Microh UV BRICK16 User manual

. INTRODUCTION AND UNPACKING
Thank you for purchasing the MICROH UV BRICK16 wash fixture. For your own safety and knowledge, please read
this manual before installing or operating the device. This manual covers the important information on installation and
applications. Please install and operate the fixture according to instructions. Meanwhile, please keep this manual for
future reference.
The MICROH UV BRICK16 wash fixture is made of a new type of high temperature cast aluminum casing. The fixture
is designed and manufactured strictly following CE standards, complying with international standard DMX512 protocol.
This fixture is applicable but not limited to large-scale live performances, theater, studio, nightclubs and discos.
The MICROH UV BRICK16 wash fixture uses 16 x 3W UV LED’s which features high brightness and stability.
Please carefully unpack it when you receive the fixture and check if it was damaged during the transportation. Please
check whether the following items are included inside the box:
Fixture – One Power Cord – One User Manual - One
2. SAFTEY INSTRUCTIONS
This device has left the factory in perfect condition. In order to maintain this condition and to ensure safe operation, it is
absolutely necessary for the user to follow the safety instructions and warning notes written in this user manual.
If the device has been exposed to temperature changes, do not switch it on immediately. The arising condensation
could damage the device. Leave the device switched off until it has reached room temperature, and is dry.
This device falls under protection-class I, therefore it is essential that the device be grounded. The electrical
connection must be carried out by a qualified technician.
The device should only be used with rated voltage and frequency. Make sure that the available voltage is not higher
than 120V as stated at the end of this manual.
Make sure the power cord is never crimped or damaged in any way, as this could cause shock and damage. If your
power cord is damaged in any way, please purchase a new cable from your local MICROH dealer. Always disconnect
power, when the device is not in use or before cleaning it. Never pull out the plug by tugging the power cord.
During initial start-up, some smoke or smell may arise. This is a normal process, and does not necessarily mean that
the device is defective. It should decrease gradually. Please do not project the beam onto combustible substances.
Fixtures cannot be installed on or near combustible substances. Keep more than 50cm distance from wall for proper
ventilation and air flow. If your fixture is or has become damaged in any way, it shall be exclusively replaced or
repaired by the manufacturer to avoid any hazard.
1

2. MOUNTING AND INSTALLATION
Caution: For added protection, mount the fixtures in areas outside walking paths, seating areas, or in areas were the
fixture might be reached by unauthorized personnel. Before mounting the fixture to any surface, make sure that the
installation area can hold a minimum point load of 10 times the device’s weight. Fixture installation must always be
secured with a secondary safety attachment, such as an appropriate safety cable. Never stand directly below the
device when mounting, removing, or servicing the fixture.
Whether installing inverted on a truss / ceiling or set on a flat level surface (see illustration below). Be sure this fixture
is kept at least 0.5m (1.5 ft.) away from any flammable materials (decoration etc.). Always use and install the supplied
safety cable as a safety measure to prevent accidental damage and/or injury in the event the clamp fails.
Mounting Points: Overhead mounting requires extensive experience, including calculating working load limits. A
knowledge of the installation material being used and periodic safety inspection of all installation material and the
fixture are all imperative and should only be performed by a qualified technician. Improper installation can result in
bodily injury and damage.
Be sure to complete all rigging and installation procedures before connecting the main power cord to the appropriate
wall outlet.
Floor Mounting: Set the 2 brackets at your desired angle and aim your fixture accordingly. Please see diagram below.
2

Clamp Mounting: The MICROH UV BRICK16 provides a unique mounting bracket assembly that integrates 2
brackets to be used to mount on a truss or the floor. When mounting this fixture to truss, be sure to secure an
appropriately rated clamp to the included bracket fitted through the center hole. As an added safety measure, be sure
to attach at least one properly rated safety cable to the fixture.
Regardless of the rigging option you choose for your MICROH UV BRICK16 wash fixture, always be sure to secure
your fixture with a safety cable. The fixture provides a built-in rigging point for a safety cable on the hanging bracket as
illustrated above. Be sure to only use the designated rigging point for the safety cable and never secure a safety cable
to a carrying handle.
5. DMX-512 CONTROL CONNECTIONS
This fixture complies with international USITT DMX standards and can be used with either a 3 pin or 5 pin DMX
connector. Plug in the provided 3 pin XLR cable to the female 3-pin XLR output of your controller and the other side to
the male 3-pin XLR input of the LED COB100 PAR/RGBWA. To connect the units to DMX, you must daisy chain the
fixtures together as referred in the diagram below. Always end your DMX-512 connection with a DMX terminator.
For installations where the DMX cable has to run a long distance, or is in an electrically noisy environment, it is
recommended to use a DMX terminator. This helps in preventing corruption of the digital control signal by electrical
noise. The DMX terminatRULVVLPSO\DQ;/5SOXJZLWKDȍUHVLVWRUFRQQHFWHGEHWZHHQSLQVDQGZKLFKLVWKHQ
plugged into the output XLR socket of the last fixture in the chain. Please see illustrations below.
1
23
PIN 3
PIN 2
120¡
3

6. SETUP MENU
NOTE: To adjust the brightness of the “full on”, press and hold the "MODE" button
for more than 5 seconds. The display will show "u255", use the "UP" or "DOWN"
buttons to adjust the brightness. Press “ENTER” to confirm.
7. DMX CHANNEL MODES
4 Channel Mode
Channel Function Value Description
CH1 DIMMER 0 - 255 INCREASE / DECREASE BRIGHTNESS
CH2 STROBE 0 - 255 SLOW - FAST
CH3 FADE 0 - 255 RANDOM FADE
0 - 127 RANDOM FADE
128 - 255 RANDOM CHASE
CH4 MACRO
Display
D001
SOUN
FUON
AUTO
CF**
CC**
CS**
SLAV
SOUND ACTIVE
DMX SETTING
Function
SLAVE MODE
COLOUR SELECTION
COLOUR CHASE
COLOUR FADE
MACROS
FULL ON
4

9. TECHNICAL SPECIFICATIONS
MODEL: UV BRICK16
LAMP: 16 x 3W UV LED’s
OPERATING TEMPERATURE: -25°C to 45°C
VOLTAGE: 90-240VAC 50/60Hz 50W
FUSE: 2A
DIMENSIONS: 320(H) x60(W) x180(L) mm
NET WEIGHT: 3kg
WARRANTY: 2 Year Limited Warranty
10. MAINTENANCE AND CLEANING
The following points have to be considered during the inspection:
1) All screws for installing the device or parts of the device must be tightly connected, and must not be corroded.
2) There must not be any deformations on the housing, colour lenses, fixations or installation spots (ceiling,
suspension, trussing).
3Mechanically moved parts must not show any traces of wearing and must not rotate with unbalances.
4㸧The electric power supply cables must not show any damage, material fatigue or sediments.
Further instructions depending on the installation spot and usage must be handled by a skilled installer or technician.
Any safety issues must be resolved.
In order to keep the fixture in good condition and extend the life, we suggest regular cleaning to the fixture.
1) Clean the inside and outside lens each week to avoid the light output from darkening due to accumulation of dust,
dirt, etc.
2) Clean the fan each week.
3) A detailed electrical check by approved technician every three months is advised. Ensure the circuit contacts are in
good condition.
We recommend a frequent cleaning of the device. Please use a moist, lint- free cloth. Never use alcohol or solvents.
There are no serviceable parts inside the device. Please refer to the instructions under “Installation instructions”.
Should you need any spare parts, please order genuine MICROH parts from your local dealer.
5

IF YOU SHOULD EXPERIENCE ANY PROBLEMS OR ISSUES PLEASE CONTACT MICROH PROFESSIONAL
PRODUCTS BY EMAIL AT [email protected]
In the event that your unit is defective in any way, please contact your local dealer to obtain an RA number for
service repair.
DISCLAIMER – MICROH believes that the information contained within this user manual is accurate. However,
Microh is not responsible for any error or addendums to this manual. If you have any comments or general
suggestions on how this manual can be improved please contact [email protected]. Thank you.
