Midea MVC-X10 User manual

MVC-X10
USER MANUAL
Cordless Floor Cleaner
All the contents of this Guide have been checked carefully. If there are any printing errors OR
misunderstanding, please contact with Midea Customer service team.
NOTE: It will be compiled into the new version of the guide without any notice if involve the technical
improvements.

01
06
19
15
21
07
02
11
13
INDEX
SAFETY INSTRUCTIONS
SPECIFICATIONS
PRODUCT INTRODUCTION
INSTALLATION
OPERATING INSTRUCTION
CLEANING AND MAINTENANCE
TROUBLESHOOTING
TRADEMARKS, COPYRIGHTS AND LEGAL STATEMENT
Thank you for choosing Midea! Please read this user manual be carefully before
start use this new appliance. To ensure that you know the operate knowledge
and understand more about the product features and functions in a safe way.
CONTENTS

Danger
This symbol indicates that there are dangers to the life and health of
persons due to extremely flammable gas.
Warning of electrical voltage
This symbol indicates that there is a danger to life and health of
persons due to voltage.
Warning
The signal word indicates a hazard with a medium level of risk which, if
not avoided, may result in death or serious injury.
Caution
The signal word indicates a hazard with a low degree of risk which, if
not avoided, may result in minor or moderate injury.
Attention
The signal word indicates important information (e.g. damage to
property), but not danger.
Observe instructions
This symbol indicates that a service technician should only operate and
maintain this appliance in accordance with the operating instructions.
The following safety guidelines are intended to prevent unforeseen risks or damage from
unsafe or incorrect operation of the appliance. Please check the packaging and appliance
on arrival to make sure everything is intact to ensure safe operation. If you find any
damage, please contact the retailer or dealer. Please note modifications or alterations to
the appliance are not allowed for your safety concern. Unintended use may cause
hazards and loss of warranty claims.
Read these operating instructions carefully and attentively before using/commissioning the
unit and keep them in the immediate vicinity of the installation site or unit for later use!
Intended Use
Explanation of Symbols
SAFETY INSTRUCTIONS
02

03
Safety Instructions
This product is suitable for hard floors in the indoor environment, including
waxed floors, stone floors, rubber floors, marble floors, granite floors,
terrazzo floors, solid wood floors, composite floors, bamboo floors, as well
as glazed tiles, ceramic facing tiles and other flat ground. It may not achieve
the best results if the product is used on uneven ground surface.
Do not use this product near or on the surface of flammable and explosive
objects, which may cause fire and explosion.
Do not use this product near a working fireplace or heater to prevent
deformation of the machine casing.
Do not use it to clean high-temperature substances (unextinguished
cigarette butts, matches or hot ash, etc.), ultra-fine substances (such as
lime, cement, wood chips, gypsum powder, ashes, charcoal, etc.), dangerous
substances (such as solvents, descaling agents, etc.), chemical substances
(such as acidic substances, detergents, etc.) and other substances with
uncertain physical properties.
Do not use this floor cleaner to absorb detergent, kerosene, gasoline,
alcohol, paint or perfume, or else it may cause short-circuit, fire or
explosion.
Do not use this floor cleaner to absorb toner used in laser printers and
copiers, or else it may cause fire or explosion.
Do not use this floor cleaner to absorb sharp or large objects, such as glass
shards, small toys, pins, paper clips, stones, plaster and large pieces of
paper, or else it may block up and damage the machine.
Do not use this floor cleaner to absorb any burning or smoking objects,
such as soot from the unextinguished heat source, burning cigarette butts
or matches.
This product can’t be used to clean stains of strong grease, strong viscosity,
or strong dyeing properties such as shoe polish, paint, and pigments.
Do not touch the plug or any live part of the product with wet hands to
avoid the risk of electric shock.
Stop using it if the plug is damaged. Please call our service personnel for
replacement in order to avoid hazards.
Please keep the airflow channels and moving parts of this product away
from long hair, loose clothing, fingers and other parts of the body. Do not
point the suction tube, accessory tip or tool to the eyes or ears, or put them
in the mouth.
Please use the cleaning agent produced by our company and the
manufacturer approved by us.
Do not add other solutions to avoid generating toxic and harmful gases.
If electric leakage, motor over-temperature, abnormal noise, peculiar smell
or weak suction is found during use, stop using it immediately and call our
service personnel.
After using the machine, please clean the wastewater tank in time to
avoid peculiar smell, and keep the ventilation path unobstructed, so as
to avoid obstruction, or else it will cause the suction power to drop, the
motor to heat up, and will aect the service life of the floor cleaner.
After using the machine, please store it in a dry place. A humid place will
aect the insulation and service life of the appliance.
Do not soak or rinse the floor cleaner or floor brush in water.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•

04
Safety Instructions
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved.
Cleaning and user maintenance shall not be made by children without
supervision.
Children should not play with the appliance.
Please check the suction nozzle regularly. If there is a blockage, please clear
it in time to avoid decrease in suction and aecting the performance of the
machine.
Turn o the power before replacing the brush.
In the following situations, do not use the machine, contact to our customer
service center for inspection and repair in time:
1. Obvious damage or abnormal operation caused by drop;
2. Power cord is damaged.
Do not disassemble the enclosed machine without permission. There are no
user serviceable parts. Do not try to change the performance of the
machine, or else it will cause danger.
Using a voltage that does not match the specifications will cause damage to
the product and more likely to cause harm to the user. The correct rated
voltage is marked on the nameplate.
When cleaning the stairs, be extra cautious to prevent falling.
Do not shake or impact the machine up and down to prevent wastewater
from flowing into the motor.
When the motor is working, do not lift or carry the appliance up and down,
and do not put the machine on its side to prevent the wastewater from
entering the motor.
To prevent tip-over, place the machine against the wall after use.
Do not use the floor cleaner before the clean water tank and wastewater
tank are installed properly.
Do not place any small objects in the outlet or block the outlet. Remove any
small objects that may interfere with the flow of air through the outlet to
prevent overheating of the machine.
Do not wet the machine body, or it may cause damage and fire due to short
circuit.
This is only allow to use the docking station for charge the battery.
The plug must be removed from the socket-outlet before cleaning or
maintaining the appliance.
All the technologies and other data in this manual are obtained by our
company or the designated third party testing company, and we reserve the
right of final interpretation.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•

05
Use and Precautions of Washer Detergent
Mix and clean according to instructions. It is recommended to use cleaning
liquid produced by our company or manufacturers approved by our
company, which do not contain acid, alkali solutions or substances harmful
to the environment.
If a large amount of cleaning liquid is added, more foam will be generated
when used, which may infiltrate into the motor and cause danger.
The cleaning liquid should be kept out of reach of children. If the cleaning
liquid accidentally gets into eyes, rinse thoroughly with clean water; in case
of accidental ingestion, seek medical treatment immediately. Follow local
environmental protection regulations when handling wastewater and
cleaning liquid.
•
•
•
READ CAREFULLY AND KEEP FOR FUTURE
REFERENCE

06
SPECIFICATIONS
MVC-X10Product Model
Charging rated input
Charging output
Power
Voltage
Net Weight
Product Size
220-240V~ 50Hz 150W
25V 1A
220W
22.2V
6.83kg
270x235x1160mm

Product introduction
Product Introduction
07
List of Accessories
Turbo Switch Power
Mode
Power ON/OFF
Press to mute
Display
Wastewater tank
release button
Dirty Water
Tank
Voice navigation
Clean tank
release
Clean
water tank
Floor
brush
Brush-roll
cover
Brush-roll
cover latch
Brush-roll
User’s
Manual
Docking station Accessory holder Floor Washer
Detergent
Filter Cleaning brush User’s Manual
Brush-roll

Parts
08
Mode switch button
AUTO
Turbo button
On/O button
Mode switch
button
• Auto mode: the water from the
machine wets the brush-roll to
clean the floor;
• Turbo mode: the speed of the
brush-roll and the amount of water
are increased to forcefully remove
the heavy stains on the floor;
• Quick suction mode: the
machine stops discharging
water, and sucks dry garbage
or residual water;
滚滚长江东逝水
Quick
Turbo
Mode
Turbo
Turbo button2.1.
• Cleaning and disinfecting agent
obtained by means of electrolysis
with a dilute sodium chloride
solution and it is no harm to the
human body and friendly to the
environment.
Electrolyzed Water3.
Electrolyzed
water

Docking Station
09
Charging base
Charging contacts
Base pedal
Power Cord
• After use, put the machine into the charging base for charging, self-cleaning
and drying.
Hot-wind
outlet
Hot-wind
outlet

10
Cleaning brush
•One end is a brush to clean the stubborn dirt attached to the wastewater tank
and the pipe under the ventilation pipe;
Brush
•The other end is a rotating blade to clean the hair wrapped on the roller brush.
Rotating
blade
Accessory holder
•Insert the protruding part of the accessory holder into the groove of the air
drying base;
•It is used to store roller brush, cleaning
brush and filter.
•Pay attention to the proportion of cleaning liquid
added;
•Use the cleaning liquid that comes with the
product.
Cleaning brush
Roller brush
Filter
Protruding part
Groove
Cleaning liquid
清潔刷
滾刷
過濾器
凸出部分
Cleaning
liquid
Groove
凹槽部分

清洗液
Handle Installation and Removal
Installation
11
Installation
Insert the end of the handle into the
port of the main unit along the
vertical direction until there is a
click, which indicates the installation
is successful;
Removal
Remove the rubber from the hole
in the back, insert a screwdriver
or other tools into the hole, and
pull out the handle upward.
Charging Battery
1. Connect the power plug to 220-240V~ power supply;
2. Put the machine upright into the charging base, and
make sure that the bottom of the body completely
falls into the charging base. At this moment, a voice
will prompt “start charging”, and the screen will display
the charging quantity.
3. It takes about 4 hours to fully charge the machine.
When the battery is fully charged, the screen will
go out and the machine will automatically power o.
Attention
Charge the product before the first use.
Handle
Insert
Disassembly
hole

12
Filling clean water tank
Attention
Fill water only to the clean water tank.
Please add water to
clean water tank
Press the clean water tank
button with the thumb and pull
outward to remove the clean
water tank;
1. 2.
3. 4.
5. 6.
Open the top cover of the clean
water tank and fill tap water to
the tank;
Tighten the cover of the clean
water tank;
If deep cleaning is required,
pour cleaning liquid into the
tank according to the
instructions on the bottle;
When the clean water tank is short
of water, there will be voice prompt;
in this case, no water is sprayed in
auto mode, but the quick mode can
be used normally.
Install the clean water tank back
to the body as it is, and the
installation is successful when you
hear a click;

Operating Instruction
13
1.
2.
4.
3.
Attention
After using the machine, it is recommended to place it vertically on the specially
designed charging base.
Turning on and Cleaning
Step on the floor brush and pull the handle, and the machine enters
standby state.
Press the On/O button to
turn on/o the machine.
It enters auto mode after turning
on; you can press the Mode button
to switch to quick suction mode.
Press the Trubo button to enable
or disable this function.
Mode
Turbo
Mode
Turbo
Mode
Turbo
Mode
Turbo
Mode
Turbo
5. Anti-bacteria function
This fuction can only be turned on
in auto or turbo mode.
Anti-bacteria
function

Upright Pause Function
Self-cleaning + Drying Function
14
In working state, you can step on the floor brush to erect the body, the
machine will stop working and enter standby state; it will automatically
turn o after 3 minutes of standby.
Put the machine into the charging base, ensure that it is in the charging
state, step on the pedal of the charging base with your foot, and start
self-cleaning; during the process, if you need to stop the
self-cleaning/drying function, step on the pedal for 3 seconds or press the
On/O button; after self-cleaning, clean the wastewater tank in time; if
there are residual stains on the base, clean it in time.
Self-cleaning: the machine automatically cleans the roller brush and body
pipe (about 2 minutes);
Drying: Keep blowing warm air on the charging base,
and dry the roller brush properly (about 50 minutes);

Cleaning and Maintenance
Attention
15
1. 2.
3. 4.
Waste water detect alarm
After cleaning, it is recommended to place the machine upright in the charging
base; do not place the machine in places with direct sunlight or moisture;
In order not to aect the performance of the machine, it is recommended that
you regularly maintain its parts;
Before cleaning, please disconnect the power supply to stop the machine;
Scrub with water or neutral detergent, wring out the cleaning cloth before
scrubbing to avoid water leaking into the electrical components.
1.
2.
3.
4.
Pull outwards
Press the button of wastewater
tank with your thumb and pull
outward to remove the tank.
As shown in the figure, pour out
the wastewater from the side of
the tank. If there is stubborn dirt
on the inner wall of the tank,
please clean it directly with a
cleaning brush.
Take out the filter from the top
cover of the wastewater tank and
check whether there is any
foreign matter stuck on the
cover.
Filter
Top cover of
wastewater
tank
Hold the tank with one hand
and pull out the top cover of
the tank with the other hand.
Top cover of
wastewater tank
Waste
water tank
Upwards

16
5.
6. 7.
Wash Dry
Dry
Press to remove
Air duct
Press the following elastic
buckles on both sides to
remove the air duct and rinse it
with water; install as it was
after rinsing.
Install the wastewater tank back to
the machine until there is a click
sound; (when installing wastewater
tank, it is recommended to hold the
body with another hand to avoid
tipping over).
Wash with clean water after taking it out, dry it
thoroughly and put it back as it was.

Brush-roll and Cover cleaning
17
Attention
1. 2.
3. 4.
It is recommended that after each use, the roller brush and cover should be
cleaned and dried in time;
If residual stains are found on the suction surface of the floor brush, wipe it
with a wet cloth. Do not rinse it with water.
1.
2.
Press the latch as shown, and
remove the cover and the roller
brush;
Remove the cover and the roller
brush, open the rotating blade of
the cleaning brush, and remove
the hair and other entanglements
on the roller brush;
Remove the small roller brush
and large roller brush in the
direction shown in the figure
and rinse the roller brushes and
cover with clean water;
After cleaning, install the small
and large roller brushes in turn
according to the direction shown
in the figure. The installation is
successful when you hear a click
sound.
Small
brush-roll
Large
brush-roll
Handle

18
5.
6.
If residual stains are found in the suction port of the floor brush (exposed
part after the roller brush is removed), wipe it; do not rinse with water;
After cleaning, align the cover of the roller brush and one end of the
roller brush with the driven wheel of the floor brush motor, and then
align the latch of the cover of the roller brush with the latch slot of
the cover of the roller brush. The installation is successful when you
hear a click sound.
Suction port of
floor brush
Driven
wheel

Troubleshooting
Please check the following table in case of any abnormal conditions when using the product.
Possible cause SolutionProblem
The floor cleaner
does not work
Suction power is
weakened
Noise when the fan
is running
The roller brush is entangled
by hair or stuck by foreign
objects
Remove the roller brush to
clean and reinstall
●
Roller brush, roller brush
cover, or wastewater tank is
not installed in place
Remove all components
and reinstall them
●
Foreign matter in the suction
port of the floor brush or in
the pipe
Wipe the suction port and
clean the pipe under the air
duct
●
Wastewater tank is full Clean the wastewater tank
●
Low battery voltage Charge
●
Wastewater tank is full Clean the Wastewater tank
●
Air duct isn’t installed Install air duct
●
Water shortage in clean water
tank
Add water to clean water
tank
●
Roller brush is entangled by
hair
Clean the roller brush
●
Wastewater tank filter isn’t
installed
Install filter
●
Floor brush suction or pipe
blockage
Wipe the floor brush suction
and clean the pipe under the
air duct
●
There is garbage blockage in
the pipe
Clean the pipes under the
wastewater tank
●
There is hair accumulation on
the roller shaft
Remove the roller brush to
clean the shaft
●
Wastewater tank filter is
dirty
Clean the filter and dry
thoroughly before installation
●
19
