Mitsubishi Electric GOT SIMPLE GS2110-WTBD User manual

GRAPHIC OPERATION TERMINAL
User's Manual
GOT SIMPLE Series

A - 1
SAFETY PRECAUTIONS
(Always read these precautions before using this equipment.)
Before using this product, please read this manual and the relevant manuals introduced in this manual
carefully and pay full attention to safety to handle the product correctly.
The precautions given in this manual are concerned with this product.
In this manual, the safety precautions are ranked as "WARNING" and "CAUTION".
Note that the caution level may lead to a serious accident according to the circumstances.
Always follow the instructions of both levels because they are important to personal safety.
Please save this manual to make it accessible when required and always forward it to the end user.
[DESIGN PRECAUTIONS]
WARNING
● Some failures of the GOT or cable may keep the outputs on or off. Some failures of a touch panel
may cause malfunction of the input objects such as a touch switch. An external monitoring circuit
should be provided to check for output signals which may lead to a serious accident. Not doing so
can cause an accident due to false output or malfunction.
● Do not use the GOT as the warning device that may cause a serious accident. An independent and
redundant hardware or mechanical interlock is required to configure the device that displays and
outputs serious warning. Not doing so can cause an accident due to false output or malfunction.
● When the GOT detects its backlight failure, the GOT disables the input operation on the touch
switch(s). Thus, operators cannot operate the GOT with touches. The GOT backlight failure can be
checked with a system signal of the GOT.
● Even when the display section has dimmed due to a failure of the liquid crystal section or the
backlight on the GOT, the input operation of the touch switches may still be enabled. This may cause
an incorrect operation of the touch switches. For example, if an operator assumes that the display
section has dimmed because of the screen save function and touches the display section to cancel
the screen save, a touch switch may be activated.
WARNING Indicates that incorrect handling may cause hazardous
conditions, resulting in death or severe injury.
CAUTION
Indicates that incorrect handling may cause hazardous
conditions, resulting in medium or slight personal injury or
physical damage.

A - 2
[DESIGN PRECAUTIONS]
[MOUNTING PRECAUTIONS]
WARNING
● The display section of the GOT is an analog-resistive type touch panel. Simultaneous pressing of
two or more areas on the display section may activate the switch between those areas. Do not press
two or more areas simultaneously on the display section. Doing so may cause an accident due to
incorrect output or malfunction.
● When programs or parameters of the controller (such as a PLC) that is monitored by the GOT are
changed, be sure to shut off the power of the GOT promptly and power on the GOT again. Not doing
so can cause an accident due to false output or malfunction.
● If a communication fault (including cable disconnection) occurs during monitoring on the GOT,
communication between the GOT and PLC CPU is suspended and the GOT becomes inoperative. A
system where the GOT is used should be configured to perform any significant operation to the
system by using the switches of a device other than the GOT on the assumption that a GOT
communication fault will occur. Not doing so can cause an accident due to false output or
malfunction.
CAUTION
● Do not bundle the control and communication cables with main-circuit, power or other wiring. Run
the above cables separately from such wiring and keep them a minimum of 100mm apart. Not doing
so noise can cause a malfunction.
● Do not press the GOT display section with a pointed material as a pen or driver. Doing so can result
in a damage or failure of the display section.
● When the GOT is connected to the Ethernet network, the available IP address is restricted according
to the system configuration.
• When multiple GOTs are connected to the Ethernet network:
Do not set the IP address (192.168.3.18) for the GOTs and the controllers in the network.
• When a single GOT is connected to the Ethernet network:
Do not set the IP address (192.168.3.18) for the controllers except the GOT in the network.
Doing so can cause the IP address duplication. The duplication can negatively affect the communication of the
device with the IP address (192.168.3.18). The operation at the IP address duplication depends on the devices
and the system.
● Turn on the controllers and the network devices to be ready for communication before they
communicate with the GOT. Failure to do so can cause a communication error on the GOT.
● When the GOT is subject to shock or vibration, or some colors appear on the screen of the GOT, the
screen of the GOT might flicker.
WARNING
● Be sure to shut off all phases of the external power supply used by the system before mounting or
removing the GOT main unit to/from the panel. Not doing so can cause the unit to fail or malfunction.

A - 3
[MOUNTING PRECAUTIONS]
[WIRING PRECAUTIONS]
CAUTION
● Use the GOT in the environment that satisfies the general specifications described in this manual.
Not doing so can cause an electric shock, fire, malfunction or product damage or deterioration.
● When mounting the GOT to the control panel, tighten the mounting screws in the specified torque
range (0.36N·m to 0.48N·m) with a Phillips-head screwdriver No.2. Undertightening can cause the
GOT to drop, short circuit or malfunction. Overtightening can cause a drop, short circuit or
malfunction due to the damage of the screws or the GOT.
● Remove the protective film of the GOT. When the user continues using the GOT with the protective
film, the film may not be removed.
● Operate and store the GOT in environments without direct sunlight, high temperature, dust, humidity,
and vibrations.
● Do not use the GOT in an environment with oil or chemicals. Doing so may cause failure or
malfunction due to the oil or chemical entering into the GOT.
WARNING
● Be sure to shut off all phases of the external power supply used by the system before wiring. Failure
to do so may result in an electric shock, product damage or malfunctions.
CAUTION
● Please make sure to ground FG terminal of the GOT power supply section by applying 100Ω or less
which is used exclusively for the GOT. Not doing so may cause an electric shock or malfunction.
● Correctly wire the GOT power supply section after confirming the rated voltage and terminal
arrangement of the product. Not doing so can cause a fire or failure.
● Tighten the terminal screws of the GOT power supply section in the specified torque range (0.5N·m
to 0.6N·m). Undertightening can cause a short circuit or malfunction. Overtightening can cause a
short circuit or malfunction due to the damage of the screws or the GOT.
● Exercise care to avoid foreign matter such as chips and wire offcuts entering the GOT. Not doing so
can cause a fire, failure or malfunction.
● Plug the communication cable into the GOT interface or the connector of the connected unit, and
tighten the mounting screws and the terminal screws in the specified torque range. Undertightening
can cause a short circuit or malfunction. Overtightening can cause a short circuit or malfunction due
to the damage of the screws or unit.

A - 4
[TEST OPERATION PRECAUTIONS]
[STARTUP/MAINTENANCE PRECAUTIONS]
WARNING
● Before performing the test operations of the user creation monitor screen (such as turning ON or
OFF bit device, changing the word device current value, changing the settings or current values of
the timer or counter, and changing the buffer memory current value), read through the manual
carefully and make yourself familiar with the operation method. During test operation, never change
the data of the devices which are used to perform significant operation for the system. False output
or malfunction can cause an accident.
WARNING
● When power is on, do not touch the terminals. Doing so can cause an electric shock or malfunction.
● Before starting cleaning or terminal screw retightening, always switch off the power externally in all
phases.
Not doing so can cause the unit to fail or malfunction.
Undertightening can cause a short circuit or malfunction.
Overtightening can cause a short circuit or malfunction due to the damage of the screws or unit.
CAUTION
● Do not disassemble or modify the unit. Doing so can cause a failure, malfunction, injury or fire.
● Do not touch the conductive and electronic parts of the unit directly. Doing so can cause a unit
malfunction or failure.
● The cables connected to the unit must be run in ducts or clamped. Not doing so can cause the unit or
cable to be damaged due to the dangling, motion or accidental pulling of the cables or can cause a
malfunction due to a cable connection fault.
● When unplugging the cable connected to the unit, do not hold and pull from the cable portion. Doing
so can cause the unit or cable to be damaged or can cause a malfunction due to a cable connection
fault.
● Do not drop the module or subject it to strong shock. A module damage may result.
● Before touching the unit, always touch grounded metals, etc. to discharge static electricity from
human body, etc. Not doing so can cause the unit to fail or malfunction.

A - 5
[TOUCH PANEL PRECAUTIONS]
[PRECAUTIONS WHEN THE DATA STORAGE IS IN USE]
[PRECAUTIONS WHEN THE DATA STORAGE IS IN USE]
[DISPOSAL PRECAUTIONS]
CAUTION
● For the analog-resistive film type touch panels, normally the adjustment is not required.
However, the difference between a touched position and the object position may occur as the period
of use elapses. When any difference between a touched position and the object position occurs,
execute the touch panel calibration.
● When any difference between a touched position and the object position occurs, other object may be
activated. This may cause an unexpected operation due to incorrect output or malfunction.
WARNING
● If the SD card mounted on drive A of the GOT is removed while the GOT is accessed, processing for
the GOT might be interrupted about for 20 seconds. The GOT cannot be operated during this period.
The functions that run in the background including a screen updating, alarm, logging, scripts, and
others are also interrupted. Since this interruption makes an impact to the system operation, it might
cause failure. After inhibiting access to the SD card on the GOT utility screen, check that the SD card
access LED is off and remove the SD card.
CAUTION
● If the data storage mounted on the GOT is removed while the GOT is accessed, the data storage
and files are damaged. To remove the data storage from the GOT, check that the access to the data
storage in SD card access LED, the system signal, and others is not performed.
● When removing the SD card from the GOT, make sure to support the SD card by hand as it may pop
out. Failure to do so may cause the SD card to drop from the GOT, resulting in a failure or break.
● Before removing the USB device from the GOT, follow the procedure for removal on the utility screen
of the GOT. After the successful completion dialog is displayed, remove the USB device by hand
carefully. Failure to do so may cause the USB device to drop from the GOT, resulting in a failure or
break.
CAUTION
● When disposing of this product, treat it as industrial waste.

A - 6
[TRANSPORTATION PRECAUTIONS]
CAUTION
● Make sure to transport the GOT main unit and/or relevant unit(s) in the manner they will not be
exposed to the impact exceeding the impact resistance described in the general specifications of this
manual, as they are precision devices. Failure to do so may cause the unit to fail. Check if the unit
operates correctly after transportation.
● When fumigants that contain halogen materials such as fluorine, chlorine, bromine, and iodine are
used for disinfecting and protecting wooden packaging from insects, they cause malfunction when
entering our products. Please take necessary precautions to ensure that remaining materials from
fumigant do not enter our products, or treat packaging with methods other than fumigation (heat
method). Additionally, disinfect and protect wood from insects before packing products.

A - 7
SAFETY PRECAUTIONS .........................................................................................................................A - 1
INTRODUCTION ......................................................................................................................................A - 7
CONTENTS ..............................................................................................................................................A - 7
About Manual..........................................................................................................................................A - 13
Quick Reference .....................................................................................................................................A - 14
Abbreviations and Generic Terms ..........................................................................................................A - 15
1. OVERVIEW
1.1 Features........................................................................................................................................... 1 - 2
1.1.1 Rough procedure.................................................................................................................. 1 - 3
2. SYSTEM CONFIGURATION
2.1 Overall Configuration ....................................................................................................................... 2 - 1
2.2 Component List................................................................................................................................ 2 - 1
2.2.1 GOT ...................................................................................................................................... 2 - 2
2.2.2 Option ................................................................................................................................... 2 - 2
3. SPECIFICATIONS
3.1 General Specifications..................................................................................................................... 3 - 1
3.2 Performance Specifications ............................................................................................................. 3 - 2
3.3 Power Supply Specifications ........................................................................................................... 3 - 3
3.4 GOT Connector Specifications ........................................................................................................ 3 - 4
3.4.1 RS-232 interface................................................................................................................... 3 - 4
3.4.2 RS-422 interface................................................................................................................... 3 - 4
4. PART NAME
4.1 Front Panel ...................................................................................................................................... 4 - 1
4.2 Back Panel....................................................................................................................................... 4 - 2
4.3 Bottom ............................................................................................................................................. 4 - 3
5. EMC DIRECTIVE
5.1 Overview.......................................................................................................................................... 5 - 1
5.1.1 Conforming standards in the EMC Directive ........................................................................ 5 - 1
5.2 EMC Directive Requirements .......................................................................................................... 5 - 2
5.2.1 Installing the GOT on the control panel ................................................................................ 5 - 2
5.2.2 Installing a noise filter (power supply line filter) .................................................................... 5 - 3
5.2.3 System configuration ............................................................................................................ 5 - 4
5.2.4 Connection of power cables and ground cables................................................................... 5 - 4
5.2.5 Fabricating a connection cable ............................................................................................. 5 - 5
INTRODUCTION
Thank you for choosing Mitsubishi Graphic Operation Terminal (Mitsubishi GOT).
Read this manual and make sure you understand the functions and performance of the GOT thoroughly in
advance to ensure correct use.
CONTENTS

A - 8
5.2.6 Grounding a cable ................................................................................................................ 5 - 7
6. INSTALLATION
6.1 Control Panel Inside Dimensions for Mounting GOT ....................................................................... 6 - 1
6.2 Panel Cutting Dimensions ............................................................................................................... 6 - 2
6.3 Mounting Position ............................................................................................................................ 6 - 2
6.4 Control Panel Temperature and Mounting Angle ............................................................................ 6 - 3
6.5 Installation Procedure ...................................................................................................................... 6 - 4
7. WIRING
7.1 Power Supply Wiring ....................................................................................................................... 7 - 2
7.1.1 Cable types and wire end processing................................................................................... 7 - 2
7.1.2 Wiring example ..................................................................................................................... 7 - 3
7.1.3 GOT's ground ....................................................................................................................... 7 - 3
7.1.4 The cause of malfunctions related wiring/Remedy ............................................................... 7 - 4
7.2 Wiring Inside and Outside the Panel ............................................................................................... 7 - 6
7.2.1 Wiring inside ......................................................................................................................... 7 - 6
7.2.2 Outside the panel.................................................................................................................. 7 - 6
7.2.3 Attaching surge killers to control equipment ......................................................................... 7 - 7
8. OPTION
8.1 SD Card ........................................................................................................................................... 8 - 1
8.1.1 Applicable SD card ............................................................................................................... 8 - 1
8.1.2 Installation/removal procedure of SD card............................................................................ 8 - 1
9. UTILITY FUNCTION
9.1 Utility Execution ............................................................................................................................... 9 - 1
9.2 Utility Function List........................................................................................................................... 9 - 2
9.3 Utility Display ................................................................................................................................... 9 - 3
9.3.1 Display operation of main menu ........................................................................................... 9 - 5
9.3.2 Utility basic configuration ...................................................................................................... 9 - 7
9.3.3 Basic operation of settings change....................................................................................... 9 - 8
10. LANGUAGE SETTING (LANGUAGE)
10.1 Display language setting................................................................................................................ 10 - 1
10.1.1 Display language setting function ....................................................................................... 10 - 1
10.1.2 Language setting operation ................................................................................................ 10 - 1
11. COMMUNICATION INTERFACE SETTING (COMMUNICATION SETTING)
11.1 Standard I/F Setting....................................................................................................................... 11 - 1
11.1.1 Standard I/F functions......................................................................................................... 11 - 1
11.1.2 Standard I/F display operation............................................................................................ 11 - 1
11.1.3 Display contents of standard I/F .........................................................................................11 - 2
11.1.4 Detail information setting operation .................................................................................... 11 - 4
11.1.5 Channel setting operation................................................................................................... 11 - 7
11.1.6 Driver setting operation....................................................................................................... 11 - 8
11.2 GOT IP Address Setting ................................................................................................................ 11 - 9
11.2.1 Standard ............................................................................................................................. 11 - 9

A - 9
11.2.2 Display operation of GOT IP address ................................................................................. 11 - 9
11.2.3 Setting operation .............................................................................................................. 11 - 10
11.3 Ethernet Communication ............................................................................................................. 11 - 11
11.3.1 Setting function for Ethernet communication.................................................................... 11 - 11
11.3.2 Display operation of Ethernet communication .................................................................. 11 - 11
11.3.3 Display contents of Ethernet setting ................................................................................. 11 - 12
11.4 Communication Monitor............................................................................................................... 11 - 15
11.4.1 Communication monitor functions .................................................................................... 11 - 15
11.4.2 Communication monitor display operation ....................................................................... 11 - 15
11.4.3 Screen display content ..................................................................................................... 11 - 16
11.5 Ethernet Check ............................................................................................................................ 11 - 18
11.6 Setting the Transparent Mode ..................................................................................................... 11 - 20
11.7 Keyword....................................................................................................................................... 11 - 21
11.7.1 Keyword functions ............................................................................................................ 11 - 21
11.7.2 Keyword display operation ............................................................................................... 11 - 21
11.7.3 Regist ............................................................................................................................... 11 - 22
11.7.4 Delete ............................................................................................................................... 11 - 25
11.7.5 Clear ................................................................................................................................. 11 - 27
11.7.6 Protect .............................................................................................................................. 11 - 29
12. DISPLAY AND OPERATION SETTINGS (GOT SET UP)
12.1 Display Settings ............................................................................................................................. 12 - 1
12.1.1 Display setting functions..................................................................................................... 12 - 1
12.1.2 Display operation of display setting .................................................................................... 12 - 2
12.1.3 Display setting operations .................................................................................................. 12 - 3
12.2 Operation Setting (Settings for Operation) .................................................................................... 12 - 5
12.2.1 Operation setting functions................................................................................................. 12 - 5
12.2.2 Display operation of operation setting ................................................................................ 12 - 6
12.2.3 Setting operation of operation ............................................................................................ 12 - 7
12.2.4 Position correction of the touch panel (touch panel calibration setting) ............................. 12 - 9
12.2.5 Setting the utility call keys ................................................................................................ 12 - 11
12.3 Inherent Information..................................................................................................................... 12 - 13
12.3.1 Setting function for inherent information........................................................................... 12 - 13
12.3.2 Display operation of inherent information ......................................................................... 12 - 13
12.3.3 Setting operation for inherent information ........................................................................ 12 - 13
12.4 GOT internal device monitor........................................................................................................ 12 - 14
12.4.1 Setting the GOT internal device monitor .......................................................................... 12 - 14
12.4.2 GOT internal device monitor display operation ................................................................ 12 - 14
12.4.3 GOT internal device monitor setting operation ................................................................. 12 - 15
13. SECURITY LEVEL AND OPERATOR SETTINGS (SECURITY SETTING)
13.1 Security Level Authentication ........................................................................................................ 13 - 1
13.2 Operator Authentication................................................................................................................. 13 - 3
13.2.1 Operator information management..................................................................................... 13 - 3
13.2.2 Password change ............................................................................................................. 13 - 13
13.2.3 Function setting ................................................................................................................ 13 - 15
13.3 Login/Logout ................................................................................................................................ 13 - 17

A - 10
14. CLOCK SETTINGS AND BATTERY STATUS DISPLAY
(TIME SETTING AND DISPLAY)
14.1 Time Setting and Display............................................................................................................... 14 - 1
14.1.1 Time setting and display functions...................................................................................... 14 - 1
14.1.2 Clock synchronization method............................................................................................ 14 - 2
14.1.3 Time setting ........................................................................................................................ 14 - 3
14.1.4 Adjusting the clock.............................................................................................................. 14 - 5
14.1.5 Local time ........................................................................................................................... 14 - 9
15. CONTROL OF VARIOUS DATA (DATA CONTROL)
15.1 Data Storage Location ................................................................................................................... 15 - 1
15.1.1 Data type and storage location ...........................................................................................15 - 1
15.1.2 Checking version of basic system application .................................................................... 15 - 3
15.2 OS information ............................................................................................................................... 15 - 4
15.3 Resource Data Information............................................................................................................ 15 - 6
15.3.1 Alarm information................................................................................................................ 15 - 6
15.3.2 Recipe information............................................................................................................ 15 - 12
15.3.3 Logging information .......................................................................................................... 15 - 21
15.3.4 Image file management ....................................................................................................15 - 28
15.4 SD Card Access .......................................................................................................................... 15 - 33
15.4.1 Functions of SD card access ............................................................................................ 15 - 33
15.4.2 Display operation of SD card access................................................................................ 15 - 33
15.4.3 Operation of SD card access............................................................................................ 15 - 33
15.5 SD Card Format........................................................................................................................... 15 - 34
15.6 Clear data .................................................................................................................................... 15 - 36
15.6.1 Clear data functions.......................................................................................................... 15 - 36
15.6.2 Clear data display ............................................................................................................. 15 - 36
15.6.3 Clear data operation ......................................................................................................... 15 - 36
15.7 Data Copy.................................................................................................................................... 15 - 37
15.7.1 Display operation of data copy ......................................................................................... 15 - 37
15.7.2 Operation of data copy ..................................................................................................... 15 - 38
15.8 BACKUP/RESTORE.................................................................................................................... 15 - 40
15.8.1 BACKUP/RESTORE......................................................................................................... 15 - 40
15.8.2 System configuration ........................................................................................................ 15 - 41
15.8.3 Access range .................................................................................................................... 15 - 46
15.8.4 Precautions....................................................................................................................... 15 - 46
15.8.5 Security and password ..................................................................................................... 15 - 49
15.8.6 Operation of backup/restore ............................................................................................. 15 - 55
15.8.7 Operation of backup ......................................................................................................... 15 - 56
15.8.8 Operation of restore.......................................................................................................... 15 - 58
15.8.9 Operation of keyword........................................................................................................ 15 - 60
15.9 Errors and Corrective Actions ...................................................................................................... 15 - 61
16. GOT SELF CHECK (DEBUG)
16.1 Device Monitor Function ................................................................................................................ 16 - 1
16.1.1 System configuration .......................................................................................................... 16 - 1
16.1.2 Devices that can be monitored ........................................................................................... 16 - 2
16.1.3 Precautions......................................................................................................................... 16 - 2

A - 11
16.1.4 Display operation of device monitor ................................................................................... 16 - 3
16.1.5 Information displayed on the device monitor screen and key functions ............................. 16 - 4
16.1.6 Basic operation of device monitor ...................................................................................... 16 - 6
16.1.7 Device registration .............................................................................................................. 16 - 7
16.1.8 Quick test.......................................................................................................................... 16 - 10
16.2 FX List Editor ............................................................................................................................... 16 - 14
16.2.1 Display operation of FX list editor ..................................................................................... 16 - 14
16.2.2 Specifications ................................................................................................................... 16 - 16
16.2.3 Access range.................................................................................................................... 16 - 17
16.2.4 Precautions....................................................................................................................... 16 - 17
16.2.5 Display operation.............................................................................................................. 16 - 18
16.2.6 Operation procedures....................................................................................................... 16 - 20
16.2.7 Selection and operation of modes .................................................................................... 16 - 22
16.2.8 Displaying sequence programs ........................................................................................ 16 - 23
16.2.9 Searching commands/devices.......................................................................................... 16 - 25
16.2.10 Writing commands............................................................................................................ 16 - 27
16.2.11 Changing operands, set values ........................................................................................ 16 - 30
16.2.12 Deleting commands.......................................................................................................... 16 - 31
16.2.13 Sequence program all clear..............................................................................................16 - 32
16.2.14 PLC diagnostics................................................................................................................ 16 - 33
16.2.15 Parameter setting ............................................................................................................. 16 - 35
16.2.16 Keyword............................................................................................................................ 16 - 37
16.2.17 List monitor ....................................................................................................................... 16 - 39
16.2.18 Action for an incorrect key input .......................................................................................16 - 40
16.2.19 Error messages and corrective actions ............................................................................ 16 - 41
16.3 FX3U-ENET-ADP Communication Setting Function ................................................................... 16 - 42
16.3.1 Specifications ................................................................................................................... 16 - 42
16.3.2 Display operation of FX3U-ENET-ADP communication setting function .......................... 16 - 43
16.3.3 Setting operation .............................................................................................................. 16 - 44
17. MAINTENANCE
17.1 Touch Panel Calibration ................................................................................................................ 17 - 1
17.2 Touch Panel Check ....................................................................................................................... 17 - 3
17.3 Clean ............................................................................................................................................. 17 - 5
18. BootOS and System Application Installation Using Data Storage
18.1 Installing when starting the GOT ................................................................................................... 18 - 2
18.2 Installing using the data control function (Utility) ........................................................................... 18 - 2
19. INSTALLATION OF Boot OS AND BASIC SYSTEM APPLICATION
19.1 Boot OS and Basic System Application to be Installed ................................................................. 19 - 1
19.2 Prior Preparations for Installing Boot OS and System Application ................................................ 19 - 2
20. ERROR MESSAGE LIST
21. MAINTENANCE AND INSPECTION
21.1 Daily Inspection ............................................................................................................................. 21 - 2
21.2 Periodic Inspection ........................................................................................................................ 21 - 2
21.3 Cleaning Method............................................................................................................................ 21 - 3

A - 12
21.4 Backlight Shutoff Detection............................................................................................................ 21 - 4
21.4.1 Backlight shutoff detection and external alarm ................................................................... 21 - 4
22. TROUBLESHOOTING
22.1 GOT Restoration Sheets ............................................................................................................... 22 - 1
23. CONNECTION
24. APPENDIX
Appendix.1External Dimensions................................................................................................................. 24- 1
REVISIONS
WARRANTY

A - 13
About Manual
The following manuals related to this product are available.
Refer to each manual in accordance with the intended use.
Screen creation software manuals
Connection manuals
GOT SIMPLE series manuals
Manual name Manual number
(Model code)
GT Works3 Installation Instructions -
GT Designer3 (GOT2000) Help -
GT Converter2 Version3 Operating Manual for GT Works3 SH-080862ENG
(1D7MB2)
Manual name Manual number
(Model code)
GOT2000 Series Connection Manual (Mitsubishi Product) For GT Works3 Version1 SH-081197ENG
(1D7MJ8)
GOT2000 Series Connection Manual (Non Mitsubishi Product 1) For GT Works3 Version1 SH-081198ENG
(1D7MJ9)
GOT2000 Series Connection Manual (Non Mitsubishi Product 2) For GT Works3 Version1 SH-081199ENG
(1D7MK1)
GOT2000 Series Connection Manual (Microcomputer, MODBUS Products, Peripherals) For GT Works3 Version1 SH-081200ENG
(1D7MK2)
Manual name Manual number
(Model code)
GOT SIMPLE Series User's Manual JY997D52901

A - 14
Quick Reference
Creating projects
Connecting a controller to the GOT
Transferring data to the GOT
Others
Obtaining the specifications and operation methods of GT Designer3
GT Designer3 (GOT2000) Help
Setting available functions on GT Designer3
Creating a screen displayed on the GOT
Obtaining useful functions to increase efficiency of drawing
Setting details for figures and objects
Setting functions for the data collection or trigger action
Setting functions to use peripheral devices
Simulating a created project on a personal computer
Obtaining information of Mitsubishi products applicable to the GOT
GOT2000 Series Connection Manual (Mitsubishi Product)
For GT Works3 Version1
Connecting Mitsubishi products to the GOT
Connecting multiple controllers to one GOT (Multi-channel function)
Establishing communication between a personal computer and a
controller via the GOT (FA transparent function)
Obtaining information of Non-Mitsubishi products applicable to the
GOT
• GOT2000 Series Connection Manual (Non Mitsubishi
Product 1) For GT Works3 Version1
• GOT2000 Series Connection Manual (Non Mitsubishi
Product 2) For GT Works3 Version1
Connecting Non-Mitsubishi products to the GOT
Obtaining information of peripheral devices applicable to the GOT GOT2000 Series Connection Manual (Microcomputer,
MODBUS Products, Peripherals) For GT Works3 Version1
Connecting peripheral devices including a bar code reader to the GOT
Writing data to the GOT
GT Designer3 (GOT2000) Help
Reading data from the GOT
Verifying an editing project to a GOT project
Obtaining the specifications and operation methods of GT Designer3
GOT SIMPLE Series User's Manual
Setting available functions on GT Designer3
Creating a screen displayed on the GOT GOT SIMPLE Series User's Manual
Obtaining useful functions to increase efficiency of drawing GT Designer3 (GOT2000) Help

A - 15
Abbreviations and Generic Terms
GOT
Option
Software
(1) Software related to GOT
Abbreviations and generic terms Description
GOT
SIMPLE
Series
GS21
GS2110-W GS2110-WTBD
GS2107-W GS2107-WTBD
GOT2000
Series
GT27
GT2712-S GT2712-STBA, GT2712-STWA, GT2712-STBD, GT2712-STWD
GT2710-S GT2710-STBA, GT2710-STBD
GT2710-V GT2710-VTBA, GT2710-VTWA, GT2710-VTBD, GT2710-VTWD
GT2708-S GT2708-STBA, GT2708-STBD
GT2708-V GT2708-VTBA, GT2708-VTBD
GT23
GT2310-V GT2310-VTBA, GT2310-VTBD
GT2308-V GT2308-VTBA, GT2308-VTBD
GT SoftGOT2000 GT SoftGOT2000 Version1
Abbreviations and generic terms Description
SD card L1MEM-2GBSD, L1MEM-4GBSD
Abbreviations and generic terms Description
GT Works3 SW1DNC-GTW3-J, SW1DND-GTW3-J, SW1DNC-GTW3-E, SW1DND-GTW3-E, SW1DND-GTW3-C
GT Designer3 Version1 Screen drawing software GT Designer3 for GOT2000/GOT1000 series
GT Designer3
Screen drawing software for GOT2000 series included in GT Works3
GT Designer3 (GOT2000)
GT Designer3 (GOT1000) Screen drawing software for GOT1000 series included in GT Works3
GT Simulator3 Screen simulator GT Simulator3 for GOT2000/GOT1000/GOT900 series

A - 16
(2) Other software
Others
Abbreviations and generic terms Description
GX Works3 SW□DND-GXW3-E (-EA) type programmable controller engineering software
(□ indicates a version.)
GX Works2 SW□DNC-GXW2-□ type programmable controller engineering software
(□ indicates a version.)
GX Simulator3 Simulation function of GX Works3
GX Simulator2 Simulation function of GX Works2
GX Simulator
SW□D5C-LLT-E (-EV) type ladder logic test tool function software package
(SW5D5C-LLT (-V) or later versions)
(□ indicates a version.)
GX Developer SW□D5C-GPPW-E (-EV)/SW□D5F-GPPW (-V) type software package
(□ indicates a version.)
GX LogViewer SW□DNN-VIEWER-E type software package
(□ indicates a version.)
PX Developer SW□D5C-FBDQ-E type FBD software package for process control
(□ indicates a version.)
MT Works2 Motion controller engineering environment MELSOFT MT Works2 (SW□DNDMTW2-E)
(□ indicates a version.)
MT Developer SW□RNC-GSV type integrated start-up support software for motion controller Q series
(□ indicates a version.)
CW Configurator C Controller module configuration and monitor tool (SW1DND-RCCPU-E)
(□ indicates a version.)
MR Configurator2 SW□DNC-MRC2-E type servo configuration software
(□ indicates a version.)
MR Configurator MRZJW□-SETUP type servo configuration software
(□ indicates a version.)
FR Configurator Inverter setup software (FR-SW□-SETUP-WE)
(□ indicates a version.)
NC Configurator2 CNC parameter setting support tool (FCSB1221)
NC Configurator CNC parameter setting support tool
FX Configurator-FP
Parameter setting, monitoring, and testing software packages for FX3U-20SSC-H
(SW□D5CFXSSCE)
(□ indicates a version.)
FX3U-ENET-L Configuration tool FX3U-ENET-L type Ethernet module setting software (SW1D5-FXENETL-E)
RT ToolBox2 Robot program creation software (3D-11C-WINE)
MX Component MX Component Version□ (SW□D5C-ACT-E, SW□D5C-ACT-EA)
(□ indicates a version.)
MX Sheet MX Sheet Version□ (SW□D5C-SHEET-E, SW□D5C-SHEET-EA)
(□ indicates a version.)
CPU Module Logging Configuration Tool CPU module logging configuration tool (SW1DNN-LLUTL-E)
Abbreviations and generic terms Description
SIEMENS Siemens AG
PLC Programmable controller manufactured by each corporation

1 - 1
1
OVERVIEW
1. OVERVIEW
■1. About GOT
A GOT is installed on the panel surface of a control panel or operating
panel and connects to the PLC within the control panel. The GOT carries
out switch operation, lamp display, data display, message display, etc.
For the display screen, two kinds of screens are available: user screen and
utility screen.
(1) User screen
The user screen is a screen drawn by drawing software.
The objects "Touch switch", "Lamp display", "Comment display", and
"Numeric display" can be arbitrarily arranged on the display.
Moreover, multiple screens created within drawing software can be
individually selected or overlapped for the display.
For details, refer to the following.
➠ GT Designer3 (GOT2000) Help
(2) Utility Screen
The utility screen is a factory drawn horizontal screen that cannot be edited.
The utility screen can be displayed on the GOT by installing the standard monitor OS from drawing software or an SD
card to the GOT.
Such as [Brightness] and [Time setting] can be set from the utility screen.
For details, refer to the following.
➠ 9. to 22.
PLC
Connector for
program
GOT

1 - 2 1.1 Features
1.1 Features
Monitoring for turning on or off bit devices of a PLC, forcibly turning on or off the bit devices of a PLC, monitoring the word
device set value/current value and changing that numeric values are easily made.
(1) The display unit is used for engineers' stage replacement, setting change and troubleshooting or
for operation guidance to an operator.
• Monitor
• Forcibly turning on or off
• Set value change
•Trouble check
(2) Improved monitoring performance and connectivity to FA devices
• Multiple languages are displayed using the Unicode2.1-compatible fonts and beautiful characters are drawn using
the TrueType and high quality fonts
• Two types of display modes are available: 65536-color display and monochrome
A fine and beautiful full-color display which shows even small characters clearly, is enabled in the 65536-color
display by adopting the high intensity, wide viewing angle and high definition TFT color liquid crystal display.
(Also compatible with digital screen displays with 65536 colors, BMP, etc.)
High speed monitoring through high speed communication at maximum of 115.2kbps
• High speed display and high speed touch switch response
• The operation performance is improved by the analog touch panel.
(3) More efficient GOT operations including screen design, startup, adjustment, management and
maintenance works
• The 9MB built-in flash memory is included as standard.
• SD card interface is included as standard.
• RS-232 interface is included as standard.
• RS-422 interface is included as standard.
• USB interface (device) is included as standard.
• Ethernet interface is included as standard.
• System font types are increased by the adoption of the font installation system.
• Four types of alarms (system alarm, user alarm, alarm history and alarm popup display) are integrated, and
realizing an efficient alarm notification.
(4) Enhanced support of FA setup tools
• Transferring or monitoring the sequence programs using the personal computer connected to GOT, during
connection to L, Q, QnA, or FX series PLC CPU (FA transparent function)
