Mitsubishi Electric PLA-RP.BA Series Instruction manual

TECHNICAL DATA BOOK
CONTENTS
1. REFERENCE SERVICE MANUAL·············································2
2. SPECIFICATIONS ······································································3
3. OUTLINES AND DIMENSIONS················································30
4. WIRING DIAGRAM···································································54
5. REFRIGERANT SYSTEM DIAGRAM ······································75
6. PERFORMANCE CURVES ······················································80
7. CORRECTION FACTORS ························································82
8. APPLICABLE EXTENSION PIPE FOR EACH MODEL ··········83
9. AIR FLOW DATA ······································································92
10. NOISE CRITERION CURVES·················································111
11. OPTIONAL PARTS···································································124
<Indoor unit>
[Model names]
R410A
PLA-RP·BA(2)
PLA-RP·AA(2)
PEAD-RP·EA(2)
PEAD-RP·GA
PEA-RP·GA
PKA-RP·GAL
PKA-RP·FAL(2)
PCA-RP·GA(2)
PCA-RP·HA
PSA-RP·GA
<Outdoor unit>
[Model names]
SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
PUHZ-RP35/50/60/71/100/125/140VHA2
PUHZ-RP35/50/60/71/100VHA3
PUHZ-RP100/125/140YHA2
PUHZ-RP100YHA3
PUHZ-RP200/250YHA2
April 2008
INVERTER
kW Model
No. OCS05
REVISED EDITION-E
Revision:
• PLA-RP·BA2 and PUHZ-
RP·HA3 are added in
REVISED EDITION-E.
• Some descriptions have been
modified.
• Please void OCS05 REVISED
EDITION-D.
OCS05E-1.qxp 08.3.31 9:52 AM Page 1

2
For information on service, please refer to the service manual as follows.
Model name Service Ref. Service
Manual No.
PLA-RP35/50/60/71AA
PLA-RP35/50/60/71/100/125/140BA
PLA-RP71/100/125BA2
PLA-RP35/50/60/71/100/125/140BA(1).UK
PLA-RP71/100/125BA2.UK
PLA-RP35/50/60/71/100/125/140BA
PLA-RP35/50/60/71AA.UK
PLA-RP35/50/60/71AA
OC335
OCH412
OCB412
OCH416
OCB416
OC327
PLA-RP100/125/140AA2 OC357
PLA-RP100/125/140AA2.UK
PCA-RP50/60/71/100/125/140GA PCA-RP50/60/71/100/125/140GA OC328
PCA-RP50GA2 PCA-RP50GA2
PCA-RP71/125HA PCA-RP71/125HA OC329
PKA-RP35/50GAL PKA-RP35/50GAL OC330
PKA-RP60/71/100FAL
PKA-RP50FAL2
PKA-RP60/71/100FAL
PKA-RP50FAL2 OC331
PSA-RP71/100/125/140GA PSA-RP71/100/125/140GA OC332
PEAD-RP50/60/71/125/140EA PEAD-RP50/60/71/125/140EA.UK HWE05210
PEAD-RP35/100EA2 PEAD-RP35/100EA2.UK
PEAD-RP60/71/100GA PEAD-RP60/71/100GA.UK HWE05060
PEA-RP200/250/400/500GA PEA-RP200/250/400/500GA.TH-AF
PEA-RP200/250GA.TH-AFMF HWE0708A
1-2. OUTDOOR UNIT
Model name Service Ref. Service
Manual No.
PUHZ-RP35/50/60/71VHA2
PUHZ-RP100/125/140VHA2
PUHZ-RP100/125/140YHA2
PUHZ-RP35/50/60/71/100VHA3
PUHZ-RP100YHA3
PUHZ-RP35/50/60/71VHA2(1)
PUHZ-RP100/125/140VHA2(1)
PUHZ-RP100/125/140YHA2(1)
PUHZ-RP35/50/60/71/100VHA3
PUHZ-RP100YHA3
PUHZ-RP60/71/100VHA3#1
PUHZ-RP100YHA3#1
PUHZ-RP125/140VHA2#2
PUHZ-RP125/140YHA2#2
OC374
OCH428
OCB428
PUHZ-RP200/250YHA2 PUHZ-RP200/250YHA2
1-1. INDOOR UNIT
1REFERENCE SERVICE MANUAL
OCS05E-1.qxp 08.3.31 9:52 AM Page 2

3
2SPECIFICATIONS
2-1. CEILING CASSETTE TYPE
Model name Indoor unit PLA-RP35BA PLA-RP50BA
Outdoor unit PUHZ-RP35VHA2 PUHZ-RP50VHA2
PUHZ-RP35VHA3 PUHZ-RP50VHA3
Cooling Capacity Btu/h 12,300 17,100
kW 3.6(1.6-4.5) 5.0(2.3-5.6)
Total input kW 1.07 1.55
EER 3.36 3.23
Energy label class AA
SHF 0.84 0.81
Heating Capacity Btu/h 14,000 20,500
kW 4.1(1.6-5.2) 6.0(2.5-7.3)
Total input kW 1.12 1.66
COP 3.66 3.61
Energy label class A A
Booster heater kW ––
Power supply Phase [1
Cycle Hz 50
Voltage V 230
Breaker size A 16
Indoor unit Air flow CMM 11-12-13-15 12-14-16-18
(Low-Medium2-Medium1-High) CFM 390-425-460-530 425-495-565-635
External pressure Pa 0 0
Sound level dB(A) 27-28-29-31 28-29-31-32
(Low-Medium2-Medium1-High)
External finish (Panel) White Munsell 6.4Y 8.9/0.4
Dimension W : mm 840 (950)
Unit (Panel) D : mm 840 (950)
H : mm 258 (35)
W : inch 33-1/16 (37-3/8)
D : inch 33-1/16 (37-3/8)
H : inch 10-3/16 (1-3/8)
Weight kg 22(6)
Unit (Panel) lbs 49(13)
Field drain pipe O.D. mm 32
inch 1-1/4
Outdoor unit Air flow CMM 35
CFM 1,240
Sound level at cooling dB(A) 44
Sound level at heating dB(A) 46
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 800
D : mm 300+23
H : mm 600
W : inch 31-1/2
D : inch 11-13/16 + 7/8
H : inch 23-5/8
Weight kg 45(VHA2)/42(VHA3)
lbs 99(VHA2)/92(VHA3)
Refrigerant pipe size Gas side O.D. mm 12.7
inch 1/2
Liquid side O.D. mm 6.35
inch 1/4
Refrigerant pipe length Height difference m Max. 30
Length m Max. 50
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor : D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚CD.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating Upper limit D.B. 28˚CD.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚CD.B. -11˚C, W.B. -12˚C
4. Above data are based on the indicated voltage.
wIf optional air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
OCS05E-1.qxp 08.3.31 9:52 AM Page 3

4
Model name Indoor unit PLA-RP60BA PLA-RP71BA
Outdoor unit PUHZ-RP60VHA2
PUHZ-RP60VHA3 PUHZ-RP71VHA2
Cooling Capacity Btu/h 20,500 24,200
kW 6.0(2.7-6.7) 7.1(3.3-8.1)
Total input kW 1.65 2.12
EER 3.64 3.35
Energy label class A A
SHF 0.76 0.73
Heating Capacity Btu/h 23,900 27,300
kW 7.0(2.8-8.2) 8.0(3.5-10.2)
Total input kW 1.85 2.21
COP 3.78 3.61
Energy label class A A
Booster heater kW ––
Power supply Phase [1
Cycle Hz 50
Voltage V 230
Breaker size A 25
Indoor unit Air flow CMM 12-14-16-18 14-16-18-21
(Low-Medium2-Medium1-High) CFM 425-495-565-635 495-565-635-740
External pressure Pa 0 0
Sound level dB(A) 28-29-31-32 28-30-32-34
(Low-Medium2-Medium1-High)
External finish (Panel) White Munsell 6.4Y 8.9/0.4
Dimension W : mm 840 (950)
Unit (Panel) D : mm 840 (950)
H : mm 258 (35)
W : inch 33-1/16 (37-3/8)
D : inch 33-1/16 (37-3/8)
H : inch 10-3/16 (1-3/8)
Weight kg 23(6)
Unit (Panel) lbs 51(13)
Field drain pipe O.D. mm 32
inch 1-1/4
Outdoor unit Air flow CMM 55
CFM 1,940
Sound level at cooling dB(A) 47
Sound level at heating dB(A) 48
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30
H : mm 943
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 37-1/8
Weight kg 75(VHA2)/68(VHA3)
lbs 165(VHA2)/150(VHA3)
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 50
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor : D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚CD.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating Upper limit D.B. 28˚CD.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚CD.B. -11˚C, W.B. -12˚C
4. Above data are based on the indicated voltage.
wIf optional air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
OCS05E-1.qxp 08.3.31 9:52 AM Page 4

5
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor : D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚CD.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating Upper limit D.B. 28˚CD.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚CD.B. -11˚C, W.B. -12˚C
4. Above data are based on the indicated voltage.
wIf optional air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PLA-RP71BA2 PLA-RP125BA2
Outdoor unit PUHZ-RP71VHA3 PUHZ-RP125VHA2
Cooling Capacity Btu/h 24,200 42,700
kW 7.1(3.3-8.1) 12.5(5.5-14.0)
Total input kW 1.94 3.73
EER 3.66 3.35
Energy label class A A
SHF 0.73 0.71
Heating Capacity Btu/h 27,300 47,800
kW 8.0(3.5-10.2) 14.0(5.0-16.0)
Total input kW 1.90 3.51
COP 4.21
PLA-RP100BA2
PUHZ-RP100VHA3
34,100
10.0(4.9-11.4)
2.44
4.10
A
0.74
38,200
11.2(4.5-14.0)
2.54
4.41 3.99
Energy label class A A
Booster heater kW ––
A
–
Power supply Phase [1
Cycle Hz 50
Voltage V 230
Breaker size A 3225
23(6)
51(13)
27(6)
60(13)
Indoor unit Air flow CMM 14-16-18-21 22-25-28-31
(Low-Medium2-Medium1-High)
CFM 495-565-635-740 780-880-990-1090
External pressure Pa 0 0
Sound level dB(A) 28-30-32-34
20-23-26-30
710-810-920-1060
0
32-34-37-40 34-36-39-41
(Low-Medium2-Medium1-High)
External finish (Panel) White Munsell 6.4Y 8.9/0.4
Dimension W : mm 840 (950)
Unit (Panel) D : mm 840 (950)
H : mm 258 (35) 298 (35)
W : inch 33-1/16 (37-3/8)
D : inch 33-1/16 (37-3/8)
H : inch 10-3/16 (1-3/8) 11-3/4 (1-3/8)
Weight kg
Unit (Panel) lbs
Field drain pipe O.D. mm 32
inch 1-1/4
Outdoor unit Air flow CMM 100
CFM 3,530
55
1,940
Sound level at cooling dB(A) 47 50
Sound level at heating dB(A) 48
49
51 52
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30
H : mm 943 1,350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 37-1/8 53-1/8
Weight kg 68 116
lbs 150 256
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 75Max. 50
OCS05E-1.qxp 08.3.31 9:52 AM Page 5

6
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor : D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚CD.B. 46:
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5:w
Heating Upper limit D.B. 28˚CD.B. 21:, W.B. 15:
Lower limit D.B. 17˚CD.B. -20:, W.B. -20:
4. Above data are based on the indicated voltage.
wIf optional air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PLA-RP100BA PLA-RP125BA PLA-RP140BA
Outdoor unit PUHZ-RP100VHA2 PUHZ-RP125VHA2 PUHZ-RP140VHA2
Cooling Capacity Btu/h 34,100 42,700 47,800
kW 10.0(4.9-11.4) 12.5(5.5-14.0) 14.0(5.5-15.3)
Total input kW 3.02 3.87 4.65
EER 3.31 3.23 3.01
Energy label class A A B
SHF 0.74 0.71 0.71
Heating Capacity Btu/h 38,200 47,800 54,600
kW 11.2(4.5-14.0) 14.0(5.0-16.0) 16.0(5.0-18.0)
Total input kW 3.10 3.88 4.43
COP 3.61 3.61 3.61
Energy label class A A A
Booster heater kW –––
Power supply Phase [1
Cycle Hz 50
Voltage V 230
Breaker size A 32
25(6)
55(13)
40
Indoor unit Air flow CMM 20-23-26-30 22-25-28-31
(Low-Medium2-Medium1-High)
CFM 710-810-920-1060 780-880-990-1090
External pressure Pa 0 0
Sound level dB(A) 32-34-37-40 34-36-39-41
24-26-29-32
850-920-1020-1130
0
36-39-42-44
(Low-Medium2-Medium1-High)
External finish (Panel) White Munsell 6.4Y 8.9/0.4
Dimension W : mm 840 (950)
Unit (Panel) D : mm 840 (950)
H : mm 298 (35)
W : inch 33-1/16 (37-3/8)
D : inch 33-1/16 (37-3/8)
H : inch 11-3/4 (1-3/8)
Weight kg 27(6)
Unit (Panel) lbs 60(13)
Field drain pipe O.D. mm 32
inch 1-1/4
Outdoor unit Air flow CMM 100
CFM 3,530
Sound level at cooling dB(A) 49 50
Sound level at heating dB(A) 51 52
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30
H : mm 1350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 53-1/8
Weight kg 121 116
lbs 267 256
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 75
OCS05E-1.qxp 08.3.31 9:52 AM Page 6

7
Model name Indoor unit PLA-RP100BA PLA-RP125BA PLA-RP140BA
Outdoor unit PUHZ-RP100YHA2 PUHZ-RP125YHA2 PUHZ-RP140YHA2
Cooling Capacity Btu/h 34,100 42,700 47,800
kW 10.0(4.9-11.4) 12.5(5.5-14.0) 14.0(5.5-15.3)
Total input kW 3.02 3.87 4.65
EER 3.31 3.23 3.01
Energy label class AAB
SHF 0.74 0.71 0.71
Heating Capacity Btu/h 38,200 47,800 54,600
kW 11.2(4.5-14.0) 14.0(5.0-16.0) 16.0(5.0-18.0)
Total input kW 3.10 3.88 4.43
COP 3.61 3.61 3.61
Energy label class AAA
Booster heater kW –––
Power supply Phase [3
Cycle Hz 50
Voltage V 400
Breaker size A 16
Indoor unit Air flow CMM 20-23-26-30 22-25-28-31
(Low-Medium2-Medium1-High)
CFM 710-810-920-1060 780-880-990-1090
External pressure Pa 0 0
Sound level dB(A) 32-34-37-40 34-36-39-41
24-26-29-32
850-920-1020-1130
0
36-39-42-44
(Low-Medium2-Medium1-High)
External finish (Panel) White Munsell 6.4Y 8.9/0.4
Dimension W : mm 840 (950)
Unit (Panel) D : mm 840 (950)
H : mm 298 (35)
W : inch 33-1/16 (37-3/8)
D : inch 33-1/16 (37-3/8)
H : inch 11-3/4 (1-3/8)
Weight kg 27 (6)
Unit (Panel) lbs 60 (13)
25 (6)
55 (13)
Field drain pipe O.D. mm 32
inch 1-1/4
Outdoor unit Air flow CMM 100
CFM 3,530
Sound level at cooling dB(A) 49 50
Sound level at heating dB(A) 51 52
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30
H : mm 1350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 53-1/8
Weight kg 135 130
lbs 298 287
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 75
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor : D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚CD.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating Upper limit D.B. 28˚CD.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚CD.B. -20˚C, W.B. -20˚C
4. Above data are based on the indicated voltage.
Indoor unit Single phase 230V 50Hz
3 phase 400V 50Hz
Outdoor unit
Indoor unit 198~264V, 50Hz
342~457V, 50Hz
Outdoor unit
3. Guaranteed voltage
wIf optional air protect guide installed. D.B.-15:
OCS05E-1.qxp 08.3.31 9:52 AM Page 7

8
Model name Indoor unit PLA-RP100BA2 PLA-RP125BA2
Outdoor unit PUHZ-RP100YHA3 PUHZ-RP125YHA2
Cooling Capacity Btu/h 34,100 42,700
kW 10.0(4.9-11.4) 12.5(5.5-14.0)
Total input kW 2.50 3.79
EER 4.00 3.30
Energy label class AA
SHF 0.74 0.71
Heating Capacity Btu/h 38,200 47,800
kW 11.2(4.5-14.0) 14.0(5.0-16.0)
Total input kW 2.60 3.57
COP 4.31 3.92
Energy label class AA
Booster heater kW ––
Power supply Phase [3
Cycle Hz 50
Voltage V 400
Breaker size A 16
Indoor unit Air flow CMM 20-23-26-30 22-25-28-31
(Low-Medium2-Medium1-High)
CFM 710-810-920-1060 780-880-990-1090
External pressure Pa 0 0
Sound level dB(A) 32-34-37-40 34-36-39-41
(Low-Medium2-Medium1-High)
External finish (Panel) White Munsell 6.4Y 8.9/0.4
Dimension W : mm 840 (950)
Unit (Panel) D : mm 840 (950)
H : mm 298 (35)
W : inch 33-1/16 (37-3/8)
D : inch 33-1/16 (37-3/8)
H : inch 11-3/4 (1-3/8)
Weight kg 27 (6)
Unit (Panel) lbs 60 (13)
Field drain pipe O.D. mm 32
inch 1-1/4
Outdoor unit Air flow CMM 100
CFM 3,530
Sound level at cooling dB(A) 49 50
Sound level at heating dB(A) 51 52
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30
H : mm 1350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 53-1/8
Weight kg 130
lbs 287
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 75
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor : D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚CD.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating Upper limit D.B. 28˚CD.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚CD.B. -20˚C, W.B. -20˚C
4. Above data are based on the indicated voltage.
Indoor unit Single phase 230V 50Hz
3 phase 400V 50Hz
Outdoor unit
Indoor unit 198~264V, 50Hz
342~457V, 50Hz
Outdoor unit
3. Guaranteed voltage
wIf optional air protect guide installed. D.B.-15:
OCS05E-1.qxp 08.3.31 9:52 AM Page 8

9
Model name Indoor unit PLA-RP35AA PLA-RP50AA
Outdoor unit PUHZ-RP35VHA2 PUHZ-RP50VHA2
Cooling Capacity Btu/h 12,300 17,100
kW 3.6(1.6-4.5) 5.0(2.3-5.6)
Total input kW 1.07 1.55
EER 3.36 3.23
Energy label class A A
SHF 0.89 0.86
Heating Capacity Btu/h 14,000 20,500
kW 4.1(1.6-5.2) 6.0(2.5-7.3)
Total input kW 1.12 1.62
COP 3.66 3.70
Energy label class A A
Booster heater kW - -
Power supply Phase [1
Cycle Hz 50
Voltage V 230
Breaker size A 16
Indoor unit Air flow CMM 11-12-13-14 14-15-16-18
(Low-Medium2-Medium1-High) CFM 390-425-460-495 495-530-565-635
External pressure Pa 0 0
Sound level dB(A) 27-28-29-31 28-29-31-33
(Low-Medium2-Medium1-High)
External finish (Panel) White Munsell 0.70Y 8.59/0.97
Dimension W : mm 840 (950)
Unit (Panel) D : mm 840 (950)
H : mm 258 (30)
W : inch 33-1/16 (37-3/8)
D : inch 33-1/16 (37-3/8)
H : inch 10-3/16 (1-3/16)
Weight kg 24 (5)
Unit (Panel) lbs 53 (11)
Field drain pipe O.D. mm 32
inch 1-1/4
Outdoor unit Air flow CMM 35
CFM 1,240
Sound level at cooling dB(A) 44
Sound level at heating dB(A) 46
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 800
D : mm 300+23
H : mm 600
W : inch 31-1/2
D : inch 11-13/16 + 7/8
H : inch 23-5/8
Weight kg 45
lbs 99
Refrigerant pipe size Gas side O.D. mm 12.7
inch 1/2
Liquid side O.D. mm 6.35
inch 1/4
Refrigerant pipe length Height difference m Max. 30
Length m Max. 50
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor : D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚CD.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating Upper limit D.B. 28˚CD.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚CD.B. -11˚C, W.B. -12˚C
4. Above data are based on the indicated voltage.
wIf optional air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
OCS05E-1.qxp 08.3.31 9:52 AM Page 9

10
Model name Indoor unit PLA-RP60AA PLA-RP71AA
Outdoor unit PUHZ-RP60VHA2 PUHZ-RP71VHA2
Cooling Capacity Btu/h 20,500 24,200
kW 6.0(2.7-6.7) 7.1(3.3-8.1)
Total input kW 1.65 1.97
EER 3.64 3.60
Energy label class A A
SHF 0.78 0.74
Heating Capacity Btu/h 23,900 27,300
kW 7.0(2.8-8.2) 8.0(3.5-10.2)
Total input kW 1.85 2.34
COP 3.78 3.42
Energy label class A B
Booster heater kW - -
Power supply Phase [1
Cycle Hz 50
Voltage V 230
Breaker size A 25
Indoor unit Air flow CMM 14-15-16-18 15-16-18-20
(Low-Medium2-Medium1-High) CFM 495-530-565-635 530-565-635-705
External pressure Pa 0 0
Sound level dB(A) 28-29-31-33 28-30-32-34
(Low-Medium2-Medium1-High)
External finish (Panel) White Munsell 0.70Y 8.59/0.97
Dimension W : mm 840 (950)
Unit (Panel) D : mm 840 (950)
H : mm 258 (30)
W : inch 33-1/16 (37-3/8)
D : inch 33-1/16 (37-3/8)
H : inch 10-3/16 (1-3/16)
Weight kg 24 (5)
Unit (Panel) lbs 53 (11)
Field drain pipe O.D. mm 32
inch 1-1/4
Outdoor unit Air flow CMM 55
CFM 1,940
Sound level at cooling dB(A) 47
Sound level at heating dB(A) 48
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30
H : mm 943
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 37-1/8
Weight kg 75
lbs 165
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 50
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor : D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚CD.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating Upper limit D.B. 28˚CD.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚CD.B. -11˚C, W.B. -12˚C
4. Above data are based on the indicated voltage.
wIf optional air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
OCS05E-1.qxp 08.3.31 9:52 AM Page 10

11
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor : D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚CD.B. 46:
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5:w
Heating Upper limit D.B. 28˚CD.B. 21:, W.B. 15:
Lower limit D.B. 17˚CD.B. -20:, W.B. -20:
4. Above data are based on the indicated voltage.
wIf optional air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PLA-RP100AA2 PLA-RP125AA2 PLA-RP140AA2
Outdoor unit PUHZ-RP100VHA2 PUHZ-RP125VHA2 PUHZ-RP140VHA2
Cooling Capacity Btu/h 34,100 42,700 47,800
kW 10.0(4.9-11.4) 12.5(5.5-14.0) 14.0(5.5-15.3)
Total input kW 3.02 3.87 4.65
EER 3.31 3.23 3.01
Energy label class A A B
SHF 0.78 0.74 0.71
Heating Capacity Btu/h 38,200 47,800 54,600
kW 11.2(4.5-14.0) 14.0(5.0-16.0) 16.0(5.0-18.0)
Total input kW 3.02 3.88 4.69
COP 3.61 3.61 3.41
Energy label class A A B
Booster heater kW - - -
Power supply Phase [1
Cycle Hz 50
Voltage V 230
Breaker size A 32 40
Indoor unit Air flow CMM 19-21-23-27 24-25-27-30
(Low-Medium2-Medium1-High) CFM 670-740-810-950 850-880-950-1060
External pressure Pa 0 0
Sound level dB(A) 33-36-39-41 37-40-43-45
(Low-Medium2-Medium1-High)
External finish (Panel) White Munsell 0.70Y 8.59/0.97
Dimension W : mm 840 (950)
Unit (Panel) D : mm 840 (950)
H : mm 298 (30)
W : inch 33-1/16 (37-3/8)
D : inch 33-1/16 (37-3/8)
H : inch 11-3/4 (1-3/16)
Weight kg 32 (5)
Unit (Panel) lbs 71 (11)
Field drain pipe O.D. mm 32
inch 1-1/4
Outdoor unit Air flow CMM 100
CFM 3,530
Sound level at cooling dB(A) 49 50
Sound level at heating dB(A) 51 52
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30
H : mm 1350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 53-1/8
Weight kg 121 116
lbs 267 256
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 75
OCS05E-1.qxp 08.3.31 9:52 AM Page 11

12
Model name Indoor unit PLA-RP100AA2 PLA-RP125AA2 PLA-RP140AA2
Outdoor unit PUHZ-RP100YHA2 PUHZ-RP125YHA2 PUHZ-RP140YHA2
Cooling Capacity Btu/h 34,100 42,700 47,800
kW 10.0(4.9-11.4) 12.5(5.5-14.0) 14.0(5.5-15.3)
Total input kW 3.02 3.87 4.65
EER 3.31 3.23 3.01
Energy label class A A B
SHF 0.78 0.74 0.71
Heating Capacity Btu/h 38,200 47,800 54,600
kW 11.2(4.5-14.0) 14.0(5.0-16.0) 16.0(5.0-18.0)
Total input kW 3.02 3.88 4.69
COP 3.61 3.61 3.41
Energy label class A A B
Booster heater kW - - -
Power supply Phase [3
Cycle Hz 50
Voltage V 400
Breaker size A 16
Indoor unit Air flow CMM 19-21-23-27 24-25-27-30
(Low-Medium2-Medium1-High) CFM 670-740-810-950 850-880-950-1060
External pressure Pa 0 0
Sound level dB(A) 33-36-39-41 37-40-43-45
(Low-Medium2-Medium1-High)
External finish (Panel) White Munsell 0.70Y 8.59/0.97
Dimension W : mm 840 (950)
Unit (Panel) D : mm 840 (950)
H : mm 298 (30)
W : inch 33-1/16 (37-3/8)
D : inch 33-1/16 (37-3/8)
H : inch 11-3/4 (1-3/16)
Weight kg 32 (5)
Unit (Panel) lbs 71 (11)
Field drain pipe O.D. mm 32
inch 1-1/4
Outdoor unit Air flow CMM 100
CFM 3,530
Sound level at cooling dB(A) 49 50
Sound level at heating dB(A) 51 52
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30
H : mm 1350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 53-1/8
Weight kg 135 130
lbs 298 287
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 75
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor : D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚CD.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating Upper limit D.B. 28˚CD.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚CD.B. -20˚C, W.B. -20˚C
4. Above data are based on the indicated voltage.
Indoor unit Single phase 230V 50Hz
3 phase 400V 50Hz
Outdoor unit
Indoor unit 198~264V, 50Hz
342~457V, 50Hz
Outdoor unit
3. Guaranteed voltage
wIf optional air protect guide installed. D.B.-15:
OCS05E-1.qxp 08.3.31 9:52 AM Page 12

13
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor : D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚CD.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating Upper limit D.B. 28˚CD.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚CD.B. -11˚C, W.B. -12˚C
4. Above data are based on the indicated voltage.
wIf optional air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PEAD-RP35EA2 PEAD-RP50EA
Outdoor unit PUHZ-RP35VHA2 PUHZ-RP50VHA2
PUHZ-RP35VHA3 PUHZ-RP50VHA3
Cooling Capacity Btu/h 12,300 16,700
kW 3.6(1.6-4.5) 4.9(2.3-5.6)
Total input kW 1.12 1.52
EER 3.21 3.22
Energy label class A A
SHF 0.89 0.82
Heating Capacity Btu/h 14,000 20,500
kW 4.1(1.6-5.2) 6.0(2.5-7.3)
Total input kW 1.20 1.65
COP 3.41 3.64
Energy label class B A
Booster heater kW - -
Power supply Phase [1
Cycle Hz 50
Voltage V 230
Breaker size A 16
Indoor unit Air flow CMM 13.5-17
(Low-High) CFM 476-600
External pressure Pa 30(70)
Sound level dB(A) 36-40
(Low-High) (70Pa : 38-44)
External finish Galvanized sheets
Dimension W : mm 935
D : mm 700
H : mm 295
W : inch 36-13/16
D : inch 27-5/8
H : inch 11-5/8
Weight kg 33 35
lbs 73 77
Unit drain pipe R1(External thread)
Outdoor unit Air flow CMM 35
CFM 1,240
Sound level at cooling dB(A) 44
Sound level at heating dB(A) 46
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 800
D : mm 300+23
H : mm 600
W : inch 31-1/2
D : inch 11-13/16 + 7/8
H : inch 23-5/8
Weight kg 45(VHA2)/42(VHA3)
lbs 99(VHA2)/92(VHA3)
Refrigerant pipe size Gas side O.D. mm 12.7
inch 1/2
Liquid side O.D. mm 6.35
inch 1/4
Refrigerant pipe length Height difference m Max. 30
Length m Max. 50
2-2. CEILING-CONCEALED TYPE
OCS05E-1.qxp 08.3.31 9:52 AM Page 13

14
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor : D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚CD.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating Upper limit D.B. 28˚CD.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚CD.B. -11˚C, W.B. -12˚C
4. Above data are based on the indicated voltage.
wIf optional air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PEAD-RP60EA PEAD-RP71EA
Outdoor unit PUHZ-RP60VHA2 PUHZ-RP71VHA2
PUHZ-RP60VHA3 PUHZ-RP71VHA3
Cooling Capacity Btu/h 20,500 24,200
kW 6.0(2.7-6.7) 7.1(3.3-8.1)
Total input kW 1.86 2.15
EER 3.23 3.30
Energy label class A A
SHF 0.79 0.83
Heating Capacity Btu/h 23,900 27,300
kW 7.0(2.8-8.2) 8.0(3.5-10.2)
Total input kW 1.90 2.34
COP 3.68 3.42
Energy label class A B
Booster heater kW - -
Power supply Phase [1
Cycle Hz 50
Voltage V 230
Breaker size A 25
Indoor unit Air flow CMM 17-21 20-25
(Low-High) CFM 600-741 706-883
External pressure Pa 30(70) 70(130)
Sound level dB(A) 37-41 37-41
(Low-High) (70Pa : 39-46) (130Pa : 40-45)
External finish Galvanized sheets
Dimension W : mm 1175
D : mm 700 740
H : mm 295
W : inch 46-1/8
D : inch 27-5/8 29-1/8
H : inch 11-5/8
325
12-13/16
Weight kg 42 44
lbs 92 97
Unit drain pipe R1(External thread)
Outdoor unit Air flow CMM 55 55
CFM 1,940 1,940
Sound level at cooling dB(A) 47 47
Sound level at heating dB(A) 48 48
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950 950
D : mm 330+30 330+30
H : mm 943 943
W : inch 37-3/8 37-3/8
D : inch 13 + 1-3/16 13 + 1-3/16
H : inch 37-1/8 37-1/8
Weight kg 75(VHA2)/68(VHA3)
lbs 165(VHA2)/150(VHA3)
Refrigerant pipe size Gas side O.D. mm 15.88 15.88
inch 5/8 5/8
Liquid side O.D. mm 9.52 9.52
inch 3/8 3/8
Refrigerant pipe length Height difference m Max. 30 Max. 30
Length m Max. 50 Max. 50
OCS05E-1.qxp 08.3.31 9:52 AM Page 14

15
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor : D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚CD.B. 46:
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5:w
Heating Upper limit D.B. 28˚CD.B. 21:, W.B. 15:
Lower limit D.B. 17˚CD.B. -20:, W.B. -20:
4. Above data are based on the indicated voltage.
wIf optional air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PEAD-RP100EA2 PEAD-RP125EA PEAD-RP140EA
Outdoor unit PUHZ-RP100VHA2
PUHZ-RP100VHA3 PUHZ-RP125VHA2 PUHZ-RP140VHA2
Cooling Capacity Btu/h 34,100 42,700 47,800
kW 10.0(4.9-11.4) 12.5(5.5-14.0) 14.0(5.5-15.3)
Total input kW 3.06 3.89 4.65
EER 3.27 3.21 3.01
Energy label class A A B
SHF 0.86 0.82 0.83
Heating Capacity Btu/h 38,200 47,800 54,600
kW 11.2(4.5-14.0) 14.0(5.0-16.0) 16.0(5.0-18.0)
Total input kW 3.19 3.88 4.69
COP 3.51 3.61 3.41
Energy label class B A B
Booster heater kW - - -
Power supply Phase [1
Cycle Hz 50
Voltage V 230
Breaker size A 32 40
Indoor unit Air flow CMM 33.5-42 36.5-46
(Low-High) CFM 1183-1483 1288-1624
External pressure Pa 70(130)
Sound level dB(A) 44-50 46-51
(Low-High) (130Pa : 46-52) (130Pa : 47-53)
External finish Galvanized sheets
Dimension W : mm 1415 1715
D : mm 740
H : mm 325
W : inch 55-11/16 67-1/2
D : inch 29-1/8
H : inch 12-13/16
Weight kg 65 70
lbs 143 154
Unit drain pipe R1(External thread)
Outdoor unit Air flow CMM 100
CFM 3,530
Sound level at cooling dB(A) 49 50
Sound level at heating dB(A) 51 52
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30
H : mm 1350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 53-1/8
Weight kg 121(VHA2)/116(VHA3) 116
lbs 267(VHA2)/256(VHA3) 256
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 75
OCS05E-1.qxp 08.3.31 9:52 AM Page 15

16
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor : D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚CD.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating Upper limit D.B. 28˚CD.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚CD.B. -20˚C, W.B. -20˚C
4. Above data are based on the indicated voltage.
Indoor unit Single phase 230V 50Hz
3 phase 400V 50Hz
Outdoor unit
Indoor unit 198~264V, 50Hz
342~457V, 50Hz
Outdoor unit
3. Guaranteed voltage
wIf optional air protect guide installed. D.B.-15:
Model name Indoor unit PEAD-RP100EA2 PEAD-RP125EA PEAD-RP140EA
Outdoor unit
PUHZ-RP100YHA3
PUHZ-RP100YHA2 PUHZ-RP125YHA2 PUHZ-RP140YHA2
Cooling Capacity Btu/h 34,100 42,700 47,800
kW 10.0(4.9-11.4) 12.5(5.5-14.0) 14.0(5.5-15.3)
Total input kW 3.06 3.89 4.65
EER 3.27 3.21 3.01
Energy label class A A B
SHF 0.86 0.82 0.83
Heating Capacity Btu/h 38,200 47,800 54,600
kW 11.2(4.5-14.0) 14.0(5.0-16.0) 16.0(5.0-18.0)
Total input kW 3.19 3.88 4.69
COP 3.51 3.61 3.41
Energy label class B A B
Booster heater kW - - -
Power supply Phase [3
Cycle Hz 50
Voltage V 400
Breaker size A 16
Indoor unit Air flow CMM 33.5-42 36.5-46
(Low-High) CFM 1183-1483 1288-1624
External pressure Pa 70(130)
Sound level dB(A) 44-50 46-51
(Low-High) (130Pa : 46-52) (130Pa : 47-53)
External finish Galvanized sheets
Dimension W : mm 1415 1715
D : mm 740
H : mm 325
W : inch 55-11/16 67-1/2
D : inch 29-1/8
H : inch 12-13/16
Weight kg 65 70
lbs 143 154
Unit drain pipe R1(External thread)
Outdoor unit Air flow CMM 100
CFM 3,530
Sound level at cooling dB(A) 49 50
Sound level at heating dB(A) 51 52
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30
H : mm 1350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 53-1/8
Weight kg 135(YHA2)/130(YHA3) 130
lbs 298(YHA2)/287(YHA3) 287
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 75
OCS05E-1.qxp 08.3.31 9:52 AM Page 16

17
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor : D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚CD.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w1
Heating Upper limit D.B. 28˚CD.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚C
D.B. -11˚C, W.B. -12˚C w2
4. Above data are based on the indicated voltage.
w1. If optional air protect guide installed. D.B.-15:
w2. For RP100 D.B. -20:, W.B. -20:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PEAD-RP60GA PEAD-RP71GA PEAD-RP100GA
Outdoor unit PUHZ-RP60VHA2 PUHZ-RP71VHA2 PUHZ-RP100VHA2
PUHZ-RP60VHA3 PUHZ-RP71VHA3 PUHZ-RP100VHA3
Cooling Capacity Btu/h 20,500 24,200 34,100
kW 6.0(2.7-6.7) 7.1(3.3-8.1) 10.0(4.9-11.4)
Total input kW 1.68 2.15 3.08
EER 3.57 3.30 3.25
Energy label class A A A
SHF 0.88 0.83 0.86
Heating Capacity Btu/h 23,900 27,300 38,200
kW 7.0(2.8-8.2) 8.0(3.5-10.2) 11.0(4.5-14.0)
Total input kW 1.77 2.34 3.23
COP 3.95 3.42 3.41
Energy label class A B B
Booster heater kW - - -
Power supply Phase [1
Cycle Hz 50
Voltage V 230
Breaker size A 25 32
Indoor unit Air flow CMM 16.5-21 20-25 26.5-33
(Low-High) CFM 582-741 706-883 935-1165
External pressure Pa 10/50/70 10/50/70
Sound level dB(A) 33-37/35-40/36-42 35-38/37-41/37-43 40-43/42-45/42-46
(Low-High) (10/50/70Pa) (10/50/70Pa) (10/50/70Pa)
External finish Galvanized sheets
Dimension W : mm 1171 1411
D : mm 740
H : mm 275
W : inch 46-1/8 55-9/16
D : inch 29-1/8
H : inch 10-13/16
Weight kg 42 50
lbs 93 111
Unit drain pipe R1(External thread)
Outdoor unit Air flow CMM 55 100
CFM 1,940 3,530
Sound level at cooling dB(A) 47 49
Sound level at heating dB(A) 48 51
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30
H : mm 943 1350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 37-1/8 53-1/8
Weight kg 75(VHA2)/68(VHA3) 121(VHA2)/116(VHA3)
lbs 165(VHA2)/150(VHA3) 267(VHA2)/256(VHA3)
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30 Max. 30
Length m Max. 50 Max. 75
OCS05E-1.qxp 08.3.31 9:52 AM Page 17

18
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor : D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚CD.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating Upper limit D.B. 28˚CD.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚CD.B. -20˚C, W.B. -20˚C
4. Above data are based on the indicated voltage.
Indoor unit Single phase 230V 50Hz
3 phase 400V 50Hz
Outdoor unit
Indoor unit 198~264V, 50Hz
342~457V, 50Hz
Outdoor unit
3. Guaranteed voltage
wIf optional air protect guide installed. D.B.-15:
Model name Indoor unit PEAD-RP100GA
Outdoor unit PUHZ-RP100YHA2
PUHZ-RP100YHA3
Cooling Capacity Btu/h 34,100
kW 10.0(4.9-11.4)
Total input kW 3.08
EER 3.25
Energy label class A
SHF 0.86
Heating Capacity Btu/h 38,200
kW 11.0(4.5-14.0)
Total input kW 3.23
COP 3.41
Energy label class B
Booster heater kW -
Power supply Phase [3
Cycle Hz 50
Voltage V 400
Breaker size A 16
Indoor unit Air flow CMM 26.5-33
(Low-High) CFM 935-1165
External pressure Pa 10/50/70
Sound level dB(A) 40-43/42-45/42-46
(Low-High) (10/50/70Pa)
External finish Galvanized sheets
Dimension W : mm 1411
D : mm 740
H : mm 275
W : inch 55-9/16
D : inch 29-1/8
H : inch 10-13/16
Weight kg 50
lbs 111
Unit drain pipe R1(External thread)
Outdoor unit Air flow CMM 100
CFM 3,530
Sound level at cooling dB(A) 49
Sound level at heating dB(A) 51
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 943
D : mm 330+30
H : mm 1350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 53-1/8
Weight kg 135(YHA2)/130(YHA3)
lbs 298(YHA2)/287(YHA3)
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 75
OCS05E-1.qxp 08.3.31 9:52 AM Page 18

19
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor : D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚CD.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w1
Heating Upper limit D.B. 28˚CD.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚C
D.B. -20˚C, W.B. -20˚C
4. Above data are based on the indicated voltage.
w1. If optional air protect guide is installed : D.B.-15:
Indoor unit 3 phase 400V 50Hz
3 phase 400V 50Hz
Outdoor unit
3. Guaranteed voltage
342~457V, 50Hz
Model name Indoor unit PEA-RP200GA PEA-RP250GA
Outdoor unit PUHZ-RP200YHA2 PUHZ-RP250YHA2
Cooling Capacity Btu/h 65,000 75,000
kW 19.0(9.0-22.4) 22.0(11.2-28.0)
Total input kW 6.70 8.34
EER
Energy label class
2.84 2.64
CD
SHF 0.81 0.86
Heating Capacity Btu/h 76,000 92,000
kW 22.4(9.5-25.0) 27.0(12.5-31.5)
Total input kW 6.50 8.20
COP 3.45 3.29
Energy label class B C
Booster heater kW - -
Power supply Phase [3
Cycle Hz 50
Voltage V 400
Breaker size A Indoor 15 / Outdoor 32
Indoor unit Air flow CMM 52-65 64-80
(Low-High) CFM 1835-2295 2260-2825
External pressure Pa 150
Sound level dB(A) 48-51 49-52
(Low-High)
External finish Galvanized steel
Dimension W : mm 16001400
D : mm 634
H : mm 400
W : inch 6355-1/8
D : inch 25
H : inch 15-3/4
Weight kg 70 77
lbs 155 170
Unit drain pipe R1
Outdoor unit Air flow CMM 130
CFM 4590
Sound level at cooling dB(A) 58
Sound level at heating dB(A) 59
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30
H : mm 1350
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 53-1/8
Weight kg 135
lbs 298
136
300
Refrigerant pipe size Gas side O.D. mm 25.4
inch 1
Liquid side O.D. mm 12.7
inch 1/2
9.52
3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 120
OCS05E-1.qxp 08.3.31 9:52 AM Page 19

20
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27:(80˚F) W.B. 19:(66˚F) Outdoor : D.B. 35:(95˚F) W.B. 24:(75˚F)
Heating Indoor : D.B. 20:(68˚F) Outdoor : D.B. 7:(45˚F) W.B. 6:(43˚F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35˚C, W.B. 22.5˚CD.B. 46˚C
Lower limit D.B. 19˚C, W.B. 15˚C D.B. -5˚C w
Heating Upper limit D.B. 28˚CD.B. 21˚C, W.B. 15˚C
Lower limit D.B. 17˚CD.B. -11˚C, W.B. -12˚C
4. Above data are based on the indicated voltage.
wIf optional air protect guide installed. D.B.-15:
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PKA-RP35GAL PKA-RP50GAL
Outdoor unit PUHZ-RP35VHA2 PUHZ-RP50VHA2
PUHZ-RP35VHA3 PUHZ-RP50VHA3
Cooling Capacity Btu/h 12,300 15,700
kW 3.6(1.6-4.5) 4.6(2.3-5.4)
Total input kW 1.03 1.63
EER 3.50 2.82
Energy label class A C
SHF 0.84 0.74
Heating Capacity Btu/h 14,000 15,400
kW 4.1(1.6-5.2) 4.5(2.5-6.2)
Total input kW 1.27 1.40
COP 3.23 3.21
Energy label class C C
Booster heater kW - -
Power supply Phase [1
Cycle Hz 50
Voltage V 230
Breaker size A 16
Indoor unit Air flow CMM 9-10-11-12
(Low-Medium2-Medium1-High) CFM 320-355-390-425
External pressure Pa 0
Sound level dB(A) 36-38-41-43
(Low-Medium2-Medium1-High)
External finish White Munsell 0.70Y 8.59/0.97
Dimension W : mm 990
D : mm 235
H : mm 340
W : inch 39
D : inch 9-1/4
H : inch 13-3/8
Weight kg 16
lbs 35
Field drain pipe I.D. mm 20
inch 13/16
Outdoor unit Air flow CMM 35
CFM 1,240
Sound level at cooling dB(A) 44
Sound level at heating dB(A) 46
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 800
D : mm 300+23
H : mm 600
W : inch 31-1/2
D : inch 11-13/16 + 7/8
H : inch 23-5/8
Weight kg 45(VHA2)/42(VHA3)
lbs 99(VHA2)/92(VHA3)
Refrigerant pipe size Gas side O.D. mm 12.7
inch 1/2
Liquid side O.D. mm 6.35
inch 1/4
Refrigerant pipe length Height difference m Max. 30
Length m Max. 50
2-3. WALL MOUNTED TYPE
OCS05E-1.qxp 08.3.31 9:52 AM Page 20
