MICRO-EPSILON thermoMETER CSmicro User manual

Infrared Sensor
Operators Manual
thermoMETER CSmicro SF15/ SF02/ 2W/ 2WM-2/ HS

CE-Conformity
The product complies with the following standards:
EMC: EN 61326-1: 2006
EN 61326-2-3: 2006
Safety regulations: EN 61010-1: 2001
The product accomplishes the requirements of the EMC Directive 2004/108/EC.
Read the manual carefully before the initial start-up. The producer reserves the right to change the herein
described specifications in case of technical advance of the product. References to other chapters are
marked as: ►
Warranty
All components of the device have been checked and tested for perfect function in the factory. In the
unlikely event that errors should occur despite our thorough quality control, this should be reported
immediately to MICRO-EPSILON. The warranty period lasts 12 months following the day of shipment.
Defective parts, except wear parts, will be repaired or replaced free of charge within this period if you return
the device free of cost to MICRO-EPSILON.
This warranty does not apply to damage resulting from abuse of the equipment and devices, from forceful
handling or installation of the devices or from repair or modifications performed by third parties. No other
claims, except as warranted, are accepted. The terms of the purchasing contract apply in full. MICRO-
EPSILON will specifically not be responsible for eventual consequential damages.
MICRO-EPSILON always strives to supply the customers with the finest and most advanced equipment.
Development and refinement is therefore performed continuously and the right to design changes without
prior notice is accordingly reserved.
For translations in other languages, the data and statements in the German language operation manual are
to be taken as authoritative.

Contents
1Description................................................................................................................................................ 4
1.1 Scope of Supply................................................................................................................................................................... 4
1.2 Maintenance......................................................................................................................................................................... 4
1.3 Cautions ............................................................................................................................................................................... 5
1.4 Model Overview.................................................................................................................................................................... 5
1.5 Factory Default Settings....................................................................................................................................................... 6
2Technical Data .......................................................................................................................................... 7
2.1 General Specifications ......................................................................................................................................................... 7
2.2 Electrical Specifications ....................................................................................................................................................... 8
2.3 Connection Diagrams .......................................................................................................................................................... 9
2.4 Measurement Specifications [SF Models]........................................................................................................................... 10
2.5 Measurement Specifications [M-2 Model]........................................................................................................................... 11
2.6 Optical Charts....................................................................................................................................................................... 12
2.7 CF Lens and Protective Window.......................................................................................................................................... 16
3Installation............................................................................................................................................... 18
3.1 Mechanical Installation......................................................................................................................................................... 18
3.1.1 Mounting Accessories [SF15/ SF02/ 2W/ 2WM-2].............................................................................................................. 19
3.1.2 Mounting Accessories [HS] ................................................................................................................................................. 20
3.1.3 Air Purge Collars [SF15/ SF02/ 2W/ 2WM-2]....................................................................................................................... 21
3.1.4 Air Purge Collar [HS]............................................................................................................................................................ 22
3.1.5 Further Accessories ............................................................................................................................................................. 23
3.2 Electrical Installation ............................................................................................................................................................ 24
3.2.1 Analog Mode ........................................................................................................................................................................ 24
3.2.2 Maximum Loop Impedance [2W/ 2WM-2/ HS].................................................................................................................... 25
3.2.3 Digital Mode ......................................................................................................................................................................... 26
3.2.4 Alarm Output ........................................................................................................................................................................ 28
thermoMETER CSmicro 2

4Software .................................................................................................................................................. 29
4.1 Installation ............................................................................................................................................................................ 29
4.2 Minimum System Requirements.......................................................................................................................................... 29
4.3 Main Features....................................................................................................................................................................... 30
4.4 Communication Settings...................................................................................................................................................... 30
5Digital Command Set [SF15/ SF02]....................................................................................................... 31
6Digital Command Set [2W/ 2WM-2/ HS]................................................................................................ 32
7Basics of Infrared Thermometry............................................................................................................ 33
8Emissivity ................................................................................................................................................ 34
8.1 Definition............................................................................................................................................................................... 34
8.2 Determination of Unknown Emissivities .............................................................................................................................. 34
8.3 Characteristic Emissivities.................................................................................................................................................... 35
Appendix A – Emissivity Table Metals............................................................................................................ 36
Appendix B – Emissivity Non Table Metals.................................................................................................... 38
Appendix C – Smart Averaging ....................................................................................................................... 39
thermoMETER CSmicro 3

Description
1Description
The sensors of the CSmicro series are noncontact infrared temperature sensors.
They calculate the surface temperature based on the emitted infrared energy of objects [►Basics of
Infrared Thermometry].
The sensor housing of the CSmicro is made of stainless steel (IP 65/ NEMA-4 rating) – the sensor
electronics is integrated inside the connection cable.
1.1 Scope of Supply
CSmicro inclusive connection cable
Mounting nut
Operators manual
1.2 Maintenance
Lens cleaning: Blow off loose particles using clean
compressed air. The lens surface can be cleaned with a
soft, humid tissue moistened with water or a water based
glass cleaner.
PLEASE NOTE: Never use cleaning
compounds which contain solvents
(neither for the lens nor for the housing).
thermoMETER CSmicro 4

Description
1.3 Cautions
Avoid abrupt changes of the ambient temperature.
In case of problems or questions which may arise when you use the sensor, please contact our service
department.
The sensors CSmicro are sensitive optical systems. Please use only the thread for mechanical
installation.
Avoid mechanical violence on the sensor – this may destroy the system (expiry of warranty).
1.4 Model Overview
The sensors of the CSmicro series are available in the following versions:
Model Measurement range spectral Output
response
CSmicro SF15/ SF02 -20 to 350 °C 8 -14 μm Voltage output 0 - 5 V/ 0-10 V
CSmicro 2W -30 to 900 °C 8 -14 μm Two-wire sensor (4 - 20 mA)
CSmicro 2WM-2 385 to 1600 °C 1.6 μm Two-wire sensor (4 - 20 mA)
CSmicro HS -20 to 150 °C 8 -14 μm Two-wire sensor (4 - 20 mA)/ Detection
ofsmallesttemperaturedifferences
(0.025K)
thermoMETER CSmicro 5

Description
1.5 Factory Default Settings
The units have the following presetting at time of delivery:
SF15 SF02 2W 2WM-2 HS e
Temperature range: 0 ... 350 °C 0 ... 350 °C 0 ... 500 °C 385 ... 1600 °C -20 ... 150 °C
Output: 0 ... 3,5 V 0 ... 3.5 V 4 ... 20 mA 4 ... 20 mA 4 ... 20 mA
Emissivity: 0.950 0.950 0.950 1.000 0.950
Transmission: 1.000 1.000 1.000 1.000 1.000
Average time: 0.09 s 0.09 s 0.09 s 0.09 s 0.2 s
Smart Averaging: active active active active active
Smart Averaging means a dynamic average adaptation at high signal edges [activation/ deactivation
via software onl
y]
.►A
pp
endix C
Read the manual carefully before the initial start-up. The producer reserves the right to change the herein
described specifications in case of technical advance of the product.
thermoMETER CSmicro 6

Technical Data
2
thermoMETER CSmicro 7
Technical Data
2.1 General Specifications
Environmental rating IP 65 (NEMA-4)
Ambient temperature Sensor: -20 ... 125 °C [2WM-2]
-20 ... 120 °C [SF15/ SF02/ 2W]
-20 ... 75 °C [HS]
Electronics (inside cable): -20 ... 75 °C
Storage temperature -40 ... 85 °C
Relative humidity 10 ... 95 %, non condensing
Material Stainless steel
Dimensions 28 mm x 14 mm (sensor) [SF15/ SF02/ 2W/ 2WM-2]
55 mm x 29.5 mm (sensor inclusive massive housing) [HS]
70 mm x 12 mm (electronic) [SF15/ SF02]
45 mm x 12 mm (electronic) [2W/ 2WM-2/ HS]
Weight 42 g [SF15/ SF02/ 2W/ 2WM-2]
200 g [HS]
Cable length 1 m (50 cm between sensor and electronics) [SF15/ SF02/ 2W/ 2WM-2]
4 m (50 cm between sensor and electronics) [HS]
Cable diameter 2.8 mm (sensor – electronics)
4.3 mm (electronics – end of cable)
Vibration IEC 68-2-6: 3 G, 11 – 200 Hz, any axis
Shock IEC 68-2-27: 50 G, 11 ms, any axis
Software (optional) Compact Connect

Technical Data
2.2
thermoMETER CSmicro 8
Electrical Specifications
SF15/ SF02 2W/ 2WM-2/ HS e
Output aonly alternatively selectable e
Analog 0 - 5 V1) or 0 -10 V2)/ scalable 4 - 20 mA/ scalable
Serial digital 3) uni- (burst mode) or bidirectional uni- (burst mode) or bidirectional
Alarm output voltage adjustable; N/O or N/C -
Additional features Programmable open collector output Programmable open collector output
0 - 30 VDC/ 50 mA4) 0 - 30 VDC/ 500 mA
Output impedances min. 10 kΩload impedance max. 1000 Ωloop impedance
Input programmable functional input:
-externalemissivityadjustment
[0V►ε=0.1 │5 V ►ε=1.1]
- ambient temperature compensation
[0V►-20 °C │5 V ►350 °C]
- trigger (reset of hold functions)
[5Vatgn]
Current draw 9 mA 4 - 20 mA
Power supply 5 ... 30 VDC 5 ... 30 VDC
1) 0 ... 4.6 V at supply voltage 5 VDC; also valid for alarm output
2) Only at supply voltage ≥11 V
3) Inverted RS232, TTL, 9.6 kBaud
4) 500 mA if the mV output is not used

Technical Data
2.3 Connection Diagrams
white Power supply
yellow Analog output/ TxD (5 V)/ Alarm output
CSmicro SF green Analog input/ RxD (5 V)/ Open collector output
brown Ground (⊥)
black Shield
white Current loop (+)
yellow TxD (5 V)
CSmicro 2W green RxD (5 V)/ Open collector output
brown Current loop (-)/ Ground (⊥)
black Shield
You will find a detailed description of the different sensor connections in chapter ►Electrical Installation.
thermoMETER CSmicro 9

Technical Data
2.4
thermoMETER CSmicro 10
Measurement Specifications [SF Models]
SF15/ SF02 2W HS e
Temperature range IR -20 ... 350 °C -30 ... 900 °C -20 ... 150 °C
(scalable via software)
Spectral range 8 ...14 μm 8 ... 14 μm 8 ... 14 μm
Optical resolution 15:1/ 2:1 15:1 15:1
CF-lens (optional) 0.8 mm@ 10 mm/ 0.8 mm@ 10 mm 0.8 mm@ 10 mm
2.5 mm@ 23 mm
Accuracy1) ±1.5 °C or ±1.5 % 2) ±1.5 °C or ±1.0 % 2) ±1 °C or ±1 % 3)
Repeatability1) ±0.75 °C or ±0.75 % 2) ±0.75 °C or ±0.75 % 2) ±0.3 °C or ±0.3 % 3)
Temperature resolution 0.2 °C 0.1 °C 0.025 K
3) 4)
Response time 30 ms (90 % signal) 30 ms (90 % signal) 150 ms (90 % signal)
Warm-up time 10 min 10 min 10 min
Emissivity/ Gain 0.100 ... 1.100 (adjustable via software)
Transmissivity 0.100 ... 1.000 (adjustable via software)
Interface (optional) USB programming interface
Signal processing Average, peak hold, valley hold (adjustable via software)
1) at ambient temperature 23 ±5 °C, whichever is greater; Epsilon = 1; response time 1 s
2) at object temperatures > 0 °C
3) at object temperatures > 20 °C
4) at time constants > 0.2 s

Technical Data
2.5
thermoMETER CSmicro 11
Measurement Specifications [M-2 Model]
2WM-2 e
Temperature range 385 ... 1600 °C
(scalable via software)
Spectral range 1.6 μm
Optical resolution 75:1
Accuracy1) ±(0.3 % of reading + 2 °C) 2)
Repeatability1) ±(0.1 % of reading + 1 °C) 2)
Temperature resolution 0.1 °C
Response time 10 ms (90 % signal)
Emissivity/ Gain 0.100 ... 1.100 (adjustable via software)
Transmissivity 0.100 ... 1.000 (adjustable via software)
Interface (optional) USB programming interface
Signal processing Average, Peak hold, Valley hold (adjustable via software)
1) at ambient temperature 23 ±5 °C; Epsilon = 1; response time = 1 s
2) at object temperatures > 450 °C

Technical Data
2.6 Optical Charts
The following optical charts show the diameter of the measuring spot in dependence on the distance
between measuring object and sensor. The spot size refers to 90 % of the radiation energy.
The distance is always measured from the front edge of the sensor housing/ CF-lens holder/ air purge.
The size of the measuring object and the optical resolution of the infrared thermometer determine the
maximum distance between sensor and measuring object.
In order to prevent measuring errors the object should fill out the field of view of the optics completely.
Consequently, the spot should at all times have at least the same size like the object or should be
smaller than that.
Fig. 2.1: SF15/2W/HS D:S = 15:1
thermoMETER CSmicro 12

Technical Data
Fig. 2.2: SF15/2W/HS with CF lens (0.8 mm@ 10 mm)
Fig. 2.3: SF02 D:S = 2:1
thermoMETER CSmicro 13

Technical Data
Fig. 2.4: SF02 with CF lens (2.5 mm@ 23 mm)
Fig. 2.5: 2WM-2 SF D:S = 75:1
thermoMETER CSmicro 14

Technical Data
Fig. 2.6: 2WM-2 CF D:S = 75:1/D:S Far field = 14:1
If the CF lens (TM-CF-CS or TM-CFH-CS) is used in connection with 2WM-2 units (SF or CF optics) the
focus is shifted to a distance of 11 mm.
thermoMETER CSmicro 15

Technical Data
2.7 CF Lens and Protective Window
If the CF lens is used, the
transmission has to be set to 0.78
[
SF
15/ 2W/
HS
].
The optional CF lens allows the measurement of very small
objects. The minimum spot size depends on the used sensor. The
distance is always measured from the front edge of the CF lens
holder or laminar air purge collar. The installation on the sensor
will be done by turning the CF lens until end stop. To combine it with the HS model please use the
version with external thread M12x1.
Versions Overview:
TM-CF-CS CF lens for installation on sensor [SF15/ 2W/ HS]
TM-CFH-CS CF lens for installation on sensor [2WM-2]
TM-CFAG-CS CF lens with external thread for installation in massive housing [SF15/ 2W/ HS]
TM-CFHAG-CS CF lens with external thread for installation in massive housing [2WM-2]
For protection of the sensor optics a protective window is available. The mechanical dimensions are equal
to the CF lens. It is available in the following versions:
TM-PW-CS Protective window for installation on sensor [SF15/ 2W/ HS]
TM-PWH-CS Protective window for installation on sensor [2WM-2]
TM-PWAG-CS Protective window with external thread for installation in massive housing [SF15/ 2W/ HS]
TM-PWHAG-CSProtective window with external thread for installation in massive housing [2WM-2]
If the protective window is used, the transmission has to be set to 0.83 [SF15/ 2W/ HS] or 0.93
[
2WM-2
]
.
thermoMETER CSmicro 16

Technical Data
Fig. 2.7: CF lens:
[TM-CF-CS/ TM-CFH-CS]
Protective window:
[TM-PW-CS/ TM-PWH-CS]
Fig. 2.8: Laminar air purge with
integrated CF lens: [TM-APLCF-
CS/ TM-APLCFH-CT]
Fig. 2.9: CF lens with external
thread: [TM-CFAG-CS]
Protective window with external
thread: [TM-PWAG-CS]
To chan
g
e the transmission value the o
p
tional USB-Kit
(
includin
g
software
)
is necessar
y
.
thermoMETER CSmicro 17

Installation
3Installation
3.1 Mechanical Installation
The CSmicro is equipped with a metric M12x1 thread and can be installed either directly via the sensor
thread or with the help of the hex nut (standard) to the mounting bracket available. The CSmicro HS will
be delivered with the massive housing and can be installed via the M18x1-thread.
The sensors CSmicro are sensitive optical systems. Please use only the thread for mechanical
installation. Avoid mechanical violence on the sensor
–
this ma
y
destro
y
the s
y
stem
(
ex
p
ir
y
of warrant
y)
.
Fig. 3.1: Sensor SF15/ 2W/ 2WM-2 Fig. 3.2: Sensor HS
thermoMETER CSmicro 18
