Midea VCS7P User manual

Vacuum CleCleaner
INSTRUCTION MANUAL
VCS7P
PLEASE R T
MANUAL CCAREFULLY
BEFORE SI AAND
KEEP IIT PROPERLY FOR
FUTURE SUSE
EAD HE
USING

STRUCTURE OF THE
PRODUCT
01
Main body
Dust container
Nozzle
Power Cord
Power switch
Accessories list:
Instruction
Manual
Manual
Tips:
Accessories can be connect with extension tube/Main body when
cleaning high position.
關
開
Extension tube
Round
Brush
Crevice
Tool
还差一
个小的
床吸

02
SAFETY DIRECTION
· If the supply cord is damaged, It must be replaced by the manufacturer,
its service agent or qualified persons in order to avoid a hazard.
· This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved.
· Cleaning and user maintenance shall not be made by children without
supervision.
· Children should not play with the appliance.
· The appliance is only to be used with the power supply unit provided with
the appliance.
· The appliance must only be supplied at safety extra low voltage
corresponding to the marking on the appliance.
· The instructions for appliances incorporating a battery that contains
materials that are hazardous to the environment shall give details on how
to remove the battery and shall state that
– the battery must be removed from the appliance before it is scrapped;
– the appliance must be disconnected from the supply mains when
removing the battery;
– the battery is to be disposed of safely.
· The instructions for appliances incorporating batteries that are intended
to be replaced by the user shall include the following:
– the type reference of the battery;
– the orientation of the battery with regard to polarity;
– the method of replacing batteries;
– details regarding safe disposal of used batteries;
– warning against using non-rechargeable batteries;
– how to deal with leaking batteries.
· The plug must be removed from the socket-outlet before cleaning or
maintaining the appliance.
· CAUTION: This hose contains electrical connections:
– do not use to suck up water (for vacuum cleaners only);
– do not immerse in water for cleaning;
– the hose shold be checked regularly and must not be used if damaged.

· Please keep the vacuum cleaner in laid down position when storing.
The vacuum cleaner can't stand by itself, please put it to the base stand
after use.
· When you pause using the vacuum cleaner, please put it to the base stand
or leave it in laid down position.

HOW TO USE
03
Note:
To avoid block the suction power, please clear the large garbage, for example
paper, cloth ,etc.
Ensure turn off the machine, before insert the plug into the socket.
Operation instruction
1. Insert the plug to AC 220~240V power socket.
2. Push forward power switch to turn ON.
3. Pull backward power switch to turn OFF.
/開
/關
/關
ON
OFF
/開
/開
/關

MAINTENANCE
04
Dust container disassembly and clean
Tips:
To keep the suction power of cleaner, please clean the dust in it regularly.
1. Knob down the dust container release button, take down the cup.
2. Take out the cyclone from dust cup and release dust.
3. Disassemble cyclone and clean, all parts are washable.
Max Line
Dust container
release button

4. After airing all parts completely, assemble them according to disassembly
steps.
Clean and maintain nozzle
Note:
1. To avoid aect the normal operation of nozzle, when wheels are dusty,
please clean and maintain them.
2. When disassemble and main brush, please make sure it’s not working.
3. Push button and take o the nozzle.
Tips:
Don’t suggest to wash the nozzle.
If the wheels were tangled by hair, please use scissor or knife to clean.
Push

PRODUCT PARAMETERS
05
Product Technical Parameters
Model
Rated Voltage
Rated Power
Suction Power
Net Weight
Product Size L x W x H
Capacity
VCS7P
220-240V~ 50/60Hz
450W
50W
1.9kg
200 x 250 x 1100mm
0.4L
