Midea RG10A(B2S)/BGEF User manual

CR247-RG10
16117000002081
20191008
AIR CONDITIONER
REMOTE CONTROLLER MANUAL
Thank you very much for purchasing our air conditioner.
Please read this owner's manual carefully before using
your air conditioner. Make sure to save this manual for
future reference.
The design and specifications are subject to change without prior
notice for product improvement. Consult with the sales agency or
manufacturer for details.

1
CONTENTS
2
Model
Rated Voltage
8m
3.0V(Dry batteries R03/LR03×2)
O O O O
-5 C~60 C(23 F~140 F)
Environment
Signal Receiving Range
RG10A(B2S)/BGEF
2
3
4
5
6
13
Handling the remote controller ......................................................
Remote controller Specifications...................................................
Function buttons .................. .........................................................
Remote LCD screen indicators .....................................................
How to use the basic functions........................................................
How to use the advanced functions ...............................................
Remote Controller Specifications
NOTE:
Buttons design is based on typical model and might be slightly different from the
actual one you purchased，the actual shape shall prevail.
All the functions described are accomplished by the unit. If the unit has no this
feature, there is no corresponding operation happened when press the relative
button on the remote controller.
When there are wide differences between Remote controller Illustration and
USER'S MANUAL on function description, the description of USER'S MANUAL
shall prevail.
,,
,, ,,
,, ,,
,,
The device could comply with the local national regulations.
In Canada, it should comply with CAN ICES-3(B)/NMB-3(B).
In USA, this device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not approved by the party responsible for compliance
could void user s authority to operate the equipment.
NOTE:

3 4
Function Buttons
ON/OFF
OK Button
Breeze Away Button
Turns the unit on or off
Used to confirm the selected
functions
Adjust
Adjust
Increases temperature in
O O
1 C(1 F) increments. Max.
o O
Temperature is 30 C(86 F).
Decreases temperature
O O
in 1 C(1 F) increments.
Min. temperature is
O O
16 C(60 F).
ECO/GEAR Button
Clean button
LED button
Starts and stops the louver
movement.(see page 14) .
This feature avoids direct air
flow blowing on the body and
makes you feel indulging in
silky coolness.
NOTE: This feature is available
under cooling mode only.
Turns indoor unit s LED display
and air conditioner buzzer on
and off, which create a comfortable
and quiet environment.
NOTE: Hold down this button
for five seconds to alternate
the temperature display of indoor
unit between setting temperature
and room temperature.
MODE Button
Scrolls through operation
modes as follows:
,
Before you begin using your new air conditioner, make sure to familiarize yourself with its remote
control. The following is a brief introduction to the remote control itself. For instructions on how to
operate your air conditioner, refer to the How to Use Basic Functions section of this manual.
NOTE：Please do not select HEAT mode if the machine you purchased is cooling only
type. Heat mode is not supported by the cooling only appliance.
AUTO g
COOLg
DRYg HEAT
g
FAN
NOT SURE WHAT A FUNCTION DOES?
Refer to the How to Use Basic Functions
and How to Use Advanced Functions
sections of this manual for a detailed
description of how to use your air conditioner.
SPECIAL NOTE
Button designs on your unit may differ
slightly from the example shown.
If the indoor unit does not have a particular
function, pressing that function s button on
the remote control will have no effect.
TIPS FOR USING REMOTE CONTROL
The remote control must be used within 8
meters of the unit.
The unit will beep when remote signal is
received.
Curtains, other materials and direct
sunlight can interfere with the infrared
signal receiver.
Remove batteries if the remote control
will not be used more than 2 months.
INSERTING AND REPLACING BATTERIES
INSTALLING REMOTE CONTROL HOLDER
Put the two batteries(optional parts) in the remote
control before use:
1. Remove the back cover from the remote
control, exposing the battery compartment.
2. Insert the batteries, paying attention to
match up the (+) and (-) ends of the
batteries with the symbols inside the
battery compartment.
3. Install the back cover on.
The remote controller can be attached to a wall
or stand by using a remote controller holder.
Before installing the remote controller, check
that the air conditioner receives the signals
properly.
the remote controller on the holder.
1.
2. Install the holder with two screws.
3. Put
BATTERY NOTES
For optimum product performance:
Do not mix old and new batteries, or
batteries of different types.
Do not leave batteries in the remote control
if you don t plan on using the device for
more than 2 months.
BATTERY DISPOSAL
Do not dispose of batteries as unsorted
municipal waste. Refer to local laws for
proper disposal of batteries.
,
,
Handling The Remote Controller
Remove the back cover
to install batteries
This function is used to clean
the air conditioner evaporator
to prevent frosting.
TIMER Button
SWING Button
Set timer to turn unit on or off
(see page 9 )
Press this button to
enter the energy efficient
mode in a sequence of
following: ECO GEAR(75%)
GEAR(50%) Previous
setting mode ECO......
SET Button
Scrolls through operation
functions as follows:
Fresh( ) Sleep( )
Follow Me( )
AP mode( ) Fresh...
gg
g
g
The selected symbol will
flash on the display area,
press the OK button to
confirm . (see page 12)
FAN SPEED BUTTON
Boost BUTTON
Selects fan speeds in the
following order:
AU g
g
20%
60%
40%
80% 100%.
gg g
Press the Adjust or
button to increase /decrease
the fan speed in 1% increments.
Enables unit to reach preset
temperature in shortest
possible time
NOTE: Press and hold
and buttons together
for 3 seconds will alternate
the temperature display
O O
between the C & F scale.
Fan
Boost

5 6
Transmission Indicator
Breeze Away display
Sleep mode display
Active clean feature display
Follow me feature display
Wireless control feature display
Fresh feature display
Displays when LOCK feature
is activated.
Silence feature
display
Silence
LOW
MED
HIGH
AUTO
Lights up when remote
sends signal to indoor
unit
TIMER ON display
Fan speed display
Displays selected fan speed:
1. Press the MODE button to select
COOL mode.
2. Set your desired temperature using
the Temp or Temp button.
3. Press the FAN button to select the
fan speed in a range of Au-100%, in
conjunction with Temp or Temp
button.
4. Press the ON/OFF button to start the
unit.
In AUTO mode, the unit will automatically
select the COOL, FAN, HEAT or DRY mode
based on the set temperature.
1. Press the MODE button to select Auto mode.
2. Set your desired temperature using the
Temp or Temp button.
3. Press the ON/OFF button to start the unit.
,
NOTE: FAN SPEED can t be set in Auto mode.
SETTING TEMPERATURE
AUTO operation
The operating temperature range for units is
O O
16-30 C/60-86 F. You can increase or
O O
decrease the set temperature in 1 C/1 F
increments.
COOL operation
Low battery detection display(If flashes)
Remote LCD Screen Indicators How To Use The Basic Functions
MODE display
Displays the current
including:
mode,
TIMER OFF display
2%-20%
21%-40%
41%-60%
61%-80%
81%-100%
1%
This fan speed can not be
adjusted in AUTO or DRY
mode.
Note:
operation only the relative functional signs are shown on the display window.
All indicators shown in the figure are for the purpose of clear presentation. But during the actual
1
4
3
2
LOCK display
1
3
2
ECO display
GEAR display
Displays when ECO feature
is activated
Displays when ECO feature
is activated
Temperature/Timer/Fan
speed display
Displays the set temperature
by default, or fan speed or
timer setting when using
TIMER ON/OFF functions
Temperature range:
o
16-30 C
O
/60-86 F
Timer setting range:
0-24 hours
Fan speed setting range:
AU -100%
This display is blank when
operating in FAN mode.
Horizontal louver
swing display
Vertical louver auto
swing display
TURBO mode display
Not available for
this unit
gg
g
gg
Fan
Fan
Boost
Boost

78
1. Press the MODE button to select DRY
mode.
2. Set your desired temperature using the
Temp or Temp button.
3. Press the ON/OFFbutton to start the unit.
,
NOTE: FAN SPEED can t be changed in
DRY mode.
1. Press the MODE button to select FAN
mode.
2. Press the FAN button to select the
fan speed in a range of Au-100%, in
conjunction with Temp or Temp
button.
3. Press the ON/OFFbutton to start the
unit.
,
NOTE: You can t set temperature in FAN
mode. As a result, your remote control s
LCD screen will not display temperature.
DRY operation(dehumidifying)
FAN operation
,
1. Press the MODE button to select
HEAT mode.
2. Set your desired temperature using
the Temp or Temp button.
3. Press the FAN button to select the
fan speed in a range of Au-100%, in
conjunction with Temp or Temp
button.
4. Press the ON/OFF button to start the
unit.
HEAT operation
NOTE: As outdoor temperature drops, the
performance of your unit s HEAT function
may be affected. In such instances, we
recommend using this air conditioner in
conjunction with other heating appliance.
,
How To Use The Basic Functions How To Use The Basic Functions
1
3
2
1
4
2
3
1
3
2
Fan
Fan
Fan
Boost
Boost
Boost

910
ON/OFF
MODE
FAN
SHORT
CUT
TIMER ON
TIMER OF
F
TEMP
S
LEEP
1sec
x5
1
3
2
4
x10
ON/OFF
MODE
FAN
SHORT
CUT
TIMER ON
TIMER OF
F
TEMP
S
LEEP
1sec
1
3
2
4
Timer
Timer
or
or
NOTE:
" 0.0h "
When setting the TIMER ON or
TIMER OFF functions, up to 10 hours,
the time will increase in 30 minute
increments with each press. After 10
hours and up to 24, it will increase in 1
hour increments. The timer will revert to
zero after 24 hours.
You can turn off either function by
setting its timer to .
2. Press the Temp or Temp button
repeatedly to set the time when you
want the unit to turn on.
3. Wait one second, then the TIMER ON
function will be activated. The digital
display on your remote control will then
return to the temperature display. The
" " indicator remains on and this
function is activated.
2. Press the Temp or Temp button
repeatedly to set the time when you want
the unit to turn off.
3. Wait one second, then the TIMER OFF
function will be activated. The digital
display on your remote control will then
return to the temperature display. The
" " indicator remains on and this
function is activated.
Example
hours.
: Setting unit to turn on after 2.5
Example
hours.
: Setting unit to turn off after 5
TIMER OFF function
The TIMER OFF function allows you to
set a period of time after which the unit
will automatically turn off.
TIMER ON function
The TIMER ON function allows you to set
a period of time after which the unit will
automatically turn on.
Your air conditioning unit has two
timer-related functions:
TIMER ON- sets the amount of timer after
which the unit will automatically turn on.
TIMER OFF- sets the amount of time after
which the unit will automatically turn off.
Setting the TIMER function
1.
This number indicates the
amount of time after the current time
that you want the unit to turn on.
For example, if you set TIMER ON for
2.5 hours, will appear on the
screen, and the unit will turn on after
2.5 hours.
Press the Timer button, the Timer on
indicator " " and time display.
Note:
" 2.5h "
1.
This number indicates the
amount of time after the current time
that you want the unit to turn off.
For example, if you set TIMER OFF for 5
hours, will appear on the screen,
and the unit will turn off after 5 hours.
Press the Timer button, the Timer off
indicator " " and time display.
Note:
" 5.0h "
Setting both TIMER ON and TIMER OFF at the same time
Keep in mind that the time periods you set for both functions refer to hours after the
current time. For example, say that the current time is 1:00 PM, and you want the unit
to turn on automatically at 7:00 PM. You want it to operate for 2 hours, then automa-
tically turn off at 9:00 PM.
Do the following:
ON/OFF
ON/OFF
MODE
MODE
SHORT
SHORT
CUT
CUT
TIMER ON
TIMER ON
TEMP
TEMP
1
sec
4
8
3
7
X12
X16
2
6
1
5
Timer
Timer
or
or

11 12
The FOLLOW ME function enables the
remote control to measure the temperature
at its current location and
.
When using AUTO, COOL, or HEAT modes,
measuring ambient temperature from the
remote control (instead of from the indoor
unit itself) will enable the air conditioner to
optimize the temperature around
you and ensure maximum comfort.
send this signal
to the air conditioner every 3 minutes interval
FOLLOW ME function( )(optional)
SLEEP Function( )
The SLEEP function is used to decrease
energy use while you sleep (and don t need
the same temperature settings to stay
comfortable). This function can only be
activated via remote control.
Note: The SLEEP function is not available
in FAN or DRY mode.
,
How To Use The Advanced Functions
Press the SET button to enter the function
setting, then press SET button or
Temp or
Temp button to select the desired function.
The selected symbol will flash on the display
area, press the OK button to confirm.
To cancel the selected function, just perform
the same procedures as above.
For the detail, see sleep operation in
USER S MANUAL.
,
,, ,
,
,
,
,
,
,,
,
,
,
,
,
,
Current
time 1PM
2PM 3PM 4PM 5PM 6PM 7PM 8PM 9PM
Timer starts Unit turns Unit turns
ON OFF
6 hours later
8 hours later
Press the SET button to scroll through
operation functions as follows:
Fresh( ) Sleep( ) Follow Me( )
AP mode ( )
gg
g
12
FRESH function( )(optional)
AP mode( )(optional)
When the FRESH function is initiated, the
Ionizer/Plasma Dust Collector(depending
on models) is energized and will help to
remove pollen and impurities from the air.
Choose AP mode to do wireless network
configuration.
Example: Setting the unit to turn on after 6 hours, operate for 2 hours, then turn off
(see the figure below)
Your remote display
Timer is set to turn ON
6 hours from current time
Timer is set to turn OFF
8 hours from current time
P
P
ress and hold Boost and Clean
buttons together for five seconds to
lock the keypads. ress and hold
Turbo and Clean buttons together for
two seconds to cancel.
Fan
Boost
If the memory feature is stopped, Of
displays for 3 seconds on the screen.
While the memory feature is activated,
press the ON/OFF button, shift the mode
or power failure will not cancel the Follow
me function.
NOTE: Press and hold Boost button for
seven seconds to start/stop memory
feature of Follow Me function.
If the memory feature is activated, On
displays for 3 seconds on the screen.

13 14
How To Use The Advanced Functions
When the air conditioner operates under
heating mode with the set temperature of
O O
16 C(60 F), pressing button twice in
O O
one second will activate 8 C(46 F) heating.
The indoor unit display shows FP .
,,
,,
FP function
The Boost function makes the unit work
extra hard to reach your present temperature
in the shortest amount of time possible.
When you select Boost feature in COOL
mode, the unit will blow cool air with
strongest wind setting to jump-start the
cooling process.
When you select Turbo feature in HEAT
mode, the unit will blow heat air with
strongest wind setting to jump-start the
heating process.
Press the Swing button to start or stop the
horizontal louver auto swing feature.
If continue to press the Swing button, five
different airflow directions can be set. The
louver can be move at a certain range each
time you press the button.
Hold down the Swing button for 2 seconds
will start or stop the vertical louver auto swing
feature.
Boost function( )
Swing function
NOTE:
Silence function
Hold down Fan speed button( ) for 2 seconds
to activate/cancel Silent mode. Due to low
frequency operation of compressor, it may result
in insufficient cooling and heating capacity
(applicable to the air conditioner with Silent
feature only)
ECO/GEAR function( )
ECO operation:
GEAR operation:
How To Use The Advanced Functions
NOTE: This function is only available under
COOL mode.
Press ECO/GEAR button to enter the energy
efficient mode in a sequence of following:
ECO GEAR(75%) GEAR(50%)
Previous setting mode ECO ......
Under cooling mode, press this button, the
remote controller will adjust the temperature
O
automatically to 24 C, fan speed of Auto to
save energy(but only if the set temperature
O
is less than 24 C). If the set temperature is
O
above 24 C , press the ECO button, the fan
speed will change to Auto, the set temperature
will remain unchanged.
NOTE:
Pressing the ON/OFF button, modifying the
mode or adjusting the set temperature to less
O
than 24 C will stop ECO operation.
Under ECO operation, the set temperature
O
should be 24 C or higher. it may result in
insufficient cooling. If you feel uncomfortable,
just press the ECO button again to stop it.
Press this button to enter the energy efficient
mode in a sequence of following:
75% (up to 75% electrical energy consumption)
50% (up to 50% electrical energy consumption)
Previous setting mode
This function is only available under COOL
mode.
Under GEAR operation, the display on the
remote controller will alternate between
electrical energy consumption and set
temperature.
When the unit is off, press and hold
Mode and Swing buttons together for
one second, the louver will open for
a certain angle, which makes it very
convenient for cleaning.
Press and hold Mode and Swing
buttons together for one second to
reset the louver.
Active Clean Function( )
This function is used to clean the air
conditioner evaporator to prevent frosting.
When this function is turned on, the indoor
unit display window appears CL , after 20
to 45 minutes, the unit will turn off automatically
and cancel Active Clean function.
,,
,,
Fan
Boost
Fan
Boost

更改说明：
1. 10月8号更改，只是更改P2页上表格里的
遥控器型号，改成RG10A(B2S)/BGEF。将封底
图纸图号更改.
