Miele G 7883 User manual

Operating instructions
Washer-disinfector
G 7883
To avoid the risk of accidents or
damage to the machine it is
essential to read these instructions
before it is installed, commissioned
and used for the first time.
G
M.-Nr. 05 803 612

Description of the machine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Guide to the machine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Warning and Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Caring for the environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Disposal of your old appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Opening and closing the door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Electric door lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
To open the door a. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
To close the door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
To open the door with the emergency release. . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Water softener . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Setting the water softener . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Filling the salt reservoir . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Salt indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Rinsing agent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Setting the dosage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Adding neutralising agent. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Setting the dosage and venting the dispensing system . . . . . . . . . . . . . . . . . 22
Adding cleaning agent. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Loading the machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Loading the machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Adjusting the top basket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Switching on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Starting the programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Changing a programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Selecting an additional function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Programme sequence indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
At the end of a programme. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Switching off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
To cancel a programme. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Contents
2

Programming special functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
1. Setting the dosage concentration and venting the dispensing system . . . . . . 33
2. Altering the wash temperature and/or the temperature holding time in
the "Main wash" and "Final rinse" programme stages . . . . . . . . . . . . . . . . . . . . 36
3. Audible tone (Buzzer) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
4. Re-setting all parameter changes back to the factory settings. . . . . . . . . . . . . 39
Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Cleaning the filters in the wash cabinet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Cleaning the spray arms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Cleaning the drain pump and non-return valve. . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Cleaning the filters in the water inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Cleaning the control panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Cleaning the front of the machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Correcting minor faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Faults / possible causes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
After sales service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Electrical connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Plumbing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Connection to the water inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Drainage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Programme chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Contents
3

The G 7883 washer-disinfector is a front
loading machine designed specifically
for processing laboratory utensils and
glassware.
In general these include glass, heat
tolerant plastic, stainless steel and
coated metal items such as containers
(e.g. beakers, narrow necked and
conical flasks, Erlenmeyer flasks,
bottles, test tubes, separatory funnels
etc.), measuring vessels (e.g.
volumetric flasks, measuring cylinders,
pipettes etc.), dishes (e.g. Petri dishes,
mortars, watch glasses etc.) and small
components (e.g. stoppers, spatula,
stirrers etc.).
The main aim of processing laboratory
utensils and glassware is to remove
contaminations from both external and
internal surfaces and to rinse off any
cleaning and neutralising agents.
Items are loaded into inserts and
mobile units which are then pushed into
the wash cabinet. The door is then
closed and the programme is started
manually. At the end of the programme
the operator opens the door, removes
the mobile unit and inserts and unloads
the items.
The G 7883 is a single cabinet system
in which the whole process takes place,
including the pre-wash, main wash,
neutralisation, interim and final rinses.
Drying can be selected as an additional
function to complete the process. Each
programme stage follows on
automatically after the previous one.
The main wash, neutralising and rinse
stages are all carried out using water
based agents only. In other words using
cold, hot or fully demineralised water
with the addition of a suitable chemical
agent (cleaning agent or neutralising
agent). Other liquid agents such as
organic solvents or combustible agents
must not be used in this machine.
Before processing anything in this
machine make sure that it is suitable for
machine processing and that it is for
example heat, acid and alkali tolerant.
It is the user’s responsibility to decide
whether items contaminated with
substances such as micro biological
material, pathogenic cells, facultative
pathogenic cells, genetically modified
material etc. should be sterilised before
machine processing.
Description of the machine
4

If sterilisation is not required prior to
machine preparation, the user must
decide whether to use the vario TD
programme for cleaning and
disinfection to general hygiene
requirements, or whether to use the
SPECIAL 93°C/10’ (§ 18 IfSG) for
cleaning and disinfection in
accordance with national Health and
Safety regulations regarding the
containing of epidemics. The
disinfecting programme chosen will
depend on the area of effectiveness
required (bactericidal and/or virucidal)
and on the thermal stability of the
instruments. Contaminated items, not
requiring initial sterilisation, can be
placed directly in the machine without
pre-treatment (no soaking required).
The parameters for thermal disinfection
in accordance with prEN ISO 15883-1
are 80 °C (+ 5 °C, - 0 °C) with a 10 min.
holding time or 90 °C (+ 5 °C, - 0 °C)
with a 5 min. holding time for the
inactivation of HBV.
The effective areas are defined as
follows:
A = suitable for the destruction of
vegetative bacteria, including
myco-bacteria, fungus and fungal
spores.
B = suitable for the inactivation of
viruses (including HBV and HIV).
Description of the machine
5

aOn/Off button (I-0)
bDoor release
cDisplay
dDelay start indicator light
eDrying indicator light
fProgramme start indicator light
gStart button
hDrying button
iButton to toggle between the actual
temperature, elapsed time and active
washing block displays
jAdd (liquid) cleaning agent
indicator light *)
Optical interface for
service technician
kAdd rinsing agent indicator light
lAdd neutralising agent indicator light
mAdd salt indicator light
nWater inlet / Drain
indicator light
oProgramme sequence display
pProgramme selector
*) (only applies to machine fitted with
optional external DOS-Module)
Guide to the machine
6

aConnection for DOS module G 60
Optional dispenser pump for
liquid cleaning agent
- at the back of the machine -
bFilter combination
cSalt container
(for the water softener)
dDispenser for powder cleaning agent
eRinsing agent reservoir
(with dosage selector)
fLevel indicator
Guide to the machine
7

This machine complies with all
relevant local and national safety
requirements. Incorrect use can lead
to personal injury and damage to
property. To avoid the risk of
accidents and damage to the
machine please read these
instructions carefully before using it
for the first time.
Keep these instructions in a safe
place for future reference, and pass
them on to any future user.
Correct use
This washer-disinfector is designed
for commercial use and for
specialised applications only, as
described in these operating
instructions. Alterations or conversions
to the machine or using it for purposes
other than those for which it was
designed are not permitted and could
be dangerous.
This machine must only be used for
cleaning and disinfecting instruments
or medical products and laboratory
ware if the manufacturer has stated that
they are suitable for machine
processing. Manufacturer's cleaning
and maintenance instructions for
instruments etc. must also be
observed. The manufacturer cannot be
held liable for damage caused by
improper or incorrect use of the
machine.
This equipment may only be used
in mobile installations such as
ships, caravans, aircraft etc. if a risk
assessment of the installation has been
carried out by a suitably qualified
engineer.
Please pay attention to the following
notes to avoid injury and damage.
The machine should be
commissioned and then
maintained only by a Miele authorised
service contract is recommended.
Repairs and other work by unqualified
persons could be dangerous.
Do not install the machine in an
area where there is any danger of
explosion or of freezing conditions.
The electrical safety of this
machine can only be guaranteed if
connected to a correctly installed
earthing system on site. It is most
important that this basic safety
requirement is tested regularly, and
where there is any doubt the electrical
system should be inspected by a
qualified electrician.
The manufacturer cannot be held liable
for damage or injury caused by the lack
of or inadequacy of an effective
earthing system (e.g. electric shock).
A damaged machine is dangerous.
Switch off at the mains immediately
and call the Miele Service Department
or an authorised and trained Miele Ser-
vice Dealer.
Personnel operating the machine
should be trained regularly.
Untrained personnel must not be
allowed access to the machine or its
controls.
This machine is not a toy! To avoid the
risk of injury never allow children to play
on or near the machine, or to operate it.
Warning and Safety instructions
8

Take care when handling chemical
agents such as cleaning agent,
neutralising agent, rinsing agent etc.
These may contain irritant or corrosive
ingredients. Do not use organic
solvents as these could cause an
explosion. Follow all relevant safety
procedures carefully. Wear protective
gloves and goggles. With all chemical
agents, the manufacturer's safety
instructions must be observed.
Avoid inhalation of powder
cleaning agents. They can cause
burning in the mouth and throat if
swallowed, and can inhibit breathing.
The water in the machine must not
be used as drinking water.
Do not sit or lean on an open door.
The machine could tip up and be
damaged or cause an injury.
Be careful when sorting items with
sharp pointed ends and
positioning them in the machine that
you do not hurt yourself or create a
danger for others. Sharp knives etc.
should be placed in baskets with the
pointed ends facing downwards.
When using this machine in the
higher temperature ranges, be
especially careful not to scald or burn
yourself or come into contact with
irritant substances when opening the
door! Where disinfecting agents are
used there is a danger of inhaling toxic
fumes. Baskets, inserts and utensils
must be allowed to cool down before
they are unloaded. Any water remaining
in containers could still be very hot.
Empty them into the wash cabinet
before taking them out.
Do not touch the heating elements
if you open the door during or
directly after the end of a programme;
you could burn yourself. They remain
hot for some time after the end of the
programme.
Never clean the machine or near
vicinity with a water hose or a high
pressure hose.
The machine must be
disconnected from the mains
electricity supply before any
maintenance or repair work is carried
out. Do not reconnect it until the
maintenance or repair work has been
successfully completed.
Warning and Safety instructions
9

The following points should be
observed to assist in maintaining
quality standards for processing
medical instruments and senstitive
laboratory glassware, and to avoid
injury to patients or damage to
equipment.
If the machine (depending on mo-
del) is being used for disinfection
in accordance with official regulations
on the control of epidemics, the steam
condenser and its connections to and
from the wash cabinet must be cleaned
and disinfected whenever any repairs
are carried out or parts replaced.
For decontamination in
accordance with official
regulations, the programme must not
be interrupted by pressing the I-0
button to switch off after START has
been pressed . Interrupting any other
programmes should also be avoided as
this will reduce cleaning, disinfection
and the final rinse results. If it is opened
the programme should be completely
repeated.
The standard of cleaning and
disinfection in the disinfection
programmes must be routinely
confirmed by the user. The process
should be regularly monitored using
thermo-electrical, chemical or
bio-indicators, and this should be fully
documented.
For thermal disinfection, use
temperatures and temperature
holding times to achieve the required
infection prophylaxis in accordance
with current health and safety
regulations.
Only use chemical agents
formulated for special processes
and approved by Miele for use with this
machine. Use of unsuitable agents
could adversely affect the components
of the machine. Any resultant damage
would invalidate the machine
guarantee.
Pre-treatments with cleaning or
disinfecting agents can create
foam, as can certain types of soiling
and chemical agents. Foam can have
an adverse effect on the disinfection
and cleaning process.
Where a chemical additive is
recommended on technical
application grounds (e.g. a cleaning
agent), this does not imply that the
manufacturer of the machine takes
responsibility for the effect of the
chemical on the items being cleaned.
Please be aware that changes in
formulation, storage conditions etc,
which may not be publicised by the
chemical manufacturer, can have a
negative effect on the cleaning result.
Warning and Safety instructions
10

When using cleaning agents and
specialised products, it is essential
that the manufacturer's instructions are
followed. Chemicals must only be used
for the purpose they are designed for
and in the situation specifed, to the
exclusion of other chemicals, to avoid
such dangers as chemical reactions
and material damage.
The machine is designed for
operation with water and
recommended additive chemical
agents only. Organic solvents must not
be used in this machine, as there is the
danger under certain circumstances of
fire or explosion. Although this is not the
case with all organic solvents, other
problems could arise with their use, for
example damage to rubber and
synthetic materials.
In critical applications where very
stringent requirements have to be
met, it is strongly recommended that all
the relevant factors for the process,
such as cleaning agent, water quality
etc. are discussed with the Miele
Application Technology specialists.
If cleaning and rinsing results are
subject to particularly stringent
requirements (e.g. chemical analysis,
specialised industrial processes etc.), a
regular quality control test must be
carried out by the user to ensure that
the required standards of cleanliness
are being achieved.
The special inserts should only be
used for the purpose they are
designed for. Hollow instruments must
be throughly cleaned, internally and
externally.
Empty any containers or utensils
before arranging them in the
machine.
Do not allow any remains of acids
or solvents, and in particular
hydrochloric acid or chloride solutions,
to get into the wash cabinet. Similarly
avoid any materials with a corrosive
effect.
The presence in compounds of any
solvents should be minimal (especially
those in hazard class A1).
Ensure that solutions or steam
containing hydrochloric acid do not
come into contact with the steel outer
casing of the machine, to avoid any
corrosion damage.
Please follow the advice on
installation in these instructions
and the separate Installation
Instructions.
Warning and Safety instructions
11

Using accessories
Only use genuine Miele
accessories with this machine.
Consult Miele on the type and
application of such equipment.
Only use Miele mobile units,
baskets and inserts in this
machine. Using accessories made by
other manufacturers, or making
modifications to Miele accessories can
result in unsatisfactory cleaning and
disinfecting results, for which Miele
cannot be held liable. Any resultant
damage would also invalidate the
machine guarantee.
Disposal of your old machine
Before throwing an old machine
away, it must first be made
unusable. Disconnect it from the mains
and cut off the cable as close to the
machine as possible.
Please note that the machine may have
contamination from blood or other
bodily fluids in it and must be
decontaminated before disposal.
For environmental and safety reasons
ensure the machine is completely
drained of any residual water, chemical
residues and cleaning agent. Observe
safety regulations and wear safety
goggles and gloves.
Make the door lock inoperable, so that
children cannot accidentally shut
themselves in. Then make appropriate
arrangements for the safe disposal of
the machine.
The manufacturer cannot be held
liable for damage caused by
non-compliance with these Warning
and Safety instructions.
Warning and Safety instructions
12

Disposal of the packing
material
The transport and protective packing
has been selected from materials which
are environmentally friendly for disposal
and can normally be recycled.
Ensure that any plastic wrappings,
bags etc. are disposed of safely and
kept out of the reach of babies and
young children. Danger of suffocation.
Rather than just throwing these
materials away, please ensure that they
are recycled.
Disposal of your old appliance
Electrical and electronic appliances
often contain materials which, if
handled or disposed of incorrectly,
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your appliance.
Please do not therefore dispose of it
with your household waste.
Please dispose of it at your local
community waste collection / recycling
centre and ensure that it presents no
danger to children while being stored
for disposal.
It should be unplugged or disconnected
from the mains electricity supply by a
competent person. Any plug must be
rendered useless and the cable cut off
directly behind it to prevent misuse.
See the "Warning and Safety" section of
this booklet for further details.
Caring for the environment
13

Electric door lock
The machine is equipped with an
electric door lock.
The door can only be opened when:
^the electricity supply to the machine
is switched on and:
^the master switch I-0 is pressed in.
To open the door a
^Press the door release button in as
far as it will go, and at the same time,
grip the handle and open the door.
Do not touch the heating elements if
you open the door during or directly
after the end of a programme, you
could burn yourself. They remain hot
for some time after the end of the
programme.
To close the door
^Lift the door upwards and push until
it clicks shut. Do not press the
release catch whilst shutting the
door!
After the first intake of water, it is no
longer possible to open the door,
except in the D(PRE-RINSE) and 6
(DRAIN) programmes. The machine
can be programmed to open during
drying (additional programme).
The door remains locked and cannot
be opened until the end of the
programme.
To cancel a programme
If a programme has to be cancelled in
an emergency, e.g. when articles in the
machine jostle against each other or
the programme has been interrupted
because of a fault, the door will have to
be opened manually:
^Turn the programme selector to the
fposition (the programme is
cancelled after approx. 2 secs.).
Important
It is essential to follow procedures,
particularly with regard to regulations
on preventing the spread of epidemics,
as described in "Operation - cancelling
a programme".
Opening and closing the door
14

To open the door with the
emergency release
The emergency release should only be
used when the door cannot be opened
normally, e.g. in the event of a power
failure.
Important
It is essential to follow procedures,
particularly with regard to regulations
on preventing the spread of epidemics,
as described in "Operation - cancelling
a programme".
^Turn the programme selector to f.
^Press I-0 to switch the machine off.
^The emergency release cable is
located at the bottom of the machine
behind the service panel. Pull it
downwards to open the door.
Opening and closing the door
15

The water needs to be softened to
avoid calcium deposits building up on
instruments and utensils and in the
machine itself.
To ensure a steady supply of soft water
the water softener unit must always be:
1. correctly set (programmed) and
2. the salt reservoir must be filled.
(If the water hardness level is below
0.7 mmol/l (4 °d - German scale) the
reservoir does not need to be filled
with reactivation salt.)
The machine is set at the factory for a
water hardness level of 3.4 mmol/l
(19 °d).
If the water supply is harder or softer
than this (including below 0.7 mmol/l
or 4 °d) the factory setting will need
to be changed following the
instructions in "Setting the water
softener". See chart on the next
page for settings.
Your local water authority will advise
you on the water hardness in your area.
For fluctuating levels (e.g. 1.4 - 3.1
mmol/l or 8 - 17 °d) set the water
softener to the highest setting (in this
example to 3.1 mmol/l or 17 °d).
Important
The built-in water softener has settings
from 0.2 - 10.8 mmol/l or 1 °d - 60 °d.
Setting the water softener
^Switch off the machine.
^Turn the programme selector to the
STOP position f.
^Press ßand 6at the same time,
hold them in and, whilst doing so,
switch the machine on with the I-0
button.
The current programme status "P..."
will show in the display.
The indicator light p/6will come
on.
^Press 0once, E01 for programming
level 1 will appear in the display.
^Turn the programme selector one
switch position clockwise (1 o’clock
position).
The number 19 appears in the
display (the factory water hardness
setting in °d), (equivalent to
3.4 mmol/l).
^Press ßas many times as is
necessary, or hold it in until the
required value (hardness level in °d)
appears in the display.
Once the number 60 has been
reached, the counter will begin again
at 0.
^Press the 6button. SP will appear in
the display.
^Press 6again. The setting will now
be stored in memory. The display will
go out.
^The machine is now ready for use.
Water softener
16

Settings
°d
(German scale)
mmol/l °f Setting
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19 *)
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
0.2
0.4
0.5
0.7
0.9
1.1
1.3
1.4
1.6
1.8
2.0
2.2
2.3
2.5
2.7
2.9
3.1
3.2
3.4
3.6
3.8
4.0
4.1
4.3
4.5
4.7
4.9
5.0
5.2
5.4
5.6
5.8
5.9
6.1
6.3
6.5
6.7
6.8
7.0
7.2
7.4
7.6
7.7
7.9
8.1
2
4
5
7
9
11
13
14
16
18
20
22
23
25
27
29
31
32
34
36
38
40
41
43
45
47
49
50
52
54
56
58
59
61
63
65
67
68
70
72
74
76
77
79
81
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
°d
(German scale)
mmol/l °f Setting
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
8.3
8.5
8.6
8.8
9.0
9.2
9.4
9.5
9.7
9.9
10.1
10.3
10.4
10.6
10.8
83
85
86
88
90
92
94
95
97
99
101
103
104
106
108
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
*) factory setting
For future servicing it is useful to make
a note of your water hardness level.
Enter your water hardness level here:
°d (German scale)
or
mmol/l
Water softener
17

Filling the salt reservoir
Please only use special coarse grained
reactivation salt with granules of
approx. 1-4 mm. Do not use other types
of salt, e.g. table salt, agricultural or
gritting salt. These could contain
components which are insoluble in wa-
ter which could result in damage to the
water softener. If in doubt consult your
Miele Professional Department.
The salt reservoir holds approx. 2.5 kg
of salt.
,Inadvertently filling the salt
reservoir with cleaning agent will
damage the water softener.
Before filling the salt reservoir make
sure that you have picked up the
right packet of reactivation salt.
^Remove the bottom basket from the
machine.
^Unscrew the salt reservoir cap.
Before filling the salt reservoir with
reactivation salt for the first time, fill it
with approx. 2.5 litres of water.
^Place the funnel provided in place.
^Fill carefully with salt. As it is filled,
displaced water will run out).
^Wipe any residual salt off the screw
threads on the socket.
^Screw the cap on firmly.
^Immediately after this: Run the
PRE-RINSE programme Dto remove
any traces of salt from the cabinet.
Important: If after starting the
PRE-RINSE programme Dthe machine
does not start for a few minutes this is
not a fault. The water softener is being
reactivated.
Water softener
18

Salt indicator
When the salt reservoir is empty the k
indicator light bcomes on to remind
you to fill the reservoir.
Reactivation takes place automatically
during a programme.
The programme sequence indicator
light kalights up whilst this is
happening.
Water softener
19

If rinsing agent is required the
rinsing agent reservoir in the
machine will first need to be
activated by a Miele Service
technician.
Rinsing agent helps water run off items
so that no droplets are left behind and
improves drying results. However,
because rinsing agent is dispensed
during the final rinse some of its
ingredients will remain on the surfaces
of your laboratory glassware etc. It
should therefore only be used if it does
not have an adverse effect on the
application the glassware or utensils
are being used for.
If used, it is poured into the rinsing
agent reservoir in the door and the
amount set is then automatically
dispensed during the final rinse.
The rinsing agent reservoir holds
approx. 180 ml.
,Inadvertently filling the rinsing
agent reservoir with cleaning agent
(including liquid cleaning agent) will
damage the reservoir.
Make sure you use a rinsing agent
which is suitable for use in washer
disinfectors.
^The reservoir must be filled with
rinsing agent when the Hindicator
light comes on.
There is also a level indicator for the
rinsing agent reservoir on the inside
of the door (see illustration).
^Open the door fully.
^Undo the screw cap.
Rinsing agent
20
