Midea DC Fan Coil Unit
Four-pipe Four-way Cassette
Technical Service Manual
Midea reserves the right to discontinue, or change specification or designs at any time without notices and without incurring obligations.

Midea DC Fan Coil Unit
1
Four-Pipe Four-way Cassette
DC Fan Coil Unit
1. External Appearance ..........................................................2
2. Features ..............................................................................2
3. Product lineup ....................................................................3
4. Accessories ........................................................................4
5. Specifications .....................................................................5
6. Capacity Table ....................................................................7
7. Dimension.........................................................................22
8. Service Spaces .................................................................22
9. Sound Levels ....................................................................23
10. Wiring Diagrams .............................................................24
11. Troubleshooting..............................................................25
12. Installation ......................................................................26

Midea DC Fan Coil Unit
2
1. External Appearance
2. Features
4-way air supply panel is standard, 360°air supply panel is optional
Current Panel
360°Panel
High comfortable, cold and hot water can supply simultaneously.
Cooling and heating model can exchange conveniently
Built-in drain water pump with 750mm pumping head
Optional extended drainage pan for protecting your ceiling better
Four speed motor with one reserved for more choice
Fresh air provision makes life healthier and more comfortable

Midea DC Fan Coil Unit
3
Excellent efficiency
Midea DC FCU adopt the brushless DC motor, the DC motor efficiency is up to 90%. The power consumption of
DC FCU can be reduced by more than 30% in contrast to the corresponding AC FCU.
DC brushless motor
The motor adopts fully enclosed structure design, it is energy-saving , of high operating efficiency and durable
motor. The motor bearing can operate 80,000 hours continuously, and easy for maintenance.
Low noise
Advanced 3-D spiral fan design reduces air resistance and operating sound. The motor bearing with unique
design makes less operation vibration.
3. Product lineup
Type
600F
750F
850F
950F
1200F
1500F
4-Pipe 4-way cassette (MKA-V)
●
●
●
●
●
●

Midea DC Fan Coil Unit
4
4. Accessories
4.1 Standard accessories
Accessory name
Qty.
Shape
Usage
Owner’s & installation manual
1
/
Installation guide
Installation paper board
1
Bolt M6
4
Tubing& Fittings
2
Soundproof/ insulation sheath
Drainpipe Fittings
1
Out-let pipe
1
Out-let pipe sheath
1
Out-let pipe clasp
5
Tightening band
Remote controller& Its Frame
1
Remote controller
R05/BGE-20
1
Frame
2
Mounting screw(ST2.9x10-C-H)
2
Alkaline dry batteries
Remote controller manual
1
4.2 Optional accessories
Accessory name
Qty.
Shape
Usage
Wired controller
KJR-12B/D
1
Wired control
Network Interface Module
NIM01/E
1
Network Interface Module
Central controller
CCM03
1
Central control
3-way valve assembly
1
Water flow switch

Midea DC Fan Coil Unit
5
5. Specifications
Model
MKA-V600F
MKA-V750F
MKA-V850F
Power supply
V/Ph/Hz
220-240/1/50
Air flow (H/M/L)
m3/h
1287/1084/851
1389/1149/929
1444/1143/1008
CFM
757/637/500
817/675/546
849/672/592
Cooling1
Capacity (H/M/L)
kW
5.36/4.81/4
5.62/5/4.26
5.63/4.88/4.5
Water flow rate(H/M/L)
m3/h
0.99/0.87/0.72
1.04/0.9/0.77
0.99/0.95/0.80
Water pressure drop(H/M/L)
kPa
14.8/11.5/8.1
15.9/12.4/9
16/14.2/10.4
Power input(H/M/L)
W
50/33/19
60/38/23
68/38/29
Heating2
Capacity (H/M/L)
kW
7.38/6.06/5.09
7.66/6.35/5.44
8.15/6.29/5.76
Water flow rate(H/M/L)
m3/h
0.61/0.55/0.47
0.65/0.58/0.50
0.67/0.58/0.54
Water pressure drop(H/M/L)
kPa
25.3/20.5/14.5
32/25.7/19.1
32.6/24.7/21.2
Power input(H/M/L)
W
51/33/19
61/38/23
68/37/28
Heating3
Capacity (H/M/L)
kW
7.66/6.88/5.83
8.15/7.19/6.17
8.34/7.17/6.57
Water flow rate(H/M/L)
m3/h
0.69/0.62/0.54
0.73/0.66/0.56
0.78/0.66/0.61
Water pressure drop(H/M/L)
kPa
37.2/26.1/19.3
39.5/32.5/23.8
41.6/31.5/26.8
Power input(H/M/L)
W
50/33/19
62/39/23
69/38/28
Sound pressure level
(H/M/L)
dB(A)
42/37/31
44/39/33
45/39/36
Rated current
A
0.4
0.5
0.6
Fan motor
Type
DC motor
DC motor
DC motor
Quantity
1
1
1
Fan
Type
Centrifugal, forward-curved Blades
Quantity
1
1
1
Coil
Row
2
2
2
Max. Working pressure
MPa
1.6
Coil length x height
mm
1990x252
Fin type
Hydrophilic aluminum
Number of circuits
Cold water 9; Hot water 3
Fin spacing
mm
1.5
Diameter
mm
Φ7
Panel
Dimensions W×H×D
mm
950×45×950
Packing W×H×D
mm
1035×90×1035
Net weight
kg
6
Gross weight
kg
9
Body
Dimensions W×H×D
mm
840×300×840
Packing W×H×D
mm
900×307×900
Net weight
kg
27.5
27.5
27.5
Gross weight
kg
33.5
33.5
33.5
Pipe connection
Water inlet/outlet pipe
inch
Cold water: RC3/4; Hot water: RC1/2
Drain pipe
mm
ODΦ32
Note:
Based on Eurovent conditions:
H: High fan speed; M: Medium fan speed; L: Low fan speed.
1：Cooling mode (2 and 4-pipe coil): entering air temperature 27°C DB/1 9°C WB, entering/leaving water temperature 7°C /12°C,
high fan speed.
2：Heating mode（1）: (4-pipe coil): entering air temperature 20°C DB, entering/leaving water temperature 65/55°C,
high fan speed.
3：Heating mode（2）(4-pipe coil): entering air temperature 20°C DB, entering/leaving water temperature 70/60°C,
high fan speed.
Specifications
Model
MKA-V950F
MKA-V1200F
MKA-V1500F

Midea DC Fan Coil Unit
6
Power supply
V/Ph/Hz
220-240/1/50
Air flow (H/M/L)
m3/h
1525/1212/1088
1785/1545/1397
1857/1410/1191
CFM
897/712/640
1050/908/821
1092/829/700
Cooling1
Capacity (H/M/L)
kW
5.82/5.07/4.75
8.75/7.97/7.4
8.76/7.29/6.45
Water flow rate(H/M/L)
m3/h
1.04/0.9/0.83
1.57/1.43/1.31
1.58/1.30/1.15
Water pressure drop(H/M/L)
kPa
16.4/12.6/10.9
33.9/30/24
33/22.6/17.7
Power input(H/M/L)
W
77/42/32
107/71/54
125/58/38
Heating2
Capacity (H/M/L)
kW
8.52/6.36/5.93
11.7/9.88/9.27
12.29/9.17/8.24
Water flow rate(H/M/L)
m3/h
0.68/0.59/0.55
0.96/0.89/0.84
0.99/0.83/0.76
Water pressure drop(H/M/L)
kPa
34/26.6/23.5
42.4/36.6/32.6
48.7/32.5/27
Power input(H/M/L)
W
76/42/32
107/72/55
126/58/38
Heating3
Capacity (H/M/L)
kW
8.37/7.24/6.76
12.19/11.21/10.52
12.47/10.53/9.53
Water flow rate(H/M/L)
m3/h
0.78/0.67/0.63
1.10/1.00/0.95
1.14/0.96/0.87
Water pressure drop(H/M/L)
kPa
43.8/33.5/29.3
52.1/44.9/40.6
62.1/45.7/38.3
Power input(H/M/L)
W
76/41/32
107/72/55
126/58/38
Sound pressure level
(H/M/L)
dB(A)
46/41/38
48/44/42
49/43/38
Rated current
A
0.6
0.9
1
Fan motor
Type
DC motor
DC motor
DC motor
Quantity
1
1
1
Fan
Type
Centrifugal, forward-curved Blades
Quantity
1
1
1
Coil
Row
2
3
3
Max. Working pressure
MPa
1.6
Coil length x height
mm
1990x252
2050x252
2080x252
Fin type
Hydrophilic aluminum
Number of circuits
Cold water 9;
Cold water 14; Hot water 4
Hot water 3
Fin spacing
mm
1.5
Diameter
mm
Φ7
Panel
Dimensions W×H×D
mm
950×45×950
Packing W×H×D
mm
1035×90×1035
Net weight
kg
6
Gross weight
kg
9
Body
Dimensions
mm
840×300×840
Packing
mm
900×330×900
Net weight
kg
27.5
30
30
Gross weight
kg
32.4
35
35
Pipe connection
Water inlet/outlet pipe
inch
Cold water: RC3/4; Hot water: RC1/2
Drain pipe
mm
ODΦ32
Note:
Based on Eurovent conditions:
H: High fan speed; M: Medium fan speed; L: Low fan speed.
1：Cooling mode (2 and 4-pipe coil): entering air temperature 27°C DB/1 9°C WB, entering/leaving water temperature 7°C /12°C,
high fan speed.
2：Heating mode（1）: (4-pipe coil): entering air temperature 20°C DB, entering/leaving water temperature 65/55°C,
high fan speed.
3：Heating mode（2）(4-pipe coil): entering air temperature 20°C DB, entering/leaving water temperature 70/60°C,
high fan speed.

Midea DC Fan Coil Unit
7
6. Capacity Table
Cooling Capacity Table
MKA-V600F
EWT
ΔT
Indoor
temp
(W.B.)
Indoor temperature (D.B.)
21
23
25
27
29
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
°C
°C
°C
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
5
3
15
5.15
4.04
0.99
33.52
5.2
4.73
1.48
35.1
5.23
5.21
1.49
35.39
5.85
5.85
1.67
42.85
6.47
6.47
1.84
50.79
17
6.63
3.71
1.89
53.01
5.73
4.13
0.99
22.05
6.56
4.84
1.87
52.04
6.34
5.31
0.99
43.81
6.66
6.22
0.99
52.63
19
8.6
3.78
2.45
82.7
8.56
4.35
2.44
81.99
8.52
4.91
2.43
81.28
6.43
4.88
0.99
17.34
8.43
6.02
2.4
79.88
20
-
-
-
-
9.59
4.38
2.74
99.72
9.55
4.95
2.72
98.88
9.5
5.51
2.71
98.06
9.45
6.06
2.7
97.23
4
15
4.63
3.99
0.99
19.63
4.14
4.07
0.89
13.58
4.81
4.81
1.03
18.76
5.45
5.45
1.17
23.34
6.08
6.08
1.3
28.08
17
5.66
3.29
1.21
24.83
5.66
3.87
0.99
25.19
6.14
4.91
1.32
28.5
5.79
5.37
0.99
23.52
6.09
6
1.31
28.16
19
7.7
3.39
1.65
41.9
7.66
3.96
1.64
41.51
7.62
4.53
1.63
41.13
6.43
4.88
0.99
17.34
7.54
5.63
1.62
40.38
20
-
-
-
-
8.71
4.01
1.87
51.69
8.67
4.57
1.86
51.23
8.62
5.13
1.85
50.78
8.58
5.68
1.84
50.33
5
15
2.63
2.63
0.45
3.65
3.21
3.21
0.55
4.46
4.27
4.27
0.73
7.28
4.98
4.98
0.85
12.3
5.65
5.65
0.97
16.64
17
5.76
3.9
0.99
17.65
5.16
4.15
0.89
13.63
4.42
4.04
0.76
8.24
4.99
4.91
0.99
12.39
5.65
5.65
0.97
16.67
19
6.65
2.96
1.14
22.3
6.61
3.53
1.13
22.06
6.57
4.09
1.13
21.82
6.43
4.88
0.99
17.34
6.92
5.62
0.99
23.85
20
-
-
-
-
7.72
3.6
1.32
28.7
7.68
4.16
1.32
28.42
7.64
4.72
1.31
28.15
7.59
5.27
1.3
27.88
6
15
2.44
2.44
0.35
2.78
2.89
2.89
0.41
3.28
3.34
3.34
0.48
3.8
4.17
4.17
0.6
4.77
5.11
5.11
0.73
7.43
17
2.71
2.29
0.99
3.08
4.41
3.92
0.99
6.36
3.34
3.34
0.48
3.8
4.17
4.17
0.6
4.78
5.12
5.12
0.73
7.46
19
5.64
2.75
0.99
10.33
6.2
3.98
0.99
12.08
6.33
4.49
0.99
14.42
5.88
4.83
0.84
11.88
5.76
5.3
0.99
11.15
20
-
-
-
-
6.5
3.11
0.93
15.28
6.46
3.67
0.92
15.04
6.68
4.47
0.99
16.03
6.96
5.24
0.99
17.46
7
3
15
3.42
3.15
0.98
17.02
3.98
3.98
1.14
22.07
4.62
4.62
1.32
28.36
5.24
5.24
1.5
35.18
5.86
5.86
1.68
42.52
17
5.24
3.12
1.5
35.08
4.85
3.87
0.99
20
5.17
4.24
0.99
34.46
5.53
5.28
1.58
38.44
5.87
5.87
1.68
42.59
19
7.23
3.19
2.07
60.76
7.19
3.76
2.06
60.19
7.15
4.33
2.05
59.62
5.62
4.57
0.99
17.18
7.07
5.43
2.02
58.5
20
-
-
-
-
8.23
3.8
2.36
75.85
8.18
4.37
2.34
75.16
8.14
4.93
2.33
74.49
8.1
5.48
2.32
73.82
4
15
2.52
2.52
0.54
4.18
3.49
3.49
0.75
8.54
4.19
4.19
0.9
14.35
4.84
4.84
1.04
18.78
5.48
5.48
1.18
23.17
17
4.95
3.42
0.99
19.59
4.63
3.78
0.99
17.4
4.29
4
0.92
15.08
4.85
4.83
1.04
18.81
5.48
5.48
1.18
23.21
19
6.25
2.8
1.34
28.93
6.21
3.37
1.33
28.63
6.17
3.93
1.33
28.33
5.62
4.57
0.99
17.18
6.26
5.28
0.99
27.89
20
-
-
-
-
7.28
3.42
1.56
37.5
7.24
3.98
1.56
37.14
7.2
4.54
1.55
36.78
7.16
5.09
1.54
36.42
5
15
2.19
2.19
0.38
2.86
2.63
2.63
0.45
3.44
3.55
3.55
0.61
4.74
4.36
4.36
0.75
8.64
5.04
5.04
0.87
13.23
17
2.33
2.15
0.4
3.04
2.63
2.63
0.45
3.44
3.56
3.56
0.61
4.76
4.36
4.36
0.75
8.68
5.05
5.05
0.87
13.26
19
5.12
2.36
0.99
14.17
5.68
3.42
0.98
16.73
5.72
4.13
0.98
16.93
5.36
4.66
0.99
14.8
5.6
5.29
0.96
16.32
20
-
-
-
-
6.18
2.99
1.06
19.39
6.14
3.55
1.06
19.16
6.22
4.41
0.99
17.82
6.66
5.12
0.99
22.51
6
15
2
2
0.29
2.14
2.44
2.44
0.35
2.62
2.88
2.88
0.41
3.09
3.39
3.39
0.49
3.64
4.47
4.47
0.64
5.26
17
2.06
1.95
0.29
2.2
2.44
2.44
0.35
2.62
2.88
2.88
0.41
3.1
3.39
3.39
0.49
3.65
4.47
4.47
0.64
5.28
19
3.9
2.88
0.99
4.14
4.29
3.3
0.99
4.93
4.4
3.9
0.99
5.41
3.4
3.4
0.49
3.65
4.48
4.48
0.64
5.3
20
-
-
-
-
5.82
3.53
0.99
10.95
5.15
3.85
0.99
7.07
3.78
3.66
0.99
3.99
5.09
4.55
0.99
8.59
9
3
15
2.67
2.67
0.76
9.66
3.35
3.35
0.96
16.13
4
4
1.14
21.8
4.63
4.63
1.32
27.93
5.25
5.25
1.5
34.59
17
4.46
3.24
0.99
26.08
3.66
3.09
1.05
18.79
4.03
3.91
1.15
22.04
4.64
4.64
1.33
27.99
5.26
5.26
1.5
34.66
19
5.74
2.59
1.64
40.15
5.7
3.16
1.63
39.72
5.66
3.73
1.62
39.29
5.63
4.28
1.61
38.87
5.61
4.89
1.6
38.66
20
-
-
-
-
6.75
3.2
1.93
53
6.71
3.77
1.92
52.47
6.67
4.33
1.91
51.94
6.63
4.88
1.9
51.42
4
15
1.93
1.93
0.41
3.01
2.78
2.78
0.6
4.49
3.55
3.55
0.76
9.7
4.22
4.22
0.91
14.54
4.87
4.87
1.05
18.62
17
2.61
2.31
0.99
4.47
2.79
2.78
0.6
4.49
3.55
3.55
0.76
9.73
4.23
4.23
0.91
14.57
4.88
4.88
1.05
18.65
19
4.89
2.46
0.99
17.94
5.2
3.24
0.99
20.67
5.34
3.95
0.99
22.43
5.07
4.4
0.99
20.47
4.94
4.73
1.06
19.06
20
-
-
-
-
5.71
2.81
1.23
24.38
5.68
3.37
1.22
24.1
5.87
4.14
0.99
25.6
6.17
4.79
0.99
32.66
5
15
1.74
1.74
0.3
2.15
2.19
2.19
0.38
2.7
2.66
2.66
0.46
3.29
3.7
3.7
0.64
5.33
4.42
4.42
0.76
9.74
17
1.75
1.73
0.3
2.16
2.19
2.19
0.38
2.7
2.66
2.66
0.46
3.29
3.71
3.71
0.64
5.35
4.43
4.43
0.76
9.77
19
4.71
2.88
0.99
12.4
3.54
2.87
0.99
4.67
3.05
2.98
0.99
3.89
3.72
3.62
0.64
5.39
4.43
4.43
0.76
9.8
20
-
-
-
-
5.56
3.2
0.99
16.1
5.11
3.56
0.99
13.69
5.21
4.32
0.99
14.28
4.6
4.21
0.79
10.84
6
15
1.56
1.56
0.22
1.58
2
2
0.29
2.02
2.44
2.44
0.35
2.48
2.88
2.88
0.41
2.92
3.61
3.61
0.52
3.68
17
1.56
1.55
0.22
1.58
2
2
0.29
2.03
2.44
2.44
0.35
2.48
2.88
2.88
0.41
2.92
3.62
3.62
0.52
3.69
19
1.99
1.44
0.99
1.95
2.1
1.98
0.3
2.12
2.44
2.44
0.35
2.48
2.88
2.88
0.41
2.92
3.63
3.63
0.52
3.7
20
-
-
-
-
2.51
1.93
0.36
2.53
2.56
2.41
0.37
2.59
3.86
3.65
0.99
4.62
3.63
3.63
0.52
3.7

Midea DC Fan Coil Unit
8
(Continued)
MKA-V600F
EWT
ΔT
Indoor
temp
(W.B.)
Indoor temperature (D.B.)
21
23
25
27
29
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
°C
°C
°C
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
11
3
15
1.93
1.93
0.55
3.89
2.71
2.71
0.78
10.55
3.37
3.37
0.97
16.1
4.01
4.01
1.15
21.61
4.64
4.64
1.33
27.63
17
1.96
1.89
0.99
4
2.71
2.71
0.78
10.58
3.38
3.38
0.97
16.13
4.02
4.02
1.15
21.65
4.65
4.65
1.33
27.68
19
4.38
2.27
0.99
23.96
4.63
3.02
1.33
27.48
4.31
3.44
0.99
23.14
4.17
3.82
1.19
23
4.65
4.62
1.33
27.73
20
-
-
-
-
5.14
2.6
1.47
32.88
4.49
3.19
0.99
16.7
5.07
3.72
1.45
32.1
5.05
4.31
0.99
31.87
4
15
1.49
1.49
0.32
2.2
1.93
1.93
0.41
2.86
2.88
2.88
0.62
5.13
3.6
3.6
0.77
10.5
4.26
4.26
0.91
14.59
17
1.49
1.49
0.32
2.2
1.93
1.93
0.41
2.86
2.89
2.89
0.62
5.15
3.6
3.6
0.77
10.53
4.26
4.26
0.92
14.62
19
3.8
2.6
0.99
12.07
1.98
1.88
0.99
2.93
3.06
2.9
0.99
6.57
3.6
3.58
0.77
10.56
4.27
4.27
0.92
14.65
20
-
-
-
-
4.88
2.95
0.99
18.39
4.58
3.4
0.98
16.49
4.01
3.45
0.86
13.15
4.33
4.12
0.93
15.04
5
15
1.3
1.3
0.22
1.52
1.74
1.74
0.3
2.04
2.18
2.18
0.38
2.55
2.8
2.8
0.48
3.28
3.78
3.78
0.65
6.27
17
1.3
1.3
0.22
1.52
1.74
1.74
0.3
2.04
2.18
2.18
0.38
2.55
2.81
2.81
0.48
3.29
3.79
3.79
0.65
6.29
19
1.59
1.36
0.27
1.85
1.77
1.73
0.3
2.06
2.19
2.19
0.38
2.55
2.81
2.81
0.48
3.29
3.79
3.79
0.65
6.32
20
-
-
-
-
2.02
1.73
0.35
2.35
2.21
2.17
0.38
2.58
2.82
2.82
0.48
3.3
3.8
3.8
0.65
6.33
6
15
1.12
1.12
0.16
1.07
1.56
1.56
0.22
1.49
2
2
0.29
1.92
2.44
2.44
0.35
2.35
2.89
2.89
0.42
2.78
17
1.12
1.12
0.16
1.07
1.56
1.56
0.22
1.5
2
2
0.29
1.92
2.44
2.44
0.35
2.35
2.9
2.9
0.42
2.79
19
1.28
1.2
0.18
1.22
1.57
1.55
0.22
1.5
2
2
0.29
1.92
2.44
2.44
0.35
2.35
2.9
2.9
0.42
2.79
20
-
-
-
-
1.7
1.54
0.24
1.62
2
1.98
0.29
1.92
2.44
2.44
0.35
2.35
2.9
2.9
0.42
2.79
13
3
15
1.23
1.23
0.35
2.33
2.02
2.02
0.58
4.31
2.73
2.73
0.78
10.95
3.39
3.39
0.97
16.01
4.03
4.03
1.16
21.4
17
1.23
1.23
0.35
2.33
2.02
2.02
0.58
4.32
2.74
2.74
0.79
10.97
3.39
3.39
0.97
16.04
4.03
4.03
1.16
21.44
19
1.91
1.21
0.99
3.75
2.17
1.91
0.62
5.59
2.75
2.69
0.79
11.07
3.4
3.4
0.98
16.07
4.03
4.03
1.16
21.48
20
-
-
-
-
4.17
2.71
1.2
22.7
3.31
2.52
0.95
15.35
3.52
3.24
1.01
17.07
4.04
4.01
1.16
21.5
4
15
1.04
1.04
0.22
1.46
1.49
1.49
0.32
2.09
1.96
1.96
0.42
2.75
2.94
2.94
0.63
6.04
3.63
3.63
0.78
10.85
17
1.04
1.04
0.22
1.46
1.49
1.49
0.32
2.09
1.96
1.96
0.42
2.75
2.94
2.94
0.63
6.06
3.63
3.63
0.78
10.87
19
1.13
1.03
0.99
1.57
1.49
1.49
0.32
2.09
1.96
1.96
0.42
2.76
2.95
2.95
0.63
6.09
3.64
3.64
0.78
10.9
20
-
-
-
-
2.26
1.77
0.99
3.52
1.96
1.96
0.42
2.76
2.95
2.95
0.63
6.1
3.64
3.64
0.78
10.91
5
15
0.87
0.87
0.15
0.95
1.3
1.3
0.22
1.44
1.74
1.74
0.3
1.93
2.18
2.18
0.38
2.42
3.08
3.08
0.53
3.55
17
0.87
0.87
0.15
0.96
1.3
1.3
0.22
1.44
1.74
1.74
0.3
1.93
2.18
2.18
0.38
2.42
3.09
3.09
0.53
3.56
19
0.89
0.85
0.15
0.99
1.3
1.3
0.22
1.44
1.75
1.75
0.3
1.93
2.18
2.18
0.38
2.42
3.09
3.09
0.53
3.57
20
-
-
-
-
1.33
1.28
0.23
1.47
1.75
1.75
0.3
1.94
2.18
2.18
0.38
2.42
3.09
3.09
0.53
3.58
6
15
0.69
0.69
0.99
0.62
1.12
1.12
0.16
1.02
1.56
1.56
0.22
1.42
2
2
0.29
1.82
2.43
2.43
0.35
2.22
17
0.69
0.69
0.99
0.62
1.12
1.12
0.16
1.02
1.56
1.56
0.22
1.42
2
2
0.29
1.82
2.44
2.44
0.35
2.22
19
0.69
0.67
0.1
0.62
1.13
1.13
0.16
1.02
1.56
1.56
0.22
1.42
2
2
0.29
1.82
2.44
2.44
0.35
2.22
20
-
-
-
-
1.14
1.11
0.16
1.03
1.56
1.56
0.22
1.42
2
2
0.29
1.82
2.44
2.44
0.35
2.22
15
3
15
0.78
0.78
0.22
1.41
1.22
1.22
0.35
2.21
2.06
2.06
0.59
5.04
2.76
2.76
0.79
11.05
3.41
3.41
0.98
15.87
17
0.78
0.78
0.23
1.41
1.23
1.23
0.35
2.21
2.06
2.06
0.59
5.06
2.76
2.76
0.79
11.07
3.41
3.41
0.98
15.9
19
0.79
0.77
0.23
1.41
1.23
1.23
0.35
2.21
2.07
2.07
0.59
5.09
2.76
2.76
0.79
11.1
3.41
3.41
0.98
15.93
20
-
-
-
-
1.23
1.22
0.35
2.21
2.07
2.07
0.59
5.1
2.76
2.76
0.79
11.11
3.41
3.41
0.98
15.94
4
15
0.61
0.61
0.13
0.8
1.04
1.04
0.22
1.39
1.49
1.49
0.32
1.98
2.08
2.08
0.45
2.78
2.98
2.98
0.64
6.82
17
0.61
0.61
0.13
0.8
1.04
1.04
0.22
1.39
1.49
1.49
0.32
1.98
2.08
2.08
0.45
2.78
2.99
2.99
0.64
6.85
19
0.61
0.61
0.13
0.8
1.04
1.04
0.22
1.39
1.49
1.49
0.32
1.98
2.09
2.09
0.45
2.79
2.99
2.99
0.64
6.87
20
-
-
-
-
1.04
1.04
0.22
1.39
1.49
1.49
0.32
1.98
2.09
2.09
0.45
2.79
2.99
2.99
0.64
6.89
5
15
0.52
0.52
0.99
0.6
0.86
0.86
0.15
0.91
1.3
1.3
0.22
1.37
1.74
1.74
0.3
1.83
2.19
2.19
0.38
2.3
17
0.52
0.52
0.99
0.6
0.87
0.87
0.15
0.91
1.3
1.3
0.22
1.37
1.74
1.74
0.3
1.83
2.19
2.19
0.38
2.3
19
0.52
0.52
0.99
0.6
0.87
0.87
0.15
0.91
1.3
1.3
0.22
1.37
1.74
1.74
0.3
1.83
2.19
2.19
0.38
2.3
20
-
-
-
-
0.87
0.87
0.15
0.91
1.3
1.3
0.22
1.37
1.75
1.75
0.3
1.84
2.19
2.19
0.38
2.31
6
15
-
-
-
-
0.69
0.69
0.1
0.59
1.12
1.12
0.16
0.97
1.56
1.56
0.22
1.35
2
2
0.29
1.73
17
-
-
-
-
0.69
0.69
0.1
0.59
1.12
1.12
0.16
0.97
1.56
1.56
0.22
1.35
2
2
0.29
1.73
19
-
-
-
-
0.69
0.69
0.99
0.59
1.13
1.13
0.16
0.97
1.56
1.56
0.22
1.35
2
2
0.29
1.73
20
-
-
-
-
0.69
0.69
0.99
0.59
1.13
1.13
0.16
0.97
1.56
1.56
0.22
1.35
2
2
0.29
1.73
Abbreviations:
EWT: Enter Water Temp. (℃)
Δt: Temperature Difference (℃)
DB: Dry Bulb Temp. (℃)
WF: Water Flow (m3/h)
WB: Wet Bulb Temp. (℃)
TC: Total Cooling Capacity (kW)
SC: Sensible Cooling Capacity (kW)
WPD: Water Pressure Drop (kPa)

Midea DC Fan Coil Unit
9
MKA-V750F
EWT
ΔT
Indoor
temp(W.B.)
Indoor temperature (D.B.)
21
23
25
27
29
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
°C
°C
°C
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
5
3
15
5.39
4.26
1.04
36.02
4.79
4.37
1.37
30.06
5.28
5.28
1.51
35.5
5.92
5.92
1.69
43.1
6.56
6.56
1.87
51.21
17
6.66
3.75
1.9
52.61
6.63
4.33
1.89
52.15
6.59
4.9
1.88
51.7
6.75
5.73
1.04
50.74
6.66
6.28
1.9
52.62
19
8.68
3.81
2.47
82.67
8.63
4.4
2.46
82
8.59
4.98
2.45
81.34
8.55
5.55
2.44
80.69
8.51
6.11
2.43
80.04
20
-
-
-
-
9.69
4.43
2.76
99.99
9.65
5.01
2.75
99.2
9.6
5.59
2.74
98.43
9.56
6.16
2.73
97.66
4
15
3.5
3.22
1.04
7.68
4.14
4.12
0.89
13.36
4.83
4.83
1.03
18.62
5.49
5.49
1.18
23.28
6.14
6.14
1.32
28.11
17
5.6
3.29
1.2
24.09
5.99
4.38
1.04
24
6.37
5.23
1.04
30.46
6.12
5.72
1.04
27.91
6.14
6.1
1.32
28.16
19
7.71
3.4
1.65
41.33
7.67
3.98
1.64
40.97
7.63
4.56
1.64
40.61
7.59
5.13
1.63
40.26
7.55
5.7
1.62
39.91
20
-
-
-
-
8.75
4.03
1.88
51.26
8.71
4.61
1.87
50.83
8.66
5.18
1.86
50.41
8.62
5.75
1.85
49.99
5
15
2.57
2.57
0.44
3.51
3.09
3.09
0.53
4.22
4.23
4.23
0.73
6.98
4.98
4.98
0.85
12.09
5.67
5.67
0.97
16.52
17
5.36
3.79
1.04
14.66
4.68
3.73
1.04
10.75
5.61
5.02
1.04
18.92
4.98
4.94
0.85
12.11
5.67
5.67
0.97
16.55
19
6.57
2.93
1.13
21.48
6.53
3.52
1.12
21.26
6.49
4.09
1.11
21.04
6.79
5.08
1.04
20.86
7.07
5.89
1.04
24.33
20
-
-
-
-
7.68
3.59
1.32
27.98
7.64
4.17
1.31
27.72
7.59
4.74
1.3
27.47
7.55
5.31
1.3
27.22
6
15
2.38
2.38
0.34
2.66
2.82
2.82
0.4
3.16
3.25
3.25
0.46
3.64
3.97
3.97
0.57
4.47
5.08
5.08
0.73
7.16
17
2.6
2.31
0.37
2.9
2.82
2.76
1.04
3.16
5.61
5.02
1.04
18.92
3.98
3.98
0.57
4.47
5.08
5.08
0.73
7.19
19
5.9
3.37
1.04
9.7
6.5
4.14
1.04
14.97
5.97
4.42
1.04
12.21
5.6
4.78
1.04
10.26
5.19
4.87
0.74
7.7
20
-
-
-
-
6.32
3.05
0.9
14.11
6.47
3.71
1.04
15.55
6.97
4.84
1.04
16.91
7.05
5.56
1.01
17.62
7
3
15
3.45
3.25
1.04
16.8
4.01
4.01
1.15
21.98
4.66
4.66
1.34
28.39
5.31
5.31
1.52
35.35
5.94
5.94
1.7
42.83
17
5.23
3.14
1.5
34.48
5.72
4.16
1.64
40.16
5.71
4.81
1.04
40.37
5.37
5.12
1.54
36.07
5.95
5.95
1.7
42.9
19
7.27
3.21
2.08
60.42
7.23
3.8
2.07
59.88
7.19
4.38
2.06
59.35
7.16
4.95
2.05
58.83
7.12
5.51
2.04
58.3
20
-
-
-
-
8.29
3.84
2.37
75.75
8.25
4.42
2.36
75.11
8.21
4.99
2.35
74.47
8.17
5.56
2.34
73.84
4
15
2.4
2.4
0.52
3.93
3.48
3.48
0.75
8.25
4.19
4.19
0.9
14.19
4.87
4.87
1.05
18.69
5.53
5.53
1.19
23.16
17
5.23
3.8
1.04
21.37
4.59
3.69
1.04
18.2
4.26
4.04
0.92
14.68
4.87
4.87
1.05
18.72
5.53
5.53
1.19
23.19
19
6.21
2.79
1.33
28.23
6.18
3.37
1.33
27.95
6.14
3.95
1.32
27.66
6.53
4.92
1.04
30.59
6.42
5.48
1.04
28.87
20
-
-
-
-
7.28
3.43
1.56
36.91
7.24
4.01
1.55
36.56
7.2
4.58
1.55
36.22
7.16
5.15
1.54
35.89
5
15
2.13
2.13
0.37
2.74
2.56
2.56
0.44
3.3
3.44
3.44
0.59
4.47
4.34
4.34
0.75
8.4
5.05
5.05
0.87
13.09
17
2.21
2.07
1.04
2.84
2.57
2.57
0.44
3.3
3.45
3.45
0.59
4.48
4.34
4.34
0.75
8.43
5.06
5.06
0.87
13.12
19
5.52
2.69
1.04
16.43
6.04
4
1.04
17.6
5.83
4.38
1
17.29
5.62
4.98
1.03
15.9
5.15
4.85
0.89
13.68
20
-
-
-
-
6.08
2.96
1.04
18.56
6.3
3.82
1.04
19.27
6.8
4.82
1.04
22.39
6.63
5.4
1.04
21
6
15
1.94
1.94
0.28
2.05
2.38
2.38
0.34
2.51
2.81
2.81
0.4
2.97
3.28
3.28
0.47
3.47
4.4
4.4
0.63
5.01
17
1.97
1.9
0.28
2.08
2.38
2.38
0.34
2.51
2.81
2.81
0.4
2.98
3.28
3.28
0.47
3.48
4.41
4.41
0.63
5.02
19
2.87
2.07
1.04
3.03
2.68
2.34
0.38
2.83
2.84
2.75
1.04
3
3.29
3.29
0.47
3.48
4.42
4.42
0.63
5.04
20
-
-
-
-
5.99
3.63
0.86
12.76
3.64
2.89
1.04
3.98
5.27
4.41
0.75
8.98
4.56
4.3
1.04
5.44
9
3
15
2.66
2.66
0.76
9.41
3.36
3.36
0.96
16
4.03
4.03
1.15
21.76
4.68
4.68
1.34
28.01
5.32
5.32
1.52
34.81
17
3.78
2.69
1.04
18.96
3.63
3.13
1.04
18.2
4.05
3.97
1.16
21.9
4.68
4.68
1.34
28.06
5.32
5.32
1.52
34.87
19
5.74
2.6
1.64
39.57
5.08
3.37
1.04
18.15
4.96
3.88
1.04
18.07
5.84
4.42
1.04
45.88
5.8
5.25
1.04
37.78
20
-
-
-
-
6.78
3.23
1.94
52.58
6.74
3.81
1.93
52.08
5.49
4.26
1.04
18.08
5.42
4.83
1.04
18.04
4
15
1.88
1.88
0.4
2.9
2.71
2.71
0.58
4.25
3.54
3.54
0.76
9.49
4.24
4.24
0.91
14.42
4.9
4.9
1.05
18.57
17
1.89
1.85
0.41
2.91
2.72
2.72
0.58
4.26
3.55
3.55
0.76
9.52
4.24
4.24
0.91
14.45
4.91
4.91
1.05
18.6
19
5.08
2.53
1.04
20.53
5.08
3.37
1.04
18.15
4.96
3.85
1.04
18.11
4.56
3.99
1.04
16.65
4.95
4.78
1.06
18.85
20
-
-
-
-
5.66
2.81
1.22
23.65
5.9
3.66
1.04
24.78
5.51
4.29
1.04
18.14
5.43
4.81
1.04
18.09
5
15
1.69
1.69
0.29
2.06
2.13
2.13
0.37
2.59
2.58
2.58
0.44
3.14
3.66
3.66
0.63
5.08
4.42
4.42
0.76
9.57
17
1.69
1.69
0.29
2.06
2.13
2.13
0.37
2.59
2.58
2.58
0.44
3.14
3.67
3.67
0.63
5.1
4.42
4.42
0.76
9.6
19
4.16
2.51
1.04
9.64
5.36
3.74
1.04
19.43
3.16
3.04
1.04
4.1
3.68
3.66
0.63
5.13
4.43
4.43
0.76
9.63
20
-
-
-
-
5.35
3.22
1.04
14.89
5.21
3.85
0.89
13.92
4.75
3.99
1.04
11.91
4.54
4.25
1.04
10.33
6
15
1.51
1.51
0.22
1.5
1.94
1.94
0.28
1.94
2.38
2.38
0.34
2.38
2.81
2.81
0.4
2.81
3.43
3.43
0.49
3.44
17
1.51
1.51
0.22
1.5
1.94
1.94
0.28
1.94
2.38
2.38
0.34
2.38
2.81
2.81
0.4
2.81
3.44
3.44
0.49
3.44
19
1.97
1.6
1.04
1.96
2.01
1.9
0.29
2
2.38
2.38
0.34
2.38
2.81
2.81
0.4
2.81
3.44
3.44
0.49
3.45
20
-
-
-
-
2.36
1.92
0.34
2.35
4
3.63
1.04
4.68
2.81
2.81
0.4
2.81
3.45
3.45
0.49
3.45

Midea DC Fan Coil Unit
10
(Continued)
MKA-V750F
EWT
ΔT
Indoor
temp(W.B.)
Indoor temperature (D.B.)
21
23
25
27
29
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
°C
°C
°C
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
11
3
15
1.82
1.82
0.52
3.6
2.7
2.7
0.77
10.37
3.39
3.39
0.97
16.01
4.05
4.05
1.16
21.61
4.69
4.69
1.35
27.75
17
1.83
1.83
0.52
3.61
2.71
2.71
0.78
10.4
3.4
3.4
0.97
16.04
4.05
4.05
1.16
21.65
4.7
4.7
1.35
27.8
19
4.77
2.64
1.04
27.63
4.89
3.37
1.4
29.77
4.59
3.75
1.04
26.71
4.17
3.89
1.2
22.72
4.7
4.7
1.35
27.84
20
-
-
-
-
5.13
2.61
1.47
32.24
4.68
3.47
1.04
17.87
5.29
3.95
1.04
34.38
5.22
4.68
1.04
30.96
4
15
1.44
1.44
0.31
2.11
1.88
1.88
0.4
2.74
2.85
2.85
0.61
4.88
3.6
3.6
0.77
10.36
4.28
4.28
0.92
14.51
17
1.45
1.45
0.31
2.11
1.88
1.88
0.4
2.74
2.85
2.85
0.61
4.9
3.6
3.6
0.77
10.38
4.28
4.28
0.92
14.53
19
2.09
1.76
1.04
3.04
2.61
2.16
1.04
4.24
2.89
2.78
0.62
5.08
3.6
3.6
0.77
10.41
4.29
4.29
0.92
14.56
20
-
-
-
-
4.72
2.96
1.04
17.14
4.7
3.71
1.01
16.99
4.04
3.58
0.87
13.09
4.33
4.17
1.04
14.81
5
15
1.26
1.26
0.22
1.45
1.69
1.69
0.29
1.95
2.13
2.13
0.37
2.45
2.66
2.66
0.46
3.07
3.76
3.76
0.65
6.05
17
1.26
1.26
0.22
1.45
1.69
1.69
0.29
1.95
2.13
2.13
0.37
2.45
2.67
2.67
0.46
3.08
3.77
3.77
0.65
6.07
19
1.48
1.3
1.04
1.69
1.7
1.7
0.29
1.96
2.13
2.13
0.37
2.45
2.67
2.67
0.46
3.08
3.77
3.77
0.65
6.09
20
-
-
-
-
1.93
1.76
1.04
2.21
2.14
2.12
0.37
2.46
2.67
2.67
0.46
3.08
3.77
3.77
0.65
6.11
6
15
1.08
1.08
0.16
1.02
1.51
1.51
0.22
1.43
1.94
1.94
0.28
1.84
2.38
2.38
0.34
2.25
2.81
2.81
0.4
2.66
17
1.08
1.08
0.16
1.02
1.51
1.51
0.22
1.43
1.94
1.94
0.28
1.84
2.38
2.38
0.34
2.25
2.81
2.81
0.4
2.67
19
1.18
1.06
1.04
1.1
1.51
1.51
0.22
1.43
1.94
1.94
0.28
1.84
2.38
2.38
0.34
2.25
2.82
2.82
0.4
2.67
20
-
-
-
-
1.62
1.55
1.04
1.53
1.94
1.94
0.28
1.84
2.38
2.38
0.34
2.25
2.82
2.82
0.4
2.67
13
3
15
1.2
1.2
0.34
2.24
1.99
1.99
0.57
4.08
2.74
2.74
0.79
10.81
3.41
3.41
0.98
15.95
4.07
4.07
1.17
21.44
17
1.2
1.2
0.34
2.24
1.99
1.99
0.57
4.09
2.74
2.74
0.79
10.84
3.42
3.42
0.98
15.98
4.07
4.07
1.17
21.48
19
1.77
1.35
1.04
3.31
2.09
1.91
0.6
4.8
2.75
2.71
0.79
10.87
3.42
3.42
0.98
16.01
4.07
4.07
1.17
21.51
20
-
-
-
-
3.69
2.47
1.04
17.63
3.24
2.53
0.93
14.57
3.51
3.28
1.01
16.75
4.08
4.08
1.17
21.53
4
15
1.01
1.01
0.22
1.39
1.45
1.45
0.31
2
1.89
1.89
0.41
2.62
2.92
2.92
0.63
5.82
3.64
3.64
0.78
10.74
17
1.01
1.01
0.22
1.4
1.45
1.45
0.31
2
1.89
1.89
0.41
2.62
2.93
2.93
0.63
5.84
3.64
3.64
0.78
10.76
19
1.06
0.98
1.04
1.46
1.45
1.45
0.31
2
1.89
1.89
0.41
2.62
2.93
2.93
0.63
5.87
3.65
3.65
0.78
10.78
20
-
-
-
-
1.52
1.47
0.33
2.09
1.89
1.89
0.41
2.62
2.93
2.93
0.63
5.88
3.65
3.65
0.79
10.79
5
15
0.83
0.83
0.14
0.91
1.26
1.26
0.22
1.37
1.69
1.69
0.29
1.85
2.12
2.12
0.37
2.32
3.01
3.01
0.52
3.35
17
0.83
0.83
0.14
0.91
1.26
1.26
0.22
1.38
1.7
1.7
0.29
1.85
2.12
2.12
0.37
2.32
3.01
3.01
0.52
3.36
19
0.85
0.81
0.15
0.92
1.26
1.26
0.22
1.38
1.7
1.7
0.29
1.85
2.13
2.13
0.37
2.32
3.02
3.02
0.52
3.37
20
-
-
-
-
1.29
1.27
0.22
1.4
1.7
1.7
0.29
1.85
2.13
2.13
0.37
2.32
3.02
3.02
0.52
3.38
6
15
0.7
0.7
1.04
0.65
1.08
1.08
0.16
0.97
1.51
1.51
0.22
1.35
1.94
1.94
0.28
1.74
2.37
2.37
0.34
2.13
17
0.7
0.7
1.04
0.65
1.08
1.08
0.16
0.97
1.51
1.51
0.22
1.35
1.94
1.94
0.28
1.74
2.38
2.38
0.34
2.13
19
0.7
0.68
1.04
0.65
1.09
1.09
0.16
0.97
1.51
1.51
0.22
1.35
1.94
1.94
0.28
1.74
2.38
2.38
0.34
2.13
20
-
-
-
-
1.09
1.07
0.16
0.97
1.51
1.51
0.22
1.36
1.95
1.95
0.28
1.75
2.38
2.38
0.34
2.14
15
3
15
0.76
0.76
0.22
1.34
1.19
1.19
0.34
2.12
2.05
2.05
0.59
4.82
2.77
2.77
0.79
10.95
3.43
3.43
0.99
15.84
17
0.76
0.76
0.22
1.35
1.19
1.19
0.34
2.12
2.05
2.05
0.59
4.83
2.77
2.77
0.79
10.97
3.44
3.44
0.99
15.87
19
0.76
0.76
0.22
1.35
1.2
1.2
0.34
2.12
2.05
2.05
0.59
4.85
2.77
2.77
0.8
10.99
3.44
3.44
0.99
15.9
20
-
-
-
-
1.2
1.2
0.34
2.12
2.05
2.05
0.59
4.86
2.77
2.77
0.8
11
3.44
3.44
0.99
15.91
4
15
0.58
0.58
0.13
0.76
1.01
1.01
0.22
1.32
1.45
1.45
0.31
1.9
1.96
1.96
0.42
2.58
2.98
2.98
0.64
6.66
17
0.58
0.58
0.13
0.76
1.01
1.01
0.22
1.32
1.45
1.45
0.31
1.9
1.96
1.96
0.42
2.58
2.98
2.98
0.64
6.68
19
0.58
0.58
0.13
0.76
1.01
1.01
0.22
1.33
1.45
1.45
0.31
1.9
1.97
1.97
0.42
2.58
2.98
2.98
0.64
6.7
20
-
-
-
-
1.01
1.01
0.22
1.33
1.45
1.45
0.31
1.9
1.97
1.97
0.42
2.59
2.98
2.98
0.64
6.72
5
15
0.52
0.52
1.04
0.63
0.83
0.83
0.14
0.86
1.26
1.26
0.22
1.3
1.69
1.69
0.29
1.76
2.12
2.12
0.37
2.2
17
0.52
0.52
1.04
0.63
0.83
0.83
0.14
0.86
1.26
1.26
0.22
1.3
1.7
1.7
0.29
1.76
2.12
2.12
0.37
2.2
19
0.52
0.52
1.04
0.63
0.83
0.83
0.14
0.86
1.26
1.26
0.22
1.31
1.7
1.7
0.29
1.76
2.13
2.13
0.37
2.2
20
-
-
-
-
0.83
0.83
0.14
0.86
1.26
1.26
0.22
1.31
1.7
1.7
0.29
1.76
2.13
2.13
0.37
2.21
6
15
-
-
-
-
0.7
0.7
1.04
0.62
1.08
1.08
0.16
0.92
1.51
1.51
0.22
1.29
1.94
1.94
0.28
1.66
17
-
-
-
-
0.7
0.7
0.1
0.62
1.09
1.09
0.16
0.92
1.51
1.51
0.22
1.29
1.94
1.94
0.28
1.66
19
-
-
-
-
0.7
0.7
1.04
0.62
1.09
1.09
0.16
0.92
1.51
1.51
0.22
1.29
1.94
1.94
0.28
1.66
20
-
-
-
-
0.7
0.7
1.04
0.62
1.09
1.09
0.16
0.92
1.51
1.51
0.22
1.29
1.95
1.95
0.28
1.66
Abbreviations:
EWT: Enter Water Temp. (℃)
Δt: Temperature Difference (℃)
DB: Dry Bulb Temp. (℃)
WF: Water Flow (m3/h)
WB: Wet Bulb Temp. (℃)
TC: Total Cooling Capacity (kW)
SC: Sensible Cooling Capacity (kW)
WPD: Water Pressure Drop (kPa)

Midea DC Fan Coil Unit
11
MKA-V850F
EWT
ΔT
Indoor
temp(W.B.)
Indoor temperature (D.B.)
21
23
25
27
29
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
°C
°C
°C
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
5
3
15
5.8
4.68
0.99
40.41
4.88
4.45
1.39
30.28
5.39
5.39
1.54
35.83
6.04
6.04
1.72
43.53
6.69
6.69
1.91
51.74
17
6.79
3.82
1.93
53.03
6.75
4.41
1.93
52.57
6.72
5
1.92
52.12
7.13
5.91
0.99
62.26
6.79
6.41
1.94
53.12
19
8.84
3.89
2.52
83.41
8.8
4.48
2.51
82.75
8.76
5.08
2.5
82.1
8.72
5.66
2.49
81.46
8.68
6.24
2.48
80.82
20
-
-
-
-
9.88
4.52
2.82
100.96
9.84
5.12
2.81
100.19
7.04
4.93
0.99
16.66
9.75
6.28
2.78
98.67
4
15
4.39
3.97
0.99
16.35
4.21
4.2
0.9
13.69
4.92
4.92
1.05
18.81
5.6
5.6
1.2
23.48
6.26
6.26
1.34
28.37
17
5.7
3.36
1.22
24.23
6.17
4.51
0.99
25.06
6.4
5.2
0.99
30.85
6.07
5.68
0.99
26.36
6.26
6.22
1.34
28.41
19
7.85
3.46
1.68
41.61
7.81
4.06
1.67
41.26
7.77
4.65
1.67
40.91
7.73
5.24
1.66
40.56
7.69
5.81
1.65
40.22
20
-
-
-
-
8.91
4.11
1.91
51.65
8.87
4.7
1.9
51.23
7.04
4.93
0.99
16.66
8.78
5.87
1.88
50.41
5
15
2.59
2.59
0.44
3.45
3.13
3.13
0.54
4.18
4.31
4.31
0.74
7.28
5.07
5.07
0.87
12.46
5.78
5.78
0.99
16.73
17
5.48
3.89
0.99
15.1
4.89
4.04
0.99
11.23
4.51
4.22
0.99
8.79
5.07
5.04
0.87
12.48
5.78
5.78
0.99
16.76
19
6.68
2.98
1.15
21.59
6.64
3.58
1.14
21.37
6.6
4.17
1.13
21.16
7.3
5.45
0.99
24.91
7.19
5.99
0.99
24.41
20
-
-
-
-
7.81
3.65
1.34
28.14
7.77
4.25
1.33
27.89
7.04
4.93
0.99
16.66
7.69
5.41
1.32
27.39
6
15
2.39
2.39
0.34
2.61
2.83
2.83
0.41
3.1
3.27
3.27
0.47
3.58
4.1
4.1
0.59
4.51
5.18
5.18
0.74
7.48
17
4.42
3.65
0.99
5.91
2.84
2.8
0.41
3.1
3.28
3.28
0.47
3.59
4.11
4.11
0.59
4.52
5.18
5.18
0.74
7.5
19
6.23
3.23
0.99
13.77
6.66
4.29
0.99
15.44
6.26
4.77
0.99
12.98
5.94
5.09
0.85
11.84
5.29
4.97
0.76
8.06
20
-
-
-
-
6.42
3.11
0.92
14.31
6.78
4
0.97
15.99
7.04
4.93
0.99
16.66
7.19
5.7
0.99
17.86
7
3
15
3.47
3.24
0.99
16.73
4.08
4.08
1.17
22.16
4.75
4.75
1.36
28.64
5.41
5.41
1.55
35.68
6.06
6.06
1.74
43.27
17
5.32
3.2
1.52
34.7
5.9
4.35
0.99
42.33
5.56
4.78
0.99
33.4
5.47
5.23
1.57
36.39
6.07
6.07
1.74
43.34
19
7.4
3.28
2.12
60.91
7.37
3.87
2.11
60.38
7.33
4.47
2.1
59.85
7.29
5.05
2.09
59.33
7.25
5.63
2.08
58.82
20
-
-
-
-
8.45
3.91
2.42
76.42
8.41
4.51
2.41
75.79
8.37
5.1
2.4
75.16
8.33
5.68
2.39
74.54
4
15
2.44
2.44
0.52
3.9
3.54
3.54
0.76
8.62
4.27
4.27
0.92
14.4
4.96
4.96
1.07
18.85
5.63
5.63
1.21
23.36
17
5.24
3.82
1.13
20.67
4.26
3.52
0.99
14.43
4.34
4.11
0.93
14.86
4.97
4.97
1.07
18.88
5.64
5.64
1.21
23.4
19
6.32
2.84
1.36
28.39
6.29
3.44
1.35
28.11
6.25
4.03
1.34
27.83
6.66
5.03
0.99
30.94
6.42
5.58
0.99
26.96
20
-
-
-
-
7.41
3.49
1.59
37.15
7.37
4.09
1.58
36.81
7.33
4.67
1.57
36.48
7.29
5.25
1.57
36.15
5
15
2.14
2.14
0.37
2.7
2.58
2.58
0.44
3.25
3.55
3.55
0.61
4.56
4.42
4.42
0.76
8.76
5.15
5.15
0.88
13.33
17
2.22
2.08
0.38
2.79
2.58
2.58
0.44
3.25
3.56
3.56
0.61
4.58
4.43
4.43
0.76
8.79
5.15
5.15
0.89
13.36
19
5.88
3.09
1.01
17.15
6.04
3.85
0.99
18.12
5.94
4.49
1.02
17.43
5.63
4.95
0.99
16
5.25
4.96
0.9
13.9
20
-
-
-
-
6.18
3.02
1.06
18.64
6.48
3.92
0.99
20.08
7.01
4.99
0.99
23.37
6.61
5.26
0.99
20.79
6
15
1.95
1.95
0.28
2.01
2.39
2.39
0.34
2.47
2.83
2.83
0.41
2.92
3.31
3.31
0.47
3.43
4.51
4.51
0.65
5.17
17
1.98
1.94
0.28
2.04
2.39
2.39
0.34
2.47
2.83
2.83
0.41
2.92
3.32
3.32
0.47
3.43
4.51
4.51
0.65
5.19
19
2.76
1.84
0.99
2.85
2.68
2.36
0.99
2.75
2.86
2.8
0.41
2.95
3.32
3.32
0.48
3.43
4.52
4.52
0.65
5.21
20
-
-
-
-
3.74
2.56
0.99
3.87
5.66
4.08
0.99
11.09
6.08
5.06
0.99
12.95
4.67
4.38
0.67
5.76
9
3
15
2.71
2.71
0.78
9.73
3.43
3.43
0.98
16.14
4.11
4.11
1.18
21.94
4.77
4.77
1.37
28.27
5.42
5.42
1.55
35.15
17
3.68
2.55
1.05
18.23
3.69
3.2
1.06
18.31
4.12
4.04
1.18
22.08
4.78
4.78
1.37
28.31
5.43
5.43
1.55
35.21
19
5.08
2.86
0.99
16.29
5.8
3.25
1.66
39.43
5.77
3.84
1.65
39.03
5.88
4.61
0.99
39.24
6.06
5.39
0.99
43.48
20
-
-
-
-
5.6
3.28
0.99
16.29
5.47
3.8
0.99
16.21
6.83
4.47
1.95
52
5.2
4.62
0.99
16.3
4
15
1.89
1.89
0.41
2.85
2.79
2.79
0.6
4.34
3.61
3.61
0.77
9.8
4.32
4.32
0.93
14.57
5
5
1.07
18.73
17
2.16
2.08
0.99
3.64
2.79
2.79
0.6
4.35
3.61
3.61
0.78
9.83
4.32
4.32
0.93
14.6
5
5
1.07
18.76
19
5.08
2.86
0.99
16.27
5.54
3.59
1.19
22.25
5.22
4.03
0.99
20.13
4.6
4.06
0.99
16.27
5.04
4.89
1.08
19.01
20
-
-
-
-
5.76
2.86
1.24
23.77
5.47
3.8
0.99
16.22
6.12
4.49
0.99
25.85
5.2
4.62
0.99
16.3
5
15
1.7
1.7
0.29
2.02
2.15
2.15
0.37
2.55
2.6
2.6
0.45
3.09
3.74
3.74
0.64
5.28
4.5
4.5
0.77
9.87
17
1.7
1.7
0.29
2.02
2.15
2.15
0.37
2.55
2.6
2.6
0.45
3.09
3.74
3.74
0.64
5.3
4.51
4.51
0.77
9.89
19
3.72
2.18
0.99
6.44
3.78
2.99
0.99
6.28
2.6
2.6
0.45
3.09
3.75
3.73
0.99
5.33
4.51
4.51
0.78
9.92
20
-
-
-
-
5.8
3.65
0.99
16.5
5.28
3.97
0.99
13.95
4.47
3.81
0.99
9.6
4.62
4.34
0.79
10.57
6
15
1.52
1.52
0.22
1.47
1.95
1.95
0.28
1.9
2.39
2.39
0.34
2.33
2.83
2.83
0.4
2.76
3.52
3.52
0.5
3.45
17
1.52
1.52
0.22
1.48
1.95
1.95
0.28
1.9
2.39
2.39
0.34
2.34
2.83
2.83
0.4
2.76
3.53
3.53
0.51
3.45
19
1.98
1.64
0.99
1.91
2.01
1.94
0.29
1.95
2.4
2.4
0.34
2.34
2.83
2.83
0.41
2.76
3.54
3.54
0.51
3.46
20
-
-
-
-
2.34
1.91
0.99
2.27
2.44
2.34
0.99
2.37
2.83
2.83
0.41
2.76
3.54
3.54
0.51
3.47

Midea DC Fan Coil Unit
12
(Continued)
MKA-V850F
EWT
ΔT
Indoor temp (W.B.)
Indoor temperature (D.B.)
21
23
25
27
29
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
°C
°C
°C
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
11
3
15
1.91
1.91
0.55
3.69
2.75
2.75
0.79
10.59
3.46
3.46
0.99
16.14
4.13
4.13
1.18
21.8
4.79
4.79
1.37
28.02
17
1.91
1.9
0.55
3.7
2.76
2.76
0.79
10.61
3.46
3.46
0.99
16.17
4.13
4.13
1.18
21.84
4.79
4.79
1.37
28.06
19
4.14
2.52
0.99
16.07
5.11
3.5
0.99
32.8
4.05
3.19
1.16
21.12
4.25
3.96
1.22
22.88
4.8
4.8
1.37
28.11
20
-
-
-
-
4.66
2.93
0.99
15.95
5.55
3.67
0.99
32.38
5.4
4.2
0.99
31.58
5.33
4.79
0.99
31.23
4
15
1.45
1.45
0.31
2.07
1.89
1.89
0.41
2.69
2.91
2.91
0.62
5.09
3.66
3.66
0.79
10.56
4.36
4.36
0.94
14.64
17
1.45
1.45
0.31
2.07
1.89
1.89
0.41
2.69
2.91
2.91
0.63
5.11
3.67
3.67
0.79
10.59
4.36
4.36
0.94
14.66
19
1.99
1.78
0.99
2.82
1.92
1.9
0.41
2.74
2.94
2.84
0.99
5.28
3.67
3.67
0.79
10.61
4.37
4.37
0.94
14.69
20
-
-
-
-
5.1
3.4
0.99
18.67
4.52
3.51
0.99
15.54
4.01
3.63
0.99
12.15
4.41
4.27
0.95
14.93
5
15
1.27
1.27
0.22
1.42
1.7
1.7
0.29
1.91
2.14
2.14
0.37
2.41
2.72
2.72
0.47
3.06
3.84
3.84
0.66
6.33
17
1.27
1.27
0.22
1.42
1.7
1.7
0.29
1.91
2.14
2.14
0.37
2.41
2.72
2.72
0.47
3.06
3.84
3.84
0.66
6.35
19
4.3
2.9
0.99
16.3
1.71
1.69
0.29
1.92
2.14
2.14
0.37
2.41
2.72
2.72
0.47
3.07
3.84
3.84
0.66
6.37
20
-
-
-
-
2.98
2.19
0.99
3.83
2.15
2.13
0.37
2.41
2.73
2.73
0.47
3.07
3.85
3.85
0.66
6.38
6
15
1.09
1.09
0.16
1
1.52
1.52
0.22
1.4
1.95
1.95
0.28
1.8
2.39
2.39
0.34
2.21
2.83
2.83
0.41
2.62
17
1.09
1.09
0.16
1
1.52
1.52
0.22
1.4
1.95
1.95
0.28
1.8
2.39
2.39
0.34
2.21
2.84
2.84
0.41
2.62
19
1.17
1.04
0.17
1.07
1.52
1.52
0.22
1.4
1.95
1.95
0.28
1.81
2.4
2.4
0.34
2.21
2.84
2.84
0.41
2.63
20
-
-
-
-
1.62
1.53
0.23
1.49
1.96
1.96
0.28
1.81
2.4
2.4
0.34
2.22
2.84
2.84
0.41
2.63
13
3
15
1.2
1.2
0.35
2.2
2.03
2.03
0.58
4.22
2.79
2.79
0.8
10.95
3.48
3.48
1
16.09
4.15
4.15
1.19
21.64
17
1.2
1.2
0.35
2.2
2.03
2.03
0.58
4.23
2.79
2.79
0.8
10.97
3.48
3.48
1
16.11
4.15
4.15
1.19
21.67
19
1.81
1.33
0.99
3.32
2.13
1.95
0.61
5.01
2.8
2.76
0.8
11
3.49
3.49
1
16.14
4.15
4.15
1.19
21.71
20
-
-
-
-
3.32
1.99
0.95
14.87
3.29
2.58
0.94
14.61
3.58
3.36
1.03
16.88
4.16
4.16
1.19
21.73
4
15
1.01
1.01
0.22
1.37
1.45
1.45
0.31
1.96
1.91
1.91
0.41
2.58
2.98
2.98
0.64
6.09
3.71
3.71
0.8
10.87
17
1.01
1.01
0.22
1.37
1.45
1.45
0.31
1.97
1.91
1.91
0.41
2.58
2.98
2.98
0.64
6.11
3.71
3.71
0.8
10.89
19
1.06
0.97
0.99
1.43
1.46
1.46
0.31
1.97
1.91
1.91
0.41
2.58
2.99
2.99
0.64
6.13
3.72
3.72
0.8
10.91
20
-
-
-
-
1.52
1.49
0.99
2.05
1.91
1.91
0.41
2.58
2.99
2.99
0.64
6.14
3.72
3.72
0.8
10.92
5
15
0.84
0.84
0.14
0.89
1.27
1.27
0.22
1.35
1.7
1.7
0.29
1.82
2.14
2.14
0.37
2.28
3.09
3.09
0.53
3.43
17
0.84
0.84
0.14
0.89
1.27
1.27
0.22
1.35
1.7
1.7
0.29
1.82
2.14
2.14
0.37
2.28
3.09
3.09
0.53
3.44
19
0.85
0.83
0.99
0.9
1.27
1.27
0.22
1.35
1.71
1.71
0.29
1.82
2.14
2.14
0.37
2.28
3.1
3.1
0.53
3.45
20
-
-
-
-
1.29
1.27
0.22
1.37
1.71
1.71
0.29
1.82
2.14
2.14
0.37
2.28
3.1
3.1
0.53
3.46
6
15
0.68
0.68
0.1
0.6
1.09
1.09
0.16
0.95
1.52
1.52
0.22
1.33
1.95
1.95
0.28
1.71
2.39
2.39
0.34
2.1
17
0.68
0.68
0.1
0.6
1.09
1.09
0.16
0.95
1.52
1.52
0.22
1.33
1.95
1.95
0.28
1.71
2.39
2.39
0.34
2.1
19
0.68
0.66
0.99
0.6
1.09
1.09
0.16
0.95
1.52
1.52
0.22
1.33
1.96
1.96
0.28
1.71
2.39
2.39
0.34
2.1
20
-
-
-
-
1.09
1.08
0.16
0.95
1.52
1.52
0.22
1.33
1.96
1.96
0.28
1.71
2.39
2.39
0.34
2.1
15
3
15
0.76
0.76
0.22
1.32
1.2
1.2
0.34
2.08
2.08
2.08
0.6
5.04
2.82
2.82
0.81
11.05
3.5
3.5
1
15.98
17
0.76
0.76
0.22
1.32
1.2
1.2
0.34
2.08
2.09
2.09
0.6
5.06
2.82
2.82
0.81
11.07
3.5
3.5
1.01
16.01
19
0.76
0.76
0.22
1.32
1.2
1.2
0.35
2.08
2.09
2.09
0.6
5.08
2.82
2.82
0.81
11.09
3.51
3.51
1.01
16.03
20
-
-
-
-
1.2
1.2
0.35
2.08
2.09
2.09
0.6
5.09
2.82
2.82
0.81
11.1
3.51
3.51
1.01
16.05
4
15
0.58
0.58
0.13
0.75
1.01
1.01
0.22
1.3
1.45
1.45
0.31
1.86
2
2
0.43
2.57
3.03
3.03
0.65
6.89
17
0.58
0.58
0.13
0.75
1.02
1.02
0.22
1.3
1.45
1.45
0.31
1.87
2.01
2.01
0.43
2.58
3.04
3.04
0.65
6.91
19
0.58
0.58
0.13
0.75
1.02
1.02
0.22
1.3
1.46
1.46
0.31
1.87
2.01
2.01
0.43
2.58
3.04
3.04
0.65
6.94
20
-
-
-
-
1.02
1.02
0.22
1.3
1.46
1.46
0.31
1.87
2.01
2.01
0.43
2.59
3.04
3.04
0.65
6.95
5
15
0.51
0.51
0.99
0.58
0.84
0.84
0.14
0.84
1.27
1.27
0.22
1.28
1.7
1.7
0.29
1.72
2.14
2.14
0.37
2.17
17
0.51
0.51
0.99
0.58
0.84
0.84
0.14
0.84
1.27
1.27
0.22
1.28
1.71
1.71
0.29
1.73
2.14
2.14
0.37
2.17
19
0.51
0.51
0.99
0.58
0.84
0.84
0.14
0.84
1.27
1.27
0.22
1.28
1.71
1.71
0.29
1.73
2.14
2.14
0.37
2.17
20
-
-
-
-
0.84
0.84
0.14
0.84
1.27
1.27
0.22
1.28
1.71
1.71
0.29
1.73
2.14
2.14
0.37
2.17
6
15
-
-
-
-
0.68
0.68
0.1
0.57
1.09
1.09
0.16
0.9
1.52
1.52
0.22
1.26
1.95
1.95
0.28
1.63
17
-
-
-
-
0.68
0.68
0.1
0.57
1.09
1.09
0.16
0.9
1.52
1.52
0.22
1.26
1.96
1.96
0.28
1.63
19
-
-
-
-
0.68
0.68
0.1
0.57
1.09
1.09
0.16
0.9
1.52
1.52
0.22
1.26
1.96
1.96
0.28
1.63
20
-
-
-
-
0.68
0.68
0.1
0.57
1.09
1.09
0.16
0.9
1.52
1.52
0.22
1.26
1.96
1.96
0.28
1.63
Abbreviations:
EWT: Enter Water Temp. (℃)
Δt: Temperature Difference (℃)
DB: Dry Bulb Temp. (℃)
WF: Water Flow (m3/h)
WB: Wet Bulb Temp. (℃)
TC: Total Cooling Capacity (kW)
SC: Sensible Cooling Capacity (kW)
WPD: Water Pressure Drop (kPa)

Midea DC Fan Coil Unit
13
MKA-V950F
EWT
ΔT
Indoor
temp
(W.B.)
Indoor temperature (D.B.)
21
23
25
27
29
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
°C
°C
°C
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
5
3
15
6.16
4.79
1.04
40.57
6
5.54
1.04
37.51
5.88
5.86
1.68
37.39
6.58
6.58
1.88
45.3
7.27
7.27
2.07
53.75
17
6.05
4.02
1.04
16.37
7.42
4.82
2.12
55.64
7.38
5.45
2.11
55.17
7.32
6.06
1.04
53.4
7.42
6.93
2.12
55.67
19
9.67
4.25
2.76
87.61
9.63
4.89
2.74
86.91
9.58
5.53
2.73
86.22
7.01
5.44
1.04
16.41
9.49
6.78
2.71
84.86
20
-
-
-
-
10.79
4.93
3.08
105.75
10.74
5.57
3.06
104.93
10.69
6.21
3.05
104.13
10.64
6.83
3.03
103.33
4
15
4.23
3.82
1.04
11.74
4.68
4.57
1
15.47
5.41
5.41
1.16
19.98
6.13
6.13
1.32
24.69
6.84
6.84
1.47
29.69
17
6.05
4.02
1.04
16.37
6.66
4.66
1.04
28.23
6.99
5.6
1.04
31.08
6.77
6.18
1.04
28.91
6.86
6.76
1.47
29.81
19
8.67
3.82
1.86
44.37
8.62
4.46
1.85
44
8.58
5.1
1.84
43.62
7.01
5.44
1.04
16.41
8.5
6.35
1.82
42.89
20
-
-
-
-
9.8
4.51
2.1
54.76
9.76
5.15
2.09
54.32
9.71
5.78
2.08
53.88
9.66
6.41
2.07
53.44
5
15
2.84
2.84
0.49
3.41
3.99
3.99
0.68
5.17
4.86
4.86
0.83
9.87
5.63
5.63
0.97
14.33
6.37
6.37
1.09
17.93
17
6.07
4.06
1.04
16.45
6.02
4.8
1.03
16.21
5.08
4.58
0.87
11.32
5.65
5.51
0.97
14.45
6.37
6.37
1.09
17.96
19
7.53
3.35
1.29
23.8
7.48
3.99
1.28
23.57
7.44
4.63
1.28
23.34
7.67
5.51
1.04
24.48
7.91
6.44
1.04
25.78
20
-
-
-
-
8.71
4.06
1.49
30.49
8.67
4.7
1.49
30.22
8.62
5.33
1.48
29.95
8.58
5.95
1.47
29.69
6
15
2.63
2.63
0.38
2.58
3.1
3.1
0.44
3.05
3.71
3.71
0.53
3.66
4.99
4.99
0.71
5.95
5.82
5.82
0.83
9.96
17
4.67
3.91
1.04
5.21
4.42
4.07
1.04
5.13
3.71
3.71
0.53
3.66
5
5
0.71
5.97
5.82
5.82
0.83
9.99
19
6.32
2.87
1.04
13.16
6.88
4.21
1.04
13.86
6.93
4.83
1.04
15.02
6.34
5.31
1.04
11.43
6.1
5.58
1.04
10.9
20
-
-
-
-
7.42
3.54
1.06
16.98
7.38
4.18
1.05
16.79
7.66
5.07
1.1
17.93
8.01
6.11
1.04
19.31
7
3
15
3.87
3.54
1.11
18.23
4.47
4.47
1.28
23.3
5.19
5.19
1.49
29.95
5.9
5.9
1.69
37.18
6.59
6.59
1.89
44.99
17
5.89
3.51
1.69
37.16
6.15
4.4
1.04
39.64
6.26
5.16
1.04
42.03
6.11
5.78
1.04
39.53
6.6
6.6
1.89
45.06
19
8.12
3.59
2.33
64.31
8.08
4.23
2.31
63.75
8.04
4.87
2.3
63.19
8
5.5
2.29
62.65
6.09
5.65
1.04
16.2
20
-
-
-
-
9.25
4.27
2.65
80.38
9.2
4.92
2.64
79.71
9.16
5.55
2.62
79.04
9.12
6.17
2.61
78.38
4
15
3.12
3.12
0.67
5
3.96
3.96
0.85
10.93
4.72
4.72
1.01
15.57
5.45
5.45
1.17
19.9
6.16
6.16
1.32
24.5
17
5.67
3.98
1.22
21.29
4.98
4.03
1.04
16.67
4.86
4.5
1.04
16.35
5.46
5.42
1.04
19.94
6.17
6.17
1.33
24.54
19
7.04
3.15
1.51
30.67
7
3.8
1.5
30.38
6.96
4.43
1.49
30.08
7.12
5.25
1.04
30.89
6.09
5.65
1.04
16.2
20
-
-
-
-
8.2
3.85
1.76
39.73
8.15
4.49
1.75
39.37
8.11
5.12
1.74
39.02
8.07
5.74
1.73
38.67
5
15
2.35
2.35
0.4
2.66
2.9
2.9
0.5
3.29
4.13
4.13
0.71
6.2
4.94
4.94
0.85
10.91
5.69
5.69
0.98
14.56
17
3.51
3.07
1.04
4.17
3.69
3.49
1.04
4.98
4.14
4.14
0.71
6.22
4.94
4.94
0.85
10.94
5.7
5.7
0.98
14.59
19
6.12
3.02
1.04
16.08
6.53
3.96
1.04
18.61
6.24
4.57
1.04
16.15
5.82
5.18
1.03
16.4
6.09
5.65
1.04
16.2
20
-
-
-
-
7
3.38
1.2
20.72
6.96
4.02
1.2
20.51
7.31
5.08
1.04
21.3
7.49
5.85
1.29
23.24
6
15
2.14
2.14
0.31
1.99
2.63
2.63
0.38
2.44
3.1
3.1
0.44
2.89
4.15
4.15
0.59
3.94
5.12
5.12
0.73
7.13
17
2.18
2.08
1.04
2.03
2.63
2.63
0.38
2.44
3.1
3.1
0.44
2.89
4.16
4.16
0.6
3.95
5.13
5.13
0.73
7.16
19
4.49
2.81
1.04
4.59
4.12
3.26
1.04
3.89
6.25
4.61
1.04
16.19
4.29
4.22
1.04
4.2
5.13
5.1
0.74
7.18
20
-
-
-
-
6.01
3.78
1.04
9.44
6.3
4.23
1.04
12.34
3.79
3.61
1.04
3.4
5.92
5.29
1.04
10.95
9
3
15
3.02
3.02
0.86
11.49
3.77
3.77
1.08
17.1
4.5
4.5
1.29
23.01
5.21
5.21
1.49
29.51
5.91
5.91
1.69
36.59
17
3.92
2.72
1.04
16.46
4.14
3.49
1.18
20.03
4.53
4.39
1.3
23.31
5.21
5.21
1.49
29.56
5.91
5.91
1.69
36.65
19
6.45
2.92
1.84
42.48
6.41
3.56
1.83
42.05
6.37
4.2
1.82
41.63
6.34
4.83
1.04
41.41
6.38
5.53
1.04
43.3
20
-
-
-
-
7.58
3.6
2.17
56.11
7.54
4.24
2.16
55.58
7.5
4.88
2.15
55.07
7.46
5.5
2.13
54.55
4
15
2.08
2.08
0.45
2.82
3.21
3.21
0.69
5.97
4.01
4.01
0.86
11.42
4.76
4.76
1.02
15.51
5.48
5.48
1.18
19.7
17
2.45
2.29
1.04
3.47
3.22
3.15
1.04
6.07
4.02
4.02
0.86
11.44
4.76
4.76
1.02
15.54
5.49
5.49
1.18
19.73
19
5.63
2.83
1.04
20.11
6.26
4.04
1.04
24.34
5.83
4.26
1.04
22.83
5.01
4.4
1.04
15.83
5.57
5.31
1.19
20.21
20
-
-
-
-
6.44
3.17
1.38
25.88
6.4
3.81
1.37
25.61
6.91
4.9
1.48
29.2
6.7
5.46
1.44
27.69
5
15
1.87
1.87
0.32
2
2.35
2.35
0.4
2.51
3.23
3.23
0.56
3.48
4.22
4.22
0.73
7.31
5
5
0.86
11.36
17
1.87
1.86
0.32
2
2.35
2.35
0.4
2.51
3.24
3.24
0.56
3.49
4.23
4.23
0.73
7.33
5.01
5.01
0.86
11.38
19
5.11
3.28
1.04
12.01
3.94
2.97
1.04
5.89
5.41
4.48
1.04
15.91
4.66
4.28
1.04
11.99
5.01
5.01
0.86
11.4
20
-
-
-
-
6.25
3.67
1.04
16.84
5.88
4.09
1.04
15.16
5.85
4.86
1
14.97
5.23
4.76
0.9
12.37
6
15
1.67
1.67
0.24
1.46
2.15
2.15
0.31
1.88
2.62
2.62
0.38
2.3
3.14
3.14
0.45
2.76
4.39
4.39
0.63
4.56
17
1.67
1.67
0.24
1.46
2.15
2.15
0.31
1.88
2.62
2.62
0.38
2.31
3.14
3.14
0.45
2.77
4.4
4.4
0.63
4.57
19
2.19
1.71
1.04
1.91
2.22
2.11
0.32
1.95
2.63
2.63
0.38
2.31
3.15
3.15
0.45
2.77
4.4
4.4
0.63
4.59
20
-
-
-
-
3.4
2.47
1.04
3.25
4.44
4.1
1.04
4.77
3.15
3.15
0.45
2.77
4.4
4.38
0.63
4.59

Midea DC Fan Coil Unit
14
(Continued)
MKA-V950F
EWT
ΔT
Indoor
temp
(W.B.)
Indoor temperature (D.B.)
21
23
25
27
29
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
°C
°C
°C
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
11
3
15
2.25
2.25
0.64
5
3.05
3.05
0.87
11.73
3.79
3.79
1.09
17.02
4.51
4.51
1.29
22.83
5.22
5.22
1.5
29.21
17
2.32
2.16
0.66
5.57
3.06
3.06
0.88
11.75
3.8
3.8
1.09
17.05
4.52
4.52
1.29
22.87
5.22
5.22
1.5
29.26
19
5.03
2.61
1.04
27.14
5.22
3.49
1.49
29.2
5.02
3.96
1.04
27.54
4.69
4.3
1.34
24.36
5.23
5.2
1.5
29.32
20
-
-
-
-
5.78
2.92
1.66
34.8
5.75
3.56
1.65
34.41
5.91
4.38
1.04
35.56
5.72
5.02
1.04
32.01
4
15
1.6
1.6
0.34
2.05
2.14
2.14
0.46
2.75
3.28
3.28
0.71
7.04
4.06
4.06
0.87
11.63
4.79
4.79
1.03
15.48
17
1.6
1.6
0.34
2.05
2.15
2.15
0.46
2.76
3.29
3.29
0.71
7.06
4.06
4.06
0.87
11.65
4.8
4.8
1.03
15.5
19
2.86
1.6
0.61
4.32
2.9
2.36
1.04
4.46
3.5
3.29
1.04
8.49
4.07
4.02
0.87
11.69
4.8
4.8
1.03
15.53
20
-
-
-
-
5.58
3.38
1.04
20.21
5.22
3.89
1.12
17.88
4.54
3.89
1.04
14.1
4.89
4.64
1.05
16
5
15
1.39
1.39
0.24
1.41
1.87
1.87
0.32
1.89
2.34
2.34
0.4
2.37
3.46
3.46
0.6
4
4.3
4.3
0.74
8.17
17
1.39
1.39
0.24
1.41
1.87
1.87
0.32
1.89
2.35
2.35
0.4
2.38
3.47
3.47
0.6
4.01
4.3
4.3
0.74
8.19
19
1.66
1.48
1.04
1.67
1.88
1.88
0.32
1.91
2.35
2.35
0.4
2.38
3.47
3.47
0.6
4.03
4.31
4.31
0.74
8.22
20
-
-
-
-
2.13
1.95
1.04
2.15
2.35
2.32
0.4
2.38
3.5
3.46
0.6
4.14
4.31
4.31
0.74
8.23
6
15
1.2
1.2
0.17
0.99
1.67
1.67
0.24
1.39
2.15
2.15
0.31
1.79
2.62
2.62
0.38
2.18
3.34
3.34
0.48
2.79
17
1.2
1.2
0.17
0.99
1.67
1.67
0.24
1.39
2.15
2.15
0.31
1.79
2.62
2.62
0.38
2.18
3.35
3.35
0.48
2.79
19
1.31
1.18
1.04
1.08
1.67
1.67
0.24
1.39
2.15
2.15
0.31
1.79
2.62
2.62
0.38
2.18
3.36
3.36
0.48
2.8
20
-
-
-
-
1.8
1.69
0.26
1.49
2.15
2.15
0.31
1.79
2.62
2.62
0.38
2.18
3.36
3.36
0.48
2.8
13
3
15
1.31
1.31
0.38
2.16
2.3
2.3
0.66
5.97
3.08
3.08
0.88
11.79
3.81
3.81
1.09
16.92
4.53
4.53
1.3
22.62
17
1.31
1.31
0.38
2.16
2.3
2.3
0.66
5.99
3.08
3.08
0.89
11.81
3.82
3.82
1.1
16.95
4.53
4.53
1.3
22.65
19
2.39
1.44
0.69
6.8
2.51
2.17
0.72
7.83
3.1
3.02
0.89
11.92
3.82
3.82
1.1
16.97
4.54
4.54
1.3
22.69
20
-
-
-
-
4.44
2.98
1.04
20.2
3.75
2.85
1.07
16.4
3.97
3.65
1.14
18.08
4.54
4.51
1.3
22.72
4
15
1.12
1.12
0.24
1.36
1.6
1.6
0.34
1.94
2.45
2.45
0.53
3.03
3.34
3.34
0.72
7.78
4.09
4.09
0.88
11.67
17
1.12
1.12
0.24
1.36
1.6
1.6
0.34
1.94
2.45
2.45
0.53
3.04
3.34
3.34
0.72
7.8
4.1
4.1
0.88
11.69
19
1.19
1.12
0.26
1.44
1.6
1.6
0.34
1.94
2.46
2.46
0.53
3.05
3.34
3.34
0.72
7.82
4.1
4.1
0.88
11.72
20
-
-
-
-
1.66
1.59
0.36
2.02
2.48
2.43
0.53
3.1
3.34
3.33
0.72
7.83
4.11
4.11
0.88
11.73
5
15
0.92
0.92
0.16
0.88
1.39
1.39
0.24
1.34
1.87
1.87
0.32
1.8
2.37
2.37
0.41
2.28
3.56
3.56
0.61
4.76
17
0.92
0.92
0.16
0.88
1.39
1.39
0.24
1.34
1.87
1.87
0.32
1.8
2.37
2.37
0.41
2.28
3.56
3.56
0.61
4.78
19
0.94
0.91
0.16
0.9
1.4
1.4
0.24
1.34
1.87
1.87
0.32
1.8
2.38
2.38
0.41
2.28
3.57
3.57
0.61
4.8
20
-
-
-
-
1.42
1.41
0.24
1.36
1.88
1.88
0.32
1.8
2.38
2.38
0.41
2.28
3.57
3.57
0.61
4.81
6
15
0.73
0.73
0.1
0.57
1.2
1.2
0.17
0.94
1.67
1.67
0.24
1.32
2.15
2.15
0.31
1.69
2.62
2.62
0.38
2.07
17
0.73
0.73
0.1
0.57
1.2
1.2
0.17
0.94
1.67
1.67
0.24
1.32
2.15
2.15
0.31
1.7
2.62
2.62
0.38
2.07
19
0.73
0.71
0.1
0.57
1.2
1.2
0.17
0.94
1.67
1.67
0.24
1.32
2.15
2.15
0.31
1.7
2.62
2.62
0.38
2.07
20
-
-
-
-
1.2
1.18
0.17
0.95
1.67
1.67
0.24
1.32
2.15
2.15
0.31
1.7
2.62
2.62
0.38
2.07
15
3
15
0.84
0.84
0.24
1.31
1.31
1.31
0.38
2.05
2.34
2.34
0.67
6.71
3.1
3.1
0.89
11.76
3.83
3.83
1.1
16.77
17
0.84
0.84
0.24
1.31
1.31
1.31
0.38
2.05
2.34
2.34
0.67
6.73
3.11
3.11
0.89
11.78
3.83
3.83
1.1
16.8
19
0.84
0.83
0.24
1.31
1.32
1.32
0.38
2.05
2.35
2.35
0.67
6.75
3.11
3.11
0.89
11.8
3.84
3.84
1.1
16.83
20
-
-
-
-
1.84
1.77
1.04
3.38
2.35
2.34
0.67
6.75
3.11
3.11
0.89
11.81
3.84
3.84
1.1
16.84
4
15
0.64
0.64
0.14
0.74
1.12
1.12
0.24
1.29
1.59
1.59
0.34
1.84
2.56
2.56
0.55
3.45
3.38
3.38
0.73
8.13
17
0.64
0.64
0.14
0.74
1.12
1.12
0.24
1.29
1.59
1.59
0.34
1.84
2.56
2.56
0.55
3.46
3.38
3.38
0.73
8.14
19
0.64
0.64
0.14
0.74
1.12
1.12
0.24
1.29
1.59
1.59
0.34
1.84
2.56
2.56
0.55
3.47
3.39
3.39
0.73
8.16
20
-
-
-
-
1.12
1.12
0.24
1.29
1.59
1.59
0.34
1.84
2.57
2.57
0.55
3.48
3.39
3.39
0.73
8.17
5
15
0.55
0.55
1.04
0.55
0.92
0.92
0.16
0.84
1.39
1.39
0.24
1.27
1.87
1.87
0.32
1.7
2.5
2.5
0.43
2.28
17
0.55
0.55
1.04
0.55
0.92
0.92
0.16
0.84
1.39
1.39
0.24
1.27
1.87
1.87
0.32
1.71
2.51
2.51
0.43
2.29
19
0.55
0.55
1.04
0.55
0.92
0.92
0.16
0.84
1.4
1.4
0.24
1.27
1.87
1.87
0.32
1.71
2.51
2.51
0.43
2.29
20
-
-
-
-
0.92
0.92
0.16
0.84
1.4
1.4
0.24
1.27
1.87
1.87
0.32
1.71
2.51
2.51
0.43
2.3
6
15
-
-
-
-
0.73
0.73
0.1
0.54
1.2
1.2
0.17
0.9
1.67
1.67
0.24
1.25
2.15
2.15
0.31
1.61
17
-
-
-
-
0.73
0.73
0.1
0.54
1.2
1.2
0.17
0.9
1.67
1.67
0.24
1.25
2.15
2.15
0.31
1.61
19
-
-
-
-
0.73
0.73
0.1
0.54
1.2
1.2
0.17
0.9
1.67
1.67
0.24
1.25
2.15
2.15
0.31
1.61
20
-
-
-
-
0.73
0.73
0.1
0.54
1.2
1.2
0.17
0.9
1.67
1.67
0.24
1.25
2.15
2.15
0.31
1.61
Abbreviations:
EWT: Enter Water Temp. (℃)
Δt: Temperature Difference (℃)
DB: Dry Bulb Temp. (℃)
WF: Water Flow (m3/h)
WB: Wet Bulb Temp. (℃)
TC: Total Cooling Capacity (kW)
SC: Sensible Cooling Capacity (kW)
WPD: Water Pressure Drop (kPa)

Midea DC Fan Coil Unit
15
MKA-V1200F
EWT
ΔT
Indoor
temp
(W.B.)
Indoor temperature (D.B.)
21
23
25
27
29
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
°C
°C
°C
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
5
3
15
7.92
5.9
2.26
69.19
7.89
6.84
2.25
68.86
8.47
8.31
2.41
77.6
9.44
9.44
2.69
93.32
10.39
10.39
2.96
109.98
17
10.83
6.01
3.09
117.89
10.76
6.9
3.07
116.63
10.69
7.77
3.05
115.39
10.62
8.63
3.03
114.17
10.66
9.72
3.04
114.91
19
13.93
6.11
3.97
181.54
13.85
7.01
3.95
179.7
13.76
7.89
3.92
177.89
13.68
8.75
3.9
176.1
10.18
8.22
1.57
36.91
20
-
-
-
-
15.47
7.06
4.41
217.6
15.39
7.94
4.39
215.45
15.3
8.82
4.36
213.34
15.21
9.68
4.34
211.24
4
15
7.06
5.75
1.57
37.14
6.98
6.64
1.57
35.01
7.9
7.9
1.69
42.42
8.9
8.9
1.91
51.83
9.87
9.87
2.12
61.77
17
9.49
5.43
2.03
57.75
9.42
6.32
2.02
57.08
9.36
7.19
2.01
56.42
9.36
8.17
2.01
56.46
9.91
9.57
2.13
62.22
19
12.66
5.56
2.72
94.3
12.59
6.46
2.7
93.3
12.51
7.34
2.68
92.32
12.43
8.21
2.67
91.35
10.18
8.22
1.57
36.91
20
-
-
-
-
14.24
6.52
3.05
115.13
14.15
7.41
3.03
113.95
14.07
8.28
3.02
112.79
13.98
9.14
3
111.65
5
15
4.41
4.41
0.76
7.85
6.1
6.1
1.05
12.07
7.23
7.23
1.24
21.48
8.28
8.28
1.42
30.63
9.29
9.29
1.59
38
17
8.12
5.05
1.57
28.61
8.46
6.14
1.57
32.83
8.11
7.01
1.57
28.03
8.67
8.28
1.49
33.49
9.32
9.29
1.6
38.15
19
11.24
4.97
1.93
52.51
11.17
5.86
1.92
51.91
11.09
6.74
1.9
51.31
11.02
7.61
1.89
50.73
10.18
8.22
1.57
36.91
20
-
-
-
-
12.87
5.95
2.21
66.02
12.79
6.83
2.19
65.3
12.71
7.71
2.18
64.6
12.63
8.57
2.17
63.9
6
15
4.04
4.04
0.58
5.89
4.77
4.77
0.68
6.96
5.95
5.95
0.85
8.7
7.54
7.54
1.08
13.51
8.63
8.63
1.23
21.43
17
6.09
5.04
1.57
8.92
4.87
4.73
0.7
7.09
8.27
7.06
1.57
30.52
7.54
7.52
1.08
13.52
8.65
8.65
1.24
21.52
19
9.5
4.27
1.36
27.77
9.42
5.16
1.35
27.23
9.34
6.04
1.34
26.69
9.72
7.3
1.57
29.04
9.99
8.45
1.57
31.67
20
-
-
-
-
11.3
5.31
1.62
38.7
11.45
6.48
1.57
38.72
11.14
7.07
1.59
37.74
11.06
7.93
1.58
37.27
7
3
15
5.76
5.06
1.65
39.9
6.5
6.44
1.86
49.06
7.5
7.5
2.15
62.44
8.47
8.47
2.43
76.83
9.43
9.43
2.7
92.25
17
8.65
5.08
2.48
79.49
8.58
5.96
2.46
78.54
8.52
6.84
2.44
77.6
8.67
8
2.48
79.92
9.45
9.45
2.71
92.47
19
11.77
5.18
3.37
134.64
11.69
6.08
3.35
133.18
11.62
6.96
3.33
131.74
11.55
7.83
3.31
130.31
11.47
8.68
3.29
128.91
20
-
-
-
-
13.33
6.13
3.82
166.71
13.25
7.02
3.79
164.97
13.17
7.89
3.77
163.25
13.09
8.75
3.75
161.55
4
15
4.76
4.69
1.02
11.69
5.88
5.88
1.26
23.67
6.92
6.92
1.49
33.27
7.93
7.93
1.7
41.98
8.91
8.91
1.91
51.14
17
7.51
4.76
1.61
38.29
7.06
5.34
1.57
34.43
7.35
6.56
1.58
36.92
7.95
7.76
1.57
42.25
8.92
8.92
1.92
51.26
19
10.4
4.63
2.23
66.45
10.33
5.52
2.22
65.67
10.26
6.4
2.2
64.91
10.19
7.27
2.19
64.16
10.12
8.13
2.17
63.42
20
-
-
-
-
12
5.59
2.58
84.73
11.92
6.48
2.56
83.79
11.85
7.35
2.54
82.87
11.77
8.21
2.53
81.96
5
15
3.62
3.62
0.62
6.06
4.66
4.66
0.8
7.83
6.22
6.22
1.07
13.99
7.31
7.31
1.26
23.45
8.34
8.34
1.43
31
17
3.87
3.5
0.67
6.48
5.47
5.17
1.57
9.44
6.25
6.08
1.07
14.19
7.32
7.32
1.26
23.53
8.35
8.35
1.43
31.08
19
9.21
4.36
1.58
36.89
8.73
4.89
1.5
33.64
8.66
5.77
1.57
33.21
8.75
7.51
1.57
33.9
9.14
8.1
1.57
36.39
20
-
-
-
-
10.51
5
1.81
46.14
10.72
6.19
1.57
47.05
10.36
6.76
1.78
45.03
10.29
7.62
1.77
44.48
6
15
3.31
3.31
0.47
4.55
4.04
4.04
0.58
5.56
4.8
4.8
0.69
6.62
6.46
6.46
0.92
9.31
7.66
7.66
1.1
15.65
17
3.43
3.17
0.49
4.7
4.04
4.04
0.58
5.56
4.81
4.81
0.69
6.63
6.47
6.47
0.93
9.34
7.67
7.67
1.1
15.73
19
5.95
3.13
1.57
8.31
7.27
4.99
1.57
12.04
7.66
6.06
1.57
15.61
6.91
6.25
1.57
11.05
7.89
7.61
1.57
17.39
20
-
-
-
-
8.64
4.29
1.24
22.71
8.98
5.47
1.29
24.92
9.07
6.52
1.57
25.49
8.63
7.34
1.57
20.81
9
3
15
4.47
4.47
1.28
24.9
5.51
5.51
1.58
36.38
6.52
6.52
1.86
48.27
7.5
7.5
2.15
61.24
8.47
8.47
2.42
75.27
17
6.43
4.31
1.57
45.05
6.2
5
1.77
44.31
6.6
6.25
1.89
49.36
7.51
7.51
2.15
61.38
8.48
8.48
2.43
75.45
19
9.43
4.24
2.7
90.46
9.37
5.13
2.68
89.37
9.3
6.02
2.66
88.29
7.56
6.29
1.57
35.92
9.18
7.76
2.63
86.32
20
-
-
-
-
11.01
5.19
3.15
117.9
10.94
6.08
3.13
116.55
10.87
6.95
3.11
115.23
8.43
6.97
1.57
35.84
4
15
3.26
3.26
0.7
6.54
4.84
4.84
1.04
13.52
5.93
5.93
1.27
24.58
6.95
6.95
1.49
32.96
7.95
7.95
1.71
41.33
17
3.46
3.27
1.57
6.9
4.89
4.59
1.57
13.83
5.94
5.92
1.27
24.69
6.96
6.96
1.49
33.03
7.96
7.96
1.71
41.43
19
7.91
3.65
1.7
41.02
7.85
4.55
1.68
40.46
7.95
5.63
1.57
40.12
7.56
6.29
1.57
35.92
8.05
7.62
1.57
38.31
20
-
-
-
-
9.57
4.64
2.05
56.58
9.83
5.81
1.57
59.14
9.43
6.4
2.02
55.19
8.43
6.97
1.57
35.84
5
15
2.89
2.89
0.5
4.57
3.61
3.61
0.62
5.72
5.11
5.11
0.88
8.33
6.31
6.31
1.08
15.99
7.36
7.36
1.27
24.28
17
2.9
2.83
0.5
4.58
3.61
3.61
0.62
5.72
5.12
5.12
0.88
8.36
6.32
6.32
1.09
16.07
7.37
7.37
1.27
24.35
19
6.49
3.68
1.57
15.41
6.81
4.72
1.17
20.25
6.29
5.3
1.57
15.48
6.47
5.98
1.11
17.43
7.39
7.25
1.27
24.44
20
-
-
-
-
7.84
3.99
1.35
27.42
8.41
5.42
1.57
30.74
7.76
5.77
1.57
27.18
8.19
7.14
1.57
29.62
6
15
2.59
2.59
0.37
3.36
3.31
3.31
0.47
4.3
4.03
4.03
0.58
5.24
4.96
4.96
0.71
6.47
6.65
6.65
0.95
10.41
17
2.59
2.58
0.37
3.36
3.31
3.31
0.47
4.31
4.03
4.03
0.58
5.25
4.97
4.97
0.71
6.48
6.66
6.66
0.95
10.46
19
6.46
3.92
1.57
13.94
3.5
3.19
0.5
4.54
4.03
4
0.58
5.25
4.98
4.98
0.71
6.49
6.67
6.67
0.95
10.52
20
-
-
-
-
6.03
3.93
1.57
8.32
5.78
4.94
1.57
7.59
6.01
5.68
1.57
8.07
6.7
6.41
0.96
10.7

Midea DC Fan Coil Unit
16
(Continued)
MKA-V1200F
EWT
ΔT
Indoor
temp
(W.B.)
Indoor temperature (D.B.)
21
23
25
27
29
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
°C
°C
°C
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
11
3
15
3.41
3.41
0.98
11.55
4.5
4.5
1.29
25.27
5.53
5.53
1.58
36
6.52
6.52
1.87
47.62
7.5
7.5
2.15
60.33
17
3.61
3.17
1.03
14.25
4.5
4.43
1.29
25.28
5.54
5.54
1.59
36.09
6.53
6.53
1.87
47.73
7.51
7.51
2.15
60.47
19
6.89
3.27
1.97
52.18
6.46
4.21
1.57
37.66
6.27
4.87
1.57
37.69
6.87
6.1
1.97
52.01
7.53
7.38
2.16
60.79
20
-
-
-
-
8.51
4.24
2.44
74.78
7.28
4.7
1.57
39.61
8.38
6
2.4
72.84
8.32
6.87
2.38
72.01
4
15
2.46
2.46
0.53
4.67
3.52
3.52
0.76
6.7
4.91
4.91
1.05
15.47
5.96
5.96
1.28
24.9
6.98
6.98
1.5
32.68
17
2.46
2.46
0.53
4.68
3.53
3.53
0.76
6.72
4.91
4.91
1.06
15.54
5.97
5.97
1.28
24.97
6.99
6.99
1.5
32.75
19
6.24
3.65
1.34
26.97
4.88
3.46
1.57
15.24
5.21
4.57
1.12
18.55
6.01
5.79
1.29
25.23
7
7
1.5
32.83
20
-
-
-
-
7.26
4
1.57
34.55
7.21
4.83
1.57
35.33
6.77
5.44
1.57
31.08
7.21
6.63
1.55
34.52
5
15
2.16
2.16
0.37
3.23
2.89
2.89
0.5
4.32
3.64
3.64
0.63
5.46
5.26
5.26
0.91
9.26
6.37
6.37
1.1
17.6
17
2.16
2.16
0.37
3.24
2.89
2.89
0.5
4.33
3.64
3.64
0.63
5.46
5.27
5.27
0.91
9.3
6.38
6.38
1.1
17.67
19
2.68
2.17
1.57
4.01
2.93
2.82
0.5
4.39
3.64
3.64
0.63
5.47
5.28
5.28
0.91
9.35
6.39
6.39
1.1
17.74
20
-
-
-
-
4.29
2.86
1.57
6.77
4.2
3.97
1.57
6.42
5.37
5.22
1.57
8.84
6.39
6.25
1.1
17.73
6
15
1.87
1.87
0.27
2.29
2.59
2.59
0.37
3.18
3.31
3.31
0.47
4.08
4.03
4.03
0.58
4.97
5.44
5.44
0.78
6.78
17
1.87
1.87
0.27
2.3
2.59
2.59
0.37
3.18
3.31
3.31
0.47
4.08
4.03
4.03
0.58
4.97
5.45
5.45
0.78
6.8
19
2.13
1.88
0.3
2.6
2.59
2.53
0.37
3.19
3.31
3.31
0.48
4.08
4.03
4.03
0.58
4.97
5.47
5.47
0.78
6.82
20
-
-
-
-
2.85
2.55
0.41
3.49
3.32
3.26
0.48
4.09
4.04
4.04
0.58
4.98
5.48
5.48
0.79
6.83
13
3
15
2.03
2.03
0.58
4.94
3.46
3.46
0.99
13.31
4.53
4.53
1.3
25.25
5.54
5.54
1.59
35.58
6.52
6.52
1.87
46.95
17
2.03
2.03
0.58
4.95
3.46
3.46
0.99
13.38
4.53
4.53
1.3
25.31
5.54
5.54
1.59
35.66
6.53
6.53
1.87
47.06
19
4.88
3.13
1.4
28.71
3.93
3.16
1.13
19.31
4.6
4.36
1.32
25.94
5.55
5.55
1.59
35.75
6.54
6.54
1.88
47.17
20
-
-
-
-
6.51
3.89
1.87
46.8
5.6
4.1
1.57
35.35
5.86
5.2
1.68
39.12
6.56
6.42
1.88
47.42
4
15
1.73
1.73
0.37
3.12
2.46
2.46
0.53
4.43
3.81
3.81
0.82
7.2
4.95
4.95
1.07
16.85
5.99
5.99
1.29
24.86
17
1.73
1.73
0.37
3.12
2.46
2.46
0.53
4.43
3.81
3.81
0.82
7.23
4.96
4.96
1.07
16.91
6
6
1.29
24.92
19
1.92
1.76
0.41
3.44
2.46
2.46
0.53
4.43
3.82
3.82
0.82
7.26
4.97
4.97
1.07
16.98
6.01
6.01
1.29
24.98
20
-
-
-
-
3.25
2.76
1.57
6.02
4.02
3.67
1.57
8.39
4.99
4.86
1.07
17.13
6.01
6.01
1.29
25.02
5
15
1.44
1.44
0.25
2.04
2.16
2.16
0.37
3.07
2.88
2.88
0.5
4.1
3.76
3.76
0.65
5.36
5.35
5.35
0.92
10.66
17
1.44
1.44
0.25
2.04
2.16
2.16
0.37
3.07
2.89
2.89
0.5
4.1
3.77
3.77
0.65
5.37
5.36
5.36
0.92
10.71
19
1.52
1.47
0.26
2.14
2.16
2.16
0.37
3.07
2.89
2.89
0.5
4.11
3.78
3.78
0.65
5.38
5.37
5.37
0.92
10.77
20
-
-
-
-
2.24
2.15
0.39
3.17
2.89
2.89
0.5
4.11
3.78
3.78
0.65
5.39
5.37
5.37
0.92
10.8
6
15
1.15
1.15
0.16
1.33
1.87
1.87
0.27
2.18
2.59
2.59
0.37
3.02
3.31
3.31
0.47
3.86
4.05
4.05
0.58
4.74
17
1.15
1.15
0.16
1.33
1.87
1.87
0.27
2.18
2.59
2.59
0.37
3.02
3.31
3.31
0.47
3.87
4.05
4.05
0.58
4.75
19
1.16
1.13
0.17
1.35
1.87
1.87
0.27
2.18
2.59
2.59
0.37
3.02
3.31
3.31
0.48
3.87
4.06
4.06
0.58
4.75
20
-
-
-
-
1.9
1.86
0.27
2.21
2.59
2.59
0.37
3.02
3.31
3.31
0.48
3.87
4.06
4.06
0.58
4.75
15
3
15
1.3
1.3
0.37
3
2.05
2.05
0.59
4.74
3.49
3.49
1
14.66
4.54
4.54
1.3
25.04
5.54
5.54
1.59
35.08
17
1.3
1.3
0.37
3.01
2.05
2.05
0.59
4.74
3.5
3.5
1
14.72
4.55
4.55
1.31
25.1
5.55
5.55
1.59
35.16
19
1.31
1.28
0.38
3.02
2.05
2.05
0.59
4.75
3.5
3.5
1.01
14.78
4.55
4.55
1.31
25.16
5.56
5.56
1.6
35.25
20
-
-
-
-
2.57
2.41
1.57
6.01
3.52
3.42
1.01
14.95
4.56
4.56
1.31
25.19
5.56
5.56
1.6
35.3
4
15
1.01
1.01
0.22
1.72
1.73
1.73
0.37
2.95
2.45
2.45
0.53
4.19
3.89
3.89
0.84
8.01
4.99
4.99
1.07
17.48
17
1.01
1.01
0.22
1.72
1.73
1.73
0.37
2.96
2.45
2.45
0.53
4.19
3.89
3.89
0.84
8.05
5
5
1.08
17.53
19
1.01
1.01
0.22
1.72
1.73
1.73
0.37
2.96
2.45
2.45
0.53
4.19
3.9
3.9
0.84
8.09
5
5
1.08
17.59
20
-
-
-
-
1.73
1.73
0.37
2.96
2.45
2.45
0.53
4.2
3.9
3.9
0.84
8.12
5.01
5.01
1.08
17.62
5
15
1.27
1.27
1.57
1.28
1.44
1.44
0.25
1.93
2.16
2.16
0.37
2.91
2.88
2.88
0.5
3.88
4.14
4.14
0.71
5.63
17
1.27
1.27
1.57
1.28
1.44
1.44
0.25
1.94
2.16
2.16
0.37
2.91
2.88
2.88
0.5
3.88
4.15
4.15
0.71
5.64
19
0.84
0.84
1.57
1.25
1.44
1.44
0.25
1.94
2.16
2.16
0.37
2.91
2.88
2.88
0.5
3.89
4.16
4.16
0.72
5.66
20
-
-
-
-
1.44
1.44
0.25
1.94
2.16
2.16
0.37
2.91
2.88
2.88
0.5
3.89
4.17
4.17
0.72
5.67
6
15
-
-
-
-
1.15
1.15
0.16
1.26
1.87
1.87
0.27
2.07
2.58
2.58
0.37
2.86
3.3
3.3
0.47
3.66
17
-
-
-
-
1.15
1.15
0.16
1.26
1.87
1.87
0.27
2.07
2.59
2.59
0.37
2.87
3.3
3.3
0.47
3.67
19
-
-
-
-
1.15
1.15
0.16
1.26
1.87
1.87
0.27
2.07
2.59
2.59
0.37
2.87
3.31
3.31
0.47
3.67
20
-
-
-
-
1.15
1.15
0.16
1.26
1.87
1.87
0.27
2.07
2.59
2.59
0.37
2.87
3.31
3.31
0.47
3.67
Abbreviations:
EWT: Enter Water Temp. (℃)
Δt: Temperature Difference (℃)
DB: Dry Bulb Temp. (℃)
WF: Water Flow (m3/h)
WB: Wet Bulb Temp. (℃)
TC: Total Cooling Capacity (kW)
SC: Sensible Cooling Capacity (kW)
WPD: Water Pressure Drop (kPa)

Midea DC Fan Coil Unit
17
MKA-V1500F
EWT
ΔT
Indoor
temp
(W.B.)
Indoor temperature (D.B.)
21
23
25
27
29
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
°C
°C
°C
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
5
3
15
7.88
6.01
1.58
63.1
7.7
6.81
1.58
63.13
8.36
8.28
2.38
72.31
9.33
9.33
2.66
87.18
10.29
10.29
2.93
103.01
17
10.61
5.92
3.03
108.63
10.55
6.81
3.01
107.52
10.73
7.95
1.58
109.78
10.42
8.55
2.97
105.35
10.51
9.69
3
106.79
19
13.71
6.02
3.91
168.48
13.64
6.92
3.89
166.86
13.56
7.8
3.87
165.27
13.48
8.67
3.85
163.69
13.41
9.53
3.82
162.13
20
-
-
-
-
15.26
6.97
4.35
202.58
15.18
7.86
4.33
200.68
15.1
8.73
4.31
198.81
15.02
9.6
4.28
196.97
4
15
6.65
5.79
1.58
29.56
6.72
6.5
1.58
30.15
7.74
7.74
1.66
39.03
8.74
8.74
1.88
47.98
9.72
9.72
2.09
57.42
17
9.53
5.61
2.04
55.47
9.12
6.19
1.96
51.48
9.42
7.32
1.58
56.3
9.48
8.47
1.58
55.19
9.74
9.49
1.58
57.66
19
12.37
5.44
2.65
86.36
12.3
6.34
2.64
85.49
12.23
7.22
2.62
84.63
12.15
8.09
2.61
83.78
12.3
9.17
2.64
85.52
20
-
-
-
-
13.95
6.4
2.99
105.99
13.87
7.29
2.97
104.97
13.79
8.16
2.96
103.95
13.71
9.03
2.94
102.94
5
15
4.15
4.15
0.71
7.03
5.77
5.77
0.99
10.13
7
7
1.2
18.39
8.08
8.08
1.39
27.63
9.1
9.1
1.56
34.91
17
8.3
5.27
1.58
30.15
8.42
6.46
1.44
30.16
8.05
7.17
1.38
27.45
8.2
7.9
1.58
28.67
9.11
9.11
1.56
34.99
19
10.84
4.81
1.86
47.07
10.77
5.7
1.85
46.55
11.01
6.88
1.89
48.3
10.63
7.45
1.82
45.51
10.72
8.47
1.84
46.15
20
-
-
-
-
12.49
5.79
2.14
59.8
12.41
6.68
2.13
59.18
12.34
7.56
2.12
58.56
12.51
8.67
2.15
59.99
6
15
5.83
5.61
1.58
13.71
4.53
4.53
0.65
6.3
5.38
5.38
0.77
7.49
7.22
7.22
1.03
11.29
8.37
8.37
1.2
18.49
17
6.23
5.64
1.58
8.61
6.68
6.18
1.58
10.41
5.38
5.38
0.77
7.5
7.23
7.23
1.03
11.34
8.38
8.38
1.2
18.57
19
8.87
4.02
1.27
22.2
8.79
4.91
1.26
21.63
9.58
6.47
1.58
27.33
9.66
7.54
1.38
27.47
9.4
8.35
1.58
25.79
20
-
-
-
-
11.21
5.51
1.6
36.37
10.69
5.99
1.53
33.48
10.62
6.86
1.52
33.04
10.78
7.95
1.54
33.98
7
3
15
5.57
5.01
1.6
35.97
6.4
6.38
1.83
45.47
7.39
7.39
2.12
58.03
8.37
8.37
2.4
71.68
9.33
9.33
2.67
86.32
17
8.79
5.3
2.52
77.9
8.37
5.87
2.4
71.7
8.31
6.75
2.38
70.87
8.52
7.96
2.44
73.94
9.34
9.34
2.68
86.51
19
11.55
5.09
3.31
124.31
11.48
5.99
3.29
123.02
11.41
6.88
3.27
121.75
8.79
6.84
1.58
35.11
11.49
8.82
3.29
123.09
20
-
-
-
-
13.12
6.05
3.76
154.56
13.04
6.94
3.73
153.02
12.96
7.81
3.71
151.5
9.64
7.48
1.58
35.01
4
15
4.53
4.53
0.97
9.75
5.71
5.71
1.23
20.77
6.77
6.77
1.45
30.44
7.78
7.78
1.67
38.77
8.77
8.77
1.88
47.46
17
7.91
5.29
1.58
39.69
7.48
5.91
1.61
36.25
7.59
7.04
1.58
37.25
7.79
7.69
1.67
38.82
8.78
8.78
1.89
47.56
19
10.1
4.5
2.17
60.23
10.03
5.4
2.15
59.55
10.26
6.57
2.2
61.9
8.79
6.84
1.58
35.11
9.84
8.03
2.11
57.6
20
-
-
-
-
11.71
5.47
2.51
77.42
11.63
6.36
2.5
76.6
11.56
7.24
2.48
75.79
9.64
7.48
1.58
35
5
15
3.44
3.44
0.59
5.49
4.22
4.22
0.73
6.75
5.98
5.98
1.03
11.62
7.1
7.1
1.22
20.69
8.15
8.15
1.4
28.32
17
6.71
5.14
1.58
21.04
4.22
4.22
0.73
6.76
5.99
5.97
1.03
11.67
7.11
7.11
1.22
20.77
8.16
8.16
1.4
28.39
19
8.35
3.82
1.44
29.64
8.28
4.72
1.42
29.19
8.86
6.14
1.52
32.92
8.76
7.7
1.58
33
8.96
8.22
1.54
33.5
20
-
-
-
-
10.24
4.9
1.58
43.22
10.04
5.73
1.72
40.65
9.96
6.61
1.71
40.17
9.64
7.48
1.58
35.01
6
15
3.13
3.13
0.45
4.11
3.83
3.83
0.55
5.03
4.53
4.53
0.65
5.95
5.93
5.93
0.85
7.84
7.39
7.39
1.06
13.17
17
3.23
3.12
1.58
4.23
3.83
3.83
0.55
5.03
4.53
4.53
0.65
5.95
5.95
5.95
0.85
7.86
7.4
7.4
1.06
13.23
19
4.24
2.45
1.58
5.57
7.58
5.37
1.58
14.73
6.13
5.66
1.58
8.08
7.67
6.97
1.58
17.77
7.4
7.24
1.06
13.24
20
-
-
-
-
8.59
4.5
1.58
21.53
9.11
5.84
1.58
24.53
8.98
6.78
1.58
23.69
8.66
7.52
1.24
21.8
9
3
15
4.35
4.35
1.24
22.27
5.4
5.4
1.54
33.48
6.41
6.41
1.83
44.73
7.4
7.4
2.12
57.02
8.37
8.37
2.39
70.34
17
6.68
4.63
1.58
47.87
6.17
5.1
1.58
41.93
6.47
6.2
1.85
45.4
7.41
7.41
2.12
57.14
8.38
8.38
2.4
70.49
19
9.21
4.15
2.63
82.78
9.15
5.05
2.62
81.81
9.09
5.93
1.58
81.06
7.51
6.38
1.58
34.61
8.98
7.72
2.57
79.32
20
-
-
-
-
10.79
5.11
3.09
108.58
10.73
6
3.07
107.4
8.4
6.15
1.58
34.54
10.59
7.74
1.58
105.19
4
15
3.04
3.04
0.65
5.82
4.66
4.66
1
11.17
5.77
5.77
1.24
22.08
6.81
6.81
1.46
30.3
7.81
7.81
1.68
38.26
17
4.21
3.84
1.58
8.25
4.71
4.54
1.58
11.81
5.78
5.78
1.24
22.14
6.82
6.82
1.46
30.36
7.82
7.82
1.68
38.34
19
7.58
3.53
1.63
36.38
7.64
4.47
1.58
37.97
7.8
5.56
1.58
38.85
7.51
6.38
1.58
34.61
8.15
7.77
1.58
40.8
20
-
-
-
-
9.61
4.89
1.58
53.58
9.19
5.41
1.97
50.38
8.4
6.15
1.58
34.54
9.06
7.16
1.94
49.17
5
15
2.73
2.73
0.47
4.12
3.43
3.43
0.59
5.18
4.6
4.6
0.79
6.96
6.1
6.1
1.05
13.55
7.18
7.18
1.23
21.89
17
2.73
2.7
0.47
4.12
3.43
3.43
0.59
5.18
4.61
4.61
0.79
6.98
6.1
6.1
1.05
13.61
7.19
7.19
1.23
21.96
19
7.16
4.21
1.58
21.9
5.9
4.17
1.58
12.95
5.93
5.16
1.58
12.68
6.18
5.87
1.06
14.23
7.19
7.12
1.23
21.95
20
-
-
-
-
8.2
4.56
1.58
27.69
8.37
5.61
1.58
29.38
8.53
6.3
1.58
34.66
8.12
7.41
1.58
27.67
6
15
2.44
2.44
0.35
3.02
3.13
3.13
0.45
3.88
3.83
3.83
0.55
4.75
4.57
4.57
0.66
5.68
6.35
6.35
0.91
8.68
17
2.44
2.44
0.35
3.02
3.14
3.14
0.45
3.88
3.83
3.83
0.55
4.75
4.58
4.58
0.66
5.69
6.36
6.36
0.91
8.71
19
3.12
2.3
1.58
3.84
3.28
3.09
0.47
4.05
3.84
3.84
0.55
4.76
4.58
4.58
0.66
5.69
6.37
6.37
0.91
8.75
20
-
-
-
-
5.57
4.18
1.58
7.1
6.82
5.32
1.58
13.41
5.97
5.81
1.58
7.92
6.38
6.31
0.91
8.76

Midea DC Fan Coil Unit
18
(Continued)
MKA-V1500F
EWT
ΔT
Indoor
temp
(W.B.)
Indoor temperature (D.B.)
21
23
25
27
29
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
TC
SC
WF
WPD
°C
°C
°C
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
kW
kW
m^3/h
kPa
11
3
15
3.27
3.27
0.94
9.46
4.39
4.39
1.26
22.95
5.42
5.42
1.55
33.23
6.42
6.42
1.84
44.23
7.4
7.4
2.12
56.27
17
3.39
3.09
0.97
10.76
4.39
4.36
1.58
22.97
5.43
5.43
1.56
33.3
6.43
6.43
1.84
44.32
7.41
7.41
2.12
56.39
19
6.65
3.18
1.91
46.89
7.03
4.44
1.58
52.73
6.98
5.27
1.58
54.19
6.67
6.05
1.58
46.09
7.42
7.33
2.13
56.55
20
-
-
-
-
8.62
4.51
1.58
71.25
8.22
5.04
2.36
67.21
8.16
5.92
2.34
66.36
8.11
6.81
2.32
65.74
4
15
2.33
2.33
0.5
4.22
3.12
3.12
0.67
5.65
4.74
4.74
1.02
13.13
5.82
5.82
1.25
22.68
6.84
6.84
1.47
30.14
17
2.33
2.33
0.5
4.23
3.12
3.12
0.67
5.66
4.75
4.75
1.02
13.19
5.83
5.83
1.25
22.73
6.85
6.85
1.47
30.2
19
3.64
2.14
0.78
6.61
4.32
3.26
0.93
9.41
5.17
4.82
1.58
16.56
5.85
5.72
1.26
22.87
6.86
6.86
1.47
30.27
20
-
-
-
-
7.4
4.23
1.58
34.75
7.05
4.99
1.51
31.65
6.79
5.75
1.58
29.24
7.13
6.72
1.53
32.3
5
15
2.04
2.04
0.35
2.91
2.73
2.73
0.47
3.9
3.43
3.43
0.59
4.9
5.02
5.02
0.86
7.71
6.18
6.18
1.06
15.36
17
2.04
2.04
0.35
2.91
2.74
2.74
0.47
3.91
3.43
3.43
0.59
4.9
5.03
5.03
0.86
7.74
6.19
6.19
1.07
15.42
19
2.41
2.02
1.58
3.42
2.75
2.69
0.47
3.93
3.43
3.43
0.59
4.91
5.03
5.03
0.87
7.77
6.2
6.2
1.07
15.49
20
-
-
-
-
4.8
3.55
1.58
7.36
4.82
4.43
1.58
7.35
5.19
5.06
1.58
8.45
6.2
6.18
1.07
15.51
6
15
1.76
1.76
0.25
2.06
2.44
2.44
0.35
2.86
3.13
3.13
0.45
3.68
3.82
3.82
0.55
4.49
4.79
4.79
0.69
5.64
17
1.76
1.76
0.25
2.06
2.45
2.45
0.35
2.87
3.14
3.14
0.45
3.68
3.83
3.83
0.55
4.5
4.8
4.8
0.69
5.65
19
1.98
1.85
1.58
2.3
2.44
2.41
0.35
2.86
3.14
3.14
0.45
3.68
3.83
3.83
0.55
4.5
4.81
4.81
0.69
5.67
20
-
-
-
-
2.64
2.42
1.58
3.08
3.14
3.11
0.45
3.68
3.83
3.83
0.55
4.5
4.82
4.82
0.69
5.67
13
3
15
1.92
1.92
0.55
4.47
3.33
3.33
0.96
11.14
4.42
4.42
1.27
23.1
5.44
5.44
1.56
32.92
6.43
6.43
1.85
43.68
17
1.93
1.93
0.55
4.47
3.34
3.34
0.96
11.19
4.43
4.43
1.27
23.15
5.45
5.45
1.56
32.98
6.44
6.44
1.85
43.77
19
4.47
2.83
1.58
24.96
3.68
3.09
1.06
15.57
4.46
4.31
1.28
23.5
5.45
5.45
1.57
33.06
6.45
6.45
1.85
43.87
20
-
-
-
-
5.82
3.63
1.58
33.56
5.92
4.52
1.7
37.94
5.69
5.15
1.63
35.52
6.46
6.37
1.85
43.97
4
15
1.63
1.63
0.35
2.8
2.33
2.33
0.5
4
3.5
3.5
0.75
6.05
4.81
4.81
1.03
14.74
5.86
5.86
1.26
22.79
17
1.64
1.64
0.35
2.8
2.33
2.33
0.5
4.01
3.51
3.51
0.76
6.07
4.81
4.81
1.04
14.8
5.87
5.87
1.26
22.84
19
1.79
1.73
0.38
3.06
2.33
2.33
0.5
4.01
3.53
3.53
0.76
6.09
4.82
4.82
1.04
14.86
5.88
5.88
1.26
22.89
20
-
-
-
-
2.48
2.38
0.53
4.25
3.58
3.5
1.58
6.19
4.83
4.78
1.58
14.9
5.88
5.88
1.27
22.92
5
15
1.35
1.35
0.23
1.83
2.04
2.04
0.35
2.76
2.73
2.73
0.47
3.7
3.46
3.46
0.6
4.69
5.15
5.15
0.89
8.84
17
1.35
1.35
0.23
1.83
2.04
2.04
0.35
2.76
2.73
2.73
0.47
3.71
3.46
3.46
0.6
4.7
5.15
5.15
0.89
8.88
19
1.39
1.32
0.24
1.87
2.04
2.04
0.35
2.76
2.74
2.74
0.47
3.71
3.46
3.46
0.6
4.7
5.16
5.16
0.89
8.92
20
-
-
-
-
2.1
2.06
0.36
2.83
2.74
2.74
0.47
3.71
3.47
3.47
0.6
4.7
5.17
5.17
0.89
8.95
6
15
1.09
1.09
1.58
1.22
1.76
1.76
0.25
1.95
2.44
2.44
0.35
2.72
3.13
3.13
0.45
3.49
3.82
3.82
0.55
4.26
17
1.09
1.09
1.58
1.22
1.76
1.76
0.25
1.95
2.44
2.44
0.35
2.72
3.13
3.13
0.45
3.49
3.82
3.82
0.55
4.26
19
1.09
1.06
1.58
1.22
1.76
1.76
0.25
1.95
2.45
2.45
0.35
2.72
3.14
3.14
0.45
3.49
3.83
3.83
0.55
4.27
20
-
-
-
-
1.77
1.73
0.25
1.96
2.45
2.45
0.35
2.72
3.14
3.14
0.45
3.5
3.83
3.83
0.55
4.27
15
3
15
1.23
1.23
0.35
2.7
1.92
1.92
0.55
4.24
3.38
3.38
0.97
12.65
4.44
4.44
1.28
23.01
5.45
5.45
1.57
32.53
17
1.23
1.23
0.35
2.7
1.92
1.92
0.55
4.24
3.39
3.39
0.97
12.71
4.45
4.45
1.28
23.05
5.46
5.46
1.57
32.59
19
1.23
1.22
0.35
2.71
1.93
1.93
0.55
4.24
3.39
3.39
0.97
12.76
4.46
4.46
1.28
23.11
5.47
5.47
1.57
32.67
20
-
-
-
-
2.52
2.46
1.58
5.77
3.39
3.35
1.58
12.8
4.46
4.46
1.28
23.14
5.47
5.47
1.57
32.71
4
15
0.95
0.95
0.2
1.53
1.63
1.63
0.35
2.66
2.33
2.33
0.5
3.79
3.71
3.71
0.8
6.61
4.85
4.85
1.04
15.65
17
0.95
0.95
0.2
1.54
1.63
1.63
0.35
2.66
2.33
2.33
0.5
3.79
3.72
3.72
0.8
6.64
4.86
4.86
1.05
15.7
19
0.95
0.95
0.2
1.54
1.64
1.64
0.35
2.66
2.33
2.33
0.5
3.8
3.73
3.73
0.8
6.67
4.87
4.87
1.05
15.75
20
-
-
-
-
1.64
1.64
0.35
2.66
2.33
2.33
0.5
3.8
3.73
3.73
0.8
6.68
4.87
4.87
1.05
15.78
5
15
0.82
0.82
1.58
1.18
1.35
1.35
0.23
1.73
2.04
2.04
0.35
2.62
2.73
2.73
0.47
3.51
3.6
3.6
0.62
4.63
17
0.82
0.82
1.58
1.18
1.35
1.35
0.23
1.73
2.04
2.04
0.35
2.62
2.73
2.73
0.47
3.51
3.6
3.6
0.62
4.64
19
0.82
0.82
1.58
1.18
1.35
1.35
0.23
1.73
2.04
2.04
0.35
2.62
2.73
2.73
0.47
3.52
3.61
3.61
0.62
4.65
20
-
-
-
-
1.35
1.35
0.23
1.73
2.04
2.04
0.35
2.62
2.73
2.73
0.47
3.52
3.61
3.61
0.62
4.66
6
15
-
-
-
-
1.09
1.09
1.58
1.16
1.76
1.76
0.25
1.85
2.44
2.44
0.35
2.58
3.13
3.13
0.45
3.31
17
-
-
-
-
1.09
1.09
1.58
1.16
1.76
1.76
0.25
1.85
2.44
2.44
0.35
2.58
3.13
3.13
0.45
3.31
19
-
-
-
-
1.09
1.09
1.58
1.16
1.76
1.76
0.25
1.85
2.44
2.44
0.35
2.58
3.13
3.13
0.45
3.32
20
-
-
-
-
1.09
1.09
1.58
1.16
1.76
1.76
0.25
1.85
2.45
2.45
0.35
2.58
3.14
3.14
0.45
3.32
Abbreviations:
EWT: Enter Water Temp. (℃)
Δt: Temperature Difference (℃)
DB: Dry Bulb Temp. (℃)
WF: Water Flow (m3/h)
WB: Wet Bulb Temp. (℃)
TC: Total Cooling Capacity (kW)
SC: Sensible Cooling Capacity (kW)
WPD: Water Pressure Drop (kPa)

Midea DC Fan Coil Unit
19
Heating Capacity Table
MKA-V600F
EWT
ΔT
Indoor temperature (D.B.)
16
18
20
22
TH
WF
WPD
TH
WF
WPD
TH
WF
WPD
TH
WF
WPD
[°C]
[°C]
[kW]
[m^3/h]
[kPa]
[kW]
[m^3/h]
[kPa]
[kW]
[m^3/h]
[kPa]
[kW]
[m^3/h]
[kPa]
40
5
3.92
0.68
30.83
3.52
0.61
25.57
3.12
0.54
20.75
2.72
0.47
16.37
8
3.4
0.37
10.8
3
0.32
8.69
2.59
0.28
6.76
2.17
0.23
5.03
10
3.02
0.26
6.08
2.6
0.23
4.72
2.17
0.19
3.47
1.71
0.15
2.08
12
2.59
0.19
3.46
2.13
0.15
2.25
1.5
0.99
0.91
1.27
0.99
0.83
15
1.6
0.1
0.83
1.49
0.99
0.82
1.36
0.1
0.81
1.23
0.99
0.8
45
5
4.93
0.86
44.9
4.53
0.79
38.7
4.13
0.72
32.93
3.73
0.65
27.57
8
4.43
0.48
16.59
4.03
0.44
14.07
3.62
0.39
11.74
3.22
0.35
9.58
10
4.08
0.35
9.87
3.68
0.32
8.25
3.27
0.28
6.74
2.85
0.25
5.36
12
3.71
0.27
6.19
3.3
0.24
5.06
2.88
0.21
4.01
2.44
0.18
3.04
15
3.09
0.18
3.12
2.62
0.15
2.25
2.1
0.12
1.15
1.62
0.1
0.76
50
5
5.94
1.03
60.91
5.54
0.96
53.83
5.13
0.89
47.15
4.73
0.82
40.88
8
5.45
0.59
23.21
5.05
0.55
20.31
4.64
0.5
17.58
4.24
0.46
15.03
10
5.12
0.44
14.2
4.71
0.41
12.32
4.31
0.37
10.56
3.9
0.34
8.91
12
4.77
0.35
9.25
4.37
0.32
7.94
3.96
0.29
6.71
3.54
0.26
5.57
15
4.22
0.24
5.18
3.8
0.22
4.33
3.38
0.2
3.55
2.94
0.17
2.81
55
5
6.94
1.21
78.71
6.54
1.14
70.79
6.13
1.07
63.27
5.73
1
56.14
8
6.46
0.7
30.6
6.06
0.66
27.34
5.66
0.62
24.24
5.25
0.57
21.32
10
6.14
0.53
19.05
5.74
0.5
16.93
5.33
0.46
14.92
4.93
0.43
13.02
12
5.81
0.42
12.68
5.4
0.39
11.19
5
0.36
9.79
4.59
0.33
8.46
15
5.3
0.31
7.42
4.88
0.28
6.47
4.47
0.26
5.56
4.06
0.23
4.72
60
5
7.95
1.39
98.22
7.54
1.32
89.5
7.13
1.25
81.16
6.73
1.17
73.21
8
7.47
0.81
38.72
7.07
0.77
35.11
6.66
0.73
31.67
6.26
0.68
28.39
10
7.16
0.62
24.39
6.75
0.59
22.03
6.35
0.55
19.78
5.94
0.52
17.65
12
6.84
0.5
16.46
6.43
0.47
14.8
6.02
0.44
13.23
5.62
0.41
11.73
15
6.34
0.37
9.89
5.93
0.34
8.82
5.53
0.32
7.81
5.12
0.3
6.85
65
5
8.95
1.57
119.37
8.54
1.49
109.88
8.13
1.42
100.76
7.73
1.35
92.02
8
8.48
0.93
47.53
8.07
0.88
43.59
7.67
0.84
39.81
7.26
0.79
36.2
10
8.17
0.71
30.18
7.76
0.68
27.61
7.38
0.61
25.3
6.95
0.61
22.77
12
7.85
0.57
20.57
7.45
0.54
18.75
7.04
0.51
17.01
6.64
0.48
15.35
15
7.37
0.43
12.58
6.97
0.4
11.41
6.56
0.38
10.28
6.15
0.36
9.21
Abbreviations:
Δt: Temperature Difference (℃)
TH: Total Heating Capacity (kW)
WF: Water Flow
(m3/h)
WPD: Water Pressure Drop (kPa)
