Midea FlashChef G1 User manual

Commercial
High Speed Oven
QUICK START GUIDE
G1
208/240V~ 60Hz, 6000W

01
HIGH SPEED
OVEN “QUICK-START” GUIDE
2
Start up screen will appear
(Swirl and Midea Logo with Music)
Place desired Accessory(ies)
in the cavity.
To turn on the oven,
Press and Hold the Start button
on the front panel (2 Sec)
1
3
1

2
5
7
PreHeat screen will appear – tap
desired pre-heat temp（Example: 500F）
When 100% is reached, this screen will appear. Oven is now preheated. Press "Start"
Screen will show PreHeat progress
by % completed. Times: (300F – 6:00,
400F – 9:45, 500F – 15:00)
The “Recents” home screen will display.
Time - 00:50
MW Power - 60%
Fan Speed - 90%
EXAMPLE: To Cook/Programme the HSO
oven to heat an 8” Sub Sandwich with
Meat & Cheese: Temperature: 495F
4
6

3
9
Press the “Chef Cook” icon in the middle
of the left of the screen.
In the Top Right corner, press the TEMP
down Caret ( )
a.Press “Input the PWD” (Password)
on the screen
b.Keyboard will appear to enter PWD
(flashtune or Password depending on
version)
c.Press “Check” icon on the keyboard
(to “enter”)
i.(PWD was set when the oven was
1st plugged in (new))
Cooking/Programming Function
Screen will appear.
8
10

4
11
14
13 "Now Press "time" for the 1st stage"
Time - 00:50
MW Power - 60%
Fan Speed - 90%
3 Control Slides will appear – Set to:
Tap or Slide TEMP Control bar to
desired Temperature. "Use the +1
or -1 for small adjustments"
In the Top Right corner, press the
TEMP UP Caret (▲) 495 is nowset
Press “Input Recipe Name”, Keyboard
will appear
12
15

5
16
18
20
Type “Sandwiches” and press “Check”
(Enter)
Enter the name of the Recipe and
press “check” to enter.
Add Category
Follow Steps 1 - 7 to simply cook the sandwich you just entered.
Temperature: 495F
Time - 00:50
MW Power - 60%
Fan Speed - 90%
Note: the “Space Bar” is along the bottom of the keyboard – it says
“English” on it.
17
19
Edit recipes and categories with the
FlashTune program on your PC.
When finished, "Drag and Drop" the
saved file on to the USB drive you
are using. Using "Save As" on the
program will work to save it on the
PC but not to the USB - must be
copied to the USB from the folder.

6
21
23
22
Save the recipes on to the pc
To Upload the recipes:
1. Drag and Drop the saved recipe file (.db) to the USB Memory Device
2. Press the "Setting" icon ( )
3. Press "User Settings"
4. Input the password by pressing that area of the screen - the keyboard
will appear and type "flashtune" - then press the small "check" mark on
the keyboard to enter.
5. Press the USB window on the screen
6. Insert the USB into the port on the front right side of the oven.
(contact on the USB drive should be oriented towards the operator)
7. Wait for the area next to "Recipes Upload" "Recipes Download" and
"Firmware Update" to populate with "DISK_IMG".
7. Press "Recipes Upload"
8. Select the folder
9. If successful, folder will now show a circled "check mark" in the center.
10. Press the recipes icon and uploaded recipes will appear.
Don’t "Save As" the recipe directly into USB, simply save it on to the PC
and drag it into your USB to upload
