mikroElektronika USB SPI click User manual

2. Soldering the headers
USB SPI click™Manual
ver. 1.01a
0 100000 026618
click™
BOARD
www.mikroe.com
USB SPI click™is an accessory board in
mikroBUS™form factor. It’s a compact
and easy solution for adding SPI serial
communication via USB cable. It features
MCP2210 USB-to-SPI protocol converter
with GPIO as well as USB MINI B connector.
USB SPI click™communicates with target
board via SPI interface as a master device.
The board is designed to use 3.3V or 5V
power supply. It has a LED diode (GREEN)
that indicates the presence of power supply.
1. Introduction
2 3
1
Turn the board upward again. Make sure
to align the headers so that they are
perpendicular to the board, then solder
the pins carefully.
Turn the board upside down so that
the bottom side is facing you upwards.
Place shorter pins of the header into the
appropriate soldering pads.
Once you have soldered the headers your
board is ready to be placed into the desired
mikroBUS™socket. Make sure to align the
cut in the lower-right part of the board
with the markings on the silkscreen at the
mikroBUS™socket. If all the pins are aligned
correctly, push the board all the way
into the socket.
3. Plugging the board in
4. Essential features
USB SPI click™with its MCP2210 IC gives
additional SPI serial communication via
USB cable. The MCP2210 IC contains 256
Bytes of user EEPROM, 128 Byte buer to
handle data (64 byte transmit and 64-byte
receive) and nine general purpose I/O pins.
The board contains 12 MHz crystal oscillator
which provides external clock waveform for
MCP2210 IC as well as a LED diode which
indicates SPI trac.
USB SPI click™
Before using your click™board, make sure
to solder 1x8 male headers to both left
and right side of the board. Two 1x8 male
headers are included with the board in
the package.

8. Support
7. Code examples
.com
MikroElektronika assumes no responsibility or liability for any errors or inaccuracies that may appear in the present document.
Specication and information contained in the present schematic are subject to change at any time without notice. Copyright © 2014 MikroElektronika. All rights reserved.
5. USB SPI click™board schematic 6. SMD jumper
MikroElektronika oers free tech support
(www.mikroe.com/support) until the end
of the product’s lifetime, so if something
goes wrong, we’re ready and willing to help!
Once you have done all the necessary prep-
arations, it’s time to get your click™board up
and running. We have provided examples
for mikroC™, mikroBasic™and mikroPascal™
compilers on our Libstock website. Just
download them and you are ready to start.
There is one zero-ohm SMD jumper J1 which
is used to select whether 3.3V or 5V power
supply is used. Jumper J1 is soldered in 3.3V
position by default.
VCC3V3
SDO
SCK
SDI
1
2
3
4
5
6
7
8
9
10 11
12
13
14
15
16
17
18
19
20
VDD
OSC1
OSC2
RST
GP0
GP1
GP2
GP3
MOSI
GP4
GP7
GP6
VSS
D+
D-
VUSB
GP8
MISO
GP5
SCK
MCP2210
U1
R1
1K
R2
2K2
X1
12MHz
C3
22pF
C2
22pF
VCC5
C7
2.2uF
GP0
GP1
GP2
D_N
D_P
D_N
D_P RST/EN
RST/EN
SDO
SCK
SDI
GP0
GP1
GP2
GP4
GP5
GP5
LD1
YELLOW
R3
2K2
VCC
LED
LED
GP4
AN
RST
CS
SCK
MOSI
MISO
+3.3V
GND
PWM
INT
RX
TX
SCL
SDA
+5V
GND
MIKROBUS DEVICE CONN.
VCC
C1
100nF
E1
10uF
VCC5VCC3V3
C5
2.2uF
C4
2.2uF
1
2
3
IN
GND
OUT 5
4
EN ADJ
U2
AP7331-ADJ
R5
287K
R7
39K
R6
2K2
VCC
J1
LD3
POWER
VCC5
VCC3V3
VCC
FP1
FERRITE
C6
100nF
1
2
3
4
5GND
ID
D+
D-
VBUS
CN2
USB MINIB
VCC5
D1
PMEG3010ER
RST/EN
D2
PMEG3010ER
