MGG DTC-2000-1 User manual

DTC-2000-1 Remote Dog Training
Collar
Operation Guide

- 1 -
DTC-2000-1 Dog Training Collar Operation Guide
Thank you for choosing DTC-2000-1 Remote dog training collar. Our
mission is to offer the best electronic training solutions. We want to
ensure your dog’s safety by providing you with the tools and
techniques to successfully train your pet. Please feel free to contact
us if you have any problems and we will resolve them immediately.
Please read the complete operation guide carefully before starting
to train your dog including the FAQ.
IMPORTANT SAFETY INFORMATION
Not for Aggressive Dogs.
Do not use this product if your dog is aggressive, or if your dog is
prone to aggressive behavior. Aggressive dogs can cause severe
injury or even death to their owners and others. If you are unsure if
this product is appropriate for your dog, please consult your
veterinarian or certified trainer.

- 2 -

- 3 -
CAUTION
Please read and follow the instructions in the manual. Proper fit
of the collar under the dog’s neck is important. A collar worn for
too long or made too tight on your dog’s neck may cause skin
damage or irritation. This can range from redness to pressure
ulcers; commonly known as bed sores. Training collars can cause
pressure necrosis if used incorrectly and is often misidentified as
burns.
The temperature of environment must be higher than 0 ℃
when charging. The ideal charging temperature is between
10-45 ℃ .
1．Avoid leaving the collar on the dog for more than 8 hours out of
every 24 hours and try to re-position the collar on your dog’s neck every
1 to 2 hours if possible.
2．Check the fit of the collar to prevent excessive pressure; follow
the instructions in the manual.
3．Never connect a lead to the electronic collar; it could cause
excessive pressure on the contacts.
4．When using a separate collar for a lead, don’t put pressure on
the electronic collar.

- 4 -
5．Wash the dog’s neck area and the contacts of the collar weekly
with a washcloth and mild soap, then rinse thoroughly.
6．Examine the contact area daily for signs of a rash or a sore.
Brushing the coat daily may help.
7．If a rash or sore is found, discontinue use of the collar until the
skin has healed.
8．If the condition persists beyond 48 hours, see your veterinarian.
These steps will help keep your pet safe and comfortable.
Millions of pets are comfortable while they wear stainless steel
contacts. Some pets are sensitive to contact pressure and it is
important to continue daily checks of the contact area. If redness or
sores are found, discontinue use until the skin has fully healed.
Training sessions which are shorter and more positive (10-15
minutes) are often the most effective.
Do not use the collar on a dog that is under 10lbs or 6 months of
old.
Improper or inappropriate use of a training collar system can be
harmful. Please use this product correctly and pay attention when
training your dog.

- 5 -

- 6 -
TABLE OF CONTENTS
CONMPONENTS……………………………………………………5
HOW TO THE SYSTEM WORKS………………………………………6
MAIN FEATURES……………………………………………………7
TRANSMITTER………………………………………………………8
RECEIVER… …… …… …… …… …… …… …… …… …… … 12
KEY POINTS TO NOTE………………………………………………14
SETTING UP MULTI DOG SYSTEM………………………………15
MATCH A RECEIVER…………………………………………………15
OPERTATE HIGH LIGHT LED………………………………………17
CANCEL A MATCHED RECEIVER……………………………………18
FIT THE RECEIVER…………………………………………………20
CHARGING…….………………………………………………21
TRAINING GUIDE……………………………………………………22
HOW DOGS LEARN.……………………………………………25
FREQUENTLY ASKED QUESTIONS………………………………29
TROUBLESHOOTING GUIDE………………………………………33

- 7 -
CONMPONENTS

- 8 -

- 9 -
HOW TO THE SYSTEM WORKS
The DTC-2000-1 dog trainer has been proven safe, comfortable, and
effective for all pets over 10 pounds and 6 months old. This system
assists you in controlling your pet without a leash in a long distance
range. At the push of a button, the remote transmitter sends a signal,
activating the receiver collar. Using the remote trainer consistently
and correctly, many misbehaves that your pet exhibits can be
corrected or any basic obedience commands can be taught.
Important: The remote trainer actual distance is dependent on
the way you hold the remote transmitter, the range may vary. Hold
the remote transmitter in a horizontal position away from your
body to achieve optimum range. Terrain, weather, vegetation,
vehicles, buildings, transmission from other radio devices, and
other factors will affect the range of your remote trainer.

- 10 -
MAIN FEATURES
⚫- Range in open field up to 2000 meters.
⚫-Highlight LED function can find pet from 200~300 meters away at night.
⚫- Train up to 2 dogs from the same transmitter.
⚫- 99 levels each of static shock.
⚫- momentary and continuous shock
⚫- “Beep” sound activated with a separate button.
⚫- Vibration activated with a separate button.
⚫- Rotation switch allow you to set your intensity
⚫- Dog selection button allow you to select your dog.
⚫- LED display for shock levels& training mode & dog ID&Battery level
⚫- Memorize shock level in transmitter for different dogs.
⚫- Easy to operate with rubber button.
⚫- Waterproof transmitter and receiver. Dogs can swim freely.
⚫- Rechargeable 3.7V Li-ion battery for transmitter and receiver.
⚫-Strong TPU Collar Strap.
⚫- LED low power indication, red light will flash when battery level is low.
⚫- Full functional multi-dog training system.
⚫- Around 8 seconds safe static shock protection.
⚫- Comes with warranty.

- 11 -

- 12 -
TRANSMITTER BUTTON FUNCTIONS
Shock Adjust & Lock Switch
Vibration Button
Continuous Shock Button
LED display
On/Off Button
DC Jack
Highlight Led Button
Beep Button
LED Light
Dog Selection Button
Momentary Shock Button
Antenna

- 13 -

- 14 -
➢On/Off button
Hold this button for 2 seconds to switch on power, then LED will display
the default “01”.
You may change Dog ID by move the Dog Selection Button.
Hold this button for 2 seconds to switch off power.
➢Dog selection button
Move up to choose first dog , The LED screen display “1” ;
Move down to choose second dog, the LED screen display “2”.
➢Shock Adjust&Lock Switch
Rotate the switch to adjust the shock intensity from levels 0 to 99
Press the switch to lock the shock level , press the switch again to
unlock the shock level.
➢Vibration button
Vibration stimulation. Press 1 time- vibrate 1 time.
Press and hold on- emit continuous vibration.
Will stop vibrating when you let go of the button.
Will stop automatically when you go past 8 seconds of holding the
button.
➢Beep button
No-stimulation warning beep

- 15 -
➢Led light
Indicates the working status and low battery
➢Highlight Led buttons
Press one time , the receive collar led flash 1 time ;
Press and hold on button for 3 seconds , the receive collar will highlight
flash 5 times then flash 1 time per 3 seconds continuously.
➢Momentary shock button
Momentary static shock.
➢Continuous shock button:
Continuous static shock for about 8 seconds.
➢LED display
Display the shock ,beep or vibration mode ; display shock level , lock or
unlock shock status ,dog ID ,battery status
The transmitter has the memory functions to save the suitable shock
Warning Beep
Shock
Vibration
Lock or Unlock
Shock Level
Shock Level
Dog 1
Battery Level
Dog 2

- 16 -
for different dogs. 99 levels of shock stimulation, 1 level of vibration
stimulation. One tone.
➢DC Jack:
Charging the transmitter .
NOTE: The red LED light will flash when the battery is low on
power. Recharge the battery at once.

- 17 -
RECEIVER BUTTON FUNCTIONS
NOTE: CHARGE RECEIVER BEFORE FIRST USE. IF IT DOESN ’ T
CHARGE CONTACT US IMMEDIATELY
On/Off Button
Turn On The Collar = Press and hold on 4 seconds.
2 “beep” sounds and the collar green LED light will flash 1 time per 5
seconds if connected. The LED will flash fast if disconnected.
Turn Off The Collar = Press and hold on 4 seconds.
1 long tone will sound and the green LED light will stop flashing and
turn off.
Turn the collar off when not in use to conserve battery
Contact Prong
Choose short or long prong to
match the dog’s coat type.
LED Light
Indicate the working status,
low battery ,charging status.
DC Jack Cover
Open the Rubber Cover
and insert the adaptor plug
into DC Jack to charge.
High Light Led
1st Dog Light = White
2nd Dog Light = Red

- 18 -
You can expand your one dog trainer to a multi-dog remote trainer
by yourself. Simply purchase extra receiver collars and add them to
your system.
NOTE: IF THE COLLAR DOESN’T TURN ON PLEASE CONTACT US
FOR A NEW BATTERY OR CHARGER.
Spanner
Change the Contact Prong depending on
the pet’s coat type.
Note: If the contact prong is tight, don’t
continue to turn the spanner clockwise or the
contact prong will be broken. Never turn the
contact prong too tightly. Turn anticlockwise to
loosen or remove.

- 19 -
KEY POINTS TO NOTE
1．Always charge before use. Ideal time to charge is 2-3
hours for the receiver as this is better for the life of the
battery.
2．The on/off buttons need to be held down for several
seconds to turn the units on and off
3．Only use the receiver for 8 in every 24 hours and
adjust the collar every 1-2 hours if possible to make sure it is
correctly placed and not causing irritation.
4．If the receiver won’t connect to a specific number on
the remote, try a different number as this does sometimes
happen.
5．Rapid flickering of the green LED means the receiver
is disconnected.
6．The receiver is still waterproof without the rubber
stopper in place. This does not affect performance.
7．You may use any collar with the receiver as long as it
