Miele Stick User manual

en Operating Instructions Stick Vacuum Cleaner
fr Mode d'emploi Aspirateur-balai
M.-Nr. 10 081 730
HS07

2
en ....................................................................................................................... 5
fr ......................................................................................................................... 27

3
Only Miele FilterBags, filters and accessories with
the "Original Miele" logo can be used with this
vacuum. Only then can the suction power of the
vacuum cleaner reach its optimum potential creating
the best possible cleaning results.
USE OF NON-MIELE COMPONENTS MAY VOID
THE WARRANTY.
,The use of FilterBags made of paper or a similar
material, or FilterBags with a cardboard retaining
plate can lead to serious damage to the vacuum
cleaner and may void the warranty, just as with the
use of FilterBags without the "Original Miele" logo.
The "Original Miele" Logo will appear on the
packaging or directly on the FilterBag.
Purchasing new FilterBags and filters
Original Miele FilterBags and filters can be purchased
from an authorized Miele vacuum dealer or by visiting the
Miele store at www.mieleusa.com.

en - Contents
4
IMPORTANT SAFETY INSTRUCTIONS ................................................................ 5
Appliance description ......................................................................................... 10
Caring for the environment ................................................................................ 12
References to illustrations.................................................................................. 13
Preparing for use................................................................................................. 13
Use........................................................................................................................ 14
Setting down and storing the vacuum cleaner................................................. 15
Maintenance ........................................................................................................ 15
Purchasing new FilterBags and filters ................................................................... 15
Ordering the correct FilterBags and filters ............................................................ 15
When to change the FilterBag .............................................................................. 16
How the FilterBag change indicator works ........................................................... 16
How to replace the FilterBag ................................................................................ 16
When to change the motor protection filter........................................................... 17
How to change the motor protection filter ........................................................... 17
When to replace the exhaust filter......................................................................... 17
How to replace the AirClean exhaust filter ........................................................... 17
How to replace an Active AirClean or an AirClean Plus exhaust filter .................. 17
Replacing one type of exhaust filter with another................................................. 18
When to change the thread catchers .................................................................... 18
How to replace the thread lifters .......................................................................... 18
Cleaning the roller on the AllTeQ floorhead .......................................................... 18
Cleaning and care ............................................................................................... 18
Frequently Asked Questions .............................................................................. 20
Technical Service................................................................................................. 21
Contact in case of fault ......................................................................................... 21
Warranty ................................................................................................................ 21
Optional accessories .......................................................................................... 21
Limited Warranty - Vacuum Cleaners USA ....................................................... 24

en - IMPORTANT SAFETY INSTRUCTIONS
5
This vacuum cleaner complies with current safety re-
quirements. Inappropriate use can, however, lead to per-
sonal injury and damage to property.
To avoid the risk of accidents and damage to the vacuum
cleaner, please read the operating instructions carefully
before using it for the first time. They contain important
information on its safety, operation and maintenance.
Keep these operating instructions in a safe place and
pass them on to any future user.
Always disconnect the vacuum cleaner from the power
supply when you have finished using it, before changing
any accessories, as well as for maintenance work and
cleaning. Turn the vacuum cleaner off and unplug it.
Correct use
 This vacuum cleaner is intended for cleaning flooring in
domestic households and similar residential environments.
 This vacuum cleaner can be used for all normal cleaning
of carpets, rugs and hard flooring.
 This vacuum cleaner is not intended for outdoor use.
 This vacuum cleaner is intended for use at altitudes of
up to 1300ft (4000m) above sea level.
 The vacuum cleaner must only be used to vacuum dry
floor surfaces. Do not use on people and animals. Any
other usage, modification or alteration is not supported by
the manufacturer and could be dangerous.

en - IMPORTANT SAFETY INSTRUCTIONS
6
 Persons which lack physical, sensory or mental abilities
or experience with the machine should not use it without
supervision or instruction by a responsible person.
Safety with children
 Danger of suffocation! Ensure that any plastic wrap-
pings, bags, etc. are disposed of safely and kept out of the
reach of children.
 Do not allow the vacuum cleaner to be used as a toy.
Close attention is necessary when used near children.
Technical safety
 Before using the vacuum cleaner and its accessories,
check for any visible signs of damage. Do not use a dam-
aged appliance.
 Ensure that the connection data on the data plate of the
vacuum cleaner (voltage and frequency) match the house-
hold power supply. Without modifications, the vacuum
cleaner is suited for 50Hz or 60Hz.
 The electrical outlet must be fitted with a 15 A fuse.
 Reliable and safe operation of this vacuum cleaner can
only be assured if it has been connected to the electricity
supply.

en - IMPORTANT SAFETY INSTRUCTIONS
7
 In areas with fluctuating power supplies the vacuum
cleaner may suffer a temporary drop in power. If the line
impedance is greater than 0.457ohm at the connection
point to the public power network, additional measures
may be required before the vacuum cleaner can be prop-
erly operated at this connection. The line impedance can
be requested from the local power supply company.
 Repairs must only be performed by an authorized ser-
vice agent in accordance with national and local safety
regulations. Unauthorized repairs could cause injury or ma-
chine damage. Otherwise the warranty will be void.
 Do not pull or carry the vacuum cleaner by the power
cord, and be careful not to damage the cord when with-
drawing the plug from the socket. Keep the cord away
from sharp edges and do not let it get pinched, for exam-
ple, under a door. Avoid running the vacuum cleaner over
the cord. This could damage the cord, plug or socket. The
appliance must not be used if any of these have suffered
damage.
 Do not use the vacuum cleaner if the power cord is
damaged. If the power cord is damaged it must be re-
placed with an original cable. For safety reasons this must
only be done by Miele Technical Service or a Miele autho-
rized service technician.
 The socket on the vacuum cleaner (depending on
model) must only be used for the Miele Electrobrushes
listed in these operating instructions.

en - IMPORTANT SAFETY INSTRUCTIONS
8
 Do not let the vacuum cleaner get wet. Clean only with a
dry cloth or slightly damp cloth when disconnected from
the electrical supply.
 Repairs should only be carried out by a Miele-authorized
service technician. Repairs and other work by unqualified
persons can cause considerable danger to users.
 Defective components should be replaced by Miele orig-
inal parts only. Only with these parts can the manufacturer
guarantee the safety of the appliance.
Proper use
 To avoid the risk of damage, do not use the vacuum
cleaner without the FilterBag, dust compartment filter and
exhaust filter in place.
 The dust compartment cover will not close without a Fil-
terBag inserted. Do not force it.
 Do not vacuum at head height and do not let the suction
get anywhere near a person's head.
 Do not vacuum up anything which has been burning or
smoking, e.g., cigarettes, ashes or hot ash, whether glow-
ing or apparently extinguished.
 Do not use the vacuum cleaner to vacuum up any water,
liquid or damp dirt. Wait until any freshly cleaned or sham-
pooed rugs or carpets are completely dry before attempt-
ing to vacuum.
 Do not use the vacuum cleaner to vacuum toner dust.
Toner, such as that used in printers and photocopiers, can
conduct electricity.

en - IMPORTANT SAFETY INSTRUCTIONS
9
 Do not vacuum up any flammable or combustible liquids
or gases and do not vacuum in areas where such sub-
stances are stored.
Accessories
 To avoid the risk of injury when vacuuming with a Miele
Powerbrush or Turbobrush, do not touch the rotating roller
brush.
 The Miele Electrobrush is a motor driven accessory for
use only with Miele vacuum cleaners. For safety reasons,
the vacuum cleaner must not be used with an Electrobrush
produced by another manufacturer.
 Only use genuine FilterBags, filters and accessories with
the "Original Miele" logo on them. Otherwise the manufac-
turer cannot guarantee the safety of the product.
SAVE THESE INSTRUCTIONS

en - Appliance description
10

en - Appliance description
11
aFloorhead *
bFilter bag change indicator
cDust compartment lid release button
dCarry handle with controls
eTwo-piece accessory set on accessory clip *
fSuction wand *
gRelease buttons
hHandle with non-slip end cap and hook
iCable hooks for connection cable
jPower cord
kCable clip
lTelescopic suction wand release button *
mExhaust filter cover (on back)
nMotor protection filter
oOriginal Miele filter bag
pSocket for Electrobrush *
* These features are model-specific and may vary or may not be available on your
vacuum cleaner.

en - Caring for the environment
12
Disposal of the packing mate-
rial
The cardboard box and packing materi-
als protect the appliance during ship-
ping. They have been designed to be
biodegradable and recyclable.
Ensure that any plastic wrappings,
bags, etc. are disposed of safely and
kept out of the reach of children. Dan-
ger of suffocation!
Disposing of the FilterBags
and filters
Filterbags and filters are made from en-
vironmentally friendly materials, and can
be disposed of with the normal house-
hold waste, as long as they have been
used exclusively for general household
dust.
Disposing of your old appli-
ance
Before disposing of your old appliance
remove the FilterBag and filters and dis-
pose of them with your household
waste.
Electronic and electrical appliances
contain many valuable materials. They
also contain certain materials, com-
pounds and components which were
essential for their correct functioning
and safety. These could be hazardous
to your health and to the environment if
disposed of with general waste or if
handled incorrectly. Please do not,
therefore, dispose of your old appliance
with general waste.
Instead, please make use of officially
designated collection and disposal
points to dispose of and recycle electri-
cal and electronic appliances. By law,
you are solely responsible for deleting
any personal data from the appliance
prior to disposal. Please ensure that
your old appliance poses no risk to chil-
dren while being stored for disposal.

en-US
13
References to illustrations
The illustrations referred to in the text
are shown on the fold-out pages at
the end of these Operating Instruc-
tions.
Preparing for use
Attach the suction wand (Fig. 01)
Fit the suction wand with the square
hole facing upwards into the body of
the vacuum cleaner and twist gently
until it clicks into place.
To detach the suction wand
Press the release button (see detail)
and pull off the wand from the vac-
uum cleaner housing with a gentle
twist.
Connecting the handle to the wand
(Fig. 02)
Fit the handle with the square hole
facing upwards into the wand and
twist gently until it clicks into position.
To release the handle from the wand,
press the release button and pull the
handle out of the wand, twisting it
slightly as you do so.
The handle can also be fitted directly to
the body of the vacuum cleaner (Fig.
03).
The vacuum cleaner is then easier to
use, e.g., when vacuuming mattresses,
upholstery, etc.
Fitting the floorhead (Fig. 04)
Attach the floorhead to the vacuum
cleaner connection stub and twist
gently until it clicks into position.
To remove the floorhead, press the
release button and pull the vacuum
cleaner away from the floorhead
twisting it slightly as you do so.
The suction wand can also be attached
to the vacuum cleaner connection stub
(Fig. 05). This is useful for vacuuming
underneath low furniture, for example.
Winding up the power cord (Fig. 06)
When the vacuum cleaner is not in use,
the power cord can be wound around
the two cord hooks.
Secure the power cord by clipping the
plug to the cord (see detailed image).
Using the accessories supplied
(Fig. 07)
Accessory clip
Crevice nozzle
Upholstery nozzle
Accessory clip (Fig. 08)
(as standard depending on model)
If required, attach the accessory clip
to the suction wand.
Push the accessory clip down over
the cable hook ring until it clicks into
position.
The accessory clip holds the acces-
sories (Fig. 09).
Some models are supplied as standard
with one of the following accessories
which are not illustrated.
– Electrobrush
– Turbobrush

en-US
14
These vacuum cleaners are supplied
with separate operating instructions for
the relevant accessory part.
Use
Unwind the power cord (Fig. 10)
The lower cable hook swivels.
Turn it upwards to release the cable.
Adjusting the telescopic suction
wand (Fig. 11)
(depending on model)
One part of the telescopic suction wand
is packed inside the other, and it can be
adjusted to suit your height for comfort-
able vacuuming.
Press the release button and adjust
the telescopic suction wand to the re-
quired length.
Plugging in the vacuum cleaner
(Fig. 12)
Plug the vacuum cleaner into a
socket protected by at least a 10A
fuse.
When vacuuming hang the cable over
the cable hook on the vacuum
cleaner (see detail).
This way the power cord will not get in
the way during vacuuming. It also pro-
tects the cable from becoming kinked
at the handle.
Switching on and off(Fig. 13 + 14)
There are two separate switches on the
carrying handle to enable the vacuum
cleaner to be conveniently operated in
any vacuum-cleaning situation.
Double slide switch
0 = Vacuum cleaner is switched off
min. = Reduced suction
max. = Maximum suction
Select min. for vacuuming lightweight
items such as curtains or rugs.
Select max. if using a turbobrush.
To switch the vacuum cleaner on,
slide either switch to max.
To switch the vacuum cleaner off,
push the slide switch to 0 until it
clicks.
Adjusting the floorhead (Fig. 15 + 16)
This vacuum cleaner can be used for
daily cleaning of carpets, rugs and ro-
bust hard flooring.
Miele offers a range of other floorheads,
brushes, and accessories for other
types of flooring and special applica-
tions (see "Optional accessories").
Please observe the flooring manufac-
turer's cleaning and care instructions.
Vacuum carpets and rugs with the
brush retracted:
Press the foot switch  .
Clean hard flooring which is not sus-
ceptible to scratching, and flooring with
gaps or deep crevices in it with the
brush protruding:
Press the foot switch .

en-US
15
When using the adjustable floorhead,
if the suction seems too high, reduce
the suction until the floorhead is eas-
ier to maneuver.
Setting down and storing the
vacuum cleaner
The vacuum cleaner can be leaned up-
right against a wall or furniture during
pauses in vacuuming or when storing it
(Fig. 17). For this purpose a non-slip
stopper is attached to the handle.
Before leaving the vacuum cleaner
make sure it is switched off and if you
lean it against a wall make sure it is at
a safe angle so that it cannot fall over.
When using a floorbrush we recom-
mend that you hang the vacuum
cleaner up when storing it to protect
the bristles.
The vacuum cleaner is easy to hang up
for this purpose. A hook is on the han-
dle so that you can do this (Fig. 18).
Maintenance
Always switch off the vacuum
cleaner for maintenance work and
remove the plug from the outlet.
The Miele filtration system consists of
three components (Fig. 19):
Original Miele FilterBag
Motor protection filter
Original Miele exhaust filter
These will need to be replaced from
time to time to ensure that your vacuum
cleaner performs efficiently.
We recommend only using genuine
FilterBags, filters, and accessories
with the "Original Miele" logo on
them. This will ensure that the suc-
tion power of the vacuum cleaner is
maintained, giving the best possible
cleaning results.
FilterBags with the "Original Miele"
logo on them are not made from pa-
per or paper-based materials and nor
do they have a cardboard collar. This
is why our FilterBags are particularly
long-lasting and reliable.
Please note that appliance faults and
damage originating from the use of
accessories which do not carry the
"Original Miele" logo will not be cov-
ered by the appliance guarantee.
Purchasing new FilterBags and filters
Original Miele FilterBags and filters are
available from the Miele web store,
Miele Technical Service, and your Miele
dealer.
Ordering the correct FilterBags and
filters
Only use original Miele KK FilterBags
with a yellow collar and original Miele
filters. These are identified by the
"ORIGINAL Miele" logo on the packag-
ing.

en-US
16
An AirClean filter and a motor protec-
tion filter are supplied with every packet
of Miele FilterBags.
Original Miele exhaust filters can also
be purchased separately from your
Miele dealer or from Miele. Please
quote the model number of your vac-
uum cleaner when ordering to make
sure you get the correct filter. You can
also order all accessories via the Miele
web store.
When to change the FilterBag
(Fig. 20)
Change the FilterBag when the color
marker in the FilterBag change indicator
turns red.
FilterBags are disposable and in-
tended to be used only once. Dis-
pose of the entire FilterBag. Do not
attempt to re-use. Blocked pores re-
duce the efficiency of the vacuum
cleaner.
Checking the FilterBag change indi-
cator
Attach the standard adjustable floor-
head to the vacuum cleaner.
Switch the vacuum cleaner on and
select the highest power setting.
Lift the floorbrush off the floor a little.
How the FilterBag change indicator
works
The FilterBag change indicator is set for
normal household dust. This generally
contains a mixture of dust, hair,
threads, carpet lint, grit, etc.
However, if the cleaner has been used
to vacuum up fine dust, such as plaster,
brick dust, cement or flour, the pores of
the FilterBag will become blocked very
quickly.
This affects the air permeability of the
bag, and the marker will indicate that
the bag is "full" even when it is not. If
this happens you must still change the
FilterBag because suction power will be
greatly reduced by blocked pores in the
FilterBag.
If, on the other hand, a large amount of
hair and carpet lint which typically con-
tains a lot of air is vacuumed up, the in-
dicator may fail to react even though
the bag is full. You should still change it.
Both these extremes can occur.
How to replace the FilterBag
(Fig. 21 & 24)
Press the release button for the dust
compartment lid and open the lid un-
til it clicks into its resting position.
Pull one of the tabs on the collar and
swing the bag up away from the suc-
tion socket before taking it out of its
holder.
Seal the bag by pressing both sides
of the closure under the seal.
The FilterBag is now sealed so that dust
cannot escape.
Fit the new FilterBag into the yellow
holder as far as it will go. Leave it
folded up when you take it out of the
box.
It should be unfolded as far as possi-
ble in the dust compartment.

en-US
17
Close the dust compartment lid se-
curely, making sure it clicks into posi-
tion. Take care not to trap the Fil-
terBag when doing so.
An empty operation lock pre-
vents the dust compartment lid from
closing without a filter bag in place.
Do not use force!
When to change the motor protection
filter
Replace this filter every time you start a
new packet of filter bags.
Every packet of original Miele filter bags
contains a motor protection filter.
How to change the motor protection
filter (Fig. 25)
Open the dust compartment lid.
Unclip the yellow filter frame, re-
move the old motor protection filter
and replace with a new one.
Close the filter frame making sure the
catch engages.
Close the dust compartment lid mak-
ing sure it clicks into position.
When to replace the exhaust filter
Depending on the model, your vacuum
cleaner will be fitted as standard with
one of the following exhaust filters (Fig.
26):
a AirClean
Replace this filter every time you start a
new packet of filter bags. Every packet
of original Miele filter bags contains one
AirClean exhaust filter.
b Active AirClean
c AirClean Plus
Replace these exhaust filters about
once a year. Make a note of the date on
the exhaust filter.
How to replace the AirClean exhaust
filter (Fig. 27 & 29)
Do not use more than one exhaust fil-
ter at a time.
Press the button on the rear of the
vacuum cleaner and remove the
cover.
Grasp the used AirClean exhaust filter
by the clean, unsoiled section and
take it out (see arrow).
Replace it with a new AirClean ex-
haust filter.
If you wish to fit an Active AirClean
or AirClean Plus exhaust filter please
see "Replacing one type of exhaust
filter with another".
Put the cover back on and close it.
How to replace an Active AirClean or
an AirClean Plus exhaust filter
(Fig. 30 & 31)
Do not use more than one exhaust fil-
ter at a time.
Press the button on the rear of the
vacuum cleaner and remove the
cover (Fig. 27).
Take out the used Active AirClean or
AirClean Plus exhaust filter.
Insert a new Active AirClean or Air-
Clean Plus exhaust filter.

en-US
18
If you wish to fit an AirClean exhaust
filter, see "Replacing one type of ex-
haust filter with another".
Put the cover back on and close it.
Replacing one type of exhaust filter
with another
Depending on the model, your vacuum
cleaner will be fitted as standard with
one of the following exhaust filters (Fig.
26).
aAirClean
bActive AirClean (SF-AA 10)
cAirClean Plus (SF-H 10)
Do not use more than one exhaust fil-
ter at a time.
When changing the filter please note
(Fig. 32)
1. If you wish to replace exhaust filter a
with filter b or c, you must com-
pletely remove the filter grille from the
lid before you install the new exhaust
filter.
2. If you wish to replace exhaust filter b
or c with filter a, it is essential that
you also fit the filter grille * in the lid.
* Filter grille – see "Optional acces-
sories"
To remove or insert the filter grille
(Fig. 32)
Grasp inside the hexagons in the filter
grille with two fingers and squeeze
slightly. You can then remove or in-
sert the filter grille as required.
When to change the thread catchers
(not possible on EcoTeQ Plus floor-
heads)
The thread catchers on the suction inlet
to the floorhead can be replaced. Re-
place the thread catchers if the pile has
worn down.
How to replace the thread lifters
(Fig. 33 + 34)
Use a suitable screwdriver to remove
the thread lifters from the slots.
Fit new thread lifters.
Cleaning the roller on the AllTeQ
floorhead (Fig. 35)
Clean the roller on the floorhead if re-
quired.
Release the bearing using a coin.
Press the bearing out, and remove.
Remove the roller.
Remove any threads and hair, replace
the roller and refit the bearing, locking
it back into position.
Replacement parts are available from
your Miele dealer or through Miele
Technical Service.
Cleaning and care
Always disconnect the vacuum
cleaner from the electrical supply be-
fore cleaning it. Turn off and unplug
it.

en-US
19
Vacuum cleaner and accessories
The vacuum cleaner and all plastic ac-
cessories can be cleaned with a propri-
etary cleaner suitable for plastic.
Do not use abrasive cleaning
agents, glass cleaning agents, all-
purpose cleaners or oil-based condi-
tioning agents!
Dust compartment
The dust compartment can, if neces-
sary, be cleaned using a dry duster,
brush or, if available, a second vacuum
cleaner to vacuum the dust out.
Monitor the filter bag change indicator
and inspect all filters regularly. Clean or
replace them when necessary accord-
ing to these Operating Instructions.
Do not let the vacuum cleaner
get wet. If moisture gets into the ap-
pliance, there is a risk of electric
shock.

en-US
20
Frequently Asked Questions
With the help of the following guide minor faults in the performance of the ma-
chine, some of which may result from incorrect operation, can be remedied with-
out contacting the Service Department. Time and money will be saved because a
service call will not be needed.
This guide may help you to find the reason for the fault, and how to correct it.
Problem Possible cause and solution
The vacuum cleaner
turns off automatically.
A temperature limiter switches the vacuum cleaner off
automatically when it gets too hot.
This can occur if, for instance, large objects block the
suction wand or when the filter bag is full or is
clogged with particles of fine dust. A heavily soiled
motor protection or exhaust filter can also be the
cause for overheating.
Then switch off the vacuum cleaner and unplug it
from the socket.
After removing the cause of the fault, wait for approxi-
mately 20–30 minutes to allow the vacuum cleaner to
cool down. It can then be turned on again.
