Mitsubishi Electric FR-LU08 User manual

PRE-OPERATION INSTRUCTIONS 1
FUNCTION AND BASIC OPERATION 2
MENU 3
CHECK FIRST WHEN YOU HAVE
TROUBLE 4
SPECIFICATIONS 5
INSTRUCTION MANUAL
INVERTER
Option unit
FR-LU08
FR-LU08-01
LCD Operation Panel

2
Thank you for choosing this Mitsubishi Electric inverter option unit.
This Instruction Manual provides handling information and precautions for use of this product. Incorrect handling might cause an unexpected
fault. Before using this product, always read this Instruction Manual carefully to use this product correctly.
Please forward this Instruction Manual to the end user.
Electric shock prevention
Additional instructions
The following instructions must be also followed. If the product is handled incorrectly, it may cause unexpected fault, an injury, or an electric
shock.
Safety instructions
Do not attempt to install, operate, maintain or inspect the product until you have read through this Instruction Manual and supplementary
documents carefully and can use the equipment correctly. Do not use this product until you have a full knowledge of this product mechanism,
safety information and instructions. In this Instruction Manual, the safety instruction levels are classified into "Warning" and "Caution".
Incorrect handling may cause hazardous conditions, resulting in death or severe injury.
Incorrect handling may cause hazardous conditions, resulting in medium or slight injury, or may cause only material
damage.
The level may even lead to a serious consequence according to conditions. Both instruction levels must be followed
because these are important to personal safety.
Warning
Do not remove the front cover or the wiring cover of the inverter while the inverter power is ON. Do not operate the inverter with any cover or wiring cover removed,
as accidental contact with exposed high-voltage terminals and internal components may occur, resulting in an electrical shock.
Do not remove the inverter front cover even if the power supply is disconnected. The only exception for this would be when performing wiring and periodic
inspection. You may accidentally touch the charged inverter circuits and get an electric shock.
Before wiring or inspection, LED indication of the inverter unit operation panel must be switched OFF. Any person who is involved in wiring or inspection shall wait
for at least 10 minutes after the power supply has been switched OFF and check that there is no residual voltage using a tester or the like. For some time after the
power-OFF, a high voltage remains in the smoothing capacitor, and it is dangerous.
Any person who is involved in wiring or inspection of this product shall be fully competent to do the work.
Do not touch the operation panel or handle the cables with wet hands. Otherwise you may get an electric shock.
Do not subject the cables to scratches, excessive stress, heavy loads or pinching. Otherwise you may get an electric shock.
Caution
Transportation and mounting
Do not install or operate the operation panel if it is damaged or has parts missing.
Do not stand or rest heavy objects on the product.
Warning
Caution
Caution

3
Caution
Transportation and mounting
The mounting orientation must be correct.
The surrounding air temperature must be between -10 to +50°C (non-freezing). Otherwise the inverter may be damaged.
The surrounding humidity must be 90% RH or less (non-condensing) for the FR-LU08, and 95% RH or less (non-condensing) for the FR-LU08-01. Otherwise the
inverter may be damaged.
The storage temperature (applicable for a short time, such as during transit) must be between -20 to +65°C. Otherwise the inverter may be damaged.
The inverter must be used indoors (without corrosive gas, flammable gas, oil mist, dust and dirt etc.) Otherwise the inverter may be damaged.
Do not use this product at an altitude above 2500 m. Vibration should not exceed 2.9 m/s2at 10 to 55 Hz in X, Y, and Z directions. Otherwise the inverter may be
damaged.
If halogens (including fluorine, chlorine, bromine, and iodine) contained in fumigants for wood packages enter this product, the product may be damaged. Prevent
the entry of fumigant residuals or use an alternative method such as heat disinfection. Note that sterilization of disinfection of wood packages should be performed
before packing the product.
Trial run
Before starting operation, each parameter must be confirmed and adjusted. A failure to do so may cause some machines to make unexpected motions.
Warning
Usage
Since pressing the STOP/RESET key of the operation panel may not stop output depending on the function setting status, separate circuit and switch that make an
emergency stop (power OFF, mechanical brake operation for emergency stop, etc.) must be provided.
OFF status of the start signal must be confirmed before resetting an inverter fault. Resetting an inverter fault with the start signal ON restarts the motor suddenly.
Do not modify the equipment.
Do not perform parts removal which is not instructed in this manual. Doing so may lead to fault or damage of the product.
Caution
Usage
When parameter clear or all parameter clear is performed, the required parameters must be set again before starting operations because all parameters return to
the initial value.
Static electricity in your body must be discharged before you touch the product.
Disposal
The product must be treated as industrial waste.
General instruction
Many of the diagrams and drawings in this Instruction Manual show the inverter without a cover or partially open for explanation. Never operate the inverter in this
manner. The cover must be reinstalled and the instructions in the Instruction Manual must be followed when operating the inverter.

4
 IPX5 refers to protection of the operation panel functions against water jets from any direction when about 12.5-liter water is injected from a nozzle with an inside
diameter of 6.3 mm from the distance of about 3 m for at least 3 minutes.
 IP5X refers to protection of the operation panel functions and maintenance of safety when the inverter is put into a stirring device containing dust of 75 m or
smaller in diameter, stirred for 8 hours, and then removed from the device.
 Water here refers to fresh water at room temperature (5 to 35°C).
 Indoor here refers to the environments that are not affected by climate conditions.
Caution
Waterproof and dustproof performances of FR-LU08-01
When securely fixed to the inverter with screws, the operation panel (FR-LU08-01) is rated IPX5 waterproof rating and IP5X dustproof rating.
The items enclosed with the FR-LU08-01 such as the Instruction Manual are not rated with the IPX5 waterproof or IP5X dustproof ratings.
Although the FR-LU08-01 (except for the connector) is rated with the IPX5 waterproof and IP5X dustproof ratings, it is not intended for use in water.
Also, the ratings do not guarantee protection of the FR-LU08-01 from needless submersion in water or being washed under strong running water such as a shower.
Do not pour or apply the following liquids over the FR-LU08-01: water containing soap, detergent, or bath additives; sea water; swimming pool water; warm water;
boiling water; etc.
The FR-LU08-01 is intended for indoor installation and not for outdoor installation. Avoid places where the FR-LU08-01 is subjected to direct sunlight, rain, sleet,
snow, or freezing temperatures.
If the screws of the FR-LU08-01 are not tightened, or if the FR-LU08-01 is damaged or deformed, the IPX5 waterproof performance and the IP5X dustproof
performance are impaired. If any abnormalities are found on the FR-LU08-01, ask for an inspection and repair.
To maintain the waterproof and dustproof performances of the FR-LU08-01, daily and periodic inspections are recommended regardless of the presence or
absence of abnormalities.

5
─CONTENTS ─
1 PRE-OPERATION INSTRUCTIONS 7
1.1 Unpacking and checking the product............................................................................................................................7
1.1.1 SERIAL number check.......................................................................................................................................................... 7
1.2 Major differences between the FR-LU08 and FR-LU08-01 ...........................................................................................9
1.3 Appearance and parts name.........................................................................................................................................10
1.4 Installation and removal................................................................................................................................................12
1.4.1 Installing the operation panel on the inverter ...................................................................................................................... 12
1.4.2 Connecting the operation panel using a connection cable (FR-CB2) ................................................................................. 14
1.4.3 Installation of a backup battery ........................................................................................................................................... 15
1.5 Initial setting...................................................................................................................................................................16
1.5.1 Language selection............................................................................................................................................................. 16
1.5.2 PU buzzer control (Pr.990) ................................................................................................................................................. 16
1.5.3 PU contrast adjustment (Pr.991)......................................................................................................................................... 16
2 FUNCTION AND BASIC OPERATION 17
2.1 Monitor function ............................................................................................................................................................17
2.1.1 Outline of the Main monitor indicator .................................................................................................................................. 17
2.1.2 Using the real time clock function ....................................................................................................................................... 20
2.1.3 Switching between the Main monitor screen and the Menu screens.................................................................................. 20
2.1.4 Changing the Main monitor screen ..................................................................................................................................... 21
2.1.5 Changing the main monitor item from the Function menu .................................................................................................. 22
2.1.6 Changing the main monitor item by parameter................................................................................................................... 22
2.1.7 Setting of the monitor data screen at power-ON (first priority monitor)............................................................................... 22
2.2 Frequency setting..........................................................................................................................................................23
2.3 Direct setting..................................................................................................................................................................24
2.4 Fault history indicator ...................................................................................................................................................25
2.5 Setting and changing the parameter values ...............................................................................................................26
2.5.1 Specifying the parameter number to change the set value................................................................................................. 26
2.5.2 Selecting the parameter from the Function group menu to change the set value............................................................... 27
2.5.3 Selecting the parameter from Function menu to change the set value............................................................................... 28

6
2.5.4 Precautions for writing the set value ................................................................................................................................... 29
2.5.5 Displaying parameter descriptions (parameter information) ............................................................................................... 29
3MENU 30
3.1 Quick menu ....................................................................................................................................................................30
3.1.1 Easy setup wizard............................................................................................................................................................... 30
3.1.2 Parameter list by application............................................................................................................................................... 31
3.1.3 Simple setup list.................................................................................................................................................................. 32
3.2 Function menu ...............................................................................................................................................................33
3.2.1 Parameter clear .................................................................................................................................................................. 34
3.2.2 Inverter reset....................................................................................................................................................................... 34
3.2.3 Terminal assignment........................................................................................................................................................... 34
3.2.4 Parameter copy................................................................................................................................................................... 35
3.2.5 Option installation monitor .................................................................................................................................................. 37
3.2.6 USB memory....................................................................................................................................................................... 38
4 CHECK FIRST WHEN YOU HAVE TROUBLE 45
4.1 Troubleshooting ............................................................................................................................................................45
5 SPECIFICATIONS 46
5.1 Standard specifications ................................................................................................................................................46
5.2 Outline and enclosure cut dimensions........................................................................................................................47
Appendix 48
Appendix 1 Disposing of equipment in EU countries .......................................................................................................48
Appendix 2 Restricted Use of Hazardous Substances in Electronic and Electrical Products......................................49

PRE-OPERATION INSTRUCTIONS 7
1
1PRE-OPERATION INSTRUCTIONS
1.1 Unpacking and checking the product
Take the operation panel out of the package, and confirm that the product is as you ordered and intact.
The FR-LU08(-01) is compatible with the 800 series inverters.
1.1.1 SERIAL number check
Check the serial number of the inverter to see if the functions below are supported.
Function Model Country-of-origin indication SERIAL number
Easy setup wizard
Parameter list by application
(refer to page 30)
Direct setting
(refer to page 24)
FR-A820-00046(0.4K) to 04750(90K)
FR-A840-00023(0.4K) to 06830(280K)
FR-A842-07700(315K) to 12120(500K)
FR-A846-00023(0.4K) to 03610(132K)
MADE in Japan 55 or later
MADE in China 56 or later
FR-F820-00046(0.75K) to 04750(110K)
FR-F840-00023(0.75K) to 06830(315K)
FR-F842-07700(355K) to 12120(560K)
MADE in Japan 54 or later
MADE in China 55 or later
Parameter information
(refer to page 29)
FR-A820-00046(0.4K) to 04750(90K)
FR-A840-00023(0.4K) to 06830(280K)
FR-A842-07700(315K) to 12120(500K)
FR-A846-00023(0.4K) to 03610(132K)
MADE in Japan 75 or later
MADE in China 74 or later
FR-F820-00046(0.75K) to 04750(110K)
FR-F840-00023(0.75K) to 06830(315K)
FR-F842-07700(355K) to 12120(560K)
MADE in Japan 75 or later
MADE in China 74 or later

8PRE-OPERATION INSTRUCTIONS
Rating plate example
   
Symbol Year Month Control number
SERIAL
The SERIAL consists of one symbol, two characters indicating the
production year and month, and six characters indicating the
control number.
The last digit of the production year is indicated as the Year, and
the Month is indicated by 1 to 9, X (October), Y (November), or Z
(December).
,1387;;;;;
02'(/)5$
287387;;;;;
6(5,$/;;;;;;;;;
0$'(,1;;;;;
SERIAL
number
Country
of origin

PRE-OPERATION INSTRUCTIONS 9
1
1.2 Major differences between the FR-LU08 and FR-LU08-01
Item FR-LU08 FR-LU08-01
Applicable model Standard model / Separated converter type IP55 compatible model
Protective structure IP40 (except for the PU connector) IP55 (except for the PU connector)
Outline dimension (WHD [mm]) 7278.517 809619
Number of fixing screws 2 4
Operation mode indicator PU/EXT HAND/AUTO
Operation key
PU/EXT key HAND/AUTO key
Installation on the enclosure Available Not available

10 PRE-OPERATION INSTRUCTIONS
1.3 Appearance and parts name
Symbol Name Description
a Power lamp ON when the power is turned ON.
b Alarm lamp ON when an inverter alarm occurs.
c Monitor Shows the frequency, parameter number, etc.
(Using Pr.52, Pr.774 to Pr.776, the monitor item can be changed.)
d FWD key, REV key FWD key: Starts the forward operation.
REV key: Starts the reverse operation.
e STOP/RESET key Stop operation commands.
Reset the inverter when the protective function is activated.
f Setting dial
Used to change the frequency and parameter settings.
Press the setting dial while the fault history is displayed to display the details of the fault.
Displays a description of the parameter when the setting dial is held down in the screen for
setting parameter values.
(a)
Front view Rear view
(m)
(d)
(f)
(b)
(i)
(h)
(c)
(e)
(g)
(j) (k) (l)
(p)
(n)
(o)
*1 In the FR-LU08-01, this appears as
*1

PRE-OPERATION INSTRUCTIONS 11
1
NOTE
• Do not operate the keys with sharp tools.
• Do not press the LCD part.
• Do not peel off the waterproof seal affixed to the FR-LU08-01. If the seal is peeled off, the FR-LU08-01 does not
conform to IP55.
g
FR-LU08 PU/EXT key Switches the operation mode between PU, PUJOG, and External.
FR-LU08-01 HAND/AUTO key Switches the operation mode between HAND (PU), HANDJOG (PUJOG), and AUTO
(External).
h MON key Displays the first priority monitor.
i MENU key Displays the Quick menu.
Displays the Function menu when the key is pressed while the Quick menu is displayed.
j Software key (F1)
Select an operation displayed on the monitor.k Software key (F2)
l Software key (F3)
m Connector Connector to the inverter. Connect this connector to the PU connector of the inverter.
n For manufacturer setting. Do not use. Do not peel off the waterproof seal affixed to the FR-LU08-01.
o Battery cover Remove the battery cover when replacing the backup battery for the real time clock function.
p Rating plate -
Symbol Name Description

12 PRE-OPERATION INSTRUCTIONS
1.4 Installation and removal
For safety, turn OFF the inverter when installing or removing the operation panel.
1.4.1 Installing the operation panel on the inverter
• Installation
(1) Remove the operation panel (FR-DU08(-01)) from the inverter. (For the removal of the operation panel, refer to the
Instruction Manual of the inverter.)
(2) Align the connector of the FR-LU08(-01) with the PU connector of the inverter, and insert the operation panel. After
confirming that the operation panel is fit securely, tighten the screws. For the FR-LU08-01, tighten the screws in a diagonal
order. (Tightening torque: 0.40 to 0.45 Nm for the FR-LU08, 0.39 to 0.49 Nm for the FR-LU08-01)
FR-LU08FR-LU08 FR-LU08-01FR-LU08-01
FastenFasten FastenFasten

PRE-OPERATION INSTRUCTIONS 13
1
• Removal
(1) Loosen the screws on the FR-LU08(-01). (These screws cannot be removed.)
(2) Push the upper part of the FR-LU08(-01), and pull out the operation panel to remove.
FR-LU08FR-LU08 FR-LU08-01FR-LU08-01
LoosenLoosen
LoosenLoosen

14 PRE-OPERATION INSTRUCTIONS
1.4.2 Connecting the operation panel using a connection cable (FR-CB2)
• Installation
To connect the FR-LU08(-01), an optional operation panel connection connector (FR-ADP) is required.
(1) Remove the operation panel (FR-DU08(-01)) from the inverter. (For the removal of the operation panel, refer to the
Instruction Manual of the inverter.)
(2) Securely insert one end of the connection cable into the PU connector of the inverter and the other end into the connection
connector of the FR-LU08(-01) along the guides until the stoppers are fixed.
• Removal
Hold down the clip at the cable end and gently pull the connector.
NOTE
• The IP55 compatible inverter model does not conform to IP55 when the FR-LU08-01 is removed.
Parameter unit connection cable
(FR-CB2[ ]) (option)
Operation panel (FR-LU08(-01))
Operation panel connection connector
(FR-ADP) (option)

PRE-OPERATION INSTRUCTIONS 15
1
1.4.3 Installation of a backup battery
With a battery (CR1216), time counting of the FR-LU08(-01) continues even when the main power of the inverter is turned OFF
(real time clock function). For the details of the real time clock function, refer to page 20.
1
Loosen the screw on the
battery cover, which is
located on the back side
of the FR-LU08(-01).
NOTE
• Do not replace the battery of the FR-LU08(-01)
while power is ON.
• Do not use batteries that have been dropped or
otherwise received an impact. Battery leakage
may occur. Discard the batteries.
2
Insert a flathead
screwdriver to the slot,
and lift the cover to
open.
3
Place the battery as shown
in the right figure.
4Close the battery cover, and tighten the screw.
(Tightening torque: 0.1 to 0.3 N·m)
+
-

16 PRE-OPERATION INSTRUCTIONS
1.5 Initial setting
1.5.1 Language selection
At first power ON, the Language selection screen appears after the
corporation logo of MITSUBISHI ELECTRIC.
Turn to select the language, and push to set.
The interface language can be changed from the Quick menu.
(Refer to page 30.)
1.5.2 PU buzzer control (Pr.990)
With Pr.990 PU buzzer control, the beeping sound of the operation panel can be enabled or disabled.
1.5.3 PU contrast adjustment (Pr.991)
With Pr.991 PU contrast adjustment, the contrast of the monitor display of the operation panel can be adjusted.
NOTE
• For how to set parameters, refer to page 26.
Pr.990 setting Description
0 Without beeping sound
1 (initial value) With beeping sound
Pr.991 setting Description
0 to 63
PREV SET NEXT
Language
▼
--- STOP PU
Japanese
English
German
French
Spanish
Russian
Italian
Turkish
Polish
Chinese
Korean
Swedish
Portuguese
Display Language
PleaseSelectLanguage
English
日本語
(SET)
[0] [63]
Light Dark
[58]
Initial value

FUNCTION AND BASIC OPERATION 17
2
2FUNCTION AND BASIC OPERATION
2.1 Monitor function
2.1.1 Outline of the Main monitor indicator
Symbol Name Description
a Main monitor item/data
Displays the output frequency, output current, output voltage, fault history, and others.
The Main monitor screen can be changed by the following methods.
• Changing the Main monitor screen using or (Refer to page 21.)
• Changing the main monitor item using the Function menu (Refer to page 22.)
• Changing the main monitor item using Pr.52 Operation panel main monitor selection (Refer to
page 22.)
b Rotation direction Displays the direction of the start command ([STF]: forward, [STR]: reverse).
([---] shows that no start command is input, or that both forward and reverse directions are ON.)
PREV SET NEXT
STF STOP PU
Hz
0. 00
Output frequency
TUNE USB- A P. RUN
12: 34
OL
▼
▲
(a)
(b)
(c)
(e)
(f)
(d)
(h)
(g)
(i)
(j)
(k)
(k)
(l)
(PREV)
(NEXT)

18 FUNCTION AND BASIC OPERATION
c Operating status
Displays the operating status of the inverter.
[STOP]: During stop
[FWD]: During forward rotation
[REV]: During reverse rotation
[JOGf]: During JOG forward rotation
[JOGr]: During JOG reverse rotation
[ALARM]: At fault occurrence
d Clock Displays time. With a battery installed, the clock keeps working even if the inverter power is turned
OFF. (Refer to page 20.)
e Tuning status
Displays the offline auto tuning status of the inverter.
[TUNE]: During turning or tuning completed
[TUNE] highlighted and flashing: Tuning error
fUSB connection/password
locked
Displays the connection status of the USB A connector of the inverter and password function
setting status.
[USB-A]: USB connection recognized
[USB-A] highlighted: USB ready
[USB-A] flashing: During USB operation
[LOCK]: Password locked
gPLC function/JOG
operation
Displays the status of the PLC function and JOG operation.
[P.RUN]: During stop with the PLC function enabled
[P.RUN] highlighted: During PLC function operation
[P.RUN] highlighted and flashing: Operation error in the PLC function
[JOG]: JOG operation enabled
h Warning Displays an inverter warning.
i Unit Shows the unit of the value on the main monitor.
Symbol Name Description

FUNCTION AND BASIC OPERATION 19
2
 For the FR-LU08-01, AUTO will be displayed instead of EXT, and HAND will be displayed instead of PU in the description of the operation
mode indicator.
j Operation mode 
Displays the operation mode.
[EXT]: External operation mode
[PU]: PU operation mode
[EXTj]: External JOG operation mode
[PUj]: PUJOG operation mode
[NET]: Network operation mode
[PU+E]: External/PU combined operation mode
k Software key Displays operations performed by pressing the F1 (left), F2 (center), or F3 (right) key.
lScroll Displayed when any data can be scrolled by turning .
Operation mode indicator
FR-LU08 FR-LU08-01
Indication of EXT/PU Indication of AUTO/HAND
Symbol Name Description
PREV SET NEXT
--- STOP PU
Hz
12: 34
0.00
PREV SET NEXT
--- STOP XT
Hz
12: 34
0.00
E
Output frequency Output frequency
PREV SET NEXT
--- STOP
Hz
12: 34
0.00
PREV SET NEXT
--- STOP AUTO
Hz
12: 34
0.00
HAND
Output frequency Output frequency

20 FUNCTION AND BASIC OPERATION
2.1.2 Using the real time clock function
With a battery (CR1216), time counting of the FR-LU08(-01) continues even when the main power of the inverter is turned OFF
(real time clock function). For how to install the backup battery, refer to page 15.
• When the battery is installed in the FR-LU08(-01), its time is written to the inverter at power-ON (except the first power-ON
after the battery is installed).
• When the battery is not installed, the FR-LU08(-01) reads the time from the inverter and starts time counting.
2.1.3 Switching between the Main monitor screen and the Menu screens
Pressing or switches the monitor display between the Main monitor screen and the Menu screens.
PREV SET NEXT
STOP PU
Hz
Output frequency
12: 34
PREV SET NEXT
Easy setup wizard
Pr. list for App.
Simple Pr. list
SET SETPr SET
STOP PU
Quick menu
PREV SET NEXT
Function menu
Monitor selection
Parameter list
Parameter clear
▼
0.00
LIST
STOP PU
SET
Main monitor Quick menu Function menu
Turn ON the power,
or press .
