MILWAUKEE ELECTRIC TOOL CORPORATION
13135 W. Lisbon Road, Brookfield, WI 53005
Drwg. 3
54-43-0060
SERVICE PARTS LIST BULLETIN NO.
0
00 EXAMPLE:
Component Parts (Small #) Are Included
When Ordering TheAssembly (Large #).
PAGE 1 OF 2
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
A90A
REVISED BULLETIN DATE
Mar. 2008
WIRING INSTRUCTION
STARTING
SERIAL NUMBER
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
BRAD NAILER
CATALOG NO. 7150-21
1 05-84-0835 Bolt Assembly 4
2 42-92-1440 Top Cap 1
3 42-38-0385 Bumper Band 1
4 42-76-0820 Valve Collar 1
5 40-50-3105 Upper Valve Spring 1
6 44-62-0270 Head Valve Piston 1
7 45-06-0935 Seal 1
8 44-90-0815 Piston Ring 1
9 --------------- Driver Assembly 1
10 34-40-3210 O-Ring, 23 mm x 2 mm 1
11 42-76-0810 Valve Collar 1
12 42-98-0365 Cylinder 1
13 34-40-3215 O-Ring, 32 mm x 2 mm 1
14 44-90-0725 Cylinder Ring 1
15 45-36-1650 Cylinder Spacer 1
16 34-40-3185 O-Ring, 47.5 mm x 2 mm 1
17 42-38-0305 Bumper 1
18 --------------- Driver Guide 1
19 45-06-0905 Top Cap Seal 1
20 05-84-0950 Set Screw M4 x 0.7-6 1
21 45-06-0955 Seal 1
22 43-64-0145 Trigger Valve Head 1
23 40-50-3190 Trigger Valve Spring 1
24 44-70-0260 Trigger Valve Plunger 1
25 34-40-3290 O-Ring 1
26 34-40-3160 O-Ring, 2.5 mm x 1.5 mm 1
27 34-40-3305 O-Ring 1
28 42-52-0415 Trigger Valve Plunger Cap 1
29 44-10-0660 Selector 1
30 40-50-3210 Selection Spring 1
31 40-50-3155 Spring 1
32 31-92-0205 Trigger Assembly 1
33 44-86-0710 Retainer 1
34 06-65-1435 Spring Pin, 3 mm x 25 mm 1
35 44-90-0825 Ring 1
36 28-50-0820 Tool Body 1
37 34-40-3155 O-Ring 2
38 44-94-0565 Link Rod 1
39 43-31-0380 Filter 1
40 43-44-1250 End Cap Gasket 1
41 42-70-0410 Spring Retainer (Belt Clip) 1
42 42-92-1370 End Cap 1
43 43-31-0365 Muffler 1
44 05-84-0975 Bolt, M5 x 0.8-25 1
45 31-05-0415 Deflector 1
46 40-50-3020 Spring 1
47 45-08-0460 Positioning Shaft 1
48 05-83-0535 Round Head Philips Bolt 2
62 44-90-0780 E-Ring 1
76 43-98-0765 Adjustment Knob 1
77 43-56-0885 Work Contact Element Guide 1
78 43-78-0450 Work Contact Element Spring Hub 1
79 40-50-3045 Work Contact Element Spring 1
80 44-90-0760 E-Ring 1
81 42-36-1990 Work Contact Element 1
82 44-94-0590 Adjustment Rod Assembly 1
83 42-36-2025 Work Contact Bracket B 1
84 05-84-0875 Bolt M4 x 0.7-4 1
85 42-36-1965 Work Contact ElementA 1
86 42-38-0340 No Mar Pad 1
90 02-02-2100 Ball 1
94 43-12-0267 Driver Assembly Kit 1
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1
2
4
5
6
7
3
8
9
10
20
11
12
13
14
15
16
17
37
38
35
33
19
36
21
18
24
26
27
31
22
23
25
28
34
30
29
32
74
85
86
80
84 83
82
81
80
79 77
46
90
78
76
42
43
40
39 44
45
44
48
20
46
47 41
21 22 23 24 25
26 27 28 35
92
9 18
49
94

49 --------------- Driver Guide 1
50 05-83-0505 Half Round Hex Bolt (M4 x 0.7-12) 1
51 42-92-1405 Cover, Driver Guide B 1
52 42-92-1390 Cover, Driver Guide A 1
53 44-60-1865 Fixed Pin 1
54 45-88-1705 Lock Handle Grip 1
55 06-65-1450 Spring Pin 1
56 44-20-0855 Lock Handle Assembly 1
57 43-40-0465 Magazine A 1
58 05-84-0880 Bolt, SHC, M4 x 0.7-6 1
59 42-36-2045 Work Contact Element Stop Bracket 1
60 40-50-3090 Work Contact Element Stop Pin 1
61 44-60-1880 Work Contact Element Stopper Pin 1
63 42-18-0300 Magazine Bar 1
64 40-50-3215 Magazine Latch Spring 1
65 44-20-0865 Latch 1
66 05-59-2040 Lock Nut, M4 x 0.7 1
67 43-72-0375 Pusher 1
68 45-08-0465 Pusher Spring Shaft 2
69 40-50-3125 Pusher Spring 2
70 43-40-0500 Magazine B 1
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
71 06-65-1445 Spring Pin 1
72 44-50-0200 Latch Pin 1
73 44-90-0765 E-Ring 1
74 05-84-0890 Bolt M4 x 0.7-22 1
75 42-92-1470 Protecting Hood Cover 1
87 05-84-0840 Bolt Assembly 2
88 05-84-0810 Bolt M4 x 0.7-6 1
89 44-86-0700 Retainer 1
91 45-88-1730 Flat Washer 1
92 31-94-0105 Trigger Valve Assembly 1
93 45-24-0035 Magazine Assembly 1
99 12-98-0320 Service Nameplate 1
101 10-20-3310 Warning Label 1
14-70-0130 Overhaul Kit (Not Shown)
14-70-0195 Driver Maintenance Kit (Not Shown)
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
Lubrication:
Type I Grease 49-08-7100
Clean all parts with a dry, clean cloth.
2, 4, 5, 6, 7 Place a thin coating of grease into internal bore of top cap (2). Coat parts (4 – 7) and reassemble in order shown.
8, 9, 10 Coat o-ring (10) and piston ring (8) prior to installing into groove of driver assembly (9).
18, 20, 23, 24 Coat o-ring (13), cylinder spacer (15), o-ring (16) and cylinder ring (14) prior to installing onto cylinder (12).
21, 22 23, 24, 25, 26 27,
28 Coat individual parts of the trigger valve assembly (21-27). Note: Plunger cover (28) does not require lubrication.
62
56 55
53
54 52
89
67
68
69
63
101
99
71
70
75
87
51
50
49
60
59
61
58
88
91
57
66
74
72
65
73
64 67 68 69
70 71 75
93

PAGE 2 OF 2
BULLETIN NO. 54-43-0060 Mar. 2008
Disassembly:
1, 2 Remove hex bolts (1) from top cap (2) using a 4mm hex key.
2, 4, 5, 6, 7 Remove valve assembly 4, 5, 6, and 7 from top cap (2) using a flat blade screwdriver.
11, 12 Remove press ring (11) from top of cylinder (12) prior to removing driver/cylinder assemblies.
8, 9, 10, 12, 13, 14, 15,
16, 17, 36 Remove driver assembly (8, 9, 10), and cylinder assembly (12, 13, 14, and 17), from tool body (36) at the same time by placing two flat blade screwdrivers under ring of cylinder (12) 180° apart, and gently prying the cylinder from the tool
body.
Note: Valve bumper (17) may stay in cylinder (12) or remain in tool body (36).
15, 16, 36 Remove cylinder spacer (15) and o-ring (16) from tool body (36) by placing a flat blade screwdriver under spacer (15) and
gently lifting spacer assembly out of the tool body (36).
57, 70, 88, 91 Remove magazine B (70) from magazine A (57) by removing screw/washer (88, 91).
29, 30, 31, 32, 33, 35, 36, Remove selector assembly (29, 30, 33, 35), and trigger assembly (31,32) from tool body (36) by placing a 3/32 in. (2.5
mm) punch inside half-moon slot of retainer (33) and gently tapping shaft of selector (29) to separate retainer (33) from
shaft (29). Remove spring (30), retainer (33) ring (35), spring, (31) and trigger (32) from tool body.
21, 22 23, 24, 25, 26, 27,
28, 36 Remove trigger valve plunger cap (28) from tool body (36) using an 8 mm wrench, and remove remaining trigger valve components (21-27).
20, 41, 42, 48 Remove belt clip (41) from end cap (42) by removing bolts (48) and loosening set screw (20) only a few turns
counterclockwise.
42, 45 Remove deflector (45) from end cap (42) using a flat blade screwdriver. Note: Using excessive force will damage or
destroy deflector.
Re-Assembly:
21, 22, 23, 24, 25, 26, 27,
28, 36 Reinstall trigger valve assembly components (21-28) into tool body (36) in order shown. Thread assembly into tool body (36) by hand a couple of turns to insure external threads on trigger valve plunger cap (28) properly engage with internal
threads inside tool body (36). Secure assembly using an 8 mm wrench.
24, 29, 30, 31, 32, 33, 35, Reinstall selection lever assembly (29, 30, 33, 35) and trigger assembly (31 and 32) by doing the following.
•Place spring (30) onto shaft of selection lever (29).
•Position spring (31) and trigger (32) over plunger of trigger valve assembly (24).
•Insert selection lever assembly (29 and 30) into tool body (36) and align half-moon slot of retainer (33) with half-
moon shaft of selection lever (29) and snap retainer assembly (33 and 35) onto the shaft.
9, 36 Install flat side of driver guide (9) towards front of tool body (36).
12, 14 Reinstall cylinder ring (14) onto cylinder (12) with large flanged end facing the top of cylinder (12).
8, 9, 10, 12, 13, 14, 15,
16, 17, 36 Reassemble driver assembly (8, 9, 10), and cylinder assembly (12, 13, and 14) and combine the two together. Set aside. Install cylinder spacer assembly (15, 16) and valve bumper (17) into tool body (36). Install assembly into tool body.
Note: Flat side of driver assembly (9) must face front of tool body (36).
6, 14, 19 Reinstall press ring (11) onto top of cylinder (12) with wide edge facing toward top cap (2).
2, 4, 5, 6, 7 Reinstall valve collar (4) into internal bore of top cap (2). Place upper valve spring (5) into center of valve collar (4) and push
head valve piston assembly (6 and 7) into top cap, applying sufficient pressure to insure seal and collar fit into position
inside top cap (2).
1, 2, 3, 36 Reinstall top cap assembly (2, 3, 4, 5, 6, and 7) onto tool body (36) using hex bolts (1).
Note: To properly seat top cap, tighten the screws at alternating corners a few turns at a time until all screws are secure.
57, 70, 88, 91 Reinstall magazine B (70) into magazine A (57) and install screw/washer (88, 91)
39, 42 Install smooth side of filter (39) toward end cap (42).
20, 41, 42, 48 Reassemble belt clip (41) onto end cap (42) and tighten set screw (20) until flush with the top thread of the clip. Install
bolts (48).
Apply Blue Loctite®242 to fastener threads (1), (44), (50), (58), (84) and (87).
