JG79A191H03 Required Tools for Installation
© MITSUBISHI MSZ-GE06/09/1 2i4 5/4 8NA pilips screwdriver pean. mn) hexagonal wrench
MSY- 5. A Scal G ifold for R410A
£ ELECTRIC Utiity knife or scissors Vacuum pump for RA1OA
When installing multi units, refer to the :
SPLIT-TYPE AIR CONDITIONERS installation manual of the multi unit for out- 3 in. (75 mm) hole saw Charge hose for R410A
INSTALLATION MANUAL door unit installation. Torque wrench Pipe cutter with reamer
Wrench (or spanner)
1. BEFORE INSTALLATION
1-1. THE FOLLOWING SHOULD ALWAYS BE OBSERVED FOR SAFETY
Be sure to read these safety precautions and instructions.
Be sure to observe the warnings and cautions specified here.
After reading this manual, be sure to store it with the OPERATING INSTRUCTIONS for future reference.
Please report to your supply authority or obtain their consent before connecting this equipment to the power supply system.
A WARNING (Could lead to death or serious injury.)
@ Do not install the unit by yourself (user). @ Securely attach the electrical cover to the indoor unit and the service panel to
Improper or incomplete installation could cause fire, electric shock, injury due to the outdoor unit.
the unit falling, or water leakage. Consult a qualified installer or the dealer from If the electrical cover of the indoor unit and/or the service panel of the outdoor unit are
whom you purchased the unit. not attached securely, dust, water, etc. could collect in the unit and could cause a fire or
@ Follow the instructions detailed in the installation manual. an electric shock.
Incomplete installation could cause fire or electric shock, injury due to the unitfall- i When installing or relocating the unit, make sure that no substance other than
ing, or leakage of water. the specified refrigerant (R410A) enters the refrigerant circuit.
@ Install the unit securely in a place that can bear the weight of the unit. Any foreign substances in the refrigerant circuit can cause abnormal pressure rise
If the installation location cannot bear the weight of the unit, the unit could fall or an explosion.
causing injury. & Do not discharge the refrigerant into the atmosphere. Check that the refriger-
@ Perform electrical work according to the installation manual and be sure to use ant gas does not leak after installation has been completed. If refrigerant leaks
an exclusive circuit. Do not connect other electrical appliances to the circuit. during installation, ventilate the room.
If the capacity of the power circuit is insufficient or there is incomplete electrical If refrigerant comes in contact with a fire, harmful gas could be generated.
work, it could result in a fire or an electric shock. If refrigerant gas leaks indoors, and comes into contact with the flame of a fan
Ground the unit correctly. heater, space heater, stove, etc., harmful gases will be generated.
Do not connect the ground wire to a gas pipe, water pipe, lightning rod or tel- & Use appropriate tools and piping materials for installation.
ephone ground. Defective grounding could cause electric shock. The pressure of R410A is 1.6 times higher than R22. Not using the appropriate
@ Do not damage the wires. tools and materials, or improper installation could cause the pipes to burst causing
Damaged wires could cause fire. an injury.
@ Be sure to shut off the main power when setting up the indoor P.C. board or Hf When pumping down the refrigerant, stop the compressor before disconnecting
wiring. the refrigerant pipes.
Failure to do so could cause electric shock. If the refrigerant pipes are disconnected while the compressor is running and the
fl Use the specified wires to securely connect the indoor and outdoor units. At- stop valve is open, air could be drawn in and the pressure in the refrigeration cycle
tach the wires firmly to avoid applying stress to the terminal block. could become abnormally high, causing the pipes to burst.
Improper connection could cause fire. & When installing the unit, securely connect the refrigerant pipes before starting
@ Do not install the unit in a place where flammable gas may leak. the compressor.
If gas leaks and accumulates around the unit, it could cause an explosion. lf the compressor is started before the refrigerant pipes are connected and the
Do not use intermediate connection of the power cord or the extension cord. stop valve is open, air could be drawn in and the pressure in the refrigeration cycle
Do not connect many devices to one AC outlet. could become abnormally high, causing the pipes to burst.
It could cause a fire or an electric shock. @ Fasten a flare nut with a torque wrench as specified in this manual.
i@ Use the parts provided or specified parts for the installation work. If fastened too tight, a flare nut could break and cause refrigerant leakage.
The use of defective parts could cause an injury or leakage of water due to a fire, & Install the unit according to national wiring regulations.
an electric shock, the unit falling, etc.
i When plugging the power supply plug into the outlet, make sure that there is
no dust, blockage, or loose parts both in the outlet and on the plug. Verify that
the power supply plug is completely in the outlet.
If there is dust, blockage, or loose parts on the power supply plug or the outlet, it could
cause electric shock or fire. If loose parts are found on the power supply plug, replace it.
Depending on the installation area, install a Ground Fault Interrupt (GF) circuit Hi Do not touch the air inlet or the aluminum fins of the outdoor unit.
breaker. This could cause injury.
If the Ground Fault Interrupt (GFI) circuit breaker is not installed, an electric shock #& Do not install the outdoor unit where small animals may live.
could occur. If small animals enter the unit and damage its electrical parts, it could cause a
i@ Perform the drainage/piping work securely according to the installation malfunction, smoke emission, or fire. Keep the area around the unit clean.
manual.
If there is defect in the drainage/piping work, water could drip from the unit, and
damage household items.

1-2. SELECTING THE INSTALLATION LOCATION
INDOOR UNIT
Where airflow is not blocked.
Where cool air spreads over the entire room.
On a rigid wall to reduce the possibility of vibration.
Where it is not exposed to direct sunlight.
Where it can be easily drained.
At a distance 3 ft. (1 m) or more away from a TV and
radio. Operation of the air conditioner may interfere
with radio or TV reception. An amplifier may be re-
quired for the affected device.
« In a place as far away as possible from fluorescent
and incandescent lights (so the infrared remote control
can operate the air conditioner normally).
« Where the air filter can be removed and replaced easily.
Note:
Install the indoor unit high on the wall where air can dis-
tribute over the entire room.
REMOTE CONTROLLER
« Where it is convenient to operate and easily visible.
« Where children cannot easily touch it.
« Select a position about 4 ft. (1.2 m) above the floor.
Check that signals from the remote controller from
that position are received by the indoor unit (‘beep’
or ‘beep beep’ receiving tone sounds). Then, attach
remote controller holder to a pillar or wall and install
wireless remote controller.
1-3. SPECIFICATIONS
1-3-1. POWER SUPPLY AND INDOOR/OUTDOOR
WIRE CONNECTION
« Power should be taken from an exclusive branched circuit.
« Wiring work should be based on applicable technical stand-
ards.
« Wiring connections should be made following the diagram.
« Securely tighten screws.
Connecting wires and the ground wire
« Use solid conductor AWG14 or stranded conductor AWG14.
« Use double insulated copper wire with 600 V insulation.
« Use copper conductors only.
* Follow local electrical codes.
Power supply cable and ground wire
« Use solid or stranded conductor AWG14.
« Use copper conductors only.
* Follow local electrical codes.
Note:
When the indoor unit is powered from the outdoor unit, depend-
ing on local code, a disconnect switch needs to be installed to a
power supply circuit.
Note:
In rooms where inverter type fluorescent lamps are used,
the signal from the wireless remote controller may not be
received.
OUTDOOR UNIT
« Where it is not overly exposed to strong winds.
« Where airflow is good and dustless.
« Where neighbours are not annoyed by operation
sound or hot air.
Where rigid wall or support is available to prevent the
increase of operation sound or vibration.
« Where there is no risk of combustible gas leakage.
If installing the unit in a location high above the ground,
be sure to secure the unit legs.
« Where it is at least 10 ft. (8 m) away from the antenna
of TV set or radio. Operation of the air conditioner may
interfere with radio or TV reception in areas where re-
ception is weak. An amplifier may be required for the
affected device.
« Install the unit horizontally.
« Please install it in an area not affected by snowfall or
blowing snow. In areas with heavy snow, please install
a canopy, a pedestal and/or baffle boards.
Electrical specifications
MODEL MSZ-GEO6NA
Power supply (V, PHASE, Hz)
Min. Circuit Ampacity (A)
Fan motor (F.L.A.) (A)
Power supply (V, PHASE, Hz)
Max. Fuse size (time delay) (A)
Min. Circuit Ampacity (A)
Fan motor (F.L.A.) (A)
MSZ
MSY
MSZ
MSY
(R.LA) (A)
Compressor
(LR.A) (A)
Control voltage
*
unit for details.
ee, Ea eee
Note:
* It is advisable to make a piping loop near outdoor unit
so as to reduce vibration.
« For increased efficiency, install the outdoor unit in a
location where continuous direct sunlight or excessive
water can be avoided as much as possible.
Note:
When operating the air conditioner in low outside tem-
perature, be sure to follow the instructions described
below.
* Never install the outdoor unit in a place where its air
inlet/outlet side may be exposed directly to wind.
* To prevent exposure to wind, install the outdoor
unit with its air inlet side facing the wall and a baffle
board on the air outlet side.
Avoid the following places for installation where air
conditioner trouble is liable to occur.
« Where flammable gas could leak.
« Where there is an excessive amount of machine oil
in the air.
* Salty places such as the seaside.
« Where sulfide gas is generated such as a hot spring.
* Where there is high-frequency or wireless equipment.
MSZ-GEOSNA | MSZ-GE12NA | MSZ-GE15NA | MSZ-GE18NA
MSY-GEOSNA | MSY-GE12NA | MSY-GE15NA | MSY-GE18NA
208/230, 1, 60
1.0
0.76
208/230, 1, 60
15
12
0.50
6.6
4.9
8.2 8.2 9.3
61 6.1 8.5
Indoor unit - Remote controller: (Wireless)
15
12
0.50
6.6
4.9
15
12
0.50
TA
6.8
Indoor unit - Outdoor unit: DC12-24 V (Polar)
MSZ-GEO6NA is a dedicated indoor unit for multi system. Refer to the installation manual of the multi
1-3-2. REFRIGERANT PIPES Outside di i Minimum wall Insulation
* To prevent condensation, insulate the two refrigerant pipes. Pipe sige clameter thickness thickness Insulation material
« Refrigerant pipe bending radius must be 4 in. (100 mm) or inch (mm)
more.
For liquid 1/4 (6.35) 0.0315 (0.8) 5/16 (8) Heat resistant foam
Z\ CAUTION 3/8 (9.52) 0.0315 (0.8) 5/16 (8) plastic 0.045 Spe-
Be sure to use the insulation of specified thickness (table on the For gas 4/2 (12.7) 0.0315 (0.8) 5/16 (8) cific gravity
right). Excessive insulation may cause incorrect installation of
the indoor unit, and too little insulation may cause condensate to
form.
* The unit has flared connections on both indoor and outdoor Limits
sides.
« Remove the valve cover from the outdoor unit, then connect . MSZ/MSY-GE09/42/15NA 65 ft. (20 m) max.
the pipe. Pipe length MSZ/MSY-GE18NA 400 ft. (30
« Refrigerant pipes are used to connect the indoor and outdoor (80m) max,
units. MSZ/MSY-GE09/12/15NA 40 ft. (12 m) max.
* Be careful not to crush or over bend the pipe in pipe bending. Height difference
MSZ/MSY-GE18NA 50 ft. (15 m) max.
No. of bends 10 max.
« Refrigerant adjustment... If pipe length exceeds 25 ft. (7.5 m),
additional refrigerant (R410A) charge is required. Up to 25 ft. (7.5 m) No additional charge is required.
(The outdoor unit is charged with refrigerant for pipe length up .
to 25 ft. (7.5 m]) Pipe length
“_ Exceeding 25 ft. (7.5 m) Additional charge is required.
9 mu“ (Refer to the table below.)
MSZ/MSY-GE09/12/15NA 1.62 oz each 5 ft. (30 g/m)
Refrigerant to be
added
MSZ/MSY-GE18NA 1.08 oz each 5 ft. (20 g/m)

1-4. INSTALLATION DIAGRAM
ACCESSORIES
Check the following parts before installation.
<[ndoor unit>
(1) | Installation plate 4
Attachment screws for the installa-
(2) | tion plate 5
4x 25mm
(3) | Remote controller holder 4
Screws for the remote controller
(4) | holder 2
3.5 x 16 mm (Black)
(5) | Battery (AAA) for (6) 2
(6) | Wireless remote controller 4
(7) | Felt tape (For left or left-rear piping) 4
(8) | Air cleaning filter 2
FIELD-SUPPLIED PARTS
(A) | Indoor/outdoor unit connecting wire* 4
(B) | Extension pipe 4
(C) | Wall hole sleeve 4
(D) | Wall hole cover 4
(E) | Pipe attachment strap 2toS
(F) | Screw for (E) 4 x 20 mm 2to5
(G) | Piping tape 4
(H) | Putty 4
Drain hose
() (or soft PVC hose, 19/32 in. [15 mm} 2105
inner diameter or hard PVC pipe
VP 16)
(J) | Refrigerant oil 4
(K) | Power supply cord * 4
* Note:
Place indoor/outdoor unit connecting wire (A)
and power supply cord (KX) at least 3 ft. (1 m)
away from the TV antenna wire.
or
more
for
left
and
left
back
piping
(using
spacer)
Unit: mm
<GE09/12/15>
Basically open 4 in.
(100 mm) or more
without any obstruction
in front and on both
sides of the unit.
4in.
(100 mm)
or more
(10 in.
Orme)
Boy (38 in
Zycooe ringnn)
Open two sides of left,
right, or rear side.
Unit: inch
31-1/2 800
5- -
19-11/16 150 500
1516 air intet | [Sairiniet |
4 @ Alt inlet 1 2 Air inlet
© Lo
=| © 9
3] o] is t/8
23] a BIS
te]
304-325
o 1-9/16 o
ir outlet 2410 x21 Slot Alr outlet
I
I |
|
1
I
2-3/8 X 13/16 slot
Units should be installed by licensed contractor
according to local code requirements.
Tin
<GE18>
15-14/32
Use the wall hole sleeve
(C) to prevent indoor/out-
door connecting wire (A)
from contacting metal
parts in the wall and to
protect the wiring from
rodents.
Wail hole cover (D)
Ae
Indoor unit Seal the wall hole
gap with putty (HR).
Wail hole
sleeve (C) Attach the pipe to
wail with pipe at-
tachment strap (E)
Cut off the
extra length. ~~»,
28
Pipe attachment
strap (E)
SSX
Attachment screw (F)
After the leak test, apply insulating mate-
rial tightly so that there is no gap.
When the piping is to be attached to a wall
comprised of tin plate or metal netting, use
chemically treated wooden piece 25/32 in.
(20 mm) or thicker between the wall and
the piping, or wrap insulation vinyl tape 7
to 8 turns around the piping.
To use existing piping, perform COOL
operation for 30 minutes and pump down
before removing the old air conditioner.
Remake flare according to the dimension
for new refrigerant.
20 in. (500 mm)
or more
KE QO)
eo
Ns
WE
)
ev
Unit: inch Unit: mm
33-1/16 840
6-5/8 19-114/16 169 500 [
TS are 4 | ma Alriniet ay
oO
2
s
S|
8
3
~ <
63]
05
rot
7
XS
Air
outtet
-
—
Fo
hi
outiet
A
7
4-3/8 x 13/16 slot 4-10 x 21 slot
1-18/32 40
Drain piping for outdoor unit
Install the unit horizontally.
water or damaged by frozen drain water.
Do not use drain socket in cold regions. Drain may freeze and make the fan stop.
The outdoor unit produces condensate during the heating operation. Select the installation place to ensure to prevent the outdoor unit and/or the grounds from being wet by drain

2. INDOOR UNIT INSTALLATION
2- 1. ATTACHING THE INSTALLATION PLATE
Find a stud in the wall to attach installation plate (1) horizontally on the wall with screws (2).
* To prevent installation plate (1) from vibrating, be sure to install the attachment screws in
the holes indicated in the illustration. For added support, additional screws may also be
installed in other holes.
« When the indoor unit is to be attached to a concrete wall using recessed bolts, secure
installation plate (1) using 7/16 in. x 13/16 in. - 7/16 in. x 1 in. (14 mm x 20 mm- 14 mm
x 26 mm) oval hole (17-3/4 in. [450 mm] pitch).
* Ifthe recessed bolt is too long, change it for a shorter one (field-supplied).
2-2. DRILLING
1) Determine where the holes will be located on the wall.
2) Drill a @ 3 in. (75 mm) hole. The outdoor side should be 6/32 to 9/32 in. (6 to 7 mm)
lower than the indoor side.
3) Insert wall hole sleeve (C).
2-3. CONNECTING WIRES FOR INDOOR UNIT
Note:
When the indoor unit is powered from the outdoor unit, depending on local code, a discon-
nect switch needs to be installed to a power supply circuit.
Remove the panel assembly. (Refer to 5-1.)
Place the upper part of the indoor unit on the installation plate.
Remove corner box and electrical cover.
Remove display panel, conduit cover and conduit plate.
Attach conduit pipe (for rear piping) / elbow joint (for right, left, or downward piping) to
conduit plate with lock nut. The thread of the installed conduit pipe / elbow joint appear-
ing inside should be less than 3/8 in. (10 mm). (Fig. 1) Elbow joint should appear less
than 1-3/16 in. (30 mm) outside. (Fig. 2)
6) Process the end of ground wire (Fig. 3). Connect it to the ground terminal of electrical
parts box.
7) Process the end of indoor/outdoor unit connecting wire (A) (Fig. 3). Attach it to the
terminal block. Be careful not to make mis-wiring. Attach the wire to the terminal block
securely so that its core cannot be seen, and no external force affects the connecting
section of the terminal block.
8) Firmly tighten the terminal screws. After tightening, verify that the wires are tightly fas-
tened.
9) Reinstall conduit plate, conduit cover and display panel.
10) According to the piping direction, remove the shaded part of the left side of box (Fig. 4)
or corner box (Fig. 5). Reinstall electrical cover, corner box and front panel.
4)
2)
3)
4)
5)
Remark: INDOOR UNIT :
A disconnect switch is 7 "hal block Grouding
required. erminal Block” terminal**
Check the local code. oO
** Use a ring tongue termi-
nal in order to connect a
ground wire to terminal. | Disconnect
switch*
208/230 V AC
tphase, 60 Hz
OUTBOOR UNIT
Power supply
208/230 V AC,
iphase 2wires.
60 Hz
Grouding terminal**
SOEL
Ceili
LISTS,
ing
SEE
2-1/8
Bind the line to the center hole.
Level
3-7/8 in.
(1060 mm)
or more
5-1/8 in. (130 mm) or more for left
and left back piping (using spacer)
in. (64 mm) or more
ih mj ormore
4-3/8 in.
(110 mm)
or more
Align the plumb Insert Align the Center of
Attachment screw (2) ting with the the scale with 33in.
mark V7. 0 scale. * || the line. * (75 mm) hole
Plumb
* Same for left hole.
Wall
B3 in. ~ Ky
(75 mm) hs 6/32-9/32 in.
Ze (5-7 mm)
Outdoor side
Electrical box Grounding
Electrical cover
Fixing
screw @,
Lock nut
Conduit plate g ey
>
Bg
Elbow joint
(for right, left, or downward piping)
Connect wires to the appropriate terminals
For future servicing, leave some slack in the connecting wires.
terminal
Conduit pipe
(for rear piping)
Indoor terminal
block
Conduit plate
Less than 3/8 in.
(10 mm)
Lock nut
Conduit pipe or
elbow joint
Conduit plat
(for right, left, or downward piping)
SA
Less than 1-3/16 in.
(30 mm)
cS
Elbow joint
Fig. 2
19/32 in.
(15 mm)
4
1-3/8 in.
(35 mm)
a
Lead
wire
« Make ground wire a little longer than
others. (More than 1-9/16 in. [40 mm])
Fig. 3
Remove panel for
piping on left side of
unit
Remove panel for
piping on bottom left
side of unit
Fig. 4
Remove panel for
piping on bottom side
of unit
Remove panel for piping
on right side of unit
Corner box

2-4, PIPE FORMING AND DRAIN PIPING
2-4-1. PIPE FORMING
« Place the drain hose below the refrigerant piping.
* Make sure that the drain hose is not crowded or bent.
« Do not pull the hose when applying the tape.
« When the drain hose passes the room, be sure to wrap it with insulation material
(field-supplied).
Note:
Make sure not to damage the cover of refrigerant pipe when attaching it back on with
screws.
Left or left-rear piping
Note:
Be sure to reattach the drain hose and the drain cap if the piping is being installed on
left or bottom left of unit, otherwise, water could drip down from the drain hose.
1)Place the refrigerant piping and the drain hose together, then firmly apply felt tape (7)
from the end.
Felt tape (7) overlap width should be 1/3 the tape width. Use a bandage stopper at
the end of felt tape (7).
2) Pull out the drain cap at the back right of the indoor unit. (Fig. 1)
« Hold the convex section at the end and pull the drain cap.
3) Pull out the drain hose at the back left of the indoor unit. (Fig. 2)
* Hold the claw marked by the arrows and pull out the drain hose forward.
4) Put the drain cap into the section to which the drain hose is to be attached at the rear
of the indoor unit. (Fig. 3)
* Insert a screwdriver into the hole on the cap and insert the cap fully into the drain
pan.
5) Insert the drain hose fully into the drain pan at the back right of the indoor unit. (Fig. 4)
« Check if the hose is hooked securely to the projection of its inserting part at the
drain pan.
6) Insert the drain hose into wall hole sleeve (C), and attach the upper part of indoor
unit onto the installation plate (1). Then, shift the indoor unit completely to the left to
make placing the piping in the back of the unit easier.
7) Cut out a piece of cardboard from the shipping box, roll it up, hook it onto the back
rib, and use it as a spacer to lift the indoor unit. (Fig. 5)
8) Connect the refrigerant piping with the extension pipe (B).
9) Attach the lower part of the indoor unit into the installation plate (1).
Rear or bottom piping
1) Place the refrigerant piping and the drain hose together, then firmly apply piping tape
(G) from the end.
2) Insert the piping and the drain hose into the wall hole sleeve (C), and attach the up-
per part of the indoor unit on the installation plate (1).
3) Check if the indoor unit is attached securely on the installation plate (1) by moving
the unit to left and right.
4) Attach the lower part of the indoor unit into the installation plate (1).
Right piping
Note:
Before performing the following, make sure that wiring is completed, and the conduit
cover is installed. (Refer to 2-3.)
1) Place the refrigerant piping and the drain hose together, shift them to left side of the
unit, and then firmly apply piping tape (G) from the end.
2) Insert the piping and the drain hose into the wall hole sleeve (C), and attach the up-
per part of the indoor unit on the installation plate (1).
3) Check if the indoor unit is attached securely on the installation plate (1) by moving
the unit to left and right.
4) Attach the lower part of the indoor unit into the installation plate (1).
2-4-2. DRAIN PIPING
* If the extension drain hose has to pass through a room, be sure to wrap it with insu-
lation (field-supplied).
* The drain hose should point downward for easy drain. (Fig. 1)
« If the drain hose provided with the indoor unit is too short, connect it with a field-
supplied drain hose (I). (Fig. 2)
« When connecting the drain hose to a hard vinyl chloride pipe, be sure to insert it se-
curely into the pipe. (Fig. 3)
Liquid pipe
Gas pipe
Indoor/outdoor unit
em connecting wire (A)
Felt tape (7)
Piping tape (G)
Fe
Remove panel for piping
on left side of unit.
"~ Drain hose
Fig. 1 Fig. 2
Drain hose
Drain cap
Fig. 3 Fig. 4
SS
I
os)
S Ss
Fig. 5
Remove panel for piping on
bottom side of unit
Remove panel
leakage
in water
Water
leakage as Ditch
for piping on
right side of
unit
To the left
C
»
Drain
Tt
I
Drain
hose
iar hose 27-9116 in I=— Hard viny! chloride pipe
Downward ey (70 cm) (30 ne in.
slope * Soft hose LD. OF OTE fee neni
- ee lL. 19/32 in. L ;
re I 15 secure
fd (15 mm) Different a ¥
) diameter joint
Fig. 1 Fig. 2 Fig. 3
| Do not make drain piping as shown below. i
Ye Accumulated At least
drain water ‘ . 1-31/32 in.
Tip of drain
, hose dipped (50 mm)
gap

3. OUTDOOR UNIT INSTALLATION
3-1. CONNECTING WIRES FOR OUTDOOR UNIT
1) Remove the service panel.
2) Remove the conduit cover.
3) Attach the conduit connector to conduit plate with lock nut then secure it against unit with
SCTEWS. f 19/32 in.
4) Connect ground wires of indoor/outdoor unit connecting wire (A) and power supply cord (KK) 1-3/8 in. (15mm)
to the TB support. (35 mm) 7
5) Loosen the terminal screw, and attach indoor/outdoor unit connecting wire (A) from the indoor L
unit correctly on the terminal block. Attach the wire to the terminal block securely so that its
core cannot be seen, and no external force affects the connecting section of the terminal
block. Power supply cord (K)
Lead wire
Firmly tighten the terminal screws. After tightening, verify that the wires are tightly fastened.
Connect power supply cord (kK).
Install the conduit cover.
6)
7)
8)
9) Install the service panel securely.
<GE09/12/15>
Terminal block
Condult plate
Kes GN olan es)
ERGs A
Welk
Connector
TB support
<GEi8>
Power
Grounding
terminal
TB support
Make earth wire a little longer than others.
(More than 2-3/8 in. [60 mm})
For future servicing, leave some slack in
the connecting wires.
Grounding
terminal
indoor/outdoor unit
connecting wire (A)
Power supply cord (K)
Conduit cover
supply cord (K)
indoor/outdoor unit
connecting wire (A)
to conduit cover
3-2. FLARE CONNECTION
1) Cut the copper pipe as straight as possible with a pipe cutter. (Fig. 1, 2)
2) Remove all burrs from the cut section of the pipe, ensuring that precautions are taken to
avoid getting metal shavings into the piping. (Fig. 3)
3) Remove flare nuts attached to indoor and outdoor units, then put them on pipe.
4) Flaring work (Fig. 4, 5). Firmly hold copper pipe in the dimension shown in the table. Select A
mm from the table according to the tool you use.
Good
a
No good
Copper
pipe
Tilted Uneven Burred
5) Check Fig. 4 Fig. 2
« Compare the flared work with Fig. 6.
« If flare is defective, cut off the section and repeat procedure.
Burr Copper pipe
“ .~ Spare reamer
\ » SS Pipe cutter » \
| |
Ainch (mm) Tightening torque /
Pipe
diameter
Nut
:
Fig.
3
Pp h inch Clutch Clutch Wing nut ftelb
inch (mm) (mm) type tool type tool type tool Nem (kgfecm)
for R410A | for R22 for R22 g A
0 1/4 (6.35) | 4 0.06to | 437toiz7 | ts
(17) 0.08 (140 to 180) C /
(1 5 to ty Die / ee Opper pipe
. od
03/8 (9.52) | oe 0.0410 | 92.9) | 343t041.2 | ge 19 Clutch type Wing nut type
(22) | oto0.02 | 0.06 (350 to 420) *P omer
qa | (0t00.5) | (4.0to ad Fig. 4 Flare nut Fig. 5
91/2 (12.7) | 56 45) 0.08 to | 49010564 | gn to B75
(26) Cot ( 0575) Smocth all around Ire thou cay
5/8 a 54 to 58 scratches.
@ 5/8 (15.88) (29) 2.5) 73.5 to 78.4 (750 to 800)
Even length
all around Fig. 6

3-3. PIPE CONNECTION
« Fasten flare nut with a torque wrench as specified in the table (refer to 3-2.).
« When fastened too tight, flare nut may eventually break and cause refrigerant leakage.
Indoor unit connection
Connect both liquid and gas pipings to indoor unit.
« Apply a thin coat of refrigerant oil (J) on the seat surface of pipe.
* To connect, first align the center, then tighten the first 3 to 4 turns of flare nut.
* Use tightening torque table above as a guideline for indoor unit side joints, and tighten
using two wrenches. Excessive tightening damages the flare section.
Outdoor unit connection
Connect pipes to stop valve pipe joint of the outdoor unit following the same procedure
detailed in Indoor unit connection.
* For tightening, use a torque wrench or spanner.
Ve ECO te
When installing the unit, securely connect the refrigerant pipes before starting the
compressor.
3-4. INSULATION AND TAPING
1) Cover piping joints with pipe cover.
2) For outdoor unit side, insulate the piping, including valves.
3) Apply piping tape (G) starting from the connection on the outdoor unit.
« When piping has to be installed through a ceiling, closet or where the temperature and
humidity are high, use additional field-supplied insulation to prevent condensation.
4. PURGING PROCEDURES, LEAK TEST, AND TEST RUN
4-1. PURGING PROCEDURES AND LEAK TEST
1) Remove service port cap of stop valve on the side of the outdoor unit gas pipe.
2) Connect gauge manifold valve and vacuum pump to service port of stop valve on the
gas pipe side of the outdoor unit.
0.101 MPa Compound pressure gauge
*4 to 5 turns Stop valve cap (-30 in.Hg (for R410A)
*Close
ore
|
ee
[760
mHg])
Pressure
gauge
(for R410A)
Gauge manifold valve
(for R410A)
Handle High
he Charge hose
(for R410A)
Stop valve
10 300 kafem) for LIQUID
*Open ar
} | 2
Hexagonal wrench
Service port cap
(Torque 13.7 to
17.7 Nem, 140 to
180 kgfecm)
Adapter for pre- TT
venting the back
flow
Vacuum pump (or the vacuum
pump with the function to
prevent the back flow)
When attaching the control valve
to the service port, valve core may
deform or loosen if excess pressure
is applied. This may cause gas leak.
Precautions when using the control valve
— °
6 e
/ Service port
A
Control valve
NS
=
Open \
Close
Body
When attaching the control valve to
the service port, make sure that the
valve core is in closed position, and
then tighten part A. Do not tighten
part A or turn the body when valve
Charge hose an v4:
core is in open position.
3) Run the vacuum pump 15 minutes or more.
4) Check the vacuum with the gauge manifold valve, then close it and shut off the vacuum
pump.
5) Leave as it is for one or two minutes. Make sure pointer gauge manifold valve remains
in the same position. Confirm that pressure gauge shows —0.101 MPa [Gauge] (—-30
in.Hg [-760 mmHg]J).
6) Quickly remove gauge manifold valve from service port of stop valve.
7) After refrigerant pipes are connected and evacuated, fully open all stop valves on both
sides of gas pipe and liquid pipe. Operating the unit without fully opening the valves
lowers the performance and causes problems.
8) Refer to 1-3. SPECIFICATIONS, and charge the prescribed amount of refrigerant if
needed. Be sure to charge slowly with liquid refrigerant. Otherwise, composition of the
refrigerant in the system may be changed and affect performance of the air conditioner.
9) Tighten cap of service port.
10) Conduct a leak test
4-2. TEST RUN
1) Insert power supply plug into the power outlet and/or turn
on the breaker.
2) Press the E.O. SW once. Test run will be performed for
30 minutes. If the power lamp blinks every 0.5 seconds,
inspect the indoor/outdoor unit connecting wire (A). After
the test run, emergency COOL mode (75°F [24°C] COOL)
will start.
3) To stop operation, press the E.O. SW several times until
all LED lamps turn off. Refer to operating instructions for
details.
Emergency
operation switch
(E.0. SW)
Checking the remote (infrared) signal reception
Press the ON/OFF button on the remote controller and listen for an audible indicator fram
the indoor unit. Press the ON/OFF button again to turn the air conditioner off.
* Once the compressor stops, the restart preventive device operates so the compressor
will not operate for 3 minutes to protect the air conditioner.
4-3. AUTO RESTART FUNCTION
This product is equipped with an auto restart function. When the power supply is cut off
during operation, such as during blackouts, the function automatically starts operation in
the previous setting once the power supply is resumed. (Refer to the operating instructions
for details.)
Caution:
« After test run or remote signal reception check, turn off the unit with the E.O. SW or
the remote controller before turning off the power supply. If this procedure is not per-
formed, the unit will automatically begin operation when power supply is resumed.
To the user
« After installing the unit, explain to the user about auto restart function.
* If auto restart function is unnecessary, it can be deactivated. Consult the service rep-
resentative to deactivate the function. Refer to the service manual for details.
4-4. EXPLANATION TO THE USER
* Using the OPERATING INSTRUCTIONS, explain to the user how to use the air condition-
er (the remote controller, removing the air filters, placing or removing the remote controller
from the remote controller holder, cleaning methods, precautions for operation, etc.)
*« Recommend that the user read the OPERATING INSTRUCTIONS carefully.

5. RELOCATION AND MAINTENANCE
5-1. REMOVING AND INSTALLING THE PANEL
ASSEMBLY
Removal procedure
1) Remove the two screws that attach the panel assembly.
2) Remove the panel assembly. Be sure to remove its bottom end first.
we i
1
Installation procedure
1) Install the panel assembly following the removal procedure in reverse.
2) Be sure to press the positions as indicated by the arrows in order to attach the
assembly completely to the unit. |
5-2. REMOVING THE INDOOR UNIT
Remove the bottom of the indoor unit from the installation plate.
When releasing the corner part, release both left and right bottom corner part of
indoor unit and pull it downward and forward as shown in the figure on the right.
if the above method cannot be used
Remove the front panel. Then, insert hexagonal wrenches into the square holes on
the left and right sides of the unit and push them up as shown in the following figure.
The bottom of the indoor unit lowers and releases the hooks.
,
Lower
Square hole
5-3. PUMPING DOWN
When relocating or disposing of the air conditioner, pump down the system following
the procedure below so that refrigerant is not released into the atmosphere.
1) Connect the gauge manifold valve to the service port of the stop valve on the gas
pipe side of the outdoor unit.
2) Fully close the stop valve on the liquid pipe side of the outdoor unit.
3) Close the stop valve on the gas pipe side of the outdoor unit almost completely
so that it can be easily closed fully when the pressure gauge shows 0 MPa [Gauge]
(0 Ibffin? [0 kgf/cm’).
4) Start the emergency COOL operation.
To start the emergency operation in COOL mode, disconnect the power supply
plug and/or turn off the breaker. After 15 seconds, connect the power supply plug
and/or turn on the breaker, and then press the E.O. SW once. (The emergency
COOL operation can be performed continuously for up to 30 minutes.)
5) Fully close the stop valve on the gas pipe side of the outdoor unit when the pressure
gauge shows 0.05 to 0 MPa [Gauge] (approx. 7.25 to 0 Ibffin’ [0.5 to 0 kgf/cm’).
6) Stop the emergency COOL operation.
To stop operation, press the E.O. SW several times until all LED lamps turn off.
Refer to operating instructions for details.
A WARNING
When pumping down the refrigerant, stop the compressor before discon-
necting the refrigerant pipes. The compressor may burst if air etc. get into it.
aa MITSUBISHI ELECTRIC CORPORATION
HEAD OFFICE: TOKYO BLDG.,, 2-7-3, MARUNOUCHI, CHIYODA-KU, TOKYO
100-8310, JAPAN
