Eaton ELC-CODNETM User manual

ELC-CODNETM Effective December 2010
Users Manual

ELC-CODNETM
MN05006002E FormoreInformationvisit:www.eaton.com 1
Introduction
3This is an OPEN-TYPE device and therefore should be installed in an enclosure free of airborne
dust, excessive humidity, shock and vibration. The enclosure should prevent non-maintenance
staff from operating the device (e.g. key or specific tools are required to open the enclosure) to
avoid potential equipment damage or personal injury. DO NOT touch any terminal when the power
is switched on.
3Please read this manual carefully and follow the instructions to avoid damage to the product or
personal injury.
Table of Contents
1Introduction............................................................................................................................2
2Specification ..........................................................................................................................2
3Product Profile and Outline..................................................................................................3
4Installation and Wiring..........................................................................................................4
5Input and Output Image mapping........................................................................................6
6Application.............................................................................................................................7
6.1 Using the CODNETM module as a polling master.....................................................7
6.2 Using Explicit Messages in the Application Program.............................................15
Microsoft® and Windows Internet Explorer® are the registered trade mark or trade mark
of Microsoft Corporation in the United States and other countries.
Java® is the registered trade mark or trade mark of Sun Microsystems, Inc. in the United
States or other countries.
The companies and products mentioned in this operation manual can be the trade mark
possessed by the owner of that trade mark right.

ELC-CODNETM
2 For more Information visit: www.eaton.com MN05006002E
1 Introduction
DeviceNet is an international, open and vendor- independent communication protocol widely
applied in industrial and process automation.
The ELC-CODNETM provides the ability for an ELC-PV processor to exchange data on a
DeviceNet network. The ELC-CODNETM can act both as a DeviceNet master and as a
DeviceNet slave.
Features
zSupports DeviceNet master and slave modes
zAs a master the CODNETM supports polled, bit-strobe, change of state and cyclic I/O
messaging.
zProvides continuous I/O scanning of slave devices
zProvides explicit messages triggered by ELC program
zSupport EDS file configure in ELCSoft software
zConnection size is flexible from 1 to 380 bytes in the input and output area
2 Specification
DeviceNet Physical and Transport layers
Interface Removable connector (5.08mm)
Transmission method CAN
Transmission cable 2-wire twisted shielded cable with 2-wire bus power cable and
drain
Electrical isolation 500VDC
Current draw from
DeviceNet supply Less than 50mA. All other power provided from the ELC supply
Message type I/O polled, bit-strobe, change of state/cyclic
Baud rates 125kbps, 250kbps, 500kbps
Product code 64
Product type 12
Vendor ID Eaton
Environmental Specifications and agency certifications
Noise immunity
ESD (IEC 61131-2, IEC 61000-4-2): 8KV Air Discharge
EFT (IEC 61131-2, IEC 61000-4-4): Power Line: 2KV, Digital I/O:
1KV,
Analog & communication I/O: 1KV
Damped-Oscillatory Wave: Power Line: 1KV, Digital I/O: 1KV
RS (IEC 61131-2, IEC 61000-4-3): 26MHz ~ 1GHz, 10V/m
Environment Operation: 0ºC ~ 55ºC (temperature); 50 ~ 95% (humidity);
pollution degree 2
Storage: -25 ºC ~ 70ºC (temperature); 5 ~ 95% (humidity)

ELC-CODNETM
MN05006002E FormoreInformationvisit:www.eaton.com 3
Vibration/shock
resistance Standard: IEC61131-2、IEC 68-2-6 (TEST Fc)/IEC61131-2 & IEC
68-2-27 (TEST Ea)
Certificates
3 Product Profile and Outline
IN0
SHLD
GND
CAN-
ERR
NODE ADDRESS
0
DR 2
DR 1
DR 0
x16
x16
1
POWER
RUN
2
4
6
7
8
5151
3
5
1. Extension port 2. Power, MS, NS LED
3. DIN rail clip 4. Digital indicator
5. Extension clip 6. Address switch
7. Function switch 8. DeviceNet connection port
Dimension
60 33.1
3
IN0
SHLD
GND
CAN-
ELC-CODNETM
ERR
NODE ADDRESS
0
DR 2
DR 1
DR 0
x16
x16
1
POWER
RUN
90 63.4
Unit: mm

ELC-CODNETM
4 For more Information visit: www.eaton.com MN05006002E
4 Installation and Wiring
Installing ELC-CODNETM With an ELC Controller
1. Adjust the extension clip on the left side of the controller.
2. Connect the extension port of the controller with ELC-CODNETM as the figure below.
3. Fasten the extension clip.
5
4
6
7
8
MS
NS
2
3
5
1
4
9
7
8
6
x10
x10
DR 1
DR 0
IN 1
IN 0
0
2
3
1
9
0
0
1
POWER
PIN Definition Of DeviceNet Connection Port
PIN Signal Color Content
1 V- Black 0 VDC
2 CAN_L Blue Signal-
3 Drain - Shield
4 CAN_H White Signal+
5 V+ Red 24 VDC
1
2
3
4
5
MAC ID Setting
Switch setting Content
0…63 Valid DeviceNet MAC ID setting
Others Invalid DeviceNet MAC ID setting
9
1
6
4
5
0
0
9
1
3
2
7
8
2
5
6
4
3
7
8
Function Switch Setting
DR1 DR0 Baud rate
OFF OFF 125kbps
OFF ON 250kbps
ON OFF 500kbps
Hold the I/O data
ON Hold the input and output buffer data when
unit losses DeviceNet communication
IN0
OFF Clear the input and output buffer data when
unit losses DeviceNet communication.
IN1 Reserved

ELC-CODNETM
MN05006002E FormoreInformationvisit:www.eaton.com 5
Connecting the ELC-CODNETM Scanner With Slave Devices
3
2
0
1
4
9
8
6
7
0
MS
NS
POWER
x10
5
3
2
4
0
1
5
DR 0
DR 1
x10
IN 1
IN 0
8
6
7
9
1
1
0
3
2
3
2
POWER
MS
NS
X0
X1
X2
X3
s
s
x10
1
6
7
8
5
7
5
6
8
44
00
1
99
1
5
6
5
6
44
X7
C0
Y0
X6
X5
Y2
C2
Y1
C1
IN 0
IN 1
DR1
DR0
9
1
8
9
8
1
00
RUN
STOP
ERROR
BAT.LOW
POWER
RUN
x10
0
77
33
X4
22
RS-485 RS-232
Y3
ELC-CODENTM
ELC-PC28NNDR/T
ELC-CODENT
ELC-PH12NNDR/T
ELC-PS01
DeviceNetAdapter
A
C Motor Driver
Cable Length and Baud Rates
The maximum cable length in a segment depends on the transmission speed. DeviceNet
communicates at speeds from 125kbps to 500kbps over distances from 100 to 500 meters.
Baud rates (bps) 125k 250k 500k
Length (m) 500 250 100
If you need more information on installing a DeviceNet network, see “DeviceNet Planning
and Installation Manual” available from ODVA.org.

ELC-CODNETM
6 For more Information visit: www.eaton.com MN05006002E
5 Input and Output Image mapping
Data exchange between ELC-CODNETM Scanner and the ELC processor
When the ELC-CODNETM scanner is connected to the ELC processor, it will map to a
section of the ELC processor data area (D registers).
Mapped d registers
Index of
ELC-CODNETM
scanner Output image table Input image table
1 D6250 ~ d6497 D6000 ~ d6247
2 D6750 ~ d6997 D6500 ~ d6747
3 D7250 ~ d7497 D7000 ~ d7247
4 D7750 ~ d7997 D7500 ~ d7747
5 D8250 ~ d8497 D8000 ~ d8247
6 D8750 ~ d8997 D8500 ~ d8747
7 D9250 ~ d9497 D9000 ~ d9247
8 D9750 ~ d9997 D9500 ~ d9747
The index is the relative position of the ELC-CODNETM module to the left side of the ELC
processor. The 1st module left of the ELC processor is index number 1. The next module to
the left is number 2. The others are indexed as 3, 4, and so on.
Input and Output Image Table contents
The table below shows the contents of the register map for an ELC-CODNETM with
index=1
Output image
D register Image mapping Length
D6250 ~ D6281 Explicit message program request 32 words
D6282 ~ D6285 Bit-strobe command 4 words
D6286 Reserved 1 word
D6287 ~ D6476 DeviceNet output data 190 words
D6477 ~ D6497 Reserved for other function (do not use these
devices in user program) 21 words
Input image
D register Image mapping Length
D6000 ~ D6031 Explicit message program response 32 words
D6032 ~ D6035 Scan list node status indication 4 words
D6036 Scanner module status indication 1 word
D6037 ~ D6226 DeviceNet input data 190 words
D6227 ~ D6247 Reserved for other function (do not use these
devices in user program) 21 words

ELC-CODNETM
MN05006002E FormoreInformationvisit:www.eaton.com 7
6 Application
6.1 Using the CODNETM module as a polling master
The ELC-CODNETM module is a polling master on DeviceNet that also supports slave
mode at the same time. The CODNETM module is configured using the DNET CONFIG tool
located in ELCSoft. Click the icon shown below to run DNET CONFIG.
When the DNET CONFIG icon is clicked, the following screen will open:

ELC-CODNETM
8 For more Information visit: www.eaton.com MN05006002E
To go online with the DeviceNet network, the computer must be connected to the ELC
controller which in turn is connected to the CODNETM module via the controller’s left-side
bus. In the DNET CONFIG software, select Setup, followed by Communication Setting, then
System Channel. The following screen will open:
These are the default communication parameters. Be sure to select the correct COM port
on your computer that is being used to connect to the ELC controller with the
ELC-CBPCELC3 programming cable. When the cable is connected and the interface
parameters are set, click the Network drop down menu and select Online and the following
screen will open:
In this case there is only one master communication module connected to the left-side bus

ELC-CODNETM
MN05006002E FormoreInformationvisit:www.eaton.com 9
of the ELC controller. Up to 8 communication modules are allowed. Click the module to
select it, then click OK and the software will scan the network for all connected DeviceNet
devices and display their icons as shown below. If a device is displayed as “Unrecognized”,
the eds file for that device must be registered into the DNET CONFIG software so the
module can be configured and placed into the CODNETM modules scan list. The eds files
for all Eaton DeviceNet devices can be found on the Eaton website. The eds files for
third-party DeviceNet products can be found on the manufacturer’s website. To register an
eds file into DNET CONFIG, click the Tools drop down menu, select “eds operation” and
follow the instructions to browse for the eds file and register it.
For this example, Eaton’s DeviceNet adapter for distributed I/O (ELC-CADNET) is the slave
device to be mapped into the CODNETM module’s scan list. When commissioning a
DeviceNet network, the following procedure should be used:
1. Configure each device with a unique MAC ID (0-63) and the same data rate (125K,
250K or 500K).
2. Configure each slave device for the amount of I/O needed for the application. Some
slave devices have fixed I/O sizes, but most have a list to choose from.
3. Map each slave device into the scanner’s (master’s) scan list and note the block of
D-registers in both the input and output image assigned to each slave device’s data.
4. Download the information to the scanner.

ELC-CODNETM
10 For more Information visit: www.eaton.com MN05006002E
The following is an example to illustrate the four points above.
Assume there are 2 devices on the DeviceNet network:
ELC-CODNETM Scanner
ELC-CADNET I/O Adapter
Right click the ELC-CADNET module’s icon and choose Parameter Edit and the following
will open:
Click “Read” and the software will begin reading each parameter listed from the device and
populate the entire list of parameters with the data from the device. When the upload is
complete, this parameter page will look like the following:

ELC-CODNETM
MN05006002E FormoreInformationvisit:www.eaton.com 11
It turns out that the CADNET module contains the following numbers of Input and Output
bytes of data for this example: 12 Input Bytes and 8 Output Bytes.
If any parameters were changed on the Parameter Edit screen, click the “Write” button to
download it to the CADNET module. Then, double click the ELC-CADNET icon and the
following screen will open:

ELC-CODNETM
12 For more Information visit: www.eaton.com MN05006002E
For polled operation, the only parameters that must be changed on this screen are under
“Polled Setting”. Be sure the Polled Setting box is checked. Then, per this example, change
the Input Size to 12 bytes and the Output Size to 8 bytes. Click OK to save and close this
window.
Right click on the scanner (ELC-COENETM) and choose Properties. The following screen
will open.

ELC-CODNETM
MN05006002E FormoreInformationvisit:www.eaton.com 13
The Polled Setting is where the CODNETM module can be configured as a DeviceNet slave,
assuming there is another DeviceNet scanner on the network to poll it. If there isn’t,
disregard this Properties page.
Click Cancel or OK to close the CODNETM Properties screen. Then double click the
CODNETM’s icon and the Scan list page will open as follows:

ELC-CODNETM
14 For more Information visit: www.eaton.com MN05006002E
All DeviceNet slave devices that are on the network will appear in the scanner’s Available
Nodes box above. Single click the ELC-CADNET module to select it, then click the arrow
pointing to the right to place the CADNET module into the Scan list. The I/O bytes
previously entered in the Properties page for the CADNET module (12 input bytes and 8
output bytes) will be mapped to D-registers. These D-registers are read from the ELC
controller (D6287 – D6476) and written to the ELC controller (D6037 – D6226) by the
CODNETM scanner module. The module also writes the output data to the appropriate
DeviceNet slave devices and reads the input data from the appropriate DeviceNet slave
devices. These D-registers are addressable in the ELC program, allowing it to control
devices via their output data and monitor status data via the devices input data.
Bit-strobe Command
Bit-strobe is one of the standard I/O transmission method for DeviceNet. The length of the
command is fixed to 8 bytes, i.e. 64 bits. Every bit corresponds to 1 slave.
Corresponding slave in network
Device in
ELC b15 b14 b13 … … b1 b0
D6282 Node15 Node14 Node 13 … … Node 1 Node 0
D6283 Node 31 Node 30 Node 29 … … Node 17 Node 16

ELC-CODNETM
MN05006002E FormoreInformationvisit:www.eaton.com 15
Corresponding slave in network
Device in
ELC b15 b14 b13 … … b1 b0
D6284 Node 47 Node 46 Node 45 … … Node 33 Node 32
D6285 Node 63 Node 62 Node 61 … … Node 49 Node 48
In the bit-strobe mode, the master does not send data to the slave. However, when the
corresponding bit is set to “0”, the slave has to respond with I/O data to the master. When
the corresponding bit is set to “1”, the slave does not need to respond with I/O data to the
master.
Network Node Status Indication
zScan List Node Status Indication
The scan module conducts real-time monitoring on the nodes in the scan list and maps
the status of each slave to a bit. The user can acquire the status of the slave in the
network by monitoring the contents in D6032 ~ D6035. See the table below for the
devices in the ELC and their corresponding nodes in the network.
Corresponding slave in network
Device in
ELC b15 b14 b13 … … b1 b0
D6032 Node 15 Node 14 Node 13 … … Node 1 Node 0
D6033 Node 31 Node 30 Node 29 … … Node 17 Node 16
D6034 Node 47 Node 46 Node 45 … … Node 33 Node 32
D6035 Node 63 Node 62 Node 61 … … Node 49 Node 48
When the node in the scan list is in normal (abnormal) status, its corresponding bit will
be Off (On).
zScanner Module Status Indication
The user can acquire the status of the scanner module by monitoring D6036. When the
scanner module is working normally, D6036 = 0. When the scanner module is being
initialized, the high byte of D6036 = 1 and the low byte of D6036 = 0. When error occurs
in the scanner module, the high byte of D6036 = 2. See the low bytes of D6036 for error
codes.
Explanation
Device in
ELC b15 b14 b13 b12 B11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
D6036 Status of the scanner module
(0: normal 1: initialize 2: error) Error codes of the scan module
6.2 Using Explicit Messages in the Application Program
Instructions in the ELC program can be used to trigger explicit messages from the
CODNETM module to another DeviceNet device.

ELC-CODNETM
16 For more Information visit: www.eaton.com MN05006002E
3
2
0
1
4
9
8
6
7
0
MS
NS
POWER
x10
5
3
2
4
0
1
5
DR0
DR1
x10
IN 1
IN 0
8
6
7
9
1
1
0
3
2
3
2
POWER
MS
NS
X0
X1
X2
X3
s
s
x10
1
6
7
8
5
7
5
6
8
44
00
1
99
1
5
6
5
6
44
X7
C0
Y0
X6
X5
Y2
C2
Y1
C1
IN 0
IN 1
DR 1
DR 0
9
1
8
9
8
1
00
RUN
STOP
ERROR
BAT.LOW
POWER
RUN
x10
0
77
33
X4
22
RS-485 RS-232
Y3
Exp Request (ELC to ELC-CODNETM)
Exp Request (ELC to ELC)-CODNETM
A
D
B
Slave explicit respons
e
Master explicit request
C
StepA: The ELC processor transfers the explicit message data to the ELC-CODNETM
scanner.
Step B: The ELC-CODNETM scanner sends the explicit request to the target devices.
Step C: The target devices process the request and send the response to the
ELC-CODNETM scanner.
Step D: The ELC processor receives the explicit response data.
Explicit Message Structure
The explicit message request and response are transferred between the ELC processor
and the ELC-CODNETM in D registers of the ELC processor.
Output image Input image
D register Image
mapping Length D register Image mapping Length
D6250 ~ D6281
Explicit
message
program
request
32 words D6000 ~ D6031
Explicit
message
program
response
32 words
The user can move the data of explicit request message to D6250 ~ D6281 and the
ELC-CODNETM scanner will send the response data to D6000 ~ D6031. The explicit
message request format is shown in the table below.

ELC-CODNETM
MN05006002E FormoreInformationvisit:www.eaton.com 17
Request Message
PLC device 15 14 13 12 11 10 98 7 6 5 4 3 2 1 0
D6250 ReqID Command
D6251 Port Size
D6252
Message Header
Service Code MAC ID
D6253 High byte of Class ID Low byte of Class ID
D6254 High byte of Instance ID Low byte of Instance ID
D6255
Message Data
Reserved Attribute ID (optional)
D6256 ~ D6281 Service Data
zReqID: When sending every explicit message, the user has to assign a Request ID for
this explicit message. ELC-CODNETM scanner identifies the response message by
this ID. Therefore, the user has to change the ID value when completing an explicit
message communication for the next transmission.
zCommand code: Fixed to 01 for every message transmission.
zPort: Reserved as 0 for every message transmission.
zSize: The length of the message, starting from D6253. The high bytes of D6255 are
reserved. When the data length is being calculated, D6255 is counted as 1 byte. The
maximum data length is 58 bytes. Errors will occur when the length is longer than 58
bytes. Unit: byte..
zService code: The service code of this explicit message.
zMAC ID: The node address of target devices.
The format of explicit message response:
Words Input explicit response
D6000 ReqID Status
D6001 Port Size
Message Header
D6002 Service code MAC ID
Message Data D6003 ~ D6031 Service response data
zThe definitions of ReqID, Port, Service Code and MAC ID are the same as their
definitions in request message.
zSize: The length of the message, starting from D6003. Max. 58 bytes. Errors will occur
when the length is longer than 58 bytes. Unit: byte.
zSee the table below for the meanings of Status (status codes):
Status Explanation
0 No explicit message is sent out.
1 The communication of explicit message is successful.
2 The explicit message is being sent out.

ELC-CODNETM
18 For more Information visit: www.eaton.com MN05006002E
Status Explanation
3 Error: No response from the target equipment.
4 Error: Command is invalid.
5 Error: Size of request message is invalid.
6 Error: Size of response message is invalid.
7 Error: Failing to establish a connection to the target equipment.
8 ~ 255 Reserved
