Mitsubishi Electric AJ61BT11 User manual

User’s Manual
(Hardware)
AJ61BT11
A1SJ61BT11
Thank you for buying the general-purpose programmable controller
MELSEC-A Series.
© 2000 MITSUBISHI ELECTRIC CORPORATION
CC-Link
System Master/Local Module
Prior to use, please read both this manual and detailed manual
thoroughly and familiarize yourself with the product.
MODEL AJ61BT11-U-H-JE
MODEL
CODE 13JT18
IB(NA)-0800146-F(1612)MEE

A-1
SAFETY PRECAUTIONS
(Read these precautions before using this product.)
Before using this product, please read this manual and the relevant manuals
carefully and pay full attention to safety to handle the product correctly.
In this manual, the safety precautions are classified into two levels:
" WARNING" and " CAUTION".
Under some circumstances, failure to observe the precautions given under
" CAUTION" may lead to serious consequences.
Observe the precautions of both levels because they are important for personal
and system safety.
Make sure that the end users read this manual and then keep the manual in a safe
place for future reference.
[DESIGN PRECAUTIONS]
WARNING
For the operating status of each station after a data link failure, refer to
Chapter 5 in the user's manual.
The master station or local station cannot detect errors when a station
specified as an error-invalidated station becomes communication error.
CAUTION
Do not install the control lines or communication cables together with main
circuit lines or power cables. Keep a distance of 100mm (3.94 inches) or
more between them. Failure to do so may result in malfunction due to noise.
WARNING
Indicates that incorrect handling may cause
hazardous conditions, resulting in death or severe
injury.
Indicates that incorrect handling may cause
hazardous conditions, resulting in minor or moderate
injury or property damage.
CAUTION

A-2
[INSTALLATION PRECAUTIONS]
[WIRING PRECAUTIONS]
CAUTION
Use the programmable controller in an environment that meets the
specifications in the user's manual of the CPU module used.
Failure to do so may result in electric shock, fire, malfunction, or damage to
or deterioration of the product.
Insert the tabs at the bottom of the module into the holes in the base unit
before mounting the module.
(For the AnS series modules, tighten the screws to the base unit with the
specified torque.)
Incorrect mounting may cause malfunction, failure, or drop of the module.
Shut off the external power supply for the system in all phases before
mounting or removing the module.
Failure to do so may result in damage to the product.
Do not directly touch any conductive part of the module.
Doing so can cause malfunction or failure of the module.
WARNING
Shut off the external power supply for the system in all phases before wiring.
Failure to do so may result in electric shock or damage to the product.
After wiring, attach the included terminal cover to the module before turning it
on for operation.
Failure to do so may result in malfunction.

A-3
[WIRING PRECAUTIONS]
CAUTION
Tighten the terminal screws within the specified torque range.
Undertightening can cause short circuit, fire, or malfunction.
Overtightening can damage the screw and/or module, resulting in drop, short
circuit, or malfunction.
Prevent foreign matter such as dust or wire chips from entering the module.
Such foreign matter can cause a fire, failure, or malfunction.
Place the cables in a duct or clamp them.
If not, dangling cables may swing or inadvertently be pulled, resulting in
damage to the module or cables or malfunction due to poor contact.
Do not install the control lines and communication cables together with the
main circuit lines or power cables.
Doing so may cause malfunction due to noise.
Use applicable solderless terminals and tighten them within the specified
torque range. If any spade solderless terminal is used, it may be
disconnected when the terminal screw comes loose, resulting in failure.
When disconnecting the cable from the module, do not pull the cable by the
cable part.
When removing the cable with a connector, hold the connector on the side
that is connected to the module.
When removing the cable without a connector, loose the screws on the side
that is connected to the module.
Pulling the cable that is still connected to the module may result in damage to
the module or cable, or malfunction due to poor contact.

A-4
[STARTUP AND MAINTENANCE PRECAUTIONS]
[DISPOSAL PRECAUTIONS]
WARNING
Do not touch any terminal while power is on.
Doing so can cause electric shock.
Shut off the external power supply for the system in all phases before
cleaning the module or retightening the terminal screws or module fixing
screws.
Failure to do so may result in electric shock.
Undertightening can cause drop of screw, short circuit, or malfunction.
Overtightening can damage the screw and/or module, resulting in drop, short
circuit, or malfunction.
CAUTION
Do not disassemble or modify the modules. Doing so may cause failure,
malfunction, injury, or a fire.
Shut off the external power supply for the system in all phases before
mounting or removing the module. Failure to do so may cause the module to
fail or malfunction.
After the first use of the product, do not mount/remove the module to/from the
base unit, and the terminal block to/from the module more than 50 times (IEC
61131-2 compliant) respectively.
Exceeding the limit of 50 times may cause malfunction.
Before handling the module, touch a grounded metal object to discharge the
static electricity from the human body.
Failure to do so may cause the module to fail or malfunction.
CAUTION
When disposing of this product, treat it as industrial waste.

A-5
CONDITIONS OF USE FOR THE PRODUCT
(1) Mitsubishi programmable controller ("the PRODUCT") shall be used in
conditions;
i) where any problem, fault or failure occurring in the PRODUCT, if any,
shall not lead to any major or serious accident; and
ii) where the backup and fail-safe function are systematically or
automatically provided outside of the PRODUCT for the case of any
problem, fault or failure occurring in the PRODUCT.
(2) The PRODUCT has been designed and manufactured for the purpose of
being used in general industries.
MITSUBISHI SHALL HAVE NO RESPONSIBILITY OR LIABILITY
(INCLUDING, BUT NOT LIMITED TO ANY AND ALL RESPONSIBILITY
OR LIABILITY BASED ON CONTRACT, WARRANTY, TORT, PRODUCT
LIABILITY) FOR ANY INJURY OR DEATH TO PERSONS OR LOSS OR
DAMAGE TO PROPERTY CAUSED BY the PRODUCT THAT ARE
OPERATED OR USED IN APPLICATION NOT INTENDED OR
EXCLUDED BY INSTRUCTIONS, PRECAUTIONS, OR WARNING
CONTAINED IN MITSUBISHI'S USER, INSTRUCTION AND/OR
SAFETY MANUALS, TECHNICAL BULLETINS AND GUIDELINES FOR
the PRODUCT.
("Prohibited Application")
Prohibited Applications include, but not limited to, the use of the
PRODUCT in;
• Nuclear Power Plants and any other power plants operated by Power
companies, and/or any other cases in which the public could be
affected if any problem or fault occurs in the PRODUCT.
• Railway companies or Public service purposes, and/or any other cases
in which establishment of a special quality assurance system is
required by the Purchaser or End User.
• Aircraft or Aerospace, Medical applications, Train equipment, transport
equipment such as Elevator and Escalator, Incineration and Fuel
devices, Vehicles, Manned transportation, Equipment for Recreation
and Amusement, and Safety devices, handling of Nuclear or
Hazardous Materials or Chemicals, Mining and Drilling, and/or other
applications where there is a significant risk of injury to the public or
property.

A-6
Notwithstanding the above, restrictions Mitsubishi may in its sole
discretion, authorize use of the PRODUCT in one or more of the
Prohibited Applications, provided that the usage of the PRODUCT is
limited only for the specific applications agreed to by Mitsubishi and
provided further that no special quality assurance or fail-safe, redundant
or other safety features which exceed the general specifications of the
PRODUCTs are required. For details, please contact the Mitsubishi
representative in your region.

A-7
REVISIONS
*The manual number is given on the bottom right of the cover.
2000 MITSUBISHI ELECTRIC CORPORATION
Print Date *Manual Number Revision
Jul.,2000 IB(NA)-0800146-A First edition
Mar.,2006 IB(NA)-0800146-B
SAFETY PRECAUTIONS,
Conformation to the EMC Directive and Low
Voltage Instruction, Section 1.1, 2.1, 5.1
Aug.,2007 IB(NA)-0800146-C
Chapter 3, Section 6.1, 6.2
Jul.,2009 IB(NA)-0800146-D "PLC" was changed to "programmable controller".
SAFETY PRECAUTIONS, Compliance with the
EMC and Low Voltage Directives, Section 1.1,
2.1 to 2.2, Chapter 3, 4.1, 5.1, 6.1
Dec.,2011 IB(NA)-0800146-E
COMPLIANCE WITH EMC AND LOW VOLTAGE
DIRECTIVES, Section 5.1
SAFETY PRECAUTIONS(Chinese),
CONDITIONS OF USE FOR THE PRODUCT
Dec.,2016 IB(NA)-0800146-F
Chapter 3, Section 6.2
This manual confers no industrial property rights or any rights of any other kind, nor does it
confer any patent licenses. Mitsubishi electric Corporation cannot be held responsible for any
problems involving industrial property rights which may occur as a result of using the contents
noted in this manual.
Correction
Correction
Correction
Correction
Addition
Partial correction

A-8
CONTENTS
1. Overview ......................................................................................................... 1
1.1 Definition of Ver.1.10 ................................................................................ 1
2. Performance Specification .............................................................................. 2
2.1 Performance specification ........................................................................ 2
2.1.1 Maximum overall cable distance ....................................................... 4
2.2 CC-Link dedicated cable .......................................................................... 4
3. Name and Setting of Each Component .......................................................... 5
4. Loading and Installation ................................................................................ 10
4.1 Handling precautions .............................................................................. 10
4.2 Installation environment.......................................................................... 11
5. External Wiring.............................................................................................. 12
5.1 Wiring the CC-Link dedicated cable ....................................................... 12
6. External Dimensions ..................................................................................... 14
6.1 AJ61BT11............................................................................................... 14
6.2 A1SJ61BT11 .......................................................................................... 15

A-9
COMPLIANCE WITH EMC AND LOW VOLTAGE DIRECTIVES
(1) Method of ensuring compliance
To ensure that Mitsubishi programmable controllers maintain EMC
and Low Voltage Directives when incorporated into other
machinery or equipment, certain measures may be necessary.
Please refer to one of the following manuals.
• User's manual for the CPU module used
• User's manual (hardware) for the CPU module or base unit
used
The CE mark on the side of the programmable controller indicates
compliance with EMC and Low Voltage Directives.
(2) Additional measures
To ensure that this product maintains EMC and Low Voltage
Directives, please refer to one of the manuals listed under (1).

1
1. Overview
This manual describes the specifications, name of each part, settings,
etc., of the AJ61BT11 CC-Link System Master/Local Module (hereafter
abbreviated as AJ61BT11) and A1SJ61BT11 CC-Link System Master/
Local Module (hereafter abbreviated as A1SJ61BT11) to be used in
combination with the MELSEC-A series programmable controller CPU.
Confirm that the following items are included in the package.
1.1 Definition of Ver.1.10
The module of which the cable length between station and station is
uniformly 20cm or more by improving the conventional limit of the cable
length between station and station is defined as Ver.1.10.
The conventional modules are defined as Ver.1.00.
The conditions for setting the cable length between station and station
uniformly to 20cm or more are indicated below.
1) All modules configuring the CC-Link system must use
Version 1.10.
2) All data link cables must be Version 1.10 compatible CC-
Link dedicated cable.
(1) Checking Version 1.10
The "CC-Link" logo is printed on the front of the module or on the
"rating plate" for the Version 1.10 modules.
Item name Number of
items
AJ61BT11 CC-Link System
Master/Local Module
AJ61BT11 1
Terminating resistor 1101/2W
(Brown-brown-brown) 2
Terminating resistor 1301/2W
(Brown-orange-brown) 2
A1SJ61BT11 CC-Link System
Master/Local Module
A1SJ61BT11 1
Terminating resistor 1101/2W
(Brown-brown-brown) 2
Terminating resistor 1301/2W
(Brown-orange-brown) 2
Point
In the case of the system containing modules of both Ver.1.00 and Ver.1.10, the maximum
overall cable length and the station-to-station cable length must meet the specifications for
Ver.1.00.

2
2. Performance Specification
2.1 Performance specification
The following shows the performance specification of the AJ61BT11
and A1SJ61BT11. Refer to the CPU module User's Manual to be used
for general specification of AJ61BT11 and A1SJ61BT11.
Item Specification
Transmission speed Selectable from 156kbps/625kbps/2.5Mbps/5Mbps/10Mbps
Maximum overall
cable distance
(Maximum
transmission
distance)
Differs according to the transmission speed (Refer to Section 2.1.1)
Maximum number of
connected modules
(when master station)
64 modules
However, the following conditions must be satisfied:
{(1 a) + (2 b)+ (3 c) + (4 d)} 64
a: Number of modules occupying 1 station.
b: Number of modules occupying 2 stations.
c: Number of modules occupying 3 stations.
d: Number of modules occupying 4 stations.
{(16 A) + (54 B) + (88 C)} 2304
A: Number of remote I/O stations 64
B: Number of remote device stations 42
C: Number of local stations, standby master stations, intelligent
device stations 26
Number of occupied
stations
(when local station)
1 to 4 stations*1 (switched using the DIP switch)
Maximum link points
for one system
Remote I/O (RX, RY)
Remote register (RWw)
Remote register (RWr)
:
:
:
2048 points
256 points (master station remote/local
station)
256 points (remote/local station master
station)
Link points for one
remote/local station
Remote I/O (RX, RY)
Remote register (RWw)
Remote register (RWr)
:
:
:
32 points (local station 30 points)
4 points (master station remote/local
station)
4 points (remote/local station master
station)
Communication
method Broadcast polling method
Synchronous method Frame synchronous method
Encoding method NRZI method
Transmission path Bus (RS-485)
Transmission format Conform to HDLC
Error control system CRC (X16+X12+X5+1)
Cable*2 CC-Link dedicated cable (Ver.1.00)/CC-Link dedicated high-
performance cable/Version 1.10 compatible CC-Link dedicated cable

3
*1 This setting is applicable to the AJ61BT11 of hardware version F or later and
the A1SJ61BT11 of hardware version G or later. For the modules with other
versions, the setting is "1 station" and "4 stations" only.
*2 Each of Ver.1.10 compatible CC-Link cables, CC-Link dedicated cables
(Ver.1.00), and CC-Link dedicated high-performance cables cannot be used
together with other cable types.
If different cable types are used together, normal data transmission is not
guaranteed.
Also attach the terminating resistor which matches the cable. (Refer to
section 5.1)
RAS function
• Auto return function
• Slave station cutoff function
• Error detection by the link special relay/register
Number of parameter
registration to
E2PROM
10000 times
Number of occupied
I/O points 32 points (I/O assignment: special 32 points)
Internal current
consumption (5VDC) AJ61BT11:0.45A, A1SJ61BT11:0.4A
Weight AJ61BT11:0.4kg , A1SJ61BT11:0.25kg
Item Specification

4
2.1.1 Maximum overall cable distance
The maximum overall cable distance differs according to the
transmission speed.
For the relationship between the transmission speed and maximum
overall cable distance, refer to the CC-Link System Master/Local
Module User's Manual.
2.2 CC-Link dedicated cable
Use the CC-Link dedicated cables in a CC-Link system.
If a cable other than the CC-Link dedicated cable is used, the
performance of the CC-Link system cannot be guaranteed.
For the specifications of the CC-Link dedicated cables or any other
inquiries, visit the following site:
CC-Link Partner Association website: www.cc-link.org
Remarks
For details, refer to the CC-Link cable wiring manual issued by CC-Link
Partner Association.

5
3. Name and Setting of Each Component
This section explains the name and setting of each component of
AJ61BT11 and A1SJ61BT11.
(6)
(5)
(4)
(3)
(2)
(1)
(2)
(6)
(5)
(4)
(3)
(1)

6
*1 When the module is operated in the synchronous mode, the LED may be lit
dimly.
*2 When all stations are in error, changes on switches may not be detected.
No. Name Description
(1) LED display Data link status can be checked from the LED on status.
LED name Description
RUN ON :
OFF:
Module is normal.
Watchdog timer error.
ERR. ON :
Flashing:
Communication error at all stations.
Communication faulty station exists.
MST ON: Set as a master station.
S MST ON: Set as a standby master station.
LOCAL ON: Set as a local station.
CPU R/W ON: Communicating with programmable
controller CPU. (FROM/TO)
E
R
R
O
R
SW ON: Switch setting error.
M/S
ON: Master station already exists on the same
line.
Flashing:
Occupied station count overlapping
(With the exception of the first station number
overlapping)
PRM ON: Parameter setting error.
TIME
ON: Cable disconnection, or no response from all
stations due to noise in a communication
path.
LINE ON: Cable disconnection, or transmission path is
affected by noise, etc.
L RUN ON: In data link. (host) *1
L ERR.
ON: Communication error (host).
Flashing at regular intervals:
The setting(s) of switches (2) to (5) was
changed while the power was on. *2
Flashing at irregular intervals:
Terminating resistor is not connected, or
module and/or CC-Link dedicated cable is
affected by noise.
B
R
A
T
E
156K ON: Transmission speed is set to "156kbps".
625K ON: Transmission speed is set to "625kbps".
2.5M ON: Transmission speed is set to "2.5Mbps".
5M ON: Transmission speed is set to "5Mbps".
10M ON: Transmission speed is set to "10Mbps".
T
E
S
T
TEST ON: Offline test in progress.
S0
(Not used)S1
S2
SD ON: Sending data.
RD ON: Receiving data.

7
*3 Use impossible at local station.
No. Name Description
(2) Station number
setting switch
AJ61BT11
A1SJ61BT11
Set the module station number.(setting at shipment: 0)
<Range>
• In the remote net mode
Master station: 0
Local station: 1 to 64
Standby master station: 1 to 63
The "SW" and "L ERR." LEDs are turned on when a value
other than 0 to 64 is set.
In the remote I/O net mode
Master station: 1 to 64 (set the last station number of remote
I/O station)
When set to 0, the "PLM" LED is turned on.
(3) Mode setting switches
AJ61BT11
A1SJ61BT11
Set the module operation status. (setting at shipment: 0)
Number Name
0 Online (remote net mode)
1 Online (remote I/O net mode)
2 Offline
3 Line test 1 *3
4 Line test 2 *3
5 Parameter confirmation test *3
6 Hardware test
7 Setting error (the "SW" LED on)
8 to A Setting prohibited
B to F Setting error (the "SW" LED on)
(4) Transmission speed
setting switch
AJ61BT11
A1SJ61BT11
Set the module transmission speed.
(setting at shipment: 0)
Number Setting detail
0156kbps
1625kbps
2 2.5Mbps
35Mbps
4 10Mbps
5 to 9 Setting error (the "SW" and "L ERR" LED on)
X1
X10
STATION NO.
STATION NO.
1
X
10
X
1:ONLINE(RIM)
2:OFFLINE
0:ONLINE(A.R.)
MODE
MODE
10M
5M
2.5M
625K
156K
4
3
2
1
0
B RATE
B RATE
10M
5M
2.5M
625K
156K
4
3
2
1
0

8
*4 The AJ61BT11 of hardware version F or later and the A1SJ61BT11 of
hardware version G or later are compatible with this setting.
For other than the above, only SW5 is used to set the number of occupied
stations.
No. Name Description
(5)
Condition setting
switch
AJ61BT11
A1SJ61BT11
Set the operation condition. (setting at shipment: SW1 to 7 are
OFF, SW8 is ON)
Number Setting
detail Description
SW1 Station type OFF:
ON :
Master station/Local station
Standby master station
SW2 (Unusable) Always off
SW3 (Unusable) Always off
SW4
Input data
status of the
data link error
station
OFF:
ON :
Clear
Hold
SW5
SW6
Number of
occupied
stations
Number of
occupied
stations
SW5 SW6
1 station OFF OFF
2 stations*4 OFF ON
3 stations*4 ON ON
4 stations ON OFF
SW7 (Unusable) Always off
SW8 Module mode OFF:
ON :
Intelligent mode
I/O mode
(6) Terminal block Connect the CC-Link dedicated cable for data link.
Refer to Section 5.1 for how to connect the cables.
Note that the following terminals are connected inside the
module.
• SLD (terminal No. 8) and FG (terminal No. 10)
• NC (terminal No. 7) and NC (terminal No. 9)
2-piece type terminal block. The module can be exchanged with
another without removing the signal lines from the terminal block.
(Replace the module after turning off its power.)
OFF : 1 station occupied
ON : 4 stations occupied
Keep SW6 OFF as it is unusable.
2/31/4
ON
8
7
6
5
4
3
2
1
SW
SFM
3/4
HOLD
S MST
ON
ISFM
1/2
CLEAR
M/L
OFF
2/31/4
ONOFFSW
SFM
3/4
HLD
S.M
ISM
1/2
CLR
M/L
8
7
6
5
4
3
2
1
NC
NC
NC
NC
(FG)
SLD
DG
DB
DA
NC

9
Point
The setting for the switches (2) to (5) when the module power supply is turned OFF ON
is valid.
When the setting is changed while the module power supply is on, reset the programmable
controller CPU or turn off and then on the module power supply again.
Important
Do not use station number 64 in a system where the waiting master station exists.
When it is used, the station number 64 will not communicate correctly.

10
4. Loading and Installation
The following is explanations of the handling precautions and
installation environment, which is common to modules when handling
AJ61BT11 and A1SJ61BT11 from unpacking to installation.
For the details of loading and installation of the module, refer to the
user's manual of the programmable controller CPU module used.
4.1 Handling precautions
The following is an explanation of handling precautions of the module.
(1) Do not drop the module case or terminal block, or subject them to
heavy impact since they are made of resin.
(2) Do not remove the print circuit board of each module from its case.
This may cause a failure in the module.
(3) Prevent foreign matter such as dust or wire chips from entering the
module.
Such foreign matter can cause a fire, failure, or malfunction.
(4) Solderless terminals with insulation sleeve cannot be used for the
terminal block. It is recommended that the wiring connecting sections
of the solderless terminals will be covered with a marking tube or an
insulation tube.
(5) Before handling the module, touch a grounded metal object to
discharge the static electricity from the human body.
Failure to do so may cause the module to fail or malfunction.
(6) Tighten the module mounting screws and terminal screws within
the following torque range.
(7) Insert the tabs at the bottom of the module into the holes in the
base unit before mounting the module. (For the AnS series
modules, make sure screws are securely tightened to the base unit
with the specified torque.)
Incorrect mounting may cause malfunction, failure, or drop of the
module.
Screw location Tightening torque range
Module mounting screws (M4 screws) 0.78 to 1.18N·m
Terminal-block terminal screws (M3.5 screws) 0.59 to 0.88N·m
Terminal-block installation screws (M3.5 screws) 0.49 to 0.78N·m
