Mitsubishi Electric MELSEC Q Series User manual

Loop Control Module User's Manual
-Q62HLC
-GX Configurator-TC (SW0D5C-QTCU-E)

A - 1 A - 1
 SAFETY PRECAUTIONS 
(Read these precautions before using this product.)
Before using this product, please read this manual carefully and pay full attention to safety to handle the
product correctly.
The precautions given in this manual are concerned with this product only.
For the safety precautions of the programmable controller system, refer to the user's manual for the CPU
module used.
In this manual, the safety precautions are classified into two levels: " ! WARNING" and " ! CAUTION".
Indicates that incorrect handling may cause hazardous conditions,
resulting in death or severe injury.
Indicates that incorrect handling may cause hazardous conditions,
resulting in minor or moderate injury or property damage.
Under some circumstances, failure to observe the precautions given under " ! CAUTION" may lead to
serious consequences.
Observe the precautions of both levels because they are important for personal and system safety.
Make sure that the end users read this manual and then keep the manual in a safe place for future
reference.
[Design Precautions]
! WARNING
 Do not write any data to the "system area" and "write-protect area" of the buffer memory in the
intelligent function module.
Also, do not use any "use prohibited" signals as input or output signals from the intelligent
function module to the CPU module.
Doing so may cause malfunction of the programmable controller system.
 Due to failure of the output element or internal circuit, normal output may not be obtained
correctly. Configure an external circuit for monitoring output signals that could cause a serious
accident.
! CAUTION
 Do not install the control lines or communication cables together with the main circuit lines or
power cables.
Keep a distance of 100mm or more between them.
Failure to do so may result in malfunction due to noise.
 At power-on or power-off, a current may flow between output terminals momentarily.
In this case, start the control after analog outputs become stable.
! WARNING
! CAUTION

A - 2 A - 2
[Security Precautions]
! WARNING
 To maintain the security (confidentiality, integrity, and availability) of the programmable controller
and the system against unauthorized access, denial-of-service (DoS) attacks, computer viruses,
and other cyberattacks from external devices via the network, take appropriate measures such
as firewalls, virtual private networks (VPNs), and antivirus solutions.
[Installation Precautions]
! CAUTION
 Use the programmable controller in an environment that meets the general specifications in the
user's manual for the CPU module used.
Failure to do so may result in electric shock, fire, malfunction, or damage to or deterioration of
the product.
 To mount the module, while pressing the module mounting lever located in the lower part of the
module, fully insert the module fixing projection(s) into the hole(s) in the base unit and press the
module until it snaps into place.
Incorrect mounting may cause malfunction, failure or drop of the module.
When using the programmable controller in an environment of frequent vibrations, fix the
module with a screw.
 If the screws are tightened too much, it may cause damage to the screw and/or the module,
resulting in fallout, short circuits or malfunction.
Tighten the screws within the specified torque range.
Undertightening can cause drop of the screw, short circuit or malfunction.
Overtightening can damage the screw and/or module, resulting in drop, short circuit, or
malfunction.
 Shut off the external power supply (all phases) used in the system before mounting or removing
the module.
Failure to do so may result in damage to the product. A module can be replaced online (while
power is on) on any MELSECNET/H remote I/O station or in the system where a CPU module
supporting the online module change function is used.
Note that there are restrictions on the modules that can be replaced online, and each module
has its predetermined replacement procedure.
For details, refer to the relevant chapter in this manual.
 Do not directly touch any conductive parts and electronic components of the module.
Doing so can cause malfunction or failure of the module.

A - 3 A - 3
[Wiring Precautions]
! CAUTION
 Prevent foreign matter such as dust or wire chips from entering the module. Such foreign matter
can cause a fire, failure, or malfunction.
 A protective film is attached to the top of the module to prevent foreign matter, such as wire
chips, from entering the module during wiring. Do not remove the film during wiring. Remove it
for heat dissipation before system operation.
 Place the cables in a duct or clamp them. If not, dangling cable may swing or inadvertently be
pulled, resulting in damage to the module or cables or malfunction due to poor contact.
 When disconnecting the cable from the module, do not pull the cable by the cable part. For the
cable connected to the terminal block, loosen the terminal screw. Pulling the cable connected to
the module may result in malfunction or damage to the module or cable.
 Individually ground the FG terminal and shielded cables of the programmable controller with a
ground resistance of 100 or less.
Failure to do so may result in electric shock or malfunction.
 After wiring, attach the included terminal cover to the module before turning it on for operation.
Failure to do so may result in electric shock.
 Use applicable solderless terminals and tighten them within the specified torque range.
If any spade solderless terminal is used, it may be disconnected when the terminal screw comes
loose, resulting in failure.
 Check the rated voltage and terminal layout before wiring to the module, and connect the cables
correctly.
Connecting a power supply with a different voltage rating or incorrect wiring may cause a fire or
failure.

A - 4 A - 4
[Startup and Maintenance Precautions]
! CAUTION
 Do not disassemble or modify the modules.
Doing so may cause failure, malfunction, injury, or a fire.
 Shut off the external power supply (all phases) used in the system before mounting or removing
the module.
Failure to do so may cause the module to fail or malfunction.
A module can be replaced online (while power is on) on any MELSECNET/H remote I/O station
or in the system where a CPU module supporting the online module change function is used.
Note that there are restrictions on the modules that can be replaced online, and each module
has its predetermined replacement procedure.
For details, refer to the relevant chapter in this manual.
 After the first use of the product, do not mount/remove the module to/from the base unit, and the
terminal block to/from the module more than 50 times (IEC 61131-2 compliant) respectively.
Exceeding the limit of 50 times may cause malfunction.
 Do not touch any terminal while power is on.
Failure to do so may cause malfunction.
 Shut off the external power supply (all phases) used in the system before cleaning the module or
retightening the terminal screws or module fixing screws.
Failure to do so may cause the module to fail or malfunction.
Undertightening can cause drop of the screw, short circuit or malfunction.
Overtightening can damage the screw and/or module, resulting in drop, short circuit, or
malfunction.
 Before handling the module, touch a grounded metal object to discharge the static electricity
from the human body.
Failure to do so may cause the module to fail or malfunction.
[Disposal Precaution]
! CAUTION
 When disposing of the product, handle it as industrial waste.

A - 5 A - 5
 CONDITIONS OF USE FOR THE PRODUCT 
(1) MELSEC programmable controller ("the PRODUCT") shall be used in conditions;
i) where any problem, fault or failure occurring in the PRODUCT, if any, shall not lead to any major or
serious accident; and
ii) where the backup and fail-safe function are systematically or automatically provided outside of the
PRODUCT for the case of any problem, fault or failure occurring in the PRODUCT.
(2) The PRODUCT has been designed and manufactured for the purpose of being used in general
industries.
MITSUBISHI ELECTRIC SHALL HAVE NO RESPONSIBILITY OR LIABILITY (INCLUDING, BUT
NOT LIMITED TO ANY AND ALL RESPONSIBILITY OR LIABILITY BASED ON CONTRACT,
WARRANTY, TORT, PRODUCT LIABILITY) FOR ANY INJURY OR DEATH TO PERSONS OR
LOSS OR DAMAGE TO PROPERTY CAUSED BY the PRODUCT THAT ARE OPERATED OR
USED IN APPLICATION NOT INTENDED OR EXCLUDED BY INSTRUCTIONS, PRECAUTIONS,
OR WARNING CONTAINED IN MITSUBISHI ELECTRIC USER'S, INSTRUCTION AND/OR
SAFETY MANUALS, TECHNICAL BULLETINS AND GUIDELINES FOR the PRODUCT.
("Prohibited Application")
Prohibited Applications include, but not limited to, the use of the PRODUCT in;
 Nuclear Power Plants and any other power plants operated by Power companies, and/or any other
cases in which the public could be affected if any problem or fault occurs in the PRODUCT.
 Railway companies or Public service purposes, and/or any other cases in which establishment of a
special quality assurance system is required by the Purchaser or End User.
 Aircraft or Aerospace, Medical applications, Train equipment, transport equipment such as Elevator
and Escalator, Incineration and Fuel devices, Vehicles, Manned transportation, Equipment for
Recreation and Amusement, and Safety devices, handling of Nuclear or Hazardous Materials or
Chemicals, Mining and Drilling, and/or other applications where there is a significant risk of injury to
the public or property.
Notwithstanding the above restrictions, Mitsubishi Electric may in its sole discretion, authorize use of
the PRODUCT in one or more of the Prohibited Applications, provided that the usage of the
PRODUCT is limited only for the specific applications agreed to by Mitsubishi Electric and provided
further that no special quality assurance or fail-safe, redundant or other safety features which exceed
the general specifications of the PRODUCTs are required. For details, please contact the Mitsubishi
Electric representative in your region.
(3) Mitsubishi Electric shall have no responsibility or liability for any problems involving programmable
controller trouble and system trouble caused by DoS attacks, unauthorized access, computer viruses,
and other cyberattacks.

A - 6 A - 6
REVISIONS
* The manual number is given on the bottom left of the back cover.
Print Date Manual Number Revision
Aug., 2005 SH (NA)-080573ENG-A First edition
Jan., 2008 SH (NA)-080573ENG-B Correction
SAFETY PRECAUTION, CONTENTS, ABOUT THE GENERIC
TERMS AND ABBREVIATIONS, Chapter 1, Section 1.1, 2.1 to
2.3, 3.1.1, 3.2, 3.2.1, 3.2.10, 3.2.13, 3.5.1, 3.5.3, 3.5.14, 3.5.15,
3.5.49, 3.5.50, 3.5.57, 3.5.65, 5.1, 5.2.2, 6.2.1, 6.2.2, 8.1, INDEX
Apr., 2008 SH (NA)-080573ENG-C Correction
COMPLIANCE WITH THE EMC AND LOW VOLTAGE
DIRECTIVES, Section 2.1, 2.3, 3.1.1, 3.2.10, 3.2.16, 3.5.15,
3.5.46, 3.5.47, 3.5.64, 4.5, 5.2.1, 5.3.3, 5.4, 5.5, 6.2, 6.3, 7.1, 8.1,
8.13
Addition
Appendix 2
May, 2008 SH (NA)-080573ENG-D Correction
SAFETY PRECAUTIONS, ABOUT THE GENERIC TERMS AND
ABBREVIATIONS, Section 2.1, 2.3, 4.1, 5.2.1, 5.3.1, 5.3.3,
Chapter 7, Section 7.1
Feb., 2011 SH (NA)-080573ENG-E Correction
SAFETY PRECAUTIONS, ABOUT THE GENERIC TERMS AND
ABBREVIATIONS, Section 1.1, 2.1 to 2.3, 3.1.1, 3.2.15, 3.5.1,
3.5.11, 3.5.14, 3.5.15, 3.5.55, 4.1, 4.3, 4.4.1, 4.4.2, 5.2.1, 5.4 to
5.6, 6.3.1, 6.3.2, 7.3.1, 7.3.2, 8.2, 8.13, Appendix 1, WARRANTY
Addition
CONDITIONS OF USE FOR THE PRODUCT
Apr., 2012 SH (NA)-080573ENG-F Correction
SAFETY PRECAUTIONS, COMPLIANCE WITH EMC AND LOW
VOLTAGE DIRECTIVES, ABOUT THE GENERIC TERMS AND
ABBREVIATIONS, PRODUCT STRUCTURE, Chapter 1, Section
1.1, 1.2, 1.3, 1.3.1, 1.3.2, 1.3.3, 1.3.4, 1.3.5, 1.3.6, 2.1, 2.2, 2.3,
3.2, 3.2.1, 3.2.9, 3.2.12, 3.2.19, 3.4.1, 3.5.1, 3.5.5, 3.5.8, 3.5.9,
3.5.11, 3.5.14, 3.5.21, 3.5.28, 3.5.37, 3.5.44, 3.5.61, 3.5.62,
3.5.64, 3.5.65, 3.5.66, 3.5.67, 3.5.68, Chapter 4, Section 4.1, 4.2,
4.3, 4.4.1, 4.4.2, 4.5, 5.1, 5.2.1, 5.2.2, 5.3.1, 5.3.2, 5.4, 5.5, 5.6,
6.2, 6.2.1, 6.2.2, 6.3, 6.3.1, 6.3.2, Chapter 7, Section 7.1, 7.2,
7.3.1, 7.3.2, 7.4, 7.4.1, 7.4.2, 7.4.3, 8.1, 8.2, 8.3, 8.4, 8.5, 8.6, 8.7,
8.8, 8.9, 8.10, 8.11, 8.12, 8.13, Appendix 1, Appendix 2
Addition
Section 3.2.15, 3.2.16, 3.2.18, 3.5.50, 3.5.51, 3.5.52, 3.5.63,
3.5.69

A - 7 A - 7
* The manual number is given on the bottom left of the back cover.
Print Date Manual Number Revision
Dec., 2012 SH (NA)-080573ENG-G Correction
COMPLIANCE WITH EMC AND LOW VOLTAGE DIRECTIVES,
Section 2.1, 3.2.9, 3.2.12, 3.2.13, 3.5.13, 3.5.28, 3.5.67, 3.5.68,
3.5.69, 8.13
Oct., 2020 SH (NA)-080573ENG-H Correction
SAFETY PRECAUTIONS, CONDITIONS OF USE FOR THE
PRODUCT, ABOUT THE GENERIC TERMS AND
ABBREVIATIONS, Section 1.3.1, 1.3.5, 2.1, 2.3, 3.1.1, 3.5.14, 4.3,
Appendix 1, WARRANTY
Japanese Manual Version SH-080547-H
This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent
licenses. Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property
rights which may occur as a result of using the contents noted in this manual.
 2005 MITSUBISHI ELECTRIC CORPORATION

A - 8 A - 8
INTRODUCTION
Thank you for purchasing the Mitsubishi Electric MELSEC-Q series programmable controller.
Before using the equipment, please read this manual carefully to develop full familiarity with the functions
and performance of the Q series programmable controller you have purchased, so as to ensure correct use.
CONTENTS
SAFETY PRECAUTIONS ............................................................................................................................. A- 1
CONDITIONS OF USE FOR THE PRODUCT ............................................................................................. A- 5
REVISIONS .................................................................................................................................................... A- 6
INTRODUCTION ............................................................................................................................................ A- 8
CONTENTS .................................................................................................................................................... A- 8
COMPLIANCE WITH EMC AND LOW VOLTAGE DIRECTIVES ............................................................... A-13
ABOUT THE GENERIC TERMS AND ABBREVIATIONS ........................................................................... A-14
PRODUCT STRUCTURE .............................................................................................................................. A-14
1 OVERVIEW 1- 1 to 1-11
1.1 Features ................................................................................................................................................... 1- 2
1.2 PID Control System ................................................................................................................................. 1- 5
1.3 PID Operation........................................................................................................................................... 1- 6
1.3.1 Operation method and formula ......................................................................................................... 1- 6
1.3.2 Actions in the Q62HLC ..................................................................................................................... 1- 7
1.3.3 Proportional action (P-action) ........................................................................................................... 1- 8
1.3.4 Integral action (I-action) .................................................................................................................... 1- 9
1.3.5 Derivative action (D-action) ............................................................................................................... 1-10
1.3.6 PID action .......................................................................................................................................... 1-11
2 SYSTEM CONFIGURATION 2- 1 to 2- 8
2.1 Applicable Systems .................................................................................................................................. 2- 1
2.2 For Using the Q62HLC with Redundant CPUs ....................................................................................... 2- 5
2.3 Checking Function Version, Production Information, Serial Number, and Software Version ............... 2- 6
3 SPECIFICATIONS 3- 1 to 3-115
3.1 Performance Specifications ..................................................................................................................... 3- 1
3.1.1 Performance specifications of the Q62HLC ..................................................................................... 3- 1
3.1.2 Operation at input disconnection ...................................................................................................... 3- 5
3.2 Functions .................................................................................................................................................. 3- 6
3.2.1 Auto tuning function .......................................................................................................................... 3- 7
3.2.2 Auto tuning setting function ............................................................................................................... 3-12
3.2.3 Reverse/forward action select function ............................................................................................ 3-13
3.2.4 RFB limiter function ........................................................................................................................... 3-13
3.2.5 Sensor compensation function ......................................................................................................... 3-13
3.2.6 Unused channel setting function ...................................................................................................... 3-14
3.2.7 Forced PID control stop function ...................................................................................................... 3-14
3.2.8 Loop disconnection detection function ............................................................................................. 3-15
3.2.9 Data storage in FeRAM function ...................................................................................................... 3-16

A - 9 A - 9
3.2.10 Alert function .................................................................................................................................... 3-18
3.2.11 Control output setting at CPU stop error occurrence function ....................................................... 3-23
3.2.12 Program control function ................................................................................................................. 3-24
3.2.13 Cascade control function ................................................................................................................ 3-37
3.2.14 Scaling function ............................................................................................................................... 3-39
3.2.15 SV tracking function ........................................................................................................................ 3-41
3.2.16 Forced output function .................................................................................................................... 3-44
3.2.17 Simplified analog I/O function ......................................................................................................... 3-48
3.2.18 Parameter change in program control function .............................................................................. 3-49
3.2.19 Q62HLC control status controlling output signal and buffer memory settings and control status
......................................................................................................................................................... 3-52
3.3 Sampling Period ....................................................................................................................................... 3-56
3.4 I/O Signals Transferred to/from the Programmable Controller CPU ...................................................... 3-57
3.4.1 I/O signals .......................................................................................................................................... 3-57
3.4.2 Input signal functions ........................................................................................................................ 3-58
3.4.3 Output signal functions ...................................................................................................................... 3-62
3.5 Buffer Memory .......................................................................................................................................... 3-65
3.5.1 Buffer memory areas ......................................................................................................................... 3-65
3.5.2 Error code (buffer memory address 0: Un\G0) ................................................................................ 3-76
3.5.3 Alert definition (buffer memory address 5, 6: Un\G5, Un\G6) ......................................................... 3-77
3.5.4 Measured value (PV) (buffer memory address 9, 10: Un\G9, Un\G10) .......................................... 3-77
3.5.5 Manipulated value (MV) (buffer memory address 13, 14: Un\G13, Un\G14) ................................. 3-78
3.5.6 Approach flag (buffer memory address 17, 18: Un\G17, Un\G18) .................................................. 3-78
3.5.7 Set value monitor (buffer memory address 25, 26: Un\G25, Un\G26) ............................................
3-78
3.5.8 Cold junction temperature measured value (buffer memory address 29: Un\G29) ........................ 3-78
3.5.9 Control mode monitor (buffer memory address 30: Un\G30) .......................................................... 3-79
3.5.10 PID constant read/write completion flag from FeRAM (buffer memory address 31: Un\G31) ..... 3-80
3.5.11 Input range (buffer memory address 32, 64: Un\G32, Un\G64) .................................................... 3-82
3.5.12 Stop mode setting (buffer memory address 33, 65: Un\G33, Un\G65) ......................................... 3-84
3.5.13 Set value (SV) setting (buffer memory address 34, 66: Un\G34, Un\G66) ................................... 3-84
3.5.14 PID constant setting
(buffer memory address 35 to 37, 67 to 69: Un\G35 to Un\G37, Un\G67 to Un\G69) ................. 3-85
3.5.15 Alert set value 1 to 4
(buffer memory address 38 to 41, 70 to 73: Un\G38 to Un\G41, Un\G70 to Un\G73) ................. 3-87
3.5.16 Upper/lower output limiter
(buffer memory address 42, 43, 74, 75: Un\G42, Un\G43, Un\G74, Un\G75).............................. 3-87
3.5.17 Output variation limiter (buffer memory address 44, 76: Un\G44, Un\G76) .................................. 3-88
3.5.18 Sensor compensation value setting (buffer memory address 45, 77: Un\G45, Un\G77) ............. 3-88
3.5.19 AT differential gap (buffer memory address 46, 78: Un\G46, Un\G78) ........................................ 3-89
3.5.20 AT additional lag (buffer memory address 47, 79: Un\G47, Un\G79) ........................................... 3-89
3.5.21 Primary delay digital filter setting (buffer memory address 48, 80: Un\G48, Un\G80) ................. 3-90
3.5.22 Control response parameter (buffer memory address 49, 81: Un\G49, Un\G81) ........................ 3-91
3.5.23 Control mode (buffer memory address 50, 82: Un\G50, Un\G82) ................................................ 3-92
3.5.24 MAN output setting (buffer memory address 51, 83: Un\G51, Un\G83) ....................................... 3-93
3.5.25 Setting change rate limiter (buffer memory address 52, 84: Un\G52, Un\G84) ............................ 3-93
3.5.26 AT bias (buffer memory address 53, 85: Un\G53, Un\G85) .......................................................... 3-94
3.5.27 Forward/reverse action setting (buffer memory address 54, 86: Un\G54, Un\G86) ..................... 3-94

A - 10 A - 10
3.5.28 Upper/lower setting limiter
(buffer memory address 55, 56, 87, 88: Un\G55, Un\G56, Un\G87, Un\G88).............................. 3-95
3.5.29 Program control run/reset (buffer memory address 57, 89: Un\G57, Un\G89) ............................. 3-95
3.5.30 Loop disconnection detection judgment time
(buffer memory address 59, 91: Un\G59, Un\G91) ........................................................................ 3-96
3.5.31 Loop disconnection detection dead band
(buffer memory address 60, 92: Un\G60, Un\G92) ........................................................................ 3-96
3.5.32 Unused channel setting (buffer memory address 61, 93: Un\G61, Un\G93) ................................ 3-97
3.5.33 PID constant read command from FeRAM
(buffer memory address 62, 94: Un\G62, Un\G94) ........................................................................ 3-97
3.5.34 Automatic backup setting after auto tuning of PID constants
(buffer memory address 63, 95: Un\G63, Un\G95) ........................................................................ 3-98
3.5.35 Alert dead band setting (buffer memory address 164: Un\G164) ................................................. 3-98
3.5.36 Alert delay count (buffer memory address 165: Un\G165) ............................................................ 3-98
3.5.37 Approach range setting (buffer memory address 167: Un\G167) ................................................. 3-99
3.5.38 Approach soak time setting (buffer memory address 168: Un\G168) ........................................... 3-99
3.5.39 PID continuation flag (buffer memory address 169: Un\G169) ..................................................... 3-99
3.5.40 Cascade ON/OFF (buffer memory address 176: Un\G176) .......................................................... 3-99
3.5.41 Cascade gain (buffer memory address 177: Un\G177) ............................................................... 3-100
3.5.42 Cascade bias (buffer memory address 178: Un\G178) ............................................................... 3-100
3.5.43 Cascade monitor (buffer memory address 179: Un\G179) ......................................................... 3-100
3.5.44 Alert 1 to 4 mode setting (buffer memory address 192 to 195, 208 to 211:
Un\G192 to Un\G195, Un\G208 to Un\G211) .............................................................................. 3-101
3.5.45 Scaling value (buffer memory address 196, 212: Un\G196, Un\G212) ...................................... 3-101
3.5.46 Scaling range upper/lower limit value
(buffer memory address 197, 198, 213, 214: Un\G197, Un\G198, Un\G213, Un\G214) ........... 3-102
3.5.47 Scaling width upper/lower limit value
(buffer memory address 199, 200, 215, 216: Un\G199, Un\G200, Un\G215, Un\G216) ........... 3-102
3.5.48 Hold command (buffer memory address 201, 217: Un\G201, Un\G217) ................................... 3-103
3.5.49 Command advancing (buffer memory address 202, 218: Un\G202, Un\G218)
......................... 3-104
3.5.50 SV tracking setting (buffer memory address 203, 219: Un\G203, Un\G219) ............................. 3-104
3.5.51 Forced output command (buffer memory address 204, 220: Un\G204, Un\G220) .................... 3-105
3.5.52 Forced output manipulated value (MV)
(buffer memory address 205, 221: Un\G205, Un\G221) ............................................................. 3-105
3.5.53 Segment monitor (buffer memory address 256, 512: Un\G256, Un\G512) ................................ 3-105
3.5.54 Segment remaining time (buffer memory address 257, 513: Un\G257, Un\G513) .................... 3-105
3.5.55 Execution times monitor (buffer memory address 258, 514: Un\G258, Un\G514) ..................... 3-106
3.5.56 Pattern end output flag (buffer memory address 259, 515: Un\G259, Un\G515) ....................... 3-106
3.5.57 End status flag (buffer memory address 260, 516: Un\G260, Un\G516) .................................... 3-106
3.5.58 Wait status flag (buffer memory address 261, 517: Un\G261, Un\G517) ................................... 3-106
3.5.59 Hold status flag (buffer memory address 262, 518: Un\G262, Un\G518) ................................... 3-106
3.5.60 Advancing completion flag (buffer memory address 263, 519: Un\G263, Un\G519) ................. 3-107
3.5.61 Execution pattern monitor (buffer memory address 264, 520: Un\G264, Un\G520) .................. 3-107
3.5.62 Zone PID monitor (buffer memory address 265, 521: Un\G265, Un\G521) ............................... 3-107
3.5.63 Forced output status flag (buffer memory address 266, 522: Un\G266, Un\G522) ................... 3-107
3.5.64 Execution pattern (buffer memory address 272, 528: Un\G272, Un\G528) ............................... 3-108
3.5.65 Start mode (buffer memory address 273, 529: Un\G273, Un\G529) .......................................... 3-108
3.5.66 Time scale (buffer memory address 274, 530: Un\G274, Un\G530) .......................................... 3-109

A - 11 A - 11
3.5.67 Zone setting (buffer memory address 275 to 313, 531 to 569:
Un\G275 to Un\G313, Un\G531 to Un\G569) .............................................................................. 3-109
3.5.68 Program pattern (buffer memory address 320 to 500, 576 to 756:
Un\G320 to Un\G500, Un\G576 to Un\G756) .............................................................................. 3-111
3.5.69 Set value at program control start (SV_PCS) setting
(buffer memory address: 501, 757: Un\G501, Un\G757) ............................................................ 3-115
4 PROCEDURES AND SETTINGS BEFORE SYSTEM OPERATION 4- 1 to 4- 9
4.1 Handling Precautions ............................................................................................................................... 4- 1
4.2 Procedures before Operation .................................................................................................................. 4- 2
4.3 Part Names .............................................................................................................................................. 4- 3
4.4 Wiring ........................................................................................................................................................ 4- 5
4.4.1 Wiring precautions............................................................................................................................. 4- 5
4.4.2 External wiring ................................................................................................................................... 4- 6
4.5 Intelligent Function Module Switch Setting ............................................................................................. 4- 8
5 UTILITY PACKAGE (GX Configurator-TC) 5- 1 to 5-23
5.1 Utility Package Functions ........................................................................................................................ 5- 1
5.2 Installing and Uninstalling the Utility Package ........................................................................................ 5- 4
5.2.1 Handling precautions ........................................................................................................................ 5- 4
5.2.2 Operating environment ..................................................................................................................... 5- 6
5.3 Utility Package Operation ........................................................................................................................ 5- 8
5.3.1 Common utility package operations ................................................................................................. 5- 8
5.3.2 Operation overview ........................................................................................................................... 5-10
5.3.3 Starting the intelligent function module utility ................................................................................... 5-12
5.4 Initial Settings ........................................................................................................................................... 5-14
5.5 Auto Refresh ............................................................................................................................................ 5-18
5.6 Monitoring/Test ........................................................................................................................................ 5-20
6 PROGRAMMING 6- 1 to 6-49
6.1 Programming Procedure .......................................................................................................................... 6- 1
6.2 For Use in Normal System Configuration ............................................................................................... 6- 2
6.2.1 Program example using the utility package ..................................................................................... 6- 5
6.2.2 Program example without using the utility package ......................................................................... 6-10
6.3 For Use on Remote I/O Network ............................................................................................................. 6-20
6.3.1 Program example using the utility package ..................................................................................... 6-23
6.3.2 Program example without using the utility package ......................................................................... 6-34
7 ONLINE MODULE CHANGE 7- 1 to 7-17
7.1 Online Module Change Conditions.......................................................................................................... 7- 2
7.2 Operations When an Online Module Change is Performed ................................................................... 7- 3
7.3 Online Module Change Procedure .......................................................................................................... 7- 4
7.3.1 When GX Configurator-TC is used for the initial setting .................................................................. 7- 4
7.3.2 When a sequence program is used for the initial setting ................................................................. 7- 9

A - 12 A - 12
7.4 Precautions for Online Module Change .................................................................................................. 7-14
7.4.1 Precautions before module change .................................................................................................. 7-14
7.4.2 Precautions after module change ..................................................................................................... 7-16
7.4.3 Precautions depending on parameter setting method ..................................................................... 7-17
8 TROUBLESHOOTING 8- 1 to 8-10
8.1 Error Codes .............................................................................................................................................. 8- 1
8.2 Processing Performed by the Q62HLC at Error Occurrence ................................................................. 8- 4
8.3 When the RUN LED Flashes or Turns Off .............................................................................................. 8- 5
8.4 When the ERR. LED Turns On or Flashes ............................................................................................. 8- 5
8.5 When the ALM LED Turns On or Flashes .............................................................................................. 8- 6
8.6 When Watchdog Timer Error Flag (Xn0) Is On ....................................................................................... 8- 6
8.7 When Error Flag (Xn2) Is On ................................................................................................................... 8- 6
8.8 When Module Ready Flag (Xn3) Does Not Turn On .............................................................................. 8- 7
8.9 When FeRAM Write Failure Flag (XnA) Is On ........................................................................................ 8- 7
8.10 When Auto Tuning Does Not Start
(When Auto Tuning Status Flag (Xn4, Xn5) Does Not Turn On)........................................................... 8- 7
8.11 When Auto Tuning Does Not Complete
(When Auto Tuning Status Flag (Xn4, Xn5) Remains to Be On and Does Not Turn Off) .................... 8- 7
8.12 When Alert Flag (XnC and XnD) is On.................................................................................................. 8- 8
8.13 Checking the Q62HLC Status by System Monitor of GX Developer ................................................... 8- 9
APPENDICES Appendix- 1 to Appendix- 3
Appendix 1 External Dimensions ...................................................................................................... Appendix- 1
Appendix 2 New Functions of the Q62HLC ..................................................................................... Appendix- 2
INDEX Index- 1 to Index- 3

A - 13 A - 13
COMPLIANCE WITH EMC AND LOW VOLTAGE DIRECTIVES
(1) Method of ensuring compliance
To ensure that Mitsubishi programmable controllers maintain EMC and Low
Voltage Directives when incorporated into other machinery or equipment, certain
measures may be necessary. Please refer to one of the following manuals.
• QCPU User's Manual (Hardware Design, Maintenance and Inspection)
• Safety Guidelines
(This manual is included with the CPU module or base unit.)
The CE mark on the side of the programmable controller indicates compliance
with EMC and Low Voltage Directives.
(2) Additional measures
The following wiring is required for the compliance of this product with the EMC
and Low Voltage Directives.
(a) Use shielded cables for all external wiring and ground them to the control
panel with the AD75CK cable clamp.
(b) Four cables can be grounded together with the AD75CK cable clamp when
the diameter of each cable is approximately 7mm (0.28 inch).

A - 14 A - 14
ABOUT THE GENERIC TERMS AND ABBREVIATIONS
Unless otherwise specified, this manual uses the following generic terms and
abbreviations to describe the Loop control module.
Generic term/abbreviation Description
Personal computer DOS/V-compatible personal computer of IBM PC/AT R or its compatible
GX Developer Product name of MELSEC programmable controller software package
GX Works2
QCPU (Q mode)
Generic term of the Q00JCPU, Q00CPU, Q01CPU, Q02CPU, Q02HCPU, Q06HCPU,
Q12HCPU, Q25HCPU, Q02PHCPU, Q06PHCPU, Q12PHCPU, Q25PHCPU,
Q12PRHCPU, Q25PRHCPU, Q00UJCPU, Q00UCPU, Q01UCPU, Q02UCPU,
Q03UDCPU, Q04UDHCPU, Q06UDHCPU, Q10UDHCPU, Q13UDHCPU,
Q20UDHCPU, Q26UDHCPU, Q03UDECPU, Q04UDEHCPU, Q06UDEHCPU,
Q10UDEHCPU, Q13UDEHCPU, Q20UDEHCPU, Q26UDEHCPU, Q50UDEHCPU
and Q100UDEHCPU
Process CPU Generic term of the Q02PHCPU, Q06PHCPU, Q12PHCPU and Q25PHCPU
Redundant CPU Generic term for the Q12PRHCPU and Q25PRHCPU
GX Configurator-TC Generic term of temperature control module setting/monitoring tool GX Configurator-
TC(SW0D5C-QTCU-E)
Q62HLC Abbreviation of Type Q62HLC loop control module
PRODUCT STRUCTURE
The product structure of the product is given in the table below.
Model Product Quantity
Q62HLC Type Q62HLC loop control module 1
SW0D5C-QTCU-E GX Configurator-TC Version 1 (Single license product) (CD-ROM) 1
SW0D5C-QTCU-EA GX Configurator-TC Version 1 (Volume license product) (CD-ROM) 1

1 - 1 1 - 1
MELSEC-Q
1 OVERVIEW
1 OVERVIEW
This manual describes the specifications, handling, wiring, and programming of the
loop control module Q62HLC (hereinafter abbreviated as Q62HLC) that is used with
the MELSEC-Q series programmable controller CPU.
(1) About Q62HLC
(a) The Q62HLC is intelligent function module for the continuous proportional
control.
The Q62HLC converts analog input from various external sensors
(temperature, humidity, pressure, and flow rate) into a measured value (16-bit
signed binary data), performs PID operations to attain the target set value,
and outputs the calculated manipulated value to external operation devices
with current output.
(b) The Q62HLC has the following five control functions.
• Normal control (Normal control mode)
• Program control (Program control mode)
• Cascade control
• Manual control (Manual control mode 1)
• Manual control (Manual control mode 2)
(c) The Q62HLC automatically sets the proportional band (P), integral time (I),
and derivative time (D) for PID operations using the auto tuning function.
(d) Thermocouples (K, J, T, B, S, E, R, N, PLII, and W5Re/W26Re type) and
sensors compatible with the input ranges of micro voltage, voltage, and
current can be connected to the Q62HLC.
Fig. 1.1 Processing outline of the Q62HLC
1

1 - 2 1 - 2
MELSEC-Q
1 OVERVIEW
1.1 Features
The Q62HLC has the following features.
(1) High speed PID control
The Q62HLC is an intelligent function module that performs the continuous
proportional control.
With the Q62HLC, the high speed sampling cycle (25ms), analog input
(thermocouple, micro voltage, voltage, and current) with high accuracy and
resolution, and the current output are available.
This enables the control that requires high-speed response, such as the high-
speed rising and falling temperature control, pressure control and flow rate
control.
(2) Optimum PID control
(a) The Q62HLC automatically performs PID control by setting the PID constants
(proportional band (P), integral time (I), derivative time (D)) and the set value
(SV) required for PID operations.
No special instruction is required to perform PID control.
(b) Five control functions are available for the Q62HLC. The Q62HLC can select
the most suitable control function for the control target.
1) Normal mode (Normal control mode)
: The Q62HLC controls the control target using the manipulated values
calculated in PID operations as the control output.
2) Program control (Program control mode)
: The Q62HLC changes the set values automatically and performs the
control, following the set program pattern. The manipulated value
calculated in PID operations is used as the control output.
3) Cascade control
: The Q62HLC performs the control using the channel 1 as master and the
channel 2 as slave.
4) Manual control (Manual control mode 1)
: The Q62HLC controls the control target using the numerical value written
in the manual output setting (-5.0 to 105.0%) as the control output.
5) Manual control (Manual control mode 2)
: The Q62HLC controls the control target using the numerical value written
in the manual output setting (0 to 4000) as the control output.
This mode is for the simplified analog I/O function.
(c) The Q62HLC automatically set PID constants by using the auto tuning
function in normal control mode.
This enables the use of PID constants without considering cumbersome PID
operation expressions (refer to Section 3.2.1).
1

1 - 3 1 - 3
MELSEC-Q
1 OVERVIEW
(3) Connection of thermocouples compatible with JIS, IEC, NBS and
ASTM Standards
(a) Thermocouples compatible with the JIS, IEC, NBS, and ASTM Standards can
be connected to the Q62HLC.
• JIS Standards : R, K, J, S, B, E, T • IEC Standards: R, K, J, S, B, E, T, N
• NBS Standards : PL II • ASTM Standards: W5Re, W26Re
(4) Connection of sensors compatible with the input ranges of micro
voltage, voltage and current
Analog input of the following ranges can be measured using the micro voltage,
voltage, and current input sensors.
• Micro voltage : 0 to 10mV, 0 to 100mV, -10 to 10mV, -100 to 100mV
• Voltage : 0 to 1V, 1 to 5V, 0 to 5V, 0 to 10V, -1 to 1V, -5 to 5 V, -10 to 10V
• Current : 4 to 20mA, 0 to 20mA
(5) RFB limiter function
The RFB (reset feed back) limiter suppresses overshooting that may occur at a
start-up or when the set value (SV) is increased (refer to Section 3.2.4).
(6) Sensor compensation function
By setting a sensor compensation value, a difference, if any, between the
measured value (PV) and actual temperature, humidity, pressure, flow rate, or
others can be eliminated (refer to Section 3.2.5).
(7) Program control function
The control can be performed automatically, changing the set value (SV) and PID
constants (proportional band (P), integral time (I), derivative time (D)) by setting a
program pattern (refer to Section 3.2.12).
(8) Cascade control function
The cascade control can be performed using the channel 1 as master and the
channel 2 as slave (refer to Section 3.2.13).
(9) Scaling function
The scaled measured value (PV) can be automatically stored in the buffer
memory (refer to Section 3.2.14).
(10) Simplified analog I/O function
The Q62HLC can be used as a simplified thermocouple/micro voltage input
module, analog-digital conversion module, or digital-analog conversion module
by monitoring the measured value and setting the manipulated value manually
(refer to Section 3.2.17).
(11) Auto tuning mode setting function
The auto tuning mode according to a control target can be specified by setting
AT differential gap and AT additional lag (refer to Section 3.2.2).

1 - 4 1 - 4
MELSEC-Q
1 OVERVIEW
(12) Online module change function
The Q62HLC can be replaced without the system being stopped (refer to
Chapter 7).
(13) Storing setting values in FeRAM
The setting data in the buffer memory can be stored into FeRAM for backup.
When the data is directly written to the buffer memory using the test functions of
GX Developer, the sequence program required is only "LD " + "OUT Yn1"
(refer to Section 3.2.9).
(14) Easy settings with GX Configurator-TC
The number of sequence programs can be reduced by using GX Configurator-
TC (sold separately) because the settings for the loop control module can be
configured on the screen.
In addition, the setting status and operating status of the module can be checked
easily with GX Configurator-TC.
