FR-A8NCG INSTRUCTION MANUAL
B
INVERTER
INVERTER
PRE-OPERATION INSTRUCTIONS 1
INSTALLATION 2
WIRING 3
CC-LINK IE TSN CONFIGURATION 4
INVERTER SETTING 5
FUNCTION OVERVIEW 6
I/O SIGNAL 7
PROGRAMMING EXAMPLES 8
PROTECTIVE FUNCTIONS 9
INVERTER
Plug-in option
INSTRUCTION MANUAL
HEAD OFFICE: TOKYO BUILDING 2-7-3, MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN
FR-A8NCG
Class B
communication function
IB(NA)-0600837ENG-B(2008) MEE Printed in Japan Specifications subject to change without notice.

1
Thank you for choosing this Mitsubishi Electric inverter plug-in option.
This Instruction Manual provides handling information and precautions for use of this product. Incorrect handling might cause an unexpected
fault. Before using this product, read all relevant instruction manuals carefully to ensure proper use.
Please forward this Instruction Manual to the end user.
Electric shock prevention
Injury prevention
Safety instructions
Do not attempt to install, operate, maintain or inspect this product until you have read this Instruction Manual and supplementary documents
carefully. Do not use this product until you have a full knowledge of this product mechanism, safety information and instructions. In this
Instruction Manual, the safety instruction levels are classified into "WARNING" and "CAUTION".
Incorrect handling may cause hazardous conditions, resulting in death or severe injury.
Incorrect handling may cause hazardous conditions, resulting in medium or slight injury, or may cause only
material damage.
Note that even the level may lead to a serious consequence depending on conditions. Be sure to follow the
instructions of both levels as they are critical to personnel safety.
WARNING
Do not remove the front cover or the wiring cover of the inverter while the inverter power is ON. Do not operate the inverter with any cover or wiring cover removed,
as accidental contact with exposed high-voltage terminals and internal components may occur, resulting in an electrical shock.
Even if power is OFF, do not remove the front cover of the inverter except for wiring or periodic inspection as you may accidentally touch the charged circuits and
get an electric shock.
Before wiring or inspection, check that the display of the inverter operation panel is OFF. Any person who is involved in wiring or inspection shall wait for 10 minutes
or longer after power OFF and check that there are no residual voltage using a tester or the like. The capacitor is charged with high voltage for some time after
power OFF, and it is dangerous.
Any person who is involved in wiring or inspection of this product shall be fully competent to do the work.
This product must be installed before wiring. Otherwise you may get an electric shock or be injured.
Do not subject the cables to scratches, excessive stress, heavy loads or pinching. Doing so may cause an electric shock.
Do not touch this product or handle the cables with wet hands. Doing so may cause an electric shock.
CAUTION
The voltage applied to each terminal must be as specified in the Instruction Manual. Otherwise an explosion or damage may occur.
The cables must be connected to the correct terminals. Otherwise an explosion or damage may occur.
The polarity (+ and -) must be correct. Otherwise an explosion or damage may occur.
While power is ON or for some time after power OFF, do not touch the inverter as it will be extremely hot. Doing so may cause burns.
WARNING
CAUTION
CAUTION

2
Additional instructions
The following instructions must be also followed. If this product is handled incorrectly, it may cause unexpected fault, an injury, or an electric
shock.
 DoS: A denial-of-service (DoS) attack disrupts services by overloading systems or exploiting vulnerabilities, resulting in a denial-of-service (DoS)
state.
CAUTION
Transportation and installation
Do not stand or place heavy objects on this product.
Ensure the mounting orientation of this product is correct.
Do not install or operate this product if it is damaged or has parts missing.
Foreign conductive objects must be prevented from entering the inverter. That includes screws and metal fragments or other flammable substance such as oil.
If halogens (including fluorine, chlorine, bromine, and iodine) contained in fumigants for wood packages enter this product, the product may be damaged. Prevent
the entry of fumigant residuals or use an alternative method such as heat disinfection. Note that sterilization or disinfection of wood packages should be performed
before packing the product.
Test operation
Before starting operation, confirm or adjust the parameter settings. Failure to do so may cause some machines to make unexpected motions.
WARNING
Usage
Do not modify this product.
Do not remove any part which is not instructed to be removed in the Instruction Manuals. Doing so may lead to a failure or damage of this product.
CAUTION
Usage
As all parameters return to their initial values after Parameter clear or All parameter clear is performed, the needed parameters for operation of the inverter and this
product must be set again before the operation is started.
To avoid damage to this product due to static electricity, static electricity in your body must be discharged before you touch this product.
To maintain the security (confidentiality, integrity, and availability) of the inverter and the system against unauthorized access, DoS attacks, computer viruses, and
other cyberattacks from external devices via network, take appropriate measures such as firewalls, virtual private networks (VPNs), and antivirus solutions. We
shall have no responsibility or liability for any problems involving inverter trouble and system trouble by DoS attacks, unauthorized access, computer viruses, and
other cyberattacks.
Depending on the network environment, the inverter may not operate as intended due to delays or disconnection in communication. Carefully consider what type of
environment the inverter will be used in and any safety issues related to its use.
Maintenance, inspection and parts replacement
Do not carry out a megger (insulation resistance) test.
Disposal
This product must be treated as industrial waste.

3
General instruction
For clarity, illustrations in this Instruction Manual may be drawn with covers or safety guards removed. Ensure all covers and safety guards are properly installed
prior to starting operation.

4
─CONTENTS ─
1 PRE-OPERATION INSTRUCTIONS 7
1.1 Unpacking and product confirmation............................................................................................................................7
1.1.1 Product confirmation ............................................................................................................................................................. 7
1.1.2 Model name .......................................................................................................................................................................... 8
1.1.3 SERIAL number check.......................................................................................................................................................... 8
1.2 Parts................................................................................................................................................................................10
1.3 CC-Link IE TSN communication specifications..........................................................................................................12
2INSTALLATION 13
2.1 Pre-installation instructions .........................................................................................................................................13
2.2 Installation procedure ...................................................................................................................................................14
3WIRING 18
3.1 System configuration example.....................................................................................................................................18
3.2 Network configuration...................................................................................................................................................19
3.3 Network components ....................................................................................................................................................22
3.3.1 Connection cable ................................................................................................................................................................ 22
3.3.2 Hubs.................................................................................................................................................................................... 22
3.4 Wiring..............................................................................................................................................................................23
3.4.1 Ethernet cable connection .................................................................................................................................................. 23
3.4.2 Precautions ......................................................................................................................................................................... 25
4 CC-LINK IE TSN CONFIGURATION 28
4.1 Procedure .......................................................................................................................................................................28
5 INVERTER SETTING 33
5.1 List of related parameters.............................................................................................................................................33

5
5.2 List of parameters for the CC-Link IE TSN communication function .......................................................................35
5.3 Operation mode setting ................................................................................................................................................36
5.3.1 Operation mode switching and communication startup mode (Pr.79, Pr.340).................................................................... 36
5.4 Operation at communication error occurrence ..........................................................................................................39
5.4.1 Operation selection at communication error occurrence (Pr.500 to Pr.502, Pr.779) .......................................................... 39
5.4.2 Fault and measures ............................................................................................................................................................ 44
5.5 Inverter reset ..................................................................................................................................................................45
5.6 CC-Link IE TSN communication function setting.......................................................................................................48
5.6.1 IP address setting ............................................................................................................................................................... 48
5.6.2 Subnet mask setting (Pr.438 to Pr.441).............................................................................................................................. 51
5.6.3 Selecting the communication speed (Pr.1130) ................................................................................................................... 51
5.6.4 IP filtering function (Ethernet) (Pr.1442 to Pr.1448)............................................................................................................ 52
5.6.5 Frequency command with sign (Pr. 541) ............................................................................................................................ 53
5.6.6 Time synchronization (Pr.1459) .......................................................................................................................................... 55
6 FUNCTION OVERVIEW 56
6.1 Output from the inverter through the network............................................................................................................56
6.2 Input to the inverter through the network ...................................................................................................................57
6.3 Cyclic transmission.......................................................................................................................................................58
6.3.1 Data flow and link device assignment................................................................................................................................. 58
7 I/O SIGNAL 61
7.1 I/O SIGNAL LIST.............................................................................................................................................................61
7.1.1 Remote I/O (64 points fixed) ............................................................................................................................................... 61
7.1.2 Remote register (128 words fixed)...................................................................................................................................... 64
7.2 Details of remote input and output signals.................................................................................................................70
7.2.1 Output signals (master module to inverter (FR-A8NCG)) ................................................................................................... 70
7.2.2 Input signals (inverter (FR-A8NCG) to master module)...................................................................................................... 72
7.3 Details of remote register .............................................................................................................................................74
7.3.1 Remote register (master module to inverter (FR-A8NCG))................................................................................................. 74
7.3.2 Remote register (inverter (FR-A8NCG) to master module)................................................................................................. 76
7.3.3 Instruction codes................................................................................................................................................................. 79

6
7.3.4 Monitor codes ..................................................................................................................................................................... 83
7.4 Torque command / torque limit through CC-Link IE TSN communication (only for the FR-A800 series) ............84
8 PROGRAMMING EXAMPLES 86
8.1 Programming example for reading the inverter status ..............................................................................................91
8.2 Programming example for setting the operation mode .............................................................................................92
8.3 Programming example for setting the operation commands....................................................................................93
8.4 Programming example for monitoring the output frequency....................................................................................94
8.5 Programming example for parameter reading............................................................................................................95
8.6 Programming example for parameter writing .............................................................................................................96
8.7 Programming example for setting the running frequency ........................................................................................97
8.8 Programming example for fault record reading .........................................................................................................99
8.9 Programming example for resetting the inverter at inverter error..........................................................................100
8.10 Instructions ..................................................................................................................................................................101
9 PROTECTIVE FUNCTIONS 103
APPENDIX 104
Appendix1 Instructions for compliance with the EU Directives ......................................................................................104
Appendix2 Instructions for EAC .........................................................................................................................................105
Appendix3 Restricted Use of Hazardous Substances in Electronic and Electrical Products ......................................106
Appendix4 Referenced Standard (Requirement of Chinese standardized law) .............................................................107
Appendix5 How to check specification changes ..............................................................................................................107

PRE-OPERATION INSTRUCTIONS 7
1
1PRE-OPERATION INSTRUCTIONS
1.1 Unpacking and product confirmation
Take the product out of the package, check the product name, and confirm that the product is as you ordered and intact.
This product is a plug-in option made for the FR-A800/F800 series.
1.1.1 Product confirmation
Check the enclosed items.
NOTE
• Ethernet is a registered trademark of Fuji Xerox Corporation in Japan.
Plug-in option
...................................... 1
Mounting screw
(M3 8 mm)
....... 3 (Refer to page 15.)
Spacer
....... 3 (Refer to page 15.)
Communication option
LED display cover
....... 1 (Refer to page 14.)
Earth plate
....... 1 (Refer to page 15.)
RUN ACT
LINK1 ERR
LINK2 L.ERR
X16 X1
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
1 2 3 4
O
N

8PRE-OPERATION INSTRUCTIONS
1.1.2 Model name
 Conforming to IEC 60721-3-3 3C2/3S2
1.1.3 SERIAL number check
The FR-A8NCG can be used with the following models of inverters which have the following SERIAL number. Check the
SERIAL number printed on the rating plate or on the package of the inverter. For information on how to read the SERIAL
number, refer to the inverter Instruction Manual.
FR-A800 series
FR-A800 Plus series
Model Country of origin indication SERIAL number
FR-A820-00046(0.4K) to 04750(90K)
FR-A840-00023(0.4K) to 06830(280K)
FR-A842-07700(315K) to 12120(500K)
FR-A846-00023(0.4K) to 03610(132K)
MADE in Japan 96 or later
MADE in China 97 or later
Model Country of origin indication SERIAL number
FR-A820-00046(0.4K) to 04750(90K)-CRN
FR-A840-00023(0.4K) to 06830(280K)-CRN
FR-A842-07700(315K) to 12120(500K)-CRN
MADE in Japan 96 or later
MADE in China 97 or later
FR-A8NCG-
Symbol Circuit board coating∗1
Without
None
With
60

PRE-OPERATION INSTRUCTIONS 9
1
FR-F800 series
Model Country of origin indication SERIAL number
FR-F820-00046(0.75K) to 04750(110K)
FR-F840-00023(0.75K) to 06830(315K)
FR-F842-07700(355K) to 12120(560K)
FR-F846-00023(0.75K) to 03610(160K)
MADE in Japan 96 or later
MADE in China 97 or later

10 PRE-OPERATION INSTRUCTIONS
1.2 Parts
Symbol Name Description Refer
to page
a Mounting hole Used to fix this product to the inverter by inserting a mounting
screw or a spacer. 15
b Connector for communication (PORT 1) For an Ethernet cable which connects to the network. 23
c Connector for communication (PORT 2) For an Ethernet cable which connects to the network. 23
d Operation status indication LED Indicates operation/communication status of the inverter by
turning ON or blinking. 11
e Board mounted option connector Used to connect this product to the option connector on the
inverter. 15
f Station number switches 1 and 2 Enter the station number. (In the initial setting, "0" is set.) 48
g Switches for manufacturer setting (SW1 and SW2) Not used. -
RUN ACT
LINK1 ERR
LINK2 L.ERR
X16 X1
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
1 2 3 4
O
N
1 2 3 4
O
N
Front view Rear view
(e)
(d)
(a)
(c) (b)
(a)
(a)
(a)
(a)
(f)
(a)
(a)
(g)(g)
(a)

PRE-OPERATION INSTRUCTIONS 11
1
Operation status LEDs
 Also lit in no-communication state.
 This LED blinks when the MAC address and IP address of the inverter match the MAC address and IP address specified by using
engineering software such as GX Works3.
 This LED indicates a communication break between the master station and the FR-A8NCG (due to cable disconnection or breakage,
power-OFF of the master power supply, and reset, etc.)
 " " (duplicate IP address) or " " (IP address error) will appear on the operation panel.
LED
name Description ON Blinking OFF
RUN Operation status Normal operation (normal
5 V internal voltage) - Hardware failure
LINK1 Connector for communication (PORT1)
status Link-up Data transmission in progress Link-down
LINK2 Connector for communication (PORT2)
status Link-up Data transmission in progress Link-down
ACT SLMP command request message
reception status -Inverter identification in progress
Inverter identification
paused
ERR Node failure status Node failure - Normal operation
L.ERR Link error Received data error IP address error Received data normal
LINK1 ERR
L.ERRLINK2
ACT
RUN

12 PRE-OPERATION INSTRUCTIONS
1.3 CC-Link IE TSN communication specifications
The communication specification varies depending on the specification of the master.
Item Description
Transmission speed 1 Gbps/100 Mbps
Minimum synchronization cycle 125.00 μs
CC-Link IE TSN authentication class B
Communication method Time sharing method
Synchronization function Compliant with IEEE 802.1AS and IEEE 1588v2
Maximum number of connected units 121 units (sum of master and slave stations)
Maximum distance between nodes 100 m
Maximum number of branches No upper limit within the same Ethernet system
Topology Line, star, ring, or a combination of line and star
Connection cable
Ethernet cable
(IEEE 802.3 1000BASE-T compliant cable or ANSI/TIA/EIA-568-B (Category 5e) compliant
shielded 4-pair branched cable)
Connector Shielded RJ-45
Node type Slave station
Maximum cyclic size
(of one node)
RX 64 bits
RY 64 bits
RWr 128 words
RWw 128 words

INSTALLATION 13
2
2INSTALLATION
2.1 Pre-installation instructions
Check that the inverter's input power and the control circuit power are both OFF.
CAUTION
Do not install or remove this product while the inverter power is ON. Doing so may damage the inverter or this product.
To avoid damage due to static electricity, static electricity in your body must be discharged before you touch this product.

14 INSTALLATION
2.2 Installation procedure
Installing the communication option LED display cover
(1) Remove the inverter front cover. (Refer to Chapter 2 of the Instruction Manual (Detailed) of the inverter for instructions for
removing the front cover.)
Follow instructions for mounting the communication option LED display cover to the inverter front cover.
(2) Cut off the tabs on the rear of the inverter front cover with nipper, etc. and
remove the separate part to make space for fitting the LED display cover.
(3) Fit the communication option LED display cover to the front side of the
front cover. Align the LED display cover with the LED position on the
circuit board of the option. Push the LED display cover until it is fixed with
the clips.
CAUTION
Take care not to hurt your hand and such with portions left by cutting tabs of the rear of the front cover.
Cut off the tabs with a nipper, etc.
Cut off the tabs with a nipper, etc.
Communication option LED display cover

INSTALLATION 15
2
Installing the option
NOTE
• When a communication option is installed to the FR-A800-E/FR-F800-E series inverter, use the earthing (grounding)
cable supplied with the inverter instead of the earth plate supplied with the communication option. (For details of the
installation method, refer to the Instruction Manual of the inverter.)
(1) Insert three spacers into the mounting holes that will not
be filled with mounting screws (see the diagrams on the
next page to identify the holes).
(2) Fit the board mounted option connector on this product to
the guide of the option connector on the inverter and
insert the plug-in option as far as it goes. (Select option
connector 1 on the inverter.)
(3) Fasten the earth plate to the inverter using the one
mounting screw through the hole on the left side (see the
diagrams on the next page to identify the hole) (tightening
torque 0.33 N∙m to 0.40 N∙m).
(4) Fasten this product to the inverter using the one mounting
screw through the hole on the left side. Fasten the earth
plate and this product to the inverter using the last screw
through the hole on the right side of the earth plate and
this product (tightening torque 0.33 N∙m to 0.40 N∙m). If
the screw holes do not line up, the connector may not be
inserted deep enough. Check the connector.
Spacer
Spacer
Spacer
Earth plate
Option connector
on the inverter
Installation to connector 1

16 INSTALLATION
Spacer
Spacer
Mounting screw
Do not attach the plug-in option to connector 2 or 3.
Mounting screw
Mounting screw Earth plate
Connector 1Connector 2
Spacer
Connector 3
Insertion positions for screws and spacers

INSTALLATION 17
2
NOTE
• When installing/removing the plug-in option, hold the sides of the option. Do not press on the parts on the option circuit
board. Stress applied to the parts by pressing, etc. may cause a failure.
• Be careful not to drop mounting screws during the installation or removal of the plug-in option.
• Attach this product to option connector 1 on the inverter. If it is attached to option connector 2 or 3, the protective
function (E.2 or E.3) is activated and the inverter will not operate.
Even if this product is attached to option connector 1, when the inverter cannot recognize that the option is mounted
due to improper installation, etc., the protective function (E.1) is activated.
• When removing the plug-in option, remove the two screws on either side, and then pull it straight out. Pressure applied
to the option connector and to the option board may break the option.
• Always attach the earth plate because a malfunction due to noises may occur without it.
Mounted position Fault indication
Option connector 1
Option connector 2
Option connector 3

18 WIRING
3WIRING
3.1 System configuration example
(1) Programmable controller side
Mount the "RJ71GN11-T2" type CC-Link IE TSN master/local module on the main or extension base unit having the
programmable controller CPU used as the master station.
(2) Inverter side
Mount the option (FR-A8NCG) on the inverter.
(3) Connect the CC-Link IE TSN programmable controller (master station) to FR-A8NCG with an Ethernet cable.
Inverter
Motor
Power
supply
Inverter
Motor
Power
supply
Up to 120
units can be
connected
RJ71GN11-T2
Slave station
RJ71GN11-T2 type
MELSEC iQ-R CC-Link IE TSN User's
Manual (Startup)
...............SH-082127ENG
MELSEC iQ-R CC-Link IE TSN User's
Manual (Application)
...............SH-082129ENG
Instruction manual regarding
the CC-Link IE TSN master station
Ethernet cable
Master station

WIRING 19
3
3.2 Network configuration
Network topology
The network can be wired into star topology, line topology, and ring topology. A network can consist of a combination of star
and line topologies, but the ring topology cannot be combined with star or line topology.
 Add/remove slave stations one by one. If multiple slave stations are added/removed at a time, all stations on the network will be
reconnected, resulting in a momentarily error in all the stations.
Station number and connection position
Modules can be connected in any order regardless of the station number.
Cascade connection
Up to 20-layer connection is available for the cascade connection.
Replacing CC-Link IE TSN devices
For star topology, slave stations can be replaced without powering off the whole system.
NOTE
• Refer to the Master Module User's Manual for detailed network configurations.
Item Description
Star topology Modules are configured into a star using a switching hub and Ethernet cables. Slave stations can be easily added in a
star topology. Furthermore, data link continues among normally-operating stations in a star topology. 
Line topology Modules are configured into a line with Ethernet cables and without a switching hub. If an error occurs, the station in
error and the stations after that will be disconnected from the network. 
Ring topology Modules are configured into a ring using Ethernet cables. Data link continues among normally-operating stations
without a switching hub. 
