Mi-Light FUT092 Installation instructions

Master ON
Color Ring
Speed+
Speed-
Saturation
Control
Master OFF
Indicator
Color
temperatureLine
Brightness
Dimming
Mode
Zone ON
(Link/Unlink)
Zone OFF
Made in China
User Instruction
4-Zone RGB+CCT Remote Controller ( FUT092 )
2.4G
Parameters
Instruction
Model No.: FUT092
Voltage: 3V(2*AAA battery)
Power Consumption: 6dBm
Standby Power Consumption: 20uA
Transmission Frequency: 2.4GHz
Modulation Method: GFSK
Control Distance: 30m
Size: 138mm*56mm*20mm
Features
This product adopt world-wide used 2.4GHz frequency, GFSK control method,
with the features of low power consumption, long distance transmitting, strong
anti-interference and fast comunication rate; can control specified Mi-Light
smart light with color, color temperature, saturation and brightness changing.
Caution
1. Remote controller only control specified
Mi-Light
products; not all Mi-Light series
can work on this remote
controller.
2.
In the using of the remote, if the indicated
lamp
blinking quickly, pls change the
battery in time.
Pls don’t use poor quality battery to
avoid the leaking
of battery liquid to
damage the remote controller.
3.
Pls don’t use the remote controller on
the
wide-range metal or strong
electromagnetic wave area, otherwise,
it
will badly affect the controlling
distance.
1. Long press “Master OFF” or “Zone OFF” to night light mode.
2. Touch “Color temperature line” to white light mode and adjust color temperature.
3. Touch “Color Ring” to change the colors.
4. Press “Speed+” to accelerate the dynamic mode speed continously until to fastest
speed.
5. Press “Speed-” to lower the dynamic mode speed continously until to lowest speed.

When the light on, short press
any zone of " " 3 times
within 3 seconds
Linking Instructions
If the light not blink slowly, the linking failed, Pls switch off the light
again, and follow the above steps again.
Switch off the light,
after 10 seconds
switch on again
1 2 3
Power
The light blink 3 times
slowly means the linking
is done successfully.
Power
Link/Unlink
button
The light can be working after
linking with the remote controller.
When the light on, short press
" " 5 times within 3 seconds
Unlinking must be the same
zone with the Linking
Unlinking Instructions
If the light not blink quickly, the unlink failed, pls switch off the light
again, and follow the above steps to unlink again.
Switch off the light,
after 10 seconds
switch on again
1 2 3
Power
The light blinking 10
times quickly, means the
unlinking successfully.
Power
Link/Unlink
button
