MiLAN MIL-9200X User manual

MIL-9200X
MEDIA CONVERSION SYSTEM
USER’S GUIDE

LEGAL
Trademark Rights
© 2000 MiLAN, the MiLAN logo, and MiLAN Technology are either trademarks or registered trademarks of Digi
International, Inc. in the United States and/or other countries. All other trademarks are the property of their
respective holders. Information in this document is subject to change without notice and does not represent a
commitment on the part of MiLAN Technology. MiLAN Technology provides this document “as is,” without
warranty of any kind, either expressed or implied, including, but not limited to, the implied warranty of fitness or
merchantability for a particular purpose. MiLAN Technology may make improvements and/or changes in this
manual or in the product(s) and/or the program(s) described in this manual at any time.
This document could include technical inaccuracies or typographical errors. Changes are periodically made to the
information herein; these changes may be incorporated in new editions of the publication.
The MiLAN Technology Five-Year Limited Warranty
MiLAN Technology warrants to the original consumer or purchaser that each of its products, and all
components thereof, will be free from defects in material and/or workmanship for a period of five years
from the original factory shipment date. Any warranty hereunder is extended to the original consumer or
purchaser and is not assignable. MiLAN Technology makes no express or implied warranties including, but
not limited to, any implied warranty of merchantability or fitness for a particular purpose, except as
expressly set forth in this warranty. In no event shall MiLAN Technology be liable for incidental or
consequential damages, costs, or expenses arising out of or in connection with the performance of the
product delivered here under. MiLAN Technology will in no case cover damages arising out of the product
being used in a negligent fashion or manner.
Regulatory Approvals
FCC Class A
UL 1950
CSA 22 No. 950
EN60950
CE
– EN55022 Class A
– EN55024
Canadian EMI Notice
This Class A digital apparatus meets all the requirements of the Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.
European Notice
Products with the CE Marking comply with both the EMC Directive (89/336/EEC) and the Low Voltage
Directive (73/23/EEC) issued by the commission of the European Community. Compliance with these
directives implies conformity to the following European Norms:
EN55022 (CISPR 22) - Radio Frequency Interference
EN6100-X Electromagnetic Immunity
EN60950 (IEC950) - Product Safety
Year 2000 Compliance
MiLAN Technology warrants that the MIL-9200X is year 2000 compliant.
See www.milan.com for additional information on other products.
To Contact Technical Support
For prompt response when calling for technical support, have the following information ready: product serial
number, date of purchase, vendor or place of purchase.
Contact one of the following:
In North America: call +1.408.744.2751 or email: [email protected]
International: call +49.231.97.47.780 or email: [email protected]

MIL-9200X MEDIA CONVERSION SYSTEM
Chapter 1: Introduction
Chapter 1 gives an overall description of the MIL-9200X Media
Conversion System.
1.1 Overview of the MIL-9200X
The MIL-9200X Media Conversion System is a 16-slot rack mount
assembly that can support up to sixteen different MiLAN media
conversion devices.
MiLAN’s MIL-4750 Master and MIL-4755 Slave devices are used to man-
age the MIL-9200X using SNMP. The Master or Slave module is installed
in the rear of the MIL-9200X.
The Media Conversion System can accommodate media converters that
support Ethernet, Fast Ethernet, Gigabit Ethernet, ATM or a combina-
tion of all these technologies. The MIL-9200X is “hot-swappable,” mean-
ing you can remove and replace media converters without powering down
the device.
1.1.1 Features
The MIL-9200X offers the following features:
4Fits into a 19" rack in a 2U size slot
4One on-board power supply, with a second bay
for one additional hot swappable, load balancing,
redundant power supply
4Diagnostic LEDs indicating power supply status
1.2 Media Converters
The MIL-9200X supports a variety of MiLAN designed devices. Refer to
the individual device’s installation guide for configuration and installation
information for each device.
1-1

MIL-9200X MEDIA CONVERSION SYSTEM
Introduction
MiLAN Technology devices supported by the MIL-9200X include,
but are not limited to, the following products:
MIL-140TRM: Converter (2 km); 10BASE-T (UTP) to 10BASE-FL MMF (ST)
MIL-160TRM: Coverter (2 km); 10BASE-T (UTP) to 10BASE-FL SMF (ST)
MIL-170TRM: Converter (15 km); 10BASE-T (UTP) to 10BASE-FL SMF (ST)
MIL-180CRM: Converter (2 km); 100BASE-T (UTP) to 100BASE-FL MMF (SC)
MIL-180TRM: Converter (2 km); 100BASE-T (UTP) to 100BASE-FL MMF (ST)
MIL-190CRM: Converter (15 km); 100BASE-T (UTP) to 100BASE-FL SMF (SC)
MIL-240TRM: Redundant transceiver (2 km); 100BASE-TX (UTP) to 100BASE-TX (UTP)
MIL-225CRM: Converter (2-15 km); 100BASE-FX MMF (SC) to 100BASE-FX SMF (SC)
MIL-1225LSRM: Converter (.5-7 km); 100BASE-SX MMF (SC) to 1000BASE-LX SMF (SC)
MIL-C1411: Converter; 10BASE-T (UTP) to 10BASE2 (BNC)
MIL-C2412: Converter (2 km); 100BASE-T (UTP) to 100BASE-FL MMF (ST)
MIL-C2413: Converter (2 km); 100BASE-T (UPT) to 100BASE-FL MMF (SC)
MIL-C2413-15: Converter (15 km); 100BASE-T (UTP) to 100BASE-FL SMF (SC)
MIL-C2413-40: Converter (40 km); 100BASE-T (UTP) to 100BASE-FL SMF (SC)
MIL-C2413-70 (70km); 100BASE-T (UTP) to 100BASE-FL SMF (SC)
MIL-C2413-100 (100 km); 100 BASE-T (UTP) to 100 BASE-FL SMF (SC)
MIL-C2414: Converter (2 km); 100BASE-T (UTP) to 100BASE-FL MMF (MT)
MIL-C2414-15: Converter (15 km); 100BASE-T (UTP) to 100BASE-FL SMF (MT)
MIL-S3410: Switch; 10/100BASE-TX (UTP) to 10/100BASE-TX (UTP)
MIL-S3412: Switch; 10/100BASE-TX (UTP) to 100BASE-FL MMF (ST)
MIL-S3413: Switch; 10/100BASE-TX (UTP) to 100BASE-FL MMF (SC)
MIL-4750: Master SNMP agent; 10/100BASE-TX
MIL-4755: Slave SNMP Agent; 10/100BASE-TX
Contact MiLAN Technology sales at [phone] for more information on all of these devices.
1-2

MIL-9200X MEDIA CONVERSION SYSTEM
Chapter 2: Installation
Chapter 2 gives installation information for a MIL-9200X Media
Conversion System.
2.1 Installation Requirements
Before installing the MIL-9200X, make sure you have the following:
4MIL-9200X Media Conversion System
4Power supply (Two if necessary for redundancy)
4Two right-angle mounting brackets
4Four 10-32 x 1/2 Binding HD cap screws or equivalent
4Power cord
4Standard, Phillips screwdriver (not included)
2-1
Figure 2-1. MIL-9200X, with no Media Converters installed
Figure 2-2. Rear of MIL-9200X, with one power supply and blank panel

MIL-9200X MEDIA CONVERSION SYSTEM
Chapter 2
2.2 Installation
To install a MIL-9200X Media Conversion System:
1. Install the two mounting brackets, one on each side of the unit.
Line up the bracket holes to the holes on the chassis. Use the
phillips head screws (supplied) to secure the brackets.
2. Install the MIL-9200X into a 2U size slot in a rack. Use the screws
supplied with the rack to secure the device to the rack.
Note: For safety reasons, MiLAN recommends that two people install the
MIL-9200X. One person should hold the unit while the other secures
the MIL-9200X to the rack. Also, excessive jarring of the unit may
damage the internal components and void the warranty.
3. Add the second power supply, if applicable. (See section 2.3 of
this User’s Guide for more detailed instructions.)
4. Populate the bays with media converters and/or SNMP agents.
Refer to the individual device documentation for installation
instructions.
5. Plug the power cord (or cords) into the unit and then into the
appropriate power source. Power 1 and/or Power 2 LEDs will
illuminate.
6. Refer to the individual device documentation for installation of the
MIL-4750 Master or MIL-4755 Slave.
The device is now ready for network connections.
2-2

MIL-9200X MEDIA CONVERSION SYSTEM
2.3 Installing a Second Power Supply
To install a redundant power supply:
1. At the rear of the Media Conversion System, remove the
screws securing the blank face plate and remove it from the
chassis.
2. Place the edges of the power supply in the guide rails in the
open bay and slide the power supply module into the bay.
3. Press the power supply into the mating connector. Make
sure it is seated properly in the connector.
4. Secure the module with the two screws located on the face
plate of the power supply module.
2-3

MIL-9200X MEDIA CONVERSION SYSTEM
Appendix A: Specifications
A.1 Diagnostics LEDs
Table A-1 describes the status of the unit when an LED lights:
A-1
A.2 Hardware Features
Hardware features for the MIL-9200X Series:
4Enclosure: Two-part steel housing (black)
4Rack mount: 2U size
4Supports half- and full-duplex modes of operation (see the specific media
converter module documentation)
4Power supply: 110/220 VAC with an IEC connector, or a -48 VDC with a
Telco connector
A.3 Environmental Operating Conditions
LED
Power 1
Power 2
COLOR
Green
Green
FUNCTION
System power is applied to the
unit from the first power supply
System power is applied to the
unit from the second power supply
PARAMETERS
Operating temperature
Humidity: Non-condensing
Altitude test
Temperature test (Operating)
Temperature test (Packaged)
Table A-2: Recommended Operation Conditions
MINIMUM
+5o C
10%
Sea Level
5o C
-25o
MAXIMUM
40o C
95%
12,000 ft. (at 40o C)
50o C
70o C
Table A-1: Diagnostic LEDs

MIL-9200X MEDIA CONVERSION SYSTEM
Appendix B: Technical Support Services
B.1 World Wide Web Server
Product information, manuals, new product announcements,
programs, applications stories and more can be obtained through
the world wide web. Our address is:
http://www.milan.com
B.2 Internet FTP Server
MiLAN has set up an anonymous FTP server for those with
access to the Internet. The address is:
ftp://ftp.milan.com
B.3 Contacting Technical Support
To contact MiLAN’s technical support:
4By Phone: [phone]
4By Fax: [phone]
4By email: [email protected]
B.4 Expediting Technical Support Service
For faster service when calling our technical support department:
4Be in a position where the Media Conversion System is accessible
4Know the type of device the conversion system is connected to
4Note LED status
4Be specific about the problem(s)
B-1

MIL-9200X MEDIA CONVERSION SYSTEM
Appendix B
B.5 RMA Procedures
To return a unit to MiLAN Technology for repair:
1. Call Technical Support at 408.744.2751
2. Technical support engineers will work with users to find the
problem. If Technical Support determines that the unit is
defective, a Return Materials Authorization (RMA) will be
issued by our RMA administrator. The RMA administrator will
also provide shipping instructions.
NOTE: It is required that any return has an RMA number or it will be rejected and returned to the sender.
B-2

MiLAN Technology
1329 Moffett Park Dr
Sunnyvale, CA 94089
Part Number: 90000224 Rev BPrinted in the USA
