Mitsubishi Electric City Multi Series Operating manual

TECHNICAL & SERVICE MANUAL
CONTENTS
1. PART NAMES AND FUNCTIONS..........2
2. SPECIFICATION.....................................5
3. OUTLINES AND DIMENSIONS..............7
4. WIRING DIAGRAM.................................8
5. REFRIGERANT SYSTEM DIAGRAM..........9
6. MICROPROCESSOR CONTROL.........10
7. TROUBLESHOOTING..........................15
8. DISASSEMBLY PROCEDURE.............22
Indoor unit
[Model names] [Service Ref.]
PKFY-P08NHMU-E2 PKFY-P08NHMU-E2
PKFY-P12NHMU-E2 PKFY-P12NHMU-E2
PKFY-P15NHMU-E2 PKFY-P15NHMU-E2
PKFY-P18NHMU-E2 PKFY-P18NHMU-E2
No. OCH515
INDOOR UNIT
SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
R22R410A
Note:
•This manual describes
only service data of the
indoor units.
•RoHS compliant products
have <G> mark on the
spec name plate.
April 2012
PARTS CATALOG (OCB515)

2
1PART NAMES AND FUNCTIONS
Indoor unit Filter Air intake
Louver Air outlet Vane
Use the specified refrigerant only
Never use any refrigerant other than that specified.
Doing so may cause a burst, an explosion, or fire when the unit is being used, serviced, or disposed of.
Correct refrigerant is specified in the manuals and on the spec labels provided with our products.
We will not be held responsible for mechanical failure, system malfunction, unit breakdown or accidents caused
by failure to follow the instructions.
OCH515

33
Wireless remote controller
ON/OFF TEMP
FAN
VANE
TEST RUN
AUTO STOP
AUTO START
h
min
LOUVER
MODE
CHECK
RESETSET CLOCK
MODEL SELECT
NOTAVAILABLE
CHECK TEST RUN
°C
AMPM
AMPM
°F
VANE CONTROL button
Used to change the air flow direction.
CLOCK button
RESET button
SET button
ON/OFF button
The unit is turned ON and OFF alternately
each time the button is pressed.
LOUVER button
Changes left/right airflow direction.
(Not available for this model.)
MODE SELECT button
Used to switch the operation mode between
cooling, drying, fan, heating and auto mode.
CHECK-TEST RUN button
Only press this button to perform an
inspection check or test operation.
Do not use it for normal operation.
FAN SPEED SELECT button
Used to change the fan speed.
TIMER display
Displays when in timer operation or when
setting timer.
button
SET TEMPERATURE button sets any desired
room temperature.
CLOCK display
Displays the current time.
“ ” “ ” display
Displays the order of timer operation.
“ ” “ ” display
Displays whether timer is on or off.
+In case the outdoor unit is cool only type,
the heating and auto mode are not
available.
Buttons used to set the “hour and minute” of
the current time and timer settings.
h and min buttons
display
display
FAN SPEED display indicates which fan
speed has been selected.
display
The vertical direction of air flow is indicated.
display
Blinks when model is selected.
display
display
CHECK and TEST RUN display indicate that
the unit is being checked or test-run.
display
OPERATION MODE display
Operation mode display indicates which
operation mode is in effect.
TIMER CONTROL buttons
AUTO STOP (OFF timer): when this switch is
set, the air conditioner will be automatically
stopped at the preset time.
AUTO START (ON timer): when this switch is
set, the air conditioner will be automatically
started at the preset time.
MODEL SELECT
CHECK TEST RUN
SET TEMP. display indicates the set desired
temperature.
Lights up while the signal is transmitted to
the indoor unit when the button is pressed.
OCH515

4
Wired remote controller
°F°C
°F°C
ERROR CODE
AFTER
TIMER
TIME SUN MON TUE WED THU FRI SAT
ON
OFF
Hr
AFTER
FILTER
FUNCTION
ONLY1Hr.
WEEKLY
SIMPLE
AUTO OFF
PAR-21MAA
ON/OFF
FILTER
CHECK
OPERATION
CLEAR
TEST
TEMP.
MENU
BACK DAY
MONITOR/SET
CLOCK
ON/OFF
Display Section
For purposes of this explanation,
all parts of the display are shown
as lit. During actual operation, only
the relevant items will be lit.
Identifies the current operation
Shows the operating mode, etc.
*Multilanguage display is available.
“Centrally Controlled” indicator
Indicates that operation from the
remote controller has been prohib-
ited by a master controller.
“Timer is Off” indicator
Indicates that the timer is off.
Temperature Setting
Shows the target temperature.
Day-of-Week
Shows the current day of the week.
Time/Timer Display
Shows the current time, unless the simple or Auto Off
timer is set.
If the simple or Auto Off timer is set, the time to be
switched off is shown.
“Sensor” indication
Displayed when the remote controller
sensor is used.
“Locked” indicator
Indicates that remote controller but-
tons have been locked.
“Clean The Filter” indicator
To be displayed on when it is time to
clean the filter.
Timer indicators
The indicator comes on if the corre-
sponding timer is set.
Up/Down Air Direction indica-
tor
The indicator shows the direc-
tion of the outcoming airflow.
“One Hour Only” indicator
Room Temperature display
Shows the room temperature. The room
temperature display range is 46–102°F.
The display blinks if the temperature
is less than 46°F or 102°F or more.
Louver display
Indicates the action of the swing louver.
Does not appear if the louver is not
running.
(Power On indicator)
Indicates that the power is on.
Fan Speed indicator
Shows the selected fan speed.
Ventilation indicator
Appears when the unit is running in
Ventilation mode.
Operation Section
Temperature setting buttons
Down
Up
Timer Menu button
(Monitor/Set button)
Mode button (Return button)
Set Time buttons
Back
Ahead
Timer On/Off button
(Set Day button)
Opening the
cover
ON/OFF button
Fan Speed button
Filter button
(<Enter> button)
Test Run button
Check button (Clear button)
Airflow Up/Down button
Louver button
( Operation button)
To return operation
number
Ventilation button
( Operation button)
To go to next operation
number
Built-in temperature sensor
Displayed if the airflow is set to
Low or downward during COOL
or DRY mode. (Operation varies
according to model.)
The indicator goes off in one hour,
at which time the airflow direction
also changes.
Note:
The phrase "Wired remote controller" in this manual refers only to the PAR-21MAA.
If you need any information for the other remote controller, please refer to either the installation manual or initial setting manual which are included in
remote controller's box.
OCH515

55
4.4
15,000
0.03
0.30
5.0
17,000
0.03
0.30
Note : Unit converter
kcal/h = kW × 860
Btu/h = kW × 3,412
cfm = m3/min × 35.31
lb = kg/0.4536
*Above specification data is
subject to rounding variation.
Service Ref.
Power source
Cooling capacity
(Nominal)
Heating capacity
(Nominal )
External finish
External dimension H × W × D
Net weight
Heat exchanger
Fan
Noise level (Low-Mid-High)
(measured in anechoic room)
Insulation material
Air filter
Protection device
Refrigerant control device
Connectable outdoor unit
Diameter of
refrigerant pipe
Field drain pipe size
Standard
attachment
Optional parts
Remarks
Power input
Current input
Power input
Current input
Type × Quantity
External
static press.
Motor type
Motor output
Driving mechanism
Airflow rate
(Low-Mid-High)
Liquid
Gas
Document
Accessory
External heater adapter
Installation
kW
Btu/h
kW
A
kW
Btu/h
kW
A
mm
in.
kg (lb)
Pa
mmH2O
kW
m3/min
L/s
cfm
dB <A>
mm (in.)
mm (in.)
mm (in.)
*1
*1
*2
*2
(R410A)
(R22)
(R410A)
(R22)
Installation Manual, Instruction Book
PAC-YU25HT
1-phase 208-230V 60Hz
Cross fin (Aluminum fin and copper tube)
DC motor
Direct-drive
Polyethylene sheet
PP honeycomb
Fuse
LEV
R410A, R22 CITY MULTI
PKFY-P12NHMU-E2
Plastic, MUNSELL (1.0Y 9.2/0.2)
3.5
12,000
0.03
0.30
4.0
13,500
0.03
0.30
295 × 898 × 249
11-5/8" × 35-3/8" × 9-13/16"
13 (29)
Line flow fan × 1
0
0
0.030
PKFY-P15NHMU-E2
9 - 10.5 - 12
150 - 175 - 200
320 - 370 - 425
36 - 41 - 45
I.D. 16mm (5/8")
ø6.35 (ø1/4")
ø6.35 (ø1/4")
ø12.7 (ø1/2")
ø12.7 (ø1/2")
Flare
Flare
Flare
Flare
ø6.35 (ø1/4")
ø6.35 (ø1/4")
ø12.7 (ø1/2")
ø12.7 (ø1/2")
Flare
Flare
Flare
Flare
PKFY-P18NHMU-E2
5.3
18,000
0.03
0.30
5.9
20,000
0.03
0.30
9 - 10.5 - 11.7
150 - 175 - 195
320 - 370 - 413
34 - 39 - 43
PKFY-P08NHMU-E2
2.3
8,000
0.03
0.30
2.6
9,000
0.03
0.30
ø6.35 (ø1/4")
ø6.35 (ø1/4")
ø12.7 (ø1/2")
ø12.7 (ø1/2")
Flare
Flare
Flare
Flare
9 - 10.5 - 11.7
150 - 175 - 195
320 - 370 - 413
34 - 39 - 43
ø6.35 (ø1/4")
ø9.52 (ø3/8")
ø12.7 (ø1/2")
ø15.88 (ø5/8")
Flare
Flare
Flare
Flare
—
—— —
9 - 10.5 - 11.7
150 - 175 - 195
320 - 370 - 413
34 - 39 - 43
*3
*1 Nominal cooling conditions
Indoor :
Outdoor :
Pipe length :
Level difference :
80°FDB/67°FWB (26.7°CDB/19.4°CWB)
95°FDB (35°CDB)
25 ft. (7.6 m)
0 ft (0m)
*2 Nominal heating conditions
70°FDB(21°CDB)
47°FDB/43°FWB (8.3°CDB/6.1°CWB)
25 ft. (7.6 m)
0 ft (0 m)
*3 Connect the joint
(purchased locally) for R22
* Due to continuing improvement, above specification may be subject to change without notice.
*3
Details on foundation work, insulation work, electrical wiring, power source switch, and other items shall be referred to
the Installation Manual.
2SPECIFICATION
2-1. Specifications
OCH515

6
Parts name
Service Ref. Symbol
TH21
TH22
TH23
TH24
FUSE
MF
MV
LEV
TB2
TB5
TB15
Resistance 30°F/15.8k, 50°F/9.6k, 70°F/6.0k, 80°F/4.8k, 90°F/3.9k, 100°F/3.2k
Resistance 30°F/15.8k, 50°F/9.6k, 70°F/6.0k, 80°F/4.8k, 90°F/3.9k, 100°F/3.2k
Resistance 30°F/15.8k, 50°F/9.6k, 70°F/6.0k, 80°F/4.8k, 90°F/3.9k, 100°F/3.2k
250V 3.15A
8-Pole Output 30W / RCOJ30-CK
MSFBC20 DC12V
(L1, L2, GR) 250V 20A
(M1, M2, S) 250V 20A
(1, 2) 250V 10A
Liquid pipe thermistor
Gas pipe thermistor
Linear expansion valve
PKFY-P08NHMU-E2 PKFY-P12NHMU-E2 PKFY-P15NHMU-E2
Room temperature
thermistor
Fuse
(Indoor controller board)
Fan motor
Vane motor
(with limit switch)
Power supply terminal
block
Transmission terminal
block
DC12V Stepping motor drive
Port :3.2 (0~2000pulse)
PKFY-P18NHMU-E2
MA remote controller
terminal block
PKFY-P08, 12, 15NHMU-E2
External static pressure : 0Pa
Power source : 208,230V, 60Hz
* Measured in anechoic room.
OCTAVE BAND PRESSURE LEVEL (dB) 0dB = 20MPa
3.3 ft. (1m)
Measurement location
PKFY-P12NHMU-E2
PKFY-P15NHMU-E2
PKFY-P18NHMU-E2
34-39-43
36-41-45
Sound level dB (A)
Sound level at anechoic room : Low-Middle-High
Service Ref.
PKFY-P08NHMU-E2
Approximate minimum
audible limit on
continuous noise
High speed
Low speed
3.3 ft.
(1m)
OCTAVE BAND CENTER FREQUENCIES(Hz)
PKFY-P18NHMU-E2
External static pressure : 0Pa
Power source : 208,230V, 60Hz
OCTAVE BAND PRESSURE LEVEL (dB) 0dB = 20MPa
OCTAVE BAND CENTER FREQUENCIES(Hz)
Approximate minimum
audible limit on
continuous noise
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC60
NC50
NC40
NC30
NC20
High speed
Middle speed
Low speed
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC60
NC50
NC40
NC30
NC20
2-2. Electrical parts specifications
2-3. Sound levels
2-4. NC curves
OCH515

77
OUTLINES AND DIMENSIONS
3
1/2F ( : 12.7)
1/4F ( : 6.35)
Refrig-
erart
Piping
Drain hose
Gas pipe
Liquid pipe
:2-1/2~:3-1/8
(:65~:80)
:2-1/2~:3-1/8
(:65~:80)
Through hole
Sleeve
(purchased locally)
Center measurement hole :3/32( : 2.5)
5/32(3.8)
2-1/4(58)
0
Wall hole for
left rear piping
Knockout hole for
rear piping
2-3/4×12-3/16(70×310)
Wall hole for
right rear piping
77-
: 3/16( : 5.1)
Tapping
screw hole
4- : 5/16( : 9) Bolt hole Mount board
Indoor unit outline
0
5/8(16)
9-15/16(253.5)
9-1/8(232.5)
1-1/16(28.5)
1-9/16(41)
3-1/16(78.5)
4-1/16(103.5)
4-9/16(116)
6-1/2(166)
7(178.5)
8(203.5)
3-9/16(91)
13/16(21.8)
9-1/16(231.5)
10-3/4(273.2)
0
1-1/4(32.7)
2-9/16(66)
2-1/16(53.5)
5(128.5)
6(153.5)
3/4(20)
9/16(15)
14-5/8(372.3) 14(356.3) 12-7/8(237.5) 11-7/16(291.5) 10-3/8(265) 9-5/16(238) 8-13/16(225) 7-13/16(200)
4-7/8(125)
2-3/4(70)
9/16(15)
14-5/8(372.3) 14(356.3) 12-7/8(327.5) 10-3/8(265) 11-7/16(291.5) 7-13/16(200) 8-13/16(225) 4-7/8(125) 2-3/4(70) 0
17-5/8(449)
7-9/16(193.5)
7-1/16(180.3)
6-9/16(167)
5-1/2(140)
4-1/2(115)
6-13/16(174)
8-3/8(213)
9-5/16(238)
10-15/16(278.3)
15-1/2(394)
11-1/16(281)
17-5/8(449)
0
Emergency operation switch
(cooling/heating)
Terminal block for
MA-remote controller
Terminal block for transmission
Front side(Grille open)
Terminal block for power supply
17-15/16(457)Gas pipe
21-3/16(539)Liquid pipe 6-5/8(169)
6-3/16(158)
24(610)Drain hose 7-3/16(184)
Required space(Indoor unit)
Air inlet
Air inlet
Air outlet
Min.1-31/32(50)
Min.9-13/16(250)
Min.5-7/8(150)
Min.8-5/8
(220)
Min.1-31/32(50)
Min.1/4(7)
Knockout hole for piping
D
2-3/16(56)
2-11/16(69)
3/16(6)
1-11/16(43)
C
2-3/16(56)7/16(12.5)
1-11/16(43)
B
1-3/4(46)
2-5/16(60)
2-5/16(59)
1-11/16(43)
A
1-11/16(43)
1-3/4(46)
2-3/16(56)
3/16(6)
A
Knockout hole
for right piping
Right side
Mount board
3/16(5)9-3/4(249)
Top side
15-3/16(387) 7-1/2(192)
7-3/4(197)
23-9/16(599)
CB
Operation lamp DEFROST/STAND BY lamp
Receiver
Louver(manual)
Vane(auto)
Knockout hole
for lower piping
Knockout hole
for lower piping
Under side
5/16(8)
24-1/16(612)
D
Knockout hole
for left piping
Left side
Front side
6-1/16(155)
2-1/8
(55) 27-1/16(688)
11-9/16(295)
35-5/16(898)
: 5/8 ( : 16) I.D
PKFY-P08NHMU-E2
PKFY-P12NHMU-E2
PKFY-P15NHMU-E2
PKFY-P18NHMU-E2
Unit : inch (mm)
OCH515

8
WIRING DIAGRAM4
<fig:+1>
Models
P08
SW2
123456
ON
OFF
P12 123456
ON
OFF
P15 123456
ON
OFF
P18 123456
ON
OFF
The black square ( ) indicates
a switch position.
FAN
CNMF
(WHT)
163
MS
3~
M
VANE
CN151
(WHT)
51 LEV
CN60
(YLW)
6
6
1
CNRU
(WHT)
LDSWE (A)
(BLU)
61
3
3
151
51
41
41
21
21
31
41
81
13
51
13
12
12345678
SW3
123456
SW2
ON
OFF
ON
OFF
1234
SW4
21
11 2
2
3
3
45678910
SW1
SWA
L1
L2
LED1
X1
LED2
M
FUSE
CND
(BLK)
CNP
(BLU)
RED BLU YLW BLK WHT
MF MV LEV
SWE
OFF
BZ1
ON
BLU
TB2
RED
RED
BLU
BLU
YLW
WHT
ORN ORN
ORN
ORN
YLW
BLU
BRN
BRN
RED
GRN/YLW
RED
BLU
BLK
I.B S.B
W.B
A.B
PULL
BOX
FUSE
( 16A) BREAKER ( 16A)
TO NEXT
INDOOR
UNIT
POWER SUPPLY
208/230V 60Hz
GRN
CN52
(GRN)
LD SWE (B)
LD101 (B) SWE1
LED1
TH24
TH23
TH22
TH21
LED2 SWE2
CN51
(WHT)
CN24
(YLW)
FLOAT SW
CN4F
(WHT)
LIQUID/GAS1
CN44
(WHT)
INTAKE
CN20
(RED)
ADDRESS
CN81
(RED)
ADDRESS
CN42
(RED)
GAS2
CN2G
(BLK)
ADDRESS
CN43
(RED)
ADDRESS
CN82
(RED)
MA-REMOCON
CN3A
(BLU)
M-NET
CN2M (BLU)
CN32
(WHT)
RU
4
8
t
ż
t
ż
t
ż
t
ż
See fig:+1
TB5
(SHIELD)
M1
M2
TB15
1
S
2
TO MA- REMOTE
CONTROLLER
DC8.7-13V
TO OUTDOOR UNIT
BC CONTROLLER
REMOTE CONTROLLER
DC24-30V
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
0 1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
SW14SW11SW12
10ths
DIGIT 1s DIGIT BRANCH No.
GR
<+2>
A.B ADDRESS BOARD
S.B SWITCH BOARD
W.B PCB FOR WIRELESS REMOTE CONTROLLER
SW1
SWA
SW11
SW12
MODE SELECTION
FAN SPEED SELECTOR
ADDRESS SETTING 1s DIGIT
SWE1
SWE2 EMERGENCY OPERATION(HEAT) EMERGENCY OPERATION(COOL)
LED(OPERATION INDICATOR:GREEN)
LED(OPERATION FOR HEATING :ORANGE )
RECEIVING UNIT
ADDRESS SETTING 10ths DIGIT
SW14 BRANCH No.
SWITCH
LED1
LED2
RU
SYMBOL NAME
TH21
THERMISTOR ROOM TEMP. DETECTION
(32°F/15k,77°F/5.4kȍ)
PIPE TEMP. DETECTION / LIQUID
(
32°F/15k,77°F /5.4kȍ)
PIPE TEMP. DETECTION / GAS1
(
32°F/15k,77°F /5.4kȍ)
TH22
TH23
PIPE TEMP. DETECTION / GAS2
(
32°F/15k,77°F /5.4kȍ)
TH24
NOTES:
1.At servicing for outdoor unit, always follow the wiring diagram of outdoor unit.
2.In case of using MA-Remote controller, please connect to TB15.
(Remote controller wire is non-polar.)
3.In case of using M-NET, please connect to TB5. (Transmission line is non-polar.)
4.Symbol [S] of TB5 is the shield wire connection.
5.Symbols used in wiring diagram above are, : terminal block, :connecter.
6.The setting of the SW2 dip switches differs in the capacity. For the detail, refer to the fig:1.
Mark Meaning Function
Power supply for
MA-Remote controller
Main power supply (Indoor unit: 208-230V)
Power on ĺIamp is lit
LED on indoor board for service
LED1 Main power supply
Power supply for MA-Remote controller
on ĺIamp is lit
LED2
<+2>Use copper supply wires.
SYMBOL NAME
I.B INDOOR CONTROLLER BOARD
BZ1
CN32
CN51
CN52
CONNECTOR
BUZZER
REMOTE SWITCH
CENTRALLY CONTROL
REMOTE INDICATION
X1 AUX.RELAY
FUSE FUSE (T3.15AL 250V)
LED1 POWER SUPPLY (I.B)
LED2 POWER SUPPLY (I.B)
MF
MV
LEV LINEAR EXPANSION VALVE
FAN MOTOR
VANE MOTOR
DRAIN PUMP
TB2
TB5
TB15 TRANSMISSION
MA-REMOTE CONTROLLER
TERMINAL
BLOCK POWER SUPPLY
SW2
SW3
SW4
SWE
CAPACITY CODE
MODE SELECTION
MODEL SELECTOR
DRAIN PUMP (TEST MODE)
SWITCH
EXTERNAL HEATER
CN24
PKFY-P08NHMU-E2
PKFY-P12NHMU-E2
PKFY-P15NHMU-E2
PKFY-P18NHMU-E2
OCH515

9
5REFRIGERANT SYSTEM DIAGRAM
Strainer (#50mesh)
Strainer (#100mesh)
Strainer1 (#50mesh)
Strainer2 (#100mesh)
Heat exchanger
Room temparature thermistor TH21
Gas pipe thermistor TH23
Liquid pipe thermistor TH22
Linear expansion valve
Gas pipe
Liquid pipe
Flare connection
Gas pipe
Liquid pipe
PKFY-P08,12,15,18NHMU-E2
:12.7(1/2)
:6.35(1/4)
Item Service Ref. Unit : mm (inch)
Gas pipe thermistor TH24
PKFY-P08NHMU-E2
PKFY-P12NHMU-E2
PKFY-P15NHMU-E2
PKFY-P18NHMU-E2
OCH515

10
6MICROPROCESSOR CONTROL
PAR-21MAA
ON/OFF
FILTER
CHECK
OPERATION
CLEAR
TEST
TEMP.
MENU
BACK DAY
MONITOR/SET
CLOCK
ON/OFF
ûF ûC
ûF ûC
ERROR CODE
AFTER
TIMER
TIME SUN MON TUE WED THU FRI SAT
ON
OFF
Hr
AFTER
FILTER
FUNCTION
ONLY1Hr.
WEEKLY
SIMPLE
AUTO OFF
INDOOR UNIT CONTROL
6-1. COOL OPERATION
<How to operate>
Press POWER ON/OFF button.
Press the operation MODE button to display COOL.
Press the TEMP. button to set the desired temperature.
NOTE: The set temperature changes 2°F when the or button is
pressed one time. Cooling 67 to 87°F
Control modes Control details
1-1. Thermostat function (Function to prevent restarting for 3 minutes)
• Room temperature desired temperature + 2°F
···Thermo ON
• Room temperature desired temperature ···Thermo OFF
1-2. Anti-freezing control
Detected condition : When the liquid pipe temp. (TH22) is 32°F or less in 16
minutes from compressors start up, anti-freezing control
starts and the thermo OFF.
Released condition : The timer which prevents reactivating is set for 3 minutes,
and anti-freezing control is cancelled when any one of the
following conditions is satisfied.
Liquid pipe temp. (TH22) turns 50°F or above.
The condition of the thermo OFF has become complete
by thermostat, etc.
The operation modes became mode other than COOL.
The operation stopped.
By the remote controller setting (switch of 3 speeds+Auto)
When [Auto] is set, fan speed is changed depending on the value of:
Room temperature - Desired temperature
2. Fan
1. Thermostat
function
Remarks
Type Fan speed notch
[Low], [Mid], [High], [Auto]
3 speeds + Auto type
ĺ
(1)Initial setting: Start at COOL mode and horizontal vane.
(2)Vane position:
Horizontal ĺDownward A ĺDownward B ĺDownward CĺDownward DĺSwingĺAuto
(3)Restriction of the downward vane setting
When setting the downward vane A, B, C or D in [Mid], [Low] or [Auto] of the fan
speed notch, the vane changes to horizontal position after 1 hour have passed.
3. Vane
(up/down vane change)
· "ONLY 1 Hr"
appears on the
wired remote
controller.
OCH515
