Micromax L2 User manual

A069 L2 Service Manual
CAUTIONS
Please refer to the phone’s user’s guide for instructions relating to operation, care, and maintenance, which include
important safety information.
Servicing and alignment must be undertaken by qualified personnel only.
Ensure all work is carried out at an anti-static workstation and that an anti-static wrist strap is worn.
Use only approved components as specified in the parts list.
Ensure all components, modules, screws, and insulators are correctly re-fitted after servicing and alignment
Ensure all cables and wires are repositioned correctly
Electrostatic discharge can easily damage the sensitive components of electronic products. Therefore, every service
supplier must observe the precautions which mentioned above.
All manuals and user guides at all-guides.com
all-guides.com

A069 L2 Service Manual
SPEC：
Network：2G: 850MHz/900MHz/1800MHz/1900MHz
Size：145*73*9.7
Camera: Back camera 5 FF Mega, Front camera 0.3 Mega
Battery: 1850 MAH
BT:4.0
USB:Micro USB 2.0
Main Function
Dual Card Full Touch Smartphone
Android 4.2
CPU MT 6572 (1.3GHz Dual core)
5 " FWVGA480*854
Camera：Back camera 5 FF Mega, Front camera
0.3 Mega
WIFI: 802.11n, 802.11g, 802.11b
4GB+512MB
Dual SIM
All manuals and user guides at all-guides.com

A069 L2 Service Manual
SERVICE TOOLS
Voltage regulator
Multimeter
Iron
Hot air gun
Solder wire, soldering paste
Computer and software download cable
Metal tweezers, Screw driver etc
Pick
Driver
Tweezers
Wrist
groun
ding
strap
Antistatic
gloves
SW
upDownlo
ad cable
All manuals and user guides at all-guides.com

A069 L2 Service Manual
CHAPTER 4.SYSTEM BLOCK DIAGRAM
4.1、PCBA A-Side
J1003 Earphone
connector. bug by
damaged.
Earphone no sound
J1203 I/O Connector
bug by damaged No charge
in, Cannot upgrade Software
U301 Flash Bug by
damaged
Cannot power on, cannot
upgrade software.
U101 CPU Bug by
damaged
Cannot power on. No RF
signal. No display or
display abnormality
U401 Power IC Buy by
damaged,Cannot power
on.
No charge in.
Speaker no sound.
U701
BT/WIFI/FM/GPS IC.
Buy by damaged.
BT/WIFI/FM/GPS Not
work
J1205 Battery connector
Bug by damaged.
Not power on.
Not charge in
U501 RF IC
Bug by damaged.
No signal
Can’t power on.
U605 GSM PA
Bug by damaged.
No signal. Large
current
All manuals and user guides at all-guides.com

A069 L2 Service Manual
PCBA-B-Side
J1204 T-Flash
connector
Bug by damaged.
Can't Access T-Flash
Card.
J901 Camera
connector
Bug by damaged.
Can’t take photos.
J1201 J1202 SIM
connector
Bug by damaged.
Cannot the SIM card.
J802 TP Connector
Bug by damaged.
TP not work.
J801 LCD Connector
Bug by damaged.
LCD No display or
display abnormality
All manuals and user guides at all-guides.com

A069 L2 Service Manual
4.2:Side A layout
All manuals and user guides at all-guides.com
all-guides.com

A069 L2 Service Manual
Side B layout
All manuals and user guides at all-guides.com

A069 L2 Service Manual
CHAPTER 6 TROUBLESHOOTING
CANNOT POWER ON-CURRENT SWING INSTABILITY
Upgrade the
software is normal?
Cannot power on
Replace the
structural member.
Check the battery is
normal?
Check the battery
connector in normal?
Replace the PCBA is
normal?.
Replace the battery.
NO
NO
yes
NO
Replace the battery
connector.
yes
yes
Replace the PCBA.
NO
All manuals and user guides at all-guides.com

A069 L2 Service Manual
REPAIR FLOW FOR PHONE DEAD
Phone dead
Upgrade the software can
settle the defect issue?
Clean and reinstall
the keypad or replace
the touch panel.
Check battery connector
and battery touch point if
is dropped or dirty?
Check the keypad if stuck
or touch panel do not work
to make the phone “dead”?
Replace the PCBA
Clean or replace
the battery or
battery connector.
YES
YES
No
No
No
All manuals and user guides at all-guides.com

A069 L2 Service Manual
NO DISPLAY OR DISPLAY ABNORMALITY
No display or display
abnormality after power on
Check LCD connector
is OK or not
Resolder the LCD
connector can settle
the defect issue?
Replace the PCBA.
Check LCD if damage or
liquid flow out
Change LCD
Yes
Clean or reweld
the LCD connector
Yes
Change the LCD can
settle the defect
issue?
No
Upgrade software
No
All manuals and user guides at all-guides.com

A069 L2 Service Manual
INSERT SIM REPAIR PROCESS
NO
Replace SIM card
Replace the
PCBA.
Insert SIM
Clean or replace
SIM connector.
Clean or reweld the
SIM connector
Check SIM connector
is OK or not
OK
Check if all the SIM
pins are clean
NO
Check FPC on SIM
connector is OK or not
NO
Replace FPC
NO
Upgrade software can
settle the defect issue?
NO
All manuals and user guides at all-guides.com
all-guides.com

A069 L2 Service Manual
N0/WEAK SIGNAL TROUBLE SHOOING
No or weak
signal
Inspect the antenna and
antenna connector to see
if there’s any distortion
Replace the
defective
components.
Check and replace RF
connector to see if there’s
any signal
Replace RF
coaxial line
Replace the PCBA.
YES
YES
Check and replace RF
coaxial line to see if there’s
any signal .
YES
Replace RF
connector
NO
NO
All manuals and user guides at all-guides.com

A069 L2 Service Manual
NO/LOW SOUND FROM SPEAKER
Set the phone as
normal mode
Replace the PCBA
No sound or noise
Remove the speaker and
measure with multimeter
to see if there’s any
sound.
Replace speaker.
The phone is in
Silent mode.
Check and replace
FPC is ok or not.
.
Replace FPC.
Yes
NO
yes
All manuals and user guides at all-guides.com

A069 L2 Service Manual
RECEIVER LOW VOICE OR NO VOICE
Measure the signal
with oscillograph
under calling mode
Receiver is low.
Check if receiver
connector is damaged.
Resolder or clean the
receiver connector.
Check if the receiver is
broken or damaged
Yes
NO
NO
Replace the
receiver.
Replace the PCBA.
All manuals and user guides at all-guides.com

A069 L2 Service Manual
NO/LOW SOUND FROM MIC
No/Low sound from
MIC
NO
Yes
YES
Check if there’s
MIC cover
Install the MIC
cover.
Press power on and side
button to test mode and
activate echo loop,
Replace the MIC
Replace FPC to check if
the problem is solved
Replace the
FPC
Replace the PCBA
YES
All manuals and user guides at all-guides.com

A069 L2 Service Manual
Upgrade the software
Check charger and cable without
problem, or change good one
Upgrade the
software is normal?
No charge
DOES NOT CHARGE –NO CHARGE IN
YES
NO
NO
NO
NO
Change battery
Check if I/O connector
works normal
Check and replace
FPC is normal
YES
Replace the PCBA.
Replace the charger
or cable without
Re-solder or replace
the I/O connector
Replace the FPC
All manuals and user guides at all-guides.com
all-guides.com

A069 L2 Service Manual
CAN’T READ T-FLASH CARD
Can’t read
T-Flash card
NO
Check if T-Flash slot
appearance was ok?
Replaced the
T-Flash slot
Check if T-Flash
FPC is normal?
Re-solder or
replace
FPC.
NO
Check if the T-Flash
connector is normal?
Re-solder or replace
the T-Flash connector.
Replace the
PCBA.
NO
All manuals and user guides at all-guides.com

A069 L2 Service Manual
Thanks
For any query or suggestion please write to [e-mail]
WIFI、BT、FM 、GPS DEFECT REPAIR FLOW CHART
YES
NO
WIFI or BT or FM or
GPS can’t open，
Can’t work normal
Software update and check
the function is OK or not
Upgrade Software
Check the WIFI or GPS antenna
is normal?
Check WIFI or GPS RF
connector is normal?
Replace the RF
connector
Replace the PCBA.
NO
Replace the
antenna.
All manuals and user guides at all-guides.com
