Mitsubishi Electric MELSEC iQ-F Series User manual

MELSEC iQ-F
FX5-ENET User's Manual

1
SAFETY PRECAUTIONS
(Read these precautions before use.)
Before using this product, please read this manual and the relevant manuals introduced in this manual carefully and pay full
attention to safety in order to handle the product correctly.
This manual classifies the safety precautions into two categories: [ WARNING] and [ CAUTION].
Depending on the circumstances, procedures indicated by [ CAUTION] may also cause severe injury.
It is important to follow all precautions for personal safety.
Store this manual in a safe place so that it can be read whenever necessary. Always forward it to the end user.
WARNING Indicates that incorrect handling may cause hazardous conditions, resulting in
death or severe injury.
CAUTION Indicates that incorrect handling may cause hazardous conditions, resulting in
minor or moderate injury or property damage.

2
[DESIGN PRECAUTIONS]
WARNING
●Make sure to set up the following safety circuits outside the PLC to ensure safe system operation
even during external power supply problems or PLC failure. Otherwise, malfunctions may cause
serious accidents.
- Most importantly, set up the following: an emergency stop circuit, a protection circuit, an interlock
circuit for opposite movements (such as normal vs. reverse rotation), and an interlock circuit (to
prevent damage to the equipment at the upper and lower positioning limits).
- Note that when the CPU module detects an error, such as a watchdog timer error, during self-
diagnosis, all outputs are turned off. Also, when an error that cannot be detected by the CPU
module occurs in an input/output control block, output control may be disabled. External circuits
and mechanisms should be designed to ensure safe machinery operation in such a case.
- Note that when an error occurs in a relay, transistor or triac of an output circuit, the output might
stay on or off. For output signals that may lead to serious accidents, external circuits and
mechanisms should be designed to ensure safe machinery operation in such a case.
●In an output circuit, when a load current exceeding the current rating or an overcurrent caused by a
load short-circuit flows for a long time, it may cause smoke and fire. To prevent this, configure an
external safety circuit, such as a fuse.
●For the operating status of each station after a communication failure of the network, refer to relevant
manuals for the network. Incorrect output or malfunction may result in an accident.
●Construct an interlock circuit in the program so that the whole system always operates on the safe
side before executing the control (for data change) of the PLC in operation.
Read the manual thoroughly and ensure complete safety before executing other controls (for program
change, parameter change, forcible output and operation status change) of the PLC in operation.
Otherwise, the machine may be damaged and accidents may occur due to erroneous operations.
●Especially, in the case of a control from an external device to a remote programmable controller,
immediate action cannot be taken for a problem on the programmable controller due to a
communication failure. Determine the handling method as a system when communication failure
occurs along with configuration of interlock circuit on a program, by considering the external
equipment and CPU module.
●Do not write any data to the "system area" and "write-protect area" of the buffer memory in the
intelligent function module. Executing data writing to the "system area" or "write-protect area" may
cause malfunction of the programmable controller alarm. For the "system area" or "write-protect
area", refer to Page 136 Buffer Memory.
●If a communication cable is disconnected, the network may be unstable, resulting in a communication
failure of multiple stations. Construct an interlock circuit in the program so that the system always
operates on the safe side even if communications fail. Incorrect output or malfunction may result in an
accident.

3
[DESIGN PRECAUTIONS]
[SECURITY PRECAUTIONS]
[INSTALLATION PRECAUTIONS]
CAUTION
●Do not install the control lines or communication cables together with the main circuit lines or power
cables. Keep a distance of 100mm or more between them. Failure to do so may result in malfunction
due to noise.
●When an inductive load such as a lamp, heater, or solenoid valve is controlled, a large current
(approximately ten times greater than normal) may flow when the output is turned from off to on. Take
proper measures so that the flowing current does not exceed the value corresponding to the
maximum load specification of the resistance load.
●Do not power off the CPU module or reset the CPU module while the settings are being written. Doing
so will make the data in the flash ROM undefined. The values need to be set in the buffer memory and
written to the flash ROM again. Doing so also may cause malfunction or failure of the module.
WARNING
●To maintain the security (confidentiality, integrity, and availability) of the programmable controller and
the system against unauthorized access, denial-of-service (DoS) attacks, computer viruses, and other
cyberattacks from unreliable networks and devices via network, take appropriate measures such as
firewalls, virtual private networks (VPNs), and antivirus solutions.
WARNING
●Make sure to cut off all phases of the power supply externally before attempting installation or wiring
work. Failure to do so may cause electric shock or damage to the product.
●Use the product within the generic environment specifications described in the User's Manual
(Hardware) of the CPU module used.
Never use the product in areas with excessive dust, oily smoke, conductive dusts, corrosive gas (salt
air, Cl2, H2S, SO2or NO2), flammable gas, vibration or impacts, or expose it to high temperature,
condensation, or rain and wind.
If the product is used in such conditions, electric shock, fire, malfunctions, deterioration or damage
may occur.

4
[INSTALLATION PRECAUTIONS]
[WIRING PRECAUTIONS]
CAUTION
●Do not touch the conductive parts of the product directly. Doing so may cause device failures or
malfunctions.
●When drilling screw holes or wiring, make sure that cutting and wiring debris do not enter the
ventilation slits of the PLC. Failure to do so may cause fire, equipment failures or malfunctions.
●For the product supplied together with a dust proof sheet, the sheet should be affixed to the ventilation
slits before the installation and wiring work to prevent foreign objects such as cutting and wiring
debris.
However, when the installation work is completed, make sure to remove the sheet to provide
adequate ventilation. Failure to do so may cause fire, equipment failures or malfunctions.
●Install the product on a flat surface. If the mounting surface is rough, undue force will be applied to the
PC board, thereby causing nonconformities.
●Install the product securely using a DIN rail or mounting screws.
●Work carefully when using a screwdriver such as installation of the product. Failure to do so may
cause damage to the product or accidents.
●Connect the extension cables, peripheral cables, input/output cables and battery connecting cable
securely to their designated connectors. Loose connections may cause malfunctions.
●Turn off the power to the PLC before attaching or detaching the following devices. Failure to do so
may cause equipment failures or malfunctions.
- Peripherals, expansion board, expansion adapter, and connector conversion adapter
- Extension modules, bus conversion module, and connector conversion module
-Battery
WARNING
●Make sure to cut off all phases of the power supply externally before attempting installation or wiring
work. Failure to do so may cause electric shock or damage to the product.
●Make sure to attach the terminal cover, provided as an accessory, before turning on the power or
initiating operation after installation or wiring work. Failure to do so may cause electric shock.
●The temperature rating of the cable should be 80or more.
●Make sure to properly wire to the spring clamp terminal block in accordance with the following
precautions. Failure to do so may cause electric shock, equipment failures, a shortcircuit, wire
breakage, malfunctions, or damage to the product.
- The disposal size of the cable end should follow the dimensions described in the manual.
- Twist the ends of stranded wires and make sure that there are no loose wires.
- Do not solder-plate the electric wire ends.
- Do not connect more than the specified number of wires or electric wires of unspecified size.
- Affix the electric wires so that neither the terminal block nor the connected parts are directly
stressed.

5
[WIRING PRECAUTIONS]
[STARTUP AND MAINTENANCE PRECAUTIONS]
CAUTION
●Perform class D grounding (grounding resistance: 100or less) of the grounding terminal on the CPU
module and extension modules with a wire 2 mm2or thicker. Do not use common grounding with
heavy electrical systems (refer to the User's Manual (Hardware) of the CPU module used).
●Individually ground the FG terminal of the programmable controller with a ground resistance of 100
or less. Failure to do so may result in electric shock or malfunction.
●Install module so that excessive force will not be applied to terminal blocks, or communication cables.
Failure to do so may result in wire damage/breakage or PLC failure.
●Make sure to observe the following precautions in order to prevent any damage to the machinery or
accidents due to malfunction of the PLC caused by abnormal data written to the PLC due to the
effects of noise.
- Do not bundle the control line and communication cables together with or lay them close to the
main circuit, high-voltage line, load line or power line. As a guideline, lay the power line, control
line and communication cables at least 100mm away from the main circuit, high-voltage line, load
line or power line.
- Ground the shield of the shielded wire or shielded cable at one point on the PLC. However, do not
use common grounding with heavy electrical systems.
●For Ethernet cables to be used in the system, select the ones that meet the specifications described in
Page 67 Wiring Products. If not, normal data transmission is not guaranteed.
WARNING
●Do not touch any terminal while the PLC's power is on. Doing so may cause electric shock or
malfunctions.
●Before cleaning or retightening terminals, cut off all phases of the power supply externally. Failure to
do so in the power-on status may cause electric shock.
●Before modifying the program in operation, forcible output, running or stopping the PLC, read through
this manual carefully, and ensure complete safety. An operation error may damage the machinery or
cause accidents.
●Do not change the program in the PLC from two or more peripheral equipment devices at the same
time. (i.e. from an engineering tool and a GOT) Doing so may cause destruction or malfunction of the
PLC program.

6
[STARTUP AND MAINTENANCE PRECAUTIONS]
[OPERATION PRECAUTIONS]
CAUTION
●When connecting an external device with a CPU module or intelligent function module to modify data
of a running programmable controller, configure an interlock circuit in the program to ensure that the
entire system will always operate safely. For other forms of control (such as program modification,
parameter change, forced output, or operating status change) of a running programmable controller,
read the relevant manuals carefully and ensure that the operation is safe before proceeding. Improper
operation may damage machines or cause accidents.
●Especially, when a remote programmable controller is controlled by an external device, immediate
action cannot be taken if a problem occurs in the programmable controller due to a communication
failure. To prevent this, configure an interlock circuit in the program, and determine corrective actions
to be taken between the external device and CPU module in case of a communication failure.
●Do not disassemble or modify the PLC. Doing so may cause fire, equipment failures, or malfunctions.
For repair, contact your local Mitsubishi Electric representative.
●Turn off the power to the PLC before attaching or detaching the following devices. Failure to do so
may cause equipment failures or malfunctions.
- Peripherals, expansion board, expansion adapter, and connector conversion adapter
- Extension modules, bus conversion module, and connector conversion module
-Battery
●Read relevant manuals carefully and ensure the safety before performing online operations (operation
status change) with peripheral devices connected to the CPU modules of other stations. Improper
operation may damage machines or cause accidents.
CAUTION
●Construct an interlock circuit in the program so that the whole system always operates on the safe
side before executing the control (for data change) of the PLC in operation. Read the manual
thoroughly and ensure complete safety before executing other controls (for program change,
parameter change, forcible output and operation status change) of the PLC in operation. Otherwise,
the machine may be damaged and accidents may occur by erroneous operations.
●Do not power off the CPU module or reset the CPU module while the setting values in the buffer
memory are being written to the flash ROM in the intelligent function module. Doing so will make the
data in the flash ROM card undefined. The values need to be set in the buffer memory and written to
the flash ROM again. Doing so can cause malfunction or failure of the module.
●Note that the whole system may not be reset by the RUN/STOP/RESET switch when the CPU module
or intelligent function module detects an error, such as a watchdog timer error, during self-diagnosis.
In such cases, turn the power off and on again.

7
[DISPOSAL PRECAUTIONS]
[TRANSPORTATION PRECAUTIONS]
CAUTION
●Please contact a certified electronic waste disposal company for the environmentally safe recycling
and disposal of your device.
CAUTION
●The PLC is a precision instrument. During transportation, avoid impacts larger than those specified in
the general specifications of the User's Manual (Hardware) of the CPU module by using dedicated
packaging boxes and shock-absorbing palettes. Failure to do so may cause failures in the PLC. After
transportation, verify operation of the PLC and check for damage of the mounting part, etc.

8
INTRODUCTION
This manual contains text, diagrams and explanations which will guide the reader in the correct installation, safe use and
operation of the FX5-ENET Ethernet module of MELSEC iQ-F series.
It should be read and understood before attempting to install or use the unit. Store this manual in a safe place so that you can
read it whenever necessary.
Always forward it to the end user.
Regarding use of this product
• This product has been manufactured as a general-purpose part for general industries, and has not been designed or
manufactured to be incorporated in a device or system used in purposes related to human life.
• Before using the product for special purposes such as nuclear power, electric power, aerospace, medicine or passenger
movement vehicles, consult Mitsubishi Electric.
• This product has been manufactured under strict quality control. However when installing the product where major
accidents or losses could occur if the product fails, install appropriate backup or failsafe functions in the system.
Note
• If in doubt at any stage during the installation of the product, always consult a professional electrical engineer who is
qualified and trained in the local and national standards. If in doubt about the operation or use, please consult the nearest
Mitsubishi Electric representative.
• Mitsubishi Electric will not accept responsibility for actual use of the product based on these illustrative examples.
• This manual content, specification etc. may be changed, without a notice, for improvement.
• The information in this manual has been carefully checked and is believed to be accurate; however, if you notice a doubtful
point, an error, etc., please contact the nearest Mitsubishi Electric representative. When doing so, please provide the
manual number given at the end of this manual.

9
CONTENTS
CONTENTS
SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
RELEVANT MANUALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
TERMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
GENERIC TERMS AND ABBREVIATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
CHAPTER 1 OUTLINE 15
CHAPTER 2 SPECIFICATIONS 17
2.1 General Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.2 Power Supply Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.3 Performance Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.4 Part Names. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
LED display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
CHAPTER 3 PROCEDURES BEFORE OPERATION 22
CHAPTER 4 FUNCTION LIST 24
4.1 CC-Link IE Field Network Basic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.2 General-purpose Ethernet Communication Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.3 Other Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
E-mail function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
DNS settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
MQTT communication function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
CHAPTER 5 SYSTEM CONFIGURATION 61
5.1 CC-Link IE Field Network Basic System Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Access range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Number of link points. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
5.2 General-purpose Ethernet Communication Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
5.3 Applicable Engineering Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
CHAPTER 6 WIRING 64
6.1 Grounding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
6.2 Wiring Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
6.3 Wiring Products. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
CHAPTER 7 PARAMETER SETTINGS 68
7.1 Procedure for Setting Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
7.2 Required Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
7.3 Basic Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Own Node Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Operational Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
CC-Link IEF Basic Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
BACnet function setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
External Device Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
7.4 Application Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

10
DNS settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Simple CPU communication settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
E-mail settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
MQTT communication settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
7.5 Starting Certificate Configuration Tool for FX5-ENET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
CHAPTER 8 APPLICABLE ENGINEERING TOOL 85
8.1 Certificate Configuration Tool for FX5-ENET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Server Certificates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Client Certificates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Checking the software version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
CHAPTER 9 PROGRAMMING 93
9.1 Interlock Programs of Cyclic Transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Program using labels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Program using buffer memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
CHAPTER 10 TROUBLESHOOTING 96
10.1 Checking with LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
10.2 Checking the Module Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Module diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Ethernet diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Checking the buffer memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Event history function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
10.3 Checking the Network Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
CC-Link IE Field Network Basic Diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
10.4 Hardware Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
10.5 Troubleshooting by Symptom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
10.6 List of Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
CC-Link IE Field Network Basic error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Module error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Ethernet communication error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
10.7 List of Event Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
APPENDIX 132
Appendix 1 External Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Appendix 2 Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
Certification of UL, cUL standards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
Compliance with EC Directive (CE marking) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
Requirement for compliance with EMC Directive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
Caution for compliance with EC Directive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
Compliance with UKCA marking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
Appendix 3 Module Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Appendix 4 Buffer Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
List of buffer memory addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Details of buffer memory addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Appendix 5 Processing Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
Transmission delay time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169

11
CONTENTS
Appendix 6 Software Licenses and Copyrights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
Appendix 7 Added and Changed Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
INDEX 172
REVISIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .174
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .175
TRADEMARKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .176

12
RELEVANT MANUALS
TERMS
Unless otherwise specified, this manual uses the following terms.
Manual name <manual number> Description
MELSEC iQ-F FX5S/FX5UJ/FX5U/FX5UC User's Manual (Hardware)
<SH-082452ENG>
Describes the details of hardware of the CPU module, including
performance specifications, wiring, installation, and maintenance.
MELSEC iQ-F FX5 User's Manual (Application)
<JY997D55401>
Describes the basic knowledge required for program design, functions of
the CPU module, devices/labels, and parameters.
MELSEC iQ-F FX5 Programming Manual (Program Design)
<JY997D55701>
Describes the specifications of ladder, ST, FBD/LD, and SFC programs, and
labels.
MELSEC iQ-F FX5 Programming Manual (Instructions, Standard Functions/
Function Blocks)
<JY997D55801>
Describes the specifications of instructions and functions that can be used
in programs.
MELSEC iQ-F FX5 User's Manual (Ethernet Communication)
<JY997D56201>
Describes the Ethernet communication function of the CPU module built-in
and the Ethernet module.
MELSEC iQ-F FX5-ENET User's Manual
<SH-082026ENG> (This manual)
Describes the FX5-ENET.
MELSEC iQ-F FX5 User's Manual (BACnet)
<SH-082218ENG>
BACnet functions of the Ethernet module.
MELSEC iQ-F FX5 User's Manual (SLMP)
<JY997D56001>
Describes methods for the device that is communicating with the CPU
module by SLMP to read and write the data of the CPU module.
GX Works3 Operating Manual
<SH-081215ENG>
Describes the system configuration, parameter settings, and online
operations of GX Works3.
Term s Description
Broker An MQTT server that mediates messages (MQTT broker)
Cyclic transmission A function by which data are periodically exchanged among stations on the same network using link
devices on CC-Link IE Field Network Basic.
Disconnection A process of stopping data link if a data link error occurs.
Engineering tool The product name of the software package for the MELSEC programmable controllers
Link device A device (RX, RY, RWr, or RWw) in a CPU module for the purpose of communicating with remote stations
Link refresh Automatic data transfer between a user device and a link device.
Link scan (link scan time) The master station of CC-Link IE Field Network Basic sends requests to all remote stations. After receiving
responses from all the remote stations, the master station sends next requests. The time taken from when
requests are sent to when the next requests are started to send by the master station.
Master station A station that controls the entire CC-Link IE Field Network Basic. Only one master station can be used in a
network.
Message Data to be exchanged between the sender (publisher) and receiver (subscriber)
Publish/Subscribe message exchange model A protocol capable of one-to-many asynchronous communications
The sender of a message is called a publisher, the receiver is called a subscriber, and an entity playing an
intermediate role is called a broker.
The term "publish" means "send", and "subscribe" means "receive".
QoS Service quality to be provided on the network
QoS is classified into 0 to 2. The larger number indicates better quality and slower transfer speed.
RAS An abbreviation for Reliability, Availability, and Serviceability. This term refers to usability of automated
equipment.
Remote input (RX) Bit data input from a remote station to the master station
Remote output (RY) Bit data output from the master station to a remote station
Remote register (RWr) Word data input from a remote station to the master station
Remote register (RWw) Word data output from the master station to a remote station
Remote station A station that performs cyclic transmission with the master station on CC-Link IE Field Network Basic. I/O
signals in units of bits and I/O data in units of words are exchanged.
Retain This term refers to whether to save the latest message for each topic.
If a message could not be sent due to reasons such as client disconnection, the latest message is
delivered when the connection is established again.
Return A process of restarting data link when a station recovers from an error.

13
Topic A key to be used for messaging
In the topic hierarchy, a slash (/) is regarded as a delimiter. For example, when multiple sensors send their
individual information to the topic, the messages can be appropriately organized according to their
installation location and device name.
Will This function sends a Will message with a specified Will topic name to subscribers when the publisher is
disconnected and the server communications are disabled.
If any unexpected disconnection or such an event occurs, subscribers can judge that the publisher is
disconnected.
Terms Description

14
GENERIC TERMS AND ABBREVIATIONS
Unless otherwise specified, this manual uses the following generic terms and abbreviations.
Generic term/abbreviation Description
Battery Different name for FX3U-32BL
Ethernet module Different name for FX5-ENET
Extension module Generic term for the FX5 extension module, FX3 extension module, and extension module (extension
cable type and extension connector type)
FX5U CPU module Generic term for FX5U-32MR/ES, FX5U-32MT/ES, FX5U-32MT/ESS, FX5U-64MR/ES, FX5U-64MT/ES,
FX5U-64MT/ESS, FX5U-80MR/ES, FX5U-80MT/ES, FX5U-80MT/ESS, FX5U-32MR/DS, FX5U-32MT/
DS, FX5U-32MT/DSS, FX5U-64MR/DS, FX5U-64MT/DS, FX5U-64MT/DSS, FX5U-80MR/DS, FX5U-
80MT/DS, and FX5U-80MT/DSS
FX5UC CPU module Generic term for FX5UC-32MT/D, FX5UC-32MT/DSS, FX5UC-64MT/D, FX5UC-64MT/DSS, FX5UC-
96MT/D, FX5UC-96MT/DSS, FX5UC-32MT/DS-TS, FX5UC-32MT/DSS-TS, and FX5UC-32MR/DS-TS
FX5UJ CPU module Generic term for FX5UJ-24MR/ES, FX5UJ-24MT/ES, FX5UJ-24MT/ESS, FX5UJ-40MR/ES, FX5UJ-
40MT/ES, FX5UJ-40MT/ESS, FX5UJ-60MR/ES, FX5UJ-60MT/ES, and FX5UJ-60MT/ESS
GX Works3 Generic product name for the product model SWnDND-GXW3 (where n represents the version)
Intelligent function module Generic term for FX5 intelligent function modules and FX3 intelligent function modules
Peripheral Generic term for engineering tools and GOTs
SD memory card Generic term for NZ1MEM-2GBSD, NZ1MEM-4GBSD, NZ1MEM-8GBSD, NZ1MEM-16GBSD, L1MEM-
2GBSD, and L1MEM-4GBSD SD memory cards
Abbreviation of Secure Digital Memory Card. Device that stores data using flash memory.

1 OUTLINE
15
1
1OUTLINE
FX5-ENET Ethernet module (hereinafter referred to as FX5-ENET) is an intelligent function module for connecting a CPU
module to a CC-Link IE Field Network Basic and general-purpose Ethernet.
CC-Link IE Field Network Basic
CC-Link IE Field Network Basic is a factory automation network using the standard Ethernet.
Data is periodically communicated between the master station and remote stations using link devices (cyclic transmission).
CC-Link IE Field Network Basic can be used with other Ethernet protocols.
Precautions
The link scan time of cyclic transmission is increased by executing following functions:
• Ethernet functions such as socket communication and communication via SLMP
• Communications with other Ethernet devices on the same line
Use the Ethernet function above or other Ethernet devices so that the system being used is not affected.
(1) FX5-ENET (master station)
(2) Hub
(3) External device (remote station)
RX, RWr
RY, RWw
RX, RWr
RY, RWw
RX, RWr
RY, RWw
RX, RWr
RY, RWw
(1)
192.168.3.39 192.168.3.1 192.168.3.2 192.168.3.3
(3)
(2)
(3) (3)
Device
Device
Link
refresh
Link
refresh
Link
scan

16 1 OUTLINE
General-purpose Ethernet communication
The module can be connected with a host system, such as a personal computer, by using the communication protocol TCP/
UDP.
(1) FX5-ENET
(2) Hub
(3) CPU module
(4) External device (personal computer)
(1)
(2)
(1)(3)
(4)(4)

2 SPECIFICATIONS
2.1 General Specifications 17
2
2SPECIFICATIONS
This chapter describes the FX5-ENET specifications.
2.1 General Specifications
The items other than the following are equivalent to those of the CPU module.
For the general specification, refer to the following manual.
MELSEC iQ-F FX5S/FX5UJ/FX5U/FX5UC User's Manual (Hardware)
2.2 Power Supply Specifications
The following table lists the power supply specifications.
Items Specifications
Dielectric withstand voltage 500VAC for 1 minute Between all terminals and ground terminal
Insulation resistance 10Mor higher by 500VDC insulation resistance
tester
Items Specifications
Internal power supply Power supply voltage 24VDC
Current consumption 110mA

18 2 SPECIFICATIONS
2.3 Performance Specifications
2.3 Performance Specifications
The following table lists the performance specifications.
Items Specifications
CC-Link IE Field
Network Basic
Station type Master station
Maximum number of connectable stations*1 32
Number of stations occupied by a remote station 1 to 4
Maximum number of link points per network RX 2048
RY 2048
RWr 1024
RWw 1024
Maximum number of link points per
station
Master
station
RX 2048
RY 2048
RWr 1024
RWw 1024
Remote
station*2
RX 64/128/192/256
RY 64/128/192/256
RWr 32/64/96/128
RWw 32/64/96/128
UDP port number used in the cyclic transmission 61450
UDP port number used in the automatic detection of connected
device
Master station: An unused port number is assigned automatically.
Remote station: 61451
Transmission
specifications
Data transmission speed 100Mbps
Interface RJ45 connector
Maximum station-to-station distance 100m
Overall cable distance Depends on the system configuration
Number of cascade
connections
100BASE-TX For the number of the connectable stages when using a switching hub,
check with the manufacturer of the switching hub used.
Network topology Star topology
Hub*3 Hubs with 100BASE-TX ports*4 can be used.
Connection cable*5 100BASE-TX Ethernet cable of category 5 or higher (STP cable)
General-
purpose
Ethernet
communication
Transmission
specifications
Data transmission speed 100/10Mbps
Communication mode Full-duplex or half-duplex*3
Transmission method Base band
Interface RJ45 connector
Maximum segment length 100m (length between hub and node)*6
Number of cascade
connections
100BASE-TX 2 levels maximum*7
10BASE-T 4 levels maximum*7
Protocol type*8 MELSOFT connection, SLMP server (3E/1E frame), socket
communication, simple CPU communication, BACnet/IP
Number of connections Total of 32 connections*9
(Up to 32 external devices can access one FX5-ENET module at the
same time.)
Hub*3 Hubs with 100BASE-TX or 10BASE-T ports*10 can be used.
Connection cable*5 100BASE-TX Ethernet cable of category 5 or higher (STP cable)
10BASE-T Ethernet cable of category 3 or higher (STP/UTP cable)
Number of ports 2*11
Number of occupied I/O points 8 points
Applicable CPU module • FX5UJ CPU module (From the first)
• FX5U CPU module (Ver. 1.110 or later)
• FX5UC CPU module*12 (Ver. 1.110 or later)
Applicable engineering tool GX Works3 • FX5UJ CPU module: GX Works3 (Ver. 1.060N or later)
• FX5U/FX5UC CPU module: GX Works3 (Ver. 1.050C or later)
Certificate Configuration Tool for FX5-ENET Ver. 1.00A or later
Number of connectable modules 1
