Microsoft Natural 6000 User manual

Results stated herein are based on internal Microsoft testing. Individual results and performance may vary. Any device images shown are not actual size. This document is provided for informational purposes only and is subject to change
without notice. Microsoft makes no warranty, express or implied, with this document or the information contained herein. Review any public use or publications of any data herein with your local legal counsel.
©2009 Microsoft Corporation. The names of actual companies and products mentioned herein may be trademarks of their respective owners.
Rev. 0906A Microsoft®Natural Wireless Laser Mouse 6000 Page 1 of 1
Version Information
Product Name
Microsoft®Natural Wireless Laser Mouse 6000
Product Version
Microsoft Natural Wireless Laser Mouse 6000
Mouse Version
Microsoft Natural Wireless Laser Mouse 6000
Receiver Version
Microsoft Wireless Mouse Receiver v1.0
Product Dimensions
Mouse Length
4.12 inches (105 millimeters)
Mouse Width
3.25 inches (82.5 millimeters)
Mouse Depth/Height
2.52 inches (64.1 millimeters)
Mouse Weight
5.07 ounces (144 grams) includes 2 AA alkaline batteries; typical battery weight may vary
Receiver Length
4.40 inches (112 millimeters)
Receiver Width
2.78 inches (70.5 millimeters)
Receiver Depth/Height
1.32 inches (33.6 millimeters)
Receiver Weight
3.17 ounces (89.8 grams)
Receiver Cable Length
60 inches +/- 6 inches (1500 millimeters +/- 150 millimeters)
Compatibility and Localization
Interface
USB Compatible
Operating Systems
• Microsoft Windows®7, Windows Vista®, and Windows XP (excluding Windows XP 64-bit)
• Mac OS X v10.2-10.5.7
Top-line System Requirements
For a Microsoft Windows-based PC:
Requires a PC that meets the requirements for and has installed one of these operating systems:
• Microsoft Windows 7, Windows Vista, or Windows XP (excluding Windows XP 64-bit)
• 45 MB of available hard disk space (install 100 MB)
• USB port
• CD drive
• Microsoft IntelliPoint software version 7.0
For a Macintosh PC:
• Macintosh Mac OS X v10.2-10.5.7
• 15 MB of available hard disk space (install 30 MB)
• USB port
• CD drive
• Microsoft IntelliPoint for Mac software version 7.0
Compatibility Logos
• Compatible with Microsoft Windows 7
• Certified for Microsoft Windows Vista
• Mac logo
• Mac OSX Universal logo
• Certified USB logo
Software Localization
Microsoft IntelliPoint software may be installed in Simplified Chinese, Traditional Chinese, English, French, German, Italian, Japanese, Korean, Brazilian Portuguese,
Iberian Portuguese, or Spanish. If available, standard setup will install the software in the default OS language. Otherwise, the English language version will be
installed.
Tracking Technology
Mouse Tracking System
Microsoft-proprietary laser technology
Imaging Rate
Dynamically adaptable to 6000 frames per second
X-Y Resolution
1000 points per inch (39.38 points per millimeter)
Tracking Speed
Up to 15 inches (381 millimeters) per second
Wireless Technology
Wireless Platform
27 MHz Radio Frequency (RF)
Wireless Channels
27.045 MHz channel 0, 27.145 MHz channel 1
Wireless IDs
Over 65,000 random identification codes
Wireless Range
6 feet (1.83 meters) typical. Note: RF range is affected by many factors, such as nearby metallic objects and relative positioning of the keyboard, mouse, and receiver.
Power Requirements
Battery Type and Quantity
2 AA alkaline batteries (included)
Battery Life
6 months typical
Product Feature Performance
Mouse Button Features
5 buttons including scroll wheel button
Mouse Right & Left Button Life
1,000,000 actuations at no more than 4 actuations per second
Mouse Wheel Button Life
150,000 actuations at no more than 4 actuations per second
Side Button Life
1,000,000 actuations at no more than 4 actuations per second
Mouse Scrolling Features
Tilt wheel enables vertical and horizontal scrolling
Mouse Wheel Vertical Scrolling Life
• 100,000 revolutions (away from user) at no more than 60 rotations per minute
• 300,000 revolutions (toward user) at no more than 60 rotations per minute
Mouse Wheel Horizontal Scrolling Life
150,000 actuations per side at no more than 4 actuations per second
Storage Temperature & Humidity
-40 °F (-40 °C) to 140 °F (60 °C) at < 5% to 65% relative humidity (non-condensing)
Operating Temperature & Humidity
14 °F (-10 °C) to 104 °F (40 °C) at <5% to 80% relative humidity (non-condensing)
Certification Information
Country of Manufacture
People's Republic of China (PRC)
ISO 9001 Qualified Manufacturer
Yes
ISO 14001 Qualified Manufacturer
Yes
Restriction on Hazardous Substances
This device complies with EU directive 2002/95/EC on the Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment.
Laser Compliance
This device complies with International standard IEC 60825-1:2001-08 for a Class 1 laser product. This device also complies with 21 CFR 1040.10 and 1040.11 except
for deviations pursuant to Laser Notice No. 50, dated July 26, 2001.
FCC ID
This device complies with part 15 of the FCC Rules and Industry Canada RSS-310. Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Tested to comply with FCC
standards. For home and office use. Model numbers: 1083, Natural Wireless Laser Mouse 6000 and 1053, Wireless Mouse Receiver v1.0. FCC IDs C3K1083.
Agency and Regulatory Marks
• FCC Declaration of Conformity (USA)
• UL and cUL Notice of Approval (USA and Canada)
• RSS-310 and ICES-003 data on file (Canada)
• Anatel Certificate (Brazil)
• R&TTE Declaration of Conformity, Safety and EMC (European Union)
• ACA/MED Declaration of Conformity (Australia and New Zealand)
• ICASA Certificate (South Africa)
• GOST Certificate (Russia)
• VCCI Certificate (Japan)
• BSMI and DGT Certificates (Taiwan)
• MIC Certificate (Korea)
• CMII Certificate (China)
• SQAS Certificate (Malaysia)
• IDA Approval (Singapore)
• WEEE (European Union)
• EIP Pollution Control Mark, EPUP (China)
• CB Scheme Certificate (International)
Windows Hardware Quality Labs
(WHQL)
ID: 1222524 Microsoft Windows Vista (x86, x64) and Windows XP (x86)
ID: PENDING Microsoft Windows 7
