Milwaukee M12 PACKOUT AREA LIGHT User manual

OPERATOR'S MANUAL
Cat. No.
M12 POAL
M12™ PACKOUT™ AREA LIGHT
To reduce the risk of injury, user must read and understand operator's manual.
WARNING

2
IMPORTANT SAFETY
INSTRUCTIONS
WARNING
Read all safety warnings and all
•
PERSONAL SAFETY
instructions. Failure to follow the
warnings and instructions may result in electric
Save all warnings
and instructions for future reference.
WORK AREA SAFETY
•Toreduce therisk ofinjury,close supervision isnec-
essary when an appliance is used near children.
•Store idle light out of reach of children. Warm
lights can become hazardous in the hands of children.
•Do not expose to rain. Store indoors.
•
Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the light in unexpected situations.
Do not use on a ladder or unstable support. Stable
footing on a solid surface enables better control of
the light in unexpected situations.
•
BATTERY TOOL USE AND CARE
•
•Do not stare at the operating light source.
and combustible materials away from lens. Lens
may become hot after extended use.
•Prevent unintentional starting. Ensure the switch
-
tery pack, picking up or carrying the appliance.
or energising appliance that have the switch on
invites accidents.
•
•
•
•
manufacturer. A charger that is suitable for one type
with another battery pack.
packs. Use of any other battery packs may create a
Disconnect the battery pack from the appliance
before making any adjustments, changing acces-
sories, or storing appliance. Such preventive safety
measures reduce the risk of starting the appliance
accidentally.
When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects,
that can make a connection from one terminal to
another. Shorting the battery terminals together may
certain industrial chemicals, and bleach or bleach
containing products, etc., can cause a short circuit.
Do not use battery packs that have been exposed
Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact acci-
eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation or burns.
SERVICE
-
son using only identical replacement parts. This
will ensure that the safety of the light is maintained.
•Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorised service providers.
SPECIFIC SAFETY RULES
FOR LIGHTS
touch hot lens.
WARNING
The lens may get hot during use.
To reduce the risk of burns, do not
SAVE THESE
INSTRUCTIONS
•
Do not expose a battery pack or tool to fire or
excessive temperature. Exposure to fire or
temperature above 130°C (265°F) may cause
explosion.
•
•
Always use common sense and be cautious
when using tools. It is not possible to anticipate
every situation that could result in a dangerous
outcome. Do not use this tool if you do not
understand these operating instructions or you feel
the work is beyond your capability; contact
MILWAUKEE®Tool or a trained professional for
additional information or training.
Maintain labels and nameplates. These carry
important information. If unreadable or missing,
contact a MILWAUKEE®service facility for a
replacement.
•
Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specified in the
instructions. Charging improperly or at
temperatures outside the specified range may
damage the battery and increase the risk of fire.
WARNING
Do
batteries.
not charge non-rechargeable
ADDITIONAL BATTERY SAFETY RULES
WARNING
To
injur
y, reduce
and
the
product
risk of
damag
fire, e du personal
e to
a short circuit, never immerse your tool, battery
pack or charger in fluid or allow a fluid to flow inside
them. Corrosive or conductive fluids, such as
seawater, certain industrial chemicals, and bleach
or bleach-containing products, etc., can cause a
short circuit.
•
Do not use a battery pack or tool that is
damaged or modified. Damaged or modified
batteries may exhibit unpredictable behaviour
resulting in fire, explosion or risk of injury.
SPECIFICATIONS
Cat. No..................................................
Battery Type .................................................
DC Input Volts....................................................
Output Volts USB-A .............................................
Output Amps USB-A.........................................
Output Volts USB-C............................................
Operating Temperature
Output Amps USB-C............................................
Battery and Tool..............................
M12 POAL
M12™
12 V
5 V
2.1 A
5 V
3 A
-20°C to 40°C

3
SYMBOLOGY
Volts
Direct Current
Alternating Current
Amps
Do not step or stand.
Read operator’s manual
Universal Serial Bus (USB)
USB power button
Class III protection
Do not stare at light source.
The product was only suitable for
indoor use. Never expose the product
to rain.
Regulatory Compliance Mark (RCM).
This product meets applicable
regulatory requirements.
Do not dispose of electric tools
together with household waste
material. Electric tools and electronic
equipment that have reached the end
of their life must be collected
separately and returned to an
environmentally compatible recycling
facility
To insert the battery, open battery cover, tilt the
battery bay into the "insert/remove" (vertical)
position. Insert the battery, ensuring it latches
securely into place. Tilt the battery bay back down
into the "use" (horizontal) position and then close
and latch battery cover.
To remove the battery, open battery bay door and
and tilt the battery bay into the "insert/remove"
(vertical) position, push in the release buttons and
pull the battery pack away from the tool.
1
2
3
45678
9
10
ASSEMBLY
WARNING
Inserting/ Removing the Battery
Recharge only with the charger
specified for the battery. For
specific charging instructions, read the
operator’s manual supplied with your charger
and battery.
WARNING
Only use accessories specifically
recommended for this tool.
Others may be hazardous.
WARNING
Always remove battery pack
before changing or removing
accessories.
1. Light
2. Storage compartment
3. Battery cover
4. USB-C port
5. USB-A port
6. Fuel gauge
7. Power button
8. MODE button
power button9. USB
10.Handle
FUNCTIONAL DESCRIPTION

4
To rotate the light, pull the light upward. The light
can then be rotated upto a maximum of 280°. The
resting position is LED light facing down into
housing.
Using the Light
1. Insert the battery.
Medium, and Low.
2. Press the power button to turn ON the light.
3. Press the MODE button to cycle through High,
4. Press the power button to turn OFF the light.
NOTE:The light will default to the selected brightness
the next time it is turned on.
Rotating the Light
CAUTION
To reduce risk of overheating,
ensure the light is turned off
before storing or placing in the resting position.
USB Power Outlets
MAINTENANCE
WARNING
Maintaining Tool
To reduce the risk of injury,
always unplug the tool and
charger and remove the battery pack from the
charger or tool before performing any
maintenance. Never disassemble the tool,
battery pack or charger. Contact a
MILWAUKEE®service facility for ALL repairs.
WARNING
The light source of this luminaire
is not replaceable. When the light
source reaches its end of life, the whole
luminaire shall be replaced.
Keep your light, battery pack and charger in good
repair by adopting a regular maintenance program.
If the light does not work properly, return the light to
a MILWAUKEE®service facility for repairs.
The outlets can be used to charge a cell phone,
power an MP3 player or any other device that uses
less than 2.1A of DC electrical current (USB-A) and
less than 3A of DC electrical current (USB-C). To
turn on the USB outlets, press the
USB power button. The USB power button
will remain illuminated when the USB outlets are
on. The USB ports will remain on for 2 hours
maximum if a drop in charge rate is detected, or 90
seconds max if no device is charging.
NOTE: Any device that uses more than the above
DC electrical current values will trip a self-resetting
overload and disable the output.
Cleaning
Clean dust and debris from any vents. Keep tool
clean, dry and free of oil or grease. Use only mild
soap and a damp cloth to clean, since certain
cleaning agents and solvents are harmful to plastics
and other insulated parts. Some of these include
petrol, turpentine, lacquer thinner, paint thinner,
chlorinated cleaning solvents, ammonia and
household detergents containing ammonia. Never
use flammable or combustible solvents around
tools.
ACCESSORIES
WARNING
Use only recommended accesso-
ries. Others may be hazardous.
For a complete listing of accessories, go online to
milwaukeetool.com.au/milwaukeetool.co.nz. or
contact a distributor.
OPERATION
The fuel gauge will indicate the amount of charge
the inserted battery has. When the light is turned
ON the fuel gauge will indicate the current charge
remaining with the 4 LEDs. The fuel gauge will
display the battery life:
1 LED flashing: 10% or less remaining
1 LED: 20-40% remaining
2 LEDs: 40-60% remaining
3 LEDs: 60-80% remaining
4 LEDs: 80-100% remaining
Fuel Gauge
To reduce the risk of injury, do not
stare at the operating light source.
CAUTION

WARRANTY - AUSTRALIA and NEW ZEALAND
SERVICE - AUSTRALIA and NEW ZEALAND
MILWAUKEE®prides itself in producing a premium quality product that is Nothing But Heavy DutyTM.
Your satisfaction with our products is very important to us! If you encounter any problems with the
operation of this tool, please contact your authorised MILWAUKEE®dealer.
For a list of MILWAUKEE®dealers, guarantee or service agents please contact MILWAUKEE®
Customer Service or visit our website.
(Australia Toll Free Telephone Number 1300 645 928)
(New Zealand Toll Free Telephone Number 0800 645 928)
or visit milwaukeetool.com.au/milwaukeetool.co.nz.
Please refer to Australian and New Zealand warranty supplied with tool. This warranty applies only to
product sold by authorised dealers in Australia and New Zealand.
