIONS
In case of allergic reactions, skin rashes
and/or pressure sores during the use of
the wheelchair sores contact a doctor im-
mediately.
In order to prevent contact allergies, we
recommend to use the electric wheel-
chair only when wearing clothes.
The functional diversity of your wheelchair
permits application in situations with ex-
treme to fully pronounced limitations in
mobility/walking in case of structural and/
or functional damages to the lower extremi-
ties (u.o. amputation, after-effects of injuries,
musculoskeletal/neuromusculoskeletally
caused motion disorders e.g. through:
– paralysis,
– loss of limbs (leg amputation),
– defective/deformed limbs,
– joint contractures/-damages,
– other diseases.
Also to be observed for individual provision
are the physical and psychological state,
age of the handicapped person as well as
the personal living condition and private
environment.
Every provision, case by case should be
checked, tested and aligned to the indi-
vidual ability limitations caused by the de-
fined disability through an educated person
(medical device consultant, rehabilitation
consultant u.o.). This also includes that
people that show a counter indications to
the named problems in some cases need
to give proof of the cognitive, mental and
moral ability to operate one of the models
shown in the list of models.
The electric wheelchair may not be used in
cases of:
– Cognitive limitations and mental re-
tarding, that rule out the independent
use of the electric wheelchair.
– Blind people and people with limited
eyesight that cannot be compensated
with other aids and lead to constraints
in daily life.
– Influence of impairing medications (ask
your doctor or pharmacist).
– Circumstances that prevent the individ-
ual use of the control device.
– Extreme limitations in balance and/or
disorders in perception.
– In case of the inability to sit.
☞To these and other possible risk
concerning your electric wheelchair
ask your doctor, therapist or special-
ist dealer.
Function exit assist
In case of unexpected symptoms that
might be associated with the use of the
exit assist, contact a doctor immediately.
The indications/counterindications listed
in this chapter do not replace the indica-
tions/counterindications for the use of the
electric wheelchair.
In case of the following indications the ap-
plication of the exist assist function is rec-
ommended:
– For people that have a remaining ability
to walk.
The exit assist function may not be used in
cases of:
– Non-existent remaining ability to walk
of the wheelchair user.
The exit assist function may only be used
with an accompanying person in cases of:

9
– People that are physically not able to
exit the wheelchair independently.
– Cognitive limitations and mental re-
tarding, that rule out the independent
use of the of the exit assist function.
ACCEPTANCE
All products are checked for faults in the
factory and packed in special boxes.
☞However, we request that you check
the electric wheelchair for possible
transport damage immediately on re-
ceipt – preferably in the presence of the
carrier.
☞The packaging of the electric wheel-
chair should be stored for a further
transport that might become neces-
sary.
INTENDED PURPOSE
The electric wheelchair serves to improve
independent mobility indoors and out-
doors.
USE
Never use the electric wheelchair without
the leg supports and arm support units
mounted!
The electric wheelchair serves solely for
transporting one sitting person. – Other
pulling or transporting uses do not com-
ply with its intended purpose.
The electric wheelchair is applicable on lev-
el, firm surfaces and can be used as follows:
– for indoors (e.g. apartment, day care),
– outdoors (e.g. paved paths in parks).
– Never expose the electric wheelchair to
extreme temperatures and damaging
environmental conditions, such as sun-
light, extreme cold or salty water.
– Sand and other dirt particles can seize
on moving parts and render them with-
out function.
The electric wheelchair offers manifold ad-
justment possibilities to individual vital sta-
tistics.
National regulations might prevent the use
on busses, trains or in aircraft.
☞Inform yourself at the transportation
companies concerning limitations.
☞Before going on a flight clarify the spe-
cific transport conditions with your
flight agency and also the legal regula-
tions concerning transport in a plane in
your country of residence as well as at
your destination.
Only apply the electric wheelchair within
the scope of the specifications and limita-
tion described in chapter Technical data on
page 52.

10
ADJUSTMENT
Always have adaptation, adjustment or re-
pair work carried out by a specialist dealer.
The electric wheelchair offers manifold ad-
justment possibilities to individual vital sta-
tistics. Before first use an adaptation of the
electric wheelchair and a practical instruc-
tion in the functionalities of your electric
wheelchair should be carried out by your
specialist dealer. The adaptation will take
into account the driving experience, the
physical limits of the user and the main
place of use of the electric wheelchair. Be-
fore first use, check the functionality of your
electric wheelchair.
Should your specialist dealer carry out a
revision/reconditioning or make funda-
mental changes to your electric wheelchair,
without the use of original spare parts, this
under certain conditions may result in a re-
marketing of your electric wheelchair. This
will further entail that your specialist dealer
might need to conduct new conformity as-
sessments and tests.
☞We recommend a regular inspection of
the electronic wheelchair adjustment
in order to ensure a long-term optimal
provision even with changing illness/
handicap patterns of the user. Especial-
ly for juveniles an adjustment every 6
months is recommendable.
☞We recommend regular medical checks
for independent determination of the
driving ability.
COMBINATION WITH MAN-
UFACTURER FOREIGN
PRODUCTS
Any combination of your electric wheelchair
with components not supplied by us gener-
ally results in an amendment to your electric
wheelchair. Please inquire with us if there is
a valid combination clearance/release.
REINSTALLMENT
The electric wheelchair is suited for reinstall-
ment. With the building block system the
electric wheelchair can be fit to accommo-
date different handicaps body sizes. Before
reimplementation the electric wheelchair is
to undergo a complete inspection.
☞Hygienical measures required for rein-
stallment are to be carried out accord-
ing to a validated hygienic plan and
must include disinfection.
The service manual, intended for the spe-
cialist dealer provides information to the re-
installment and reinstallment frequency of
your electric wheelchair.
LIFE SPAN
We expect an average life span of about
5 years for this product, as far as the product
is applied for its designated purpose and all
maintenance and service guidelines. The life
span of your product depends upon the fre-
quency of use, the application environment
and care. The implementation of spare parts
can prolong the life span of the product. As
a rule spare parts are available up to 5 years
after production is discontinued.
☞The indicated lifespan does not consti-
tute additional guarantee.

11
BASE POSITION
Only drive on slopes, inclines and obsta-
cles in the basic position of the seat rising
function, back inclination and seat angle.
– Danger of overturning!
Basic position is to be understood as:
– Seat height adjustment in the lowest
position.
– Back inclination in upright position.
– Seat inclination in horizontal position
(but max 10°).

1 2 3
4
11
16
15 14
6
5
10 7 8
13
9
12
12
OVERVIEW
Model 1.620
The overview shows the most important
components and operating devices of the
electric wheelchair.
Pos. Description
(1) Head support
(2) Back support
(3) Arm support
(4) Seat pad
(5) Knee pad
(6) Footboard
(7) Steering wheel
(8) Type plate
(9) Selection lever drive-/push mode
(10) Driving wheel
(11) Operating module
(12) Side cushion
(13) Front lighting
(14) Rear lighting
(15) Support castor
(16) Electronic cover

13
HANDLING THE ELECTRIC
WHEELCHAIR
Securing the electric wheelchair
The electric wheelchair is to be secured as
follows to prevent it from rolling off unin-
tentionally:
1. Switch the selection lever for drive-/
push mode up to drive mode on both
sides.
2. Switch off the operating module.
Functional checks
The functions and safety of the electric
wheelchair must be checked before the
start of each journey.
☞For this observe chapter < Inspections
before starting to drive > in the accom-
panying documentation.
Driving
You define the speed and direction yourself
with the joystick movements (driving and
steering lever) while driving as well as the
preadjusted maximum final speed of your
electric wheelchair.
☞Therefore observe operation manual
< Operating module >.
BRAKES
Brake the vehicle down carefully and in
time. This is especially the case when driv-
ing in front of people and while driving
downhill!
Service brake
The motors work electrically as operating
brake and carefully brake the electric wheel-
chair down without jerks to stillstand.
Braking the electric wheelchair
For allotted braking of the electric wheel-
chair slowly guide the joystick (steering and
driving lever) back to the centre position
(zero-setting).
Emergency braking
☞The electric wheelchair stops in short-
est distance after releasing the joysticks.
Parking brake
The parking brakes are only effective when
the selection lever drive-/push mode is set
to drive mode on both drives.
☞The parking brake disengages auto-
matically when you start to drive.
The parking brakes are manually disen-
gaged by switching the selection lever
drive-/push mode on both drives to push
mode.

1
2
14
Locking the brakes
It should not be possible to push the elec-
tric wheelchair forward when the brakes
are engaged.
To engage the brakes swivel the selection
lever drive-/push mode on both sides as far
as possible into drive mode [1].
☞Activation of the selection lever is in-
tended for an accompanying person.
Releasing the brakes
Only transfer into or out of the electric
wheelchair when the electric wheelchair
is switched off and the selection lever
drive-/push mode on both sides is in drive
mode!
An unintentional movement of the joy-
sticks (driving and steering lever) can
otherwise lead to an uncontrolled start of
the electric wheelchair! – Danger of acci-
dents!
To loosen the brakes swivel the selection le-
ver drive-/push mode on both sides down
as far as possible into push mode [2].
☞Activation of the selection lever is in-
tended for an accompanying person.

2
1
15
Drive-/push mode
Only switch the electric wheelchair to
push mode when it is standing still for
positioning or in case of emergencies, but
not on slopes/hills.
After push mode do not forget to switch
the drive back to drive mode. Danger of
uncontrolled electric wheelchair move-
ment if you do not do this.
☞To manoeuvre the electric wheelchair
grab hold behind the back support at
the height of the arm supports.
Selecting the push mode
1. Switch off the operating module be-
cause the pushing will otherwise be
made difficult by the electric system.
☞Therefore observe operation manu-
al < Operating module >.
2. Disengage the brakes [1].
☞Therefore observe chapter Releasing
the brakes on page 14.
☞The electric wheelchair can now be
pushed.
Selecting the motor mode
1. Activate the brakes [2].
☞Therefore observe chapter Releasing
the brakes on page 14.
2. Switch the operating module on.
☞Therefore observe operation manu-
al < Operating module >.
The electric wheelchair is now ready for use
again.

2
1
16
SELECTING THE
OPERATION
In order to obtain operational readiness of
the electric wheelchair the following direc-
tions are to be carried out in the indicated
order.
☞Charge the drive batteries via the oper-
ating module before the first journey.
1. Selecting the motor mode.
Switch the drive motors to the drive mode
[1]. – For this engage the brakes.
☞Observe chapter Locking the brakes
on page 14.
2. Check the correct fit of the battery/
mains fuse.
☞The blade fuse for the battery/main
current has to sit tightly in the fuse
holder (2).

4
3
17
3. Check the position of the operating
module.
The maximum extension reached, when
a mark becomes visible in the receptacle
tube of the operating module.
☞The operating module should be
positioned in such a way that you
can comfortably and safely steer
the electric wheelchair.
☞The distance of the operating mod-
ule to the padded arm supports
can be adjusted after loosening the
clamping screw (3).
4. After the adjustment retighten the
clamping screw.
☞Therefore observe chapter Posi-
tioning the operating module on
page 19.
5. Switch the operating module on.
☞Press the On/Off-key (4) on the con-
trol panel of the operating module.
☞Therefore observe operation manu-
al < Operating module >.

2
1
18
Pre-operation checks
Before starting to drive, the following should
be checked:
☞the battery charging condition,
☞the setting of the preselected final
speed.
– For this observe the operating manual
< Operating module >.
Battery charging procedure
Do not insert any objects other than the
battery charger plug into the battery
charging socket. – Danger of short circuit!
Only charge the batteries in well aired, dry
rooms.
Protect the charger from heat, dampness,
drop and spray water and jamming since
it contains voltage. – Short circuit- and
mortal danger!
Ensure a good ventilation of the charger
during the charging (do not cover) in or-
der to dissipate the heat generated by the
charger. – Danger of fire!
Place the battery on a firm surface for
charging.
Do not put the charger on the seat of the
electric vehicle for charging.
Do not smoke and avoid open flame or
sparking when handling cables and elec-
tric devices. The charging gases that can
be produced by the charging are always
explosive.
Avoid spark build up through electrical
static (for example caused by synthetic
floor covers).
☞For the battery charging procedure also
observe the operating manual of the
battery charger.
1. Lock the electric wheelchair.
☞Therefore observe chapter Securing
the electric wheelchair on page 13.
2. Insert the charger plug into the battery
charging socket (1) of the operating
module.
3. Switch the battery charger on, resp.
insert the main plug of the battery
charger into the corresponding power
socket.
☞The charging procedure is initiated.
☞The charging procedure only runs
with an intact mains/battery fuse
(2)!
4. After a completed charging procedure
disconnect the battery charger from
the socket and remove the battery
charging plug from the battery charg-
ing socket.

1
2
19
Positioning the operating module
Switch off the operating module before
adjusting/removing it.
Function description
You will find a detailed description of the
keys and symbols in the operating manual
for < Operating module >.
The position of the operating module can
be adjusted to suit the individual size of the
user. The operating module can also be
removed for transportation or storage and
can be laid on the seat or stored separately.
Adjusting the distance to the padded
arm support
Switch off the operating module before
adjusting/removing it.
The maximum extension reached, when
a mark becomes visible in the receptacle
tube of the operating module.
Slacken the clamping screw distance ad-
justment (1). Afterwards slide the operating
module into the desired position. In doing
so carefully guide the cable and retighten
the clamping screw (1) securely.
Removing the operating module
In order to remove the operating module
loosen the clamping screw (1) and discon-
nect the plugged connection (2).
☞Do not pull on the cable while do-
ing so.
Afterwards pull out the operating module
toward the front out of the arm support
tube.
Inserting the operating module
Watch for possible jamming areas when
plugging in the operating module.
For drive mode insert the operating mod-
ule from the front into the arm support tube
and adjust the distance to the padded arm
support.
☞Therefore observe chapter Adjusting
the distance to the padded arm sup-
port on page 19.
Afterwards re-establish the plugged con-
nection (2).
☞Check the function of the operating
module.

1
2
20
Swivelling the operating module
Do not grab into the area of the cross
brace. – Danger of squashing!
With the swivel away operating module
adapter [1] the operating module can be
swivelled back to the side (2) so that it is
located parallel to the arm support. This
makes it possible, for example:
– to drive closer to a table,
– remove the operating module more
easily.
For regular drive mode the operating mod-
ule can be swivelled back toward the front
until it engages back into the magnetic lock
[1].
☞Should the operating module be po-
sitioned too close to the arm support,
move it forward before swivelling.
