Lab Manual for TCP 17051
Table of Contents
Hardware Architecture 2
Lab 1 Instructions 4
Appendix A: Command Reference 12
Appendix B: Reference documents 17
Appendix C: Schematics 18
Adding Wi-Fi to Embedded Designs
Using the RN-131/RN-171 modules

Lab Manual for TCP 17051
Page | 2
Hardware Architecture: Development Environment
UART Interface (J3)
RX - input to evaluation
board
TX - output from evaluation
board
Pin
Description
1
3.3 VDC output
2
GND
3
UART RX
4
UART TX
5
UART RTS
6
UART CTS
7
GPIO4
8
GPIO5
9
GPIO6
10
GPIO7
11
GPIO8
12
GPIO9
13
Reset
Sensors (J1)
Pin
Description
1
Sensor Power
2
Sensor 4 (3.3-V tolerant)
3
Sensor 5 (3.3-V tolerant)
4
Sensor 7 (1.2 V only)
5
Sensor 5 (1.2 V only)
6
Sensor 4 (1.2 V only)
7
Sensor 6 (1.2 V only)
8
Sensor 3 (1.2 V only)
9
GND
WARNING: Sensors must not
have more than 1.2-V DC.
Otherwise, the module may be
permanently damaged.
Table 1. RN-131-EK Evaluation Board LED Indicators
Condition
Blue LED
Red LED
Yellow LED
Green LED
On solid!
Unused
"!
"!
Connected over
TCP
Fast blink!
Unused
Not associated!
Rx/Tx data transfer!
No IP address
Slow blink!
Unused
Associated, no
Internet!
"!
IP address OK
Off!
Unused!
Associated, Internet
OK!
"!
-
Sensor
Interface (J1)
LED Indicators
UART Interface
(J3)
Reset
Pushbutton
USB
Connector
AP/WPS/Factory Reset
Pushbutton (GPIO9)
1
2
3
4
5
6
7
8
9
10
11
12
13
95234678 1

Lab Manual for TCP 17051
Page | 3
Lab Equipment
For this lab, you need the following hardware and software.
Hardware
•RN-131-EK evaluation board, which contains the RN-131 WiFly module
•Personal computer with a USB port
•USB cable to interface the RN-131-EK to the PC
•Access point(s) configured with WAP2 security (this hardware is already set up in
the lab by the instructor)
Software
•Tera Term software (http://sourceforge.jp/projects/ttssh2/releases/)
Access Point Setup
•We have four Access Points set up for this class, each having a unique SSID
•Three Access Point are configured with WAP2-Personal encryption
•One Access Point is open (has no security enabled)

Lab Manual for TCP 17051
Page | 4
Lab 1: Association and Data Transmission over TCP
Purpose:
This lab will teach you how to:
•Configure the module’s parameters.
•Scan, join, and authenticate to wireless networks.
•Discover the WiFly module on your wireless network via UDP.
•Send data over TCP using the RN-131-EK to your lab partner.

Page | 5
Overview:
The following steps will show you how to:
1. Set up the hardware.
2. Configure the module on the evaluation kit.
3. Associate with a network.
4. Discover the module on the network via UDP broadcast.
5. Send data to your lab partner using TCP.
Part 1: Hardware Setup
1. Connect the evaluation board.
a. Connect the RN-131-EK board to your computer using the USB cable.
b. Use the device manager to find the COM port. See the following figures.
2. Launch the Tera Term terminal software from your PC.
a. Choose Serial.
b. In the drop-down menu, select the COM port you found in step 1b.

Lab Manual for TCP 17051
Page | 6
3. Configure the RN-131-EK to enter command mode:
a. Type the escape sequence (three dollar signs, $$$).
b. The module responds with CMD. When you press the enter key, Tera Term
console displays the version prompt.
4. Review the module’s configuration and initialize the module to the factory default
conditions:
a. Check the configuration and firmware version:
i. ver
b. Perform a factory reset (starts the module in a known state):
i. factory RESET
ii. reboot
You have completed the hardware setup.
Example Output:
CMD
<4.00> ver
wifly-GSX Ver 4.00.1, Apr 19 2013 11:48:31 on RN-131
<4.00> factory RESET
Set Factory Defaults
<4.00> reboot
*Reboot*.wifly-GSX Ver 4.00.1, Apr 19 2013 11:48:28 on RN-131
MAC Addr=00:06:66:21:3a:08
*READY*

Lab Manual for TCP 17051
Page | 7
Part 2: Associating with a Wireless Network (Access Points)
1. Search for wireless networks.
a. $$$ (enter command mode)
b. scan
Example Output:
<4.00> scan
<4.00>
SCAN:Found 15
01,01,-69,08,1104,28,00,00:1a:70:74:15:43,youllneverbelievewhatsinside
02,01,-67,08,3104,28,00,06:90:e8:25:54:86,Moxa
03,01,-73,08,3104,28,00,84:c9:b2:65:5b:54,ADoctorADayKeepsAnAppleAway
04,01,-70,08,3104,28,00,00:15:f9:38:bd:b0,laptastic
05,01,-66,04,1100,28,c0,00:22:3f:6b:95:42,SensorNet
06,01,-74,04,3100,28,00,e0:91:f5:a9:8a:a0,accelbiotech
07,06,-58,06,3100,14,00,d8:c7:c8:aa:e7:a0,mchp-peap
08,06,-65,00,2100,00,00,d8:c7:c8:aa:e7:a1,guest
09,06,-57,08,3100,28,00,d8:c7:c8:aa:e7:a2,mchp-secure
10,06,-52,04,3104,28,00,b8:c7:5d:06:d0:2b,
11,06,-53,04,3104,28,00,00:26:f2:4f:89:d6,roving-guest
12,09,-49,04,3104,28,00,e0:91:f5:57:a3:54,
13,11,-48,04,3104,28,00,00:16:b6:45:63:98,CoolBox
14,11,-64,04,3108,28,00,00:14:d1:af:12:0c,roving1
15,11,-72,00,2100,40,40,00:18:02:70:7e:e8,GPT
END:
The scan output format is shown below:
Index
Channel
RSSI
Security
Mode
Capabilities
WPA
Configuration
WPS
Mode
MAC
Address
SSID
For a more detailed description of the scan output fields, refer to the WiFly Command
Reference, Advanced Features & Applications User’s Guide.
NOTE 1: If you do not see the desired access point in the list, re-issue the scan
command.
2: The module does not display hidden access points in the scan output.

Lab Manual for TCP 17051
Page | 8
2. Auto-join a network with persistent configuration.
a. set wlan ssid <string> // AP name
b. set wlan pass <string> // AP passphrase
c. set wlan join 1 // Enable auto-join to AP after reboot
d. set option deivce-id <string> //Give your module a unique device name
e. save
f. reboot
Example Output:
<4.00> set wlan ssid roving1
AOK
<4.00> set wlan pass rubygirl
AOK
<4.00> set wlan join 1
AOK
<4.00> save
Storing in config
<4.00> reboot
*Reboot*.wifly-GSX Ver 4.00.1, Apr 19 2013 11:48:28 on RN-131
MAC Addr=00:06:66:21:3a:08
*READY*
Auto-Assoc roving1 chan=11 mode=MIXED SCAN OK
Joining roving1 now..
Associated!
DHCP: Start
DHCP in 17ms, lease=60s
IF=UP
DHCP=ON
IP=172.35.1.13:2000
NM=255.255.0.0
GW=172.35.0.1
Listen on 2000
TIP: If the network is secure, set the pass phrase with set wlan pass <string> before
joining the network.

Lab Manual for TCP 17051
Page | 9
Part 3: Discovering Your Devices on the Network Using the UDP Broadcast
Protocol
NOTE: You will be observing this section. There is no action required.
The following figure illustrates device discovery via UDP broadcast. The module sends a
UDP broadcast at programmable intervals to make itself discoverable. The UDP
broadcast contains information that identifies the module on the network.
Device Discovery via UDP Broadcast
The UDP broadcast is a fixed 110 byte packet with the following structure:
Roving
Networks
Device
192.168.0.3
Access Point
DHCP server
Roving
Networks
Device
192.168.0.2
192.168.0.1
174.201.25.16
To Internet
Roving
Networks
Device
Roving
Networks
Device Roving
Networks
Device
Roving
Networks
Device
Roving
Networks
Device
192.168.0.4
192.168.0.5
192.168.0.6
192.168.0.7
192.168.0.8
192.168.0.100
UDP Server
Who is
there
I’m
here
I’m
here
I’m
here
I’m
here
I’m
here
I’m
here
I’m
here
0 - 5 6 7 8 - 9 10 - 13 14 - 15 16 - 17 18 - 31 32 - 59 60 - 91 92 - 93 94 - 110
Programmable Device ID Set with set option deviceid <string> (32 Bytes)
Version String with Date Code (26 Bytes)
ASCII Time (13 Bytes)
GPIO Pin Value (2 Bytes)
Access Point’s MAC Address (6 Bytes)
Channel (1 Byte)
RSSI (1 Byte)
Local TCP Port (2 Bytes)
Pin 20’s Battery Voltage in mV, e.g., 2755 (2 Bytes)
RTC Value, MSB to LSB (4 Bytes)
Position
Sensor 0 - 7 Voltage Readings Enabled with set opt format <mask>(16 Bytes)
Boot Time in ms (2 Bytes)

Lab Manual for TCP 17051
Page | 10
Part 4: Communicating with your lab partner over TCP
This lab section will teach you how to:
•Connect from the module to a remote host using TCP (client).
•Connect to module from remote host using TCP (server).
Student A’s module initiates the TCP open and acts as the client. Student B’s module
accepts the TCP connection and acts as the server.
TCP connections are point-to-point connections that provide reliable, guaranteed, in
order data delivery. They are also known as sockets. See the following figure.
TCP Connections
1. Restore the module to the factory defaults:
a. $$$ // Enter command mode.
b. factory RESET // Restore module to factory defaults
c. reboot // Reboot module with factory defaults
2. Associate with AP
a. $$$ // Enter command mode
b. set wlan ssid <string> // Enter AP SSID
c. set wlan pass <string> // Enter AP passphrase
d. set wlan join 1 // Enable auto join
e. save
f. reboot
WiFly Module Opens TCP Connection
Sensing applications
Sending data to web server
Data acquisition systems
Fleet management
Remote Host Opens TCP Connection
Industrial controls
Home automation
Universal remotes
open 192.168.1.200 5000 open 192.168.1.50 2000
RN-134-K
192.168.1.50
Listen on Port 2000
Access Point
DHCP server
Remote
Host
192.168.1.200
Listen on Port 5000

Lab Manual for TCP 17051
Page | 11
3. Check and note your module’s IP address at this stage.
Example Output:
*Reboot*.wifly-GSX Ver 4.00.1, Apr 19 2013 11:48:28 on RN-131
MAC Addr=00:06:66:21:3a:08
*READY*
Auto-Assoc roving1 chan=11 mode=MIXED SCAN OK
Joining roving1 now..
Associated!
DHCP: Start
DHCP in 17ms, lease=60s
IF=UP
DHCP=ON
IP=172.35.1.13:2000
NM=255.255.0.0
GW=172.35.0.1
Listen on 2000
My module’s IP address:________________________
4. Student A, open a TCP connection to your lab partner:
a. $$$ // Enter command mode
b. open <Lab Partner IP address> 2000 // 2000 is the port number
*OPEN* is shown on student A’s Tera Term window and a packet with *HELLO*
is shown on student B’s Tera Term window.
At this point, either student can type data in their Tera Term window and it is sent
over Wi-Fi to your partner’s module using TCP.
5. Close the TCP connection:
a. $$$ // Enter command mode.
b. close // Issue command to close TCP connection
Tera Term displays the close string, *CLOS*.

Lab Manual for TCP 17051
Page | 12
Appendix A: Command Quick Reference
Set Commands (Part 1 of 4)
Command
Default
Description
set adhoc beacon <value>
102
Sets the ad hoc beacon interval in milliseconds.
set adhoc probe <value>
5
Sets the ad hoc probe timeout in seconds (ad hoc
mode only).
set adhoc reboot <value>
0
Sets the reboot timer.
set broadcast address
<address>
255.255.255.255
Sets the address to which the UDP hello/heartbeat
message is sent.
set broadcast backup
<address>
0.0.0.0
Sets the secondary broadcast backup address.
set broadcast interval <mask>
7
Sets the interval (in seconds) at which the
hello/heartbeat UDP message is sent.
set broadcast port <value>
55555
Sets the port to which the UDP hello/heartbeat
message is sent.
set broadcast remote <port>
0
Sets the secondary broadcast port.
set comm $ <char>
$
Sets character used to enter command mode to
<char>.
set comm close <string>
*CLOS*
Sets the ASCI string that is sent to the local UART
when the TCP port is closed.
set comm idle <value>
0
Sets the idle timer value in seconds.
set comm match <value> |
<hex>
0
Sets the match character in hex or decimal.
set comm open <string>
*OPEN*
Sets the ASCI string that is sent to the local
UART when the TCP port is opened.
set comm remote <string>
*HELLO*
Sets the ASCI string that is sent to the remote TCP
client when the TCP port is opened.
set comm size <value>
64
Sets the flush size in bytes.
set comm time <value>
5
Sets the flush timer.
set dhcp lease <value>
86400
Sets the soft AP mode DHCP lease time in seconds.
set dns address <address>
0.0.0.0
Sets the IP address of the DNS sever.
set dns backup <string>
rn.microchip.com
Sets the name of the backup host for TCP/IP
connections to <string>.
set dns name <string>
server1
Sets the name of the host for TCP/IP connections to
<string>.
set ftp addr <address>
0.0.0.0
Sets the FTP server’s IP address of the FTP server.
set ftp dir <string>
public
Sets the starting directory on the FTP server.
set ftp filename <filename>
See description
Sets the name of the file that is transferred when
issuing the ftp u command, where <filename> is
the firmware image. Firmware version 4.0 default is
wifly3-<version>.img (RN131) wifly7-<version>.img
(RN171).
Firmware prior to 4.0 default is wifly-GSX-
<version>.img (RN131) wifly-EZX-<version>.img
(RN171).
set ftp pass <string>
Pass123
Sets the password for accessing the FTP server.
set ftp mode <mask>
0x0
Sets the ftp mode, where <mask> indicates active
or passive mode. Default is passive.
set ftp remote <value>
21
Sets the FTP server’s remote port number.

Lab Manual for TCP 17051
Page | 13
Set Commands (Part 2 of 4)
Command
Default
D
e
s
cr
ip
ti
o
n
set ftp time <value>
200
Sets the FTP timeout value, where <value> is a
decimal number that is five times the number of
seconds required.
set ftp user <string>
roving
Sets the user name for accessing the FTP server.
set ip address <address>
0.0.0.0
Sets the WiFly module’s IP address.
set ip backup <address>
0.0.0.0
Sets a secondary host IP address.
set ip dhcp <value>
1
Enables/disables DHCP mode.
set ip flags <mask>
0x7
Sets the TCP/IP functions.
set ip gateway <address>
0.0.0.0
Sets the gateway IP address.
set ip host <address>
0.0.0.0
Sets the remote host’s IP address.
set ip localport <value>
2000
Sets the local port number.
set ip netmask <address>
255.255.255.0
Sets the network mask.
set ip protocol <flag>
2
Sets the IP protocol.
set ip remote <value>
2000
Sets the remote host port number.
set ip tcp-mode <mask>
0x0
Controls the TCP connect timers, DNS
preferences, and remote configuration
options.
set opt average <value>
5
Sets the number of RSSI samples used to calculate
the running RSSI average.
set opt deviceid <string>
WiFly-XXX
Sets the configurable device ID, where XXX is GSX
for the RN131 and EZX for the RN171.
set opt format <flag>
0x00
Sets the HTTP client/web server information.
set opt jointmr <value>
1000
Sets the join timer, which is the length of time (in
ms) the join function waits for the access point to
complete the association process.
set opt replace <char>
$ (0x24)
Sets the replacement character you use to indicate
spaces in the SSID and pass phrases, where
<char> is a single character.
set opt password <string>
“” (no password
required)
Sets the TCP connection password.
set opt signal <value>
0
Configures the threshold level for the RSSI value in
infrastructure mode.
set q power <value>
0
Automatically turns on the sensor power.
set q sensor <mask>
0
Specifies which sensor pins to sample when
sending data using the UDP broadcast packet
or the HTTP auto sample function.
set sys autoconn <value>
0
Sets the auto-connect timer in TCP mode.
set sys autosleep <value>
0
Sets the auto-sleep timer in UDP mode.
set sys iofunc <mask>
0x0
Sets the I/O port alternate functions.
set sys launch_string <string>
web_app
Sets the application to launch when GPIO9 is high
after powerup.
set sys mask <mask>
0x20F0 (RN131)
0x21F0 (RN171)
Sets the I/O port direction.
set sys printlvl <value>
0x1
Controls the debug print messages printed by the
WiFly module on the UART.
set sys output <mask> <mask>
None
Sets the output GPIO pins high or low. The
optional <mask> sets a subset of the pins.

Lab Manual for TCP 17051
Page | 14
Set Commands (Part 3 of 4)
Command
Default
Description
set sys sleep <value>
0
Sets the sleep timer.
set sys trigger <flag> or
<mask>
0x1
With this parameter setting, the module wakes from
sleep state using the sensor input 0, 1, 2, and 3.
set sys value <mask>
0x0
Sets the default value of the GPIO pins’
outputs upon power-up.
set sys wake <value>
0
Sets the automatic wake timer in seconds.
set time address <address>
64.90.182.55
Sets the time server address.
set time enable <value>
0
Tells the module how often to fetch the time from the
specified SNTP time server in minutes.
set time port <value>
123
Sets the time server port number.
set time raw <value>
None
Allows you to set the RTC raw value from the
console in seconds.
set uart baud <value>
9600
Sets the UART baud rate, where <value> is 2400,
4800, 9600, 19200, 38400, 57600, 115200,
230400, 460800, or 921600.
set uart flow <value>
0
Sets the flow control mode and parity.
set uart instant <value>
Not applicable
Immediately changes the baud rate, where <value>
is 2400, 4800, 9600, 19200, 38400, 57600, 115200,
230400, 460800, or 921600.
set uart mode <mask>
0
Sets the UART mode register.
set uart raw <value>
Not applicable
Sets a raw UART value.
set uart tx <value>
Not applicable
Disables or enables the UART’s TX pin (GPIO10),
where <value> is 1 or 0.
set wlan auth <value>
0
Sets the authentication mode.
set wlan channel <value>
<flag>
0
Sets the WLAN channel, where <value> is a
decimal number from 1 to 13 representing a fixed
channel and <flag> is the optional character i
(meaning immediate).
set wlan ext_antenna <value>
0
Determines which antenna is active, where <value>
is 0 (use the chip antenna) or 1 (use the U.FL
connector).
set wlan fmon <value>
3600
Sets the soft AP mode link monitor timeout threshold
for the associated client device.
set wlan id <string>
–
Reserved for future use.
set wlan hide <value>
0
Hides the WEP key and WPA passphrase, where
<value> is 0 or 1.
set wlan join <value>
1|0
Sets the policy for automatically associating with
network access points.
set wlan key <value>
Not applicable
Sets the 128-bit WEP key, where <value> is
EXACTLY 26 ASCII chars (13 bytes) in hex
without the preceding 0x.
set wlan linkmon <value>
0 (disabled)
Sets the link monitor timeout threshold, where
<value> is a decimal number representing the
number of failed scans before the module declares
AP is Lost and de-authenticates.
set wlan mask <mask>
0x1FFF (all chan-
nels)
Sets the WLAN channel mask, which is used for
scanning channels with auto-join policy 1 or 2).
set wlan phrase <string>
rubygirl
Sets the passphrase for WPA and WPA2 security
modes.
set wlan number <value>
0
Sets the WEP key number.

Lab Manual for TCP 17051
Page | 15
Set Commands (Part 4 of 4)
Command
Default
Description
set wlan rate <value>
12
Sets the wireless data rate.
set wlan ssid <string>
roving1
Sets the SSID with which the module associates.
set wlan tx <value>
0
Sets the Wi-Fi transmit power, where <value> is a
decimal number from 1 to 12 that corresponds to 1 to
12 dBm.
set wlan user <string>
–
Reserved for future use.
Get Commands
Command
Description
get adhoc
Displays the ad hoc settings.
get broadcast
Displays the broadcast UPD address, port, and interval.
get com
Displays the communication settings.
get dns
Displays the DNS settings.
get everything
Displays all of the configuration settings, which is useful for debugging.
get ftp
Displays the FTP settings.
get ip <char>
Displays the IP address and port number settings, where <char> is the
optional parameter a. Using <char> returns the current IP address.
get mac
Displays the device’s MAC address.
get option
Displays the optional settings such as the device ID.
get sys
Displays the system settings, sleep and wake timers, etc.
get time
Displays the time server UDP address and port number.
get wlan
Displays the SSID, channel, and other WLAN settings.
get uart
Displays the UART settings.
ver
Displays the firmware version.
Status Commands
Command
Description
show battery
Displays current battery voltage, and is only applicable to Roving Networks’
battery-powered products such as the RN370 and temperature sensors
(ISENSOR-CB).
show connection
Displays the connection status in the hex format 8<XYZ>.
show io
Displays the GPIO pins’ level status in the hex format 8<ABC>.
show net <char>
Displays the current network status, association, authentication, etc., where
<char> is the optional parameter n. Using the n parameter displays only the
MAC address of the access point with which the module is currently
associated.
show q <value>
Displays the value of the analog interface pin, where <value> is 0 to 7.
show q 0x1<mask>
Displays multiple analog interface values simultaneously.
show rssi
Displays the last received signal strength.
show stats
Displays the current statistics, packet RX/TX counters, etc.
show time
Displays the number of seconds since the module was last powered up or
rebooted.

Lab Manual for TCP 17051
Page | 16
Action Commands
Command
Description
$$$
Use this command to enter command mode.
apmode <bssid> <chan-
nel>
Creates a soft AP network.
close
Disconnects a TCP connection.
exit
Exits command mode.
factory RESET
Loads the factory defaults into the module’s RAM and writes the settings to
the standard configuration file. You must type the word RESET in capital
letters.
join <string>
Instructs the WiFly module to join the network indicated by <string>.
join # <value>
Use this command to join a network that is shown in the scan list, where
<value> is the entry number listed for the network in the scan list.
leave
Disconnects the module from the access point to which it is currently
associated.
lookup <string>
Causes the module to perform a DNS query for host name <string>.
open <address> <value>
Opens a TCP connection to <address>, where <value> is the port number.
ping <string> <value>
Pings a remote host, where <string> is a parameter setting and <value> is the
number of pings. The default is 1 packet.
reboot
Forces the module to reboot (similar to a power cycle).
run
Runs an application using ASCII commands.
scan <value> <char>
Performs an active probe scan of access points on all 13 channels. The
default is 200 ms/channel.
sleep
Puts the module to sleep.
time
Sets the real-time clock by synchronizing with the time server specified
with the time server (set time) parameters.
File I/O Commands
Command
Description
del <string> <value>
Deletes a file.
load <string>
Reads in a new configuration file.
ls
Displays the files in the system.
save <string>
Saves the your configuration settings to a file.
boot image <value>
Makes a file represented by <value> the new boot image.
ftp update <string>
Deletes the backup image file, retrieves a new image file, and updates the
boot pointer to the new image.

Lab Manual for TCP 17051
Page | 17
Appendix B: Reference Documents
For more information, refer to the following documentation:
•WiFly Command Reference, Advanced Features & Applications User’s Guide
•RN-131G & RN-131C 802.11 b/g Wireless LAN Module Data Sheet
•RN-171 802-11 b/g Wireless LAN Module Data Sheet
•RN-131-PICTAIL & RN-171-PICTAIL Evaluation Boards User Manual

Lab Manual for TCP 17051
Page | 18
Appendix C: Schematics
The following figures illustrate the RN-131-EK, RN-131-PICtail, and RN-171-PICtail
schematics, respectively.
RN-131 EK Board Schematic
SENS O R _P O W E R
SENSOR _4
SENSOR _5
SENSOR _7
SENSOR _6
SENSOR _5
SENSOR _4SENSOR4_ P IN
SENSOR5_ P IN
SENSOR _0
SENSOR _1
SENSOR _3
SENSOR _2GPIO _9
RX D
CT S
100k
R16
100k
R9
100k
R6
100k
R7
100k
R14
220kR5
220k
R10
220k
R15
220k
R8
220k
R11
1
2
3
4
5
6
7
8
9
J1
Sensor Interface
VDD_3V3
GPIO _8
GPIO _5
GPIO _6
GPIO _7
GPIO _4
RESET _N
GPIO _9
TX D
RX D
CT S
RT S
1
2
3
4
5
6
7
8
9
10
11
12
13
J3
UART I nterface
VBUS
D_N
D_P
TXD
RXD
RTS
CTS
VBUS
RESET 18
3V 3OU T 16
USBDP 14
USBDM 15
GND
17
CBUS2
10 CBUS1
21
VCCIO 1
CBUS3
11
CBUS4
9
CBUS0
22
GND
20
RI
3DCD
7DSR
6DTR
31 CTS
8RTS
32 RXD
2TXD
30
VCC 19
OSCI 27
OSCO 28
AGND
24
TEST
26
GND
4
THPAD
33
FT232RQ
U1
100nF
C2
100nF
C3
100nF
C1
GND
5
D+
3D-
2VBUS
1
MTAB 6
USB Mini B
J2
i
Power Net
iPowerNet
3k3R1
3k3R3
3k3
R2
3k3
R4
GPIO _5
GPIO _6
GPIO _4
GPIO _6
GPIO _5
GPIO _4
GPIO _7
GPIO _8
GPIO _7
220R
R21
220R
R23
220R
R17
220R
R13
100k
R20
100k
R18
100k
R12
100k
R19
100k
R22
Blue
D4
Green
D3
Yellow
D2
Red
D1
VDD_3V3
GPIO _9
S1
S2
RESET _N
SENSOR _0
SENSOR _1
SENSOR _2
SENSOR _3
SENSOR _6
SENSOR _7
SENSOR _4
SENSOR _5
SENS O R _P O W E R
RESET _N
FOR C E _ AW A K E
GPIO _8
GPIO _9
GPIO _5
GPIO _6
GPIO _7
GPIO _4
CT S
RT S
TX D
RX D
VDD_3V3
29 GPIO_4
29
30 SENSOR_1
30
31 SENSOR_2
31
32 SENSOR_3
32
33 SENSOR_POWER
33
34 SENSOR_0
34
36 GND
36
EPC_A 6
6
EPC_B 7
7
SUPERCAP_BAL ANCE 8
8
FORCE_AWAKE 99
UART_RTS(GPI O_13) 10
10
UART_CTS(GPI O_12) 11
11
UART_RX(GPI O_11) 12
12
UART_TX (GPI O_10) 13
13
SENSOR_6 1
1
SENSOR_4 2
2
SENSOR_5 3
3
SENSOR_7 4
4
RESET 5
5
SPI_MOSI 14 14
SPI_SC K 15 15
SPI_MISO 16 16
SR E G_O UT 17 17
SR E G_I N 18 18
GND 19 19
BATT 2020
VDD 2121
I SP_T X 22 22
23 ISP_RX
23
24 GPIO_9
24
25 GPIO_8
25
26 GPIO_7
26
27 GPIO_6
27
28 GPIO_5
28
37 GND
37
38 GND
38
39 GND
39
40 GND
40
41 GND
41
42 GND
42
43 GND
43
44 GND
44
M1
RN131 Module
100nF
C4
VBUS
i Power NetVin
1
GND
2
Vout 3
Tab
4
TC1262- 3.3VDBTR
U2
VDD_3V3
i Power Net

Lab Manual for TCP 17051
Page | 19
RN-131-PICtail Schematic
29 GPIO_4
29
30 SENSOR_1
30
31 SENSOR_2
31
32 SENSOR_3
32
33 SENSOR_POWER
33
34 SENSOR_0
34
36 GND
36
EPC_A 6
6
EPC_B 7
7
SUPERCAP_BAL ANCE 8
8
FORCE_AWAKE 99
UART_RTS(GPI O_13) 10
10
UART_CTS(GPI O_12) 11
11
UART_RX(GPI O_11) 12
12
UART_TX (GPI O_10) 13
13
SENSOR_6 1
1
SENSOR_4 2
2
SENSOR_5 3
3
SENSOR_7 4
4
RESET 5
5
SPI_MOSI 14 14
SPI_SC K 15 15
SPI_MISO 16 16
SR E G_O UT 17 17
SR E G_I N 18 18
GND 19 19
BATT 2020
VDD 2121
I SP_T X 22 22
23 ISP_RX
23
24 GPIO_9
24
25 GPIO_8
25
26 GPIO_7
26
27 GPIO_6
27
28 GPIO_5
28
37 GND
37
38 GND
38
39 GND
39
40 GND
40
41 GND
41
42 GND
42
43 GND
43
44 GND
44
M2
RN131 Module
VDD3V3
PI C_CTS
PI C_RTS
UART_TX
SS
SCK
MI SO
MOSI
ISP_TX
ISP_RX
STATUS_L ED
WAKEUP
RESET
SI RQ
SEN2
SEN3
SEN0
PI C_TX
iPowerNet
100k
R13
100k
R15
100k
R16
100k
R17
STATUS_L ED
SS
MI SO
MOSI
SI RQ
100k
R14
VDD3V3
SEN0
100k
R22
220k
R21
PI C_TX
10uF
C3
10uF
C4
VDD3V3
Vin
1
GND
2
Vout 3
Tab
4
TC1262- 3.3VU2Vin
iPowerNet
220R
R18
Green L ED
D4
STATUS_LED
220R
R19
RedLED
D5
PI C_L E DR
220R
R20
PIC _L E DY
YellowLED
D6
3k3
R12
1
2
3
4
S2
UART_TXPI C_RX
PI C_TX
ISP_TX
ISP_RX
SEN2
SEN3
RB2/SS1/AN2
1RF2/U1RX_E 2
RF6/SCK1
3RF3/U1TX_E 4
RF7/SDI 1_E
5RG2/SCL 1 6
RF8/SDO1_E
7RG3/SDA1 8
GND
9GND 10
RB0/AN0
11 RB1/AN1 12
RB3/AN3
13 RB4/AN4 14
GND
15 GND 16
RE9/I NT2
17 RE8/I NT1 18
RD14/U1CTS_E
19 RD15/U1RTS_E 20
3.3V
21 3.3V 22
5V
23 5V 24
9V
25 9V 26
RG0
27 RF0 28
RG1
29 RF1 30
J2 PI CTAI L PLUS 30 Pin
VDD3V3
V
DD3V3
PI C_CTS PI C_RTS
PI C_RX
PI C_TX
SS
SCK
MI SO
MOSI
RESET
WAKEUP
PI C_L EDR
SI RQ
PI C_L EDY
RE2
1RA5 2
RE3
3RA4 4
RA7/OSC1
5RA3 6
RA6/OSC2
7RC5 8
RC7
9RC4 10
RC6
11 RC3 12
RB7
13 RA0 14
RB6
15 RA1 16
RB5
17 RA2 18
RB4
19 RC0 20
RB3
21 RC1 22
RB2
23 RC2 24
RB1
25 V_VAR 26
RB0
27 GND 28
J1 PI CTAI L 28 Pin
PI C_TX
PI C_RX
SCK
MI SO
MOSI
PI C_CTS
PI C_RTS
WAKEUP
RESET
PI C_L EDR
SI RQ
PI C_L EDY
i
Power Net
SS
Vin
ISP_ TX
ISP_ R X
1 2
3 4
5 6
7 8
J3
ISP Connector
UART_TX
PI C_TX
RESETWAKEUP
VDD3V3

Lab Manual for TCP 17051
Page | 20
RN-171-PICtail Schematic
RB2/SS1/AN2
1RF2/U1RX_E 2
RF6/SCK1
3RF3/U1TX_E 4
RF7/SDI 1_E
5RG2/SCL 1 6
RF8/SDO1_E
7RG3/SDA1 8
GND
9GND 10
RB0/AN0
11 RB1/AN1 12
RB3/AN3
13 RB4/AN4 14
GND
15 GND 16
RE9/I NT2
17 RE8/I NT1 18
RD14/U1CTS_E
19 RD15/U1RTS_E 20
3.3V
21 3.3V 22
5V
23 5V 24
9V
25 9V 26
RG0
27 RF0 28
RG1
29 RF1 30
J2 PI CTAI L PLUS 30 Pin
VDD3V3VDD3V3
PI C_CTS PI C_RTS
PI C_RX
PI C_TX
SS
SCK
MI SO
MOSI
RESET
WAKEUP
PI C_L EDR
SI RQ
PI C_L EDY
RE2
1RA5 2
RE3
3RA4 4
RA7/OSC1
5RA3 6
RA6/OSC2
7RC5 8
RC7
9RC4 10
RC6
11 RC3 12
RB7
13 RA0 14
RB6
15 RA1 16
RB5
17 RA2 18
RB4
19 RC0 20
RB3
21 RC1 22
RB2
23 RC2 24
RB1
25 V_VAR 26
RB0
27 GND 28
J1 PI CTAI L 28 Pin
PI C_TX
PI C_RX
SCK
MI SO
MOSI
PI C_CTS
PI C_RTS
WAKEUP
RESET
PI C_L EDR
SI RQ
PI C_L EDY
i
Power Net
SS
Vin
VDD3V3
Vin
1
GND
2
Vout 3
Tab
4
TC1262- 3.3VU1Vin
10uF
C1
10uF
C2
100k
R1
100k
R3
100k
R5
100k
R4
STATUS_L ED
SS
MI SO
MOSI
SI RQ
100k
R2
VDD3V3
220R
R10
Green L ED
D1
ST A T U S _L E D
220R
R9
RedLED
D2
PIC _LEDR
220R
R11
PIC _L E DY
YellowLED
D3
SEN0
100k
R7
220k
R6
PI C_TX
ISP_ TX
ISP_ R X
1 2
3 4
5 6
7 8
J3
ISP Connector
UART_TX
PI C_TX
RESETWAKEUP
VDD3V3
29 SENSOR_0
29
30 SENSOR_1
30
31 SENSOR_2
31
32 SENSOR_3
32
33 SENSOR_POWER
33
34 VDD_3V3_RF
34
35 SENSOR_4
35
36 SENSOR_5
36
GPI O_7 6
6
GPI O_6 7
7
GPI O_5 8
8
GPI O_4 9
9
VDD_3V3 10
10
GPI O_3 11
11
GPI O_2 12
12
GPI O_1 13
13
GND 1
1
ISP_TX 2
2
ISP_RX 3
3
GPI O_9 4
4
GPI O_8 5
5
GND 14
14
FL ASH_CS 15
15
SPI _MI SO 16
16
SPI _SCK 17
17
SPI _MOSI 18
18
VDD_3V3_SW 1919
GND 20
20
GND 21 21 GND 22 22
GND 23 23
ANTENNA 24 24
GND 25 25
GND 26 26
GND 27 27
28 GND
28
37 SENSOR_6
37
38 SENSOR_7
38
39 GND
39
40 RESET
40
41 FORCE_AWAKE
41
42 GPIO_14
42
43 GPIO_13 (UART_RTS)
43
44 GPIO_12 (UART_CTS)
44
45 GPIO_11 (UART_RX)
45
46 GPIO_10 (UART_TX)
46
47 GND
47
48 3V 3_R E G _CT R L
48
49 V B A T T
49
M1
RN171 Module
A1
VDD3V3
VDD3V3
VDD3V3
PI C_CTS
PI C_RTS
UART_TX ISP_TX
ISP_RX
RESET
WAKEUP
STATUS_L ED
SS
SCK
MI SO
MOSI
SI RQ
SEN2
SEN3
SEN0
PI C_TX
iRF Net
3k3
R8
1
2
3
4
S1
UART_TXPI C_RX
PI C_TX
ISP_TX
ISP_RX
SEN2
SEN3
