Mitsubishi Electric MELSENSOR Vision Sensor VS20M-11F310 Instruction Manual

Vision Sensor Connection Guide
-VS20M-11F310 -VS80M-202-E
-VS20M-12F410 -VS80M-202-ER
-VS20M-13F410 -VS80M-202
-VS20C-12F410 -VS80M-202-R
-VS20C-13F410 -VS80M-402-E
-VS70M-600-E -VS80M-402-ER
-VS70M-600-ER -VS80M-402
-VS70M-600 -VS80M-402-R
-VS70M-600-R
-VS70M-800-E
-VS70M-800-ER
-VS70M-800
-VS70M-800-R
-VS70M-802-E
-VS70M-802-ER
-VS70M-802
-VS70M-802-R
-VS80M-100-E
-VS80M-100
-VS80M-200-E
-VS80M-200-ER
-VS80M-200
-VS80M-200-R
-VS80M-400-E
-VS80M-400-ER
-VS80M-400
-VS80M-400-R
This product is designed and manufactured by Cognex Corporation.
*Note that the warranty and general specifications of this product
differ from that of programmable controller products.

1
SAFETY PRECAUTIONS
(Read these precautions before using this product.)
Before using this product, please read this manual and the relevant manuals carefully and pay full attention to safety to handle
the product correctly.
The precautions given in this manual are concerned with this product only. For the safety precautions for other modules, refer
to their respective user's manuals.
In this manual, the safety precautions are classified into two levels: " WARNING" and " CAUTION".
Under some circumstances, failure to observe the precautions given under " CAUTION" may lead to serious
consequences.
Observe the precautions of both levels because they are important for personal and system safety.
Make sure that the end users read this manual and then keep the manual in a safe place for future reference.
[Installation Precautions]
[Installation Precautions]
[Wiring Precautions]
WARNING
●Before handling the product, touch a conducting object such as a grounded metal to discharge the
static electricity from your body. Failure to do so may cause the vision sensor to fail or malfunction.
●Be sure to install an I/O connector module to a main module. If not installed, dust or water-proof
performance may not be obtained.
CAUTION
●IP protection rating is guaranteed only when all the connectors are connected with cables or sealed
with sealing caps.
●The cable is designed to connect with its key aligned with the keyway of the connector on the Vision
Sensor. Do not force the connections or damage may occur.
CAUTION
●Use only 24 VDC and observe the indicated polarity. Otherwise, fire or damage may result.
●The frame ground terminal of the I/O module and the shield ground of each connector (RS232 OUT
port and SENSOR port) are internally conducting. The system ground is designed on the condition
that a ground connection is provided. The ground potential may affect the vision sensor and
peripheral devices such as programmable controllers via cables. For safe operation, it is
recommended to connect all the ground connections securely.
WARNING Indicates that incorrect handling may cause hazardous conditions, resulting in
death or severe injury.
CAUTION Indicates that incorrect handling may cause hazardous conditions, resulting in
minor or moderate injury or property damage.

2
[Startup and Maintenance Precautions]
CAUTION
●Do not clean the Vision Sensor VS20 with highly irritating or corrosive solvent such as caustic alkali
solution, methyl ethyl ketone (MEK), and gasoline. Doing so may cause a fault.

3
CONDITIONS OF USE FOR THE PRODUCT
(1) This vision sensor shall be used in conditions;
i) where any problem, fault or failure occurring in the vision sensor, if any, shall not lead to any major or serious
accident; and
ii) where the backup and fail-safe function are systematically or automatically provided outside of the vision sensor for
the case of any problem, fault or failure occurring in the vision sensor.
(2) This vision sensor has been designed and manufactured for the purpose of being used in general industries.
MITSUBISHI SHALL HAVE NO RESPONSIBILITY OR LIABILITY (INCLUDING, BUT NOT LIMITED TO ANY AND ALL
RESPONSIBILITY OR LIABILITY BASED ON CONTRACT, WARRANTY, TORT, PRODUCT LIABILITY) FOR ANY
INJURY OR DEATH TO PERSONS OR LOSS OR DAMAGE TO PROPERTY CAUSED BY THIS VISION SENSOR
THAT ARE OPERATED OR USED IN APPLICATION NOT INTENDED OR EXCLUDED BY INSTRUCTIONS,
PRECAUTIONS, OR WARNING CONTAINED IN MITSUBISHI'S USER, INSTRUCTION AND/OR SAFETY MANUALS,
TECHNICAL BULLETINS AND GUIDELINES FOR the VISION SENSOR.
("Prohibited Application")
Prohibited Applications include, but not limited to, the use of the vision sensor in;
• Nuclear Power Plants and any other power plants operated by Power companies, and/or any other cases in which the
public could be affected if any problem or fault occurs in the vision sensor.
• Railway companies or Public service purposes, and/or any other cases in which establishment of a special quality
assurance system is required by the Purchaser or End User.
• Aircraft or Aerospace, Medical applications, Train equipment, transport equipment such as Elevator and Escalator,
Incineration and Fuel devices, Vehicles, Manned transportation, Equipment for Recreation and Amusement, and
Safety devices, handling of Nuclear or Hazardous Materials or Chemicals, Mining and Drilling, and/or other
applications where there is a significant risk of injury to the public or property.
Notwithstanding the above, restrictions Mitsubishi may in its sole discretion, authorize use of the vision sensor in one or
more of the Prohibited Applications, provided that the usage of the vision sensor is limited only for the specific
applications agreed to by Mitsubishi and provided further that no special quality assurance or fail-safe, redundant or
other safety features which exceed the general specifications of the vision sensors are required. For details, please
contact the Mitsubishi representative in your region.

4
INTRODUCTION
Thank you for purchasing the Mitsubishi Electric FA sensor, MELSENSOR.
This manual describes the CC-Link IE Field Network Basic connection, SLMP scanner connection, and I/O connection to use
the vision sensors listed below.
Before using the product, please read this manual and relevant manuals carefully, and develop familiarity with the functions
and performance of the MELSENSOR vision sensor to handle the product correctly.
Please make sure that the end users read this manual.
Available vision sensors
INSTALLATION
To connect a vision sensor, the following must be installed on a networked personal computer.
■In-Sight Explorer
For information on how to obtain In-Sight Explorer, please contact your local Mitsubishi sales office or representative.
■Engineering tool
Install any of the following engineering software, depending on the programmable controller system used.
• GX Works3
• GX Works2
■Profile
To configure communication between a programmable controller and a vision sensor with an engineering tool, a profile of the
vision sensor needs to be registered to the engineering tool.
A profile is data that stores information of a connected device (such as a model name.)
By registering the profile to an engineering tool, vision sensors are added to "Module List" in the "Ethernet Configuration"
window and the "CC-Link IEF Basic Configuration" window.
For details on how to register a profile, refer to the following manual.
GX Works2 Version 1 Operating Manual (Common)
GX Works3 Operating Manual
For information on how to obtain a profile, please contact your local Mitsubishi Electric sales office or representative.
Product
name
Model
VS20 VS20M-11F310, VS20M-12F410, VS20M-13F410, VS20C-12F410, VS20C-13F410
VS70 VS70M-600-E, VS70M-600-ER, VS70M-600, VS70M-600-R, VS70M-800-E, VS70M-800-ER, VS70M-800, VS70M-800-R, VS70M-802-E,
VS70M-802-ER, VS70M-802, VS70M-802-R
VS80 VS80M-100-E, VS80M-100, VS80M-200-E, VS80M-200-ER, VS80M-200, VS80M-200-R, VS80M-400-E, VS80M-400-ER, VS80M-400, VS80M-
400-R, VS80M-202-E, VS80M-202-ER, VS80M-202, VS80M-202-R, VS80M-402-E, VS80M-402-ER, VS80M-402, VS80M-402-R

5
CONTENTS
CONTENTS
SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
CONDITIONS OF USE FOR THE PRODUCT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
CHAPTER 1 CC-Link IE Field Network Basic CONNECTION 7
1.1 System Configuration Example for Connecting a Vision Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Connection and wiring of a vision sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.2 Basic Operations for a CC-Link IE Field Network Basic Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Basic operation process for a CC-Link IE Field Network Basic connection . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Remote I/O signals (RX/RY) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Remote registers (RWr and RWw) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.3 Setting the Vision Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.4 Setting a Programmable Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Timing chart of a CC-Link IE Field Network Basic connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
1.5 Writing the Parameters and Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
1.6 Checking Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Making the vision sensor online . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Enabling a trigger on the vision sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Checking inspection results. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Changing a recognition parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Changing jobs (loading another job) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
CHAPTER 2 SLMP SCANNER CONNECTION 34
2.1 System Configuration Example for Connecting a Vision Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Connection and wiring of a vision sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
2.2 Basic Operations for an SLMP Scanner Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Basic operation process for an SLMP scanner connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Basic operations for an SLMP scanner connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Data blocks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
2.3 Setting the Vision Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
2.4 Setting a Programmable Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Timing chart of SLMP scanner connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
2.5 Writing the Parameters and Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
2.6 Checking Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Making the vision sensor online . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Enabling a trigger on the vision sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Checking inspection results. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Changing a recognition parameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Changing jobs (loading another job) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Controlling the vision sensor by using native mode commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
CHAPTER 3 I/O CONNECTION 66
3.1 System Configuration Example for Connecting a Vision Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Connection and wiring of a vision sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
3.2 Setting the Vision Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

6
3.3 Setting a Programmable Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Timing chart of an I/O connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
3.4 Writing the Parameters and Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
3.5 Checking Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Making the vision sensor online . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Enabling a trigger on the vision sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Checking inspection results. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
3.6 Using CIO-MICRO I/O module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
REVISIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87
TRADEMARKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88

1 CC-Link IE Field Network Basic CONNECTION
1.1 System Configuration Example for Connecting a Vision Sensor 7
1
1CC-Link IE Field Network Basic CONNECTION
This chapter explains the procedure for connecting a vision sensor VS20 to a programmable controller and controlling the
vision sensor with CC-Link IE Field Network Basic connection.
For details on CC-Link IE Field Network Basic, refer to the following manual.
CC-Link IE Field Network Basic Reference Manual
1.1 System Configuration Example for Connecting a
Vision Sensor
The following figure shows the system configuration for connecting a vision sensor VS20.
CC-Link IE Field Network Basic connection is available for other vision sensors (VS70 and VS80).
For details on the system configuration, refer to the user's manual of the vision sensor used.
(9) USB cable
(3) Engineering tool, Profile
(4) Vision sensor setup tool
(2) Programmable controller
(8) Ethernet cable
(8) Ethernet cable
(5) Ethernet cable
(COGNEX product)
(6) Breakout cable
(1) Vision sensor
100 V power supply
(7) Switching
hub
(10) 24 VDC
power supply

81 CC-Link IE Field Network Basic CONNECTION
1.1 System Configuration Example for Connecting a Vision Sensor
Configurations
The devices used in the system configuration are as follows.
Required equipment
■Mitsubishi Electric products
■COGNEX products
■Commercial products
For available devices for the system configuration, refer to the user's manual of the vision sensor used.
(1) Vision sensor
• VS20M-13F410
(2) Programmable controller
• CPU module: R08ENCPU
(3) Engineering tool, profile
•GXWorks3
(4) Vision sensor setup tool
• In-Sight Explorer
(5) Ethernet cable (COGNEX product) (6) Breakout cable
(7) Switching hub (8) Ethernet cable (9) USB cable (10) 24 VDC power supply

1 CC-Link IE Field Network Basic CONNECTION
1.1 System Configuration Example for Connecting a Vision Sensor 9
1
Connection and wiring of a vision sensor
This section shows the procedure for connecting and wiring a vision sensor.
Operating procedure
1. Check that the 24 VDC power supply is OFF.
2. Connect an I/O or a serial wire to an appropriate device (such as a programmable controller).
3. Connect the 24 VDC (red wire) and GND (black wire) of a breakout cable to the corresponding terminals on the power
supply.
4. Connect the M12 connector of the breakout cable to the Power, I/O and RS-232 connector of the vision sensor.
5. Turn ON the 24 VDC power supply.
Precautions
• When connecting a vision sensor and a programmable controller, simultaneously turn ON the power of the vision sensor
and programmable controller, or first turn ON the power of the programmable controller.
• Cut unused wires or protect them with insulating materials. Be careful not to short-circuit with 24 VDC wires.
• The cable is designed to connect with its key aligned with the keyway of the connector on the Vision Sensor. Do not force
the connections or damage may occur.
For details on the connection with a vision sensor, refer to the user's manual of the vision sensor used.

10 1 CC-Link IE Field Network Basic CONNECTION
1.2 Basic Operations for a CC-Link IE Field Network Basic Connection
1.2 Basic Operations for a CC-Link IE Field Network
Basic Connection
Basic operation process for a CC-Link IE Field Network Basic
connection
With a CC-Link IE Field Network Basic connection, data communication (cyclic transmission) is periodically performed
between a master station (programmable controller) and a slave station (vision sensor) using link devices.
Remote input and output (RY and RX), and remote registers (RWr and RWw) are used for data communication.
RX, RWr
RY, RWw
RX, RWr
RY, RWw
Device
Device
Link
refresh
Link
refresh
Link
scan

1 CC-Link IE Field Network Basic CONNECTION
1.2 Basic Operations for a CC-Link IE Field Network Basic Connection 11
1
Remote I/O signals (RX/RY)
The following shows the I/O signals for a master station (programmable controller) in a CC-Link IE Field Network Basic
connection.
The I/O signal assignment in the following tables is an example when the remote I/O signals of a vision sensor are assigned
for RX0 to RX3F and RY0 to RY3F.
For details on each data, refer to the help of In-Sight Explorer.
• Remote output (RY)
Remote output (RY) is a signal that is sent to a vision sensor from a mater station (programmable controller) used for the CC-
Link IE Field Network Basic connection.
• Remote input (RX)
Remote input (RX) is a signal that is sent to a mater station (programmable controller) from a vision sensor used for the CC-
Link IE Field Network Basic connection.
Remote registers (RWr and RWw)
The following shows the remote registers (RWr and RWw) used for the CC-Link IE Field Network Basic connection.
• Remote register (RWr)
• Remote register (RWw)
RY7 RY6 RY5 RY4 RY3 RY2 RY1 RY0
Set Offline Reserved Execute
Command
Inspection
Results Ack
Buffer Results
Enable
Trigger Trigger Enable
RYF RYE RYD RYC RYB RYA RY9 RY8
Reserved
RY17 RY16 RY15 RY14 RY13 RY12 RY11 RY10
Reserved Clear Exposure
Complete
Clear Error Reserved Set User Data
RY1F RY1E RY1D RY1C RY1B RY1A RY19 RY18
Soft Event 7 Soft Event 6 Soft Event 5 Soft Event 4 Soft Event 3 Soft Event 2 Soft Event 1 Soft Event 0
RY20..RY3F
User Data (Bit Area)
RX7 RX6 RX5 RX4 RX3 RX2 RX1 RX0
Online Offline Reason Missed Acq Reserved Trigger Ack Trigger Ready
RXF RXE RXD RXC RXB RXA RX9 RX8
Error Command Failed Command
Completed
Command
Executing
Results Valid Results Buffer
Overrun
Inspection
Completed
System Busy
RX17 RX16 RX15 RX14 RX13 RX12 RX11 RX10
Reserved Job Pass Exposure
Complete
Reserved Reserved Set User Data
Ack
RX1F RX1E RX1D RX1C RX1B RX1A RX19 RX18
Soft Event Ack 7 Soft Event Ack 6 Soft Event Ack 5 Soft Event Ack 4 Soft Event Ack 3 Soft Event Ack 2 Soft Event Ack 1 Soft Event Ack 0
RX20..RX3F
Inspection Results (Bit Area)
RWr0 RWr1 RWr2 RWr3 RWr4 RWr5..
Current Job ID Error Code Acquisition ID Inspection ID Inspection Result Code Inspection Results
RWw0 RWw1..
Command User Data

12 1 CC-Link IE Field Network Basic CONNECTION
1.2 Basic Operations for a CC-Link IE Field Network Basic Connection
For details on each data to control a vision sensor, refer to the help of In-Sight Explorer.
Enter "CC-Link IE Field Network Basic" as a keyword in the [Search] tab of Help, and refer to the explanation of the data.

1 CC-Link IE Field Network Basic CONNECTION
1.3 Setting the Vision Sensor 13
1
1.3 Setting the Vision Sensor
Start In-Sight Explorer to set the vision sensor.
Setting an IP address to a personal computer
Set the IP address (192.168.3.3) to a personal computer.
Connecting the vision sensor
Start In-Sight Explorer to set the vision sensor.
1. Start In-Sight Explorer.
2. Add the vision sensor to the network.
Click the [Add] button.
Add the vision sensor to the
network.
• IP Address: 192.168.3.1
• Subnet Mask: 255.255.255.0
Click the [Apply] button.
Ò
Ò
Ó

14 1 CC-Link IE Field Network Basic CONNECTION
1.3 Setting the Vision Sensor
3. Connect to the vision sensor.
Click the [Connect] button to
connect to the vision sensor.
Ò

1 CC-Link IE Field Network Basic CONNECTION
1.3 Setting the Vision Sensor 15
1
Creating a new job
As an example, set a CE mark for inspection target.
1. Create a new job.
2. Adjust so that the lens captures an inspection target in [Set Up Image], and configure the settings to acquire the image.
Click the [New Job] button.
Click the [Set Up Image] button.
Select the [Trigger] tab.
Select "Industrial Ethernet".
Click the [Live Video] button to
adjust the image. After adjusting the
image, click the [Live Video] button
again.
Ò
Ò
Ó
Ô
Õ

16 1 CC-Link IE Field Network Basic CONNECTION
1.3 Setting the Vision Sensor
3. Set a tool.
4. Set a model on the position to be detected.
Click the [Locate Part] button.
Select "Pattern".
Click the [Add] button.
Set a model. (CE mark is selected.)
Click the [OK] button.
Check that Name is "Pattern_1".
Ò
Ó
Ô
Ò
Ó
Ô

1 CC-Link IE Field Network Basic CONNECTION
1.3 Setting the Vision Sensor 17
1
Configuring a communication setting
1. Configure the communication setting (CC-Link IE Field Network Basic).
2. Add the CC-Link IE Field Network Basic.
Click the [Communication] button.
Click the [Add Device] button.
Configure a device setting.
• Device: PLC/Motion Controller
• Manufacturer: Mitsubishi
• Protocol: CC-Link IE Field Basic
Click the [OK] button.
When the [Protocol Service
Change Required] appears, click the
[OK] button.
Ò
Ó
Ó
Ô
Ò

18 1 CC-Link IE Field Network Basic CONNECTION
1.3 Setting the Vision Sensor
3. Add the data to be transmitted in the cyclic transmission of the CC-Link IE Field Network Basic.
Select the [Format Output Word
Data] tab.
Click the [Add] button.
Select the data to add in the
following order.
• Pattern_1.Pass
• Pattern_1.Fail
• Job.Inspection_Count
Click the [OK] button.
Ó
Ô
Ô
Õ
Ò
