Mitsubishi Electric MELSEC Q Series User manual

Analog-Digital Converter Module
User's Manual
-Q64AD
-Q68ADV
-Q68ADI
-GX Configurator-AD (SW2D5C-QADU-E)

A-1 A-1
SAFETY PRECAUTIONS 
(Read these precautions before using this product.)
Before using this product, please read this manual and the relevant manuals carefully and pay full
attention to safety to handle the product correctly.
In this manual, the safety precautions are classified into two levels: " WARNING" and " CAUTION".
Indicates that incorrect handling may cause hazardous conditions,
resulting in death or severe injury.
Indicates that incorrect handling may cause hazardous conditions,
resulting in minor or moderate injury or property damage.
Under some circumstances, failure to observe the precautions given under " CAUTION" may lead to
serious consequences.
Observe the precautions of both levels because they are important for personal and system safety.
Make sure that the end users read this manual and then keep the manual in a safe place for future
reference.
[DESIGN PRECAUTION]
WARNING
Do not write data into "System area" of the buffer memory of intelligent function modules. Also,
do not use any "Use prohibited" signals as an output signal to an intelligent function module
from the programmable controller CPU.
Writing data into "System area" or outputting a signal for "Use prohibited" may cause a
programmable controller system malfunction.
CAUTION
Do not bunch the control wires or communication cables with the main circuit or power wires, or
install them close to each other.
They should be installed 100mm or more from each other.
Not doing so could result in noise that may cause malfunction.
WARNING
CAUTION

A-2 A-2
[SECURITY PRECAUTIONS]
WARNING
To maintain the security (confidentiality, integrity, and availability) of the programmable controller
and the system against unauthorized access, denial-of-service (DoS) attacks, computer viruses,
and other cyberattacks from external devices via the network, take appropriate measures such
as firewalls, virtual private networks (VPNs), and antivirus solutions.
[INSTALLATION PRECAUTIONS]
CAUTION
Use the programmable controller in an environment that meets the general specifications
contained in the user's manual of the CPU module to use.
Using this programmable controller in an environment outside the range of the general
specifications may cause electric shock, fire, malfunction, and damage to or deterioration of the
product.
While pressing the installation lever located at the bottom of module, insert the module fixing tab
into the fixing hole in the base unit until it stops. Then, securely mount the module with the fixing
hole as a supporting point.
Improper installation may result in malfunction, breakdown or the module coming loose and
dropping.
Securely fix the module with screws if it is subject to vibration during use.
Tighten the screws within the range of specified torque.
If the screws are loose, it may cause the module to fallout, short circuits, or malfunction.
If the screws are tightened too much, it may cause damage to the screw and/or the module,
resulting in fallout, short circuits or malfunction.
Be sure to shut off all phases of the external power supply used by the system before mounting
or removing the module.
Not doing so may cause damage to the module.
In the system where a CPU module supporting the online module change is used and on the
MELSECNET/H remote I/O stations, modules can be replaced online (during energizing).
However, there are some restrictions on replaceable modules and the replacement procedures
are predetermined for each module.
For details, refer to the chapter of the online module change in this manual.
Do not directly touch the conductive area or electronic components of the module.
Doing so may cause malfunction or failure in the module.

A-3 A-3
[WIRING PRECAUTIONS]
WARNING
After wiring, attach the included terminal cover to the module before turning it on for operation.
Failure to do so may result in electric shock.
CAUTION
Individually ground the FG terminal of the programmable controller with a ground resistance of
100or less.
Failure to do so may result in electric shock or malfunction.
Use applicable solderless terminals and tighten them within the specified torque range. If any
spade solderless terminal is used, it may be disconnected when a terminal screw comes loose,
resulting in failure.
Tighten the terminal screws within the specified torque range.
Undertightening can cause short circuit, fire, or malfunction.
Overtightening can damage the screw and/or module, resulting in drop, short circuit, or
malfunction.
Be careful not to let foreign matter such as sawdust or wire chips get inside the module.
They may cause fires, failure or malfunction.
The top surface of the module is covered with protective film to prevent foreign objects such as
cable offcuts from entering the module when wiring.
Do not remove this film until the wiring is complete.
Before operating the system, be sure to remove the film to provide adequate ventilation.

A-4 A-4
[STARTING AND MAINTENANCE PRECAUTIONS]
WARNING
Do not touch any terminal while power is on.
Doing so will cause electric shock or malfunction.
Shut off the external power supply (all phases) used in the system before cleaning the module or
retightening the terminal screws or module fixing screws.
Failure to do so may result in electric shock or cause the module to fail or malfunction.
Undertightening can cause drop of the screw, short circuit, or malfunction.
Overtightening can damage the screw and/or module, resulting in drop, short circuit, or
malfunction.
CAUTION
Do not disassemble or modify the modules.
Doing so may cause failure, malfunction, injury, or a fire.
Be sure to shut off all phases of the external power supply used by the system before mounting
or removing the module.
Not doing so may cause failure or malfunction of the module.
In the system where a CPU module supporting the online module change is used and on the
MELSECNET/H remote I/O stations, modules can be replaced online (during energizing).
However, there are some restrictions on replaceable modules and the replacement procedures
are predetermined for each module.
For details, refer to the chapter of the online module change in this manual.
Do not install/remove the module to/from the base unit, or the terminal block to/from the module
more than 50 times after the first use of the product. (IEC 61131-2 compliant)
Failure to do so may cause malfunction.
Always make sure to touch the grounded metal to discharge the electricity charged in the body,
etc., before touching the module.
Failure to do so may cause a failure or malfunctions of the module.
[DISPOSAL PRECAUTIONS]
CAUTION
When disposing of this product, treat it as industrial waste.

A-5 A-5
CONDITIONS OF USE FOR THE PRODUCT 
(1) Mitsubishi programmable controller ("the PRODUCT") shall be used in conditions;
i) where any problem, fault or failure occurring in the PRODUCT, if any, shall not lead to any major or
serious accident; and
ii) where the backup and fail-safe function are systematically or automatically provided outside of the
PRODUCT for the case of any problem, fault or failure occurring in the PRODUCT.
(2) The PRODUCT has been designed and manufactured for the purpose of being used in general
industries.
MITSUBISHI SHALL HAVE NO RESPONSIBILITY OR LIABILITY (INCLUDING, BUT NOT LIMITED
TO ANY AND ALL RESPONSIBILITY OR LIABILITY BASED ON CONTRACT, WARRANTY, TORT,
PRODUCT LIABILITY) FOR ANY INJURY OR DEATH TO PERSONS OR LOSS OR DAMAGE TO
PROPERTY CAUSED BY the PRODUCT THAT ARE OPERATED OR USED IN APPLICATION NOT
INTENDED OR EXCLUDED BY INSTRUCTIONS, PRECAUTIONS, OR WARNING CONTAINED IN
MITSUBISHI'S USER, INSTRUCTION AND/OR SAFETY MANUALS, TECHNICAL BULLETINS AND
GUIDELINES FOR the PRODUCT.
("Prohibited Application")
Prohibited Applications include, but not limited to, the use of the PRODUCT in;
Nuclear Power Plants and any other power plants operated by Power companies, and/or any other
cases in which the public could be affected if any problem or fault occurs in the PRODUCT.
Railway companies or Public service purposes, and/or any other cases in which establishment of a
special quality assurance system is required by the Purchaser or End User.
Aircraft or Aerospace, Medical applications, Train equipment, transport equipment such as Elevator
and Escalator, Incineration and Fuel devices, Vehicles, Manned transportation, Equipment for
Recreation and Amusement, and Safety devices, handling of Nuclear or Hazardous Materials or
Chemicals, Mining and Drilling, and/or other applications where there is a significant risk of injury to
the public or property.
Notwithstanding the above, restrictions Mitsubishi may in its sole discretion, authorize use of the
PRODUCT in one or more of the Prohibited Applications, provided that the usage of the PRODUCT is
limited only for the specific applications agreed to by Mitsubishi and provided further that no special
quality assurance or fail-safe, redundant or other safety features which exceed the general
specifications of the PRODUCTs are required. For details, please contact the Mitsubishi
representative in your region.
(3) Mitsubishi shall have no responsibility or liability for any problems involving programmable controller
trouble and system trouble caused by DoS attacks, unauthorized access, computer viruses, and other
cyberattacks.

A-6 A-6
REVISIONS
The manual number is given on the bottom left of the back cover.
Print Date Manual Number Revision
Dec., 1999 SH (NA)-080055-A First printing
Oct., 2000 SH (NA)-080055-B Add the contents of the function version B.
Correction
A
bout the Generic Terms and Abbreviations, Section 2.1, Section 3.1.3,
3.4.1, Section 4.3, 4.4.2, Section 5.2.1, 5.2.2, 5.3.3, 5.6.1
Partial addition
Section 1.1, Section 3.1.1, 3.1.2, 3.2, 3.3.1, 3.3.2, Section 4.5, Section
7.2.3, 7.2.4
Addition
Section 1.2, Section 2.2, Appendix 1, 1.1, 1.2, 1.3
Jun., 2001 SH (NA)-080055-C Standardize the name from software package (GPP function) to Product
name (GX Developer).
Standardize the name from utility package (QADU) to Product name (GX
Configurator-AD).
Correction
Conformation to the EMC Directive and Low Voltage Instruction, About
the Generic Terms and Abbreviations, Product Structure, Section 2.1,
2.2, Section 4.6, Section 5.2, 5.2.1, 5.2.2, 5.3.3, Appendix 1.2
Feb., 2002 SH (NA)-080055-D Add the contents of the function version C.
Correction
Section 2.2, Section 3.4.1, Section 4.2, 4.4.1, 4.4.2, Section 5.3.3
Partial addition
SAFETY PRECAUTIONS, , About the Generic Terms and Abbreviations,
Product Structure, Section 1.2, Section 2.1, Section 3.1.1, 3. 2, Section
4.3, 4.6, Section 5.2.1, 5.2.2, Section 8.1, 8.2.1, Appendix 1.1, 1.2, 1.3
Addition
Section 3.4.2, 3.4.3, 3.4.13, 3.4.14, 3.4.15, Chapter 7, Appendix 2, 2.1,
2.2, 2.3
Renumbering
Section 3.4.2 to Section 3.4.10 Section 3.4.4 to Section 3.4.12,
Chapter 7 Chapter 8, Appendix 2 Appendix 3
May, 2002 SH (NA)-080055-E Correction
Section 3.4.1, 3.4.2, 3.4.3, 3.4.14, 3.4.15, Section 4.2, 4.5, 4.6,
Section 7.2, 7.3.1, 7.3.2, 7.3.4, 7.3.6, 7.4, 7.5, Appendix 1.1, 2.2, 2.3
Partial addition
Section 3.3.2, Section 8.2.3

A-7 A-7
The manual number is given on the bottom left of the back cover.
Print Date Manual Number Revision
Feb., 2003 SH (NA)-080055-F Correction
SAFETY PRECAUTIONS, Section 1.2, Section 2.1, Section 3.4.1 to
3.4.3, 3.4.15, Section 4.5, Section 5.1, 5.2.1, 5.2.2, 5.3.2, 5.6.1 to 5.6.3,
Section 7.3.1, 7.3.3 to 7.3.6, Appendix 1.1, Appendix 1.2, Appendix 2.2,
Appendix 2.3
Addition
Section 5.6.4, 5.6.5
May, 2003 SH (NA)-080055-G Correction
Section 2.2, Section 3.4.1, 3.4.2, 3.4.3, 3.4.14, 3.4.15, Section 4.5, 4.6,
Section 5.3.1
May, 2004 SH (NA)-080055-H Addition of program example for use on the remote I/O network.
Correction
Section 2.2, Section 4.6, Chapter 6, Section 7.1, 7.3.1 to 7.3.6
Aug., 2004 SH (NA)-080055-I Correction
Section 1.1, Section 5.1, 5.2.1, 5.2.2, 5.3.1, 5.3.2, 5.3.3, 5.6.1, 5.6.2,
5.6.3, Appendix 2.3
Addition
Section 5.6.4, 5.7, 5.8
Oct., 2004 SH (NA)-080055-J Correction
SAFETY PRECAUTIONS, Section 2.1, Section 3.1.1, Section 4.1,
Section 6.2, 6.2.1
Sep., 2005 SH (NA)-080055-K Correction
SAFETY PRECAUTIONS, Section 2.1, Section 5.2.2, Section 6.2.2,
Feb., 2006 SH (NA)-080055-L Correction
Section 6.1.1, 6.1.2, 6.2.1, 6.2.2, Appendix 2
Jan., 2007 SH (NA)-080055-M Correction
SAFETY PRECAUTIONS, Section 3.3.2, 4.4.2, 4.6, 6.2.1, 6.2.2,
Chapter 7
Jun., 2007 SH (NA)-080055-N Correction
Section 4.3, Appendix 3
Jan., 2008 SH (NA)-080055-O Correction
SAFETY PRECAUTIONS, About the Generic Terms and Abbreviations,
Section 1.2, Section 2.1, 2.3, Section 4.1, 4.5, 4.6, Section 5.2.1, 5.2.2,
5.3.2, 5.3.3, 5.4, 5.6.1, 5.6.5, 5.6.6, Section 6.1.1, 6.2.1, Section 7.3.1,
7.3.3, 7.3.4, 7.3.5, Section 8.1, Appendix 1.1, Appendix 2, Appendix
2.1, Appendix 2.2, Appendix 2.3
Addition
Section 2.2

A-8 A-8
The manual number is given on the bottom left of the back cover.
Print Date Manual Number Revision
May, 2008 SH (NA)-080055-P Correction
SAFETY PRECAUTIONS, Compliance with the EMC and Low Voltage
Directives, About the Generic Terms and Abbreviations, Section 2.1,
Section 3.1.1, 3.1.2, 3.3.2, 3.4.4 to 3.4.6, Section 4.1, Section 5.2.1,
5.2.2, 5.3.1, 5.3.3, Chapter 7, Section 7.1
Nov., 2010 SH (NA)-080055-Q Correction
SAFETY PRECAUTIONS, About Manuals, INTRODUCTION, About the
Generic Terms and Abbreviations,
Section 1.1, Section 2.1, 2.2, 2.3, Section 3.1.1, 3.1.2, 3.3.2,
3.4.1 to 3.4.3, 3.4.5, 3.4.7, 3.4.8, 3.4.10, 3.4.12, Section 4.1, 4.3, 4.4.2,
4.5, 4.6, Section 5.1, 5.2.1, 5.3.1, 5.3.3, 5.4, 5.5, 5.6.1 to 5.6.4, 5.7,
Section 6.2.2, Section 7.1, 7.3.1 to 7.3.6, 7.5, Section 8.1, 8.2.3, 8.2.4,
Appendix 2.1 to Appendix 2.3, Appendix 3
Addition
CONDITIONS OF USE FOR THE PRODUCT
Dec., 2012 SH (NA)-080055-R Correction
SAFETY PRECAUTIONS, COMPLIANCE WITH EMC AND LOW
VOLTAGE DIRECTIVES, ABOUT MANUALS, ABOUT THE GENERIC
TERMS AND ABBREVIATIONS, Section 1.2, Section 2.1,
Section 2.3, Section 3.1.2, 3.2.2, 3.3.1, 3.4.6, 3.4.7, 3.4.8, 3.4.10,
3.4.11, 3.4.15, Section 4.1, 4.6, Section 5.2.2, 5.6.1 to 5.6.4,
Section 6.1, 6.2, 6.2.2, Chapter 7, Section 7.3.4, 7.4, 7.5, Section 8.1,
8.2.3
May, 2015 SH (NA)-080055-S Correction
ABOUT THE GENERIC TERMS AND ABBREVIATIONS, Section 2.1,
2.3, Section 4.3, 4.6, Section 5.2.1, 5.6.2, 5.6.3, Section 6.1.2,
Appendix 3
Jan., 2021 SH (NA)-080055-T Correction
SAFETY PRECAUTIONS, CONDITIONS OF USE FOR THE PRODUCT,
PRODUCT STRUCTURE, Section 8.1
Japanese Manual Version SH-080028-Y
This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent
licenses. Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property
rights which may occur as a result of using the contents noted in this manual.
1999 MITSUBISHI ELECTRIC CORPORATION

A-9 A-9
INTRODUCTION
Thank you for purchasing the MELSEC-Q series programmable controller.
Before using the product, please read this manual carefully to develop full familiarity with the functions and
performance of the Q series programmable controllers to ensure correct use.
CONTENTS
SAFETY PRECAUTIONS............................................................................................................................. A-
1
CONDITIONS OF USE FOR THE PRODUCT ............................................................................................ A-
5
REVISIONS ................................................................................................................................................... A-
6
INTRODUCTION........................................................................................................................................... A-
9
CONTENTS................................................................................................................................................... A-
9
ABOUT MANUALS ........................................................................................................................................A-12
COMPLIANCE WITH EMC AND LOW VOLTAGE DIRECTIVES ...............................................................A-12
ABOUT THE GENERIC TERMS AND ABBREVIATIONS...........................................................................A-13
PRODUCT STRUCTURE..............................................................................................................................A-14
1 OVERVIEW 1-
1 to 1- 2
1.1 Features.................................................................................................................................................1- 1
1.2 Functions Added to Function Version B and Later...............................................................................1-
2
2 SYSTEM CONFIGURATION 2-
1 to 2- 8
2.1 Applicable Systems ...............................................................................................................................2- 1
2.2 Precautions on System Configuration ..................................................................................................2-
4
2.3 Checking Function Version, Serial Number, and Software Version....................................................2-
5
3 SPECIFICATIONS 3-
1 to 3-33
3.1 Performance Specifications ..................................................................................................................3- 1
3.1.1 Performance specifications list.......................................................................................................3-
1
3.1.2 I/O conversion characteristic ..........................................................................................................3-
2
3.1.3 Accuracy .........................................................................................................................................3-
9
3.2 Function List .......................................................................................................................................... 3-10
3.2.1 A/D conversion methods ................................................................................................................ 3-11
3.2.2 Maximum and minimum value hold function ................................................................................. 3-13
3.3 I/O Signals for the Programmable Controller CPU............................................................................... 3-13
3.3.1 List of I/O signals ............................................................................................................................ 3-13
3.3.2 Details of I/O signals....................................................................................................................... 3-14
3.4 Buffer Memory ....................................................................................................................................... 3-18
3.4.1 Buffer memory assignment (Q64AD)............................................................................................. 3-18
3.4.2 Buffer memory assignment (Q68ADV) .......................................................................................... 3-20
3.4.3 Buffer memory assignment (Q68ADI)............................................................................................ 3-23
3.4.4 A/D conversion enable/disable setting (buffer memory address 0: Un\G0) ................................. 3-26
3.4.5 Average time/average number of times
(buffer memory address 1 to 8: Un\G1 to Un\G8)......................................................................... 3-26
3.4.6 Averaging process setting (buffer memory address 9: Un\G9) .................................................... 3-27
3.4.7 A/D conversion completed flag (buffer memory address 10: Un\G10)......................................... 3-28
3.4.8 CHDigital output value (buffer memory address 11 to 18: Un\G11 to Un\G18)....................... 3-29
3.4.9 Error code (buffer memory address 19: Un\G19).......................................................................... 3-30

A-10 A-10
3.4.10 Setting range (buffer memory address 20, 21: Un\G20, Un\G21).............................................. 3-30
3.4.11 Offset/gain setting mode Offset/gain specification
(buffer memory address 22, 23: Un\G22, Un\G23) ...................................................................... 3-31
3.4.12 Maximum and minimum value storage area
(buffer memory address 30 to 45: Un\G30 to Un\G45) ................................................................ 3-31
3.4.13 Mode switching setting (buffer memory address 158, 159: Un\G158, Un\G159) ...................... 3-32
3.4.14 Pass data classification setting (buffer memory address 200: Un\G200) (Q64AD only)........... 3-32
3.4.15 Industrial shipment settings and User range settings offset/gain value
(buffer memory address 202 to 233: Un\G202 to Un\G233) ........................................................ 3-33
4 SETUP AND PROCEDURES BEFORE OPERATION 4-
1 to 4-14
4.1 Handling Precautions ............................................................................................................................4- 1
4.2 Setup and Procedures before Operation..............................................................................................4-
2
4.3 Part Identification Nomenclature...........................................................................................................4-
3
4.4 Wiring.....................................................................................................................................................4-
5
4.4.1 Wiring precautions ..........................................................................................................................4-
5
4.4.2 External wiring ................................................................................................................................4-
6
4.5 Switch Setting for Intelligent Function Module .....................................................................................4-
8
4.6 Offset/Gain Settings .............................................................................................................................. 4-10
5 UTILITY PACKAGE (GX Configurator-AD) 5-
1 to 5-34
5.1 Utility Package Functions......................................................................................................................5- 1
5.2 Installing and Uninstalling the Utility Package ......................................................................................5-
2
5.2.1 Handling precautions......................................................................................................................5-
2
5.2.2 Operating environment...................................................................................................................5-
4
5.3 Utility Package Operation......................................................................................................................5-
6
5.3.1 Common utility package operations...............................................................................................5-
6
5.3.2 Operation overview.........................................................................................................................5-
9
5.3.3 Starting the intelligent function module utility................................................................................. 5-11
5.4 Initial Setting .......................................................................................................................................... 5-14
5.5 Auto Refresh Settings ........................................................................................................................... 5-15
5.6 Monitoring /Test..................................................................................................................................... 5-17
5.6.1 Monitor/test screen ......................................................................................................................... 5-17
5.6.2 Offset/gain setting operation (Function version C or later) ........................................................... 5-21
5.6.3 Offset/gain setting operation (Function version B or earlier)......................................................... 5-23
5.6.4 Confirmation of Conversion Characteristic .................................................................................... 5-25
5.6.5 Pass data (Q64AD) ........................................................................................................................ 5-27
5.6.6 Pass data (Q68ADV/Q68ADI)........................................................................................................ 5-29
5.7 FB Conversion of Initial Setting/Auto Refresh Setting ......................................................................... 5-30
5.8 Usage of FB........................................................................................................................................... 5-31
5.8.1 Outline............................................................................................................................................. 5-31
5.8.2 Paste an FB to a Sequence Program ............................................................................................ 5-33
5.8.3 Convert (Compile) a Sequence Program ...................................................................................... 5-34
6 PROGRAMMING 6-
1 to 6-12
6.1 For Use in Normal System Configuration.............................................................................................6- 1
6.1.1 Programming example using the utility package...........................................................................6-
2
6.1.2 Programming example without using the utility package ..............................................................6-
4

A-11 A-11
6.2 For Use in Remote I/O Network............................................................................................................6-
6
6.2.1 Programming example using the utility package...........................................................................6-
7
6.2.2 Programming example without using the utility package .............................................................. 6-10
7 ONLINE MODULE CHANGE 7-
1 to 7-36
7.1 Online Module Change Conditions .......................................................................................................7- 2
7.2 Online Module Change Operations ......................................................................................................7-
3
7.3 Online Module Change Procedure .......................................................................................................7-
4
7.3.1 When industrial shipment setting is used and initial setting was made with GX Configurator-AD
..........................................................................................................................................................7-
4
7.3.2 When industrial shipment setting is used and initial setting was made with sequence program
..........................................................................................................................................................7-
9
7.3.3 When user range setting is used and initial setting was made with GX Configurator-AD
(other system is available) ............................................................................................................... 7-14
7.3.4 When user range setting is used and initial setting was made with GX Configurator-AD
(other system is unavailable)........................................................................................................... 7-19
7.3.5 When user range setting is used and initial setting was made with sequence program
(other system is available) ............................................................................................................... 7-25
7.3.6 When user range setting is used and initial setting was made with sequence program
(other system is unavailable)........................................................................................................... 7-30
7.4 Range Reference Table ........................................................................................................................ 7-35
7.5 Precautions for Online Module Change................................................................................................ 7-36
8 TROUBLESHOOTING 8-
1 to 8- 6
8.1 Error Code List.......................................................................................................................................8- 1
8.2 Troubleshooting.....................................................................................................................................8-
3
8.2.1 When the "RUN" LED is flashing or turned off ..............................................................................8-
3
8.2.2 When the "ERROR" LED is on or flashing ....................................................................................8-
3
8.2.3 When the digital output values cannot be read .............................................................................8-
4
8.2.4 Checking the A/D converter module status using GX Developer system monitor.......................8-
5
APPENDICES App.-
1 to App.-15
Appendix 1 Function Upgrade for the A/D Converter Module ............................................................. App.- 1
Appendix 1.1 A comparison of functions of the A/D converter module ........................................... App.-
1
Appendix 1.2 Combinations of A/D converter module functions and GX Configurator-AD
software versions.......................................................................................................... App.-
2
Appendix 1.3 Precautions for replacing the module of function version A with the one of
function version B or later............................................................................................. App.-
2
Appendix 2 Dedicated Instruction List and Available Devices ........................................................... App.-
3
Appendix 2.1 G(P).OFFGAN............................................................................................................. App.-
4
Appendix 2.2 G(P).OGLOAD ............................................................................................................ App.-
6
Appendix 2.3 G(P).OGSTOR ............................................................................................................ App.-10
Appendix 3 External Dimension Diagram............................................................................................. App.-15
INDEX Index-
1 to Index- 2

A-12 A-12
ABOUT MANUALS
The following manuals are also related to this product.
If necessary, order them by quoting the details in the tables below.
Related Manuals
Manual Name Manual Number
(Model Code)
GX Developer Version 8 Operating Manual
Describes the methods of using GX Developer to create a program and print out, monitor, and debug
the program. (Sold separately)
SH-080373E
(13JU41)
GX Developer Version 8 Operating Manual (Function Block)
Describes the methods of using GX Developer to create a function block and print out the function block.
(Sold separately)
SH-080376E
(13JU44)
GX Works2 Version 1 Operating Manual (Common)
Describes the system configuration, parameter settings, and online operations (common to Simple
project and Structured project) of GX Works2 (Sold separately)
SH-080779E
(13JU63)
GX Works2 Version 1 Operating Manual (Intelligent Function Module)
Explains methods of intelligent function module for such as parameter setting, monitoring programs, and
predefined protocol support function in GX Works2. (Sold separately)
SH-080921ENG
(13JU69)
REMARK
If you would like to obtain a manual individually, printed matters are available
separately. Order the manual by quoting the manual number on the table above
(model code).
COMPLIANCE WITH EMC AND LOW VOLTAGE DIRECTIVES
(1) Method of ensuring compliance
To ensure that Mitsubishi programmable controllers maintain EMC and Low
Voltage Directives when incorporated into other machinery or equipment,
certain measures may be necessary. Please refer to one of the following
manuals.
QCPU User's Manual (Hardware Design, Maintenance and Inspection)
Safety Guidelines
(This manual is included with the CPU module or base unit.)
The CE mark on the side of the programmable controller indicates compliance
with EMC and Low Voltage Directives.
(2) Additional measures
No additional measures are necessary for the compliance of this product with
EMC and Low Voltage Directives.

A-13 A-13
ABOUT THE GENERIC TERMS AND ABBREVIATIONS
Unless otherwise specified, this manual uses the following general terms and
abbreviations.
Abbreviation/general terms Description of the abbreviation/general terms
A/D converter module Generic term for Q64AD, Q68ADI, Q68ADV
Personal computer IBM PC/AT®or compatible computer with DOS/V.
GX Developer Product name of the software package for the MELSEC programmable controllers
GX Works2
GX Configurator-AD Generic term for analog-digital converter module setting and monitor tool GX
Configurator-AD (SW2D5C-QADU-E)
QCPU (Q mode) Generic term for Basic model QCPU, High Performance model QCPU, Process CPU,
Redundant CPU, and Universal model QCPU
Basic model QCPU Generic term for Q00JCPU, Q00CPU, and Q01CPU
High Performance model
QCPU Generic term for Q02CPU, Q02HCPU, Q06HCPU, Q12HCPU, and Q25HCPU
Process CPU Generic term for Q02PHCPU, Q06PHCPU, Q12PHCPU and Q25PHCPU.
Redundant CPU Generic term for Q12PRHCPU, Q25PRHCPU.
Universal model QCPU
Generic term for Q00UJCPU, Q00UCPU, Q01UCPU, Q02UCPU, Q03UDCPU,
Q03UDVCPU, Q03UDECPU, Q04UDHCPU, Q04UDVCPU, Q04UDEHCPU,
Q06UDHCPU, Q06UDVCPU, Q06UDEHCPU, Q10UDHCPU, Q10UDEHCPU,
Q13UDHCPU, Q13UDVCPU, Q13UDEHCPU, Q20UDHCPU, Q20UDEHCPU,
Q26UDHCPU, Q26UDVCPU, Q26UDEHCPU, Q50UDEHCPU, and Q100UDEHCPU
Personal computer Generic term for DOS/V personal computer
Factory setting Generic term for analog input ranges 0 to 10V, 0 to 5V, 1 to 5V, -10 to 10V, 0 to 20mA
and 4 to 20mA
FB Abbreviation of function block.
Windows Vista®
Generic term for the following:
Microsoft®Windows Vista®Home Basic Operating System,
Microsoft®Windows Vista®Home Premium Operating System,
Microsoft®Windows Vista®Business Operating System,
Microsoft®Windows Vista®Ultimate Operating System,
Microsoft®Windows Vista®Enterprise Operating System
Windows®XP
Generic term for the following:
Microsoft®Windows®XP Professional Operating System,
Microsoft®Windows®XP Home Edition Operating System
Windows®7
Generic term for the following:
Microsoft®Windows®7 Starter Operating System,
Microsoft®Windows®7 Home Premium Operating System,
Microsoft®Windows®7 Professional Operating System,
Microsoft®Windows®7 Ultimate Operating System,
Microsoft®Windows®7 Enterprise Operating System
Note that the 32-bit version is designated as "32-bit Windows®7", and the 64-bit
version is designated as "64-bit Windows®7".

A-14 A-14
PRODUCT STRUCTURE
The product structure of this product is given in the table below.
(GX Configurator-AD is sold separately.)
Model code Product name Quantity
Q64AD Q64AD Model Analog-Digital Converter Module 1
Q68ADV Q68ADV Model Analog -Digital Converter Module 1
Q68ADI Q68ADI Model Analog -Digital Converter Module 1
The product structure of GX Configurator-AD is given in the table below.
Model code Product name Quantity
SW2D5C-QADU-E GX Configurator-AD Version 2 (1-license product) (CD-ROM) 1
SW2D5C-QADU-EA GX Configurator-AD Version 2 (Multiple-license product) (CD-ROM) 1

1 - 1
1-1
MELSEC-Q
1 OVERVIEW
1
1 OVERVIEW
This User's Manual describes the specifications, handling and programming methods
for the Q64AD analog-digital converter module (hereinafter referred to as the Q64AD),
Q68ADV analog-digital converter module (hereinafter referred to as the Q68ADV), and
Q68ADI analog-digital converter module (hereinafter referred to as the Q68ADI), which
are used in conjunction with MELSEC-Q Series CPUs.
In this manual, the Q64AD, Q68ADV, and Q68ADI are collectively referred to as the
A/D converter modules.
1.1 Features
(1) Select the type of module according to the application.
• Q64AD ........... 4 channels, where the voltage input or current input can be
selected for each channel.
• Q68ADV ........ 8 channels, all of which are voltage input.
• Q68ADI .......... 8 channels, all of which are current input.
(2) High speed conversion
Conversion is performed at a high speed of 80 s/channel. Also, the
temperature drift compensation function can be performed using a processing
time of "conversion time for all channels + 160 s".
(3) High degree of accuracy
The degree of accuracy for the conversion process is ± 0.1% (When the ambient
temperature is 25 ± 5 °C).
(4) Changing the resolution mode
The resolution mode can be changed according to the application, and digital-
value resolution settings of 1/4000, 1/12000 or 1/16000 can be selected.
(5) Changing the input range
The input range 1can easily be set from GX Developer.
1: Input range refers to the type of offset/gain settings. The most frequently
used range is set as the default but the user can also set the offset/gain.
(6) Easy settings with GX Configurator-AD
The number of sequence programs can be reduced since GX Configurator-AD
(sold separately) allows A/D converter module settings in the dialog box.
Also, GX Configurator-AD simplifies checking of the module settings and
operation status.
In addition, FB 1 can be automatically created from intelligent function module
parameters set in advance to use them in a sequence program.
1: FB is the function for making a circuit block used in a sequence program
repeatedly a part (FB) to use it in the sequence program.
This function can improve the efficiency of program development and
minimize program bugs to improve program qualities.
For details of FB, refer to "GX Developer Version 8 Operating Manual (Function
Block)."

1 - 2
1-2
MELSEC-Q
1 OVERVIEW
1
1.2 Functions Added to Function Version B and Later
(1) Functions added to function version B
The functions added by the function version B A/D converter module are listed
below.
Item Function overview Reference section
Multiple CPU system
compatibility
Compatible with a multiple CPU system. A programmable controller
CPU of function version B or later are required. Section 2.1
Resolution mode
The resolution mode can be changed according to the application, and
digital-value resolution settings of 1/4000, 1/12000 or 1/16000 can be
selected.
Section 3.2
High resolution mode
status flag (X8) This turns on when the high resolution mode is set. Section 3.3
Maximum value/minimum
value reset completed flag
(XD)
This signal turns on when the maximum and minimum values stored in
Maximum and minimum values storage area (buffer memory address
30 to 45: Un\G30 to Un\G45) are reset by Maximum value/minimum
value reset request (YD).
Section 3.3
(2) Functions added to function version C
The functions added to the A/D converter module of function version C are listed
below.
Item Function overview Reference section
Online module change You can change the module without stopping the system. A
programmable controller CPU of function version C or later is required. Chapter 7
Mode switching that does
not require programmable
controller CPU to be reset
Using Mode switching setting (buffer memory address 158, 159:
Un\G158, Un\G159) and Operating condition setting request (Y9), the
module is switched between the normal mode and offset/gain setting
mode without the programmable controller CPU being reset.
Section 3.4.13
Using the dedicated instruction (G(P).OFFGAN), the module is
switched between the normal mode and offset/gain setting mode
without the programmable controller CPU being reset.
Appendix 2.1
Using GX Configurator-AD, the module is switched between the normal
mode and offset/gain setting mode without the programmable controller
CPU being reset.
Section 5.6.2
POINT
(1) Refer to Appendix 1.1 for a comparison of functions of the function version.
(2) Refer to Section 2. 3 on how to check the function version.

2 - 1
2-1
MELSEC-Q
2 SYSTEM CONFIGURATION
2
2 SYSTEM CONFIGURATION
This chapter explains the system configuration of the A/D converter module.
2.1 Applicable Systems
This section describes applicable systems.
(1) Applicable modules and base units, and No. of modules
(a) When mounting to CPU module
For the applicable modules, the number of modules, and base units
applicable to the A/D converter module, refer to the user’s manual for the
CPU module used.
Note the following when the A/D converter module is mounted with a CPU
module.
• Depending on the combination with other modules or the number of
mounted modules, power supply capacity may be insufficient. Pay attention
to the power supply capacity before mounting modules, and if the power
supply capacity is insufficient, change the combination of modules.
• Mount a module within the number of I/O points for the CPU module. If the
number of slots is within the available range, the module can be mounted
on any slot.
Remark
When the module is used with a C Controller module, refer to the user’s manual for
the C Controller module.
(b) Mounting to a MELSECNET/H remote I/O station
For the MELSECNET/H remote I/O station, the number of modules, and
base units applicable to the A/D converter module, refer to the Q
Corresponding MELSECNET/H Network System Reference Manual
(Remote I/O network).
(2) Support of the multiple CPU system
When using the A/D converter module in a multiple CPU system, refer to the
following manual first.
• QCPU User's Manual (Multiple CPU System)
(3) Compatibility with online module change
To make an online module change, use the module of function version C or later.

2 - 2
2-2
2
(4) Supported software packages
Relation between the system containing the A/D converter modules and software
package is shown in the following table.
GX Developer or GX Works2 are necessary when using the A/D converter
module.
Software Version
GX Developer GX Configurator-AD 1GX Works2
Q00J/Q00/
Q01CPU
Single CPU system Version 7 or later Version 1.10L or later
(cannot be used with the
SW0D5C-QADU-E 50F
or earlier versions).
Refer to the GX Works2
Version 1 Operating
Manual (Common).
Multiple CPU system Version 8 or later
Q02/Q02H/
Q06H/ Q12H/
Q25HCPU
Single CPU system Version 4 or later SW0D5C-QADU-E 00A
or later
Multiple CPU system Version 6 or later SW0D5C-QADU-E 20C
or later
Q02PH/
Q06PHCPU
Single CPU system Version 8.68W or later Version 1.13P or later
(cannot be used with the
SW0D5C-QADU-E 50F
or earlier versions).
Multiple CPU system
Q12PH/
Q25PHCPU
Single CPU system Version 7.10L or later
Multiple CPU system
Q12PRH/
Q25PRHCPU Redundant System Version 8.45X or later Version 1.15R or later
Q00UJ/Q00U/
Q01UCPU
Single CPU system Version 8.78G or later
Version 2.05F or later
Multiple CPU system
Q02U/Q03UD/
Q04UDH/
Q06UDHCPU
Single CPU system
Version 8.48A or later
Multiple CPU system
Q10UDH/
Q20UDHCPU
Single CPU system Version 8.78G or later
Multiple CPU system
Q13UDH/
Q26UDHCPU
Single CPU system Version 8.62Q or later
Multiple CPU system
Q03UDE/
Q04UDEH/
Q06UDEH/
Q13UDEH/
Q26UDEHCPU
Single CPU system
Version 8.68W or later
Multiple CPU system
Q10UDEH/
Q20UDEHCPU
Single CPU system Version 8.78G or later
Multiple CPU system
CPU modules
other than the
above
Single CPU system
Cannot be used Cannot be used
Multiple CPU system
If installed in a MELSECNET/H remote
I/O station Version 6 or later SW0D5C-QADU-E 50F
or later
1: Refer to Appendix 1.2 for the combinations of the A/D converter module functions and GX
Configurator-AD software versions.
