mikroElektronika click BOARD IR reflect click User manual

2 3
click™
BOARD
www.mikroe.com
2. Soldering the headers
3. Plugging the board in
Once you have soldered the headers your
board is ready to be placed into the desired
mikroBUS™socket. Make sure to align the
cut in the lower-right part of the board with
the markings on the silkscreen at the
mikroBUS™socket. If all the
pins are aligned correctly,
push the board all the way
into the socket.
Turn the board upward again. Make sure
to align the headers so that they are
perpendicular to the board, then solder the
pins carefully.
Turn the board upside down so that
the bottom side is facing you upwards.
Place shorter pins of the header into the
appropriate soldering pads.
Before using your click™board, make sure
to solder 1x8 male headers to both left and
right side of the board. Two 1x8 male headers
are included with the board in the package.
4. Essential features
These sensors are used to detect an object’s
presence or motion, such as a piece of paper
passing through a printer. To avoid setting
o false alarms, avoid exposing the sensor
to other sources of infrared light (which
could come from an ordinary incandescent
light bulb). Also, black objects won’t reect
infrared so the click™won’t detect them. On
the other hand, reective metalic surfaces will
trigger the sensor from a larger range.
1
IR reect click™carries a GP2S700HCP
reective photointerrupter. On this type of
photointerrupter the infrared emitter and
receiver are facing the same direction; the
infrared beam from the emitter gets bounced
back to the receiver when an object is placed
within the detecting range of the sensor
(Optimal Sensing Distance is 3mm). IR reect
click™communicates with the target board
microcontroller through mikroBUS™AN and
INT pins (an onboard potentiometer sets
the Interrupt threshold). It’s designed to use
either a 3.3V (by default) or 5V power supply.
1. Introduction
IR reflect click™ manual
ver 1.02
0100000077290
IR reect click™

AN
RST
CS
SCK
MOSI
MISO
+3.3V
GND
PWM
INT
RX
TX
SCL
SDA
+5V
GND
MIKROBUS DEVICE CONN.
R2
120
GND
VCC
GND
VCC
1
2
3
LD2
GND
VCC
R6
1K
R7
N/A
R10
4K7
3.3V 5V
VCC
VCC
R1
2K2
GND
LD1
GNDGNDGND
3mm
DETECTING OBJECT SURFACE
1
2
4
3
EMITTER
COLLECTOR
ANODE
CATHODE
GP2S700HCP
S1
R8
5K6
R9
0R
GND
VCC
GND
VCC
P1
VCC
R5
4K7
GND
R3
3K3
R4
6K8
8
7
6
54
3
2
1
LM2903
1OUT
1IN-
1IN+
GND
VCC
2OUT
2IN-
2IN+
U1
LM2903
M1
DMG3420U
C1
2.2uF
VCC
R11
0R C2
100nF
GND
8. Code examples
MikroElektronika oers free tech support
(www.mikroe.com/support) until the end of
the product’s lifetime, so if something goes
wrong, we’re ready and willing to help!
Once you have done all the necessary
preparations, it’s time to get your click™board
up and running. We have provided examples
for mikroC™, mikroBasic™and mikroPascal™
compilers on our Libstock website. Just
download them and you are ready to start.
.com
6. Dimensions
MikroElektronika assumes no responsibility
or liability for any errors or inaccuracies
that may appear in the present document.
Specication and information contained in
the present schematic are subject to change
at any time without notice.
Copyright © 2015 MikroElektronika.
All rights reserved.
mm mils
LENGTH 57.15 2250
WIDTH 25.4 1000
HEIGHT* 7.62 300
5. Schematic
9. Support
25.4 mm / 1000 mils
57.15 / 2250 mils
* without headers
10. Disclaimer
A dierent type of photo interrupter, one in
which the emitter and receiver face each other
is also available, with IR eclipse click™. Visit:
www.mikroe.com/click/ir-eclipse
7. IR eclipse click™
