Midwest Feline Nuvo 139R-BL User manual

Unwrap and remove all parts from the box. Keep the box and packing material until the product is assembled.
In case of return or exchange, failure to return product in similar condition as received could result in limited
reimbursement. Please save sales receipt as proof of purchase for warranty purposes. Check to ensure you
have all the parts below. If you discover any parts are missing, immediately call our toll-free service helpline at
1-800-428-8560 (Monday - Friday 9 a.m. to 4 p.m. EST) or email customer service at
[email protected].
IMPORTANT INFORMATION
PART IDENTIFICATION
Assembly Instructions for Model Number 139R-BL
Resort
A - Base
B - Oval Platform (2)
C - Hoop Hammock
D - Hooded Bed
Allen Wrench included for
assembly
E - ong Post with Screw
F - Short Post with Screw (3)
G - ong Post (without screw)
H - Short Post (without screw)
I - Bolt (2)
1.9in (50mm)
J - Short Dual Thread Screw
2.75in (70mm)
K - ong Dual Thread Screw (2)
3.15in (80mm)
- Bolt Cap
A EMBLY IN TRUCTION
Pre-assembly:
1. Posts with pre-attached screw comes with black cap attached. Remove black cap before
assembly.
2. Hoop Hammock (C) uses a pillow; this does is not come attached. Place pillow in hammock after
securing hammock in Step 3.
3. Hooded Bed (D) comes in two parts; a circular wooden board and the faux fur shell. Attach the fur shell to
woooden board, using the draw strings. Strings can be tighten to place Shell opening in desired location.
800-428-8560
midwesthomes4pets.com
P.O. Bo 1031
Muncie, Indiana 47308
by
TM
TM

Attach a ong Post with Screw (E) and two of the
Short Posts with Screw (F) to the Base (A). Insert
the pre-attached screws into the Base and rotate
posts until secure.
Place one of the Oval Platforms (B) on the Short
Posts. Secure the Oval Platform with a Bolt (I) and
a ong Dual Thread Screw (K), Bolt attaches to
front (rounded edge of base) and Screw attaches in
back (corner of base). Tighten bolt with Allen
Wrench and cover with Bolt Cap ( ). Tighten the
Screw until bottom threads disappear and top
threads stick out.
Attach the ong Post (G) to the Platform
placing on top of the Screw and rotating until
secure.
Place the Hoop Hammock (C) on top of the ong
Post that is attached to the Base. Insert Short Dual
Thread Screw (J) through the top of the Scoop and
tighten until bottom threads disappear.
Attach the Short Post (H) to the Scoop and ong
Post by placing the post on the Screw and
rotating until secure.
Place remaining Oval Platform (B) on top of ong
Post and Short Post. Use a Bolt (I) to attach
Platform to ong Post, tighten with Allen Wrench
and cover with Bolt Cap ( ).
Insert a ong Dual Thread Screw (K) through the
Oval Platform through the Short Post, tighten until
bottom threads disappear. Attach Short Post with
Screw (F) to the Oval Platform by placing on Screw
and rotating until secure.
Attach Hooded Bed (D) to Short Post by placing on
top of Post’s screw and rotate until secure.
1.
2.
3.
4.
Bolt (I)
Long Dual
Thread Screw (K)
Short Dual
Thread Screw (J)
Bolt (I)
Long Dual
Thread Screw (K)

TOLL-FREE ERVICE HELPLINE: If you have any problems or questions with the assembly of your new
Feline Nuvo Cat Furniture: Resort, call our Service Helpline at: 1-800-428-8560 between 9:00 a.m. and 4:00
p.m. (EST) Monday through Friday.
