MISURA P23PW27DQI01B User manual

USER MANUAL ENGLISH
Model: P23PW27DQI01B – 75 Hz
MISURA MONITOR 27” FLAT
178°
Ultra Wide
Viewing Angle
Low Blue
Eyes Technology
QHD resolution
2560x1440
OD
Overdrive Time
Power Delivery
Technology
Adaptive
Sync
QHD 4 ms
Super TFT
display
IPS
Narrow Bezeles
Design

 Read these instructions - All the safety and operating instructions
should be read before this product is operated.
 Keep these instructions - The safety and operating instructions should
be retained for future reference.
 Heed all warnings - All warnings on the appliance and in the operang
instructions should be adhered to.
 Follow all instrucions - All operating and usage instructions should be
followed.
 Do not use this equipment near water, or in humid environments –
The appliance should not be used near water or moisture e.g. in a wet
basement or near a swimming pool.
 Clean only with a dry cloth. Do not use solvents or petroleum based fluids.
 Do not block any ventilation openings.
 Do not install near any heat sources such as radiators, stoves or other
apparatus (including amplifiers) that produce heat.
 Do not tamper with the supplied plug. This plug is a BS1363 standard plug.
 Protect the power cord from being walked on or trapped, particularly at
the plug and at the point where it exits from the appliance.
 Only use attachments/accessories specified by the manufacturer.
 Use only with a cart, stand, tripod, bracket or table specified by the
manufacturer or sold with the apparatus. When a cart or stand is used,
use caution when moving it to avoid any injuries or damage from it
tipping over.
 Unplug the apparatus during lightning storms or when unused for long
periods of time.
 Refer all servicing to qualified personnel. Servicing is required when the
apparatus has been damaged in any way, such as if the power supply
cord or plug is damaged, liquid has been spilled or objects have fallen
into the apparatus or it has been exposed to rain or moisture, it does not
operate normally or has been dropped.
 Please keep the unit in a well-ventilated environment.
 The monitor should only be connected to a mains power supply as rated
on the back of the equipment.
 To prevent overload, do not share the same power supply socket with
too many other electronic components.
 Do not place any connecting wires where they may be stepped on
or tripped over.
SAFETY INFORMATION

 Do not place heavy items on the cable as this may cause damage.
 When removing from a socket hold by the plug and not the wires.
 Disconnect the power immediately and seek professional help if the plug
or cable is damaged, liquid has spilt onto the set, if accidentally exposed
to water or moisture, if anything accidentally penetrates the ventilation
slots or if the set does not work normally.
 Do not remove the safety covers. There are no user serviceable parts
inside. Trying to service the unit yourself is dangerous and may invalidate
the product’s warranty. Only qualified personnel should service this
apparatus.
 Do not block ventilation slots on the back cover. The monitor can be
placed in a cabinet but ensure at least 5 cm (2’’) clearance all around.
Do not tap or shake the screen, this may damage Internal components.
 Warning: To reduce the risk of fire or electric shock, do not expose this
apparatus to rain or moisture. The apparatus shall not be exposed to
dripping or splashing and objects filled with liquids, such as vases, shall
not be placed on the apparatus.
 Warning: The wall plug socket is used as a disconnection device and
should remain readily accessible.
 Warning: The batteries shall not be exposed to excessive heat such as
direct sunlight or fire.
AT FULL VOLUME, PROLONGED LISTENING MAY
DAMAGE THE USERS HEARING.

MONITOR INPUTS
MONITOR CONTROL BUTTONS
12345
1|HDMI
2|DP
3|USB-C
4|AUDIO OUT
5|AC Power
1. Power. Press and hold the switch to turn it on, and take a look to
enter the selection menu mode.
2. UP. Change the value on selected menu/Switch a menu on OSD.
3. DOWN. Change the value on selected menu/ Switch a menu on OSD.
4. LEFT. Change the value on selected menu/ Switch a menu on OSD.
5. RIGHT. Change the value on selected menu/ Switch a menu on OSD.
ACCESSORIES
1|27 Inch Monitor
2|Stand
3|USB-C Cable
4|HDMI Cable
5|Power Adaptor and Power Cable
6|User manual

Press the Monitor Button ’’Enter’’ key when the screen is turned on.
The Function Key Guide will appear. To access the onscreen menu when
the guide is displayed, press the corresponding direction button again.
Funkcion Key Guide may vary depending on the function or product model.
Please refer to the actual product.
Selects by moving the monitor button in the function key guide
screen. Press to enable or disable ECO Mode.
Select to change the input signal by moving the monitor button in
the Function Key Guide screen. A message will appear on the top
left corner of the screen if the input signal has been changed.
Selects by moving the monitor button in the function key guide
screen. The OSD (On Screen Display) of your Monitor’s feature
appears.
Select to turn the Monitor off by moving the monitor button
in the function key guide screen.
Monitor
Button Action
FUNCTION KEY GUIDE

Connect the monitor to a power outlet.
1.
Press the POWER button on the monitor
or to turn it on (The indicator will be blue).
2. Connect the relevant cable to the
corresponding input on the monitor.
The source will be automatically detected.
3. To change between inputs, press the
“Source” button to enter the source menu.
Use the “” and“” buttons to choose the
input source between TYPE-C, DP and
HDMI.
INITIAL SETUP
TYPE C
DP
HDMI
Brightness
BRIGHTNESS: Allows the adjustment of the image brightness, according to
ambient light in the room. Value “0-100” |CONTRAST:Allows the adjustment
of the contrast between white and black areas of the image. Value “0-100”
ECO: Allows selection of image settings between the following: STANDARD,
TEXT, MOVIE, GAME. |DCR: Allows the dynamic contrast of the picture to
be turned ON and OFF |HDR 10: Allows to change the value between “OFF,
AUTO, 2084 “.
OSD MENU CONTROLS
OSD
BRIGHTNESS
BRIGHTNESS
DCR
HDR 10
OFF
STANDARD
50
80
CONTRAST
ECO
OFF

OSD
WIDE
ASPECT
ASPECT: Allows selection of video format of the between “WIDE,4:3 “.
COLOR TEMP.:Allows adjustment of the colour settings between the
following options: ”Normal – Warm - Cool - User”- 7500 - 5800 - SRGB
RED: Allows adjustment of the red element of the image
GREEN: Allows adjustment of the green element of the image
BLUE: Allows adjustment of the blue element of the image
LOW BLUE LIGHT: Allows adjustment of the low blue effect of the display,
value : 0-25-50-75-100.
BLACK LEVEL: Allows adjustment of the black level of the OSD, value“0-100”.
Color temp
OSD
50
50
50
0
COLOR TEMP
WARMCOLOR TEMP
LOW BLUE LIGHT
50
BLACK LEVEL
RED
GREEN
BLUE

OSD Setting
Reset
DP1
OSD
OSD SETTING
50
50
10
0
LANGUAGE
OSD H. POS
OSD V. POS
OSD TIMER
TRANSPARENCY
LANGUAGE: Allows selection of desired language: “ENGLISH, FRENCH,
TURKISH, ITALIAN, SPANISH, PORTUGUESE, CHINESE, DUTCH, JAPANESE,
GERMAN, POLISH, AND KOREAN.”
OSD H. POS: Allows adjustment of the horizontal position of the OSD
OSD V. POS: Allows adjustment of the vertical position of the OSD
OSD TIMER: Allows adjustment of the duration of the OSD, value “5-60”
TRANSPARENCY: Allows adjustment of the transparency of the OSD,
value “0-100”.
RESET: Returns the monitor to its factory default settings.
FLICKER FREE: Allows flicker free to be turned ON and OFF.
OSD
RESET
IMAGE AUTO ADJUS T
COLOR AUTO ADJUST
RESET
FLICKER FREE OFF

Misc
OSD
MISC
50
SIGNAL SOURCE HDMI
MUTE OFF
OFF
OFF
VOLUME
FREESYNC
OD
SIGNAL SOURCE: Allows user to choose the signal source of the display
“HDMI, DP and TYPE- C”.
VOLUME: Allows adjustment of the volume of the monitor from “0-100”.
FREE SYNC: Allows FreeSync to be turned ON and OFF.
MUTE: Allows Mute to be turned ON and OFF.
OD: Allows OD to be turned ON and OFF.

TECHNICAL SPECIFICATION
Model P23PW27DQI01B – 75 Hz
Screen Size 27”
Aspect Ratio 16:9
Backlight LED
Brightness 350 cd/m
Panel Type IPS
Resolution 2560  1440
Refresh Rate 75 Hz
Response Time 4 ms (with OD)
Viewing Angle 178° (H) / 178° (V)
Contrast Ratio 1000:1
VESA Mounting 100 x 100 mm
Colours 16.7M (8bit)
AMD FreeSync Supported
G-Sync Supported
HDR Supported
Signal Input HDMI+DP+USB-C
Audio out
Speakers 2x3W
Power Cable Supported
Input Cable HDMI 2.0, Type-C
Low Blue Light Supported
Flicker Free Supported
Power Consumption Typical 40W (without power delivery)
Power Type Internal power supply (AC 110-240V)

90°
HIGH ADJUSTABLE STAND
90° Rotation function
