Miele PG 8063 User manual

Operating instructions
Cleaning machine for air regulators
and breathing masks
PG8063
To avoid the risk of accidents or damage
to the machine, it is essential to read
these instructions before it is installed
and used for the first time.
en - GB
M.-Nr. 11 463 821

2

Contents
3
Notes about these instructions...................................................................................... 7
Definition of terms ............................................................................................................. 7
Intended use .................................................................................................................... 8
Guide to the machine...................................................................................................... 9
Machine overview.............................................................................................................. 9
Control panel..................................................................................................................... 10
LEDs in the buttons........................................................................................................... 11
User profiles..................................................................................................................... 12
Warning and Safety instructions.................................................................................... 13
Symbols on the machine................................................................................................... 18
Using the machine........................................................................................................... 19
Display illustrations............................................................................................................ 19
Switching on...................................................................................................................... 20
Switching off...................................................................................................................... 20
Auto-off function ............................................................................................................... 20
Ready for use .................................................................................................................... 20
Display interface................................................................................................................ 21
Menu operation ................................................................................................................. 21
Symbols on the display ..................................................................................................... 22
Settings in the menu ......................................................................................................... 23
Options.......................................................................................................................... 23
Opening and closing the door........................................................................................ 24
Opening the door .............................................................................................................. 24
Closing the door................................................................................................................ 24
Water softener ................................................................................................................. 25
Water hardness ................................................................................................................. 25
Setting the water hardness level ....................................................................................... 26
Filling the salt reservoir...................................................................................................... 28
Add salt reminder .............................................................................................................. 30
Areas of application ........................................................................................................ 31
Load carriers ..................................................................................................................... 31
Air regulators ................................................................................................................. 31
Breathing masks............................................................................................................ 32
Colour coding................................................................................................................ 32
Carrier frames for compressed air units........................................................................ 33
Adjusting the upper basket ........................................................................................... 34
Preparing the load ............................................................................................................. 36
Air regulators ..................................................................................................................... 38
Preparing the insert ....................................................................................................... 38
Pre-cleaning and dismantling air regulators.................................................................. 39
Protective caps on the quick-release coupling ............................................................. 39
Connecting the medium-pressure hose ........................................................................ 39
Inserting air regulators................................................................................................... 40
Breathing masks................................................................................................................ 43
Pre-cleaning breathing masks....................................................................................... 43
Arranging breathing masks ........................................................................................... 44

Contents
4
Carrier frames for compressed air units............................................................................ 45
Pre-cleaning the carrier frame ....................................................................................... 45
Inserting the carrier frame ............................................................................................. 45
After reprocessing ............................................................................................................. 46
Air regulators ................................................................................................................. 46
Breathing masks............................................................................................................ 47
Carrier frames for compressed air units........................................................................ 47
Adding and dispensing chemical agents ...................................................................... 48
Dispensing systems .......................................................................................................... 48
Dispensing module for liquid cleaning agent ................................................................ 48
DOS modules .................................................................................................................... 49
Connecting a DOS module ........................................................................................... 49
Dispensing liquids ......................................................................................................... 49
Rinsing agent..................................................................................................................... 50
Filling the reservoir ........................................................................................................ 50
Cleaning agent .................................................................................................................. 52
Replenishing liquid cleaning agent................................................................................ 52
Refill indicator................................................................................................................ 53
Dispensing liquid cleaning agent .................................................................................. 53
Powder cleaning agents ................................................................................................ 54
Dispensing powder cleaning agents ............................................................................. 54
Operation.......................................................................................................................... 56
Selecting a programme ..................................................................................................... 56
Starting a programme ....................................................................................................... 56
Starting a programme using delay start ........................................................................ 56
Programme sequence indicator ........................................................................................ 58
At the end of the programme ............................................................................................ 58
Interrupting a programme.................................................................................................. 59
Cancelling a programme ................................................................................................... 59
Programme cancelled due to a fault ............................................................................. 59
Cancelling a programme manually ................................................................................ 59
Settings ......................................................................................................................... 60
Delay start ......................................................................................................................... 61
DOS venting ...................................................................................................................... 62
Language ....................................................................................................................... 63
Date ................................................................................................................................... 64
Time of day........................................................................................................................ 66
Volume............................................................................................................................... 69
Further settings .............................................................................................................. 70
Code.................................................................................................................................. 72
Enter code ..................................................................................................................... 72
Release.......................................................................................................................... 73
Log book ........................................................................................................................... 75
Temperature unit................................................................................................................ 76
Moving a programme: allocating programme selection buttons....................................... 77

Contents
5
Additional functions........................................................................................................... 78
Reset ............................................................................................................................. 79
Increased water level..................................................................................................... 80
Interim rinse................................................................................................................... 80
Dispensing systems ...................................................................................................... 81
Temperature / time ........................................................................................................ 85
Release programme .......................................................................................................... 87
Water hardness ................................................................................................................. 87
Display: Temperature......................................................................................................... 88
Display brightness and contrast........................................................................................ 89
Switch off after .................................................................................................................. 90
Ready for operation....................................................................................................... 90
Auto-off function ........................................................................................................... 90
Switching off after activating......................................................................................... 91
Factory default................................................................................................................... 92
Software version................................................................................................................ 92
Maintenance .................................................................................................................... 93
Periodic checks ................................................................................................................. 93
Cleaning the filters in the wash cabinet ............................................................................ 94
Cleaning the spray arms.................................................................................................... 96
Cleaning the machine........................................................................................................ 98
Cleaning the control panel ............................................................................................ 98
Cleaning the door and the door seal............................................................................. 98
Cleaning the wash chamber.......................................................................................... 98
Cleaning the door front ................................................................................................. 98
Preventing re-soiling...................................................................................................... 98
Checking the load carriers ................................................................................................ 99
Problem solving guide .................................................................................................... 100
Technical faults and messages ......................................................................................... 100
Dispensing/Dispensing systems ....................................................................................... 101
Insufficient salt/Water softener.......................................................................................... 103
Cancel with fault code....................................................................................................... 104
Process-related faults and messages ............................................................................... 105
Unsatisfactory cleaning and corrosion.............................................................................. 106
Water inlet and drainage ................................................................................................... 107
Noises................................................................................................................................ 108
Problem solving guide .................................................................................................... 109
Cleaning the drain pump and non-return valve................................................................. 109
Cleaning the water intake filters ........................................................................................ 110
Retrofitting the large-surface filter................................................................................. 110
After sales service........................................................................................................... 111
Contacting the Customer Service Department ................................................................. 111
Software version................................................................................................................ 112
Installation........................................................................................................................ 113
Installation and levelling .................................................................................................... 113
Building under a continuous worktop ............................................................................... 114
Removing the lid........................................................................................................... 114
Electromagnetic compatibility (EMC) ................................................................................ 115

Contents
6
Electrical connection ...................................................................................................... 116
Equipotential bonding connection .................................................................................... 116
Peak-load negotiation ....................................................................................................... 117
Plumbing .......................................................................................................................... 118
Connection to the water supply ........................................................................................ 118
Retrofitting the large-surface filter................................................................................. 119
Connecting the drain hose ................................................................................................ 121
Programme chart ............................................................................................................ 122
Technical data.................................................................................................................. 124
Caring for the environment ............................................................................................ 125
Disposal of the packing material ...................................................................................... 125

Notes about these instructions
7
Important warnings
Information which is important for safety is highlighted in a thick
framed box with a warning symbol. This alerts you to the potential
danger of injury to people or damage to property.
Read these warning notes carefully and observe the procedural
instructions and codes of practice they describe.
Notes
Information of particular importance that must be observed is
highlighted in a thick framed box.
Additional information and comments
Additional information and comments are contained in a simple
frame.
Operating steps
Operating steps are indicated by a black square bullet point.
Example:
 Select an option using the arrow buttons and save your choice with
OK.
Display
Certain functions are shown in display messages using the same font
as that used for the function itself in the display.
Example:
Settings  menu.
Definition of terms
Cleaning machine The dishwasher is referred to as “the cleaning machine” in these op-
erating instructions.
Load items The term “load items” is used wherever the items to be processed are
not defined in any further detail.
Wash water The term “wash water” is used for the mixture of water and process
chemicals.

Intended use
8
This Miele cleaning machine can be used to clean, rinse and chemic-
ally disinfect breathing apparatus for professional use that can be re-
processed by machine, such as air regulators, breathing masks and
carrier frames for compressed air units. Information issued by the
manufacturers of the breathing apparatus must be heeded.
The cleaning machine may only be used with Miele baskets, carriers
and accessories approved for the machine and designed for the
breathing apparatus.
The cleaning machine may not be used with organic solvents or in-
flammable or foaming liquids.
Soiling, such as ash, sand, wax, lubricants or paint, must not be in-
troduced into the cleaning machine.
The breathing apparatus must only be contaminated with the usual
soiling from fire brigade operations or exercises. Manual pre-cleaning
is required if the apparatus is heavily soiled with soot.
The cleaning machine may not be used for breathing apparatus that
has not been approved for machine reprocessing by the manufac-
turer.
The cleaning machine may not be used for reprocessing any products
other than breathing apparatus, especially medical devices.
Disposable items, such as single-use masks or breathing filters, must
not be reprocessed.

Guide to the machine
9
Machine overview
aDoor lock
bTest point for performance checks
(top, front right; only visible with lid re-
moved)
cUpper machine spray arm
dRails for baskets and mobile units
eLower machine spray arm
fData plate
gContainer for neutralising agent or rinsing
agent
hSalt container
iDispenser for powder cleaning agent
jFilter combination
kPlinth cover
lOn the back:
– Second data plate
– Electrical and water connections
– Connection for an external dispensing
module (DOS module)
mWater connections for mobile units and
baskets

Guide to the machine
10
Control panel
a On/Off button
For switching the machine on and off.
b,  and  buttons
Programme selection buttons.
Can be configured.
c Programme list button
For accessing the list of all programmes.
dDisplay
User interface and programme sequence display.
e and  arrow buttons
For navigating within the display.
f Cancel button
For cancelling a process
(not for cancelling programmes).
gStart/Stop button
For starting or cancelling a programme.
hOK button
For selecting or confirming entries in the user interface
(acknowledge or save).
i PC/Optical interface
This is used by Miele Service technicians to run diagnostic checks
and can also be used to update programming data in the future.

Guide to the machine
11
LEDs in the buttons
The buttons on the control panel have LEDs (Light Emitting Diodes)
that indicate the status of the machine.
Button LED Status
 button ON The machine is switched on.
FLASHES The machine is ready for use.
OFF The machine is switched off.
Programme
selection
buttons
, 
and 
ON The respective programme has been se-
lected. At the end of the programme the
LED will remain lit until a different pro-
gramme is selected.
OFF The programme is not selected or the
programme settings are being selected.
 button ON A programme has been selected from
the programme list with this button. At
the end of the programme the LED will
remain lit until a different programme is
selected.
OFF No programme has been selected from
the list with this button or the pro-
gramme settings are being selected.
Start/Stop
button
ON Programme running.
FLASHES
GREEN
A programme has been selected but not
yet started.
FLASHES
RED
A fault has occurred (see “Problem solv-
ing guide”).
OFF A programme has finished.

User profiles
12
Daily operators
For day-to-day use, operators must be instructed on the basic func-
tions and how to load the cleaning machine and must also be trained
regularly. In addition, operators must be trained in line with the na-
tional requirements for reprocessing personal protective equipment,
such as air regulators and breathing masks.
Day-to-day work is carried out using the user level and in the Settings
 menu. The menu is freely accessible to all users.
Administration
More advanced tasks, e.g. interrupting or cancelling a programme,
require more detailed knowledge about the machine reprocessing of
personal protective equipment and the process chemicals used.
Alterations to the reprocessing process or adaptations to the cleaning
machine, e.g. to accessories used or on-site conditions, require addi-
tional specific knowledge of the machine.
Validation processes assume specialised knowledge of the machine
reprocessing of personal protective equipment, of the processes in-
volved and of applicable standards and legislation.
The Further settings menu incorporates all administrative processes
and settings. This is protected from unauthorised access by a PIN
code.

Warning and Safety instructions
13
This machine complies with all statutory safety requirements. Inap-
propriate use can, however, lead to personal injury and material
damage.
Read these instructions carefully before using it for the first time to
avoid the risk of accidents and damage to the machine.
Keep these instructions in a safe place where they are accessible
to users at all times.
Correct application
 Use of the machine is only permitted for the applications expressly
approved in the operating instructions. Alterations or conversion of
the machine, or using it for purposes other than those for which it
was intended, are not permitted and could be dangerous.
The reprocessing procedures are only designed for air regulators and
breathing masks declared by the manufacturer as reprocessable. The
information provided by the manufacturer of the load items must be
observed.
 This machine is intended for indoor use only.
Risk of injury
Please pay attention to the following notes to avoid injury
 The machine may only be installed, commissioned, repaired and
maintained by the Miele Customer Service Department or a suitably
qualified service technician. A Miele service contract is recommended
to ensure full compliance with the normative and regulatory provi-
sions. Incorrect repairs can cause considerable danger to users.
 Do not install the machine in an area where there is any risk of ex-
plosion or of freezing conditions.
 Some metal parts pose a risk of injury/being cut. Wear cut-resist-
ant protective gloves when transporting and setting up the machine.
 In order to reduce the risk of water damage, the area around the
machine should be limited to furniture and fittings that are designed
for use in commercial environments.
 If the machine is built under, it must only be installed under a con-
tinuous worktop run which is firmly secured to adjacent units to im-
prove stability.
 The electrical safety of this machine can only be guaranteed when
correctly earthed. It is essential that this standard safety requirement
is met. If in any doubt, please have the on-site wiring system tested
by a qualified electrician. Miele cannot be held liable for the con-
sequences of an inadequate earthing system
(e.g. electric shock).
 A damaged or leaking machine could be dangerous and comprom-
ise your safety. Disconnect the machine from the mains immediately
and call the Miele Service Department.

Warning and Safety instructions
14
 Label cleaning machines which have been taken out of operation
and secure them against being switched on again without authorisa-
tion. The cleaning machine may only be put back into operation once
it has been successfully repaired by the Miele Customer Service De-
partment or by an appropriately qualified specialist.
 Personnel operating the machine should be trained regularly. Un-
trained personnel must not be allowed access to the machine or its
controls.
 Only use process chemicals which have been approved by their
manufacturer for the relevant application. The manufacturer of the
process chemicals is liable for any negative influences on the material
of the load and the machine.
 Take care when handling chemical agents. These may contain irrit-
ant, corrosive or toxic ingredients.
Please observe the chemical agent manufacturer's safety instructions
and safety data sheets.
Wear protective gloves and goggles.
 The machine is designed for operation with water and recommen-
ded additive chemical agents only. Organic solvents and flammable
liquid agents must not be used in it.
This could cause an explosion, damage rubber or plastic components
in the machine and cause liquids to leak out of it.
 The water in the cabinet must not be used as drinking water.
 Take care not to inhale powder agents. Chemical agents can cause
chemical burns in the mouth and throat or lead to asphyxiation.
 Do not lift the machine by protruding parts such as the control
panel or the opened service flap as these could be damaged or torn
off.
 Do not sit or lean on the opened door. This could cause the ma-
chine to tip up and be damaged or cause an injury.
 When using this machine in the higher temperature ranges, be es-
pecially careful not to scald or burn yourself or come into contact with
irritant substances when opening the door. Where disinfecting agents
are used there is a danger of inhaling toxic fumes.
 Should personnel accidentally come into contact with toxic va-
pours or chemical agents, follow the emergency instructions given in
the manufacturer's safety data sheets.
 Allow baskets, modules, inserts and the load to cool down before
removing them. Empty any remaining water into the wash cabinet or
an on-site slops basin before removing items.
 Never clean the machine or near vicinity with a water hose or a
pressure washer.

Warning and Safety instructions
15
 The machine must be disconnected from the mains electricity sup-
ply before any maintenance or repair work is carried out.
Quality assurance
The following points should be observed to assist in maintaining
quality standards when reprocessing air regulators and breathing
masks and to avoid damage to the load items being cleaned.
 If it is necessary to interrupt a programme in exceptional circum-
stances, this may only be done by authorised personnel.
 Make sure items being washed are suitable for machine repro-
cessing and are in good condition. Plastic items must be thermally
stable. Nickel plated items and aluminium items can be machine pro-
cessed using special procedures only.
Items containing iron, and soiling containing residual rust must not be
placed in the cabinet.
 Chemical agents can, in certain circumstances, cause damage to
the machine. Always follow the recommendations of the chemical
agent manufacturer.
In case of damage or doubt about compatibility, please contact
Miele.
 Abrasive substances must not be placed in the machine as they
could cause damage to the mechanical components of the water
supply. Any residues of abrasive substances on items to be washed
must be removed without trace before reprocessing in the machine.
 Pre-treatments with cleaning or disinfecting agents can create
foam, as can certain types of soiling and chemical agents. Foam can
have an adverse effect on the cleaning and disinfection result.
 Processes must be set up such that foam cannot escape from the
wash cabinet. It would hinder the correct functioning of the machine.
 The process used must be monitored on a regular basis by the su-
pervisor to check foaming levels.
 To avoid the risk of damage to the machine and any accessories
used with it caused by chemical agents, soiling and any reaction
between the two please read the notes in “Chemical processes and
technology”.
 When using process chemicals, always consult the instructions is-
sued by individual manufacturers. Process chemicals must only be
used for the purpose they are designed for by the manufacturer to
avoid any material damage or the occurrence of very strong chemical
reactions (e.g. oxyhydrogen explosion).
 Always follow the relevant manufacturer's instructions on storage
and disposal of chemical agents.

Warning and Safety instructions
16
 In critical applications where very stringent requirements have to
be met, it is strongly recommended that all the relevant factors for the
process, such as chemical agents, water quality etc. are discussed
with the Miele Application Technology specialists.
 Load carriers which hold the load items must be used only as in-
tended.
Lumened load items must be thoroughly cleaned, internally and ex-
ternally, with the wash water.
 Place small and light items in a small-part basket so that they do
not block the spray arms.
 The amount of residual solvents and acids on items going into the
cabinet should be minimal.
There should be no more than a trace of any solvents with a flash
point of below 21°C.
 Chlorous solutions, in particular hydrochloric acid, must not be
placed in the cabinet.
 Ensure that solutions or steam containing chlorides or hydrochloric
acid do not come into contact with the stainless steel outer casing of
the machine in order to avoid any damage through corrosion.
 After any plumbing work the water pipework to the machine will
need to be vented. If this is not done, components can be damaged.
 The gaps between a built-in machine and adjacent cabinetry must
not be filled e.g. with silicone sealant as this could compromise the
ventilation to the circulation pump.
 Follow the installation instructions in the operating and installation
instructions.

Warning and Safety instructions
17
Safety with children
 Children must be supervised in the vicinity of the machine. Do not
allow children to play with the machine. They could get locked inside
it.
 Children must not use the machine.
 Keep children away from chemical agents. These can cause burn-
ing in the mouth, nose and throat if swallowed, or inhibit breathing.
Keep children away from the machine when the door is open. There
could still be residual chemical agent in the cabinet. Observe the
safety data sheets for the chemical agent and seek medical advice
immediately if a child has swallowed chemical agent or got it in the
eyes.
Use of components and accessories
 Only Miele accessories should be connected to this machine. They
must be suitable for the application they are required for. Consult
Miele for details on the type of accessories that can be used.
 Only use Miele load carriers. Using load carriers made by other
manufacturers or making modifications to Miele accessories can res-
ult in unsatisfactory cleaning results.

Warning and Safety instructions
18
Symbols on the machine
Warning:
Observe the operating instructions!
Warning:
Danger of electric shock!
Warning: Hot surfaces:
It can be very hot inside the wash cabinet
when the door is opened!
Risk of being cut:
Wear cut-resistant protective gloves when
transporting and setting up the machine!
Disposing of your old machine
 Please note that the machine may contain contamination from
blood and other bodily fluids as well as substances which are harmful
to the health and environment, and must be decontaminated before
disposal.
For environmental and safety reasons, dispose of all process chem-
ical residues in accordance with safety regulations (wear safety
goggles and gloves).
Remove or disable the door lock prior to disposal of the machine, so
that children cannot become trapped inside. Then make appropriate
arrangements for safe disposal of the machine.

Using the machine
19
Control panel
The machine is operated exclusively by the buttons located on the
stainless steel surfaces either side of the display. The display is not a
touch screen.
A light touch on the relevant button is sufficient to operate the func-
tions. The buttons can also be pressed and held for approx. 20
seconds.
Display illustrations
All display illustrations shown in these operating instructions are ex-
amples which can be different from the actual display screens shown.
Temperature
Duration Min24
60 °C
Sf Special
The control buttons, with the exception of the  and the Start/Stop
buttons, are shown next to the display.

Using the machine
20
Switching on
The machine must be connected to the electrical supply.
Press the button until the button’s LED lights up.
After that, the display shows the following:
PG 8063
As soon as the machine is ready for operation, the display changes to
show the last selected programme, e.g.:
Temperature
Duration Min24
60 °C
Sf Special
If the machine is being used for the first time, or if the factory default
settings have been reinstated, some basic parameters, e.g. lan-
guage, date, time, etc., must first be set. To enable this, the display
automatically changes to the relevant screen.
Switching off
Press the button.
Auto-off function
To save energy, the machine has an automatic switch-off function
(Auto-off function). If the machine has not been used for a specific
time period, it switches itself off automatically, see “Further settings/
Switch off after”.
Use the button to switch the machine on again.
Ready for use
When it is ready for use, the machine remains switched on, the
button flashes and the time is shown on the display. Pressing any
button reactivates the machine. Standby can be switched on and off
as required, see “Further settings/Switch off after”.
