Mitsubishi Electric SVZ-KP12NA User manual

Air-Conditioners
SVZ-KP12,18, 24, 30, 36NA
M-SERIES
OPERATION MANUAL FOR INSTALLER
En
For safe and correct use, please read this operation manual thoroughly before installing
the air-conditioner unit.
MANUEL D'INSTALLATION POUR L’INSTALLATEUR
Fr
Veuillez lire le manuel d’installation en entier avant d’installer ce climatiseur pour éviter
tout accident et vous assurer d’une utilisation correcte.

Table of Contents
SVZ-KP12,18, 24, 30, 36NA ................................................................................................................ 5
1. Safety Precautions .................................................................................................................. 5
Symbols used in the text ..................................................................................................... 5
Symbols used in the illustrations .......................................................................................... 5
Disposing of the unit ........................................................................................................... 6
2. Part Names ............................................................................................................................ 7
3. Operation ............................................................................................................................... 8
3.1 Operation mode select .................................................................................................. 8
3.2 Fan speed setting .......................................................................................................... 9
3.3 Ventilation ..................................................................................................................... 9
4. Timer .................................................................................................................................... 10
5. Care and Cleaning ................................................................................................................. 11
6. Troubleshooting ..................................................................................................................... 13
7. Specifications ........................................................................................................................ 15
Memo ....................................................................................................................................... 16
SVZ-KP12,18, 24, 30, 36NA ............................................................................................................... 17
1. Consignes de sécurité ............................................................................................................ 17
Symboles utilisés dans le texte ........................................................................................... 17
Symboles utilisés dans les illustrations ................................................................................ 17
Mise au rebut de l’appareil ................................................................................................. 18
2. Nomenclature ........................................................................................................................ 19
3. Fonctionnement ..................................................................................................................... 20
3.1. Sélection du mode de fonctionnement .......................................................................... 20
3.2. Réglage de la vitesse du ventilateur ............................................................................. 21
3.3. Ventilation ................................................................................................................... 21
4. Minuterie ............................................................................................................................... 22
5. Entretien et nettoyage ............................................................................................................ 23
6. Guide de dépannage .............................................................................................................. 25
7. Spécifications techniques ....................................................................................................... 27
Note de service ......................................................................................................................... 29
3 © 2018 Mitsubishi Electric US, Inc.
SVZ-KP12,18, 24, 30, 36NA

Specifications are subject to change without notice. 4
SVZ-KP12,18, 24, 30, 36NA

1. Safety Precautions
• Before installing the unit, make sure you read all
the “Safety Precautions”.
• The “Safety Precautions” provide very important
points regarding safety. Make sure you follow
them.
• Please report to or take consent by the supply
authority before connection to the system.
Symbols used in the text
WARNING
Describes precautions that should be observed to prevent danger of injury or death to the
user.
CAUTION
Describes precautions that should be observed to prevent damage to the unit.
Symbols used in the illustrations
: Indicates a part which must be grounded.
5 © 2018 Mitsubishi Electric US, Inc.
ENGLISH
SVZ-KP12,18, 24, 30, 36NA

WARNING
•The unit must not be installed by the user. Ask the dealer or an authorized company to
install the unit. If the unit is installed improperly, water leakage, electric shock or fire may
result.
• Do not stand on, or place any items on the unit.
• Do not splash water over the unit and do not touch the unit with wet hands. An electric
shock may result.
• Do not spray combustible gas close to the unit. Fire may result.
• Do not place a gas heater or any other open-flame appliance where it will be exposed to
the air discharged from the unit. Incomplete combustion may result.
• Do not remove the front panel or the fan guard from the outdoor unit when it is running.
• When you notice exceptionally abnormal noise or vibration, stop operation, turn off the
power switch, and contact your dealer.
• Never insert fingers, sticks etc. into the intakes or outlets.
• If you detect odd smells, stop using the unit, turn off the power switch and consult your
dealer. Otherwise, a breakdown, electric shock or fire may result.
• This air conditioner is NOT intended for use by children or infirm persons without
supervision.
• Young children must be supervised to ensure that they do not play with the air
conditioner.
• If the refrigeration gas blows out or leaks, stop the operation of the air conditioner,
thoroughly ventilate the room, and contact your dealer.
CAUTION
•Do not use any sharp object to push the buttons, as this may damage the remote
controller.
• Never block or cover the indoor or outdoor unit’s intakes or outlets.
Disposing of the unit
When you need to dispose of the unit, consult your dealer.
SVZ-KP12,18, 24, 30, 36NA
Specifications are subject to change without notice. 6
ENGLISH

2. Part Names
•Indoor Unit
SVP-KP·NA
Fan steps 3 steps
Vane -
Louver -
Filter Normal
Filter cleaning indication -
•SVZ-KP·NA
Multi Position
Air Outlet
Filter
Door
Air Inlet
•Remote controller (Optional parts)
Radio frequency interface Wired remote controller
RF thermostat
SVZ-KP12,18, 24, 30, 36NA
7 © 2018 Mitsubishi Electric US, Inc.
ENGLISH

3. Operation
• About the operation method, refer to the operation manual that comes with each remote controller.
3.1 Operation mode select
Cool/DRY/Fan/Heat/Automatic (cool/heat)/Ventilation modes are available.
NOTE
• Heat and Automatic modes can not be available for cooling only units.
• Ventilation mode: only indicated on the following condition. Wired remote controller is
used and LOSSNAY is connected.
• Automatic mode
– According to a set temperature, cooling operation starts if the room temperature is too
hot and heating operation starts if the room temperature is too cold.
– During automatic operation, if the room temperature changes and remains 4 °F [2 °C]
or more above the set temperature for 15 minutes, the air conditioner switches to
cooling mode. If the room temperature remains 4 °F [2 °C] or more below the set
temperature for 15 minutes, the air conditioner switches to heating mode.
Cooling mode 15 minutes (switches from
heating to cooling)
Set temperature +4 °F [2 °C]
Set temperature
Set temperature -4 °F [-2 °C]
15 minutes (switches
from cooling to heating)
SVZ-KP12,18, 24, 30, 36NA
Specifications are subject to change without notice. 8
ENGLISH

3.2 Fan speed setting
NOTE
In the following cases, the actual fan speed generated by the unit will differ from the speed
shown the remote controller display.
1. When the unit is in STAND BY or DEFROST states.
2. When the temperature of the heat exchanger is low in the heating mode. (e.g.
immediately after heating operation starts)
3. In HEAT mode, when room temperature is higher than the temperature setting.
4. When the heater control mode is the factory setting and the heater is on, the fan will
operate at high speed.
5. When the unit is in DRY mode.
3.3 Ventilation
For LOSSNAY combination
The following 2 patterns of operation are available:
• Run the ventilator together with the indoor unit.
• Run the ventilator independently.
NOTE
With some model configurations, the fan on the indoor unit may come on even when you
set the ventilator to run independently.
NOTE
(for wireless RF thermostat):
• Running the ventilator independently is not available.
• No indication on the remote controller.
SVZ-KP12,18, 24, 30, 36NA
9 © 2018 Mitsubishi Electric US, Inc.
ENGLISH

4. Timer
• Timer functions are different by each remote controller.
• For details on how to operate the remote controller, refer to the appropriate operation manual included
with each remote controller.
SVZ-KP12,18, 24, 30, 36NA
Specifications are subject to change without notice. 10
ENGLISH

5. Care and Cleaning
•Cleaning the filters
– Clean the filters using a vacuum cleaner. If you do not have a vacuum cleaner, tap the filters against a
solid object to knock off dirt and dust.
– If the filters are especially dirty, wash them in lukewarm water. Take care to rinse off any detergent
thoroughly and allow the filters to dry completely before putting them back into the unit.
CAUTION
– Do not dry the filters in direct sunlight or by using a heat source, such as an electric
heater: this may warp them.
– Do not wash the filters in hot water (above 122 °F [50 °C]), as this may warp them.
– Make sure that the air filters are always installed. Operating the unit without air filters
can cause malfunction.
CAUTION
– Before you start cleaning, stop operation and turn OFF the power supply.
– Indoor units are equipped with filters to remove the dust of sucked-in air. Clean the
filters using the methods shown in the following sketches.
•Filter removal
CAUTION
Caution:
– In removing the filter, precautions must be taken to protect your eyes from dust. Also,
if you have to climb up on a stool to do the job, be careful not to fall.
– When the filter is removed, do not touch the metallic parts inside the indoor unit,
otherwise injury may result.
•Removal and replacement of filter
– Unscrew the two thumb knobs on the panel stamped “filter” tilt forward and pull the panel out. Grasp
the edge of the filter and slide out. Re-install in reverse. (see Fig A)
SVZ-KP12,18, 24, 30, 36NA
11 © 2018 Mitsubishi Electric US, Inc.
ENGLISH

■SVZ-KP·NA
Filter
Fig A
SVZ-KP12,18, 24, 30, 36NA
Specifications are subject to change without notice. 12
ENGLISH

6. Troubleshooting
Having trouble? Here is the solution. (Unit is operating normally.)
Air conditioner does not heat or cool well. • Clean the filter. (Airflow is reduced when the filter is dirty or clogged.)
• Check the temperature adjustment and adjust the set temperature.
• Make sure that there is plenty of space around the outdoor unit. Is the indoor unit air intake or
outlet blocked?
• Has a door or window been left open?
When heating operation starts, warm air does not blow from the
indoor unit soon.
• Warm air does not blow until the indoor unit has sufficiently warmed up.
During Heat mode, the air conditioner stops before the set room
temperature is reached.
• When the outdoor temperature is low and the humidity is high, frost may form on the outdoor unit.
If this occurs, the outdoor unit performs a defrosting operation. Normal operation should begin
after approximately 10 minutes.
Airflow direction changes during operation or airflow direction
cannot be set.
• During Heat mode, the vanes automatically move to the horizontal airflow direction when the air-
flow temperature is low or during defrosting mode.
When the airflow direction is changed, the vanes always move up
and down past the set position before finally stopping at the posi-
tion.
• When the airflow direction is changed, the vanes move to the set position after detecting the base
position.
A flowing water sound or occasional hissing sound is heard. • These sounds can be heard when refrigerant is flowing in the air conditioner or when the refriger-
ant flow is changing.
A cracking or creaking sound is heard. • These sounds can be heard when parts rub against each due to expansion and contraction from
temperature changes.
The room has an unpleasant odor. • The indoor unit draws in air that contains gases produced from the walls, carpeting, and furniture
as well as odors trapped in clothing, and then blows this air back into the room.
A white mist or vapor is emitted from the indoor unit. • If the indoor temperature and the humidity are high, this condition may occur when operation
starts.
• During defrosting mode, cool airflow may blow down and appear like a mist.
Water or vapor is emitted from the outdoor unit. • During Cool mode, water may form and drip from the cool pipes and joints.
• During Heat mode, water may form and drip from the heat exchanger.
• During defrosting mode, water on the heat exchanger evaporates and water vapor may be emit-
ted.
“ ” appears in the remote controller display.
• During central control,
“ ” appears in the remote controller display.
and air conditioner operation cannot be started or stopped using the remote controller.
When restarting the air conditioner soon after stopping it, it does
not operate even though the ON/OFF button is pressed.
• Wait approximately three minutes. (Operation has stopped to protect the air conditioner.)
Air conditioner operates without the ON/OFF button being press-
ed.
• Is the on timer set?
Press the ON/OFF button to stop operation.
• Is the air conditioner connected to a central remote controller?
Consult the concerned people who control the air conditioner.
•
Does “ ” appear in the remote controller display?
Consult the concerned people who control the air conditioner.
• Has the auto recovery feature from power failures been set?
Press the ON/OFF button to stop operation.
Air conditioner stops without the ON/OFF button being pressed. • Is the off timer set?
Press the ON/OFF button to restart operation.
• Is the air conditioner connected to a central remote controller?
Consult the concerned people who control the air conditioner.
•
Does “ ” appear in the remote controller display?
Consult the concerned people who control the air conditioner.
SVZ-KP12,18, 24, 30, 36NA
13 © 2018 Mitsubishi Electric US, Inc.
ENGLISH

Having trouble? Here is the solution. (Unit is operating normally.)
Remote controller timer operation cannot be set. • Are timer settings invalid?
or appears in the remote controller
If the timer can be set, display.
“PLEASE WAIT” appears in the remote controller display. • The initial settings are being performed. Wait approximately 3 minutes.
An error code appears in the remote controller display. • The protection devices have operated to protect the air conditioner.
• Do not attempt to repair this equipment by yourself.
Turn off the power switch immediately and consult your dealer. Be sure to provide the dealer with
the model name and information that appeared in the remote controller display.
Draining water or motor rotation sound is heard. • When cooling operation stops, the drain pump operates and then stops. Wait approximately 5 mi-
nutes.
Noise is louder than specifications. • The indoor operation sound level is affected by the acoustics of the particular room as shown in
the following table and will be higher than the noise specification, which was measured in anecho-
ic room.
High sound absorbing
rooms
Normal rooms Low sound ab-
sorbing rooms
Location ex-
amples
Broadcasting studio,
music room, etc
Reception room,
hotel lobby, etc.
Office, hotel room
Noise levels 3 to 7 dB(A) 6 to 10 dB(A) 9 to 13 dB(A)
Nothing appears in the wireless remote controller display, the dis-
play is faint, or signals are not received by the indoor unit unless
the remote controller is close.
• The batteries are low.
Replace the batteries and press the Reset button.
• If nothing appears even after the batteries are replaced, make sure that the batteries are installed
in the correct directions (+, –)
The operation lamp near the receiver for the wireless remote
controller on the indoor unit is blinking.
• The self diagnosis function has operated to protect the air conditioner.
• Do not attempt to repair this equipment by yourself.
Turn off the power switch immediately and consult your dealer. Be sure to provide the dealer with
the model name.
SVZ-KP12,18, 24, 30, 36NA
Specifications are subject to change without notice. 14
ENGLISH

7. Specifications
SVZ-KP NA Series
Small Cabinet Medium Cabinet
Item / Model SVZ-KP12NA SVZ-KP18NA SVZ-KP24NA SVZ-KP30NA SVZ-KP36NA
Power Source 208/230V, 1-phase, 60hZ
Cooling capacity/Heating capacity Btu/h 12,000 / 13,500 18,000 / 22,800 24,000 / 27,000 30,000 / 34,000 36,000 / 40,000
kW 3.5/4.0 5.3/6.7 7.0 / 7.9 8.8 / 10.0 10.6 / 11.7
Tonnage 1 1.5 2 2.5 3
Dimensions
Height mm [in] 1,101 [39-3/4] 1,113.8 [43-7/8]
Width mm [in] 432 [17]
Depth mm [in] 548 [21-5/8]
Net weight kg [lb] 43 [93] 54 [119]
Fan
Airflow rate
(Low-Mid-High)
CFM 314 – 381 – 448 471 – 573 – 675 515 - 625 - 735 613 - 744 - 875 767 - 931 - 1,095
External static
pressure
in. WG 0.30 - 0.50 - 0.80
[Pa] [75 - 125 - 200]
Sound Pressure
(Low - Mid - High)
dB(A) 29 - 34 - 37 31 - 35 - 39 30-34-38 32-36-40 35-39-43
Notes:
1. Rating conditions (cooling)
Indoor : 80 °F [26.7 °C] D.B., 67 °F [19.4 °C]
W.B.
Outdoor : 95 °F [35 °C] D.B.
2. Rating conditions (heating)
Indoor : 70 °F [21.1 °C] D.B.
Outdoor : 47 °F [8.3 °C] D.B., 43 °F [6.1 °C]
W.B.
3. The indicated capacity is the value when one
indoor unit is connected to the outdoor unit.
4. Specifications subject to change without notice.
5. The external static pressure is set to 0.50 in.
WG (125 Pa) at factory shipment.
Table 1. Guaranteed operating range
Indoor
Cooling
Upper limit 95 °F [35 °C] D.B.
71 °F [21.7 °C] W.B.
Lower limit 67 °F [19.4 °C] D.B.
57 °F [13.9 °C] W.B.
Heating
Upper limit 80 °F [26.7 °C] D.B.
-
Lower limit 70 °F [21.1 °C] D.B.
-
1. Units should be installed by licensed electric contractor accordingly to local code requirement.
2. For outdoor units to be connected, refer to the Installation Manual that comes with the units.
SVZ-KP12,18, 24, 30, 36NA
15 © 2018 Mitsubishi Electric US, Inc.
ENGLISH

Memo
SVZ-KP12,18, 24, 30, 36NA
Specifications are subject to change without notice. 16
ENGLISH

1. Consignes de sécurité
• Avant d’installer le climatiseur, lisez
attentivement toutes les “Consignes de sécurité”.
•Les “Consignes de sécurité” concernent des
points très importants en matière de sécurité.
Veillez à bien les suivre.
• Veillez à consulter ou obtenir la permission de la
compagnie d’électricité avant de connecter au
système.
Symboles utilisés dans le texte
AVERTISSEMENT
Décrit les précautions à suivre pour éviter tout danger de blessure ou de décès de
l’utilisateur.
ATTENTION
Décrit les précautions à suivre pour éviter d’endommager l’appareil.
Symboles utilisés dans les illustrations
: Indique une pièce à mettre à la terre.
17 © 2018 Mitsubishi Electric US, Inc.
FRANÇAIS
SVZ-KP12,18, 24, 30, 36NA

AVERTISSEMENT
• Cet appareil ne doit pas être installé par l’utilisateur. Demandez au revendeur ou à une
société agréée de l’installer. Si l’appareil n’est pas correctement installé, il peut y avoir
un risque de fuite d’eau, d’électrocution ou d’incendie.
• Ne montez pas sur l’appareil et ne posez aucun objet dessus.
• N’éclaboussez pas l’appareil et ne le touchez pas avec des mains humides. Cela
risquerait de provoquer une électrocution.
• Ne vaporisez pas de gaz inflammable à proximité de l’appareil. Cela risquerait de
provoquer un incendie.
• Ne placez pas un chauffage au gaz ou tout autre appareil fonctionnant avec une flamme
nue là où il serait exposé à l’échappement d’air du climatiseur. Cela risquerait de
provoquer une mauvaise combustion.
• Ne retirez pas la face avant ou la protection du ventilateur de l’appareil extérieur
pendant son fonctionnement.
• En cas de vibrations ou de bruits particulièrement anormaux, arrêtez l’appareil, mettez-
le hors tension et contactez votre revendeur.
• Ne mettez jamais les doigts, des bâtons, etc. dans les entrées ou les sorties d’air.
• En cas d’odeurs étranges, arrêtez l’appareil, mettez-le hors tension et contactez votre
revendeur. Dans le cas contraire, une panne, une électrocution ou un incendie pourrait
se produire.
• Ne laissez JAMAIS des enfants ou des personnes handicapées utiliser le climatiseur
sans surveillance.
• Il est nécessaire de surveiller les jeunes enfants pour qu’ils ne jouent pas avec le
climatiseur.
• Si le gaz réfrigérant fuit, arrêtez le fonctionnement du climatiseur, aérez convenablement
la pièce et contactez votre revendeur.
ATTENTION
• N’utilisez pas d’objet pointu pour enfoncer les boutons car cela risquerait d’endommager
la commande à distance.
•N’obstruez ou ne couvrez jamais les entrées ou les sorties des appareils extérieurs et
intérieurs.
Mise au rebut de l’appareil
Lorsque vous devez mettre l’appareil au rebut, consultez votre revendeur.
SVZ-KP12,18, 24, 30, 36NA
Specifications are subject to change without notice. 18
FRANÇAIS

2. Nomenclature
•Appareil intérieur
SVP-KP·NA
Modes du ventilateur 3 modes
Ailette -
Louvre -
Filtre Normal
Témoin de nettoyage du
filtre
-
•SVZ-KP·NA
Multi-positions

Porte


•Commande à distance (pièces en option)
Interface radiofréquence (RF) Commande à distance câblée
Thermostat RF
SVZ-KP12,18, 24, 30, 36NA
19 © 2018 Mitsubishi Electric US, Inc.
FRANÇAIS

3. Fonctionnement
• Concernant le mode de fonctionnement, reportez-vous au manuel d’utilisation fourni avec chaque
commande à distance.
3.1. Sélection du mode de fonctionnement
Les modes de refroidissement/asséchement/soufflerie/chauffage/automatique (refroidissement/chauffage)/
ventilation sont disponibles.
NOTE
• Le mode de chauffage et le mode automatique ne sont pas disponibles pour les
appareils de refroidissement uniquement.
• Mode de ventilation : uniquement indiqué dans les conditions suivantes.Utilisation de la
commande à distance câblée et raccordement d’un appareil LOSSNAY.
• Mode automatique
– En fonction de la température définie préalablement, l’opération de refroidissement
débutera si la température de la pièce est trop élevée ; à l’inverse, l’opération de
chauffage débutera si la température de la pièce est trop basse.
– En mode de fonctionnement automatique, le climatiseur passera en mode de
refroidissement si la température de la pièce change et affiche 4 °F [2 °C] ou plus au-
dessus de la température définie pendant 15 minutes. De la même façon, le
climatiseur passera en mode de chauffage si la température de la pièce affiche 4 °F [2
°C] ou plus au-dessous de la température définie pendant 15 minutes.
Mode de refroidissement 




-

SVZ-KP12,18, 24, 30, 36NA
Specifications are subject to change without notice. 20
FRANÇAIS
